DUAL AND MULTIFUEL ENGINE

Introduction • Shortage of liquid fuel and gaseous fuels being cheaper than liquid fuels gave birth to dual fuel engines. • From recent air and water pollution concern it became necessary to utilize sewage gas. • Gaseous fuels have high self-ignition temperature and burn efficiently.

2

‰ Duel-fuel

operation combines the possibility of operating a diesel engine on liquid fuels such as diesel oil or gas oil and on gaseous fuels such as natural gas, sewage gas and cook oven gas.

3

Working Principle

• Works on diesel cycle. • Gaseous fuel (primary fuel) is added to air inducted into the engine or supplied by supercharger. • The mixture of air and gaseous fuel gets compressed in the cylinder. • Liquid fuel called pilot fuel injected near the TDC acts as a source of ignition. • Gas-air mixture ignites establishing a number of flamefronts. • In a dual-fuel engine combustion starts similar to CI engine, but it is propagated by flame-fronts as in SI engine. 4

Working Principle

5

Gas mode • High efficiency and low emissions • Automatic and instant transfer to diesel operation in alarm to situations • Transfer diesel at any load operation

Diesel mode • As an ordinary diesel engine • Transfer to gas operation preferably at load part • Pilot fuel injection in operation

6

Performance of Dual-Fuel engines

• Produce equal power when operating on liquid fuels as with gaseous fuel. • Dual fuel engines are slightly more efficient to conventional diesel at full • However, the maximum output is load. the same. about • Efficiency of dual in part load is poor. slightly • Typical diesel efficiency is 41%, and dual efficiency is 38.5. 7

Advantages of Dual Fuel Engines • Efficient utilization of cheap gas from various available sources. • Gas burns without leaving any residue pollution). (no

• Clean combustion results in reduced wear of engine parts and reduced consumption of lubricating oil. 8

Advantages of Dual Fuel Engines

• Increased utility of the power plant as the versatility of change-over from gas to diesel andamount vice-versa. • Only a small of liquid fuel needed to run engine. • Suitable for total energy installation (sewage gas) 9

Advantages of Dual Fuel Engines • Can be used to produce synthetic gas, which is a mixture of CO and H2. • Ideal for LPG tankers as they can utilize the gas which evaporates.

10

Factors affecting combustion in a dual fuel engine • Pilot fuel quantity

11

12

• Injection timing

13

• Effect of Cetane number • Effect of inlet temperature

14

15

• Effect of type of gaseous fuels

16

• Effect of throttling • Effect of mixture strength

17

Main type of gaseous fuel & their requirement

• Natural gas • Sewage gas • LPG • Town gas • Hydrogen gas • Clean • Dry • Minimum calorific value gas 4500 kcl/cm3 light fuel oil 10,200 kcl/kg 18

Knock control in dual engine • Excess supply of air • Use of cold combustion air • Increased cooling of piston • Use of additives • Reducing the pressure of gaseous fuel the

19

Multi-fuel Engines

• A multi-fuel engine is one which would operate satisfactorily with substantially unchanged performance and efficiency, on a wide verity of fuels ranging from diesel oil, crude oil to lighter fuels like gasoline and even normal lubrication oil. • Mainly developed for military requirements. • Has good idling and part load efficiency and low exhaust smoke. 20

• Should have high compression ratios as gasoline have low cetane numbers. • Must be capable of starting at subzero temperatures. • Large stroke/bore ratio gives a compact combustion chamber so that it remains hot in all conditions of speed. • An open combustion chamber is suited as in a pre-combustion chamber, additional heat losses due to throat occur (e.g., spherical or M-combustion chamber). 21

Difficulties • Tendency of vapor lock while using lighter fuels. • Tendency of increased wear due to lower lubricity of gasoline. • Requirements for injecting different volumes of fuel depending on their heating values and compressibility.

22
