Shutdown SIS Previous Screen Product: EXCAVATOR Model: 320 EXCAVATOR YBP Configuration: 320 Excavator YBP00001-UP (MACHINE) POWERED BY C7.1 Engine

Troubleshooting 2D, 2D Advanced, and 3D GRADE System for Next Gen Hydraulic Excavators Media Number -M0082989-04

Publication Date -01/09/2018

Date Updated -28/09/2018

i07291145

3D System Components - Test SMCS - 1408; 7610; 7620 The 3D System Components does not have diagnostic codes, but a warring and error text messages appears on the 3D Cat® GRADE display TD-520. This informs the operators and the technician of the system about the malfunction or poor performance. The system will initiate a self-check of all its components, when the 3D system Grade display is powered up for the first time. The status of the components will be displayed after the display complete it startup sequence. Any warning or error messages will be displayed, the system status menu also provides the status of the system components. The licenses menu provides: • The status of the license installed on the R2 ECM and the GNSS Receivers (Right and Left). • Core Bundle status. • The 3D Module license – Design status.

GNSS Receivers The Cat GRADE 2D and 3D System on Excavators will be equipped with two GNSS Receivers (RH/LH) from factory.

https://127.0.0.1/sisweb/sisweb/techdoc/techdoc_print_page.jsp?returnurl=/sisweb/sisweb/... 7/15/2019


Illustration 1

Page 2 of 8

g06234157

GNSS Receiver

Illustration 2

g06195084

GNSS Receiver Status Indicators (1) Power LED light indicator (2) Data Link LED status light indicator (3) Satellite LED status light indicator

When troubleshooting the Global Navigation Satellite System (GNSS) Receiver, observing the indicator LED lights status could be helpful to isolate and troubleshoot any GNSS Receivers warning or error messages.



Page 3 of 8

The LED indicator status when the Left and the Right GNSS Receivers are operating properly is given in Table 1. Table 1 The LED light status when the GNSS Receiver operating properly LED Light

Left GNSS Receiver

Right GNSS Receiver

Power (1)

ON (solid)

ON (Solid)

Data Link (2)

Flashing at 1HZ/Sec

ON (Solid)

Satellite (3)

Flashing Slowly

Flashing slowly

Note: On machine using only one GNSS Receiver, the Left GNSS Receiver section on the Table 1 describes the proper operation of that GNSS Receiver. The LED light status meaning for improper operations is given in Table 2. Table 2 GNSS Receiver LED lights status indication meaning LED Light

OFF

Power LED Status (1)

The Receiver has no power

Data Link Status LED (2)

NO CRM data received or few satellites are available

Satellite No satellites being Status LED tracked (3)

Slow Flash

Flash 1Hz/Sec

Fast flash

ON Solid

Beta test period expired

The Receiver has power

CRM Data Type 0 being processed Tracking four satellite or more

10 HZ CMR data being processed Tracking three satellite Monitor mode or less

When the LED Lights on the GNSS receivers are not indicating proper operations, refer to Table 2 for troubleshooting the system. The LED light status when the RH/LH GNSS Receivers are operating properly is given in Table 3. Table 3 The LED light status when the GNSS Receivers operating properly Left GNSS Receiver

Right GNSS Receiver

The Power LED light is ON (solid)

The Power LED light is ON (solid)

The Data Link LED will flash at 1HZ/Sec

The Data Link LED light is ON (solid)



The Satellite LED will flash slowly

Page 4 of 8

The Satellite LED light will flash slowly

SNRxxx Data Radio

Illustration 3

g06195402

Machine equipped with the SNRxxx Radios

The SNRxxx Radios are fitted with power/data indictor LED light, the flashing pattern of the indictor LED light will provide valuable information for troubleshooting. The LED indicator light flashing pattern meaning is given in Table 4. Table 4 LED Pattern

SNRxxx Radio Status

OFF

No Power to the Radio or the machine key switch is in the off position

N/A

GNSS Providing a position

ON Solid

Power is available, but Radio is not synchronized with the base station.



Irregular Flashing Steady Flashing at rate 1 Hz/Sec

Page 5 of 8

Power is available, the Radio is synchronized, but radio is losing data Power is available, the Radio is synchronized, and receiving data

SNM 940 Cellular Radio

Illustration 4

g06195088

SNM 940 Cellular Radio (Front View) (4) GPS antenna connector (5) Power and GPS activity indicator (6) Cellular antenna connector (7) Electrical harness connector (8) WLAN antenna connector (9) WLAN indicator

Illustration 5

g06195091

SNM 940 Cellular Radio (Rear View) (10) SIM card access door



Page 6 of 8

The SNM940 Radio has two LED indicators lights on the front face of it as shown in Illustration 4. The Green LED Indicator light (5) will provide the power supply and the GNSS status The amber indicator light (9) provides the wireless communications status. The two LED indicator light on the SNM940 Radio provides information of the device status for troubleshooting. The two LED lights flashing status meaning is explained in the below Table 5. Table 5 Green LED

Amber LED

SNM940 Status

ON Solid

OFF

Powered and Initialized

Blink

N/A

GNSS Providing a position

Fast Blink

N/A

No GNSS Signal or poor Position quality

N/A

ON Solid

N/A

Blink

N/A

Slow Blink

WLAN cellular connection

N/A

Fast Blink

Poor or no wireless

OFF

OFF

Low Power standby

Cellular data connection WLAN (Wireless local Area Network) data connection

Blink rating • Slow Blink- 3 second on and 3 Seconds off. • Blink 1 Second on / 1 second off. • Fast blink- 200 milliseconds on / 200 milliseconds off. Table 6 3D System Components CAN communication pinout Component

CAN Hi/Pin

CAN Lo/Pin

Data Radio

4

9

GNSS Receivers

P

L

Body Tilt Sensor

C

D

3D System ECM -R2 EC520 CAN 1

5

6



CAN 2

7

8

CAN 3

9

10

Page 7 of 8

The CAN components CAN troubleshooting section on the diagnostics. Note: When troubleshooting the 3D system Components, refer to the machine system schematics or 3D system components connectors pinout tables. The CAN Data Link or the Electrical Power Supply - Tests can be performed by implementing their troubleshooting steps to troubleshoot the 3D system components, CAN bus, or the power supply circuit.

GNSS Problems There are a large variety of issues that can affect GNSS satellites and the position accuracy of the GRADE system. Many of these issues are due to factors inherent in the technology. These factors should be understood and ed for when operating the GRADE system. Some of the common issues are: • Poor satellite configuration • Loss of satellite signal

Poor Satellite Configuration This value is measured as Position Dilution Of Precision (PDOP). The GRADE display will allow the operator to monitor the PDOP. PDOP should be as low as possible, and will change throughout the day as satellites go through orbits. PDOP will also be affected if there are obstructions that prevent view of the sky such as trees, buildings, and other terrain. PDOP will tend to introduce an offset from desired grade, but PDOP issues can also introduce grade roughness as satellites appear and disappear.

Loss of Satellite Signal Loss of satellite signals eventually results in an error message on the GRADE display. The message indicates that the system no longer has a high precision location established. GRADE requires a RealTime Kinematic (RTK) Fixed type of position solution. If signals are lost, RTK Float or Autonomous modes for the position solution are degenerated. This action will result in poor accuracy. Load Assist and Sequence Assist do not require positions to be calculated from the GNSS receiver. These features use ground speed data generated by the GNSS receiver. The ground speed data can be affected by satellite reception and configuration, but is not as sensitive to those factors as position. Other factors include the following: • Poor satellite configuration affecting grade control accuracy • Poor base station placement



Page 8 of 8

• Loss of signal due to obstructions - use of Global Navigation Satellite System (GLONASS) to improve reception/performance for velocity signal (Auto Ripper and Auto Carry)

Base Station Problems GRADE system relies on a GNSS base station to achieve the required position accuracy while grading. If the base station is not correctly sending position corrections to the machine, the GRADE system may see the following: • "Low GNSS Accuracy" warnings shown on the 3D GRADE system display • A warning on the display that the base station position has moved There are some general guidelines to proper placement of a base station for grade control use. • Maintain good line of sight between the base station and the work site. The data radios used for this data are line of sight only. An elevated position for the base station transmit antenna will provide greater range. • Multipath effects must be avoided. These effects are caused by satellite signals reflecting from surfaces and ad-hoc antennas such as: metal sides of a building, nearby truck trailers, power lines (which can interfere with the signal in several ways), chain link fences, and other obstructions. The base station antenna will perform better at a higher (more elevated) position if clear of the listed reflecting surfaces and ad-hoc antennas. • Maintain as full a view of the sky as possible. The base station relies on keeping view of as many satellites as possible. Any sky obstruction such as buildings, trees, and terrain should be minimized. • Keep the base station away from roads or other areas where there is vehicle traffic. ing vehicles can cause transient multi-path effects that are difficult to troubleshoot. Note: For detailed troubleshooting, the vendor that is providing the base station equipment. Copyright 1993 - 2019 Caterpillar Inc.
