MCC
TM
Micro Commercial Components
2SD880-Q 2SD880-Y 2SD880-GR
omponents 20736 Marilla Street Chatsworth !"# $ % !"#
Features •
• • •
Lead Free Finish/RoHS Compliant(Note 1) ("P" Suffix designates RoHS Compliant. See ordering information) Power amplifier applications
NPN Silicon Power Transistors
Epoxy meets UL 94 V-0 flammability rating Moisure Sensitivity Level 1
Maximum Ratings Symbol VCEO VCBO VEBO IC PC TJ TSTG
Rating Collector-Emitter Voltage Collector-Base Voltage Emitter-Base Voltage Collector Current Collector power dissipation Junction Temperature Storage Temperature
Rating 60 60 7 3 1.5 -55 to +150 -55 to +150
Unit V V V A W к к
Electrical Characteristics @ 25OC Unless Otherwise Specified Symbol
OFF CHARACTERISTICS V(BR)CEO
V(BR)CBO
V(BR)EBO
ICBO
IEBO
Parameter
Min
Type
Max
TO-220 C
B
S
F Q T A U 1 2
Units
3
H
Collector-Emitter Breakdown Voltage (IC=50mAdc, IB=0) Collector-Base Breakdown Voltage (IC=100uAdc, IE=0) Emitter-Base Breakdown Voltage (IE=100uAdc, IC=0) Collector-Base Cutoff Current (VCB=60Vdc,IE=0) Emitter-Base Cutoff Current (VEB=7Vdc, IC=0)
60
---
---
Vdc
60
---
---
Vdc
7
---
---
Vdc
---
---
100
uAdc
---
---
100
uAdc
K
V
L
VCE(sat)
VBE
fT
Cob
ton ts tf
Forward Current Transfer ratio (IC=500mAdc, VCE=5Vdc) Collector-Emitter Saturation Voltage (IC=3Adc, IB=300mAdc) Base-Emitter Voltage (IC=0.5Adc,VCE=5Vdc) Transistor Frequency (IC=500mAdc, VCE=5Vdc) Collector Output Capacitance (VCB=10Vdc, IE=0, f=1MHz) Turn on time IB1=-IB2=0.2A, IC=2A, Storage time VCC=30V, PW=20us Fall time
Classification OF hFE(1) Rank Range
Q 60-120
Y 100-200
60 ---
-----
300 1
--Vdc
---
---
1
Vdc
---
3
---
MHz
---
70
---
pF
-------
0.8 1.5 0.8
-------
us us us
GR 150-300
R
G N
PIN 1. PIN 2. PIN 3.
ON CHARACTERISTICS hFE
J
D
BASE COLLECTOR EMITTER
DIM A B C
DIMENSIONS INCHES MM MIN MAX MIN MAX .560 .625 14.22 15.88 .380 .420 9.65 10.67 .140 .190 3.56 4.82
D F G H J K L N
.020 .139 .190 --.012 .500 .045 .190
.045 .161 .110 .250 .025 .580 .060 .210
0.51 3.53 2.29 --0.30 12.70 1.14 4.83
1.14 4.09 2.79 6.35 0.64 14.73 1.52 5.33
Q R S T U V
.100 .080 .045 .230 ----.045
.135 .115 .055 .270 .050 -----
2.54 2.04 1.14 5.84 ----1.15
3.43 2.92 1.39 6.86 1.27 -----
NOTE
∅
Notes: 1. High Temperature Solder Exemption Applied, see EU Directive Annex 7.
Revision: A
www.mccsemi.com 1 of 2
2011/01/01
MCC
TM
Micro Commercial Components
Ordering Information : Device
Packing
Part Number-BP
Bulk;1Kpcs/Box
***IMPORTANT NOTICE*** Micro Commercial Components Corp. reserves the right to make changes without further notice to any product herein to make corrections, modifications , enhancements , improvements , or other changes . Micro Commercial Components Corp . does not assume any liability arising out of the application or use of any product described herein; neither does it convey any license under its patent rights ,nor the rights of others . The of products in such applications shall assume all risks of such use and will agree to hold Micro Commercial Components Corp . and all the companies whose products are represented on our website, harmless against all damages. ***LIFE *** MCC's products are not authorized for use as critical components in life devices or systems without the express written approval of Micro Commercial Components Corporation. ***CUSTOMER AWARENESS*** Counterfeiting of semiconductor parts is a growing problem in the industry. Micro Commercial Components (MCC) is taking strong measures to protect ourselves and our customers from the proliferation of counterfeit parts. MCC strongly encourages customers to purchase MCC parts either directly from MCC or from Authorized MCC Distributors who are listed by country on our web page cited below. Products customers buy either from MCC directly or from Authorized MCC Distributors are genuine parts, have full traceability, meet MCC's quality standards for handling and storage. MCC will not provide any warranty coverage or other assistance for parts bought from Unauthorized Sources. MCC is committed to combat this global problem and encourage our customers to do their part in stopping this practice by buying direct or from authorized distributors.
Revision: A
www.mccsemi.com 2 of 2
