Clover® Lapping Compounds

Search

Search the Newman Tools site

order on line

Uses

Size and Grit Selection Carriers

Abrasive Types

CLOVER LAPPING AND GRINDING COMPOUNDS are abrasive pastes for the cutting, smoothing and finishing of metal surfaces, and for the precision mating of metal parts. For over 100 years Clover Compounds have helped mechanics, tool and die makers, and machine builders create precision, silky-smooth fits in machine parts, valve seats and gear teeth. Clover Compounds are formulated from silicon carbide abrasives. These compounds are classified by grit size; from very coarse to extremely fine. They are available in grease based formulations. Clover Compounds supplement other metal removal techniques such as grinding, milling, boring and EDM machining. Where these techniques alone cannot achieve the required finishing, Clover Compounds are used to: Produce an ultra flat surface as in the lapping or gauges, valve seats, spacers and mechanical seal faces. Smooth out surfaces as in the lapping of tool marks from machine ways, bearing races and shaft surfaces. Achieve precise dimensions while maintaining smooth surfaces as in finishing gauges, tools and dies. http://www.newmantools.com/clover.htm

1/4

6/18/2014

Clover lapping compounds and grinding compound, clover brand, clover, fel-pro, felpro, loctite lapping compounds, lapping paste

Achieve perfect mating of metal parts as in lapping in of automotive and industrial valves, running-in gears, and sharpening of shear-type cutters. Clean surfaces without changing the topography of the surfaces as in cleaning mold cavities and die surfaces. Remove metal or material too hard to remove in other ways as in finishing hardened tool steel or stellite valve seats.

Back to Top of Page

Order on-line. These are the part number for 1 lbs. containers. Grade and Grit Selector Guide

Part Number ( 1 lb. can) CL.7A

GRIT 1200

Descriptions

CL.6A * EXTREMELY FINE 1000* (discontinued) Polishing, High Precision Lapping CL.5A 800 CL.4A 600 CL.3A * VERY FINE 500* (discontinued) For fine Polishing and Lapping CL.2A 400 CL.1A 320 FINE For Finishing, Valve Lapping, Bearings, CL.A 280 Dies and Gauges CL.B 240 MEDIUM FINE CL.C 220 For Cylinder Lapping CL.D 180 MEDIUM General Purpose for controlled Metal CL.NC * 150* Removal (discontinued) CL.E 120 COARSE CL.F 100 For the Initial "Cut" CL.G 80 Fast Removal of Metal CL.J * VERY COARSE 54* (discontinued) For Fastest Metal Removal * discontinued grits ,no longer available

Average Particle Sizes of Abrasive Grains Microns 1/1000 (0.001 inches mm) 0.12 3 0.20

5

0.38 0.56

9 14

0.68

17

0.90

23

1.28

33

1.75

44

2.48 2.6 3.4

63 66 86

4.8

122

5.6 6.8 15

142 173 267

18

463

Back to Top of Page http://www.newmantools.com/clover.htm

2/4

6/18/2014

Clover lapping compounds and grinding compound, clover brand, clover, fel-pro, felpro, loctite lapping compounds, lapping paste

The Abrasives: Clover compounds are available with the following abrasive grains and in a range of grit sizes. See the chart for availability of grit by size. Silicon Carbide The preferred abrasive for fast cutting of all but the hardest and toughest metals. It will produce a smooth flat surface but not a polished one.

Back to Top of Page

The Carriers: Grease Mix The most widely used carrier for Clover abrasives. It retains its texture and lubrication properties during extended lapping and leaves a rust- preventing film on lapped surfaces.

Back to Top of Page

link to clover price list link to barrel type lapping tools link to boron carbide lapping compounds link to non imbedding lapping compounds
