3 Types Of Welding 3o615y

1.0

Arc Welding Arc welding is a process utilizing the concentrated heat of an electric arc to metal by fusion of the parent metal and the addition of metal to t usually provided by a consumable electrode. Either direct or alternating current may be used for the arc, depending upon the material to be welded and the electrode used. 1.1

Electroslag Welding Electroslag

Welding

(ESW)

deposits the weld metal into the weld cavity between the two plates to be ed. This space is enclosed by water cooled copper dams

or

shoes

to

prevent

molten slag from running off. The weld metal is produced from a filler wire that forms an initial arc with the workpiece until a sufficient pool of liquid metal is formed to use the electrical resistance of the molten slag. This process requires special equipment used primarily for horizontal welds of very large plates up to 36 inches or more by welding them in one as in large machinery and nuclear reactor vessels. There are also variations of ESW where shielding is provided by an appropriate gas and a continuous arc is used to provide weld metal. These are termed Electrogas Welding or EGW machines. 1.2

Fluxed-Core Arc-Welding Fluxed-Core Arc-Welding (FCAW) uses a tubular electrode filled with flux that is much less brittle than the coatings on SMAW

electrodes while preserving most

of

its

potential alloying benefits. The emissive fluxes used shield the weld arc from surrounding air, or shielding gases are used and nonemissive fluxes are employed. The higher weld-metal deposition rate of FCAW over GMAW (Gas Metal Arc Welding) has led to its popularity in ing relatively heavy sections of 1" or thicker. Another major advantage of FCAW is the ease with which specific weld-metal alloy chemistries can be developed. The process is also easily automated, especially with the new robotic systems. 1.3

Gas Metal-Arc Welding Gas Metal-Arc Welding (GMAW), also called Metal Inert Gas (MIG) welding, shields the weld zone with an external gas such as argon, helium, carbon dioxide, or gas mixtures. Deoxidizers present in the electrode can completely prevent oxidation in the weld puddle, making multiple weld layers possible at the t. GMAW is a relatively simple, versatile, and economical welding apparatus to use. This is due to the factor of 2 welding productivity

over

SMAW

processes.

In

addition,

the

temperatures involved in GMAW are relatively low and are therefore suitable for thin sheet and sections less than ¼ inch.

GMAW may be easily automated, and lends itself readily to robotic

methods.

It

has

virtually replaced SMAW in present-day

welding

operations

in

manufacturing plants.

1.4

Gas Tungsten-Arc Welding Gas Tungsten-Arc Welding (GTAW), also known as Tungsten Inert Gas or TIG welding, uses tungsten electrodes as one pole of the arc to generate the heat required. The gas is usually argon, helium, or a mixture of the two. A filler wire provides the molten material if necessary. The GTAW process is especially suited to thin materials producing welds of excellent quality and surface finish. Filler wire is usually selected to be similar in composition to the materials being welded. Atomic Hydrogen Welding (AHW) is similar and uses an arc between two tungsten or carbon electrodes in a shielding atmosphere of hydrogen. Therefore, the work piece is not part of the electrical circuit.

1.5

Plasma Arc Welding

Plasma Arc Welding (PAW) uses electrodes and ionized gases to generate an extremely hot plasma jet aimed at the weld area. The higher energy concentration is useful for deeper and narrower welds and increased welding speed.

1.6

Shielded-Metal

Arc

Metal

Arc

Welding

Welding (SMAW)

is

one of the oldest, simplest, and most versatile arc welding processes. The arc is generated by touching the tip of a coated electrode to the workpiece and withdrawing it quickly to an appropriate distance to maintain the arc. The heat generated melts a portion of the electrode tip, its coating, and the base metal in the immediate area. The weld forms out of the

alloy

materials

of

these

as

they

solidify in the weld area. Slag formed to protect against

the

weld forming

oxides, nitrides, and inclusions must be removed after each to ensure a good weld. The SMAW process has the advantage of being relatively simple, only requiring a power supply, power cables, and

electrode holder. It is commonly used in construction, shipbuilding, and pipeline work, especially in remote locations. 1.7

Submerged Arc Welding Submerged Arc Welding (SAW) shields the weld arc using a granular flux fed into the weld zone forming a thick layer that completely covers the molten zone and prevents spatter and sparks. It also acts as a thermal insulator, permitting deeper heat penetration. The process is obviously limited to welding in a horizontal position and is widely used for relatively high speed sheet or plate steel welding in either automatic or semiautomatic configurations. The flux can be recovered, treated, and reused. Submerged Arc Welding provides very high welding productivity....4-10 times as much as the Shielded Metal Arc Welding process.

2.0

MIG Welding MIG (Metal Inert Gas) or as it even is called GMAW (Gas Metal Arc Welding) uses an aluminium alloy wire as a combined electrode and filler

material. The filler metal is added continuously and welding without filler-material possible.

is

Since

therefore all

not

welding

parameters are controlled by the welding machine, the process is also

called semi-automatic welding.

The

MIG-process uses a direct current

power source, with the electrode positive (DC, EP). By using a positive electrode, the oxide layer is efficiently removed from the aluminium surface, which is essential for avoiding lack of fusion and oxide inclusions. The metal is transferred from the filler wire to the

weld bead by magnetic forces as small droplets spray transfer. This gives a deep penetration capability to the process and makes it possible to weld in all positions. It is important for the quality of the weld that the spray transfer is obtained. There are two different MIG-welding processes, conventional MIG and pulsed MIG: 2.1

Conventional Conventional MIG uses a constant voltage DC power source. Since the spray transfer is limited to a certain range of arc current, the conventional MIG process has a lower limit of arc current (or heat input). This also limits the application of conventional MIG to weld material thicknesses above 4 mm. Below 6 mm it is recommended that backing is used to control the weld bead.

2.2

Pulse Pulsed MIG uses a DC power source with superimposed periodic pulses of high current. During the low current level the arc is maintained without metal transfer. During the high current pulses the metal is transferred in the spray mode. In this way pulsed MIG is possible to operate with lower average current and heat input compared to conventional MIG. This makes it possible to weld thinner sections and weld much more easily in difficult welding positions.

3.0

TIG Welding TIG-welding (Tungsten Inert Gas) or GTAW-welding (Gas Tungsten Arc Welding) uses a permanent non-melting electrode made of tungsten. Filler metal is added separately, which makes the process very flexible. It is also possible to weld without filler material.

The most used power source for TIG-welding generates alternating current (AC). Direct current can be used, but due to high heat generation on the tungsten electrode when DC-EP (electrode positive) welding, that particular polarity is not feasible. In some cases DC-EN (electrode negative) is used, however, this requires special attention before welding, due to the arc's poor oxide cleaning action. AC TIG-welding usually uses argon as a shielding gas. The process is a multipurpose process, which offers the great flexibility. By changing the diameter of the tungsten electrode, welding may be performed with a wide range of heat input at different thicknesses. AC TIG-welding is possible with thicknesses down to about 0,5 mm. For larger thicknesses, > 5 mm, AC TIG-welding is less economical compared to MIG-welding due to lower welding speed. DC TIG-welding with electrode negative is used for welding thicknesses above 4 mm. The negative electrode gives a poor oxide cleaning compared to AC-TIG and MIG, and special cleaning of t surfaces is necessary. The process usually uses helium shielding gas. This gives a better penetration in thicker sections. DC TIGwelding is applicable for welding thicknesses in the range 0,3 - 12 mm. More and more popular is also pulsed DC TIG-welding, which makes it possible to weld uniform welds with deeper penetration at the same heat input. Pulse frequency is usually in the range 1 - 10 Hz.
