AUTOMATIC - NAG1 SERVICE INFORMATION

21 - 303

12. Install the electrohydraulic control module (12) onto the shift plate (13). 13. Bend the retaining lug on the stiffening rib on the transmission oil temperature sensor to retain the electrohydraulic control module. 14. Install the solenoid valves (6 - 11) into the shift plate (13). Note: Check the O-rings on the solenoid valves for damage and replace if necessary. 15. Install the leaf springs (5). 16. Install the bolts (3, 4). Tighten the bolts to 8 N·m (71 in. lbs.). Note: Pay attention to the different lengths of the bolts. 17. Install the solenoid caps (1, 2). 18. Install the electrohydraulic unit into the vehicle. (Refer to 21 - TRANSMISSION/TRANSAXLE/AUTOMATIC NAG1/ELECTROHYDRAULIC UNIT - INSTALLATION).

INSTALLATION 1. Position the electrohydraulic unit in the transmission housing. 2. Insert the selector valve (1) in the driver of the detent plate (2). When installing the electrohydraulic control module in the transmission housing, the plastic part of the selector valve (1) must engage in the driver of the detent plate (2).

21 - 304

AUTOMATIC - NAG1 SERVICE INFORMATION

3. Install the bolts (3) and tighten to 8 N·m (71 in. lbs.). 4. Install a new oil filter.. 5. Install the oil pan (5) and torque the oil pan bolts to 8 N·m (71 in. lbs.). 6. Install the oil drain plug (8) with a new drain plug gasket (9). Torque the drain plug to 20 N·m (177 in. lbs.). 7. Install the guide bushing (12) into the transmission housing and install the bolt (11) to hold the guide bushing in place.

8. Check the O-ring on the plug connector (1), and replace if necessary. 9. Install the plug connector (1) into the guide bushing (2). Turn the bayonet lock of the guide bushing (2) clockwise to connect plug connector (1).
