Altecnic Expansion Vessel Guide 4i5k26

| 1.25

Sealed Systems Sealed Systems Sealed primary central heating systems are the most commonly used form of heating system throughout Europe and the rest of the developed world. Sealed central heating systems should not be confused with unvented mains pressure hot water systems, which apply only to the secondary hot water supply side of a combined heating and hot water system. From an installers viewpoint, therefore, there is no requirement to be ed or to notify any authority when fitting a sealed primary heating system. The ease of installation of a sealed system makes it particularly attractive to the installer, eliminating the feed and expansion tank and associated pipework, and thus reducing the risk of corrosion and noise in the system.

Heating vessel sizing guide Boiler output

Vessel size per system static head

kw

btu/hr

5 m (Litre)

10 m (Litre) 15 m (Litre)

10

34120

8

12

18

15

51180

12

18

24

20

68240

12

18

35

25

85300

18

25

35

35

119421

25

35

50

40

136480

35

35

80

0.5 bar

1.0 bar

1.5 bar



vessel pre-charge (set by installer)

Also refer to the Altecnic expansion vessel sizing calculator

FREE

on request.

www.altecnic.co.uk

Advantages can be summarised as follows; • System flexibility due to component siting alternatives. • Cost savings due to considerably reduced installation time. • No feed and expansion tank hence avoiding over pumping problems, risk of freezing up etc. • Longer life due to virtual elimination of corrosion problems. • Noise reduction due to higher system pressure, boiler noise (localised boiling) is significantly reduced or eliminated. • Low maintenance costs as equipment is virtually maintenance free, other than for periodic operational checks.

Essential Components and Location Note: Domestic sealed heating systems should take due of the following British Standards: BS 7074: Part 1: 1998 – “Application, selection and installation of expansion vessels and ancillary equipment for sealed water sytems – Part 1. Code of practice for domestic heating and water supply”. BS EN 12828: 2003 – “Heating systems in buildings – Design for water based heating systems”. The essential components for a sealed system are: • Diaphragm Expansion Vessel (complying with BE EN 13831: 2007 – “Closed expansion vessels with built in diaphragms for installation in water”) • Safety Valve (pressure relief valve) • Pressure Gauge • Filling Point (means for system filling, make-up and venting).

Altecnic Ltd - Caleffi group

1.26 | Sealed Systems - Robokits

Robokit extra sealed system - Nitrogen filled CA-900025

Ref. no

Vessel (Litre) Description

CA-900008

8

8 litre robokit extra

CA-900012

12

12 litre robokit extra

CA-900018

18

18 litre robokit extra

CA-900025

25

25 litre robokit extra

CA-900035

35

35 litre robokit extra

CA-900050

50

50 litre with legs robokit extra

CA-900080

80

80 litre robokit extra

NEW IMPROVED

• Sealed system kit comprising: expansion vessel, filling loop, safety relief valve complete with gauge, mounting bracket to suit up to a 25 litre capacity and manifold fitting

Robokit sealed system kits & brackets CA-900000

Ref. no

Description

CA-900000

½˝ sealed system kit (for 8 litre to 80 litre) with tapered vessel connection

CA-900001

¾˝ sealed system kit with tapered vessel connection

CA-100085

½˝ sealed system kit with remote SRV (SRV remote from robokit)

CA-100000

½˝ sealed system kit without bracket

• Sealed system filling kit comprising: filling loop, safety relief valve complete with gauge, mounting bracket to suit up to 25 litre capacity and manifold fitting • Water regulations G24.1 and 24.2 compliant filling loop

Condensate/siphon trap ALT-SBP001

Ref. no

Description

ALT-SBP001

Retro Fit Externally Mounting Boiler Condensate/siphon Trap & Wall Bracket c/w inlet connection and discharge to suit solvent welded overflow pipe

NE800010

Condensate/siphon Trap only

LU-210580A01

Wall bracket only

• Size of Condensate Trap Size 85mm (W) x 100mm (H) x 45mm (D) • Max Ambient Temp 65°C • 75mm water seal NE800010

LU-210580A01

To place an order T: 01785 218222 (Trade sales) T: 01785 218208 (OEM sales) E: [email protected]

Sealed Systems - Accessories | 1.27 Components for sealed system Ref. no

Description

502649

15mm automatic air vent

312430

½˝ M x F 3 bar safety relief valve

311430

½˝ F x F 3 bar safety relief valve

311530

¾˝ F x F 3 bar safety relief valve

313430

½˝ F x F 3 bar safety relief valve with pressure gauge

A314437 CST

½˝ M x F 3 bar safety relief valve with gauge port only

313530

¾˝ F x F 3 bar safety relief valve with gauge

A312401 CST

½˝ 3 bar safety relief valve

A312438 CST

½˝ pushfit x ½˝ M 3 bar safety relief valve

WI-557204

Pressure gauge for robokit

303915

Robo-quattro - 4 way manifold and double check valve

RS-MB

Vessel mounting bracket 8 litre - 25 litre heating vessels

YU-JQAL324

Quattro 8 - 80 litre heating vessels

YU-JQAL326

Quattro 80+ litre heating vessels

A314437 CST

RS-MB

Filling loops Ref. no

Description

CA-300001

Robofil fill loop complete with PRV

CA-300606

Ecofil plus filling loop (G24 approved)

CA-300611

Ecofil plus filling loop (G24 approved) with caps and collars

CA-3006MI

Tidy loop filling loop (WRAS approved)

CA-3006MICA

Tidy loop Plus filling loop with caps and collars (WRAS approved)

YU-JQAL304

Cap and collar for filling loop

JI-300608

Robofil (poly bag - as with robokit) *

• Used to fill sealed systems from the mains cold water • Approved flexible hoses complete with check valves • Comply with water regulations and use WRAS approved components * Water regulation G24.1 and 24.2 compliant where indicated

CA-300606

NEW IMPROVED

CA-3006MICA

Digital hand held pressure gauge Ref. no

Description

PVADG

Digital hand held pressure gauge

www.altecnic.co.uk

PVADG

Altecnic Ltd - Caleffi group

1.28 |

Expansion Vessels

The benefits of Nitrogen filled vessels Nitrogen, a dry inert gas used in the Reflex range of expansion vessels, improves the vessel’s life span by reducing corrosion inside the vessel, and prevents loss of pre-charge pressure. Nitrogen permeates through rubber slower than oxygen, is far less reactive to both steel and aluminium and does not degrade rubber prolonging the membrane life. Oxygen in compressed air permeates through the membrane, thus reducing the pre-charge pressure over time. During normal operation,

oxygen oxides the membrane in the vessel, causing under-inflation, but dry Nitrogen will maintain proper inflation pressure and will not corrode the inside of the vessel. It’s recognised in the industry that oxidative aging is one of the primary causes of decreased vessel life. Tests have shown that if vessels are inflated with nitrogen, there is a significant reduction in failure and increased vessel life.

To place an order T: 01785 218222 (Trade sales) T: 01785 218208 (OEM sales) E: [email protected]

| 1.29

Vessels Heating vessel sizing guide Also refer to the Altecnic expansion vessel sizing calculator

FREE

on request.

Boiler output

Vessel size per system static head

kw

btu/hr

5 m (Litre)

10 m (Litre) 15 m (Litre)

10

34120

8

12

18

15

51180

12

18

24

20

68240

12

18

35

25

85300

18

25

35

35

119421

25

35

50

40

136480

35

35

80

0.5 bar

1.0 bar

1.5 bar



Vessel pre-charge (set by installer)

Heating expansion vessels sizing Heating vessel calculation V=

exC

SRVSRV

Static Static Head Head

[1 - (Pprec + 0.3 + 1) ÷ (Pmax +1)]

V = Vessel size e = Coefficient of water expansion C = System volume in litres Pmax = System pressure in Bar Pprec = Precharge pressure in Bar

Potable water expansion vessels sizing Potable water vessel calculation V=

exC [1 - (Pprec + 1) ÷ (Pmax + 1)]

V = Vessel size e = Coefficient of water expansion C = System volume in litres Pmax = System pressure in Bar Pprec = Precharge pressure in Bar Pmax = The set pressure of the system safety relief valve typically 6 Bar Pprec = The set pressure of the system pressure reducing valve (typically 3 Bar) * Note system layouts are indicative only. Refer to relevant standards.

www.altecnic.co.uk

Altecnic Ltd - Caleffi group

H

1.30 | Vessels - Heating Vessels

Materials

Technical Specification

Component

Material

Shell

Carbon Steel

Connections

Carbon Steel

C

Test pressure 8 to 25 litres Max. flow operating

120°C

temperature H ØD

Capacity Product Code Diaphragm Synthetic rubber compound litres Coating Powder Epoxy8 HV8C Dimensions HV12C 12 HV18C 18 HV25C 25

Dimensions

1.5 x max working pressure

C

Weight

Max. vessel operating 70°C mm mm Connection temperature

kg R¾ 1.7 1.5 bar - nitrogen R¾ 2.3 R¾ 2.8 R¾ 3.5

272 235 Factory pre-charge 272 315 308 365 ØD 308 485 ØD

H

H

H

ØD

hh

CC

C

200 250 litres 35 toand litres 35 -140 140 litres

88to- 25 25 litres litres

mm 235 315 365 485

Carbon Steel ØD SBR synthetic rubber Powder Epoxy

C ProductWeight Code Capacity litres Connection kg 35 R¾HV35C 1.7 HV50C 2.3 50 R¾ 80 R¾HV80C 2.8 100 R¾HV100C 3.5 HV140C 140

ØD

ØD H mm mm 376 465 441 495 512 570 512 680 512 895

h

C

Weight

mm 130 175 175 175 175

Connection

kg 5.7 7.5 9.9 11.2 14.5

R¾ R¾ R1 R1 R1

marked Accessories - Vessels 8 to 25 litres

tion

8 to 35 litres 3 bar 50 to 140 litres 6 bar 1.5 x max working pressure mperature 120˚C C C ge 1.5 bar - nitrogen

Wall bracket with retaining strap - RS MB2

C

hh

ure

H

litres mm 8 272 12 272 18 Material 308 25 Carbon308 ØD Steel

H

h

ØD

H

HV8C HV12C Dimensions HV18C HV25C

Capacity

H

Product Code

35 to 140 litres 200and & 250 200 250litres litres Product Code Capacity litres HV35C To place an 35 order HV50C 50

300to - 800 300 800litres litres

ØD

H h C Weight ØD Product kg Code Capacity ØD mm mm mm Connection litres mm 376 130 T: 01785465 218222 (TradeR¾ sales) T:5.7 01785 218208 (OEM HV200W 200 634 441 495 175 R¾ 7.5

H

h

C

Weight

mm 760

mm 205

Connection

kg 37

sales) E: [email protected] R1

Vessels - Heating Vessels | 1.31 Heating expansion vessels 8 - 25 litres Ref. no

Capacity (Litres)

Diameter (Ø D mm)

Height (H mm)

Connection Weight (C inches) (kg)

Max working pressure (bar)

HV8C

8

272

235

R ¾

1.7

3

HV12C

12

272

315

R ¾

2.3

3

HV18C

18

308

365

R ¾

2.8

3

HV25C

25

308

485

R ¾

3.5

3

HV35C

35

376

465

R ¾

5.7

3

Heating expansion vessels 35 - 140 litres Ref. no

Capacity (Litres)

Diameter (Ø D mm)

Height (H mm)

Connection Weight (C inches) (kg)

Max working pressure (bar)

HV50C

50

441

495

R ¾

7.5

6

HV80C

80

512

570

R 1

9.9

6

HV100C

100

512

680

R 1

11.2

6

HV140C

140

512

895

R 1

14.5

6

EN OG D R T E N I FI L L E L S S S VE HV25C

EN OG D R T E N I FI L L E L S SS E V

marked

Accessories - Vessels 8 to 25 litres HV500W

Wall bracket with retaining strap - RS-MB

Heating expansion vessels 200 - 800 litres Ref. no

Capacity (Litres)

Diameter (Ø D mm)

Height (H mm)

Connection Weight (C inches) (kg)

Max working pressure (bar)

HV200W 200

634

760

R 1

37

6

HV250W

250

634

890

R 1

45

6

HV300W

300

634

1090

R 1

52

6

HV400W

400

740

1090

R 1

65

6

HV500W

500

740

1290

R 1

79

6

HV600W

600

740

1530

R 1

85

6

HV800W

800

740

1995

R 1

103

6

EN OG D R T E N I FI L L E L S S S VE

marked

OEM heating vessels Ref. no

Capacity Model Description (Litres)

Width (mm)

Height (mm)

Length (mm)

HV8F

8

541

Round flat exp vessel

324 Ø

129

n/a

HV10F

10

541

Round flat exp vessel

324 Ø

139

n/a

HV12F

12

541

Round flat exp vessel

324 Ø

169

n/a

EN OG D R T E N I FI L L E L S S S VE

• Flat vessels for expansion on heating systems and boiler HV8F

www.altecnic.co.uk

Altecnic Ltd - Caleffi group

H

1.32 | Vessels - Potable Vessels C

Materials

ns ØD ØD

C

2 to 25 litres

Technical Specification

Component

Material

Shell

Carbon Steel

Connections

Carbon Steel with plastic insert

Diaphragm

Synthetic rubber compound

Coating

Powder Epoxy

Max. working pressure 10 bar

Capacity

Product Code

Max. vessel operating 70°C temperature litres

Factory pre-charge PV8W - Vertical range PV12W - Horizontal range

PV18W System water connection thread PV25W - 140 litre size PV33W - horizontal range

33 litres - with w ØD

H

mm 8 206 4.0 bar - nitrogen 122.0 bar - nitrogen 280 18BE EN ISO 228 280- male 25 280 BE EN 10226 - male 33 354 BE EN ISO 228 - male

mm 325 310 380 500 455

H

H

ØD

Dimensions Dimensions

C

Weight

mm mm Connection kg 206 325 G¾ 1.8 280 310C G¾ 2.4 C 280 2 to 380 2.8 C 25 litres G¾ C G¾33 litres33 2 to litres500 8280 - 2525litres litreswall bracket -4.7 with 33 litres with wall 354 455 G¾ 6.6 bracket ØD

ØD

H

H

h

C

h

C

ØD

Horizontal rangeH L

h

h

h

H

h

mm 605 740 730 835 1015 970 1270 1245 1475 1860 2325 2604

mm 104 152 152 152 145 145 145 135 135 265 265 265

marked L WRAS approved product

Product Code Capacity ØD litres mm Capacity ØD H h C Weight PVH25W 25 280 kgC PVH50W litres mm mmC mm Connection 50 409 PVH80W 80 480 C To place409 an order T: 01785 (Trade sales) C 605 50 104218222G1 9.5 T: 01785 218208 (OEM PVH100W 100 480

h

ode

600 600 -and 10001000 litreslitres H

50 to 500 litres

600 and

C Weight Product Code Capacity ØD C Weight mm Connection kg litres mm mm Connection kg 206 325Dimensions G¾ 1.8 PV50W 50 409 280325 310G¾ G¾ 1.8 2.4 PV60W 60 409 280310 380G¾ G¾ 2.4 2.8 PV80W 80 480 280380 500G¾ G¾ 2.8 4.7 PV100W 100 480 354500 455G¾ G¾4.7 6.6 PV140W 140 480 455 G¾ 6.6 PV200W 200 634 ØD C PV300W 300 634 ØD PV400W 400 740 PV500W 500 740 PV600W 600 740 PV800W 800 740 PV1000W 1000 740 H

H ØD

to 500 5050 - 500 litreslitres

H

mm H

H

Product Code Capacity ØD Product Code Capacity litres ØD litres PV8W 8 mm PV8W PV12W 8 12 206 12 ØD PV12W PV18W 18 280 PV18W PV25W 18 25 280 PV25W PV33W 25 33 280 PV33W 33 354

C

C

H

H

H

ØD

H

33 litres - with wall bracket

h

litres 8 12 18 25 33

C

H

Capacity

ode

ØD

H

2 to 25 litres

ØD

ØD

ØD

H

C

ØD

mm 484 492 562 sales) 667

C

Weight

kg mm Connection 294 G1 5.5 433 G1 15 504 G1 18 E: [email protected] 504 G1 21

Vessels - Potable Vessels | 1.33 Vertical potable water expansion vessels 8 - 33 litres Ref. no

Capacity (Litres)

Diameter (Ø D mm)

Height (H mm)

Connection Weight Membrane (inches) (kg)

PV8W

8

206

325

G ¾

1.8

Fixed

PV12W

12

280

310

G ¾

2.4

Fixed

PV18W

18

280

380

G ¾

2.8

Fixed

PV25W

25

280

500

G ¾

4.7

Fixed

PV33W

33

354

455

G ¾

6.6

Fixed

EN OG D R T E N I FI L L E L S SS E V

PV33W

EN OG D R T E N I FI L L E L S S S VE

PV500W

EN OG D R T E N I FI L L E L S SS VE

PVH50W

marked

Vertical potable water expansion vessels 50 - 1000 litres Ref. no

Capacity (Litres)

Diameter (Ø D mm)

Height (H mm)

Height (h mm)

Connection Weight Membrane (inches) (kg)

PV50W

50

409

605

104

G 1

9.5

Replaceable

PV60W

60

409

740

152

G 1

14

Replaceable

PV80W

80

480

730

152

G 1

16

Replaceable

PV100W

100

480

835

152

G 1

19

Replaceable

PV140W

140

480

1015

145

R 1

29

Fixed

PV200W

200

634

970

145

G 1¼

40

Replaceable

PV300W

300

634

1270

145

G 1¼

54

Replaceable

PV400W

400

740

1245

135

G 1¼

70

Replaceable

PV500W

500

740

1475

135

G 1¼

79

Replaceable

PV600W

600

740

1860

265

G 1½

103

Replaceable

PV800W

800

740

2325

265

G 1½

195

Replaceable

PV1000W

1000

740

2604

265

G 1½

228

Replaceable

marked

Horizontal potable water expansion vessels 25 - 100 litres Ref. no

Capacity (Litres)

Diameter (Ø D mm)

Length (L mm)

Height (H mm)

Connection Weight (inches) (kg)

PVH25W

25

280

492

298

G¾

5.5

PVH50W

50

409

503

434

G 1

15

PVH80W

80

480

576

504

G 1

18

PVH100W

100

480

681

504

G 1

21

marked

Accessories for expansion vessels Ref. no

Description

RS-MB2

Potable vessel mounting bracket 5 litre - 18 litre

RS-MB24

Potable vessel mounting bracket 25 litre only

CA-100700

Potable vessel bracket 33 litre only

www.altecnic.co.uk

Altecnic Ltd - Caleffi group

1.34 | Vessels - Potable Vessels

Flow Through Series Potable Vessels

D C

ØB

D C

The flow through series of potable water vessels for the home are ideal for using with water heaters to save money. Water flows through the vessel, it has a stainless steel connection and thereby meets the ultra-exacting hygiene requirements of DIN 1988. The T piece required is supplied with the unit and the Flowjet flow through valve is optionally available.

Materials

A

Component

Material

Shell

Carbon Steel

Connections

Stainless Steel

Bladder

Synthetic rubber compound

Coating

Powder ØB Epoxy

ØB

D C

Technical Specification

litre 8 -8 to 2525litres

D C

Max. working pressure 10 bar Max. vessel operating 70°C temperature Factory pre-charge - Vertical range System water connection thread

PVA8G

EN OG D R T E N I FI L L E L S S S VE

4.0 bar - nitrogen

A

A

8 to 25 litre

33 litre 33 withlitres wall bracket

BE EN ISO 228 - male

Flow through potable water expansion vessels 8 - 33 litres Ref. no

Capacity (Litres)

Diameter (Ø D mm)

Height (H mm)

Connection Weight Membrane (inches) (kg)

PVA8G

8

206

335

G ¾ B

2.7

Fixed

PVA12G

12

280

325

G ¾ B

3.7

Fixed

PVA18G

18

280

395

G ¾ B

4.7

Fixed

PVA25G

25

280

515

G ¾ B

5.7

Fixed

PVA33G

33

354

465

G ¾ B

6.5

Fixed

marked

Flowjet valve for potable water systems PVACC1

Ref. no

Description

PVACC1

¾˝ Flowjet valve

To place an order T: 01785 218222 (Trade sales) T: 01785 218208 (OEM sales) E: [email protected]

Vessels - Mini Vessels | 1.35

Materials Component

Material

Body and inlet connection - 0.16 & 2 litre Stainless steel Body and inlet connection

Dimensions Dimensions

Noryl polymer

C C

C C

C

Membrane Chlorobutyl

Technical Specification Max. working pressure

10 bar

Max. system temperature

90°C

Pre-charge pressure - 0.16 litre - 0.5 litre - 1 & 2 litre

3.5 bar 4 bar 4 bar

AA ØB ØB Prod ProdCode Code

AA ØB ØB

Litres Litres

PV016C PV016C0.16 litre 0.16 0.16

AA

BB

R½ R½

85 85

CC

A ØB

kg kg

0.5/1112 litre 112

2 litre

0.34 0.34

PV05C PV05C

0.5 0.5

G½B G½B

113 113

135 135

0.6 0.6

PV1C PV1C

1.0 1.0

G½B G½B

120 120

197 197

0.9 0.9

Mini expansion vessels 0.16 - 1 litre Capacity (Litres)

Diameter (Ø B mm)

Height (C mm)

Connection Weight (A inches) (kg)

PV016C

0.16

85

112

R ½ 0.34

PV05C

0.5

113

135

G ½

0.6

PV1C

1

120

197

G ½

0.9

PV016C

C C

Ref. no

PV1C

AA ØB ØB

Mini expansion vessel 2 litre Ref. no

Capacity (Litres)

Diameter (Ø B mm)

Height Prod Prod Code (CCode mm)

PV2W

2

132

PV2W PV2W 260

PV2Z

2

132

260

Connection Weight Litres Litres (A inches) AA BB (kg) 2.0 2.0

R1” R1” 126 126 G ¾ 1.0

G ½

PV2W CC

kg kg

208 208

1.2 1.2

1.0

Mechanical shock arrester Ref. no

Description

Box quantity

525040

½˝ BSP mechanical type

25

525040

• Minimum pressure : 3 bar

www.altecnic.co.uk

Altecnic Ltd - Caleffi group

1.36 | Vessels - General/Accessories

CA-100148

EN OG D R T E N I FI L L E L S S S VE

Water heater accessory packs Ref. no

Description

CA-100148

Water heater pack 1 includes: 1 x ½˝ PRV at 3.5 bar, 1 x expansion vessel 2 litre, 1 x ½˝ SRV at 6 bar 312460, 1 x 15mm single check valve

CA-100149

Water heater pack 2 includes: 1 x expansion vessel 2 litre, 1 x ½˝ safety valve, 1 x 15mm single check valve

CA-100150

Water heater pack 4 includes: 1 x ½˝ PRV at 3.5 bar, 1 x expansion vessel 2 litre, 1 x 15mm single check valve

CA-100151

Water heater pack 5 includes: 1 x expansion vessel 2 litre, 1 x 15mm single check valve

CA-100025

Water heater pack 6 includes: 1 x 22mm x ¾˝ PRV at 3.5 bar, 1 x SRV push fit at 6 bar

Installation packs suitable for installation of single / multipoint water heaters.

Temperature / pressure relief valves 309473 CST

Ref. no

Connections

Set pressure (bar)

Probe length (mm)

309400 CST

½˝ M x 15mm Compression

10

102

309405 CST

½˝ M x 15mm Compression

10

203

309435 CST

½˝ M x 15mm Compression

3

203

309440 CST

½˝ M x 15mm Compression

4

102

309445 CST

½˝ M x 15mm Compression

4

203

309465 CST

½˝ M x 15mm Compression

6

203

309470 CST

½˝ M x 15mm Compression

7

102

309475 CST

½˝ M x 15mm Compression

7

203

309500 CST

¾˝ M x 22mm Compression

10

99

309505 CST

¾˝ M x 22mm Compression

10

203

309535 CST

¾˝ M x 22mm Compression

3

203

309545 CST

¾˝ M x 22mm Compression

4

203

309547 CST

¾˝ M x 15mm Compression

4

200

309565 CST

¾˝ M x 22mm Compression

6

203

309570 CST

¾˝ M x 22mm Compression

7

99

309575 CST

¾˝ M x 22mm Compression

7

203

309473 CST

½˝ M Parallel x 15mm Compression

7

97

Pressure and temperature relief valves for use when the system calls for two controls. Designed for use on unvented hot water supply systems.

To place an order T: 01785 218222 (Trade sales) T: 01785 218208 (OEM sales) E: [email protected]

Vessels - General/Accessories | 1.37 Tundishes Ref. no

Description

* AP-400001

½˝M x ¾˝F plastic angle tundish

* AP-400002

¾˝M x 1˝F plastic angle tundish

* AP-400003

¾˝M x ½˝F plastic straight tundish

* AL-400010

15mm x 22mm straight tundish with plastic nuts

552140

½˝ angle aluminium tundish M x F

552150

¾˝ angle aluminium tundish M x F

552160

1˝ x 1¼˝ angle aluminium tundish M x F

552050

¾˝ straight aluminium tundish F x F

552070

1¼˝ straight aluminium tundish F x F

CA-100113

22mm x 1˝F plastic straight tundish with nut and olive

Suitable for use where air gap or air break is required in sealed or unvented systems.

www.altecnic.co.uk

AL-400010

*

Altecnic Ltd - Caleffi group
