EMU Drive settings from old Fax 12-23-98… Kevin Sykes Sony MPF420-1 Drive Model:

Sony MPF420-1 Power

Sampler:

ESI E4 E64

Pin Config: 10-5 11-6

15 14 13 12 11

10 9 8 7 6

5 4 3 2 1

Floppy Cable

Sony MPF420-1 Drive Model:

Sony MPF420-1 Power

Sampler:

E IIIX EMAX EMAX II

Pin Config: 10-5 11-6 13-14

15 14 13 12 11

10 9 8 7 6

5 4 3 2 1

Floppy Cable

Sony MPF420Drive Model: Sampler:

Sampler:

Sp-1200

Sony MPF420-2 Rev 2? Pin Config: 10-5 9-4 12-13 11-6

Drive Model:

Teac FD-235F

Emax SE Hd

Pin Config:

Power 15 14 13 12 11

10 9 8 7 6

5 4 3 2 1

Floppy Cable

MS

D0 Drive Model: Sampler:

Sony MFD-73W-01D

Emax SE Hd Switch all the way back.
