Altium Shortcuts 3b5h9

shortcuts

Function

X

Rotating components along the X-axis (X-axis symmetry through)

Y

Rotating components along the Y axis (the axis Y Mirror).

SPACE (Space)

Rotate 90 degrees components.

ALT + Click on the Net

Highlight the Net with the same name (Blur entire rest of the drawing SCH)

Shift + Ctrl + C

Clear all applicable on SCH

Ctrl + Click and drag

Moving parts along with wiring (Like in Proteus)

Shift + Space

Rotate 45 degrees components

Shift + Left Click

Copy components

Shift + Click and drag

Pull components out

Ctrl + Shift + L (or AL)

Align straight vertical components

Ctrl + Shift + T (or AT)

Align straight horizontal components

Ctrl + Shift + H (or AH)

Align components equally spaced horizontal

Ctrl + Shift + V (or AV)

Align components equally spaced vertical

Ctrl + M

Measure the distance

CC

Compile Project - Check the connection errors, port

DB

Take the library components

DIRTY

Change the drawings

ENOUGH

Update principles into printed circuit

JC

Jump to components

PB

Draw a Line bus

PN

Name the line

PO

Get GND

PT

Add Text

PW

To go wire components legs

PVN

Mark Vacuum

DOZEN

Open the windows management component name

TN

Automatic naming components

TS

Find components inside the printed circuit (You select the blocks you need circu automatically find that the printed circuit blocks for you)

TW

Creating new components

TAB

Change the parameters of the circuit

VD

Putting drawings fit in the screen frame

Design the printed circuit board (PCB Layout) shortcuts

Function

2

See the printed circuit in 2D

3

See the printed circuit in 3D

Q

Unit Converter mil -> mm and vice versa

PT

(Place> Interactive Routing) Manual mode wiring

PL

Re-size format and then click on the layer printed circuit layer outlined keep out th

PM

Pull the wire 1 more time (MultiRoute) (by: Shift to select multiple Pad, then press MultiRoute, you can press Tab to adjust the relative distance between the wire tog

PG

government contracts

Reporter

Take Via holes

PR

Draw lines to circuits, the gap between the small circuit road

PDD

Information display size PCB (like in the form Cad <- 80mm ->)

AA

Automatic wiring

FRINGES

Remove all lines were running circuit

TUN

Delete the line of the same name

TDR

Check that all wire connections are not after the completion of wiring by hand

FALL

Rounded lines near the foot parts (Tea Drop - tears for the foot path near the circu

TM

Clear error displayed on the screen

DK

Select a drawing class

DR

To adjust the parameters of the circuit as the width of the lines (Width), a distance (shortcircuit) ...

DIRTY

Adjust circuit parameters, if you do not want the squares to affect the transfer line

DTA

Show all layers

DTS

Only visible layers TOP + BOTTOM + MULTI ...

CK

Open editing window path components.

RB

Show vessel information (size, number of components ...)

PVN

Show Window Configurations (Adjust hidden ingredients)

OD (Or Ctrl + D)

Open the windows management component name

VB

180 degree swivel drawings

VF

Show the whole drawing

L

When moving parts components flip between layers Top and Bottom (Bottom and

TAB

The time change information window when operations

L or Ctrl + L

Open View Configuration to adjust the display of layers

fliped Board

Printed Circuit overturned

Ctrl G or G

Grid Settings

Ctrl M

Circuit size measure

Shift M

Magnifying glass squares

Shift R

Changing the wiring mode (Cut - Do not cut - Push wire)

Shift S

Allow only one layer is currently selected (the remaining layers are hidden)

Shift + Space

Change the line mode (Freedom - By law - Square 90 degrees - Cong)

Ctrl + Shift + L (or AL)

Align straight vertical components

Ctrl + Shift + T (or Align straight horizontal components AT) Ctrl + Shift + H (or Align components equally spaced horizontal AH) Ctrl + Shift + V (or Align components equally spaced vertical AV) Ctrl + Shift + Scroll

Switch between layers

3D Mode (3D visualization) shortcuts

Function

0

Rotate the view original circuit board

9

Rotate 90 degrees board

2

Switch to 2D mode when in 3D View

3

Switch to 3D View when in 2D mode

SHIFT

Simultaneously press Shift and right click, move the mouse to rotate the circu

VF

Adjust to fit the screen circuit board

VB

Flip the circuit boad

scroll mouse

Pull up - Scroll down

SHIFT + Scroll

Left - right Sang

CTRL + Mouse Scroll

Zoom - Zoom

CTRL + Mouse

Zoom - Zoom

CTRL + C

Photographing current perspective 3D circuit board to the Clipboard, to save a Paint.

TP

Open the Preferences window

L

Open Window Configurations - Adjusting the display properties
