Bpel Tutorial 435g28

BPEL Tutorial 1. 2. 3. 4. 5. 6. 7. 8.

What is SOA? What is BPEL? Difference between SOA and BPEL Advantages of SOA/BPEL SOA Suite “Hello World/ErpSchools” Tutorial in BPEL Compile and deploy BPEL Suitcase using bplec.bat Monitor the activities/instances/statuses in Dashboard

What is SOA? SOA stands for “Service Oriented Architecture”. SOA is an architectural approach using technology to present business processes as reusable services. SOA is focused on the business and enables process transformation to new levels of integration, visualization, monitoring, and optimization.SOA is not a technology, it is a concept and a strategy for using technologies to build business automation solutions. SOA can be achieved through web services like BPEL. What is BPEL? BPEL stands for “Business Process Execution Language”. BPEL is a technology used to build programs in SOA architecture. Difference between SOA and BPEL SOA is an architecture and not a technology. BPEL is a technology to build SOA architectural programs. Advantages of SOA architecture and BPEL technology 9.

Being SOA an architectural concept rather than a technology it is concentrated on business rather than development or coding. 10. Using SOA architecture and BPEL technology you can integrate multiple legacy systems through reusable services/objects. 11. BPEL provides handshaking which means you can track what is happening to your input. If it is successfully processed or not. 12. You Can create alerts to notify about errors in processing or critical conditions.

SOA Suite Click here to the BPEL Suite

“Hello World/ErpSchools” Tutorial in BPEL

Click “close” to close the tip Right click on the Application and select “New Application”

Select “Integration Tier” and then “BPEL” in the categories and then in Items select “BPEL Process Project”

Click OK. Now “BPEL Project Creation Wizard” will open as shown below Enter the name: erpschools_process Name Space: Leave it as default Template: Synchronous BPEL Process

Click Next

Leave the default values and click Finish Now you will see a screen like this

Now on the right side tab you can see the “Assign” icon in the component pallet

Select it and drag into the diagram. When you drag you will see green circles representing where you can drop the Assign component. I will drop between “Receive Input” and “Reply output” as shown below

Double click on the “Assign_1” icon in the diagram You will see the below screen

In “General” tab you can change the Name or you can leave the default Next Click on “Copy Operation” And select “Create” drop down as show below

Now you will see “Create Copy Operation” box with From and To tabs

By default both from and to types are defaulted to “Variable” Now in the From “Type” box select the “Expression”

Now click on the “XPath Expression Builder” icon

Expression Builder screen will pop up as shown

Now in the right side tab in “Advanced Functions” select “String Functions” as shown below

Now double click on “Concat” and it should copy the concat function to expression tab on the top as shown

Now manually enter the parameters for that concat() function as shown Enter the welcome message as shown and place the cursor immediately after the comma

In the BPEL Variables select the Clinet:Input variable and double click it. It will automatically insert the path on the top

Click OK.

We are done with from expression now In the right side tab select the output variable as show below

To see the detailed information for that input variable select “Show Detailed Node Information” check box in the bottom

Now click OK

Click Apply and then OK Now coding part is done. We have to deploy this process.

Searc Tables Forums Scripts General

API Interface

Shell Scripts Misc Ask a Question

Apps Mock Interview Apps Consultancies Apps Related Sites Guides

Links Apps Installation Interview Q'ns Oracle Reports Oracle Forms Workflow General Apps PL/SQL Payables(AP) Receivables(AR) Order Entry(OM) Purchasing(PO) Articles Financials Manufacturing Tools

App Developer

Videos

Home

Receive Updates

Enter Your

Sponsors

Subscribe

Keep in touch Click here to Bookmark this site. Click here to set this page as your homepage

About me I am Prudhvi working for iAppz Solutions Inc as Oracle Apps techno-functional consultant. [email protected] www.erpschools.com (847)877-2662

Direct Links                     

BPEL Tutorial Apps Story Shell Script from Database procedure Alerts in Oracle Apps Shell Scripting Tutorial Concurrent program from menu Order to Cash Cycle Interface Programs Descriptive Flexfields Change LOV using Forms Personalization Oracle Attachments Workflow Tutorial Technical Form Customization Report Creation Concurrent Program Registration Using FNDLOAD XML Publisher SQL * LOADER Adhoc Roles Forms Personalization

BPEL / SOA Prepare to deploy the process. Start the SOA Suite Programs >> BPEL >> Start SOA Suite

Once it is started you will see a screen like this

Now go back to JDeveloper In the left you can see the “Connections Navigator” click on that

Now select “Application Server” and right click to select “New Application Server Connection”

You get to see the below screen

Leave the Connection Name as it is and click “Authentication” tab and Enter the name/ By default it is oc4j/welcome1

Go to next tab “Connection” and enter as follows.

Now go to Test tab and click “Test Connection”. If you get “Success” message you are good to move forward if not go back and check the ports and hostname e.t.c

Click OK If you expand the “application Server” in the left you will see the directory structure as follows

Integration Server Connection Now right click on “Integration Server” folder as shown and select “New Integration Server Connection”

You can leave the Connection Name as it is and click on next tab “Connection”

Now select the Application Server that we created in the previous step. Click on “Test Connection” tab

Click “Test Connection” button

Now you should see the below text Application Server: OK BPEL Process Manager Server: OK ESB Server: OK If all the three servers are OK you are good to deploy the process. If you expand the Integration Server folder you will see the directory structure as show below

Now preparation to deploy the process is done. Go back to Applications Navigator in the Left

Select the process , right click , select deploy , Server Connections >> Connection that you created previously

You get a message in the bottom of the screen saying success or fail. If success everything is good if not you can deploy through another method. It can fail for many reasons it depends on your browser settings, windows settings, ports, permissions e.t.c Deploy and create BPEL Suitcase Go to Developer Prompt Click Programs >> BPEL >> Oracle BPEL Process Manager >> Developer Prompt

It will open a command prompt and will take you to “samples” directory Cd .. Cd bin Now type Bpelc.bat “path of your bpel.xml file in your application folder” In the first step while creating the new application we have the path “C:\product\10.1.3.1\OracleAS_2\bpel\samples\Prudhvi\Application1” So navigate to that folder and then click the process folder here it will be erpschools_process and then to bpel directory Final path will be “C:\product\10.1.3.1\OracleAS_2\bpel\samples\Prudhvi\Application1\erpschools_process \bpel\bpel.xml” Execute the below command in the developer prompt(in cmd prompt) Bpel.bat C:\product\10.1.3.1\OracleAS_2\bpel\samples\Prudhvi\Application1\erpschools_process\ bpel\bpel.xml

You should see the successful message as shown above. It will also tell you where the BPEL Suitcase is created and the name of the suitcase file. Usually the name suitcase will be appended with date and its extension is .jar After you create the BPEL Suitcase you have to manually deploy it. In the browser type the below url http://localhost:8888/BPEL default name and will be name: oc4j : welcome1

Once you you will see the below screen

Click on “BPEL Domains” tab on the top

Now click on “default” BPEL Domain It will open a new window as shown below

In the Left you can see all the BPEL processes you have deployed till now. To deploy our new process click on “BPEL Processes” tab on the top

Click on “Deploy New Process” in Related Tasks

Click Browse and select the BPEL Suitcase that we created using bplec.bat previously

Now click “Deploy” button. If you get a successful message as shown below your BPEL process is deployed successfully.

Click Done.
