MILLING MACHINE A milling machine is a machine tool that removes metal as the work is fed against a rotating multipoint cutter.

CH/ONTC/PT

MILLING MACHINE (KNEE TYPE)

CH/ONTC/PT

Types of Milling Machine The milling machine are classified according to the general design 1.

Column and Knee Type a) Plain milling machine b) Ram type milling machine c) Universal milling machine d) Omniversal milling machine e) Vertical milling machine CH/ONTC/PT

Types of Milling Machine 2.

Manufacturing or fixed bed type a) Simplex milling machine b) Duplex milling machine c) Triplex milling machine

3.

Planer type

4.

Special type a) Rotary table milling machine b) Drum milling machine c) Planetary milling machine d) Pantograph, tracer controlled milling machine CH/ONTC/PT

HORIZONTAL MILLING MACHINE (KNEE TYPE)

CH/ONTC/PT

HORIZONTAL MILLING MACHINE (KNEE TYPE)

CH/ONTC/PT

HORIZONTAL MILLING MACHINE (KNEE TYPE)

CH/ONTC/PT

HORIZONTAL MILLING MACHINE (KNEE TYPE)

CH/ONTC/PT

HORIZONTAL MILLING MACHINE (KNEE TYPE)

CH/ONTC/PT

HORIZONTAL MILLING MACHINE (KNEE TYPE)

CH/ONTC/PT

HORIZONTAL MILLING MACHINE (KNEE TYPE)

CH/ONTC/PT

VERTICAL MILLING MACHINE (KNEE TYPE)

CH/ONTC/PT

VERTICAL MILLING MACHINE (KNEE TYPE)

CH/ONTC/PT

VERTICAL MILLING MACHINE (KNEE TYPE)

CH/ONTC/PT

VERTICAL MILLING MACHINE (KNEE TYPE)

CH/ONTC/PT

VERTICAL MILLING HEAD

CH/ONTC/PT

VERTICAL MILLING MACHINE (KNEE TYPE)

VIDEO CH/ONTC/PT

EDGE FINDER

VERTICAL MILLING MACHINE (KNEE TYPE)

VIDEO SETTING THE WORKPIECE

CH/ONTC/PT

UNIVERSAL MILLING MACHINE

CH/ONTC/PT

UNIVERSAL MILLING MACHINE

CH/ONTC/PT

UNIVERSAL MILLING MACHINE

CH/ONTC/PT

UNIVERSAL MILLING MACHINE

CH/ONTC/PT

UNIVERSAL MILLING MACHINE

CH/ONTC/PT

OMNIVERSAL MILLING MACHINE

CH/ONTC/PT

PLANNER TYPE MILLING MACHINE

CH/ONTC/PT

PLANNER TYPE MILLING MACHINE

CH/ONTC/PT

SPECIAL PURPOSE MILLING MACHINE 3-PRINCIPLE LINEAR MOVEMENT 2-ANGULAR MOVEMENT

CH/ONTC/PT

HEAVY DUTY DOUBLE HOUSING MILLING MACHNE

CH/ONTC/PT

FOUR SPINDLE TRACE MILLING MACHINE

CH/ONTC/PT

TWO OR THREE AXIS TRASING MACHINE

CH/ONTC/PT

TWIN SPINDLE CNC MILLING MACHINE

CH/ONTC/PT

CNC MILLING MACHINE

CH/ONTC/PT

SPECIAL PURPOSE MACHINE

CH/ONTC/PT

MILLING MACHINE (FEED MECHANISM)

CH/ONTC/PT

MILLING MACHINE ATTACHMENTS 1. Vertical milling attachment 2. Universal milling attachment

3. High speed milling attachment 4. Slotting attachment 5. Universal spiral attachment 6. Rack milling attachment 7. Circular milling attachment

8. Dividing head attachment CH/ONTC/PT

VERTICAL MILLING ATTACHMENT

CH/ONTC/PT

VERTICAL MILLING ATTACHMENT

CH/ONTC/PT

ROTARY TABLE

CH/ONTC/PT

DIVIDING HEAD

CH/ONTC/PT

DIVIDING HEAD

CH/ONTC/PT

INDEXING PLATE

CH/ONTC/PT

INDEXING

CH/ONTC/PT

MILLING MACHINE ATTACHMENTS

CH/ONTC/PT

BORING HEAD

CH/ONTC/PT

BORING HEAD

CH/ONTC/PT

TOOL HOLDING DEVICES 1. 2. 3.

4.

CH/ONTC/PT

Collet Spring collet Adapter Arbor

COLLET

CH/ONTC/PT

SPRING COLLET

CH/ONTC/PT

ARBOR

CH/ONTC/PT

ARBOR

CH/ONTC/PT

ARBOR

CH/ONTC/PT

TAPER USED IN MILLING MACHINE ARBOR

CH/ONTC/PT

WORK HOLDING DEVICES 1.    2.

3. 4. 5.

Vice Plain vice Swivel vise Tool makers universal vice Angle plate Step block, T-bolt & strap clamp Vee block Fixtures

CH/ONTC/PT

PLAIN VICE

CH/ONTC/PT

PLAIN VICE

CH/ONTC/PT

SWIVEL VICE

CH/ONTC/PT

UNIVERSAL VICE

CH/ONTC/PT

UNIVERSAL VICE

CH/ONTC/PT

ANGLE PLATE

CH/ONTC/PT

V- BLOCK

CH/ONTC/PT

SLOT MILLING FIXTURE

CH/ONTC/PT

FIXTURES

CH/ONTC/PT

MILLING PROCESS PERIPERAL MILLING  FACE MILLING 

CH/ONTC/PT

BASIC MILLING METHOD 1. UP MILLING 2. DOWN MILLING

CH/ONTC/PT

MILLING OPERATIONS 1. 2. 3. 4.

5. 6. 7.

8.

CH/ONTC/PT

Plain milling Face milling Side milling Straddle milling Angular milling Gang milling Form milling Profile milling

MILLING OPERATIONS 9. 10. 11. 12. 13. 14. 15.

End milling Saw milling Milling keyways, grooves and slots Gear cutting Helical milling Cam milling Thread milling

CH/ONTC/PT

MILLING OPERATION

CH/ONTC/PT

PLAIN MILLING

CH/ONTC/PT

PLAIN MILLING

CH/ONTC/PT

SLAB MILLNG

CH/ONTC/PT

FACE MILLING

CH/ONTC/PT

FACE MILLING

CH/ONTC/PT

END MILLING

CH/ONTC/PT

END MILLING

CH/ONTC/PT

FORM MILLING (CONVEX)

CH/ONTC/PT

FORM MILLING (CONCAVE)

CH/ONTC/PT

FORM MILLING (CORNER ROUND CUTTER)

CH/ONTC/PT

STRADDLE MILLING

CH/ONTC/PT

GANG MILLING

CH/ONTC/PT

GANG MILLING

CH/ONTC/PT

PROFILE MILLING

CH/ONTC/PT

KEY WAY MILLING

CH/ONTC/PT

T-SLOT CUTTING

CH/ONTC/PT

DOVE TAIL CUTTING

CH/ONTC/PT

SLITTING

CH/ONTC/PT

SLITTING

CH/ONTC/PT

ANGULAR FACE MILLING

CH/ONTC/PT

ANGULAR FACE MILLING

CH/ONTC/PT

HELICAL MILLING

CH/ONTC/PT

GEAR CUTTING

CH/ONTC/PT

THREAD MILLING

CH/ONTC/PT

WALL MILLING

CH/ONTC/PT

SPLINE MILLING

CH/ONTC/PT

VERTICAL MILLING OPERATIONS

CH/ONTC/PT

MILLING CUTTERS Standard milling cutters are classified below. 1. Plain milling cutter a) Light duty plain milling cutter b) Heavy duty plain milling cutter c) Helical plain milling cutter 2. Side milling Cutter a) Plain side milling cutter b) Staggered teeth side milling cutter c) Half side milling cutter d) Inter locking side milling cutter. CH/ONTC/PT

MILLING CUTTERS 3.

4.

5.

Metal slitting saw a) Plain metal slitting saw b) Staggered teeth metal slitting saw Angle milling cutter a) Single angle milling cutter b) Double angle milling cutter End mill a) Taper shank end mill b) Straight shank end mill c) Shell end mill CH/ONTC/PT

MILLING CUTTERS 6. 7. 8. 9.

10.

T -slot milling cutter Woodruff key slot milling cutter Fly cutter Formed cutter a) Convex milling cutter b) Concave milling cutter c) Corner rounding milling cutter d) Gear cutter e) Thread milling cutter Tap and reamer cutter CH/ONTC/PT

LIGHT DUTY PLAIN MILLING CUTTER

oDiameter of the cutter varies from 16 to 160mm oWidth of the cutter is less than 20mm oHelix angle varies from 10 to 25° CH/ONTC/PT

HEAVY DUTY PLAIN MILLING CUTTER (HELICAL)

oDiameter of the cutter varies from 16 to 160mm oWidth of the cutter is less than 20 to 160mm oHelix angle varies from 45 to 60° CH/ONTC/PT

SIDE MILLING CUTTER (PLAIN)

oDiameter of the cutter varies from 50 to 200mm oWidth of the cutter is less than 5 to 32mm

CH/ONTC/PT

SIDE CUTTER

CH/ONTC/PT

STAGGERED TOOTH SIDE MILLING CUTTER

oDiameter of the cutter varies from 50 to 200mm oWidth of the cutter is less than 10 to 45mm

CH/ONTC/PT

HALF SIDE MILLING CUTTER

CH/ONTC/PT

SLITTING CUTTER

oDiameter of the cutter varies from 50 to 200mm oWidth of the cutter is less than 0.8 to 5mm

CH/ONTC/PT

SINGLE ANGLE MILLING CUTTER

oDiameter of the cutter varies from 40 to 150mm oAngle of the cutter available in 30,45,60,65,75,80,84°

CH/ONTC/PT

DOUBLE ANGLE MILLING CUTTER

oDiameter of the cutter varies from 50 to 100mm oWidth of the cutter available from 12 to 36mm oAngle of the cutter available in 50,55,60,65,70,75,80,85,90,95° CH/ONTC/PT

DOUBLE ANGLE MILLING CUTTER

CH/ONTC/PT

ANGLE MILLING CUTTER

CH/ONTC/PT

END MILLING CUTTER

CH/ONTC/PT

END MILLING CUTTER

CH/ONTC/PT

END MILLING CUTTER

CH/ONTC/PT

T-SLOT MILLING CUTTER

T-SLOT CUTTING

CH/ONTC/PT

WOOD ROOF KEYSEAT CUTTER

CH/ONTC/PT

FLY CUTTER

CH/ONTC/PT

FORM CUTTER (CONVEX)

oDiameter of the cutter varies from 50 to 125mm oSemicircle varies from 1.6 to 20mm

CH/ONTC/PT

FORM CUTTER (CONCAVE)

oDiameter of the cutter varies from 50 to 125mm oSemicircle varies from 1.6 to 20mm

CH/ONTC/PT

FORM CUTTER (CORNER ROUND CUTTER)

oDiameter of the cutter varies from 50 to 110mm oSemicircle varies from 1.5 to 20mm

CH/ONTC/PT

KEY WAY MILLING

CH/ONTC/PT

INSERTED TYPE MILLING CUTTER

CH/ONTC/PT

FACING TYPE MILLING CUTTER

CH/ONTC/PT

SHELL MILLING CUTTER

oDiameter of the cutter varies from 40 to 160mm

oWidth of the cutter 32 to 36mm CH/ONTC/PT

SHELL END MILL

CH/ONTC/PT

THREAD CUTTER

CH/ONTC/PT

TREPANNING CUTTER

CH/ONTC/PT

INVOLUTE GEAR TOOTH CUTTER

CH/ONTC/PT

VARIOUS MILLING CUTTERS

CH/ONTC/PT

VARIOUS MILLING CUTTERS

CH/ONTC/PT

MILLED COMPONENT

CH/ONTC/PT

PRECAUTIONS IN USE OF MILLING CUTTER 

The milling machine must be stopped before setting up or removing a workpiece, cutter, or other accessory.



All the chips should be removed from the cutter. A wiping cloth should be placed on the cutter to protect the hands



If cutting teeth are dull, these should be sharpened on a tool and cutter grinder. CH/ONTC/PT

PRECAUTIONS IN USE OF MILLING CUTTER 

Burrs should be removed from the milling cutter with an abrasive stone.



Hole type milling cutters should be stored on a rack. It should be ensure that the teeth do not hit other cutter or metal parts.



The cutter should be rotated in right direction only

CH/ONTC/PT

ELEMENTS OF PLAIN MILLING CUTTER

CH/ONTC/PT

ELEMENTS OF PLAIN MILLING CUTTER

CH/ONTC/PT

NOMENCLATURE OF MILLING CUTTER

CH/ONTC/PT

RAKE ANGLES OF MILLING CUTTER

CH/ONTC/PT

FACE MILLING CUTTER

CH/ONTC/PT

INFLUENCE OF RAKE ANGLE

CH/ONTC/PT

MACHINING TIME CALCULATION FOR

MILLING MACHINE

CH/ONTC/PT

MACHINING TIME CALCULATION

CH/ONTC/PT

MACHINING TIME CALCULATION 

In milling machine for machining time calculation the approach length formula will be changed depends on the cutter used.



Approach length for plain milling cutter Approach length for face milling cutter



CH/ONTC/PT

MACHINING TIME CALCULATION L MACHININGTIME (Tm)  Sz  Z  n TOOLLENGTHTRAVEL  l  la  lx Where, l = length of the work piece in mm. la = Approach distance in mm. lx = over run in mm (Appximately – 6mm).

CH/ONTC/PT

Approach length for plain milling cutter

CH/ONTC/PT

Approach length for plain milling cutter 2

D D  A     B 2 2  or

2

2

A  B( D  B) Where, A  TheApproachinMM B  TheDepthOf TheCutinMM D  TheDiameterOf TheCutterinMM CH/ONTC/PT

Approach length for face milling cutter D A  C 2 Where, A  TheApproachLengthinMM D  TheDiameterOfTheCutterinMM D 2 B 2 C  ( ) ( ) 2 2 B  TheWidthOf TheWorkinMM CH/ONTC/PT

MACHINING TIME CALCULATION 

FEED : It is the distance that the work advances in the time when the cutter turns through one complete revolution. The feed is expressed in millimeter per revolution.

Sm = N x Srev = (Sz x Z) x N Where, Sm = Feed per minute. Srev = Feed per cutter revolution. Sz = Feed per tooth Z = number of teeth in the cutter. n = the cutter speed in r.p.m CH/ONTC/PT

MACHINING TIME CALCULATION 

CUTTING SPEED : The speed of cutter is its peripheral linear speed resulting from rotation. It is expressed in meters per minute. v

Where,

πdn m/min 1000

V = Cutting speed in m/min. D = Cutter diameter in mm. N = cutter speed in rpm. CH/ONTC/PT

MACHINING DATA FOR MILLING

HSS WORK MTRL.

HARDNESS (BHN)

CAST STEEL

140 - 240

CARBIDE

SPEED (m/min)

FEED (mm/rev)

SPEED (m/min)

FEED (mm/rev)

16

0.15

50

0.18

CH/ONTC/PT
