DATAWAREHOUSE: What is Data ware house: 1.A data warehouse is a relational data base that is designed for query and analysis rather than for transactional processing 2. its usually contains historical data derived from transactional data but it can include data from other sources

Data ware house is nothing but collection of transactional data and historical data and can be maintained in DWH for analysis purpose. They are 3 types of tools should be maintained in any data warehousing project 1. ETL Tools 2. OLAP Tools (or) Reporting Tools 3. Modeling Tool

1

ETL TOOLS: ETL is nothing but Extraction, Transformation, and Loading. a ETL Developer(those who are expertise in dwh extracts data from heterogeneous databases(or)Flat files, Transform data from source to target(dwh) while transforming needs to apply transformation rules and finally load data into dwh. There are several ETL Tools available in the market those are 1. Data stage 2. Informatica Power center 3. Abinitio 4. Oracle Warehouse Builder 5. Bodi (Business Objects Data Integration) 6. MSIS (Microsoft Integration Services) 7. Pentaho Kettle 8.Talend 9. Inaplex Inaport OLAP: OLAP is nothing but Online Analytical Processing and these tools are called as reporting Tools Also A OLAP Developer analyses the data ware house and generate reports based on selection criteria. There are several OLAP Tools are available 1. Business Objects 2. Cognos 3. Report Net 4. SAS 5. Micro Strategy 6. Hyperion 7. MSAS (Microsoft Analysis Services) MODELING TOOL: Those who are working with ERWIN Tool called data modeler .A data modeler can design data base of DWH with the help of fallowing tools A ETL Developer can extract data from source databases (or) flat files(.txt,csv,.xls etc) and populates into DWH .While populating data into DWH they are some staging areas can be maintained between source and target .these staging areas are called staging area1 and staging area2.

2

STAGING AREA: Staging Area is nothing but is temporary place which is used for cleansing unnecessary data (or) unwanted data (or) inconsistency data. Note: A Data Modeler can design DWH in two ways 1. ER Modeling 2. Dimensional Modeling ER Modeling: ER Modeling is nothing but entity relationship modeling. in this model always call table as entities and it may be second normal form (or) 3rd normal form (or) in between 2nd and 3rd normal form Dimensional Modeling: In this model tables called as dimensions (or) fact tables. It can be subdivided into three schemas. 1. Star Schema 2. Snow Flake Schema 3. Multi Star Schema (or) Hybrid (or) Galaxy Star Schema: A fact table surrounded by dimensions is called start schema. it looks like start In a start schema if there is only one fact table then it is called simple start schema. In a start schema if there are more than one fact table then it is called complex start schema

3

Sales Fact table: Sale_id Customer_id Product_id _id Time_id Promotion_id Sales_per_day Profit_per_day Dimension: _id _type _holder_name _open_date _nominee _open_balence Pramotion: Promotion_id Promotion_type Promotion_date Pramotion_designation Pramotion_Area

4

Product: Product_id Product_name Product_type Product_desc Product_version Product_stratdate Product_expdate Product_maxprice Product_wholeprice Customer: Cust_id Cust_name Cust_type Cust_address Cust_phone Cust_nationality Cust_gender Cust_father_name Cust_middle_name Time: Time_id Time_zone Time_format Month_day Week_day Year_day Week_Yeat DIMENSION TABLE: If a table contains primary keys and provides detail information about the table (or) master information of the table then called dimension table. FACT TABLE: If a table contains more foreign keys and it’s having transactions, provides summarized information such a table called fact table.

5

DIMENSION TYPES: There are several dimension types are available CONFORMED DIMENSION: If a dimension table shared with more than one fact table (or) having foreign key more than one fact table. Then that dimension table is called confirmed dimension. DEGENERATED DIMENSION: If a fact table act as dimension and it’s shared with another fact table (or) maintains foreign key in another fact table .such a table called degenerated dimension. JUNK DIMENSION: A junk dimension contains text values, genders,(male/female),flag values(True/false) and which is not use full to generate reports. Such dimensions is called junk dimension.

DIRTY DIMENSION: If a record occurs more than one time in a table by the difference of non key attribute such a table is called dirty dimension FACT TABLE TYPES: There are 3 types of fact s are available in fact table 1. Additive facts 2. Semi additive facts 3. Non additive facts ADDITIVE FACTS: If there is a possibility to add some value to the existing fact in the fact table .that facts we called as additive fact. SEMI ADDITIVE FACT: If there is possibility to add some value to the existing fact up to some extent in the fact table is we called as semi additive fact. NON ADDITIVE FACT: If there is not possibility to add some value to the existing fact in the fact table is we called as Non additive fact. SNOW FLAKE SCHEMA: Snow Flake schema maintains in dimension table normalized data .in this schema some dimension tables are not directly maintained relation ship with fact table and those are maintained relation ship with another dimension

6

DIFFERENCE BETWEEN STAR SCHEMA AND SNOW FLAKE SCHEMA: Star schema It maintains demoralized data in the dimension table Performance will be increased when ing fact table to dimension table when

Snow flake schema It maintains normalized data in the dimension table Performance will be decreases when ing fact table to dimension table to shrunken dimension table because it require more inner s when compared with snow flake Some dimension tables are not directly maintained relationship with fact table

compared with snow flake All dimension table should maintain ed relation ship directly with fact table

INTRODUCTION ABOUT ETL TOOLS:

What do ETLs tool do? An ETL tool is a tool that:  Extracts data from various data sources (usually legacy) Transforms data  from -> being optimized for transaction to -> being optimized for reporting and analysis  synchronizes the data coming from different databases data cleanses to remove errors  Loads data into a data warehouse ETL stands for Extarction,Transformation ,Load EExtraction from any source TTransformation(rich set of transformation capabilities) LLoading in to any target

Why use an ETL tool? ETL tools save time and money when developing a data warehouse by removing the need for “hand-coding”. “Hand Coding” is still the most common way of integrating data today. It requires hours and hours of development and expertise to create a Business-Intelligence-System. It is very difficult for data base s to connect between different brands of databases without using an external tool.

7

In the event that databases are altered or new databases need to be integrated, a lot of “hand-coded” work needs to be completely redone.

Different ETL Tools: There are several ETL Tools are available in the market those are 1. Data stage 2. Informatica Power center 3. Pentaho Kettle 4. Talend 5. Inaplex Inaport 6. Abinitio 7. Oracle Warehouse Builder 8. Bodi (Business Objects Data Integration) 9. MSIS (Microsoft Integration Services)

1. Data stage: Data stage is a comprehensive ETL tool Or we can say Data stage is an data Integration and transformation tool which enables collection and consolidation of data from several sources,its transformation and delivery into one or multiple target systems History begins in 1997 the first version of data stage released by VMRAK company it’s a US based company  Mr. Lee scheffner is the father of data stage Those days data stage we called as Data integrator In 1997 Data integrator acquired by company called TORRENT Again in 1999 INFORMIX Company has acquired this Data integrator from TORRENT Company In 2000 ASCENTIAL Company acquired this Data Integrator and after that Ascentaial Data stage server Edition From 6.0 to 7.5.1 versions they s only Unix flavor environment Because server configured on only Unix plot form environment In 2004, a version 7.5.x2 is released that server configuration for windows flat Form also. In 2004, December the version 7.5.x2 were having ASCENTIAL suite components Profile stage,  Quality stage,  Audit stage,  Meta stage,  DataStage Px,  DataStage Tx,  DataStage MUS, These are all Individual tools In 2005, February the IBM acquired all the ASCENTIAL suite components and the IBM released IBM DS EE i.e., enterprise edition. In 2006, the IBM has made some changes to the IBM DS EE and the changes are the integrated the profiling stage and audit stage into one, quality stage, Meta stage, and 8

DataStage Px.IBM WEBSPHERE DS & QS 8.0 In 2009, IBM has released another version that “IBM INFOSPHERE DS & QS 8.1”

Informatica Power center: Informatica has a very good commercial data integration suite  It was founded in 1993  It is the market share leader in data integration (Gartner Dataquest)  It has 2600 customers. Of those, there are fortune 100 companies, companies listed on the Dow Jones and government organization The company's sole focus is data integration  It has quite a big package for enterprises to integrate their systems, cleanse their data and can connect to a vast number of current and legacy systems

Pentaho Kettle: Pentaho is a commercial open-source BI suite that has a product called Kettle for data integration.  It uses an innovative meta-driven approach and has a strong and very easy-to-use GUI  The company started around 2001  It has a strong community of 13,500 ed s  It uses a stand-alone java engine that process the tasks for moving data between many different databases and files

Talend:  Talend is an open-source data integration tool It uses a code-generating approach and uses a GUI(implemented in Eclipse RC) It started around October 2006  It has a much smaller community then Pentaho, but is ed by 2 finance companies It generates Java code or Perl code which can later be run on a server

Inaplex: Inaplex is a small UK company InaPlex is a producer of Customer Data Integration products for mid-market CRM solutions Inaplex mainly focuses on providing simple solutions for it’s Customers to integrate their data into CRM and ing Software like Sage and Goldmine

9

Features Of Data stage: There are 5 important features of DataStage, they are - Any to Any, - Plat form Independent, - Node configuration, - Partition parallelism, and - Pipe line parallelism.

Any to Any: Data stage can Extarct data from any source and can load data in to any target

Platform Independent: A job can run in any processor is called platform independent Data stage jobs can run on 3 types of processors Three types of processor are there, they are 1. UNI Processor 2. Symmetric Multi Processor (SMP), and 3. Massively Multi Processor (MMP).

Node Configuration: Node is a logical U ie.instance of physical U The process of creating virtual U’s is called Node configuration

Example: ETL job requires executing 1000 records In Uni processor it takes 10 mins to execute 1000 records But in same thing SMP processor takes 2.5 mins to execute 1000 records

Difference between server jobs and Parallel jobs: Parallel jobs: 1. Datastage parallel jobs can run in parallel on multiple nodes 2. Parallel jobs partition parallelism(Round robin Hash modulus etc. 3. The transformer in Parallel jobs compiles in C++ 4. Parallel jobs run on more than one node 5. Parallel jobs run on unixplotform 6. Major difference in job architecture level Parallel jobs process in parallel. It uses the configuration file to know the number of U's defined to process parallely Server jobs: 1. Datastage server jobs do not run on multiple nodes 2. Data stage server jobs don't the parallelism (Round robin Hash modulus etc. 3. The transformer in server jobs compiles in Basic language 4. Data stage server jobs run on only one node 10

5. Data stage server jobs run on unix platform 6. Major difference in job architecture level Server jobs process in sequence one stage after other

Configuration File: What is configuration file? What is the use of this in data stage? It is normal text file. it is having the information about the processing and storage resources that are available for usage during parallel job execution. The default configuration file is having like Node: - it is logical processing unit which performs all ETL operations. Pools: - it is a collection of nodes. Fast Name: it is server name. by using this name it was executed our ETL jobs. Resource disk:- it is permanent memory area which stores all Repository components. Resource Scratch disk:-it is temporary memory area where the staging operation will be performed. Configuration file: Example: { node "node1" { fastname "abc" pools "" resource disk "/opt/IBM/InformationServer/Server/Datasets" {pools ""} resource scratchdisk "/opt/IBM/InformationServer/Server/Scratch" {pools ""} } node "node2" { fastname "abc" pools "" resource disk "/opt/IBM/InformationServer/Server/Datasets" {pools ""} resource scratchdisk "/opt/IBM/InformationServer/Server/Scratch" {pools ""} } }

11

Note: In a configuration file No node names has same name Default Node pool is “ “  At least one node must belong to the default node pool, which has a name of "" (zerolength string).

Pipeline parallelism: Pipe: Pipe is a channel through which data moves from one stage to another stage

Pipeline parallelism: It’s a technique of simultaneously processing Extraction, Transformation and, Loading

Partition Parallelism: Partitioning: Partioning is a technique of dividing the data into chunks Data stage s 8 types of partitions Partioning plays a important role in data stage Every stage in Data stage associated with default partitioning technique Defualt partinining technique is auto Note: Selection of partioning techniques is based on 1 .Data(Volume ,Type 2 .Stage 3. No of key Columns 5.Key column data type Partitioning techniques are grouped in to two categories 1.Key Based 2.Key Less Key Based Partitiong techniques: 1.Hash 2.Modulo 3.Range 4.DB2 Key Less Partioning techniques: 1.Random 2.Round robin 3.Entire

12

4.Same

Data stage Architecture: Data stage is a client server technology so that it has server components and client components Servercompoents (Unix) PX Engine Data stage Repository Package Installer

Client components (Windows) Data stage Data stage Manager Data stage Director Data stage Designer

Data stage Server: The server components again classified in to Data stage server: It is the heart of data stage and its contain the archestrate Engine usually this engine picks up requirement from the client component and according to the request it performs the operation and respond to the client components ,if it requires it get the information from data stage repository Data stage Repository: The repository conatins jobs,table definations,file definations,routines,shared containers etc Package Instaler: It is used to install the softwares and gives compatability to the other softwares

Client Components: The client component again classified into Data stage istartor Data stage Manager Data stage Director Data stage Designer Data stage : Ds can create projects and delete the projects Can give permissions to the s Can define global parameters Data stage Manager: Datastage Manager can import and export the jobs can create routines Can configure configuration file Data stage Director: 13

Da ta stage Director can validate ajobs Can run the jobs Can monitor a job Can schedule ajob Can view the job logs Data stage Designer: Through Data stage Designer a developer can design a jobs and compile and run a jobs

Differences between 7.5.x2 & 8.0.1: 7.5X2: 1. Four client components (Ds Designer,Ds Director,Ds Manager,Ds ) 2. Architecture Components( Server Components,Client Component 3. Two tier architecture 4.Os dependent with respect to s 5. Capable of Phase3, Phase4 6.No web based istration 7.File Based Repository 8.0.: 1. Five client components (Ds Designer,Ds Director,Information Analyzer,Ds , Web console) 2. Architecture Components Common Interface Common Repository Common Engine Common Connectivity Common Shared services 3. N- tier architecture 4. Os Independent with respect to s but one time dependent 5. Capable of All Phases 6.Web based istration through web console 7.Data base Based Repository

Data stage 7.5x2 Client Components: In 7.5x2 we have 4 client components Data stage Designer: 14

it is to create jobs, compile, run and multiple job compile. It can handle four type of jobs 1.Server Jobs 2. Parallel jobs 3. Job Sequencing 4. Main frame Jobs Data stage Director Using data stage Director Can schedule the jobs,run the jobs Can Monitor the jobs,Unlock the jobs,Batch jobs Can View (job, Status, logs) Message Handling Data stage Manager Can Import and Export the repository components Node Configuration Data stage Can create the projects Can delete the projects Organize the projects

Server Components: We have 3 server components 1. PX Engine: it is executing DataStage jobs and it automatically selects the partition technique. 2. Repository: It contains the repository components 3.Package Installer: Package Instaler has packs and Plug Ins

Data stage 8.0.1 Client Components: In 8.0.1 we have 5 client components Data stage Designer: it is to create jobs, compile, run and multiple job compile. 15

It can handle four type of jobs 1.Server Jobs 2. Parallel jobs 3. Job Sequencing 4. Main frame Jobs 5.Data Qulaity jobs Data stage Director Using data stage Director Can schedule the jobs,run the jobs Can Monitor the jobs,Unlock the jobs,Batch jobs Can View (job, Status, logs) Message Handling Data stage Can create the projects Can delete the projects Organize the projects Web Console: Through components can perform the below tasks 1.Security services 2.Scheduling services 3.Logging services 4.Reporting services 5.Domian Management 5.Session Management Information Analyzer: It is also console for IBM infosphere Information Server console It performs All activities of Phase1 1.Column Analysis 2.BaseLine Analysis 3.Primary Key Analysis 4.foriegn Key Analysis 5.Cross Domian Analysis

Data stage 8.0.1 Architecture: 1. Common Interface Unified is called a Common interface 1. Web console 2. Information Analyzer 16

3. Data stage Designer 4. Data stage Director 5. Data stage 2. Common Respository Common Repository devided in to two types 1. Global Repository: It is used for data stage jobs files would store here 2. Local Repository: for storing induvidual files Common repository we called as a Meta data server 3. Comon Engine: It is responsible for the following Data Profiling Analysis Data Data Quality Analysis Data Transmission Analysis 4. Common Connectivity It provides the common connections to the Common Repository

Stages Enhancements and Newly Introduced stages Comparison from 7.5x2 And 8.0.1: Stage Category Type

Available Stage version 7.5X2

Processing Stage Processing Stage Processing Stage Processing Stage

Stage Name SCD(Slowly Change Dimension) FTP(File Transfer Protocal) WTX(Webshere Transfer) Surrogate Key

Processing Stage Data Base Stage Data Base Stage Data Base Stage Data Base Stage

Look up IWAY Classic Federation ODBC Connector Netteza

Not Available Not Available Not Available Available Available (Normal Lookup,Sprase Lookup) Not Available Not Available Not Available Not Available

Data Base Stage

Sql builder

Not Available

Note: Data base stages and Processing stage has Enhancements has done Datastage Designer Window: Its has Title BarIBM Infosphere Datastage and Quality stage Designer

17

Avilable Stage in Version 8.0.1

Available Available Available Available (Enhance ment done

Available( Range Lookup,Case Lookup) Available Available Available Available Available (All Stages Technqs used wrto Builder)

Menu bar File,Edit,View,Repository,Diagram,Import,Export,Tools,Window,Help Tool BarTool Options like Jobproperties,Compile,Run RepositoryRepository which contains Repository components Palletehas list of categorize stages Designer Canvas: here we can design the jobs

File Stages: ---------------Sequential file stage: =============== Sequential file stage is a file stage which is used to read the data sequentially or Parallely. If it is 1 file - It reads the data sequentially If it is N files - It reads the data Parallely Sequential file s 1 Input link |1 Output Link | 1 reject link. To read the data, we have read methods. Read methods are a) Specific files b) File Patterns Specific File is for particular file And File Pattern is used for Wild cards. And in Error Mode. It has Continue Fail and Output If you select Continue-If any data type mismatch it will send the rest of the data to the target If you Select Fail- Job Abort or Any Data type mismatch Output- It will send the mismatch data to Rejected data file. Error data we get are Data type Mismatch Format Mismatch Condition Mismatch and we have the option like Missing File Mode: In this Option we have three sub options like Depends Error Ok (That means How to handle, if any file is missed) Different Options usage in Sequential file: ----------------------------------------------------Read Method=Specific file Then execute in sequencial mode 18

Read Method=File patternThen execute in file pattern Note :If we choose Read method =Specific file then it asks input file path If we select Read method=File Pattern then it asks ask pattern Example for file pattern: Emp1.txt Emp2.txt To read the data of above two files then file pattern should be like Emp?.txt ?--> for one character match *--> for one or more character match Example jobs for Lab Hand out: 1. Read Method =Specific files Rejectmode=Continue,Fail,Output Note:If Reject Mode=Output then you must provide the output reject link for rejected records other wise it gives error 2. Read Method=File Pattern Rejectmode=Continue,Fail,Output Note:If Reject Mode=Output then you must provide the output reject link for rejected records other wise it gives error 3. Read Method =Specific files Rejectmode=Continue,Fail,Output FileNameColumn=InputRecordFilepath Note1:If Reject Mode=Output then you must provide the output reject link for rejected records other wise it gives error Note2: If FileNameColumn=InputRecordFilepath Here FileNameColumn is an Option if we select this option then we have to create one more extra column in extended column properties then in output file you will get the InputRecordFilepathColumn extra at output 4. Read Method =Specific files Rejectmode=Continue,Fail,Output RowNumberColumn=InputRowNumberColumn Note1:If Reject Mode=Output then you must provide the output reject link for rejected records other wise it gives error Note2: RowNumberColumn=InputRowNumberColumn

19

Here RowNumberColumn is an Option if we select this option then we have to create one more extra column in extended column properties then in output file you will get the InputRowNumberColumn extra at output

Sequencialfile Options: Filter FileNameColumn RowNumcolumn Read Firstrows NullFieldvalue 1. Filter Options Sed command: -------------------Sed: is a stream Editor for filtering and transforming text from standard input to standard output Sed ‘5q’It displays first 5 lines Sed ‘2p’It displays all lines but 2nd line will displayed twice Sed ‘1d’it displays all records except first record Sed ‘1d,2d’ it displays all lines except the first and second record Sed –n ‘2,4p’ here it prints only from record 2 to 4 only Sed –n –e ‘2p’ –e ‘3p’It displays only 2 nd 3rd line Sed ‘$d’ it is for deleting the trailer record Grep commands: ----------------------Syntax: grep “string” Ex: grep “bhaskar” 1) grep –v “string” Ex: grep – v “bhaskar” it displays except ’bhaskar’ 2) grep –i “String” Ex: grep - i “bhaskar” it ignores case sensitive

20

Example Job for Sequential File: Requirement: Extracting EMP data from text file and loading into text file By using Sequential file Stage Here Read method= specific file(s) Input File data:

Output File data:

21

Job:

Properties for sequential_File_0:

Target Sequential_File_1 Properties: 22

Importing table definition from sequential file: Right click on sequential_file_0 Or double click on seqential_file_0

Click on Columns tab on left hand side tab

23

Click on Load Tab at Bottom It will show the Window like this

Now Click On import and select Sequential file definitions..

24

Now in the file list u select the file emp1.txt

Click on Import tab:

25

Tick the check box First line is column names and Click on Defines

Now Click on Ok and click on Close tab Now that file emp1.txt will show in the table Definition list

26

Now Select Emp1.txt in table definition list and click on OK

It will show Window like this

Now Click on OK and again Click on OK ….This is the way of procedure for importing table definition

27

2)Example Job for Sequential File: Requirement: Extracting EMP data from text file and loading into text file By using Sequential file Stage Here Read method=file pattern Input sequential_File_0 Properties: Emp1.txt

Emp2.txt

These two files are in this path: D:\dspractice\sanjeev\emp*.txt Requirement: Output target sequential_File_1:

28

Job:

Input Sequential_File_0 Properties:

29

Output Sequential_File_1 Properties:

30

3)Example Job for Sequential File: Requirement: Extracting EMP data from text file and loading into text file By using Sequential file Stage Here Read method= specific file(s) Reject Mode=Continue Continue: Continue to simply discard any rejected rows; Fail: Fail to stop if any row is rejected; Output to send rejected rows down a reject link.

here two records field delimiter is not properly ended empno=300,400 Input sequential file_0 data:

31

Job:

Input sequential file_0 data Properties:

32

Output sequential_File_01 Properties:

Output data:

4)Example Job for Sequential File: Requirement: Extracting EMP data from text file and loading into text file By using Sequential file Stage Here Read method= specific file(s) Reject Mode=Output

33

Input file data:

Input sequential file data :

Output Sequential File Data:

Output Rejects Data:

34

Job:

Note: if U select Reject Mode=Output then u must have reject link 5)Example Job for Sequential File: Requirement: Extracting EMP data from text file and loading into text file By using Sequential file Stage Here Read method= specific file(s) Reject Mode=Output Options: File Name Column=InputRecFilepath Note:Here u should create InputRecFilepath Column in Extended column Properties Job:

Input Seq file data: 35

Input Properties:

36

Columns:

Output Properties:

Outputdata:

37

6)Example Job for Sequential File: Requirement: Extracting EMP data from text file and loading into text file By using Sequential file Stage Here Read method= specific file(s) Reject Mode=Output Options: File Name Column=InputRecFilepath RowNumberColumn=InputRowNumberColumn Note:Here u should create InputRecFilepath Column and InputRowNumberColumn in Extended column Properties Job:

InputProperties:

38

Columns:

Input Data:

39

Output Properties:

OutputData:

40

7)Example Job for Sequential File: Requirement: Extracting EMP data from text file and loading into text file By using Sequential file Stage Here Read method= specific file(s) Reject Mode=Output Options: File Name Column=InputRecFilepath RowNumberColumn=InputRowNumberColumn Options Filter=Sed –n’3,5p’ Note:Here u should create InputRecFilepath Column and InputRowNumberColumn in Extended column Properties Input Source file data:

Input Sequential filedata:

41

Job:

Input properties:

42

Input Columns:

Output properties:

43

Output Data:

8)Example Job for Sequential File: Requirement: Extracting EMP data from text file and loading into text file By using Sequential file Stage Here Read method= specific file(s) Reject Mode=Continue Options: File Name Column=InputRecFilepath RowNumberColumn=InputRowNumberColumn Read First Rows=3 Input source File data:

Job:

44

Input sequential file properties:

Columns:

45

Output sequential file properties:

46

9)Example Job for Sequential File: Requirement: Extracting EMP data from text file and loading into text file By using Sequential file Stage Here Read method= specific file(s) Reject Mode=Output Options: File Name Column=InputRecFilepath RowNumberColumn=InputRowNumberColumn Read First Rows=5 Filter=grep “bhaskar” Grep Options: 3) grep “string” Ex: grep “bhaskar” 4) grep –v “string” Ex: grep – v “bhaskar” 5) grep –i “String” Ex: grep - i “bhaskar”

47

Source filed data:

Job:

Input sequential file Properties:

48

Columns:

Output sequential file properties:

49

Output Data:

10)Example Job for Sequential File: Requirement: Extracting EMP data from text file and loading into text file By using Sequential file Stage Here Read method= specific file(s) Reject Mode=Output Options: File Name Column=InputRecFilepath RowNumberColumn=InputRowNumberColumn Filter=grep –v “bhaskar” It dsiplay except bhaskar record Filter=grep –i “bhaskar”It display only bhaskar record “I “ means ignore case sensitive

50

Source filedata:

Job:

Input Sequential file stage properties:

Columns: 51

Output seqfile stage properties:

52

Usage of Parameters at Sequential file stage input file Path Example : ------------My input file is located in the path: C:\Sourcefiles\Bhaskar\Emp1.txt Here create one parameter for Path: C:\Sourcefiles\Bhaskar\ And another parameter for inputfile name: Emp1.txt Job Parameters Creation Process: Step1: Go to job parameters and click on paramer tab provide the below details

1 2 3

Parameter name

prompt

type

Default Value

$APT_CLOBBER_OUTPUT Inputpath Inputfilename

automaticaly overwrite Inputfilepath InputfileName

List Pathname String

FALSE C:\Sourcefiles\Bhaskar\ Empdata1.txt

File Stages: ----------------Data set: -----------Dataset is the parallel processing file stage which is used for staging the data when we design dependent jobs. By Default dataset is parallel processing stage Dataset will be stored in the binary format. If we use dataset for the jobs, data will be stored in the Data Stage. That’s is inside the repository. Dataset will over come the limitations of the sequential file. Limitations of sequential files are 1) Memory limitations ( It can store up to 2 GB Memory in the file format ) 2) Sequential ( By default it is Sequential ) 3) Conversion Problem ( Every time when we run the job, it has to convert from one format to another format) 4) Stores the data outside the Data stage ( Where in Dataset it stores the data inside the Data stage) Types of Datasets are 2 types 1) Virtual Dataset 2) Persistence Dataset Virtual Dataset is the temporary dataset which is formed when ing in the link. Persistence Dataset is the Permanent Dataset which is formed when loaded in the Target.

53

Help Text Allows files or data s over written if they al exist

Alias names of Datasets are a) Orchestrate Files b) Operating System Files Datasets are Multiple files Dataset files are 1) Descriptor Files 2) Data Files 3) Controll Files 4) Header Files 1) Descriptor Files contains the Schema Details and address of the data. It stores the data in C:/Data/file.ds 2) Data Files contains the data in Binary format It will be stored in the c:/IBM/InformationServer/Server/Data/file.ds 3rd and 4th Control and Header Files resides in the Operating System. Dataset Organization are View, Copy, Delete Dataset utilities for organizing are GUI - Dataset management ( In Windows Environment ) CMD- Orch ( In Unix Environment ) Data set GUI utility: It is an utility for Organizing data set ToolsDataset ManagementFile Name Output. Ds Multiple files for Data set 1. Descriptor file 2. Data File 3. Control File 4. Header File Descriptor file: It holds the information about the address and about the structure Data file: Represents the data in the native form Control and Header file: these files are operate at the OS level for controlling the Descriptor and Data file Note: Data set other names or alias 1. Os Files 2. Orchestrate File

54

EXAMPLE JOBS FOR DATA SET STAGE: Example Job on DATA SET: Source file data:

JOB:

Input sequential properties:

Output dataset Properties:

55

Note: the target dataset file extension is .ds Output dataset data:

We can view the record schema of data set Go to toolsdataset management it will show the window like this

56

it will show the list of files and datasets

Now select empoutput1.ds and click OK

57

U can view the record schema By click on table definition icon

you can see the data here by click on data viewer option:

58

Note: By using data set management we can we can open the dataset, it can show the schema window’ it can show the data window, it can copy dataset and can delete dataset DIFFRENCES BETWEEN SEQUENTIAL FILE AND DATA SET: Sequential File stage It executes in sequential Mode Cannot Apply Part ion techniques It s all formats like.txt,.csv,.xls etc

Data set stage It executes in parallel mode Can Apply Part ion Techniques It s only .ds

It is used to extract data from flat file

It never use to extract data from client flat files

59

Development and Debugging Stages: Row Generator stage: 1.The Row Generator stage is a Development/Debug stage 2. It has no input links, and a single output link. 3. The Row Generator stage produces a set of mock data fitting the specified meta data 4. This is useful where you want to test your job but have no real data available to process Example job for Row Generator: Requirement: Need to generate employee sample data For fields empno,ename,Hiredate JOB:

Row generator properties:

60

Click on Columns

now click Doble click on Row no 1 it will show the below screen

For empno filed U select Type=cycle,intial value=1000,increment=1 and then click next Again it will show the below screen for Name field Set the Algorithm=Cycle,and give value=RafelNadal,value=JamesBlake,value=Andderadick Similary click next it will show the window for hire datefield set Type=Random 61

For Name field

62

for hire datafield:

Target Seq_EMPData Properties:

63

Click on view data: It will show the screen here In this job I defined 3 parameters i) is for No of rows 2) and inputfilepath 3)inputfilename

Now click ok and again click ok it will show the data

64

2. Column Generator stage: 1.The Column Generator stage is a Development/Debug stage 2. It can have a single input link and a single output link. 3. The Column Generator stage adds columns to incoming data and generates mock data for these columns for each data row processed. The stage editor has three pages: Stage Page. This is always present and is used to specify general information about the stage. Input Page. This is where you specify details about the input link. Output Page. This is where you specify details about the generated data being output from the stage. Example Job For Column generator: Input seqEmpData:

JOB:

seqEmpData properties:

65

Column Generator Properties:

Click on in put and click on Columns

66

Click on output and click on columns: Here u need to give column name salary in extended column properties:

67

Output columns:

Target Output_Sequential_data properties:

68

Output:

Development and Debugging Stages: Head Stage: 1.The Head Stage is a Development/Debug stage 2. It can have a single input link and a single output link 3. The Head Stage selects the first N rows from each partition of an input data set and copies the selected rows to an output data set. You determine which rows are copied by setting properties which allow you to specify:  The number of rows to copy

69

 The partition from which the rows are copied  The location of the rows to copy  The number of rows to skip before the copying operation begins 4.This stage is helpful in testing and debugging applications with large data sets. For example, the Partition property lets you see data from a single partition to determine if the data is being partitioned as you want it to be. The Skip property lets you access a certain portion of a data set. The stage editor has three pages: Stage Page. This is always present and is used to specify general information about the stage. Input Page. This is where you specify the details about the single input set from which you are selecting records. Output Page. This is where you specify details about the processed data being output from the stage. Head stage properties: 1. Rows  All Rows[After Skip]=True/False Copy all rows to the output following any requested skip positioing  All Rows[After Skip]=False No of rows [Per partition]=10 Period[Per Partition]=N Copy every N'th row per partition, starting with the first. Skip[Per Partition]=1 Number of rows to skip at the start of every partition. If we select false then only No of rows [Per partition]=10 will come 2. Partitions  All Partition=True When set to True copies rows from all partitions. When set to False, copies from specific partition numbers, which must be specified.

70

Example Job for Head Stage: Input SeqEmpData:

Output seqEmpdata:

JOB:

InputseqEmpData Properties:

71

Case-1: Head stage Properties: AllRows=False Number of rows=5 Allpartitios=TRUE

72

Head Stage Output columns:

Target Output_Sequentialdata:

73

Example Job for Head Stage: Input SeqEmpData:

OutputSequential data:

Job:

74

Input SeqEmpData:

Head stage Properties Case-2: Head stage Properties: AllRows=True Allpartitions=True

75

Head stage output columns:

Target OutputSequentialData:

Target Output_Sequentail_data:

76

Tail Stage: 1.The Tail Stage is a Development/Debug stage 2. It can have a single input link and a single output link 3. The Tail Stage selects the last N records from each partition of an input data set and copies the selected records to an output data set. You determine which records are copied by setting properties which allow you to specify:  The number of records to copy  The partition from which the records are copied

4.This stage is helpful in testing and debugging applications with large data sets. For example, the Partition property lets you see data from a single partition to determine if the data is being partitioned as you want it to be. The Skip property lets you access a certain portion of a data set The stage editor has three pages: Stage Page. This is always present and is used to specify general information about the stage. Input Page. This is where you specify the details about the single input set from which you are selecting records. Output Page. This is where you specify details about the processed data being output from the stage Tail stage properties: 1.Rows 2.Partitions Rows:  No of rows[Per partition]=10(Default is 10 if we need more than 10 or less than 10 we have to change the number) Number of rows to copy from input to output per partition.

Partitions: All Partition=True/False When set to True copies rows from all partitions. When set to False, copies from specific partition numbers, which must be specified.

77

Example Job for Tail Stage: Input SeqEmpData:

JOB:

Input seqEmpdata Properties:

78

Tailstage Properties:

Output Columns:

79

Target Output_Sequentialdata:

Sample Stage: 1.The Sample stage is a Development/Debug stage. 2. It can have a single input link and any number of output links when operationg in percent mode, 3. And a single input and single output link when operating in period mode 4.The Sample stage samples an input data set. It operates in two modes. In Percent mode, it extracts rows, selecting them by means of a random number generator, and writes a given percentage of these to each output data set. You specify the number of output data sets, the percentage written to each, and a seed value to start the random number generator. You can reproduce a given distribution by repeating the same number of outputs, the percentage, and the seed value 5.In Period mode, it extracts every Nth row from each partition, where N is the period, which you supply. In this case all rows will be output to a single data set, so the stage used in this mode can only have a single output link 6.For both modes you can specify the maximum number of rows that you want to sample from each partition. The stage editor has three pages:

80

Stage Page. This is always present and is used to specify general information about the stage. Input Page. This is where you specify details about the data set being Sampled. Output Page. This is where you specify details about the Sampled data being output from the stage. EXAMPLE JOB FOR SAMPLE STAGE: Note: Sample stage we can Operate in Two Modes one is Period and Another one is Percentage Mode Input data:

JOB:

Input seqfile properties:

81

Sample stage properties:

Output Columns:

82

Target Seqfile properties:

Output data:

83

Note :Here out put we get only 3 records because we set option period[perpartion]=3 So it takes every 3 rd record from input file data

Example Job for Sample stage : Operate in percentage mode: Input seqfile data:

Job:

84

Input sequential file stage properties:

Sample stage properties:

85

Output columns for Output1:

Output Columns for Output2:

Output Coluns for output3: 86

Sample stage link order ing:

Output1 seqfile stage properties:

87

Output data for outdat1 seqfile:

Output2 Seqfile stage properties:

88

Output2 seqfile data:

Output3 Seqfile stage properties:

Output3 Seqfile data:

89

Peek Stage: 1.The Peek stage is a Development/Debug stage. 2. It can have a single input link and any number of output links. 3.The Peek stage lets you print record column values either to the job log or to a separate output link as the stage copies records from its input data set to one or more output data sets. 4.Like the Head stage and the Tail stage (Sample stage), the Peek stage can be helpful for monitoring the progress of your application or to diagnose a bug in your application. The stage editor has three pages: Stage Page. This is always present and is used to specify general information about the stage. Input Page. This is where you specify the details about the single input set from which you are selecting records. Output Page. This is where you specify details about the processed data being output from the stage.

Peek Stage Properties: 1.Rows  All records[AfterSkip]=True/False Print all rows following any requested skip positioning. All records[AfterSkip]=True/False If we select True then Number of records [Per Partition]=10 it wont come if we set false then only the number of records[ Per Partition]=10 will appear 2.Columns  Peek all input columns=True/False When set to True prints all column values. When set to False, prints specific column values, which must be specified. 3.Partitions  All Partitions=True/False When set to True prints rows from all partitions. When set to False, prints from specific partition numbers, which must be specified. 4.Options  Peek Records output mode=Joblog/output Job log = print output to log file; Output = write to second output link of stage  Show column names=True/False Set True to print the column name, followed by a colon, followed by the value; otherwise prints only the value, followed by a space. 90

Example Job for Peek Stage: Inputdata:

JOB:

Input sequential file properties:

91

Peek stage properties:

Peek stage Output columns:

92

Output seqfile properties:

Output seq file data:

EXAMPLE JOB FOR PEEKSTAGE: Inputdata:

Option outputmode=Joblog: Job:

93

Input seqfile properties:

Input seqfile data:

94

peek stage properties:

Here we set the option Peek output mode=job log so we can see the data at Logs only Procedure for see the data at logs: Go to the tools and run directornow click on view log it will show the screen like

95

in the above screen from bottom to 8th row u click it will show the log details

96

Example Job for Peek Stage Inputdata:

JOB:

97

Input seqfile data:

Input seqfile properties:

98

Peek stage properties:

Peek output1 columns:

99

peek output1 mappings:

Peek output2 columns:

100

peekoutput2 mappings:

peekoutput3 columns:

101

Peekoutput3 mappings:

peekout1 properties:

102

peekoutput1 data:

Peekoutput2 properties:

103

Peekoutput2 data:

Peekoutput2 properties:

104

Peekoutput3 data:

Peekoutput3 properties:

Steps for using the Trunctable script: Server:/home/bhaskar$ Example: Server:/home/bhaskar$ cd/ Server:/$ cd /Data/Script Server:/Data/Script$ls Deletetab.sh Trunctab.sh It will show the list of script files in the Script files

Truncate script for deleting data in a table command: Server:/Data/Script$sh Trunctab.sh “DBname” “id” “” “Schemaname.tabalename”

Create table syntax: Create Schema “Schemaname” Create table “schemaname.tablename”

105

( “Field1” datatype(size), “Field2” datatype(size), “Field3” datatype(size), “Field4” datatype(size), “Field5” datatype(size) Field6” datatype(size), “Field7” datatype(size), “Field8” datatype(size), “Field9” datatype(size), “Field10” datatype(size) ) GRANT SELECT, INSERT, UPDATE, DELETE ON TABLE "Schemaname.Tablename" TO Group "Groupname";

Using Script in job properties before subroutine or After Sub routine: Before subroutine:ExecSh Input Value /Data/Script/Deletetab.sh #Servername # #Id# ## #schemaname.TableName#

How to create New configuration File by Using Default Configuration file(Default.Apt) Goto Tools->Configuration-> select default from configuration drop down list Copy the content of Default configuration file and select “New” and Paste the content of default configuration file content and now remove which ever the nodes are not required and click on save and Save configuration as provide the configuration file Name “2Nodeconfigfile” Step2:select the environment variable APT_CoONFIG_FILE at job parameters Step3:When we trigger the job then prompt will display the default conguration file and change the file name as “2Nodeconfigfile” Now your job will run on 2 node configuration file

106

Differences Between Filer ,Switch,External Filter Filter: 1.Condition can put on Multiple Columns 2.It Have 1-Input,N-Output, 1-Reject Link

Switch: 1.Condition can put on Single Column 2.It Have 1-Input,128-Output, 1- default Reject Link

External Filter: 1.Here we can use All unix Filter commands 2.It Have 1-Input,1-Output, No-Reject Link

Differences Between Oracle Enterprise Stage,ODBC Enterprise Stage: 1.Oracle Enterprise Stage 1.Version Dependent 2.Good Performance 3.Specific to Oracle 4.Uses Plug Ins 5.No rejects at source

2.ODBC Enterprise Stage: 1.Version In Dependent 2.Poor Performance 3.Use for Multiple DB 4.Uses OS Drivers 5.Rejects at source and Target

Extraction process of XLS data with ODBC Enterprise Stage: First step is to create MS Excel that is called “work book”. It’s having ‘n’ number of sheets in that.  For example CUST work book is created 1.Read Excel work book with ODBC Enterprise Stage: Read Method=Table Table=”emp1$” \\when we reading from excel name must be in double codes end with $ Symbol Connections DSN=EXE =OS system =OS system name 107

Columns  Load  Import ODBC Table Defination  DSN here select work Book  ID and Operating System Add in ODBC  MS EXCEL Drivers  Name=EXE (DSN)

Example Job for Dynamic Rdbms: JOB:

Dynamic Rdbms Properties:

108

Click On output Properties for Outputname=Emp

Columns:

109

Selection:

SQL:

110

Viwe Data: Properties for Outputname=Emp

111

Columns:

112

SQL:

113

View Data:

Emp_Dataset Properties:

View data:

114

Dept_Data_set:Properties:

View data:

ENCODE STAGE: 1.It is processing stage that encodes the records into single format with the of command line”. 2.It s – “1-input and 1-output”. Properties:  Stage 

Options Command Line=Compress/gZip



Load the meta data of source files

 Input  Output

DECODE STAGE: 1.It is processing stage that decodes the encoded data”. 2.It s – “1-intput and 1-output”. Properties:  Stage  Options: command line = (uncompress/gunzip)  Output  Load the ‘Meta’ data of the source file. 115

Filter Stage: 1.The Filter stage is a processing stage. 2.It can have a single input link and a any number of output links and, optionally, a single reject link. 3.The Filter stage transfers, unmodified, the records of the input data set which satisfy the specified requirements and filters out all other records. 4.You can specify different requirements to route rows down different output links. The filtered out records can be routed to a reject link, if required. The stage editor has three pages: Stage Page. This is always present and is used to specify general information about the stage. Input Page. This is where you specify details about the input link carrying the data to be filtered. Output Page. This is where you specify details about the filtered data being output from the stage down the various output links. Filter stage properties tab options  Predicates 

Where Clause

 Options  Output rejects=False  Output rejects=True Set to true to output rejects to reject link. 

Output Row only once=False

Output row only once=True/False Set to true to output the row only to the first 'Where Clause' it matches; False means the row will be output to all 'Where Clauses' that match.

116

Example Job for Filter stage: JOB: Emp Properties:

Copy stage properties:

117

Copy1 output : Outputname=Emp_Copy

Output name=Emp_Copy_all

118

Out_Emp_Copyall_Dataset Properties:

outputdata:

Filter_3properties:

119

Filter_3 Output Mappings:

OutputName=OutputSalg1andsall3:

120

Output_Deptno10 PROPERTIES:

OUTPUT DATA:

Data_SET5 properties:

121

OUTPUT DATA:

Filter_10 PROPERTIES:

Output Mappings:Dslink15

122

Output columns:

output name=dslink13:

123

Dataset_14 PROPERTIES:

output

Datbase_12 Properties:

Output:

124

Switch stage: 1.The Switch stage is a processing stage. 2.It can have a single input link, up to 128 output links and a single rejects link. The Switch stage takes a single data set as input and assigns each input row to an output data set based on the value of a selector field. 3.The Switch stage performs an operation analogous to a C switch statement, which causes the flow of control in a C program to branch to one of several cases based on the value of a selector variable. 4.Rows that satisfy none of the cases are output on the rejects link. The stage editor has three pages: Stage Page. This is always present and is used to specify general information about the stage. Input Page. This is where you specify the details about the single input set from which you are selecting rows. Output Page. This is where you specify details about the processed data being output from the stage. Switch stage properties options 1.Input 2. defined Mapping 3.Options 1.Input 

Selector=Column Name



Selector Mode=Auto,Hash, Defined Mapping

1.Auto can be used when there is as many distinct selector values as output links. 2.Hash means that rows are hashed on the selector column modulo the number of output links and assigned to an output link accordingly. In this case, the selector column must be of a type that is convertible to Unsigned Integer and may not be nullable. 3.-defined Mapping means that the onus is on the to provide explicit mapping for values to outputs 2. Defined Mapping  Case=? Specifies -defined mapping between actual values of the selector column and an output link. Mapping is a string of the form: <Selector Value>[=

125

Number>], The Link Label Number is not needed if the value is intended for the same output link as specified by the previous mapping that specified a number. You must specify an individual mapping for each value of the selector column you want to direct to one of the output links, thus this property will be repeated as many times as necessary to specify the complete mapping. 3.Options If Not Find =Fail,Drop,Output Fail means that an invalid selector value causes the job to fail; Drop drops the offending row; Output sends it to a reject link. EXAMPLE JOB FOR SWITCH STAGE: JOB:

126

Oracle_Enterprise_0 properties:

Switch stage properties:

127

Outputmappings: Outputname=T1;

Output_Dataset_2 properties::

128

Output

Outputname=T2;

Output Dataset_3 Properties:

129

output:

Outputname=T3;

Output Dataset_4 Properties:

130

Output:

External Filter stage: 1.The External Filter stage is a processing stage. 2. It can have a single input link and a single output link. The External Filter stage allows you to specify a UNIX command that acts as a filter on the data you are processing. 3.An example would be to use the stage to grep a data set for a certain string, or pattern, and discard records which did not contain a match. This technique can be a quick and efficient way of filtering data. 4.Whitespace is stripped from the start and end of the data before the command is executed. To avoid this behavior, use an explicitly wrapped command that sets format options on the schema. The stage editor has three pages: Stage Page. Use this page to specify general information about the stage. Input Page. Use this page to specify details about the input link carrying the data to be filtered. Output Page. Use this page to specify details about the filtered data being output from the stage. 131

External Filter Proper ties options 1.Options 

Arguments=?

Type: String Any command-line arguments required. 

Filter Command=?

Type: Pathname Program or command to execute, which must be configured to accept input from stdin and write its results to stdout. Example Filter Commands: sed’1d2d’ Grep ‘bhaskar’ Sed –n –e ‘2p’-e ‘3p’ EXAMPLE JOB FOR EXTERNAL FILTER: Input data:

Job:

132

Sequential_File_7 Properties:

Columns:

133

External Filter properties:

Output columns: Here we need to give the column names manually at output columns

134

Target data set_9: Properties:

OUTPUT:

Example job for copy and External filter: Inputdata:

135

JOB:

Sequential file stage properties:

136

Copy_1 STAGE properties:

Copy_1 stage output mappings:

External_filter3 stage properties: 137

External_Filter_3 Output columns:

Data_set_7 stage properties:

138

output:

External_FILT4 stage properties: 139

Output Columns:

Dataset_8 Properties:

140

OUTPUT:

Queries: is a query which combines the data from multiple tables Types of s: 1. Cartezion 2. Equi 3. Non equi 4.Self or inner 5.Outer Left outer Right outer

Employee Table Data: SQL> select * from emp; 141

EMPNO ENAME

JOB

MGR

DEPTNO

---------- ---------- ---------- ---------- ---------111

bhaskar

analyst

444

10

222

prabhakar

clerk

333

20

333

pradeep

manager

111

10

444

srujana

engineer

222

40

Department Table Data SQL> select * from dept; DEPTNO DNAME

LOC

------ ---------- ---------10

marketing

hyderabad

20

finance

banglore

30

hr

bombay

Examples: Cartezion : If we combine a data from multiple tables with out applying any condition then each record in the first table will with all records in the second table SQL>select * from emp,dept SQL>select empno,ename,job ,dname,loc from emp e,dept d

Equi : If we combine a data from multiple tables by applying equal no of conditions on multiple tables then each record in the first table will with one row in the second table. This kind of can be called as Equi SQL>select e.empno,e.ename,d.dname,d.loc from emp e,dept d where e.deptno=d.deptno

Inner : This will display all the records that have matched. Ex: SQL> select empno,ename,job,dname,loc from emp inner dept using(deptno);

142

Left outer : This will display the all matching records and the records which are in left hand side table those that are not in right hand side table. Ex: SQL> select empno,ename,job,dname,loc from emp e left outer dept d on(e.deptno=d.deptno); Or SQL> select empno,ename,job,dname,loc from emp e,dept d where e.deptno=d.deptno(+);

Right outer : This will display the all matching records and the records which are in right hand side table those that are not in left hand side table. Ex: SQL> select empno,ename,job,dname,loc from emp e right outer dept d on(e.deptno=d.deptno); Or SQL> select empno,ename,job,dname,loc from emp e,dept d where e.deptno(+) = d.deptno;

Full outer This will display the all matching records and the non-matching records from both tables. Ex: SQL> select empno,ename,job,dname,loc from emp e full outer dept d on(e.deptno=d.deptno);

Stage: These topics describe stages, which are used to data from two input tables and produce one output table. You can use the stage to perform inner s, outer s, or full s. 1.An inner returns only those rows that have matching column values in both input tables. The unmatched rows are discarded. 143

2.An outer returns all rows from the outer table even if there are no matches. You define which of the two tables is the outer table. 3.A full returns all rows that match the condition, plus the unmatched rows from both input tables. Unmatched rows returned in outer s or full s have NULL values in the columns of the other link 1. stages have two input links and one output link. 2. The two input links must come from source stages. The ed data can be output to another processing stage or a ive stage

stage Properties: 1. Keys 2.Options 1. Keys  Key=? Type: Input Column Name of input column you want to on. Columns with the same name must appear in both input data sets and have compatible data types. Case sensitive=True/False Type: List Whether this column is case sensitive or not. 2.Options  type= F,I,L,R F->Full outer I->Inner L->Left outer R->Right outer Type: List Type of operation to perform.

Example Job for stage: Emp table data:

144

Dept table Data:

JOB: Inner

Inner Output:

145

JOB2: Left Outer

Output:

LOOKUP JOB :

146

JOB3:Right Outer

Output:

JOB4;Full outer

147

Output:

148

LOOKUP STAGE: 1.The Lookup stage is a processing stage. 2.It is used to perform lookup operations on a data set read into memory from any other Parallel job stage that can output data 3. The most common use for a lookup is to map short codes in the input data set onto expanded information from a lookup table which is then ed to the incoming data and output. For example, you could have an input data set carrying names and addresses of your U.S. customers. The data as presented identifies state as a two letter U. S. state postal code, but you want the data to carry the full name of the state. You could define a lookup table that carries a list of codes matched to states, defining the code as the key column. As the Lookup stage reads each line, it uses the key to look up the state in the lookup table. It adds the state to a new column defined for the output link, and so the full state name is added to each address. If any state codes have been incorrectly entered in the data set, the code will not be found in the lookup table, and so that record will be rejected. 4/Lookups can also be used for validation of a row. If there is no corresponding entry in a lookup table to the key's values, the row is rejected. 5.The Lookup stage is one of three stages that tables based on the values of key columns. The other two are: stage - stage Merge stage - Merge Stage 6.The three stages differ mainly in the memory they use, the treatment of rows with unmatched keys, and their requirements for data being input 7. The Lookup stage can have a reference link, a single input link, a single output link, and a single rejects link Input Data:

149

ReferenceData:

LOOK UPJOB: Lookup Faiure: Drop If Lookup failure =Drop then Inner will perform

Output:

150

2.LOOK UP JOB Lookup Failure=Continue If Lookup failure =Continue then Left outer will perform

Output:

151

3.LOOKUP JOB: Lookup Failure=Reject If Lookup failure =Reject then the records which are not match with reference data those records will send to the reject output Link JOB:

Output:

Input Rejected :

LOOK UPJOB: Lookup Faiure: Fail If Lookup failure =Fail then If any of the input record not found in the reference file Then the job will fails

152

MERGE STAGE: Merge Stage Properties: 1.Merge keys 2.Options 1.Merge Keys  Key=?  Sort order=Ascending Sort in Either ascending or descending order 2.Options:  Unmatched Master mode=Drop/keep  Warn on reject updates=True  Warn on unmatched master=True Masterdata:

UpdateData:

153

JOB1:  Unmatched Master mode=Drop  Warn on reject updates=True  Warn on unmatched master=True Type: List Keep means that unmatched rows (those without any updates) from the master link are output; Drop means that unmatched rows are dropped

Output:

Master_Rejects:

154

JOB2:  Unmatched Master mode=Keep  Warn on reject updates=True  Warn on unmatched master=True

Output:

Master_Records:

Note : If the options "Warn on Reject Updates = True" and "Warn on Unmatched Masters = True" then the log file shows the warnings on Reject Updates and Unmatched Data from Masters

Note : If the options "Warn on Reject Updates = False" and "Warn on Unmatched Masters = False" then the log file do not shows the warnings on Reject Updates and Unmatched Data from Masters.

155

MODIFY STAGE JOBS: Modify Stage Job1: TypeConversion:Date_From_Timestamp Inputfile Data: CUSTID,CNAME,ADDRESS,CITY,STATE,ZIP,CUSTDOB 1000,BHASKAR,MOOSPET,HYDERABAD,AP,500071,1983-03-10 16:02:00 2000,SUMIT,,BANGALORE,KA,560070,1985-03-01 16:02:00 3000,SRIKAR,ERRAGADDA,HYDERABAD,AP,,1985-05-01 16:02:00 4000,SRUJANA,,HYDERABAD,AP,,1986-07-01 16:02:00

Job:

Sequential file Input columns:

Modify stage properties: Specification=CUSTDOB=date_from_timestamp(CUSTDOB)

156

Modify stage input columns

Modify stage output columns

Output:

157

Modify Job2: Null Handle: Inputdata:

Job:

Modify stage properties

CUSTDOB=date_from_timestamp(CUSTDOB) ZIP=Handle_Null('ZIP','999999')

158

Output:

3.Modify Job Drop Columns

Job:

Sequential file Input columns:

Modify stage properties: Specification=CUSTDOB=date_from_timestamp(CUSTDOB)

159

ZIP=Handle_Null('ZIP','999999') Specification=Drop CUSTID Modify stage Input columna

Output:

160

3.Modify Job Keep Columns Inputdata:

Job:

Sequential file Input columns:

161

Modify stage properties:

KEEP CUSTID Modify stage input columns

162

Modify stage output columns

Output:

Copy Stage: 1.The Copy stage is a processing stage. 2.It can have a single input link and any number of output links. 3. The Copy stage copies a single input data set to a number of output data sets. 4. Each record of the input data set is copied to every output data set. Records can be copied without modification or you can drop or change the order of columns (to copy with more modification - for example changing column data types - use the Modify stage 5. Where you are using a Copy stage with a single input and a single output, you should ensure that you set the Force property in the stage editor TRUE. This prevents InfoSphere™ DataStage® from deciding that the Copy operation is superfluous and optimizing it out of the job The stage editor has three pages: Stage Page. This is always present and is used to specify general information about the stage.

163

Input Page. This is where you specify details about the input link carrying the data to be copied. Output Page. This is where you specify details about the copied data being output from the stage Copy stage Properties tab Options: 1.Force=True/False True to specify that DataStage should not try to optimize the job by removing the Copy operation.

Input:

Output:

Job:

164

Copy stage general tab

Copy stage Output Mapping

165

Copy stage Results set Output:

166

Aggregator Stage: 1.The Aggregator stage is a processing stage. 2.It classifies data rows from a single input link into groups and computes totals or other aggregate functions for each group. The summed totals for each group are output from the stage via an output link. The stage editor has three pages: Stage Page. This is always present and is used to specify general information about the stage. Input Page. This is where you specify details about the data being grouped or aggregated. Output Page. This is where you specify details about the groups being output from the stage. Aggregator stage general tab Options: 1.Grouping Keys: 2.Aggregations 3.Options

1.Gropuing Keys: Group=Specifies an input column you are using as a grouping key. Grouping Keys  Group 

CaseSensitive=True/False

2. Aggrigations: Aggregation type Whether to perform calculation(s) on column(s), re-calculate on previously created summary columns, or count rows.  Calculation  Count of Rows  Re-Calculation Aggregation type=Calculation Column for calculation=Column name If u given the column name then it asks

167

1.Corrected sum of squares output column Name of column to hold the corrected sum of squares of data in the aggregate column. ->Decimal output=? 1.Maximum value output column Name of column to hold the maximum value encountered in the aggregate column. ->Decimal output=? 2.Mean Value output column ->Decimal output=? Name of column to hold the mean value of data in the aggregate column. 3.Minimum Value output column ->Decimal output=? Name of column to hold the minimum value encountered in the aggregate column. 4. missing values Specifies what constitutes a 'missing' value, for example -1 or NULL. Enter the value as a floating point number. 5.missing values count output column ->Decimal output=? Name of column to hold the count of the number of aggregate column fields with values in them. 6. Percentage Coefficient of variation output column ->Decimal output=? Name of column to hold the percent coefficient of variation of data in the aggregate column.. 7.Preserve type=True/False True means that the datatype of the output column is derived from the input column when calculating minimum value, maximum value. 8.Range output Column: ->Decimal output=? Name of column to hold the range of values in the aggregate column (maximum minimum). 9.Standard derivation output column: ->Decimal output=? Name of column to hold the standard deviation of data in the aggregate column. 10. Standard Error output column: ->Decimal output=?

168

Name of column to hold the standard error of data in the aggregate column. 11.sum of weights output column ->Decimal output=? Name of column to hold the sum Of weights of data in the aggregate column. (See Weighting Column.) 12.sum output column ->Decimal output=? Name of column to hold the sum of data in the aggregate column. 13.Summary output column ->Decimal output=? Name of sub record column to which to write the results of the reduce or rereduce operation. 14.un corrected sum of squares ouput column ->Decimal output=? Name of column to hold the uncorrected sum of squares for data in the aggregate column. 15.Variance output column ->Decimal output=? ->Variance Devisor=? Name of column to hold the variance of data in the aggregate column. 16.weighting column Increment the count for the group by the contents of the weight field for each record in the group, instead of by 1. (Applies to: Percent Coefficient of Variation, Mean Value, Sum, Sum of Weights, Uncorrected Sum of Squares.)

2.Options:  Allow null output=True/False True means that NULL is a valid output value when calculating minimum value, maximum value, mean value, standard deviation, standard error, sum, sum of weights, and variance. False means 0 is output when all input values for calculation column are NULL.  Method=Hash/Sort Use hash mode for a relatively small number of groups; generally, fewer than about 1000 groups per megabyte of memory. Sort mode requires the input data set to have been partition sorted with all of the grouping keys specified as hashing and sorting keys.

Example Job for Aggrigator: 169

Input data:

Requirement: Output file11 data:

Output field12 data: JOB:

database properties;

170

Copy stage properties:

171

output tab:

Aggrigator2 properties:

172

output tab:

Target seqfile 11 properties:

173

Column generator properties:

output tab:

174

Aggrigator 4 properties:

Output tab:

175

Target seqfile 12 properties:

Aggrigator job example2: Example Job for Aggrigator: Input data:

176

Requirement: Output file11 data:

Output field12 data:

JOB:

database properties;

177

Copy stage properties:

Aggrigator 2 properties:

178

Output tab:

target seqfile11 properties:

179

Column generator properties:

Column genenator out put tab:

180

Aggrigator4 properties:

output tab:

181

Target se file12 Properties:

Sorting: Sorting can be done at different ways 1.If source is a Data base then we can use order by class by that we can sort the data based on column names 2.If source is a Data base then we can use query like this Select Distinct column(s) From tabname Order by Column(s) Same above task can perform using link level sort Step1: open the target sequential file and select partition and select the check box perform sort Stable Unique Here the data display order is Ascending with case sensitive and Nulls first

182

Link level sort Example: Input Data:

Target Partitioning tab

Here in the above screen shot if we can observe carefully 3 check box has to be selected

183

Output:

Example Job for Dynamic Rdbms: JOB:

Dynamic Rdbms Properties:

184

Click On output Properties for Outputname=Emp

185

Columns:

Selection:

186

SQL:

Viwe Data:

187

Properties for Outputname=Emp

Columns:

188

SQL:

189

View Data:

Emp_Dataset Properties:

190

View data:

Dept_Data_set:Properties:

191

View data:

ENCODE STAGE: 1.It is processing stage that encodes the records into single format with the of command line”. 2.It s – “1-input and 1-output”. Properties:  Stage 

Options Command Line=Compress/gZip



Load the meta data of source files

 Input  Output

DECODE STAGE: 1.It is processing stage that decodes the encoded data”. 2.It s – “1-intput and 1-output”. Properties:  Stage  Options: command line = (uncompress/gunzip)  Output  Load the ‘Meta’ data of the source file.

192

Parameter Set : Procedure to create Parameter Set: 1. Choose File > New to open the New dialog box. 2. Open the Other folder, select the Parameter Set icon, and click OK. 3. The Parameter Set dialog box appears. 4. Enter the required details on each of the pages as detailed in the following sections. Parameter Set General tab Use the General page to specify a name for your parameter set and to provide descriptions of it. Parameter Set  Parameters tab: Use this page to specify the actual parameters that are being stored in the parameter Set Parameter Set Value tab: Use this page to optionally specify sets of values to be used for the parameters in this parameter set when a job using it is designed or run. 1.Parameter Set General tab Use the General page to specify a name for your parameter set and to provide descriptions of it. Parameter Sets General Parameters Parameter set Name: Ps_StagingDB Short Description Parameter Set cretaed for connecting for StagingDB Short Description

Values

2.Parameter Set  Parameters tab: Use this page to specify the actual parameters that are being stored in the parameter Set Parameter Sets General Parameters

1 2 3

Paramater name HostSerever Name

Values Prompt Server Id

193

Type String String Encrypted

Default Vaue

Help Text

3.Parameter Set Value tab: Use this page to optionally specify sets of values to be used for the parameters in this parameter set when a job using it is designed or run. Parameter Sets General Parameters

1 2 3

Value File name DevdDB ProdDB TestDB

Values HostSerever DevdDB ProdDB TestDB

Name abreddy abreddy abreddy

****** ****** ******

Run Time Prompt Display Window: The Above Parameters prompt when u run the job immediately prompt display and ask the details of above Parameters Name Ps_StagingDB Ps_StagingDB Ps_StagingDB Server Id

Limits

General Value DevdDB ProdDB TestDB ABC abreddy ******

Transformer Job Example4: -----------------------------------InputData1:

InputData2:

Output:

194

Job:

Here Type choose=Full outer Transformer Logic: Here create Stage variable STATUS= If ((DSLink9.leftRec_ENO = DSLink9.rightRec_ENO) And (DSLink9.ENAME = DSLink9.ENAME1) And (DSLink9.SAL = DSLink9.SAL1) )Then "SAME" Else If (((DSLink9.leftRec_ENO = DSLink9.rightRec_ENO)) And (DSLink9.ENAME = DSLink9.ENAME1) And (DSLink9.SAL <> DSLink9.SAL1) ) Or ((DSLink9.leftRec_ENO = DSLink9.rightRec_ENO) And (DSLink9.ENAME <> DSLink9.ENAME1) And (DSLink9.SAL = DSLink9.SAL1)) Or ((DSLink9.leftRec_ENO = DSLink9.rightRec_ENO) And (DSLink9.ENAME <> DSLink9.ENAME1) And (DSLink9.SAL <> DSLink9.SAL1))Then "UPDATE" Else "NEW"

Output:

195

Pivote Stage: 1.Pivot stage is an active stage, 2.Pivote stage is an processing stage 3.Maps sets of columns in an input table to a single column in an output table. This type of mapping is called pivoting. 4. Pivot Stage converts columns in to rows. Scenario: Eg., Marks1 and Marks2,Marks3 are three columns. Task : Convert all the columns in to one column ie Marks Using Methodology : In the deviation field of the output column change the input columns in to one column. Eg., Column Name – "Marks". Derivation : Marks1 and Marks2,Marks3 Note : Column "Marks" is derived from the input columns Marks1 and Marks2 and Marks3

Example Job for Pivote stage: Input Data:

OutputData:

196

Job: -----

Pivote stage inputs columns:

Pivote stage outputs columns:

197

OutputData:

2.Surrogate Key Stage: 1.The Surrogate Key Generator stage is a processing stage that generates surrogate key columns and maintains the key source. 2.A surrogate key is a unique primary key that is not derived from the data that it represents, therefore changes to the data will not change the primary key. In a star schema database, surrogate keys are used to a fact table to a dimension table. 3.The Surrogate Key Generator stage can have a single input link, a single output link, both an input link and an output link, or no links. Job design depends on the purpose of the stage. 4.You can use a Surrogate Key Generator stage to perform the following tasks:  Create or delete the key source before other jobs run 198

 Update a state file with a range of key values  Generate surrogate key columns and them to the next stage in the job View the contents of the state file 5.Generated keys are unsigned 64-bit integers. The key source can be a state file or a database sequence. If you are using a database sequence, the sequence must be created by the Surrogate Key stage. You cannot use a sequence previously created outside of DataStage. 6.You can use the Surrogate Key Generator stage to update a state file, but not a database sequence. Sequences must be modified with database tools. InputData:

Output:

Job:

Surrogate key stage proper ties:

199

Surrogate key properties: 1.Key source:  Generate output column name= Surrogatekey1(This column we have to generate at output)  Source Name=C:/data/bhaskar/empty.txt(we have to create the empty .txt file in the given path)  Source Type=Flat File 2.Options:  Generate key from Last Highest value= Yes/No Output:

TRANSFORMER STAGE: Trans former stage plays major role in data stage .it is used to modify the data, apply some functions while populating data from source to target It takes one input link and gives one (or) more than one output links. It has 3 components 1. Stage variable 2. Constraints 3. Derivations (or) Expressions 1. Transformer stage can works as copy stage and filter stage 2. Transformer stage requires C++ Compiler .it convert high level data into machine language 200

Double click on transformer stage drag and drop of required target columnsClick Ok The order of execution of transformer stage is 1. Stage variable 2. Constraints 3. Derivations Example:

How to work transformer as filter stage (or) how to apply constraints in the transformer stage: Double click on trans former stage  double click on constraint again double on particular link click on this window  it provides all information’s automatically and view Constraints  for reject link click other wise. Example Derivation: If Sale_Id <300 then Amount_Sold=Amount_Sold+300 Else if Sale_Id>300 and Sale_Id<600 then Amount _Sold=Amount_Sold+600 Else if Sale_Id>600 and Sale_Id<1000 then Amount _Sold=Amount_Sold+1000 Else Amount_Sold=Amount_Sold+100

Transformer stage provides some Functions and other informations.those are 1. Ds Macro 2. Ds routine 3. Job parameter 4. Input column 5. Stage Variables 6. System Variables 7. String 8. Function 9. Parenthesis 10. If Then Else 1. Ds Macro:

201

Ds Macro provides some built in Functions like 1. DsProjectName() 2. DsJobName() 3. DsHostName() 4. DsJobStartDate() 5. DsJobStartTime() 6. DsJobStartTimeStamp() 2. Ds routine: It is nothing but set up functions 3. Job parameters: Job parameters are nothing but some variables. these are used to reduce the redundancy of work 4. Input columns: It provides all input column names 5. Stage variables: Stage variables are used to increase the performance and to reduce the redundancy of work How to define stage variable properties: Click on stage variable right click on stage variable select stage variable propertiesdefine stage variables 6. System variables: It contain some built in functions like 1. @INROWNUM 2. @OUTROWNUM 3. @NUMPARTIONS INROWNUM and OUTROWNUM provides how many records are loading into transformer stage and how many records extracted from transformer stage ,Num Portion tells how many nodes is handled 7. String: It provides information with in double quotation hard coded value 8. Functions: There are several built functions in data stage 1. Date&Time 2. Logical 3. Mathematical 4. Null Handling 5. Number 6. Raw 7. String 8. Type Conversion

202

9. Utility EXAMPLE JOBS OF TRANSFORMER STAGE: 1)EXAMPLE JOB FOR TRANSFORMER JOB:1 Inputfile:

Output requirement

JOB:

203

Sequential file:

Transformer Stage properties:

204

Results stage variable Derivation: --------------------------------------Reults=If (Input.MARKS1>=35 And Input.MARKS2 >=35 And Input.MARKS3>=35) Then '' Else 'FAIL'

INPUTCOLUMNS:

OUTPUTLINK:

TARGET FILE:

205

2) EXAMPLE JOB FOR TRANSFORMER: JOB2: Input file:

Output requirement:

206

JOB:

Input file properties:

Transformer stage properties:

207

Stage variable derivation: Field(INPUT.HDATE,"/",3):"-": Field(INPUT.HDATE,"/",2):"-": Field(INPUT.HDATE,"/",1) 4. EXAMPLE JOB FOR TRANSFORMER: Inputfile data:

Out put Reqirements: Output1:

Output2:

JOB:

INPUT:

208

Transformer1:

Stage variable derivation:

209

Left(INPUT.REC,1) Transformer2:

Constrains logic:

210

OUTPUTINVC:

OUTPUTPRODID:

211

212

4. EXAMPLE JOB FOR TRANSFORMER STAGE: Input file:seqfile1:

Input file:seqfile0:

Out put Requirement:

Job:

213

Input file file1 properties:properties:

properties:

Transformer stage properties:

214

Stage variable Status derivation: If ((DSLink9.leftRec_ENO = DSLink9.rightRec_ENO) And (DSLink9.ENAME = DSLink9.ENAME1) And (DSLink9.SAL = DSLink9.SAL1) )Then "SAME" Else If (((DSLink9.leftRec_ENO = DSLink9.rightRec_ENO)) And (DSLink9.ENAME = DSLink9.ENAME1) And (DSLink9.SAL <> DSLink9.SAL1) ) Or ((DSLink9.leftRec_ENO = DSLink9.rightRec_ENO) And (DSLink9.ENAME <> DSLink9.ENAME1) And (DSLink9.SAL = DSLink9.SAL1)) Or ((DSLink9.leftRec_ENO = DSLink9.rightRec_ENO) And (DSLink9.ENAME <> DSLink9.ENAME1) And (DSLink9.SAL <> DSLink9.SAL1))Then "UPDATE" Else "NEW"

Target filel :properties:

215

2. REMOVE DUPLICATES: Inputdata:

Output:

216

JOB:

Remove duplicates properties:

Xml Output Stage: Input Text file data: EMPID,NAME,GENDER,COMPANY,CITY 1,BHASKAR,MALE,IBM,HYDERABAD 2,PRADEEP,MALE,WIPRO,BANGLORE 3,SRUJANA,FEMALE,INFOSYS,HYDERABAD 4,KRISHNAVENI,FEMALE,TCS,PUNE 5,SRIKARAN,MALE,COGNIZANT,CHENNAI

Output file XML data:
217

--> - <EMPINFO> - <EMPDETAILS> <EMPID>1 BHASKAR MALE IBM HYDERABAD - <EMPDETAILS> <EMPID>2 PRADEEP MALE WIPRO BANGLORE - <EMPDETAILS> <EMPID>3 SRUJANA FEMALE INFOSYS HYDERABAD - <EMPDETAILS> <EMPID>4 KRISHNAVENI FEMALE TCS PUNE - <EMPDETAILS> <EMPID>5 SRIKARAN MALE COGNIZANT CHENNAI

218

JOB:

XML Output stage properties: 1. Validation settings

219

1. Validation settings

3. Transformation settings

220

3. Options

Options->Input->Columns

221

XML Input Stage: Xml input file data: <EMPLOYEE> <EMP> BHASKAR FINANCE <SAL>10000 <EMP> SRUJANA OTC <SAL>20000 <EMP> PRADEEP CUSTOMER <SAL>30000

222

Job:

Input Sequential file data at data browser window

Input Sequental file proper ties:

223

sequential file columns: Here we have to read the entire xml file as a single reocrd

Xml Input Stage Stage tab proper ties: 224

Xml Input Stage Input tab column proper ties:

225

Xml Input Stage Output tab general proper ties:

Xml Input Stage Output tab Transformation setting proper ties:

226

Xml Input Stage Output tab advanced proper ties:

Xml Input Stage Output tab columns proper ties:

227

Xml Input Stage Output tab Last Advanced proper ties:

228

Target sequential file proper ties:

Output sequential file data at data browser:

FTP STAGE: File Transfer from one data stage file server to other file server: Job:

Sequential file stage Input properties:

229

FTP stage general tab proper ties:

230

FTP stage properties tab properties:

FTP input properties tab :

231

File Transfer from Local Windows machine to UNIX server: C:\Documents and Settings\\Data>ls BeforeData.txt AfterData .txt Sample.txt C:\Documents and Settings\\Data>ftp “server name or IP Address” Connected to “servername”  > <servername:<none>>:id  Required for Id  :<Enter > FTP>cd “Path” Example: FTP>cd temp\Data 250 command Successful FTP>PWD 257 “temp\Data” is a current directory FTP>put Sample.text 200 PORT command successful 150 Opening data connection for Sample.txt 232

Containers: Containers are used to minimize the complexity of a job and for better under standing and reusability purpose. There are two types of containers are available in data stage. 1. Local container 2. Shared container Local containers: it is used to minimize the complexity of job for better understanding purpose only. And It never used for reusability purpose and it limit is with in a job. Shared container: Shared containers used for both purposes like to minimize the complexity of a job and reusability. Its limit is with in project. Differences between local container and shared containers Local Container: 1. 2. 3. 4.

Itis used to minimize the complexity of job only Its limit is with in a job It occupies No memory Can be constructed directly

Shared container: 1. Itis used to for both purposes minimize the complexity of job and reusability 2.It is limit is with in a project 3. It occupies some memory 4. It can not be deconstructed directly first need to convert into local then Constructed How to construct container: Go to data stage designer-->open a specific job-->select required stages in ajob--> Click on edit--> click on construct container then choose local or shared container Note: if we want to deconstruct then right click on containerclcik deconstruct.

233

Usage of shared containers in another job: Create anew job-->drag and drop of shared container into new job-->double click on shared container--> go to output--> assign old output link(shared container link)to new output link--> go to columns--> click on load--->select reconcile from container link->click on validate-->same thing do it for remaing links-->click okss

JOB SEQUENCE: It is used to run all jobs in a sequence (or) in a order by considering its dependencies. it has many activities. How to go to job sequence: Select job sequencedrag drop of required jobs from jobs in repositorygive connectionsave itcompile it now sequentially these 3 jobs will be run.

These jobs are called job activity. Double click on job activity we can find general/job/triggersgo to job make execution =reset if required ,then rungo to triggersin expression type make un conditional/conditional ok/conditional fail Unconditionally= if job1 is successfully finished (or) aborted then job2 will run Conditional ok= if job1 is successfully finished then job2 will run. Conditional fail=if job1 is fail then job2 will run. NOTIFICATION ACTIVITY: It is used to send a mail to required persons automatically.

Double click on notification activity go to notification SMTP mail server: Company name (www.xyz.com) ,sender email address: [email protected], recipients email

234

address: recipients email address : [email protected] Email subject:Aggregatot job has been aboarted,give some information on the bodyclick ok

TERMINATOR ACTIVITY: It is used to send stop request to all running job.

WAIT FOR FILE ACTIVITY: It is used to wait for a file up to some extent of time

Double click on wait for file activitygo to filefilename: select the file and set timing(24 hours time only)

235

SEQUENCER: It is used to connect one activity to another activity it takes more input links and gives one output link

Double click on sequencergo to sequencer chose mode=All/Any All is nothing but needs to get all requests from all input links. Any means any request from one input link

236

ROUTINE ACTIVITY: It is used to execute a routine between two jobs Double click on routine activitychoose routine nameif required parameter give parameter.

EXECUTE COMMAND ACTIVITY: It is used to execute a UNIX command between two jobs Double click on execute command activityexecute UNIX command click ok

END LOOP START LOOP ACTIVITY: It is used to execute some jobs more than one time in a sequence.

237

SLOWLY CHANGING DIMENSIONS: There are 3 types of SCD‘s Available in DWH. Type1: It always maintains current data and updated data Type2: It always maintains current data and full historical data Type3: It always maintains current data and partial historical data EXERICE-1: no 100 101 103

name Bhaskar Mohan Sanjeev

sal 1500 2000 2000

no 100 101 102

name Bhaskar Mohan Srikanth

sal 1000 1500 2000

After implementing SCD Type1

no 100 101 102 103

name Bhaskar Mohan Srikanth Sanjeev

sal 1500 2000 2000 2000

Type-I:

238

In SCD Type-I If a record exists in source table and not exists in target table then simply insert a record into target table (103 record) if a record exists in both source and target tables then simply update source record into target table(100,101) Type-II: While implementing SCD Type-II there are two extra columns are maintained in target called Effective Start Date and Effective End Date .Effective start date is also part of primary key. If a record exists in source and not exists in target table then simply insert records into target table. while inserting put Effective Start Date is equal to current date and effective end date set null. If a record exists in both source and target tables even though we are inserting a source record into target table but before insert a record into target table the existing record in target table update effective End Date=CurrentDate-1. Now insert source record into target table effective start date=Current Date and Effective End Date=Null

no 100 101 102 100 101 103

name Bhaskar Mohan Srikanth Bhaskar Bhaskar Sanjeev

sal 1000 1500 2000 1500 2000 2000

Effective_Strat_Date 2011-01-31 2011-01-31 2011-01-31 2011-02-01 2011-02-01 2011-02-01

Effective_End_Date 2012-04-05 2012-04-05 2012-04-05 Null Null Null

Type-III: If a record exists in source and not exists in target table then simply insert records Into target table. While inserting put Effective start Date is equal to Current Date and Effective End Date set Null. If a record exists in both source and target tables then check target table count group by primary key if count=1 then update Effective End Date=Current Date-1 then simply insert source record into target record. If count greater than one then delete a record into target table group by primary key where Effective End Date=Not Null. Now update target record Effective End Date=Current Date-1 Then simply insert source record into target.

DATAWAREHOUSE: Data ware house is nothing but collection of transactional data and historical data and can be maintained in dwh for analysis purpose. They are 3 types of tools should be maintained on any data warehousing project 239

1. ETL Tools 2. OLAP Tools (or) Reporting Tools 3. Modeling Tool

ETL TOOL: ETL is nothing but Extraction, Transformation, and Loading. a ETL Developer(those who are expertise in dwh extracts data from heterogeneous databases(or)Flat files, Transform data from source to target(dwh) while transforming needs to apply transformation rules and finally load data into dwh. There are several ETL Tools available in the market those are 1. Data stage 2. Informatica 3. Abinitio 4. Oracle Warehouse Builder 5. Bodi (Business Objects Data Integration) 6. MSIS (Microsoft Integration Services) OLAP: OLAP is nothing but Online Analytical Processing and these tools are called as reporting Tools Also A OLAP Developer analyses the data ware house and generate reports based on selection criteria. There are several OLAP Tools are available 1. Business Objects 2. Cognos 3. Report Net 4. SAS 5. Micro Strategy 6. Hyperion 7. MSAS (Microsoft Analysis Services) MODELING TOOL: Those who are working with ERWIN Tool called data modeler .A data modeler can design data base of DWH with the help of fallowing tools

240

A ETL Developer can extract data from source databases (or) flat files(.txt,csv,.xls etc) and populates into DWH .While populating data into DWH they are some staging areas can be maintained between source and target .these staging areas are called staging area1 and staging area2.

STAGING AREA: Staging Area is nothing but is temporary place which is used for cleansing unnecessary data (or) unwanted data (or) inconsistency data. Note: A Data Modeler can design DWH in two ways 3. ER Modeling 4. Dimensional Modeling ER Modeling: ER Modeling is nothing but entity relationship modeling. in this model always call table as entities and it may be second normal form (or) 3rd normal form (or) in between 2nd and 3rd normal form Dimensional Modeling: In this model tables called as dimensions (or) fact tables. It can be subdivided into three schemas. 4. Star Schema 5. Snow Flake Schema 6. Multi Star Schema (or) Hybrid (or) Galaxy Star Schema: A fact table surrounded by dimensions is called start schema. it looks like start In a start schema if there is only one fact table then it is called simple start schema. In a start schema if there are more than one fact table then it is called complex start schema

241

Sales Fact table: Sale_id Customer_id Product_id _id Time_id Promotion_id Sales_per_day Profit_per_day Dimension: _id _type _holder_name _open_date _nominee _open_balence Pramotion: Promotion_id Promotion_type Promotion_date Pramotion_designation Pramotion_Area

242

Product: Product_id Product_name Product_type Product_desc Product_version Product_stratdate Product_expdate Product_maxprice Product_wholeprice Customer: Cust_id Cust_name Cust_type Cust_address Cust_phone Cust_nationality Cust_gender Cust_father_name Cust_middle_name Time: Time_id Time_zone Time_format Month_day Week_day Year_day Week_Yeat DIMENSION TABLE: If a table contains primary keys and provides detail information about the table (or) master information of the table then called dimension table. FACT TABLE: If a table contains more foreign keys and it’s having transactions, provides summarized information such a table called fact table. DIMENSION TYPES: There are several dimension types are available

CONFORMED DIMENSION:

243

If a dimension table shared with more than one fact table (or) having foreign key more than one fact table. Then that dimension table is called confirmed dimension. DEGENERATED DIMENSION: If a fact table act as dimension and it’s shared with another fact table (or) maintains foreign key in another fact table .such a table called degenerated dimension. JUNK DIMENSION: A junk dimension contains text values, genders,(male/female),flag values(True/false) and which is not use full to generate reports. Such dimensions is called junk dimension. DIRTY DIMENSION: If a record occurs more than one time in a table by the difference of non key attribute such a table is called dirty dimension FACT TABLE TYPES: There are 3 types of fact s are available in fact table 1. Additive facts 2. Semi additive facts 3. Non additive facts ADDITIVE FACTS: If there is a possibility to add some value to the existing fact in the fact table .that facts we called as additive fact. SEMI ADDITIVE FACT: If there is possibility to add some value to the existing fact up to some extent in the fact table is we called as semi additive fact. NON ADDITIVE FACT: If there is not possibility to add some value to the existing fact in the fact table is we called as Non additive fact. SNOW FLAKE SCHEMA: Snow Flake schema maintains in dimension table normalized data .in this schema some dimension tables are not directly maintained relation ship with fact table and those are maintained relation ship with another dimension

DIFFERENCE BETWEEN STAR SCHEMA AND SNOW FLAKE SCHEMA:

244

Star schema It maintains demoralized data in the dimension table Performance will be increased when ing fact table to dimension table when

Snow flake schema It maintains normalized data in the dimension table Performance will be decreases when ing fact table to dimension table to shrunken dimension table because it require more inner s when compared with snow flake Some dimension tables are not directly maintained relationship with fact table

compared with snow flake All dimension table should maintain ed relation ship directly with fact table

Data Profiling Data Profiling: 1.Data profiling is the process of examining the data available in an existing data source 2.A data source usually a data base or a file 3. By doing data profiling we can collect the statistics and information about data

Data Profiling Tools: 1)

Informatica Data Explorer 8x

2)

Informatica PowerCenter 8x (Profiling option in Source Analyzer)

3)

Oracle Warehouse Builder 10g (Data Profiling node in the Project Explorer)

4)

SQL Server Integration Service (Data Profiling Task)

5)

IBM InfoSphere (Information Analyzer)

Why we need Data statistics 1. Find out whether existing data can easily be used for other purposes 2. whether the data conforms to particular standards or patterns 3. Assess whether metadata accurately describes the actual values in the source database 4. Understanding data challenges early in any data intensive project, so that late project surprises are avoided. Finding data problems late in the project can lead to delays and cost overruns

Data governance: Is a quality control discipline for assessing, managing, using, improving, monitoring, maintaining, and protecting organizational information?

245

Overview about Data Profiling: 1. Data profiling helps you create data model of the 3’rd normal form, based solely on data available in the source system 2. In order to create a data model of the 3’rd normal form we need the following information 1)

Domain - Column Data type and Length.

2)

Dependency – Primary Key.

3)

Relationship - Foreign Key .

Data profiling is divided into three steps 1)

Single Column Profiling: to get column domain information

2)

Table Structural Profiling to get dependency information

3)

Cross Table Profiling to get relationship information.

What is a Domain A simple example of a Domain is the list of United States state abbreviations. The Domain could be implemented as a CHAR(2) and would contain the following valid value set: AL, AK, AR, CA, CO, CT, DE, DC, FL, GA, HI, ID, IL, IN, IA, KS, KY, LA, ME, MD, MA, MI, MN, MS, MO, MT, NE, NV, NH, NJ, NM, NV, NC, ND, OH, OK, OR, PA, RI, SC, SD, TN, TX, UT, VT, VA, WA, WV, WI, WY. 2 Many Columns can share the same Domain. Columns which share the same Domain may be Synonym candidates. A Domain is defined as the set of all valid values for a Column or set of Columns. Domains contain target data type information, a -defined list of valid values, and a list of valid patterns. Each Schema has its own set of Domains. Normalization: Normalization is a process of decomposing a relation into smaller, well structured relations without anomalies is called as narmalization

246

The rules are used in a relations is called normal forms

1.Single Column Profiling: Single Column profiling gives you a column domain Information,which is used to determine the correct data type and length of a column Example: If the values in a column all have six digits and look like 040500 and the data type could be either INTEGER OR DATE in ‘mmddyy’ or’ddmmyy’ format Column profiling produces a list of Inferred data types which fits the column data below are some of the reports generated by SSIS Data profiling task

1.Column Length distribution profile: Reports all distinct lengths of string values in the selected column and percentage of rows in a table that each length represents 2. Column Statistics Profile: Reports statistics such as Minimum, Maximum, Average and standard deviation for numeric columns and minimum and maximum values for date and time columns 3. Column Null Ratio Profile: Reports the percentage of Null values in a selected column 4. Profile Time How much time it took to profile the sample data

2.Table Structural Profiling: Table structural profiling discovers functional dependencies, table structural profiling asks the question “If I know a value in one column(or a values in a set of columns) can I positively determine the value in another column

If you ran a Dependency profile for this table you would find the following dependencies, among others

247

The List in the previous slide represents True dependencies Now lets take a look at the below dependencies

The first one is not a true dependency because First Name does not positively determine Last Name, in that “BHASKAR” could be “REDDY” or “RAO”. Similarly FirstName + LastName doesn’t uniquely determine PAN. If you add the first list to the Dependency Model, you would get two keys: EmployeeID PAN However, only one of them can be a primary key, the other key is called an alternate key

3.CrossTable Profiling: Cross table profiling compares column in a schema determines which ones contain similar values. This profile can determine whether a column or set of columns is appropriate to serve as a foreign key between the selected tables. Cross Table profiling can find the following types of redundancies:  Redundant data to eliminate by creating Synonyms.  Redundant data that is intentionally redundant to improve database performance. You may still want to synonym these Column pairs to allow the normalizer to create a true third normal form (3NF).  ♦ Data that looks redundant but actually represents different business facts (homonyms).  For example, the Columns Employee_Age and Quantity_On_Hand may appear as a pair of redundant Columns if both contain integer values under 100. Although the values in these Columns are similar, the Columns actually have very different business meanings. 4

Synonyms: Two or more Columns that have the same business meaning are called Synonyms 248

. Suppose a Schema contains the following two Tables:

Both relations contain employee data, but they are defined separately to segregate public and private information. The EmpID and EmployeeID Columns have the same business meaning and can be meaningfully combined into a single Column. In contrast, look at how the MgrID column is used in the Employee Table. Even though MgrID uses similar values to EmployeeID, it represents a different role in the database. Therefore you would not define MgrID and EmployeeID as Synonyms. Normalization has the following impacts on Synonyms:  If two or more “Columns made Synonyms” represent the identical construct, they will collapse into one Column in the normalized model.  If two “Columns made Synonyms” represent a parent-child relationship, they will result in two Columns in two Tables, with one Column participating in a primary Key and the other in the corresponding Foreign Key

Introduction About Infosphere Information Analyzer: 1. Infosphere Information Analyzer is a Data Profiling tool 2. Information Analyzer is a critical component of IBM InfoSphere Information Server that profiles and analyzes data so that you can deliver trusted information to your s Information Analyzer Capabilities: Information Analyzer automates the task of source data analysis by expediting comprehensive data profiling and minimizing overall costs and resources for critical data integration projects. End-to-end data profiling and content analysis: Provides standard data profiling features and quality controls. The metadata repository holds the data analysis results and project metadata such as project-level and role-level security and function istration. Business-oriented approach: With its task-based interface, aids business s in reviewing data for anomalies and changes over time, and provides key functional and design information to developers.

249

Adaptable, flexible, and scalable architecture : Handles high data volumes with common parallel processing technology, and utilizes common services such as connectivity to access a wide range of data sources and targets

Information Analyzer workspace Navigator Menus:

1. Home 2. Overview 3. Investigate 4. Develope 5. Operate 1. Home: Contains system istration, security, configuration, and metadata tasks  My home  Reports  Metadata Management  Data stores  Data schemas  Tables or Files  Data Fields  Data Clasess  Classes  s  Policies  Global Logical Variable

250

2. Overview: Contains project properties tasks and the project dashboard.  Dash board  Project properties 3. Investigate: Contains information discovery and investigation tasks.  Column Analysis  Key and Cross Domain Analysis  Base Line Analysis  Publish Analysis Results  Table Management 4. Develop: Contains data transformation and information services enablement tasks.  Data Quality 5. Operate: Contains scheduling and log view tasks.  Log Views  Scheduling Views

Information Analyzer Project roles: Information Analyzer, s can further define authority by asg suite component and project roles to InfoSphere Information Analyzer s. You can assign suite component roles in the IBM InfoSphere Information Server console or the IBM InfoSphere Information Server Web console. Project roles can be assigned only in the Project Properties workspace of the console.

Suite Component roles: Information Analyzer Data Can import metadata, modify analysis settings, and add and modify system sources. Information Analyzer Project Can ister projects by creating, deleting, and modifying information analysis projects. Information Analyzer Can log on to InfoSphere Information Analyzer, view the dashboard, and open a project.

Information Analyzer Project roles: Information Analyzer Business Analyst Reviews analysis results. With this role, s can set baselines and checkpoints for baseline analysis, publish analysis results, delete analysis results, and view the results of analysis jobs. Information Analyzer Data Operator Manages data analyses and logs. With this role, s can run or schedule all analysis jobs.

251

Information Analyzer Data Steward Provides read-only views of analysis results. With this role, s can also view the results of all analysis jobs. Information Analyzer DrillDown Provides the ability to drill down into source data if drill down security is enabled.

Information Analyzer Real Time Environment :

Data Profiling Process from End to end delivery: 1. Prior to start Data profiling Data load needs to be completed using middle ware technologies called Data stage. 2. Source to staging area Data stage Jobs need to created for data loading for data analysis or for columns examine purpose 3. Once the data load completed now have to start work on IA environment

252

4. Create the IA project to create IA project have to be with IA privileges 5. Import metadata from staging tables to IA environment 6. To Import Meta data have to be with IA privileges 7. Add a data sources to created project 8. Adding the necessary s to the created project 9 .And also can Add the Groups to the created project 10. Asg a project roles to the or groups 11. The following are the four different project roles we have in IA  Information Analyzer Business Analyst  Information Analyzer Data operator  Information Analyzer Data steward  Information Analyzer Data operator 12.Running CA job for single or multiple columns 13. View Analysis results 14.Capture the analysis results where ever the data validation rules given in Data profiling requirement template 15. Fill the Data profiling requirement sheet with all the columns where ever the Data validation rules given 16.Generate the project required reports 17.Deliver the analysis results template and reports to the Focals

Steps to run Column Analysis job: 1. First with IBM Infosphere Information server console

2. Enter Name, , and Host Name of the services tier 3. After to Information Analyzer main home screen click on file menu

4. Select open project and open project will display the list of created projects 5. Select the project for which analyze table want to run Column Analysis and click on open 6. Now in the Information Analyzer workspace navigator menu select Investigate Tab 7. Select Column Analysis then it will display the below column analysis window

253

8. Now select the table and go to the Tasks and under the task will find the Run Column Analysis option now click on Run column Analysis then it it will several minutes to complete the column analysis once the column analysis completes then it will give the status as Analyzed with analysis Run date. 9. Now find the below screen shot the CA status was now Analyzed

2.Process to Review the Column Analysis Results:

1. Now select the EMPID Column from the above list and now go to task and under task select Open column analysis

254

And next click on view details then it will open the Column Analysis results window 2. Now we will find the column analysis results encountered in different tabs:

1. Overview:

2.Frequency Distribution:

3.Data Class:

255

4. Properties Analysis: Properties has the fallowing Information 1.Data type 2.Data Length 3.Precision 4. Scale 5.Nallability 6.Cardinality Type

5.Domain and Completeness Analysis:

6.Format tab Analysis

Note: If the format is Invalid then we have to change the status as violate and then have to change the domain value status is Mark as invalid then automatically those Invalid format associate values became change as Invalid in Domain and Completeness tab

Base Line Analysis: You use baseline analysis to determine whether the structure or content of your data has changed between two versions of the same data. After a baseline analysis job completes,

256

you can create a report that summarizes the results of that job and then compare the results with the results from your baseline data.

Baseline analysis reports: You use baseline analysis to determine whether the structure or content of your data has changed between two versions of the same data. After a baseline analysis job completes, you can create a report that summarizes the results of that job and then compare the results with the results from your baseline data. There are two types of baseline analysis reports: Baseline structure - current to prior variances report: Shows a summary of the structural differences between the baseline version of your data and another version of the same data. The structure of your data consists of the elements of the data such as data values and properties. Structure also depends on how the data is organized.

Baseline content - current to prior variances report: Shows a summary of the differences in content between the baseline version and another version of the same data source. Content is the actual data, such as names, addresses, or dates.

Baseline analysis: When you want to know if your data has changed, you can use baseline analysis to compare the column analysis results for two versions of the same data source. The content and structure of data changes over time when it is accessed by multiple s. When the structure of data changes, the system processes that use the data are affected. To compare your data, you choose the analysis results that you want to set as the baseline version. You use the baseline version to compare all subsequent analysis results of the same data source. For example, if you ran a column analysis job on data source A on Tuesday, you could then set the column analysis results of source A as the baseline and save the baseline in the repository. On Wednesday, when you run a column analysis job on data source A again, you can then compare the current analysis results of data source A with the baseline results of data source A. To identify changes in your data, a baseline analysis job evaluates the content and structure of the data for differences between the baseline results and the current results. The content and structure of your data consists of elements such as data classes, data properties, primary keys, and data values. If the content of your data has changed, there will be differences between the elements of each version of the data. If you are

257

monitoring changes in the structure and content of your data on a regular basis, you might want to specify a checkpoint at regular intervals to compare to the baseline. You set a checkpoint to save the analysis results of the table for comparison. You can then choose to compare the baseline to the checkpoint or to the most recent analysis results. If you know that your data has changed and that the changes are acceptable, you can create a new baseline at any time Comparing analysis results To identify changes in table structure, column structure, or column content from the baseline version to the current version, you can compare analysis results. Before you begin

You must have InfoSphere™ Information Analyzer Business Analyst privileges and have completed the following task.  Setting an analysis baseline Over time, the data in your table might change. You can import metadata for the table again, analyze that table, and then compare the analysis results to a prior version to identify changes in structure and content. You can use baseline analysis to compare the current analysis results to a previously set baseline. Procedure

To compare analysis results: 1. On the Investigate navigator menu, select Baseline Analysis. 2. Select the table that you want to compare to the baseline analysis. To locate changes in data, you must have re-imported metadata for the table and run a column analysis job on the table. 3. On the Tasks pane, click View Baseline Analysis. 4. In the Pick an Analysis Summary window, select which analysis result you want to compare to the baseline. o Select Checkpoint to compare the baseline to the last checkpoint analysis. o Select Current Analysis to compare the baseline to the last run analysis job. What to do next

The View Baseline Analysis pane details the changes in data.

Setting an analysis baseline To establish which version of analysis results will be used as the baseline for comparison, you must set an analysis baseline. Before you begin

258

You must have InfoSphere™ Information Analyzer Business Analyst privileges and an Information Analyzer Data Operator must have completed the following task.  Running a column analysis job After you run a column analysis job and the results of that analysis, you can set the analysis results as an analysis baseline. You set an analysis baseline to create a basis for comparison. You can then compare all of the subsequent analyses of this table to the baseline analysis to identify changes in the content and structure of the data. Procedure

To set an analysis baseline: 1. 2. 3. 4.

On the Investigate navigator menu in the console, select Baseline Analysis. Select a table in which at least one column has been analyzed. On the Tasks pane, click Set Baseline. On the Set Baseline window, click Close.

What to do next

You can now compare the analysis baseline to a subsequent analysis result of the table.

Setting the checkpoint You can set a checkpoint to save a subsequent point of the selected analysis results for a table to use in comparing to the baseline. The checkpoint is saved as a point of comparison even if subsequent analysis jobs are run on the table. About this task

If you are monitoring changes in the structure and content of your data on a regular basis, you might want to specify a checkpoint at regular intervals to compare to the baseline. You set a checkpoint to save the analysis results of the table for comparison. You can then choose to compare the baseline to the checkpoint or to the most recent analysis results. A checkpoint can also save results at a point in time for analysis publication. Procedure

To set the checkpoint: 1. On the Investigate navigator menu in the console, select Baseline Analysis. 2. Select the table that you want to set as the checkpoint. 3. On the Tasks pane, click Set Checkpoint. What to do next

You can now compare the checkpoint to the baseline.

Identifying changes in your data over time

259

To determine whether the content and structure of your data has changed over time, you can use baseline analysis to compare a saved analysis summary of your table to a current analysis result of the same table. About this task

You can use baseline analysis to identify an analysis result that you want to set as the baseline for all comparisons. Over time, or as your data changes, you can import metadata for the table into the metadata repository again, run a column analysis job on that table, and then compare the analysis results from that job to the baseline analysis. You can continue to review and compare changes to the initial baseline as often as needed or change the baseline if necessary. To compare analysis results, you complete the following tasks: 1.Setting an analysis baseline To establish which version of analysis results will be used as the baseline for comparison, you must set an analysis baseline. 2.Comparing analysis results To identify changes in table structure, column structure, or column content from the baseline version to the current version, you can compare analysis results.

Data Rules Creation Process: Data Rules Creation Process: 1.Go to Develop in Work space navigator Menu

2. select Data quality and go to task under task find the New data rule definition

260

3. Click on new data rule definition then the below window will be pop up

4.Click on overview and provide the Data rule name in the name text field and short description and Long description is optional 5. Goto Rule Logic and there we have to right the logic

Write this logic source_data exists and len(trim(source_data))<>0

1.Condtion:  IF  THEN  ELSE  AND  OR  NOT 2.(

261

 ((  ((( Example:

Once we written the logic then we have to be validate weather the logic is syntactically correct or not if the logic is correct then have to click on and save and exist. 3. SourceData Here source data is a field name 4. Condtion Not 5. Type of check  =  >  <  >=  <=  <>  Contains-- >String containment  Exists->Null value test  Matches_Format-- >If country=India then zip code format=’999999’  ,Matches_Regex  occurs  occurs>  occurs>=  occurs<  occurs<=  In_Reference_column  In_reference_List  Unique  Is_numeric  Is_Date 6. Reference Data: Here in reference data we have to give the reference column name 7.) )) )))

262

Rule Builder:

1. Business Problem: Identifies when a column contains Data Type of Check: exists

Here exists check for Non Null fields And len(trim(sourcedata))<>0 for non empty field 2. Business Problem: Type of Check: in_reference_list Identify weather a column GENDER contains a data value has MALE or FEMALE Here in source we may have either upper or lower case then those values have to Compare with reference data

263

3. Business Problem: Type of Check: matches_regex Identify weather a column EMPID contains a value has numeric value and length of EMPID is 4 and the format of EMPID should be ‘9999’ Here in source we may have either upper or lower case then those values have to Compare with reference data

3. Business Problem: Type of Check: matches_format If country code=”India” then have to be check weather the zip code format is ‘999999’ or not

Quality Stage: 1.Why investigate: Discover trends and potential anomalies in data Identify invalid and default values in a data  the reliability of the data in the fields to be used as a matching criteria Gain complte understanding of the data in a context Investiage: the domain: Review each field and the data matches the meta data Identyfy the data formats and missing and default values Identify the data anomalies: Format Structure

264

Content Feature of investigate: Analyze free form and single domain columns Provide frequency distribution of distinct values and patterns Investigaet methods: Characte distcrete Character concate nate: Word invistgate:

INVESTIGATE STAGE:

1.Character Discrete Investigate C mask: Job:

Add the columns which ever u want to investigate:

265

Click on change mask and select for all the fields C mask At out put it gives 5 columns 1.qsInvColumnName 2.qsInvPattern 3.qsInvSample 4.qsInvCount 5.QsInvPercent At output it gives like below

Above screen shot is only for one field it gives same like another fields which ever u selected

1.Character Discrete Investigate T mask: 266

Job:

Add the columns which ever u want to investigate:

Click on change mask and select for all the fields C mask At out put it gives 5 columns 1.qsInvColumnName 2.qsInvPattern 3.qsInvSample 4.qsInvCount 5.QsInvPercent

267

At output it gives like below

3. Character Discrete Investigate X mask:

Add the columns which ever u want to investigate:

Here I selected for Policy Number Column C,T,X alternatively 268

At out put it gives like below

CharacterConcatenate Investigate T mask: Job:

Add the columns which ever u want to concatenate and investigate:

269

At out put it gives like below

CharacterConcatenate Investigate C mask: Job:

Add the columns which ever u want to concatenate and investigate:

270

At out put it gives like below

CharacterConcatenate Investigate X mask: Job:

Add the columns which ever u want to concatenate and investigate

271

At out put it gives like below

Word Investigate Adding rule set to NAME field Job:

Select the Name rule set from USNAME

Select the Full name field from Available data columns

272

Output you will get like below

Word Investigate Adding rule set to NAME field Token report and pattern report Job:

Select the Name rule set from USNAME And add fullname field from available data columns If u want two reports tokenreport and pattern report tick mark for both token report box and pattern report box

273

Pattern report output u will get like below: Word investigate pattern report it give 5 columns at output 1.qsInvColumnName 2.qsInvPattern 3.qsInvSample 4.qsInvCount 5.QsInvPercent Pattern report Output:

Token Report output u will get like below Word investigate pattern report it give 3 columns at output 274

1.qsInvCount 2.qsInvWord 3.qsInvClassCode Token report Output

Classification Code table:

2.STANDARDIZE STAGE: Example job:

Open standardize stage and select rule set text field and select standardize rules folder with in that folder select OTHER folder and select COUNTRY folder and select COUNTRY Next in literal text field enter ZQUSZQ

275

Add column which column u want to select from available data columns Select column name and AddressLine1, AddressLine1, city, state, Zip columns in selected columns list You will get the below screen after entering all

Next click on OK you will get the below screen

next click on Ok Output: At output it gives additional column ie ISOCOUNTRYCODE AND identifierFlag_COUNTRY

276

Quality stage : Investigate: 3 methods: 1.chardiscreate->C,T,X masks 2.Charconcatenate:C,T.X masks Investigate default column names for Pattern Report: 1.Qsinvcolumn name: 2.QsInvPattern 3.QsInvsample 4.QsInvcount 5.Qsinvpercentgae Investigate default column names for column Report: 1.QsInvcount 2.QsInvword 3.QsInvclasscode Lab: Chardiscreate C mask (select one or many columns) Characterconcatenate C MASK(select two or more columns concate nate) WordInvstgate: FullName: Token Rpt Pattern Rpt WordInvestigate:Address( address line 1,address line2) Token Rpt Pattern Rpt WordInvestigate:Area(city ,state,Zip) Token Rpt Pattern Rpt

2.Standardize stage: 1.country identifier: --- >select the rule set from others COUNTRY --- > the literal ZQUSZQ and add the columns addressline1,addressline 2,city ,state,zip --- > filter the records where ever we have flag ‘Y’ Those or US records --- >split US, non US records into separate target 2. Apply the USPREP rule set to filter name components from address fields, and area components from address fields    

->Select USPREP rule set from standardize rules -> ZQNAMEZQ and add the column “Fullname” -> ZQADDRZQ and add the column “addressline1” -> ZQADDRZQ and add the column “addressline2”

277

 -> ZQAREAZQ and add the column “City”  -> ZQAREAZQ and add the column “State”  -> ZQAREAZQ and add the column “Zip”

Standardize USNAME USADDR USAREA 1.Select USNAME rule set from standardize rules and add the clumn NameDomain_USPREP 2. select new process and select the USADDR rule set and add the column AddressDomain_USPREP 3. select new process and select the USAREA rule set and add the column AreaDomain_USPREP Rules USNAME.SET USADDR.SET USAREA.SET

Columns NameDomain_USPREP AddressDomain_USPREP AreaDomain_USPREP

Investigate unhandled name patterns Take the above job as input and use 3 investigate stages 1 for Inv Unhandled Name 2. for InvUnhandeldAddr 3.for InvUnhandledArea Inv Unhandled Name: select the method character concatenate for Name select the columns UnhandledPattern_USNAME, --- >set C mask UnhandledData_USNAME--- >set X mask InputPattern_USNAME--- >set X mask NameDomain_USPREP--- >set X mask InvUnhandeldAddr: select the method character concatenate for Address select the columns UnhandledPattern_USADDR, --- >set C mask UnhandledData_USADDR--- >set X mask InputPattern_USADDR--- >set X mask AddressDomain_USPREP--- >set X mask InvUnhandeldArea: select the method character concatenate for Area select the columns UnhandledPattern_USAREA, --- >set C mask UnhandledData_USAREA--- >set X mask InputPattern_USAREA--- >set X mask AreaDomain_USPREP--- >set X mask

278

Rule Set override 1.Input Pattern +FI UnhandledPttern UnhandledData +FI DAMORA WILLIAM H

Inputpattern InputName +FI DAMORA WILLIAM H

Process to Apply Input Pattern Override  > Select the Name rule set USNAME  > Click the Test Button to test the string DAMORA WILLIAM H  > Select the Overrides  >select the Input Pattern  >Enter the input pattern +FI  >From the current Pattern List select the first entry + Current Pattern List Token Override Code + Primary Name1 F AdditionalName1 I Additional Name1  >Click the check boxesMove current,Orginal Value ,NoLeading Space  Similarty for F and I also  Now Test the String DAMORA WILLIAM H

2.Unhandled Pattern +,+ UnhandledPattern Unhandled Data +,+ HOCHREITER, CAROLYNNE

InputPattern +,+

Input Name Text HOCHREITER, CAROLYNNE

Process to Apply Classification Override  > Select the Name rule set USNAME  > Click the Test Button to test the string HOCHREITER, CAROLYNNE  > Select the Overrides  >select the Classifictaion  >Enter the input token CAROLYNNE  >From the classification drop down menu chose F-FirstName click the add button  >Use the test process to validate results.  Now Test the String HOCHREITER, CAROLYNNE

279

3.Unhandled Pattern FFI The pattern FFI represents a last name that was recognized as a first name, UnhandledPattern Unhandled Data Input Pattern FFI HARRIS MARJORIE M +FI.

Input Name Text HARRIS MARJORIE M.

Process to Apply UnhandledPattern Override  > Select the Name rule set USNAME  > Click the Test Button to test the string HARRIS MARJORIE M  > Select the Overrides  >select the Unhandled Pattern tab Enter The unhandled pattern FFI  >From the Current Pattern List select the first entry, F  >From the Override Options choose a. Dictionary Fields: PrimaryName b. Move Current c. Original Value d. No Leading Space  Repeat the process for the remaining tokens for F,I also  Now Test the String HARRIS MARJORIE M ETL PROJECT LIFE CYCLE: Data warehousing projects are categorized into 4 types. 1) 2) 3) 4)

Development Projects. Enhancement Projects Migration Projects Production Projects.

-> The following are the different phases involved in a ETL project development life cycle. 1) Business Requirement Collection ( BRD ) 2) System Requirement Collection ( SRD ) 3) Design Phase a) High Level Design Document ( HRD ) b) Low level Design Document ( LLD ) c) Mapping Design 4) Code Review 5) Peer Review 6) Testing a) Unit Testing b) System Integration Testing. c) Acceptance Testing (UAT)

280

7) Pre - Production 8) Production (Go-Live) Business Requirement Collection: ---------------------------------------------> The business requirement gathering start by business Analyst, onsite technical lead and client business s. -> In this phase, a Business Analyst prepares Business Requirement Document (BRD) (or) Business Requirement Specifications (BRS) -> BR collection takes place at client location. -> The o/p from BR Analysis are -> BRS: - Business Analyst will gather the Business Requirement and document in BRS -> SRS: - senior technical people (or) ETL architect will prepare the SRS which contains s/w and h/w requirements. The SRS will includes a) O/S to be used ( windows or UNIX ) b) RDBMS required to build database ( oracle, Teradata etc ) c) ETL tools required ( Informatica,Datastage ) d) OLAP tools required ( Cognos ,BO ) The SRS is also called as Technical Requirement Specifications ( TRS ) Deg and Planning the solutions: ------------------------------------------------> The o/p from design and planning phase is a) HLD ( High Level Design ) Document b)LLD ( Low Level Design ) Document HLD ( High Level Design ) Document : An ETL Architect and DWH Architect participate in deg a solution to build a DWH. An HLD document is prepared based on Business Requirement. LLD ( Low Level Design ) Document : Based on HLD,a senior ETL developer prepare Low Level Design Document The LLD contains more technical details of an ETL System. An LLD contains data flow diagram (DFD), details of source and targets of each mapping. An LLD also contains information about full and incremental load. After LLD then Development Phase will start

281

Development Phase (Coding):--------------------------------------------------> Based an LLD, the ETL team will create mapping (ETL Code) -> After deg the mappings, the code ( Mappings ) will be reviewed by developers.

Code Review:-> -> -> -> ->

Code Review will be done by developer. In code review, the developer will review the code and the logic but not the data. The following activities takes place in code review You have to check the naming standards of transformation, mappings of data etc. Source and target mapping ( Placed the correct logic or not in mapping )

Peer Review:-> The code will reviewed by your team member (third party developer) Testing:-------------------------------The following various types testing carried out in testing environment. 1) Unit Testing 2) Development Integration Testing 3) System Integration Testing 4) Acceptance Testing Unit Testing:-> A unit test for the DWH is a white Box testing, It should check the ETL procedure and Mappings. -> The following are the test cases can be executed by an ETL developer. 1) data loss 2) No.of records in the source and target 3) Dataload/Insert 4) Dataload/Update 5) Incremental load 6) Data accuracy 7) Naming standards. 8) column Mapping -> The Unit Test will be carried by ETL developer in development phase. -> ETL developer has to do the data validations also in this phase. Development Integration Testing -

282

-> Run all the mappings in the sequence order. -> First run the source to stage mappings. -> Then run the mappings related to dimensions and facts. System Integration Testing:-> -> -> ->

After development phase, we have to move our code to QA environment. In this environment, we are giving read-only permission to testing people. They will test all the workflows. And they will test our code according to their standards.

Acceptance Testing (UAT):-> This test is carried out in the presence of client side technical s to the data migration from source to destination. Production Environment:---------------------------------> Migrate the code into the Go-Live environment from test environment ( QA Environment ). EXPLANATION: We have to start with ….Our projects are mainly onsite and offshore model projects.Inthis project we have one staging area in between source to target databases. In some project they won’t use staging area’s. Staging area simplify the process..

Architecture AnalysisRequirement GatheringDesign Development Testing Production Analysis and Requirement Gathering: Output :Analysis Doc, Subject Area 100% in onsite,Business Analyst, project manager. Gather the useful information for the DSS and indentifying the subject areas, identify the schema objects and all.. Design: Output: Technical Design Doc’s, HLD, UTP ETL Lead, BA and Data Architect 80%onsite .( Schema design in Erwin and implement in database and preparing the technical design document for ETL. 20% offshore: HLD & UTP Based on the Technical specs.. developers has to create the HLD(high level design) it will have he Informatica flow chart. What are the transformation required for that mapping. In some companies they won’t have HLD. Directly form technical specs they will create mappings. HLD will cover only 75% of requirement.

283

UTP Unit Test Plan.. write the test cases based on the requirement. Both positive and negative test cases. Development : output : Bugs free code, UTR, Integration Test Plan ETL Team and offshore BA 100% offshore Based on the HLD. U have to create the mappings. After that code review and code standard review will be done by another team member. Based on the review comments u have to updated the mapping. Unit testing based on the UTP. U have to fill the UTP andEnter the expected values and name it as UTR (Unit Test Results). 2 times code reviewand 2 times unit testing will be conducted in this phase. Migrating to testing repositoryIntegration test plan has to prepare by the senior people. Testing : Output: ITR, UAT, Deployment Doc and Guide Testing Team, Business Analyst and Client. 80% offshore Based on the integration test plan testing the application and gives the bugs list to thedeveloper. Developers will fix the bugs in the development repository and again migrated to testing repository. Again testing starts till the bugs free code. 20% Onsite UAT Accept Testing.Client will do the UAT.. this is last phase of the etl project. If client satisfy with the product .. next deployment in production environment. Production: 50% offshore 50% onsite Work will be distributed between offshore and onsite based on the run time of the application. Mapping Bugs needs to fix by Development team. Development team will for warranty period of 90 days or based on agreement days.. In ETL projects Three Repositorys. For each repository access permissions and location will be different. Development : E1 Testing : E2 Prduction : E3

284

1.Project Explanation: I’m giving generic explanation of the project. Any project either banking or sales or insurance can use this explanation. First u have to start with 1) U have to first explain about objective of the project and what is client expectations 2) u have to start where ur involvement and responsibility of ur job and limitations of job. Add some points from post Project Architecture reply like offshore and onsite model and team structure.. etc., Main objective of this project is we are providing a system with all the information regarding Sales / Transactions(sales if sales domain / transactions if bank domain or insurance domain) of entire organizations all over the country US / UK ( based on the client locationUS/UK/…..). we will get the daily transaction data from all branches at the end of the day. We have to validate the transactions and implement the business logic based on the transactions type or transaction code. We have to load all historical data into dwh and once finished historical data.We have to load Delta Loads. Delta load means last 24 hrs transactions captured from the source system.In other words u can call it as Change Data Capture (CDC). This Delta loads are scheduled daily basis. Pick some points from What is Target Staging Area Post.. Source to Staging mappings, staging to warehousing.. based on ur comfort level. .Each transaction contains Transaction code.. based on the transaction code u can identify wheather that transaction belongs to sales, purchase / car insurance, health insurance,/ deposit , loan, payment ( u have to change the words based on the project..) etc., based on that code business logic will be change.. we validate and calculate the measureand load to database.

One Mapping explanation :

In Informatica mapping, we first lookup all the transaction codes with code master table to identify the transaction type to implement the correct logic and filter the unnecessary transactions.. because in an organization there are lot of transactions will be there but u have to consideronly required transactions for ur project.. the transaction code exists in the code master table are only transactions u have to consider and other transactions load into one tablecalled Wrap table and invalid records( transaction code missing, null, spaces) to error table. For each dimension table we are creating surrogate key and load into dwh tables. SCD2 Mapping: We are implementing SCD2 mapping for customer dimension or dimension to keep history of the s or customers. We are using SCD2 Date method.before telling this u should know it clearly abt this SCD2 method..careful abt it..

285

Responsibilities.. pick from Project architecture Post and tell according ur comfortable level.. we are responsible foronly development and testing and scheduling we are usingthird party tools..( Control M, AutoSys, Job Tracker, Tivoli or etc..) we simply give the dependencies between each mapping and run time. Based on that Informationscheduling tool team will schedule the mappings. We won’t schedule in Informatica .. that’s itFinished… Please Let me know if u required more explanation regarding any point reply

Telme Your self and Explain your current project process:

I have done my B.sc Computers from Osmania University in 2007. Ap.After that I had an opportunity to work for a Wipro Technologies from Oct 2006 to Aug 2008 where I started off my career as an ETL developer. I have been with Wipro almost 2 years then I shifted to Ness Technologies In Aug 2008. Presently I am working with Ness Total I have 3.5 Years of experience in DWH using Data stage tool in development and Enhancement projects. Primarily I worked on healthcare and manufacturing domains. In my Current project my roles & responsibilities are basically 

I am working with onsite offshore model so we use to get the tasks from my onsite team.



As a developer first I need to understand the physical data model i.e dimensions and facts; their relationship & also functional specifications that tells the business requirement designed by Business Analyst.



I involved into the preparation of source to target mapping sheet (tech Specs) which tell us what is the source and target and which column we need to map to target column and also what would be the business logic. This document gives the clear picture for the development.



Creating Data stage jobs using different transformations to implement business logic.



Preparation of Unit test cases also one of my responsibilities as per the business requirement.

286



And also involved into Unit testing for the mappings developed by myself.



I use to source code review for the Data stage jobs developed by my team .



And also involved into the preparation of deployment plan which contains list of

Data stage jobs they need to migrate based on this deployment team can

migrate the code from one environment to another environment. 

Once the code rollout to production we also work with the production team for 2 weeks where we parallel give the KT. So we also prepare the KT document as well for the production team.

Coming to My Current Project: Currently I am working for XXX project for YYY client. Generally YYY does not have a manufacturing unit, What BIZ (Business) use to do here is before quarter ends they will call for quotations for primary supply channels this process we called as a RFQ’s(Request for quotations).Once BIZ creates RFQ automatically notification will go to supply channels .So these supply channels send back their respective quoted values that we called it as response from the supply channel. After that biz will start negotiations with supply channels then they approve the RFQ’s. All these activities (Creating RFQ, supplier response and approve RFQ etc.)Performed in the oracle apps this is source frontend tool application. These data which get stored into OLTP. So the OLTP contains all the RFQs, supplier response and approval status data. We have some Oracle jobs running between OLTP and ODS which replicate the OLTP data to ODS. It is designed in such a way that any transaction entering into the OLTP is immediately reflected into the ODS. We have a staging area where we load the entire ODS data into staging tables for this we have created some ETL Data stage jobs

these jobs will truncate and

reload the staging tables for each session run. Before loading to staging tables we are dropping indexes then after loading bulk data we are recreating indexes using store procedures. Then we extract all this data from stage & load it into the dimensions & facts on top of dims and facts we have created some materialized views as per the report requirement .Finally report directly pulls the data from MV .These reports /dashboards performance always good because we are not doing any calculation at

287

reporting level. These

dashboards/reports can be used for the analysis purpose like say

how many RFQs created, how many RFQs approved, how many RFQs got responded from the supply channels? What is the budget? What is budget approved? Who is the approval manager pending with whom what is the of the supply channels from the past etc? They don’t have the BI design, so they are using the manual process to achieve the above by exporting the excel sheet; so we can do the drill up, drill down & get all the detailed reports by charts.

Prepared By A.Bhaskar Reddy Email: [email protected] 91-9948047694

288
