Broadcasting in IBM Sterling File Gateway

© 2014 IBM Corporation

and Presenter

 – Eileem Mejia, IBM Sterling B2B Integrator , L2 Engineer – [email protected]

© 2014 IBM Corporation

Agenda

        

Overview of SFG Features MyFileGateway Role of Partner in myFileGateway Broadcasting Determining the consumer using a Fact Determining the consumer using a Business Process Broadcasting through Shared Mailboxes Related Properties and Event Codes

© 2014 IBM Corporation

Overview of SFG

     

Application for transferring Files. Large and High Volume Transfers End to End Visibility Automation and Data Security s Integration Single Sign on access

© 2014 IBM Corporation

Features

        

File/File name Transformations File Transfer Visibility Replay/Redeliver Notifications Extensibility Communications Protocol Partner Interface (myFileGateway) Dynamic Routing Partner Onboarding

© 2014 IBM Corporation

MyFileGateway

     

or files. Search for routes. View recent activity Generate reports Change their . Subscribe to notifications

© 2014 IBM Corporation

Role of Partner in myFileGateway

     

Partners can be internal or external. or files to myFileGateway View the status of file transfers Choose events to be notified Manage their own Generate reports

© 2014 IBM Corporation

Broadcasting

     

Publish type message patterns are quite common. Various retail/Manufacturing scenarios Copies of the same payload file to multiple consumers Dynamic Routing Channel Templates Consumers can be defined through the system fact 'ConsumerBroadcastGroup' Consumers can be definted through Business Process

© 2014 IBM Corporation

Determining the Consumer using a Fact

© 2014 IBM Corporation

Determining the Consumer using a Fact  SFG with fg_sys  Create Partner Groups

© 2014 IBM Corporation

Determining the Consumer using a Fact  Create Partners

© 2014 IBM Corporation

Determining the Consumer using a Fact  Add Partners to the Groups

© 2014 IBM Corporation

Determining the Consumer using a Fact  Create Producers and Producer Groups

© 2014 IBM Corporation

Determining the Consumer using a Fact  Create Dynamic Routing Channel Template  Type – Dynamic  What will determine the consumer – Facts in Producer File structure

© 2014 IBM Corporation

Determining the Consumer using a Fact  Special Characters handling

© 2014 IBM Corporation

Determining the Consumer using a Fact  Add Producer Groups and Consumer Groups

© 2014 IBM Corporation

Determining the Consumer using a Fact  Add Provisioning Facts (Optional)  Note: The fact ConsumerBroadcastGroup does not have to be set as a provisioning fact here. it can also be set as a producer file structure file name pattern. If the ConsumerBroadcastGroup is set by the file name pattern in the producer file structure, the producer specifies the name of the File Gateway Partner Group in the name of the file they .

© 2014 IBM Corporation

Determining the Consumer using a Fact  Add Producer File Structure  In the below example Producer would send files with names following the format 'ConsumerGroupName_RealFileName'

© 2014 IBM Corporation

Determining the Consumer using a Fact  Add Pattern for Consumer Mailbox Path  Add Consumer File Structure

© 2014 IBM Corporation

Determining the Consumer using a Fact  Save Routing Channel Template

© 2014 IBM Corporation

Determining the Consumer using a Fact  Create Routing Channel

© 2014 IBM Corporation

Determining the Consumer using a Fact  Broadcast a file through myFileGateway  Please note that the file that has to be routed should match the Producer File Structure we have configured in the Routing Channel Template.  In this example it should be ConsumerGroupName_RealFileName

© 2014 IBM Corporation

Determining the Consumer using a Fact  Observe from Filegateway UI that the file has been routed to the ConsumerGroupNames successfully.

© 2014 IBM Corporation

Determining the Consumer using a Fact  Observe from Filegateway UI that the file has been routed to the ConsumerGroupNames successfully.

© 2014 IBM Corporation

Determining the Consumer using a Fact  Observe from Filegateway UI that the file has been routed to the ConsumerGroupNames successfully.

© 2014 IBM Corporation

Determining the Consumer using a Fact  Observe that the files are routed to corresponding Consumer mailboxes with filename defined in consumer file structure.

© 2014 IBM Corporation

Determining the Consumer using a Business Process

© 2014 IBM Corporation

Determining the Consumer using a Business Process  SFG with fg_sys  Create a Partner Group  Add partners to the group

© 2014 IBM Corporation

Determining the Consumer using a Business Process Create a Business Process in IBM Sterling B2B Integrator which will populate list of consumers at the ProcessData level. For the below example the list of consumers are generated under ConsumerNameList/Consumer. <process name = "MyBroadcastList"> <sequence> CONS1 CONS2 CONS3 CONS4

© 2014 IBM Corporation

Determining the Consumer using a Business Process Check the output of the Business Process and make sure the list of consumers are populated under the process data element level ConsumerNameList/Consumer

© 2014 IBM Corporation

Determining the Consumer using a Business Process     

Create Dynamic Routing Channel Template Type – Dynamic What will determine the consumer – Business Process Select the Business Process name which you have created in IBM Sterling B2B Integrator Give the Process Data Element Name from the previous step ConsumerNameList/Consumer

© 2014 IBM Corporation

Determining the Consumer using a Business Process  Special Characters handling

© 2014 IBM Corporation

Determining the Consumer using a Business Process  Add Producer Groups and Consumer Groups

© 2014 IBM Corporation

Determining the Consumer using a Business Process  Add Provisioning Facts (Optional)

© 2014 IBM Corporation

Determining the Consumer using a Business Process  Add Producer File Structure  In the below example Producer would send files with names following the format 'OriginalFileName'

© 2014 IBM Corporation

Determining the Consumer using a Business Process  Add Pattern for Consumer Mailbox Path  Add Consumer File Structure as you prefer

© 2014 IBM Corporation

Determining the Consumer using a Business Process  Save Routing Channel Template

© 2014 IBM Corporation

Determining the Consumer using a Business Process  Create Routing Channel

© 2014 IBM Corporation

Determining the Consumer using a Business Process  Broadcast a file through myFileGateway

© 2014 IBM Corporation

Determining the Consumer using a Business Process  Observe from Filegateway UI that the file has been routed to the Consumer Names obtained from the Business Process successfully.

© 2014 IBM Corporation

Determining the Consumer using a Business Process  Observe from Filegateway UI that the file has been routed to the Consumers successfully.

© 2014 IBM Corporation

Determining the Consumer using a Business Process  Observe that the files are routed to corresponding Consumer mailboxes with filename defined in consumer file structure.

© 2014 IBM Corporation

Broadcasting through Shared Mailboxes

© 2014 IBM Corporation

Broadcasting through Shared Mailboxes  Add mailbox.enableSharedLinkedMailboxes=true in customer_overrides.properties file.  Create a Shared Mailbox in IBM Sterling B2B Integrator

© 2014 IBM Corporation

Broadcasting through Shared Mailboxes  SFG with fg_sys  Create a Partner Group  Add partners to the group

© 2014 IBM Corporation

Broadcasting through Shared Mailboxes  Create Dynamic Routing Channel Template  Type – Dynamic  What will determine the consumer – Facts in producer file structure

© 2014 IBM Corporation

Broadcasting through Shared Mailboxes  Special Characters handling

© 2014 IBM Corporation

Broadcasting through Shared Mailboxes  Add Producer Groups and Consumer Groups

© 2014 IBM Corporation

Broadcasting through Shared Mailboxes  Add Provisioning Facts (Optional)

© 2014 IBM Corporation

Broadcasting through Shared Mailboxes  Add Producer File Structure  In the below example Producer would send files with names following the format 'ConsumerGroupName_RealFileName'

© 2014 IBM Corporation

Broadcasting through Shared Mailboxes  Add the shared mailbox as Pattern for Consumer Mailbox Path  Add Consumer File Structure as you prefer

© 2014 IBM Corporation

Broadcasting through Shared Mailboxes  Save Routing Channel Template

© 2014 IBM Corporation

Broadcasting through Shared Mailboxes  Create Routing Channel

© 2014 IBM Corporation

Broadcasting through Shared Mailboxes  Edit consumer partner mailboxes in IBM Sterling B2B Integrator to make them linked mailboxes, and link them to the shared mailbox.  Linked mailbox restrictions apply.

© 2014 IBM Corporation

Broadcasting through Shared Mailboxes  Broadcast a file through myFileGateway

© 2014 IBM Corporation

Broadcasting through Shared Mailboxes  Observe from Filegateway UI that the file has been routed to the Consumer Names obtained from the Business Process successfully.

© 2014 IBM Corporation

Broadcasting through Shared Mailboxes  Observe from Filegateway UI that the file has been routed to the Consumers successfully from the SHARED mailbox.

© 2014 IBM Corporation

Broadcasting through Shared Mailboxes  Observe that the files are routed to corresponding Consumer Linked mailboxes from the Shared mailbox with the file names defined in consumer file structure.

© 2014 IBM Corporation

Properties and Event Codes  FgmaxBroadcastListSize : Maximum allowed size of the consumer list used for broadcast. If the returned list of consumers exceeds this size, the file is not routed. By default, the maximum size of a broadcast list is set to 100.

 FG_0553 : InvalidConsumerBroadcastGroup  FG_0554 : MaxBroadcastGroupSizeExceeded
