GBTS ABIS over IP configuration Guide

GBTS ABIS Over IP • There are Two way for GBTS ABIS over IP configuration • Flash Drive • SMT

Abis over IP configuration by using Flash Drive • Need USB flash drive and BTS configuration File. • Copy the BTS configuration in flash drive. • Plug-in USB Flash drive in GTMU board.

ABIS over IP configuration by using SMT • Connect laptop to the BTS. • As per provided plan Configure the BTS by using SMT software

Basic Steps for start the configuration • Check the BTS Hardware and Powered ON. • Check the CWO status with CWO engineer, the port for BTS should be defined in the transmission side. • Ping test from RTN or GPON to the BSC gateway is OK. • If the transmission is ping able, go to the site and connect the LAN cable between the transmission FE1 port and GTMU FE0 port.

USB Flash Drive for GBTS Commissioning • Plug the USB flash drive into the USB port of the computer. • Create a folder named BTS3900 GSM in the USB flash drive. • create a folder named Site0 (the name is the site name ) in the folder BTS3900 GSM. • Copy the TransCfg.ini file to the folder ,you can get the TransCfg.ini file from the BSC integration Team.

• Check the status of the GBTS, make sure the GTMU board is power on and working normal. • Put the USB flash into the USB port of the GTMU.

• Do not remove the USB flash drive during the period from plugging in the flash drive to the duration of normal operation of the base station. Otherwise, the file load fails. • Check with BSC integration team whether the BSC can Ping to the BTS IP.

Use SMT for GBTS Commissioning • Set your computer IP address like below: IP address is 192.168.0.77,subnet mask is 255.255.255.0

• Use an Ethernet cable to connect the BTS and the laptop. One end is connected to the ETH port on the GTMU of the main cabinet, and the other end is connected to the Ethernet port on the a laptop. • Run the SMT software.

• Obtaining the Site Management Rights by click the “Site Management Right” and then click “Get”.

• In the left pane of the SMT System window, select Site. In the right pane of the window, double-click IP over FE Static IP and Confirm the static IP network, and then click OK.

Attribute to be set in BTS BTS Type

Controller Card

Type of Integration

3900L

GTMU

Configuring IP's from Script

Integration Steps Commands 1

Enable Static IP

2

Enter BTS IP & Mask

3

Enter BSC IP & Mask

4

Enter VLAN

5

Enter Router 1 IP's

6

Enter Router 2 IP's

7

Enter Router 3 Ip's

8

Qauery &

9

Check Ping

•

•

In this dialog box, set the IP addresses of the BTS and BSC and other related parameters step by step like below, the parameters in the red box are the same to all the sites, the parameters in the yellow box are different to different sites. Click Config Para to complete the settings of the IP addresses and VLAN parameters.

•

Click the Config Router tab. On the Config Router tab page, set the route of the BTS, as shown in the below snapshot.

• Every site we need add 3 router(1,2,3), first one goes to BSC DEVIP, •

other one goes to IPCLK1,the last one goes to IPCLK2. Add the router to BSC like below:

•

Add the router to IPCLK1 like below:

• •

Add the router to IPCLK2 like below: Click Config Para to complete the setting of the route

• •

Click the Query tab. On the Query tab page, click Query to query the static IP addresses Make sure all the parameters are correct according to the IP design.

•

Click the “Board” in the left ,then click “Board Management”, then right click GTMU board, choose “Board Reset” to reset the site.

• •

After the site reset, you should the BSC integration team and check whether they can PING to the BTS IP, if the site is UP, you can see the board is OK. If the site is UP, also you should check with the BSC integration Team whether there are any alarms in the BTS and Clear all the alarms.
