SPE-D TRAINING SESSION TITLE: -
PRESENTED BY:
DOL, RDOL, STARDELTA SCHEMES
PSW/SPE-D/TVP Date: -18.06.05
CONCEPTS OF DOL, RDOL & STAR-DELTA STARTER SCHEMES
ELECTRICAL SYSTEMS & EQUIPMENT
1 OF 1
DESIGN STANDARDISATION & DOCUMENTATION GROUP
SHEETS
.
SPE-D TRAINING SESSION TITLE: -
PRESENTED BY:
DOL, RDOL, STARDELTA SCHEMES
PSW/SPE-D/TVP Date: -18.06.05
•
Different terminology in schemes
•
DOL basic concept
•
DOL with additional starting/stopping commands
•
DOL with L/R switch
•
DOL with A/M switch
•
RDOL
•
STAR-DELTA
ELECTRICAL SYSTEMS & EQUIPMENT
2 OF 2
DESIGN STANDARDISATION & DOCUMENTATION GROUP
SHEETS
.
SPE-D TRAINING SESSION TITLE: -
PRESENTED BY:
DOL, RDOL, STARDELTA SCHEMES
PSW/SPE-D/TVP Date: -18.06.05
Different terminology in schemes: Any scheme consists of two types of circuits as mentioned below: 1. Power circuit: It consists of power equipments for switching and protection of the downstream equipment e.g. ACB, MCCB, fuse switch, power or, relays, CTs, etc. Power circuit is generally indicated by the use of thick lines in the scheme drawing. Such that, it can be easily differentiated from the control circuit. 2. Control circuit: The control circuit consists of metering, protection and indication devices with necessary switches and interlocks. It includes the coil circuit of ors, ACBs, their auxiliary s, shunt trips of MCCBs and all indicating lamp circuits. The supply for control circuit is either tapped from one of the phases and neutral of the feeder directly (or through a control transformer) or from external supplies. Control fuses are used for protection of control circuit. The rating of control fuses is selected according to the equipments connected in the control circuit. The following nomenclatures are used while referring to a scheme drawing. •
Cross-reference: For reading convenience, the drawing page on which scheme is drawn is divided into equal parts. The scheme drawing consists of various different equipments like ors, relays, ACBs, MCCBs, etc. These devices consist of power s & auxiliary s. A specific number denotes each device & its terminals used in the scheme. The family of a device alongwith its s & terminals are drawn in one of the sections of the drawing page & the section where each terminal is used is also written alongside. Now the section in which a specified terminal is used also bears a notation alongside, which indicates the section in which the family of that specified terminal exists & the number of the device to which the terminal belongs. This is used as a cross-reference for the referring device and vice-versa. (Please refer the drawings attached )
•
s / Push Buttons: The push buttons are the switches, which can close or open the circuit whenever it is pressed. The is a part which is actually responsible for opening or closing of the circuit. The s are basically of two types
ELECTRICAL SYSTEMS & EQUIPMENT
3 OF 3
DESIGN STANDARDISATION & DOCUMENTATION GROUP
SHEETS
.
SPE-D TRAINING SESSION TITLE: -
PRESENTED BY:
DOL, RDOL, STARDELTA SCHEMES
PSW/SPE-D/TVP Date: -18.06.05
viz. power s & the auxiliary s. The power s act in the power circuit, whereas the auxiliary s act in the control circuit. •
NO/NC s: The auxiliary s are further classified into two parts, namely NO (Normally Open) & NC (Normally Closed). This implies that these s are opened or closed respectively when the coil is de-energised or is in the OFF condition.
•
Stay-put Push Button: This type is a special version of push buttons. As its name suggests these buttons once pressed stay or remain in the same position. Turning the button in the clockwise direction can open these buttons. Another version of this button can be turned to open only by using its own specific key to prevent any unauthorized use of it.
ELECTRICAL SYSTEMS & EQUIPMENT
4 OF 4
DESIGN STANDARDISATION & DOCUMENTATION GROUP
SHEETS
.
SPE-D TRAINING SESSION TITLE: -
PRESENTED BY:
DOL, RDOL, STARDELTA SCHEMES
PSW/SPE-D/TVP Date: -18.06.05
DOL (DIRECT ON LINE) STARTER SCHEME: Power circuit for DOL: The DOL starter power circuit consists of following devices all connected in series. 1. Short circuit protective device -SD(Switch fuse disconnector) or MCCB 2. Power or 3. Overload relay To start the motor, the SD is closed and the start command is given through start P.B. Control circuit for DOL: The coil of or gets supply through the interlocks in the control circuit. The proper operation of DOL starter mainly depends upon the pick-up and drop-off of the or. The indications for the starter are given according to the power or status (ON/OFF) and the fault indication through the relay.
ELECTRICAL SYSTEMS & EQUIPMENT
5 OF 5
DESIGN STANDARDISATION & DOCUMENTATION GROUP
SHEETS
.
SPE-D TRAINING SESSION TITLE: -
PRESENTED BY:
DOL, RDOL, STARDELTA SCHEMES
PSW/SPE-D/TVP Date: -18.06.05
TYPE 1: BASIC DOL STARTER: The basic DOL starter scheme is as explained below •
NO (13,14) of the SD (Q1) is connected in series with the coil of the power or to ensure that unless the fuse switch is closed, the or will not pick up.
•
NC (95,96) of the overload relay (K1) is connected in series of the power or coil so that during an overload when the relay operates, the opens cutting off the supply to the or coil. Therefore, power or opens thus disconnecting the supply to the motor.
•
The stop push button (S1:11,12) is also in series with the or coil so as to cut-off the supply when the stop button is pressed.
•
NO of the power or is connected across the momentary start push button. This is to ensure the continuity of supply even after the start command to the P.B. is relieved. This is called as a hold-on .
•
INDICATION CIRCUIT: Red colour LED is used for 'ON' indication. NO of power or is connected in series with the red LED. Therefore, the red LED illuminates on energizing of the or coil. Green colour LED is used for 'OFF' indication. Hence, a NC of power or is connected in series with the green LED. Therefore, the LED illuminates on de-energizing of the or coil. Amber colour LED is used for 'AUTO TRIP' indication. NO of thermal overload relay is connected in series with the amber LED. Therefore, the LED illuminates on operation of the relay.
ELECTRICAL SYSTEMS & EQUIPMENT
6 OF 6
DESIGN STANDARDISATION & DOCUMENTATION GROUP
SHEETS
.
SPE-D TRAINING SESSION TITLE: -
PRESENTED BY:
DOL, RDOL, STARDELTA SCHEMES
PSW/SPE-D/TVP Date: -18.06.05
TYPE 2: DOL STARTER WITH REMOTE START OPTION: The start P.B. connected in the circuit earlier was connected in the module itself. But many a times a start push button is also required at a remote place like in a control room etc. In order to attain this, another detachable start button is provided across the existing local start push button. The hold on for both the push buttons remains the same. Please refer the attached sketch “DOL02”. •
Both start commands are connected in parallel connection since on operation of any of the start commands, the coil should get supply.
•
The local and remote stop P.B. s are in series with the or coil. This ensures that, if any of the stop command is given, the supply to or coils cuts off. Also, both local as well as remote stop commands are independent of the start commands.
ELECTRICAL SYSTEMS & EQUIPMENT
7 OF 7
DESIGN STANDARDISATION & DOCUMENTATION GROUP
SHEETS
.
SPE-D TRAINING SESSION TITLE: -
PRESENTED BY:
DOL, RDOL, STARDELTA SCHEMES
PSW/SPE-D/TVP Date: -18.06.05
TYPE 3: DOL STARTER WITH LOCAL-REMOTE SELECTOR SWITCH: This case is similar to the previous case, except the addition of a LOCAL-REMOTE SELECTOR SWITCH which allows the to select between local or remote starting only. Please refer the attached sketch “DOL03”. •
This selector switch is used to select from the options of local start and remote start. This ensures that if the wants the start command to be given only from one location in a particular situation, the other start command will not operate the feeder.
•
In such case, two separate hold-on s are required for each of the start commands since the two paths are totally separate from each other.
•
Both remote as well as local stop commands are independent of the selector switch position. This is to ensure that irrespective of the local/remote position of the switch, operator at any location should be able to stop the feeder.
ELECTRICAL SYSTEMS & EQUIPMENT
8 OF 8
DESIGN STANDARDISATION & DOCUMENTATION GROUP
SHEETS
.
SPE-D TRAINING SESSION TITLE: -
PRESENTED BY:
DOL, RDOL, STARDELTA SCHEMES
PSW/SPE-D/TVP Date: -18.06.05
TYPE 4: DOL STARTER WITH LOCAL-REMOTE SELECTOR SWITCH AND MAINTAINED REMOTE START OPTION IN ADDITION TO LOCAL START Please refer the attached sketch “DOL04”. •
In this case, the remote start/stop command is maintained type. This may be also a combined start/stop command. Therefore, the remote start circuit does not need any hold on across it to maintain the continuity of the circuit.
•
Since the start command itself acts as stop command (once start is withdrawn), it is connected in the circuit such that it is independent of the selector switch position. There is no separate start command required in such case.
ELECTRICAL SYSTEMS & EQUIPMENT
9 OF 9
DESIGN STANDARDISATION & DOCUMENTATION GROUP
SHEETS
.
SPE-D TRAINING SESSION TITLE: -
PRESENTED BY:
PSW/SPE-D/TVP Date: -18.06.05
DOL, RDOL, STARDELTA SCHEMES
TYPE 5: DOL STARTER WITH AUTO-MANUAL AND LOCAL-REMOTE SELECTOR SWITCHES: In this case, there is a selector switch in addition to a local-remote selector switch to make a choice between auto start command and manual start command. Please refer the attached sketch “DOL05”. •
In auto mode, only the auto start command (coming from central control room through PLC/DCS, etc.) will be able to start the motor. This command is generally combined start/stop type and hence, separate auto-stop command is not required.
‰
In such cases, the coming in the circuit should be capable to carry the pick-up current of the power or coil. This needs special attention since the comes from an electronic circuit. In case the is not rated for that much current, we have to use an auxiliary relay to multiply this command. The of the auxiliary relay is then used in the circuit of the power or coil. The auxiliary relay in such cases is known as Interposing relay.
‰
Also, the surge coming at the time of switching the coil may harm the circuitry connected to the DCS/PLC . To avoid any such situation, a surge suppressor is used across the coil of the power/auxiliary or. This is an R-C circuit through which the voltage of surge is circulated at the time of switching. Thus, the damage to the
electronic
circuit
is
avoided.
(Same
practice
is
followed
in
case
of
intelligent/electronic relays used.) •
In manual mode, the remote and local start commands can start the motor. The localremote selector switch is used further to differentiate between the two starts (local and remote).
•
The local and remote stop commands will be independent of the type of start command. The auto-stop command since combined with start command should not depend on position of any selector switch.
ELECTRICAL SYSTEMS & EQUIPMENT
10 OF 10
DESIGN STANDARDISATION & DOCUMENTATION GROUP
SHEETS
.
SPE-D TRAINING SESSION TITLE: -
PRESENTED BY:
DOL, RDOL, STARDELTA SCHEMES
PSW/SPE-D/TVP Date: -18.06.05
TYPE 6: REVERSIBLE DOL (RDOL) STARTER This kind of starter is required when the motor is required to run in both forward as well as reverse directions according to the application. Please refer the attached sketch “RDOL06”. •
Power circuit: There is one more power or connected across the power or in the power circuit with two of the phases interchanged to achieve reversal of rotation. The two ors are mechanically interlocked to ensure that both of them do not operate simultaneously. The shorting of two different phases is avoided through this arrangement.
•
Control circuit: The control circuit obviously consists of two start push buttons, one for ‘FORWARD START’ and another for ‘REVERSE START’. Each of them controls the supply to the respective or coils responsible for the supply to the motor in forward and reverse modes. The stop command is common for both modes since it is independent of type of operation. The NC of forward or is connected in series with reverse or coil and that of reverse or is connected in series with forward or coil. This is the electrical interlock, which ensures that only one or will pick up at a time avoiding any mal-operation and consequent damage to the feeder and problems to the dependant processes.
•
Indication circuit: One more Red LED is required to indicate the ‘Reverse ON’ mode. One NO of the reverse or is connected in series with it.
ELECTRICAL SYSTEMS & EQUIPMENT
11 OF 11
DESIGN STANDARDISATION & DOCUMENTATION GROUP
SHEETS
.
SPE-D TRAINING SESSION TITLE: -
PRESENTED BY:
DOL, RDOL, STARDELTA SCHEMES
PSW/SPE-D/TVP Date: -18.06.05
STAR-DELTA (REDUCED VOLTAGE) STARTER In star-delta starter, the starter starts the motor in star-connection so as to reduce starting current taken by the motor. After the motor picks up sufficient speed, the starter changes the connection of motor from star to delta to give higher torque. Please refer the attached sketch “STDL01”. When the push button S2 is pressed the s 23,24 gets closed & the coil of the ETR550 timer gets excited through K3(21,22). ETR550 is a STAR-DELTA timer. It has 2 s i.e. STAR & DELTA . When ETR550 energises, its STAR operates & 15, 18 get shorted. As a result the coil of or K4 gets excited & the power s as well as Auxiliary s (NO & NC) change their positions respectively. Now coil of or K2 gets excited through K4 (13,14) & the power as well as Auxiliary s of K2 change their positions. Now even if the start PB is released the K2 coil continues to get excited through K2 (43,44) & K2 (53,54). After the set time of STAR operation, STAR of timer ETR550 deenergises. So or K4 drops off opening the star point of the motor. It is recommended that after the STAR or drops off there should be some time delay before the DELTA or picks up. This is to ensure that or has fully opened. This period is called as transition period & generally 60 to 80mS is sufficient time. DELTA of ETR550 picks up after this time delay. Now the coil of K3 gets excited through K2 (43,44), K2 (53,54), K4 (21,22) & D1 (25,28) & its s changes its position. As a result the coil of the ETR550 relay loses its excitation & gets isolated from the circuit. Meanwhile the coil of K3 continues to be excited through its hold on s K3 (13,14) & the coil of K2 through the above mentioned path & the motor continues to run in the delta connection. Now when the stop PB is pressed all the coils get de-energised and the motor stops running.
Following are some features of a star-delta starter:
ELECTRICAL SYSTEMS & EQUIPMENT
12 OF 12
DESIGN STANDARDISATION & DOCUMENTATION GROUP
SHEETS
.
SPE-D TRAINING SESSION TITLE: -
PRESENTED BY:
DOL, RDOL, STARDELTA SCHEMES
•
PSW/SPE-D/TVP Date: -18.06.05
A special timer is used along with three power ors. One or connects one end of motor windings to the busbar (known as main or). Other two ors decide the star/delta connection of the motor.
•
The timer is used to control the time duration for which the motor runs in star mode and then automatic changeover to delta. The timer coil gets supply as soon as the start command is given. There are two types of s, which are operated on giving supply to the timer coil. One is immediate changeover and another is delayed changeover . The immediate changeover is connected in series with the star or coil, while the delayed changeover is connected in series with the delta or coil.
•
Since instantaneous of the timer is connected in series with the star or coil, the or picks up as soon as start command is given. After this, the main or also picks up immediately. The star or is closed before main or to avoid arcing at the s while shorting the other end of motor windings.
•
After set time delay in the timer according to load characteristics, the instantaneous of the timer drops down. Therefore star or also drops down. The delayed closes after the instantaneous has opened. The delta or therefore closes after the star or drops down. This is again ensured by putting NC of the star or in series with the delta or coil.
ELECTRICAL SYSTEMS & EQUIPMENT
13 OF 13
DESIGN STANDARDISATION & DOCUMENTATION GROUP
SHEETS
.
SPE-D TRAINING SESSION TITLE: -
PRESENTED BY:
DOL, RDOL, STARDELTA SCHEMES
•
PSW/SPE-D/TVP Date: -18.06.05
Thus, the time delay in the timer consists of two parts: 1. Time for which the motor windings are connected in star. This is the time required by the motor to reach 85%-90% of the full load speed. 2. The time required for transition from star to delta connection.
The first time delay can be set in the timer according to the load characteristics. The range generally available with timer is upto 30s or upto 60s. The second time delay is selectable between 60ms or 120ms. Depending on the circuit condition during transition from star to delta, there are two types of star-delta starters: 1. Open transition: The circuit of the motor remains open in this case during the star to delta transition. The disadvantage of this type of starter is that if the timing between star-delta transition is not selected appropriately then the delta phase becomes equivalent to DOL starter. The motor while changing over from star to delta draws a large current. The advantage of using this starter is its simplicity and lesser space requirement. The sketch “STDL01” shows open transition type of starter. 2. Closed transition: The circuit of the motor remains closed in this case during the star to delta transition. The advantage of using this starter is that the motor keeps on getting supply even during the transition time. A resistance of suitable rating is inserted at the other end of the windings. Thus, the windings of motor are actually connected in star during the transition time, only the resistance is added in series with the windings. The disadvantage of this type of starter is larger space requirement since it requires an additional or for connection of resistance and the space required for the resistors itself. This type of starter is very rarely used since most of the motors/loads are suitable for open transition type of starter.
ELECTRICAL SYSTEMS & EQUIPMENT
14 OF 14
DESIGN STANDARDISATION & DOCUMENTATION GROUP
SHEETS
.
SPE-D TRAINING SESSION TITLE: -
PRESENTED BY:
DOL, RDOL, STARDELTA SCHEMES
PSW/SPE-D/TVP Date: -18.06.05
CONCEPT OF DRAWOUT FEEDER: The starter circuitry is generally accommodated in draw out type of feeder in a MCC . This type of feeder can be racked in or racked put with the help of racking handle, racking screw & sliding telescopic rails. Power supply to the feeder is given through the STABIN mounted on the dropper & power supply to customer is given through the D/O O/G power . Control supply from external side as well as interlock/feedeback from/to outside is given through SICs (Secondary Isolating s). There are three types of SICs (i.e. SERVICE, TEST & SERVICE + TEST). SERVICE SICs can be mounted in front as well as rear column. However TEST & SERVICE + TEST SICs are mounted only in front column. Fully draw-out module has 3 distint functional positions additonal 2 positions for maintenance purpose. 1.SERVICE: The module has stab-in type of s and power s on its rear side (behind the base plate). The stab-in s get connected to the droppers and the power s get connected to the outgoing power terminals in this position. In this position SERVICE SICs & SERVICE +TEST SICs remain engaged. However TEST SICs remain disengaged. 2.TEST: After opening the door module is racked out to bring it to TEST position. In this position, STAB-IN as well as O/G gets disengaged. Hence no power supply is available to module. In this position SERVICE SICs gets disengaged. However TEST & SERVICE +TEST SICs remain engaged. In this position, Control circuit can be tested selectively. 3.ISOLATED: In this position, both power and control SICs get disengaged. 4.MAINTENANCE: In this position, one can get access to all components. 5.HINGED OUT: In this position, one can get access to components on rear and incoming s without removing the module.
ELECTRICAL SYSTEMS & EQUIPMENT
15 OF 15
DESIGN STANDARDISATION & DOCUMENTATION GROUP
SHEETS
.
SPE-D TRAINING SESSION TITLE: -
PRESENTED BY:
DOL, RDOL, STARDELTA SCHEMES
PSW/SPE-D/TVP Date: -18.06.05
TEST FACILITY IN A STARTER: Sometimes the customer asks for a facility to check whether the feeder is working OK or not. The test facility is provided in the test position of a draw-out module since in test position, the power s of the module are disengaged. The Test-SICs however are still in and the module can get the control supply through the same. A test push button is given in place of all the commands, which will give supply to or coil only in test position. Wherever the customer wants some interlocks to be followed even in test position, Service + Test SICs are to be used. This ensures the interlocks work in both the positions. Please refer to the attached sketch ”DOLTEST” for details of the circuit.
ELECTRICAL SYSTEMS & EQUIPMENT
16 OF 16
DESIGN STANDARDISATION & DOCUMENTATION GROUP
SHEETS
.
SPE-D TRAINING SESSION TITLE: -
PRESENTED BY:
DOL, RDOL, STARDELTA SCHEMES
PSW/SPE-D/TVP Date: -18.06.05
CRITICAL THINGS TO BE TAKEN CARE WHILE MAKING A STARTER SCHEME: Following things need special attention while making a scheme drawing for any starter feeder: 1. Control cabling: The control cables for commands coming from customer side (remote, DCS, PLC, etc.) are generally multi-core cables. Therefore whenever control terminals are numbered for external commands, attempt should be made to keep the numbers of these terminals serially. This makes the cable termination at site easier. 2. Draw-Out / Fixed feeders: The starter feeders can be offered in draw-out as well as fixed type. While making scheme, the type of feeder should be kept in mind. The type of draw-out and fixed feeder affects the type of control terminals and power terminals. The representation of the two types of terminals is different in a scheme diagram. 3. Control Supply: Control supply coming to the control circuit of the feeder should be shown appropriately. It may be coming from inside the feeder or from the switchboard or any external supply. The auxiliary bus, from which the supply is tapped, should be named correctly in accordance with the general arrangement drawing. 4. Control circuit protection: The fuses or MCBs given for the control circuit protection should be appropriately selected. The rating of the fuses/MCBs is to be selected according to the equipments connected in the circuit. According to the application, the type of SIC is to be selected. 5. SIC arrangement: The SICs have specific position in a draw-out module. Therefore the arrangement of the SICs should be checked in a scheme. The number of SICs that can be accommodated also should be checked with respect to the feeder size. Also it should be kept in mind that Test SICs and Service + Test SICs can only come in the front column of the module. 6. Star-Delta scheme logic: If any interlocks are there in a star-delta starter feeder, the scheme should be re-checked for logic. The operation of the feeder in star and delta modes should be analysed.
ELECTRICAL SYSTEMS & EQUIPMENT
17 OF 17
DESIGN STANDARDISATION & DOCUMENTATION GROUP
SHEETS
SPE-D TRAINING SESSION TITLE: -
PRESENTED BY:
DOL, RDOL, STARDELTA SCHEMES
PSW/SPE-D/TVP Date: -18.06.05
CONCEPTS OF DOL, RDOL & STAR-DELTA STARTER SCHEMES
ELECTRICAL SYSTEMS & EQUIPMENT
1 OF 1
DESIGN STANDARDISATION & DOCUMENTATION GROUP
SHEETS
.
SPE-D TRAINING SESSION TITLE: -
PRESENTED BY:
DOL, RDOL, STARDELTA SCHEMES
PSW/SPE-D/TVP Date: -18.06.05
•
Different terminology in schemes
•
DOL basic concept
•
DOL with additional starting/stopping commands
•
DOL with L/R switch
•
DOL with A/M switch
•
RDOL
•
STAR-DELTA
ELECTRICAL SYSTEMS & EQUIPMENT
2 OF 2
DESIGN STANDARDISATION & DOCUMENTATION GROUP
SHEETS
.
SPE-D TRAINING SESSION TITLE: -
PRESENTED BY:
DOL, RDOL, STARDELTA SCHEMES
PSW/SPE-D/TVP Date: -18.06.05
Different terminology in schemes: Any scheme consists of two types of circuits as mentioned below: 1. Power circuit: It consists of power equipments for switching and protection of the downstream equipment e.g. ACB, MCCB, fuse switch, power or, relays, CTs, etc. Power circuit is generally indicated by the use of thick lines in the scheme drawing. Such that, it can be easily differentiated from the control circuit. 2. Control circuit: The control circuit consists of metering, protection and indication devices with necessary switches and interlocks. It includes the coil circuit of ors, ACBs, their auxiliary s, shunt trips of MCCBs and all indicating lamp circuits. The supply for control circuit is either tapped from one of the phases and neutral of the feeder directly (or through a control transformer) or from external supplies. Control fuses are used for protection of control circuit. The rating of control fuses is selected according to the equipments connected in the control circuit. The following nomenclatures are used while referring to a scheme drawing. •
Cross-reference: For reading convenience, the drawing page on which scheme is drawn is divided into equal parts. The scheme drawing consists of various different equipments like ors, relays, ACBs, MCCBs, etc. These devices consist of power s & auxiliary s. A specific number denotes each device & its terminals used in the scheme. The family of a device alongwith its s & terminals are drawn in one of the sections of the drawing page & the section where each terminal is used is also written alongside. Now the section in which a specified terminal is used also bears a notation alongside, which indicates the section in which the family of that specified terminal exists & the number of the device to which the terminal belongs. This is used as a cross-reference for the referring device and vice-versa. (Please refer the drawings attached )
•
s / Push Buttons: The push buttons are the switches, which can close or open the circuit whenever it is pressed. The is a part which is actually responsible for opening or closing of the circuit. The s are basically of two types
ELECTRICAL SYSTEMS & EQUIPMENT
3 OF 3
DESIGN STANDARDISATION & DOCUMENTATION GROUP
SHEETS
.
SPE-D TRAINING SESSION TITLE: -
PRESENTED BY:
DOL, RDOL, STARDELTA SCHEMES
PSW/SPE-D/TVP Date: -18.06.05
viz. power s & the auxiliary s. The power s act in the power circuit, whereas the auxiliary s act in the control circuit. •
NO/NC s: The auxiliary s are further classified into two parts, namely NO (Normally Open) & NC (Normally Closed). This implies that these s are opened or closed respectively when the coil is de-energised or is in the OFF condition.
•
Stay-put Push Button: This type is a special version of push buttons. As its name suggests these buttons once pressed stay or remain in the same position. Turning the button in the clockwise direction can open these buttons. Another version of this button can be turned to open only by using its own specific key to prevent any unauthorized use of it.
ELECTRICAL SYSTEMS & EQUIPMENT
4 OF 4
DESIGN STANDARDISATION & DOCUMENTATION GROUP
SHEETS
.
SPE-D TRAINING SESSION TITLE: -
PRESENTED BY:
DOL, RDOL, STARDELTA SCHEMES
PSW/SPE-D/TVP Date: -18.06.05
DOL (DIRECT ON LINE) STARTER SCHEME: Power circuit for DOL: The DOL starter power circuit consists of following devices all connected in series. 1. Short circuit protective device -SD(Switch fuse disconnector) or MCCB 2. Power or 3. Overload relay To start the motor, the SD is closed and the start command is given through start P.B. Control circuit for DOL: The coil of or gets supply through the interlocks in the control circuit. The proper operation of DOL starter mainly depends upon the pick-up and drop-off of the or. The indications for the starter are given according to the power or status (ON/OFF) and the fault indication through the relay.
ELECTRICAL SYSTEMS & EQUIPMENT
5 OF 5
DESIGN STANDARDISATION & DOCUMENTATION GROUP
SHEETS
.
SPE-D TRAINING SESSION TITLE: -
PRESENTED BY:
DOL, RDOL, STARDELTA SCHEMES
PSW/SPE-D/TVP Date: -18.06.05
TYPE 1: BASIC DOL STARTER: The basic DOL starter scheme is as explained below •
NO (13,14) of the SD (Q1) is connected in series with the coil of the power or to ensure that unless the fuse switch is closed, the or will not pick up.
•
NC (95,96) of the overload relay (K1) is connected in series of the power or coil so that during an overload when the relay operates, the opens cutting off the supply to the or coil. Therefore, power or opens thus disconnecting the supply to the motor.
•
The stop push button (S1:11,12) is also in series with the or coil so as to cut-off the supply when the stop button is pressed.
•
NO of the power or is connected across the momentary start push button. This is to ensure the continuity of supply even after the start command to the P.B. is relieved. This is called as a hold-on .
•
INDICATION CIRCUIT: Red colour LED is used for 'ON' indication. NO of power or is connected in series with the red LED. Therefore, the red LED illuminates on energizing of the or coil. Green colour LED is used for 'OFF' indication. Hence, a NC of power or is connected in series with the green LED. Therefore, the LED illuminates on de-energizing of the or coil. Amber colour LED is used for 'AUTO TRIP' indication. NO of thermal overload relay is connected in series with the amber LED. Therefore, the LED illuminates on operation of the relay.
ELECTRICAL SYSTEMS & EQUIPMENT
6 OF 6
DESIGN STANDARDISATION & DOCUMENTATION GROUP
SHEETS
.
SPE-D TRAINING SESSION TITLE: -
PRESENTED BY:
DOL, RDOL, STARDELTA SCHEMES
PSW/SPE-D/TVP Date: -18.06.05
TYPE 2: DOL STARTER WITH REMOTE START OPTION: The start P.B. connected in the circuit earlier was connected in the module itself. But many a times a start push button is also required at a remote place like in a control room etc. In order to attain this, another detachable start button is provided across the existing local start push button. The hold on for both the push buttons remains the same. Please refer the attached sketch “DOL02”. •
Both start commands are connected in parallel connection since on operation of any of the start commands, the coil should get supply.
•
The local and remote stop P.B. s are in series with the or coil. This ensures that, if any of the stop command is given, the supply to or coils cuts off. Also, both local as well as remote stop commands are independent of the start commands.
ELECTRICAL SYSTEMS & EQUIPMENT
7 OF 7
DESIGN STANDARDISATION & DOCUMENTATION GROUP
SHEETS
.
SPE-D TRAINING SESSION TITLE: -
PRESENTED BY:
DOL, RDOL, STARDELTA SCHEMES
PSW/SPE-D/TVP Date: -18.06.05
TYPE 3: DOL STARTER WITH LOCAL-REMOTE SELECTOR SWITCH: This case is similar to the previous case, except the addition of a LOCAL-REMOTE SELECTOR SWITCH which allows the to select between local or remote starting only. Please refer the attached sketch “DOL03”. •
This selector switch is used to select from the options of local start and remote start. This ensures that if the wants the start command to be given only from one location in a particular situation, the other start command will not operate the feeder.
•
In such case, two separate hold-on s are required for each of the start commands since the two paths are totally separate from each other.
•
Both remote as well as local stop commands are independent of the selector switch position. This is to ensure that irrespective of the local/remote position of the switch, operator at any location should be able to stop the feeder.
ELECTRICAL SYSTEMS & EQUIPMENT
8 OF 8
DESIGN STANDARDISATION & DOCUMENTATION GROUP
SHEETS
.
SPE-D TRAINING SESSION TITLE: -
PRESENTED BY:
DOL, RDOL, STARDELTA SCHEMES
PSW/SPE-D/TVP Date: -18.06.05
TYPE 4: DOL STARTER WITH LOCAL-REMOTE SELECTOR SWITCH AND MAINTAINED REMOTE START OPTION IN ADDITION TO LOCAL START Please refer the attached sketch “DOL04”. •
In this case, the remote start/stop command is maintained type. This may be also a combined start/stop command. Therefore, the remote start circuit does not need any hold on across it to maintain the continuity of the circuit.
•
Since the start command itself acts as stop command (once start is withdrawn), it is connected in the circuit such that it is independent of the selector switch position. There is no separate start command required in such case.
ELECTRICAL SYSTEMS & EQUIPMENT
9 OF 9
DESIGN STANDARDISATION & DOCUMENTATION GROUP
SHEETS
.
SPE-D TRAINING SESSION TITLE: -
PRESENTED BY:
PSW/SPE-D/TVP Date: -18.06.05
DOL, RDOL, STARDELTA SCHEMES
TYPE 5: DOL STARTER WITH AUTO-MANUAL AND LOCAL-REMOTE SELECTOR SWITCHES: In this case, there is a selector switch in addition to a local-remote selector switch to make a choice between auto start command and manual start command. Please refer the attached sketch “DOL05”. •
In auto mode, only the auto start command (coming from central control room through PLC/DCS, etc.) will be able to start the motor. This command is generally combined start/stop type and hence, separate auto-stop command is not required.
‰
In such cases, the coming in the circuit should be capable to carry the pick-up current of the power or coil. This needs special attention since the comes from an electronic circuit. In case the is not rated for that much current, we have to use an auxiliary relay to multiply this command. The of the auxiliary relay is then used in the circuit of the power or coil. The auxiliary relay in such cases is known as Interposing relay.
‰
Also, the surge coming at the time of switching the coil may harm the circuitry connected to the DCS/PLC . To avoid any such situation, a surge suppressor is used across the coil of the power/auxiliary or. This is an R-C circuit through which the voltage of surge is circulated at the time of switching. Thus, the damage to the
electronic
circuit
is
avoided.
(Same
practice
is
followed
in
case
of
intelligent/electronic relays used.) •
In manual mode, the remote and local start commands can start the motor. The localremote selector switch is used further to differentiate between the two starts (local and remote).
•
The local and remote stop commands will be independent of the type of start command. The auto-stop command since combined with start command should not depend on position of any selector switch.
ELECTRICAL SYSTEMS & EQUIPMENT
10 OF 10
DESIGN STANDARDISATION & DOCUMENTATION GROUP
SHEETS
.
SPE-D TRAINING SESSION TITLE: -
PRESENTED BY:
DOL, RDOL, STARDELTA SCHEMES
PSW/SPE-D/TVP Date: -18.06.05
TYPE 6: REVERSIBLE DOL (RDOL) STARTER This kind of starter is required when the motor is required to run in both forward as well as reverse directions according to the application. Please refer the attached sketch “RDOL06”. •
Power circuit: There is one more power or connected across the power or in the power circuit with two of the phases interchanged to achieve reversal of rotation. The two ors are mechanically interlocked to ensure that both of them do not operate simultaneously. The shorting of two different phases is avoided through this arrangement.
•
Control circuit: The control circuit obviously consists of two start push buttons, one for ‘FORWARD START’ and another for ‘REVERSE START’. Each of them controls the supply to the respective or coils responsible for the supply to the motor in forward and reverse modes. The stop command is common for both modes since it is independent of type of operation. The NC of forward or is connected in series with reverse or coil and that of reverse or is connected in series with forward or coil. This is the electrical interlock, which ensures that only one or will pick up at a time avoiding any mal-operation and consequent damage to the feeder and problems to the dependant processes.
•
Indication circuit: One more Red LED is required to indicate the ‘Reverse ON’ mode. One NO of the reverse or is connected in series with it.
ELECTRICAL SYSTEMS & EQUIPMENT
11 OF 11
DESIGN STANDARDISATION & DOCUMENTATION GROUP
SHEETS
.
SPE-D TRAINING SESSION TITLE: -
PRESENTED BY:
DOL, RDOL, STARDELTA SCHEMES
PSW/SPE-D/TVP Date: -18.06.05
STAR-DELTA (REDUCED VOLTAGE) STARTER In star-delta starter, the starter starts the motor in star-connection so as to reduce starting current taken by the motor. After the motor picks up sufficient speed, the starter changes the connection of motor from star to delta to give higher torque. Please refer the attached sketch “STDL01”. When the push button S2 is pressed the s 23,24 gets closed & the coil of the ETR550 timer gets excited through K3(21,22). ETR550 is a STAR-DELTA timer. It has 2 s i.e. STAR & DELTA . When ETR550 energises, its STAR operates & 15, 18 get shorted. As a result the coil of or K4 gets excited & the power s as well as Auxiliary s (NO & NC) change their positions respectively. Now coil of or K2 gets excited through K4 (13,14) & the power as well as Auxiliary s of K2 change their positions. Now even if the start PB is released the K2 coil continues to get excited through K2 (43,44) & K2 (53,54). After the set time of STAR operation, STAR of timer ETR550 deenergises. So or K4 drops off opening the star point of the motor. It is recommended that after the STAR or drops off there should be some time delay before the DELTA or picks up. This is to ensure that or has fully opened. This period is called as transition period & generally 60 to 80mS is sufficient time. DELTA of ETR550 picks up after this time delay. Now the coil of K3 gets excited through K2 (43,44), K2 (53,54), K4 (21,22) & D1 (25,28) & its s changes its position. As a result the coil of the ETR550 relay loses its excitation & gets isolated from the circuit. Meanwhile the coil of K3 continues to be excited through its hold on s K3 (13,14) & the coil of K2 through the above mentioned path & the motor continues to run in the delta connection. Now when the stop PB is pressed all the coils get de-energised and the motor stops running.
Following are some features of a star-delta starter:
ELECTRICAL SYSTEMS & EQUIPMENT
12 OF 12
DESIGN STANDARDISATION & DOCUMENTATION GROUP
SHEETS
.
SPE-D TRAINING SESSION TITLE: -
PRESENTED BY:
DOL, RDOL, STARDELTA SCHEMES
•
PSW/SPE-D/TVP Date: -18.06.05
A special timer is used along with three power ors. One or connects one end of motor windings to the busbar (known as main or). Other two ors decide the star/delta connection of the motor.
•
The timer is used to control the time duration for which the motor runs in star mode and then automatic changeover to delta. The timer coil gets supply as soon as the start command is given. There are two types of s, which are operated on giving supply to the timer coil. One is immediate changeover and another is delayed changeover . The immediate changeover is connected in series with the star or coil, while the delayed changeover is connected in series with the delta or coil.
•
Since instantaneous of the timer is connected in series with the star or coil, the or picks up as soon as start command is given. After this, the main or also picks up immediately. The star or is closed before main or to avoid arcing at the s while shorting the other end of motor windings.
•
After set time delay in the timer according to load characteristics, the instantaneous of the timer drops down. Therefore star or also drops down. The delayed closes after the instantaneous has opened. The delta or therefore closes after the star or drops down. This is again ensured by putting NC of the star or in series with the delta or coil.
ELECTRICAL SYSTEMS & EQUIPMENT
13 OF 13
DESIGN STANDARDISATION & DOCUMENTATION GROUP
SHEETS
.
SPE-D TRAINING SESSION TITLE: -
PRESENTED BY:
DOL, RDOL, STARDELTA SCHEMES
•
PSW/SPE-D/TVP Date: -18.06.05
Thus, the time delay in the timer consists of two parts: 1. Time for which the motor windings are connected in star. This is the time required by the motor to reach 85%-90% of the full load speed. 2. The time required for transition from star to delta connection.
The first time delay can be set in the timer according to the load characteristics. The range generally available with timer is upto 30s or upto 60s. The second time delay is selectable between 60ms or 120ms. Depending on the circuit condition during transition from star to delta, there are two types of star-delta starters: 1. Open transition: The circuit of the motor remains open in this case during the star to delta transition. The disadvantage of this type of starter is that if the timing between star-delta transition is not selected appropriately then the delta phase becomes equivalent to DOL starter. The motor while changing over from star to delta draws a large current. The advantage of using this starter is its simplicity and lesser space requirement. The sketch “STDL01” shows open transition type of starter. 2. Closed transition: The circuit of the motor remains closed in this case during the star to delta transition. The advantage of using this starter is that the motor keeps on getting supply even during the transition time. A resistance of suitable rating is inserted at the other end of the windings. Thus, the windings of motor are actually connected in star during the transition time, only the resistance is added in series with the windings. The disadvantage of this type of starter is larger space requirement since it requires an additional or for connection of resistance and the space required for the resistors itself. This type of starter is very rarely used since most of the motors/loads are suitable for open transition type of starter.
ELECTRICAL SYSTEMS & EQUIPMENT
14 OF 14
DESIGN STANDARDISATION & DOCUMENTATION GROUP
SHEETS
.
SPE-D TRAINING SESSION TITLE: -
PRESENTED BY:
DOL, RDOL, STARDELTA SCHEMES
PSW/SPE-D/TVP Date: -18.06.05
CONCEPT OF DRAWOUT FEEDER: The starter circuitry is generally accommodated in draw out type of feeder in a MCC . This type of feeder can be racked in or racked put with the help of racking handle, racking screw & sliding telescopic rails. Power supply to the feeder is given through the STABIN mounted on the dropper & power supply to customer is given through the D/O O/G power . Control supply from external side as well as interlock/feedeback from/to outside is given through SICs (Secondary Isolating s). There are three types of SICs (i.e. SERVICE, TEST & SERVICE + TEST). SERVICE SICs can be mounted in front as well as rear column. However TEST & SERVICE + TEST SICs are mounted only in front column. Fully draw-out module has 3 distint functional positions additonal 2 positions for maintenance purpose. 1.SERVICE: The module has stab-in type of s and power s on its rear side (behind the base plate). The stab-in s get connected to the droppers and the power s get connected to the outgoing power terminals in this position. In this position SERVICE SICs & SERVICE +TEST SICs remain engaged. However TEST SICs remain disengaged. 2.TEST: After opening the door module is racked out to bring it to TEST position. In this position, STAB-IN as well as O/G gets disengaged. Hence no power supply is available to module. In this position SERVICE SICs gets disengaged. However TEST & SERVICE +TEST SICs remain engaged. In this position, Control circuit can be tested selectively. 3.ISOLATED: In this position, both power and control SICs get disengaged. 4.MAINTENANCE: In this position, one can get access to all components. 5.HINGED OUT: In this position, one can get access to components on rear and incoming s without removing the module.
ELECTRICAL SYSTEMS & EQUIPMENT
15 OF 15
DESIGN STANDARDISATION & DOCUMENTATION GROUP
SHEETS
.
SPE-D TRAINING SESSION TITLE: -
PRESENTED BY:
DOL, RDOL, STARDELTA SCHEMES
PSW/SPE-D/TVP Date: -18.06.05
TEST FACILITY IN A STARTER: Sometimes the customer asks for a facility to check whether the feeder is working OK or not. The test facility is provided in the test position of a draw-out module since in test position, the power s of the module are disengaged. The Test-SICs however are still in and the module can get the control supply through the same. A test push button is given in place of all the commands, which will give supply to or coil only in test position. Wherever the customer wants some interlocks to be followed even in test position, Service + Test SICs are to be used. This ensures the interlocks work in both the positions. Please refer to the attached sketch ”DOLTEST” for details of the circuit.
ELECTRICAL SYSTEMS & EQUIPMENT
16 OF 16
DESIGN STANDARDISATION & DOCUMENTATION GROUP
SHEETS
.
SPE-D TRAINING SESSION TITLE: -
PRESENTED BY:
DOL, RDOL, STARDELTA SCHEMES
PSW/SPE-D/TVP Date: -18.06.05
CRITICAL THINGS TO BE TAKEN CARE WHILE MAKING A STARTER SCHEME: Following things need special attention while making a scheme drawing for any starter feeder: 1. Control cabling: The control cables for commands coming from customer side (remote, DCS, PLC, etc.) are generally multi-core cables. Therefore whenever control terminals are numbered for external commands, attempt should be made to keep the numbers of these terminals serially. This makes the cable termination at site easier. 2. Draw-Out / Fixed feeders: The starter feeders can be offered in draw-out as well as fixed type. While making scheme, the type of feeder should be kept in mind. The type of draw-out and fixed feeder affects the type of control terminals and power terminals. The representation of the two types of terminals is different in a scheme diagram. 3. Control Supply: Control supply coming to the control circuit of the feeder should be shown appropriately. It may be coming from inside the feeder or from the switchboard or any external supply. The auxiliary bus, from which the supply is tapped, should be named correctly in accordance with the general arrangement drawing. 4. Control circuit protection: The fuses or MCBs given for the control circuit protection should be appropriately selected. The rating of the fuses/MCBs is to be selected according to the equipments connected in the circuit. According to the application, the type of SIC is to be selected. 5. SIC arrangement: The SICs have specific position in a draw-out module. Therefore the arrangement of the SICs should be checked in a scheme. The number of SICs that can be accommodated also should be checked with respect to the feeder size. Also it should be kept in mind that Test SICs and Service + Test SICs can only come in the front column of the module. 6. Star-Delta scheme logic: If any interlocks are there in a star-delta starter feeder, the scheme should be re-checked for logic. The operation of the feeder in star and delta modes should be analysed.
ELECTRICAL SYSTEMS & EQUIPMENT
17 OF 17
DESIGN STANDARDISATION & DOCUMENTATION GROUP
SHEETS
Related Documents 3m3m1z
Dol Schemes 54642x
December 2019 45
Dol Dol Dol Tol Pal Tol...... 5g2p2b
December 2021 0
Baby Dol 4754f
May 2022 0
Dol Laporan 382b3q
April 2020 19
Sol I De Dol 4i5q6i
May 2023 0
