Drill Stem Test 2n4x14

Drill Stem Test

Drill Stem Test A drill stem test (DST) is a procedure for isolating and testing the surrounding geological formation through the drill stem. The test is a measurement of pressure behavior at the drill stem and is a valuable way to obtain important sampling information on the formation fluid and to establish the probability of commercial production. In oil and natural gas extraction, the drill stem includes the drill pipe, drill collars, bottomhole assembly, and drill bit. During normal drilling, fluid is pumped through the drill stem and out the drill bit. In a drill stem test, the drill bit is removed, a drill stem test tool is added, and fluid from the formation is recovered through the drill stem, while several measurements of pressure are being made.[1] The basic drill stem test tool consists of a packer or packers, valves or ports that may be opened and closed from the surface, and two or more pressure-recording devices. (A packer is an expanding plug which can be used to seal off sections of the open or cased well, to isolate them for testing.[2]) The drill stem test tool is lowered on the drill pipe to the zone to be tested. The packer or packers are set to isolate the zone from the drilling fluid column, the tester valve is opened, and testing begins. History Working in El Dorado, Arkansas, in the 1920s, E.C. Johnston and his brother M.O. Johnston developed the first drill stem tester and ran the first commercial drill stem test in 1926. In April 1929, the Johnston Formation Testing Corporation was granted a patent (U.S. Patent 1,709,940) and they subsequently refined the testing system in the early 1930s.[3] In the 1950s, Schlumberger introduced a method for testing formations using wireline. The Schlumberger formation-testing tool, placed in operation in 1953, fired a shaped charge through a rubber pad that had been expanded in the hole until it was securely fixed in the hole at the depth required. Formation fluids flowed through the perforation and connecting tubing into a container housed inside the tool. When filled, the container was closed, sealing the fluid sample at the formation pressure. The tool was then brought to the surface, where the sample could be examined. In 1956, Schlumberger acquired Johnston Testers and continues to perform drill stem tests and wireline formation tests in both open and cased holes.

External links • A good definition http://www.northstardst.com/our_services/drillstem_testing.html • A good definition http://www.horizontalwelltesting.com

Notes [1] Society of Petrophysicists & Well Log Analysts glossary, accessed on 12 September 2006 at http:/ / www. spwla. org/ library_info/ glossary/ reference/ glossd/ glossd. htm [2] Society of Petrophysicists & Well Log Analysts glossary, accessed on 12 September 2006 at http:/ / www. spwla. org/ library_info/ glossary/ reference/ glossp/ glossp. htm [3] History of Petroleum Engineering, API Division of Production, New York City, 1961, pages 561-566
