Semiconductor Logic Device
Cross-Reference Here is a comprehensive cross-reference of TTL and CMOS chips that are readily available over the counter ( from such places as Maplin Electronics in the UK ). Tables of both TTL and CMOS devices are provided along with tables grouping chips with the same functionality together. The following tables are available ... TTL Device Summary CMOS Device Summary NAND Gates NOR Gates AND Gates OR Gates XOR Gates Buffers Inverters Interface Devices Counters Latches and Flip-Flops Decoders Encoders Shift s Computational Devices Monostables and Multivibrators Analogue Switches Miscellaneous Functions
Please note that although the descriptions of the chips are taken from manufacturer's data sheets and other sources; these descriptions are only a brief indication of the generic functionality of that chip and a particular chip may have functionality that is slightly different to that actually required. Before using any device in the design or implementation of a project; always consult the original manufacturer's data sheet to ensure that a particular device is suitable for your purposes.
1 of 12
E&OE.
TTL Device Summary Please click on a device number to see the table of devices that belong to the same group.
Device 7400 7402 7403 7404 7405 7406 7407 7408 7410 7411 7414 7420 7421 7427 7430 7432 7447 7448 7473 7474 7476 7483 7485 7486 7490 7493 74121
2 of 12
Function Quad 2-Input NAND Gate Quad 2-Input NOR Gate Quad 2-Input NAND Gate ( Open collector ) Hex Inverter Hex Inverter ( Open collector ) Hex Inverter ( Open collector ) Hex Buffer Quad 2-Input AND Gate Triple 3-Input NAND Gate Triple 3-Input AND Gate Hex Inverter ( Schmitt trigger ) Dual 4-Input NAND Gate Dual 4-Input AND Gate Triple 3-Input NOR Gate 8-Input NAND Gate Quad 2-Input OR Gate BCD to 7-Segment decoder ( 15v ) BCD to 7-Segment decoder Dual J-K Flip-Flop Dual D-Type Flip-Flop Dual J-K Flip-Flop 4-Bit Binary Full Adder 4-Bit Magnitude Comparator Quad 2-Input XOR Gate Decade Counter 4-Bit Binary Counter Monostable Multivibrator
Similar Devices 7403 / 74132 / 4011 / 4093 / 40107 4001 7400 / 74132 / 4011 / 4093 / 40107 7405 / 7406 / 7414 / 4009 / 4049 / 4069 7404 / 7406 / 7414 / 4009 / 4049 / 4069 7404 / 7405 / 7414 / 4009 / 4049 / 4069 74240 / 74241 / 74244 / 74365 / 74541 / 4050 / 4503 / 40106 4081 4023 4073 7404 / 7405 / 7406 / 4009 / 4049 / 4069 4012 4082 4025 4068 4071 7448 / 4056 / 4511 7447 / 4056 / 4511 7476 / 4027 74175 / 74273 / 4013 / 40174 7473 / 4027 74283 4063 / 4585 74266 / 4030 / 4070 / 4077 74390 / 4017 / 4510 74161 / 74163 / 74193 / 74393 / 4029 74221 / 4098 / 4528
74123 74125 74132 74133 74137 74138 74139 74154 74157 74161 74163 74161 74164 74175 74193 74221 74240 74241 74244 74245 74259 74260 74266 74273 74279 74283 74365 74373 74373 74374 74374 74390 74393 74533 74533 74541 74573
3 of 12
Dual Regtriggerable Monostable Quad Bus Buffer Quad 2-Input NAND Gate ( Schmitt trigger ) 13-Input NAND Gate 3 to 8 Line Decoder 3 to 8 Line Decoder Dual 2 to 4 Line Decoder 4 to 16 Line Decoder Quad 2 to 1 Line Select 4-Bit Binary Counter 4-Bit Binary Counter 8-Bit Shift 8-Bit Shift Quad D-Type Flip-Flop Dual 4-Bit Binary Counter Dual Monostable Multivibrator Octal Buffer Octal Buffer Octal Buffer Octal Bus Transceiver 8-Bit Addressable Latch Dual 5-Input NOR Gate Quad 2-Input XOR Gate Octal D-Type Flip-Flop Octal S-R Latch 4-Bit Binary Full Adder Hex Buffer Octal D-Type Latch ( Inverting / Tri-State ) Octal D-Type Latch ( Inverting / Tri-State ) Octal D-Type Latch Octal D-Type Latch Dual Decade Counter Dual 4-Bit Binary Counter Octal D-Type Latch Octal D-Type Latch Octal Buffer Octal D-Type Latch
7400 / 7403 / 4011 / 4093 / 40107 74138 74137 4514 7493 / 74163 / 74193 / 74393 / 4029 7493 / 74161 / 74193 / 74393 / 4029 74164 / 4014 / 4015 74161 / 4014 / 4015 7474 / 74273 / 4013 / 40174 7493 / 74161 / 74163 / 74393 / 4029 74121 / 4098 / 4528 7407 / 74241 / 74244 / 74365 / 74541 / 4050 / 4503 / 40106 7407 / 74240 / 74244 / 74365 / 74541 / 4050 / 4503 / 40106 7407 / 74240 / 74241 / 74365 / 74541 / 4050 / 4503 / 40106 4099 7486 / 4030 / 4070 / 4077 7474 / 74175 / 4013 / 40174 7483 7407 / 74240 / 74241 / 74244 / 74541 / 4050 / 4503 / 40106 74374 / 74533 / 74573 / 74574 / 4042 74374 / 74533 / 74573 / 74574 / 4042 74373 / 74533 / 74573 / 74574 / 4042 74373 / 74533 / 74573 / 74574 / 4042 7490 / 4017 / 4510 7493 / 74161 / 74163 / 74193 / 4029 74373 / 74374 / 74573 / 74574 / 4042 74373 / 74374 / 74573 / 74574 / 4042 7407 / 74240 / 74241 / 74244 / 74365 / 4050 / 4503 / 40106 74373 / 74374 / 74533 / 74574 / 4042
74573 74574 74574 74688
Octal D-Type Latch Octal D-Type Latch Octal D-Type Latch 8-Bit Magnitude Comparator
74373 / 74374 / 74533 / 74574 / 4042 74373 / 74374 / 74533 / 74573 / 4042 74373 / 74374 / 74533 / 74573 / 4042
CMOS Device Summary Please click on a device number to see the table of devices that belong to the same group.
Device 4001 4002 4007 4008 4009 4011 4012 4013 4014 4015 4016 4017 4018 4019 4020 4021 4022 4023 4024 4025 4026 4027 4028 4029 4030 4033 4035
4 of 12
Function Quad 2-Input NOR Gate Dual 4-Input NOR Gate Complementary Pair plus Inverter 4-Bit Full Adder Hex Inverter Quad 2-Input NAND Gate Dual 4-Input NAND Gate Dual D-Type Flip-Flop 8-Bit Shift 8-Bit Shift 4-Channel Analogue Multiplexor Decade Counter BCD Counter ( Presettable ) Quad AND/OR Select Gate 14-Stage Ripple Counter 8-Stage Shift Divide by 8 Counter Triple 3-Input NAND Gate 7-Stage Ripple Counter Triple 3-Input NOR Gate 7-Segment Display Decade Counter Dual J-K Flip-Flop ( Master / Slave ) BCD to Decimal Decoder 4-Bit Binary Counter Quad 2-Input XOR Gate 7-Segment Display Decade Counter 4-Stage Shift
Similar Devices 7402
7404 / 7405 / 7406 / 7414 / 4049 / 4069 7400 / 7403 / 74132 / 4093 / 40107 7420 7474 / 74175 / 74273 / 40174 74161 / 74164 / 4015 74161 / 74164 / 4014 4052 7490 / 74390 / 4510 4518
4094 7410 7427 4033 7473 / 7476 7493 / 74161 / 74163 / 74193 / 74393 7486 / 74266 / 4070 / 4077 4026
4040 4042 4043 4044 4046 4047 4049 4050 4051 4052 4053 4056 4060 4063 4066 4067 4068 4069 4070 4071 4072 4073 4075 4076 4077 4078 4081 4082 4093 4094 4098 4099 4503 4510 4511 4512 4514
5 of 12
12-Stage Binary Counter Quad D-Type Latch ( Clocked ) Quad 3-Stage NOR R-S Latch Quad 3-Stage NAND R-S Latch Phase Locked Loop Multivibrator Hex Inverter Hex Buffer 8-Channel Analogue Multiplexor Dual 4-Channel Analogue Multiplexor Triple 2-Channel Analogue Multiplexor BCD to 7-Segment Decoder 14-Stage Binary Counter 4-Bit Magnitude Comparator Quad Bilateral Switch 16-Channel Multiplexor 8-Input NAND Gate Hex Inverter Quad 2-Input XOR Gate Quad 2-Input OR Gate Dual 4-Input OR Gate Triple 3-Input AND Gate Triple 3-Input OR Gate 4-Bit D-Type Latch Quad 2-Input XOR Gate 8-Input NOR/OR Quad 2-Input AND Gate Dual 4-Input AND Gate Quad 2-Input NAND Gate ( Schmitt trigger ) 8-Stage Shift Dual Monostable Multivibrator 8-Bit Addressable Latch Hex Buffer Decade Counter BCD to 7-Segment Decoder 8-Channel Data Selector 4 to 16 Line Decoder
74373 / 74374 / 74533 / 74573 / 74574
4538 7404 / 7405 / 7406 / 7414 / 4009 / 4069 7407 / 74240 / 74241 / 74244 / 74365 / 74541 / 4503 / 40106 4016 7447 / 7448 / 4511 7485 / 4585
7430 7404 / 7405 / 7406 / 7414 / 4009 / 4049 7486 / 74266 / 4030 / 4077 7432 7411
7486 / 74266 / 4030 / 4070 7408 7421 7400 / 7403 / 74132 / 4011 / 40107 4021 74121 / 74221 / 4528 74259 7407 / 74240 / 74241 / 74244 / 74365 / 74541 / 4050 / 40106 7490 / 74390 / 4017 7447 / 7448 / 4056 74154
4516 4518 4520 4528 4532 4538 4541 4541 4555 4585 40103 40106 40107 40110 40174
Binary Counter ( Presetable ) Dual BCD Counter Dual Binary Counter Dual Monostable Multivibrator 8-Bit Priority Encoder Multivibrator Programmable Timer Oscillator Dual Binary to 1 of 4 Decoder 4-Bit Magnitude Comparator 8-Stage Counter Hex Buffer ( Schmitt trigger ) Dual 2-Input NAND Gate Up/Down Decade Counter Hex D-Type Flip-Flop
4520 4018 4516 74121 / 74221 / 4098 4047
7485 / 4063 7407 / 74240 / 74241 / 74244 / 74365 / 74541 / 4050 / 4503 7400 / 7403 / 74132 / 4011 / 4093 7474 / 74175 / 74273 / 4013
NAND Gates Device 7400 7403 7410 7420 7430 74132 74133 4011 4012 4023 4068 4093 40107
Function Quad 2-Input NAND Gate Quad 2-Input NAND Gate ( Open collector ) Triple 3-Input NAND Gate Dual 4-Input NAND Gate 8-Input NAND Gate Quad 2-Input NAND Gate ( Schmitt trigger ) 13-Input NAND Gate Quad 2-Input NAND Gate Dual 4-Input NAND Gate Triple 3-Input NAND Gate 8-Input NAND Gate Quad 2-Input NAND Gate ( Schmitt trigger ) Dual 2-Input NAND Gate
Similar Devices 7403 / 74132 / 4011 / 4093 / 40107 7400 / 74132 / 4011 / 4093 / 40107 4023 4012 4068 7400 / 7403 / 4011 / 4093 / 40107 7400 / 7403 / 74132 / 4093 / 40107 7420 7410 7430 7400 / 7403 / 74132 / 4011 / 40107 7400 / 7403 / 74132 / 4011 / 4093
NOR Gates Device
6 of 12
Function
Similar Devices
7402 7427 74260 4001 4002 4025
Quad 2-Input NOR Gate Triple 3-Input NOR Gate Dual 5-Input NOR Gate Quad 2-Input NOR Gate Dual 4-Input NOR Gate Triple 3-Input NOR Gate
4001 4025 7402 7427
AND Gates Device 7408 7411 7421 4073 4081 4082
Function Quad 2-Input AND Gate Triple 3-Input AND Gate Dual 4-Input AND Gate Triple 3-Input AND Gate Quad 2-Input AND Gate Dual 4-Input AND Gate
Similar Devices 4081 4073 4082 7411 7408 7421
OR Gates Device 7432 4071 4072 4075
Function Quad 2-Input OR Gate Quad 2-Input OR Gate Dual 4-Input OR Gate Triple 3-Input OR Gate
Similar Devices 4071 7432
XOR Gates Device 7486 74266 4030 4070 4077
Buffers
7 of 12
Function Quad 2-Input XOR Gate Quad 2-Input XOR Gate Quad 2-Input XOR Gate Quad 2-Input XOR Gate Quad 2-Input XOR Gate
Similar Devices 74266 / 4030 / 4070 / 4077 7486 / 4030 / 4070 / 4077 7486 / 74266 / 4070 / 4077 7486 / 74266 / 4030 / 4077 7486 / 74266 / 4030 / 4070
Device 7407 74365 4050 4503 40106
Function
Similar Devices
Hex Buffer Hex Buffer Hex Buffer Hex Buffer Hex Buffer ( Scmitt trigger )
74240 / 74241 / 74244 / 74365 / 74541 / 4050 / 4503 / 40106 7407 / 74240 / 74241 / 74244 / 74541 / 4050 / 4503 / 40106 7407 / 74240 / 74241 / 74244 / 74365 / 74541 / 4503 / 40106 7407 / 74240 / 74241 / 74244 / 74365 / 74541 / 4050 / 40106 7407 / 74240 / 74241 / 74244 / 74365 / 74541 / 4050 / 4503
Inverters Device 7404 7405 7406 7414 4009 4049 4069
Function Hex Inverter Hex Inverter ( Open collector ) Hex Inverter ( Open collector ) Hex Inverter ( Schmitt trigger ) Hex Inverter Hex Inverter Hex Inverter
Similar Devices 7405 / 7406 / 7414 / 4009 / 4049 / 4069 7404 / 7406 / 7414 / 4009 / 4049 / 4069 7404 / 7405 / 7414 / 4009 / 4049 / 4069 7404 / 7405 / 7406 / 4009 / 4049 / 4069 7404 / 7405 / 7406 / 7414 / 4049 / 4069 7404 / 7405 / 7406 / 7414 / 4009 / 4069 7404 / 7405 / 7406 / 7414 / 4009 / 4049
Interface Devices Device 74125 74240 74241 74244 74245 74373 74374 74533 74541 74573 74574
Function Quad Bus Buffer Octal Buffer Octal Buffer Octal Buffer Octal Bus Transceiver Octal D-Type Latch ( Inverting / Tri-State ) Octal D-Type Latch Octal D-Type Latch Octal Buffer Octal D-Type Latch Octal D-Type Latch
Similar Devices 7407 / 74241 / 74244 / 74365 / 74541 / 4050 / 4503 / 40106 7407 / 74240 / 74244 / 74365 / 74541 / 4050 / 4503 / 40106 7407 / 74240 / 74241 / 74365 / 74541 / 4050 / 4503 / 40106 74374 / 74533 / 74573 / 74574 / 4042 74373 / 74533 / 74573 / 74574 / 4042 74373 / 74374 / 74573 / 74574 / 4042 7407 / 74240 / 74241 / 74244 / 74365 / 4050 / 4503 / 40106 74373 / 74374 / 74533 / 74574 / 4042 74373 / 74374 / 74533 / 74573 / 4042
Counters Device
8 of 12
Function
Similar Devices
7490 7493 74161 74163 74193 74390 74393 4017 4018 4020 4022 4024 4029 4040 4060 4510 4516 4518 4520 40103 40110
Decade Counter 4-Bit Binary Counter 4-Bit Binary Counter 4-Bit Binary Counter Dual 4-Bit Binary Counter Dual Decade Counter Dual 4-Bit Binary Counter Decade Counter BCD Counter ( Presettable ) 14-Stage Ripple Counter Divide by 8 Counter 7-Stage Ripple Counter 4-Bit Binary Counter 12-Stage Binary Counter 14-Stage Binary Counter Decade Counter Binary Counter ( Presetable ) Dual BCD Counter Dual Binary Counter 8-Stage Counter Up/Down Decade Counter
74390 / 4017 / 4510 74161 / 74163 / 74193 / 74393 / 4029 7493 / 74163 / 74193 / 74393 / 4029 7493 / 74161 / 74193 / 74393 / 4029 7493 / 74161 / 74163 / 74393 / 4029 7490 / 4017 / 4510 7493 / 74161 / 74163 / 74193 / 4029 7490 / 74390 / 4510 4518
7493 / 74161 / 74163 / 74193 / 74393
7490 / 74390 / 4017 4520 4018 4516
Latches and Flip-Flops Device 7473 7474 7476 74175 74273 74279 74373 74374 74533 74573 74574 4013
9 of 12
Function Dual J-K Flip-Flop Dual D-Type Flip-Flop Dual J-K Flip-Flop Quad D-Type Flip-Flop Octal D-Type Flip-Flop Octal S-R Latch Octal D-Type Latch ( Inverting / Tri-State ) Octal D-Type Latch Octal D-Type Latch Octal D-Type Latch Octal D-Type Latch Dual D-Type Flip-Flop
Similar Devices 7476 / 4027 74175 / 74273 / 4013 / 40174 7473 / 4027 7474 / 74273 / 4013 / 40174 7474 / 74175 / 4013 / 40174 74374 / 74533 / 74573 / 74574 / 4042 74373 / 74533 / 74573 / 74574 / 4042 74373 / 74374 / 74573 / 74574 / 4042 74373 / 74374 / 74533 / 74574 / 4042 74373 / 74374 / 74533 / 74573 / 4042 7474 / 74175 / 74273 / 40174
4027 4042 4043 4044 4076 40174
Dual J-K Flip-Flop ( Master / Slave ) Quad D-Type Latch ( Clocked ) Quad 3-Stage NOR R-S Latch Quad 3-Stage NAND R-S Latch 4-Bit D-Type Latch Hex D-Type Flip-Flop
7473 / 7476 74373 / 74374 / 74533 / 74573 / 74574
7474 / 74175 / 74273 / 4013
Decoders Device 7447 7448 74137 74138 74139 74154 74259 4026 4028 4033 4056 4067 4099 4511 4514 4555
Function BCD to 7-Segment decoder ( 15v ) BCD to 7-Segment decoder 3 to 8 Line Decoder 3 to 8 Line Decoder Dual 2 to 4 Line Decoder 4 to 16 Line Decoder 8-Bit Addressable Latch 7-Segment Display Decade Counter BCD to Decimal Decoder 7-Segment Display Decade Counter BCD to 7-Segment Decoder 16-Channel Multiplexor 8-Bit Addressable Latch BCD to 7-Segment Decoder 4 to 16 Line Decoder Dual Binary to 1 of 4 Decoder
Similar Devices 7448 / 4056 / 4511 7447 / 4056 / 4511 74138 74137 4514 4099 4033 4026 7447 / 7448 / 4511 74259 7447 / 7448 / 4056 74154
Encoders Device 74157 4512
Function
Similar Devices
Quad 2 to 1 Line Select 8-Channel Data Selector
Shift s Device
10 of 12
Function
Similar Devices
74161 74164 4014 4015 4021 4035 4094
8-Bit Shift 8-Bit Shift 8-Bit Shift 8-Bit Shift 8-Stage Shift 4-Stage Shift 8-Stage Shift
74164 / 4014 / 4015 74161 / 4014 / 4015 74161 / 74164 / 4015 74161 / 74164 / 4014 4094 4021
Computational Devices Device
Function
7483 7485 74283 74688 4008 4063 4532 4585
4-Bit Binary Full Adder 4-Bit Magnitude Comparator 4-Bit Binary Full Adder 8-Bit Magnitude Comparator 4-Bit Full Adder 4-Bit Magnitude Comparator 8-Bit Priority Encoder 4-Bit Magnitude Comparator
Similar Devices 74283 4063 / 4585 7483
7485 / 4585 7485 / 4063
Monostables and Multivibrators Device 74121 74123 74221 4047 4098 4528 4538 4541 4541
Function Monostable Multivibrator Dual Regtriggerable Monostable Dual Monostable Multivibrator Multivibrator Dual Monostable Multivibrator Dual Monostable Multivibrator Multivibrator Programmable Timer Oscillator
Similar Devices 74221 / 4098 / 4528 74121 / 4098 / 4528 4538 74121 / 74221 / 4528 74121 / 74221 / 4098 4047
Analogue Switches Device
11 of 12
Function
Similar Devices
4016 4051 4052 4053 4066
4-Channel Analogue Multiplexor 8-Channel Analogue Multiplexor Dual 4-Channel Analogue Multiplexor Triple 2-Channel Analogue Multiplexor Quad Bilateral Switch
4052 4016
Miscellaneous Functions Device 4007 4019 4046 4078
12 of 12
Function Complementary Pair plus Inverter Quad AND/OR Select Gate Phase Locked Loop 8-Input NOR/OR
Similar Devices
Cross-Reference Here is a comprehensive cross-reference of TTL and CMOS chips that are readily available over the counter ( from such places as Maplin Electronics in the UK ). Tables of both TTL and CMOS devices are provided along with tables grouping chips with the same functionality together. The following tables are available ... TTL Device Summary CMOS Device Summary NAND Gates NOR Gates AND Gates OR Gates XOR Gates Buffers Inverters Interface Devices Counters Latches and Flip-Flops Decoders Encoders Shift s Computational Devices Monostables and Multivibrators Analogue Switches Miscellaneous Functions
Please note that although the descriptions of the chips are taken from manufacturer's data sheets and other sources; these descriptions are only a brief indication of the generic functionality of that chip and a particular chip may have functionality that is slightly different to that actually required. Before using any device in the design or implementation of a project; always consult the original manufacturer's data sheet to ensure that a particular device is suitable for your purposes.
1 of 12
E&OE.
TTL Device Summary Please click on a device number to see the table of devices that belong to the same group.
Device 7400 7402 7403 7404 7405 7406 7407 7408 7410 7411 7414 7420 7421 7427 7430 7432 7447 7448 7473 7474 7476 7483 7485 7486 7490 7493 74121
2 of 12
Function Quad 2-Input NAND Gate Quad 2-Input NOR Gate Quad 2-Input NAND Gate ( Open collector ) Hex Inverter Hex Inverter ( Open collector ) Hex Inverter ( Open collector ) Hex Buffer Quad 2-Input AND Gate Triple 3-Input NAND Gate Triple 3-Input AND Gate Hex Inverter ( Schmitt trigger ) Dual 4-Input NAND Gate Dual 4-Input AND Gate Triple 3-Input NOR Gate 8-Input NAND Gate Quad 2-Input OR Gate BCD to 7-Segment decoder ( 15v ) BCD to 7-Segment decoder Dual J-K Flip-Flop Dual D-Type Flip-Flop Dual J-K Flip-Flop 4-Bit Binary Full Adder 4-Bit Magnitude Comparator Quad 2-Input XOR Gate Decade Counter 4-Bit Binary Counter Monostable Multivibrator
Similar Devices 7403 / 74132 / 4011 / 4093 / 40107 4001 7400 / 74132 / 4011 / 4093 / 40107 7405 / 7406 / 7414 / 4009 / 4049 / 4069 7404 / 7406 / 7414 / 4009 / 4049 / 4069 7404 / 7405 / 7414 / 4009 / 4049 / 4069 74240 / 74241 / 74244 / 74365 / 74541 / 4050 / 4503 / 40106 4081 4023 4073 7404 / 7405 / 7406 / 4009 / 4049 / 4069 4012 4082 4025 4068 4071 7448 / 4056 / 4511 7447 / 4056 / 4511 7476 / 4027 74175 / 74273 / 4013 / 40174 7473 / 4027 74283 4063 / 4585 74266 / 4030 / 4070 / 4077 74390 / 4017 / 4510 74161 / 74163 / 74193 / 74393 / 4029 74221 / 4098 / 4528
74123 74125 74132 74133 74137 74138 74139 74154 74157 74161 74163 74161 74164 74175 74193 74221 74240 74241 74244 74245 74259 74260 74266 74273 74279 74283 74365 74373 74373 74374 74374 74390 74393 74533 74533 74541 74573
3 of 12
Dual Regtriggerable Monostable Quad Bus Buffer Quad 2-Input NAND Gate ( Schmitt trigger ) 13-Input NAND Gate 3 to 8 Line Decoder 3 to 8 Line Decoder Dual 2 to 4 Line Decoder 4 to 16 Line Decoder Quad 2 to 1 Line Select 4-Bit Binary Counter 4-Bit Binary Counter 8-Bit Shift 8-Bit Shift Quad D-Type Flip-Flop Dual 4-Bit Binary Counter Dual Monostable Multivibrator Octal Buffer Octal Buffer Octal Buffer Octal Bus Transceiver 8-Bit Addressable Latch Dual 5-Input NOR Gate Quad 2-Input XOR Gate Octal D-Type Flip-Flop Octal S-R Latch 4-Bit Binary Full Adder Hex Buffer Octal D-Type Latch ( Inverting / Tri-State ) Octal D-Type Latch ( Inverting / Tri-State ) Octal D-Type Latch Octal D-Type Latch Dual Decade Counter Dual 4-Bit Binary Counter Octal D-Type Latch Octal D-Type Latch Octal Buffer Octal D-Type Latch
7400 / 7403 / 4011 / 4093 / 40107 74138 74137 4514 7493 / 74163 / 74193 / 74393 / 4029 7493 / 74161 / 74193 / 74393 / 4029 74164 / 4014 / 4015 74161 / 4014 / 4015 7474 / 74273 / 4013 / 40174 7493 / 74161 / 74163 / 74393 / 4029 74121 / 4098 / 4528 7407 / 74241 / 74244 / 74365 / 74541 / 4050 / 4503 / 40106 7407 / 74240 / 74244 / 74365 / 74541 / 4050 / 4503 / 40106 7407 / 74240 / 74241 / 74365 / 74541 / 4050 / 4503 / 40106 4099 7486 / 4030 / 4070 / 4077 7474 / 74175 / 4013 / 40174 7483 7407 / 74240 / 74241 / 74244 / 74541 / 4050 / 4503 / 40106 74374 / 74533 / 74573 / 74574 / 4042 74374 / 74533 / 74573 / 74574 / 4042 74373 / 74533 / 74573 / 74574 / 4042 74373 / 74533 / 74573 / 74574 / 4042 7490 / 4017 / 4510 7493 / 74161 / 74163 / 74193 / 4029 74373 / 74374 / 74573 / 74574 / 4042 74373 / 74374 / 74573 / 74574 / 4042 7407 / 74240 / 74241 / 74244 / 74365 / 4050 / 4503 / 40106 74373 / 74374 / 74533 / 74574 / 4042
74573 74574 74574 74688
Octal D-Type Latch Octal D-Type Latch Octal D-Type Latch 8-Bit Magnitude Comparator
74373 / 74374 / 74533 / 74574 / 4042 74373 / 74374 / 74533 / 74573 / 4042 74373 / 74374 / 74533 / 74573 / 4042
CMOS Device Summary Please click on a device number to see the table of devices that belong to the same group.
Device 4001 4002 4007 4008 4009 4011 4012 4013 4014 4015 4016 4017 4018 4019 4020 4021 4022 4023 4024 4025 4026 4027 4028 4029 4030 4033 4035
4 of 12
Function Quad 2-Input NOR Gate Dual 4-Input NOR Gate Complementary Pair plus Inverter 4-Bit Full Adder Hex Inverter Quad 2-Input NAND Gate Dual 4-Input NAND Gate Dual D-Type Flip-Flop 8-Bit Shift 8-Bit Shift 4-Channel Analogue Multiplexor Decade Counter BCD Counter ( Presettable ) Quad AND/OR Select Gate 14-Stage Ripple Counter 8-Stage Shift Divide by 8 Counter Triple 3-Input NAND Gate 7-Stage Ripple Counter Triple 3-Input NOR Gate 7-Segment Display Decade Counter Dual J-K Flip-Flop ( Master / Slave ) BCD to Decimal Decoder 4-Bit Binary Counter Quad 2-Input XOR Gate 7-Segment Display Decade Counter 4-Stage Shift
Similar Devices 7402
7404 / 7405 / 7406 / 7414 / 4049 / 4069 7400 / 7403 / 74132 / 4093 / 40107 7420 7474 / 74175 / 74273 / 40174 74161 / 74164 / 4015 74161 / 74164 / 4014 4052 7490 / 74390 / 4510 4518
4094 7410 7427 4033 7473 / 7476 7493 / 74161 / 74163 / 74193 / 74393 7486 / 74266 / 4070 / 4077 4026
4040 4042 4043 4044 4046 4047 4049 4050 4051 4052 4053 4056 4060 4063 4066 4067 4068 4069 4070 4071 4072 4073 4075 4076 4077 4078 4081 4082 4093 4094 4098 4099 4503 4510 4511 4512 4514
5 of 12
12-Stage Binary Counter Quad D-Type Latch ( Clocked ) Quad 3-Stage NOR R-S Latch Quad 3-Stage NAND R-S Latch Phase Locked Loop Multivibrator Hex Inverter Hex Buffer 8-Channel Analogue Multiplexor Dual 4-Channel Analogue Multiplexor Triple 2-Channel Analogue Multiplexor BCD to 7-Segment Decoder 14-Stage Binary Counter 4-Bit Magnitude Comparator Quad Bilateral Switch 16-Channel Multiplexor 8-Input NAND Gate Hex Inverter Quad 2-Input XOR Gate Quad 2-Input OR Gate Dual 4-Input OR Gate Triple 3-Input AND Gate Triple 3-Input OR Gate 4-Bit D-Type Latch Quad 2-Input XOR Gate 8-Input NOR/OR Quad 2-Input AND Gate Dual 4-Input AND Gate Quad 2-Input NAND Gate ( Schmitt trigger ) 8-Stage Shift Dual Monostable Multivibrator 8-Bit Addressable Latch Hex Buffer Decade Counter BCD to 7-Segment Decoder 8-Channel Data Selector 4 to 16 Line Decoder
74373 / 74374 / 74533 / 74573 / 74574
4538 7404 / 7405 / 7406 / 7414 / 4009 / 4069 7407 / 74240 / 74241 / 74244 / 74365 / 74541 / 4503 / 40106 4016 7447 / 7448 / 4511 7485 / 4585
7430 7404 / 7405 / 7406 / 7414 / 4009 / 4049 7486 / 74266 / 4030 / 4077 7432 7411
7486 / 74266 / 4030 / 4070 7408 7421 7400 / 7403 / 74132 / 4011 / 40107 4021 74121 / 74221 / 4528 74259 7407 / 74240 / 74241 / 74244 / 74365 / 74541 / 4050 / 40106 7490 / 74390 / 4017 7447 / 7448 / 4056 74154
4516 4518 4520 4528 4532 4538 4541 4541 4555 4585 40103 40106 40107 40110 40174
Binary Counter ( Presetable ) Dual BCD Counter Dual Binary Counter Dual Monostable Multivibrator 8-Bit Priority Encoder Multivibrator Programmable Timer Oscillator Dual Binary to 1 of 4 Decoder 4-Bit Magnitude Comparator 8-Stage Counter Hex Buffer ( Schmitt trigger ) Dual 2-Input NAND Gate Up/Down Decade Counter Hex D-Type Flip-Flop
4520 4018 4516 74121 / 74221 / 4098 4047
7485 / 4063 7407 / 74240 / 74241 / 74244 / 74365 / 74541 / 4050 / 4503 7400 / 7403 / 74132 / 4011 / 4093 7474 / 74175 / 74273 / 4013
NAND Gates Device 7400 7403 7410 7420 7430 74132 74133 4011 4012 4023 4068 4093 40107
Function Quad 2-Input NAND Gate Quad 2-Input NAND Gate ( Open collector ) Triple 3-Input NAND Gate Dual 4-Input NAND Gate 8-Input NAND Gate Quad 2-Input NAND Gate ( Schmitt trigger ) 13-Input NAND Gate Quad 2-Input NAND Gate Dual 4-Input NAND Gate Triple 3-Input NAND Gate 8-Input NAND Gate Quad 2-Input NAND Gate ( Schmitt trigger ) Dual 2-Input NAND Gate
Similar Devices 7403 / 74132 / 4011 / 4093 / 40107 7400 / 74132 / 4011 / 4093 / 40107 4023 4012 4068 7400 / 7403 / 4011 / 4093 / 40107 7400 / 7403 / 74132 / 4093 / 40107 7420 7410 7430 7400 / 7403 / 74132 / 4011 / 40107 7400 / 7403 / 74132 / 4011 / 4093
NOR Gates Device
6 of 12
Function
Similar Devices
7402 7427 74260 4001 4002 4025
Quad 2-Input NOR Gate Triple 3-Input NOR Gate Dual 5-Input NOR Gate Quad 2-Input NOR Gate Dual 4-Input NOR Gate Triple 3-Input NOR Gate
4001 4025 7402 7427
AND Gates Device 7408 7411 7421 4073 4081 4082
Function Quad 2-Input AND Gate Triple 3-Input AND Gate Dual 4-Input AND Gate Triple 3-Input AND Gate Quad 2-Input AND Gate Dual 4-Input AND Gate
Similar Devices 4081 4073 4082 7411 7408 7421
OR Gates Device 7432 4071 4072 4075
Function Quad 2-Input OR Gate Quad 2-Input OR Gate Dual 4-Input OR Gate Triple 3-Input OR Gate
Similar Devices 4071 7432
XOR Gates Device 7486 74266 4030 4070 4077
Buffers
7 of 12
Function Quad 2-Input XOR Gate Quad 2-Input XOR Gate Quad 2-Input XOR Gate Quad 2-Input XOR Gate Quad 2-Input XOR Gate
Similar Devices 74266 / 4030 / 4070 / 4077 7486 / 4030 / 4070 / 4077 7486 / 74266 / 4070 / 4077 7486 / 74266 / 4030 / 4077 7486 / 74266 / 4030 / 4070
Device 7407 74365 4050 4503 40106
Function
Similar Devices
Hex Buffer Hex Buffer Hex Buffer Hex Buffer Hex Buffer ( Scmitt trigger )
74240 / 74241 / 74244 / 74365 / 74541 / 4050 / 4503 / 40106 7407 / 74240 / 74241 / 74244 / 74541 / 4050 / 4503 / 40106 7407 / 74240 / 74241 / 74244 / 74365 / 74541 / 4503 / 40106 7407 / 74240 / 74241 / 74244 / 74365 / 74541 / 4050 / 40106 7407 / 74240 / 74241 / 74244 / 74365 / 74541 / 4050 / 4503
Inverters Device 7404 7405 7406 7414 4009 4049 4069
Function Hex Inverter Hex Inverter ( Open collector ) Hex Inverter ( Open collector ) Hex Inverter ( Schmitt trigger ) Hex Inverter Hex Inverter Hex Inverter
Similar Devices 7405 / 7406 / 7414 / 4009 / 4049 / 4069 7404 / 7406 / 7414 / 4009 / 4049 / 4069 7404 / 7405 / 7414 / 4009 / 4049 / 4069 7404 / 7405 / 7406 / 4009 / 4049 / 4069 7404 / 7405 / 7406 / 7414 / 4049 / 4069 7404 / 7405 / 7406 / 7414 / 4009 / 4069 7404 / 7405 / 7406 / 7414 / 4009 / 4049
Interface Devices Device 74125 74240 74241 74244 74245 74373 74374 74533 74541 74573 74574
Function Quad Bus Buffer Octal Buffer Octal Buffer Octal Buffer Octal Bus Transceiver Octal D-Type Latch ( Inverting / Tri-State ) Octal D-Type Latch Octal D-Type Latch Octal Buffer Octal D-Type Latch Octal D-Type Latch
Similar Devices 7407 / 74241 / 74244 / 74365 / 74541 / 4050 / 4503 / 40106 7407 / 74240 / 74244 / 74365 / 74541 / 4050 / 4503 / 40106 7407 / 74240 / 74241 / 74365 / 74541 / 4050 / 4503 / 40106 74374 / 74533 / 74573 / 74574 / 4042 74373 / 74533 / 74573 / 74574 / 4042 74373 / 74374 / 74573 / 74574 / 4042 7407 / 74240 / 74241 / 74244 / 74365 / 4050 / 4503 / 40106 74373 / 74374 / 74533 / 74574 / 4042 74373 / 74374 / 74533 / 74573 / 4042
Counters Device
8 of 12
Function
Similar Devices
7490 7493 74161 74163 74193 74390 74393 4017 4018 4020 4022 4024 4029 4040 4060 4510 4516 4518 4520 40103 40110
Decade Counter 4-Bit Binary Counter 4-Bit Binary Counter 4-Bit Binary Counter Dual 4-Bit Binary Counter Dual Decade Counter Dual 4-Bit Binary Counter Decade Counter BCD Counter ( Presettable ) 14-Stage Ripple Counter Divide by 8 Counter 7-Stage Ripple Counter 4-Bit Binary Counter 12-Stage Binary Counter 14-Stage Binary Counter Decade Counter Binary Counter ( Presetable ) Dual BCD Counter Dual Binary Counter 8-Stage Counter Up/Down Decade Counter
74390 / 4017 / 4510 74161 / 74163 / 74193 / 74393 / 4029 7493 / 74163 / 74193 / 74393 / 4029 7493 / 74161 / 74193 / 74393 / 4029 7493 / 74161 / 74163 / 74393 / 4029 7490 / 4017 / 4510 7493 / 74161 / 74163 / 74193 / 4029 7490 / 74390 / 4510 4518
7493 / 74161 / 74163 / 74193 / 74393
7490 / 74390 / 4017 4520 4018 4516
Latches and Flip-Flops Device 7473 7474 7476 74175 74273 74279 74373 74374 74533 74573 74574 4013
9 of 12
Function Dual J-K Flip-Flop Dual D-Type Flip-Flop Dual J-K Flip-Flop Quad D-Type Flip-Flop Octal D-Type Flip-Flop Octal S-R Latch Octal D-Type Latch ( Inverting / Tri-State ) Octal D-Type Latch Octal D-Type Latch Octal D-Type Latch Octal D-Type Latch Dual D-Type Flip-Flop
Similar Devices 7476 / 4027 74175 / 74273 / 4013 / 40174 7473 / 4027 7474 / 74273 / 4013 / 40174 7474 / 74175 / 4013 / 40174 74374 / 74533 / 74573 / 74574 / 4042 74373 / 74533 / 74573 / 74574 / 4042 74373 / 74374 / 74573 / 74574 / 4042 74373 / 74374 / 74533 / 74574 / 4042 74373 / 74374 / 74533 / 74573 / 4042 7474 / 74175 / 74273 / 40174
4027 4042 4043 4044 4076 40174
Dual J-K Flip-Flop ( Master / Slave ) Quad D-Type Latch ( Clocked ) Quad 3-Stage NOR R-S Latch Quad 3-Stage NAND R-S Latch 4-Bit D-Type Latch Hex D-Type Flip-Flop
7473 / 7476 74373 / 74374 / 74533 / 74573 / 74574
7474 / 74175 / 74273 / 4013
Decoders Device 7447 7448 74137 74138 74139 74154 74259 4026 4028 4033 4056 4067 4099 4511 4514 4555
Function BCD to 7-Segment decoder ( 15v ) BCD to 7-Segment decoder 3 to 8 Line Decoder 3 to 8 Line Decoder Dual 2 to 4 Line Decoder 4 to 16 Line Decoder 8-Bit Addressable Latch 7-Segment Display Decade Counter BCD to Decimal Decoder 7-Segment Display Decade Counter BCD to 7-Segment Decoder 16-Channel Multiplexor 8-Bit Addressable Latch BCD to 7-Segment Decoder 4 to 16 Line Decoder Dual Binary to 1 of 4 Decoder
Similar Devices 7448 / 4056 / 4511 7447 / 4056 / 4511 74138 74137 4514 4099 4033 4026 7447 / 7448 / 4511 74259 7447 / 7448 / 4056 74154
Encoders Device 74157 4512
Function
Similar Devices
Quad 2 to 1 Line Select 8-Channel Data Selector
Shift s Device
10 of 12
Function
Similar Devices
74161 74164 4014 4015 4021 4035 4094
8-Bit Shift 8-Bit Shift 8-Bit Shift 8-Bit Shift 8-Stage Shift 4-Stage Shift 8-Stage Shift
74164 / 4014 / 4015 74161 / 4014 / 4015 74161 / 74164 / 4015 74161 / 74164 / 4014 4094 4021
Computational Devices Device
Function
7483 7485 74283 74688 4008 4063 4532 4585
4-Bit Binary Full Adder 4-Bit Magnitude Comparator 4-Bit Binary Full Adder 8-Bit Magnitude Comparator 4-Bit Full Adder 4-Bit Magnitude Comparator 8-Bit Priority Encoder 4-Bit Magnitude Comparator
Similar Devices 74283 4063 / 4585 7483
7485 / 4585 7485 / 4063
Monostables and Multivibrators Device 74121 74123 74221 4047 4098 4528 4538 4541 4541
Function Monostable Multivibrator Dual Regtriggerable Monostable Dual Monostable Multivibrator Multivibrator Dual Monostable Multivibrator Dual Monostable Multivibrator Multivibrator Programmable Timer Oscillator
Similar Devices 74221 / 4098 / 4528 74121 / 4098 / 4528 4538 74121 / 74221 / 4528 74121 / 74221 / 4098 4047
Analogue Switches Device
11 of 12
Function
Similar Devices
4016 4051 4052 4053 4066
4-Channel Analogue Multiplexor 8-Channel Analogue Multiplexor Dual 4-Channel Analogue Multiplexor Triple 2-Channel Analogue Multiplexor Quad Bilateral Switch
4052 4016
Miscellaneous Functions Device 4007 4019 4046 4078
12 of 12
Function Complementary Pair plus Inverter Quad AND/OR Select Gate Phase Locked Loop 8-Input NOR/OR
Similar Devices
Related Documents 3m3m1z
2080sc-ntc Datasheet2 3f2i4
November 2022 0
Nano Hornet Org1411 Datasheet2 59j33
November 2019 38More Documents from "Psykovsky Becker Fùher" 5y4u5e
6l6m1j
December 2019 125
Laboratorio : Coriolis Y Bousinesq 2b6144
April 2020 29
Hybrid Performance Sample 4r1d1u
November 2022 0
6l6m1j
December 2019 30
Tesis Seguridad Industrial 2 3q336c
December 2019 30
