 Codd rule is a set of 13 rules number 0-12 proposed by

Edgar F. Codd. A  OracleTM database referred to OracleTM RDBMS or simply

as object –relational database management systems produced and marketed by OracleTM Corporation.

 The system must qualify as relational, as a database, and

as a management system. For a system to qualify as a relational database management system (RDBMS), that system must use its relational facilities (exclusively) to manage the database. With adherence to the other rules, oracle adheres to this rule.

All data should be presented to the in tabular form Implementation of Oracle.  All information in an Oracle database including table names, column names are represented by values in tables.  Oracle satisfies complies fully with this rule by storing all values in a table. This simple view of data speeds design and learning. productivity is improved since knowledge of only one language is necessary to access all data such as description of the table and attribute definitions, integrity constraints. Action can be taken when the constraints are violated. Access to data can be restricted. All these information are also stored in tables.

 Each item of data should be accessible without ambiguity.

In a purely relational database such as oracle this is accomplished through a combination of the table name, primary key and column name. This rule cannot be met unless every table both has a primary key and the uniqueness of that key is rigorously enforced. Pointers were a key feature of earlier database management software and most master or detail navigation relied on them. In the relational model pointers simply do not meet the guaranteed access rule and are not part of the scheme

A field should be allowed to remain empty. This involves the of a Null value, which is distinct from an empty string or a number with a value of zero. Of course, this can't apply to primary keys. In addition, most database implementations the concept of a nunnull field constraint that prevents null values in a specific table column. Null values must be uniformly treated as "missing information," not as empty strings, blanks, or zeros.

 Oracle provides for this rule as of null value by

handling records that have unknown or inapplicable values in a pre-defined fashion. Also by distinguishing between zeros, blanks and nulls in the records hand handles such values in a consistent manner that produces correct answers, comparisons and calculations. Through the set of rules for handling nulls, s can distinguish results of the queries that involve nulls, zeros and blanks. Even though the rule doesn’t specify what should be done in the case of nulls it specifies that there should be a consistent policy in the treatment of nulls.

A relational database must provide access to its structure through the same tools that are used to access the data. (This is usually accomplished by storing the structure definition within special system tables.) Oracle satisfies this rule.  Has "hidden" tables that provides some access to the data structure

Database must at least one clearly defined language that includes functionality for data definition and manipulation. This rule is ed in oracle All commercial relational databases use forms of the standard SQL (Structured Query Language) as their ed comprehensive language.  Oracle uses SQL to change data definition, data manipulation, data integrity and database transaction control.

Here each rule should the same full range of data manipulation whose direct access to a table is available  Oracle does not this. They do provide some

limited view-updating for simple views. Oracle provides the facility to programmatically allow view updating via "instead-of" triggers.  In practice, providing update and delete access to logical views is difficult and is not fully ed by any current database.

 A single operation must be able to retrieve, insert, update, or delete

data.  Data can be retrieved from a relational database in sets constructed of data from multiple rows and/or multiple tables. This rule states that insert, update, and delete operations should be ed for any retrievable set rather than just for a single row in a single table. High-level Insert, Update, and Delete: Data can be retrieved from a relational database in sets constructed of data from multiple rows and/or multiple tables. (This rule states that insert, update, and delete operations should be ed for any retrievable set rather than just for a single row in a single table.) It does provide some limited view-updating for simple views. Oracle provides the facility to programmatically allow view updating via "instead-of" triggers.  Oracle does not this role because its termed difficult

It states that the (the person coding the sql statements) is isolated from the physical method of storage and retrieval of information from a database.  This rule is ed in oracle. For query and update operations oracle completely meets this requirement, allowing sql to be written with no knowlegde whatever of the underlying software or hardware. One of the great strengths of oracle over the years has been the ease with which an application can be moved from one server technology to another without any change whatever.

States that the viewing of data by a should not change when the table structure of database changes  This rule is not ed in oracle because oracle relies

on strong ties between the view of the data and the actual structure of the underlying tables

The database language (like Oracle) should constraints on input that maintain database . -the following is how Oracle follows the Integrity independence rule i Proxy Authentication in Oracle8i.  The OCI proxy authentication feature was initially released in Oracle8i.  It enabled a database client to set up, within a single database connection, a number of "lightweight" sessions, each of which is associated with a different database .

Proxy Authentication in Oracle9i.  In Oracle9i proxy authentication, authentication of the client is ed in the following ways:  Through a database that is given when the use accesses Oracle9i proxy authentication  Through a distinguished name or X.509 certificate  In Oracle9i this feature is designed so that a specific middle tier can be restricted to acting on behalf of a specified set of s.  Once the middle tier has authenticated itself to the database, it can establish a lightweight session on behalf of those s without submitting -specific authentication information such as s. ii.

Authentication and Access Controls in Oracle9i  Oracle9i provides authentication to ensure that the identity of a , host or client is correctly known. To access a database, a must supply a valid name and associated of the database. These prevent unauthorized use. Oracle9i also provides authorization, to ensure that a , program, or process receives the appropriate privileges to access an object or set of objects  To prevent unauthorized use of a database name, Oracle provides validation by several different methods for normal database s. You can perform authentication by:  The operating system  The associated Oracle database

 Further, Oracle Enterprise Edition s

additional modes of authentication:  The Oracle database of a middle-tier application that performs transactions on behalf of the .  The Secure Socket Layer (SSL) protocol.  A network service (through Oracle Advanced Security).  For simplicity, one method is usually used to authenticate all s of a database. However, Oracle permits use of all methods within the same database instance.

A should be totally unaware of whether or not the database is distributed (whether parts of the database exist in multiple locations). In order for Oracle to achieve this rule, it utilizes the following system:Distributed Warehouse Management System  The Oracle Warehouse Management System (WMS) is an integral

part of the Oracle E-Business Suite comprised of transaction source systems, like Oracle Purchasing and Oracle Order Management, and execution systems, like WMS, residing and operating within the same instance.  This integrated solution eliminates the need for reference and transaction data integrations which are typically required when WMS is implemented as a "bolted-on" solution (that is, installed independent from the E-Business Suite).

Features of the Distributed Warehouse Management System  Distributed WMS can integrate with any host system including legacy systems, other ERP systems like SAP, or another Oracle ERP system.  Distributed system is an independent WMS solution with minimal setup requirements. It s all the routine warehouse and inventory functions currently available in the E-Business suite.  Distributed system is a pure execution system without any costing or ing implications of material transactions. The financial implications of the transactions are maintained in the host system.  The distributed system executes the transactions and sends the confirmations back to the host system.

 Any change management ed for the

transaction documents like sales orders and purchase orders in the E-Business Suite is ed in the Distributed WMS system.  Distributed WMS solution can send inventory adjustments or current on-hand inventory snapshots to the host system as needed.  The profile option WMS: Deployment Mode is set to identify the instance as distributed.

Setting Up the Distributed Warehouse Management System  Oracle Distributed Warehouse Management

System (Architecture and Solution Overview)  Oracle Distributed Warehouse Management System (Setup Document)  Oracle Distributed Warehouse Management System (Technical Implementation)  Oracle Distributed Warehouse Management System (Integration)  Oracle Distributed Warehouse Management System Post Patch Application Steps  EBS 11i10 to Distributed WMS Integration paper

Basically means that it should be possible to do everything you want with the DBMS using the standard set of abstract commands, e.g. SQL. It means that in certain situations you don't have to resort to "special" code to do what you want - in fact, that no such facility exists.  The advantage of implementing rule 12 properly is that the DBMS's underlying physical implementation is independent of the interface, and may be changed at will.  For example, in Oracle I can write "hints" in SQL code that request the DBMS to run a query in a particular way. If Oracle changes the way it does things, the idea is that my code will still run without error (hopefully, better).

 Oracles databases tends to be backwards compatible.  Very new release contains a documentation that is

friendly to learn those new features.  Offers a powerful combination of technology and comprehensive, pre integrated business apps, including key functionality built specifically for particular organizations i.e. banks.  With new release s have better capabilities with improved performance than previous versions while still maintaining old features in 8i there was Java compatibility and large database partitioning, in 9i the features were maintained while new features were added to help the DBA handle change database configuration.  Oracle responds very well with demanding environment. It es the acid test, important in ensuring integrity of data.

 It s atomicity thus result of transactions are either 







committed or rolled back. It’s consistent. Database is transformed from one valid state to another. Illegal transaction not allowed and if integrity constraints can’t be satisfied transaction is rolled back. Isolation .result of a transaction are invisible to other transaction until the transaction is complete thus increasing the security on data. Durability .Once completed the result of transaction are permanent and survive future system and media failures thus ensures maintenance and protection of data. Oracle 10g has flashback technology for restoring data lost through accidental transaction or hardware failure.

 Price, the single most expensive Enterprise Database

Software on the market (but for a reason, it is the best).  Bulky software bundles. Most installations (sometimes 510 on one server) have similar tree structures, all containing the same java/Perl /etc files, scripts. Most of them have not been changed since 9i.  High performance system requirements.  Takes longer to learn and is not that simple.

 In summary, most of Codd's ideas have been

implemented, but not all - there is a new DBMS in development currently that purports to all of them, including full view updateability. It remains to be seen whether it becomes a commercial success.
