Manual For Rock Island Armory / Armscor .22 Carbine Semi Automatic Rifle M20c 66715g

MANUAL

FOR

RIA 22-CARBINE SEMI AUTOMATIC RIFLE

WARNING READ THE INSTRUCTIONS AND SAFETY PRECAUTIONS IN THIS MANUAL CARE· FULLY BEFORE USING THIS FIREARM. DISCHARGING FIREARMS IN POORLY VENTILATED AREAS, CLEANING FIREARMS OR HANDLING AMMUNITION MAY RESULT IN EXPOSURE TO LEAD AND OTHER SUBSTANCES KNOWN TO CAUSE BIRTH DEFECTS, REPRODUCTIVE HARM AND QTHER SERIOUS PHYSICAL IN.JURY. HAVE ADEQUATE VENTILATION AT ALL TIMES. WASH HANDS THOROUGHLY AFTER EXPOSURE.

Manufactured by ARMS CORPORATION OF THE PHILIPPINES Annscor Avenue, Fortune, Marlkina City 1800,

Philippines Tela. (632)941-6243, (632)941-6244, (632)941-4288 Fax. No.: (632)942-0682 · · Email: info@annscor com.ph

Website: www.annscor.com.ph

This rifle is shipped from the factory fully assembled and ready to shoot after removing the grease from its bore. TO LOAD MAGAZINE : Hold the magazine box firmly with one hand and with the other, insert cartndge at the throat of the magazine. Push the cartridge at the spring follower head down and forward towards the ing notch until it is securely locked. A maximum of len rounds can be loaded. TO ATTACH MAGAZINE : Load the magazine into the magazine box clearance of the receiver-trigger guard housing assembly, push the magazine box inward until it locks in place. TO DETACH MAGAZINE : Press magazine latch and, simultaneously, the magazine will automatically detach and fall. TO MAKE GUN SAFE : Safety button is at .he bottom portion of the trigger guard housing just in front of the trigger guard. Push the left side of the button to move it towards the right side where it will protrude. At this position, the sear is locked-up in the process and gun cannot be fired. TO LOAD CHAMBER : Draw safety on and insert a loaded magazine into the rifle. Retract bolt handle fully to the rear of the receiver slot and release. Allow the bolt to be snapped back under the full force ·of the operating spring. Bolt automatically picks up a cartridge from the magazine and feeds it into the chamber. Do not ease bolt forward. TO FIRE : Be sure gun is pointed at a safe target. Release safety and pull trigger. Pressure from the burning powder opens up bolt, ejects empty shell, and reloads the chamber for the next shot. Pull trigger again. Gun fires as fast as trigger is pulled until magazine is empty. TO UNLOAD WITHOUT FIRING : Draw safety on and release the magazine from guard. Work action several times to remove any cartridge left inside the chamber. Slide bolt handle rearward with your right thumb as far .as it will go and press bolt lock located at bottom part of the trigger guard housing with your right forefinger without releasing bolt handle. Release hold of the bolt handle before releasing the bolt lock. This locks the bolt in place. Inspect the chamber to make sure no cartridge is left. Empty magazine can be placed back if ·desired. To close the bolt, press it rearward so that bolt lock can be easily pressed, and release hold of bolt lock before releasing the bolt. I. DISASSEMBLY A. TAKEDOWN 1. Remove the magazine by pressing the magazine latch. 2. Loosen barrel takedown screw and barrel band and detach the barrel-receiver assembly from the gunstock. B. RECEIVER- BARREL DISASSEMBLY 1. Loosen and detach barrel retainer screws ·- ·'and p"ulrthe barrEH fron'l the receiver. C. RECEIVER- TRIGGER GUARD HOUSING DISASSEMBLY 1. Disassemble the receiver and trigger guard housing by punching out the two receiver cross pins and bolt stop pin.

2.

Pull the bolt handle until it reaches the end of the bolt guide rail. Then pull the bolt out of the receiver. D. TRIGGER GUARD HOUSING DISASSEMBLY

E.

1.

Remove all the pivot pins by punching them out and carefully remove all the small parts (such as trigger assembly, bolt lock, bolt lock spring, ejector, magazine latch, magazine plunger, magazine plunger spring, hammer, hammer strut, hammer spring and hammer bushing) inside the trigger guard housing until only the safety button is left.

2.

To remove safety button, just rotate the button until the safety detent plunger that locks the button in place. is now seated on the button radial surface. lu.tt'lis position , push the button out of the trigger guard housing. Be careful as the safety detent plunger and safety detent plunger spring inside are under compression.

BOLT DISASSEMBLY 1.

Remove the firing pin stop pin by punching it out and pull the firing pin out of its slot but be careful with the firing pin rebound spring because it is too small, it might get lost.

2.

To remove the extractor, just push the extractor plunger flush to its hole using a pin punch or any pointed rod until extractor is free to be pulled out from the bolt. Then remove the extractor plunger and the spring .

II. ASSEMBLY A. BOLT ASSEMBLY 1. At normal position of the bolt, insert the extractor plunger w/ the spring into the extractor plunger hole and push the plunger until its head is flush to the wall of the extractor clearance hole. While the plunger is depressed, insert the extractor to its slot on the bolt with the catch to the front and the hook into the extractor clearance hole and after attaining the right position, release the plunger to hold the extractor in-place. 2. At same position. place the firing pin rebound spring in the slot at the rear of the firing pin rebound spring stop pin.(Note:The firing pin rebound spnng stop pin is permanently attached to the bolt.) Then the firing pin is inserted to its slot on top of the bolt from the rear to compress the spring. 3. Press the firing pin backward until the firing pin oval slot is aligned to the hole on the bolt, then insert the firing pin stop pin. B. TRIGGER GUARD HOUSING ASSEMBLY 1. SAFETY BUITON: Insert the safety detent plunger with the spring into the safety detent plunger hole on the trigger guard housing. Press the safety detent plunger until its tip is flush to the hole surface. While in this position ,insert the safety button into its respective hole from the left side of the trigger guard housing and push it until the safety detent plunger locks it in-place. (Note: Be careful since the sc.fety detent plunger

PART NAME

PART NUMBER

A-SARREL-RECENERASSEMBLY Barrel

Barrel Retainer Barret Retainer Sl::rew (2 pes.) Boll Stop Pin Front Sight Ramp Front Sight Screw Rear Sight Elevator Rear Sight leaf Rear Sight leaf Insert (not shown) Scope Base Adaptor (Optional) Scope Base Adaptor Retainer Sctew(Oplional)(4 pes.) Receiver Receiver Top Set Screw (4 pes.) Receiver Cross Pin Take Down Saew Take Down Screw Washer

10C01 1oCo2 10C03 10C04 140E09FO 15006 2010 2011 2012 10C06A 10C06B 10C07 10C07A 10C08 10C09 10C10

1~

~

OPT10NAl.

B- BOLT ASSEMBLY

Bolt Boll Handle

Extractor Extractor Plunger Extractor Spring Firing Firing Firing Firing

Pin Pin Rebound Spring Pin Rebound Spring Stop Pin Pin Stop Pin Recoil Spring Guide Rod Recoil Spring Guide Rod Bushing Recoil Spring Guide Rod Bushing Retaining Ring

Recoil Spring C - MAGAZINE ASSEMBLY (Not Shown) Magazine cap Magazine cap Nut Magazine Rotor Magazine Rotor Spring Magazine Screw Magazine Shell Magazine Throat D- TRIGGER GUARD HOUSING ASSEMBLY Boll lock Boll lock Spring

Disconnector · Disc:onnector Pivot Pin Ejector Ejector Pivot Pin Hammer Hanmer Bushing (2 pes.) Hanmer Pivot Pin Hanmer Spring Hanmer Strut H.-nmer Strut washer Magazine latch Magazine Latch Pivot Pin Magazine latch Plunger Magazine latch Plunger Spring

Safely Button Safety Detent Plunger Safely Detent Plunger Spring

s..r

Sear Spring

Trigger

Trigger Guard Trigger Pivot Pin Trigger Plunger Trigger Plunger Spring E- GUNSTOCK ASSEMBLY Barrel Band

Barrel Band Screw

Butt Pad Butt Pad Retainer Saew Top Butt Pad Retainer Screw Rear Gunltock

10C11 10C12 10C13 10C14 10C15 10C16 10C17 10C17J 10C18 10C19 10C20 10C20A 10C21 10C22 10C23 10C24 10C25 10C26 10C27 10C28 10C29 10C30 10C31 10¥32 1QG33 10<),41 10CS4 10C35 10C36 10C37 10C36 10C39 10C40 10C41 10C42 10C43 10C44 10C45 10C46 10C47 10C48 10C49 10CSO 10C51 10C52 10C53 '. 10C54 10C55 20C65 20C66

20C67 10C58

OC11

, ., "-.... "1oc17A ' ,"'"10C17 , , "-10C18 "10C16

RIA 22 CARBINE RIFLE
