Emf Survey 3o4b47

4/15/15

EMF SURVEY GUIDLINE 









Always wear Safety kit to Climb up in Tower. Talk to Technician For Excess in Site, Without permission never go to the Site. Take Signage's Photo, Sector Photo, Panoramic Photo as in format. Consider All Adjacent building inside 60m Radius from the Tower. Consider All Adjacent Tower inside 20m

1

4/15/15

EMF SURVEY PROCESS Requirement Before Survey •

Talk to technician/Engineer for access in the site (Talk to him one day before going to site so that no issue should be there in the site) • Charge your Rechargeable cells for continuous working. • Before going to site that your kit is working properly 2

4/15/15

KIT USED IN EMF SURVEY GPS (Global Positioning System) Camera Measuring Tap Magnetic Com Signage Poster Cell Charger 4-Rechargeable cells Laptop

Safety kit- compulsary 3

4/15/15

SURVEY PROCESS 

After Reaching site first signage's are available or not, if not then place the signage's at the PositionDanger Warning Caution





At Tower At Shelter At Entry Gate

Take GPS Photo ( Lat- Long ) should be clearly visible. Note Lat/Long , DFN from nominal, AMSL. Count No. of Operators with Name 4

Take Antenna Sector Photo

4/15/15

Antenna and no. of operator should be Visible

5

4/15/15

TAKE SIGNAGE'S PHOTO

Take these photo’s by some distance as Background should be visible. 6

4/15/15

g n o r W

a n g i S

e g

o t o h P

7

PANORAMIC PHOTO

4/15/15

8

4/15/15

9

4/15/15

g c i n o r am W or to n o a h p P 10

4/15/15

Adjacent Building and Tower Photo Consider all the Buildings and Tower in 60m Radius from Tower No. of Building and Photo should be in order and no. of floor of building should be clearly visible from the picture.

11

4/15/15

Roof Top Layout All Dimension s and Signage's are necessary

12

4/15/15

BUILDING LAYOUT Building No., Height, Azimuth and Distance should be properly Motioned

13

4/15/15

TOWER PHOTO Tower Photo should show the complete Height of the Tower

Take Building Photo in case of RTT,RTP or Wall Mount name it B0.

14

4/15/15

CORNER DATA

Building Data

15

4/15/15

THAT THERE ARE AT LEAST 20 PHOTO’S I.E. 12 PANORAMIC 3 SECTOR 3 SIGNAGE'S 1 TOWER 1 GPS +NO. OF BUILDINGS PHOTO

16

4/15/15

EMF EXPOSURE ZONES

17

4/15/15

ACCESSIBILITY CATEGORIES

18

4/15/15

19

4/15/15

20

4/15/15

21
