SCD5200/RTU50 Software Release Note 1101155-R MR-1
RTU50/SCD5200 Software Release Note 1101155-R MR-1
Invensys Process Systems (Australia) Pty Ltd 10 Brandl Street Eight Mile Plains, QLD, 4113 Australia Telephone: +61 7 3340 2111
The Foxboro Company 33 Commercial Street, Foxboro Massachusetts 02035-2099 United States of America Telephone: +1-888-369-2676
Acknowledgements Foxboro and I/A Series are ed trademarks of The Foxboro Company. Invensys is a trademark of Invensys plc.
Checked By & Date: SCADA Product Representative C. Sloane
Approved By & Date: Development Group Representative Andrew C. West
Development Manager – RTU Technology Shahid Ansari
COPYRIGHT RESERVED The information and design as detailed in this document is the property of Invensys Process Systems (Australia) Pty Limited, and / or its Associates and must be returned on demand. It is issued on the strict condition that, except with our written permission it must not be reproduced, copied or communicated to any third party, nor be used for any purpose other than that stated in the particular inquiry, order or contract with which it is issued. The reservation of copyright in this document extends from each date appearing thereon and in respect of the subject matter as it appeared at the relevant date.
© Invensys Process Systems (Australia) Pty. Ltd. 1999–2008 ACN 000 522 261
I/A Series Intelligent SCADA System
Page 2 of 7
RTU50/SCD5200 Software Release Note 1101155-R MR-1
DOCUMENT REVISION HISTORY: Rev:
Date:
Comments:
Prep:
Check:
App:
_
29 Mar 1999
Initial Release
C. Weaver
P. Ellis
P. Holloway
A
23 Jun 1999
Release 12.2.1 1101155-A
C. Weaver
P. Johns
C. Sloane
B
06 Mar 2000
Release 12.4.2 1101155-B
C. Weaver
P. Johns
P. Ellis
C
D
27 Jul 2001
Release 12.5.0 1101155-D
J. McDonald
P. Holloway C. Sloane B. Atchison
O. Traynor
E
20 Dec 2001
Release 12.6.2 1101155-E
J. McDonald
P. Holloway C. Sloane B. Atchison
O. Traynor
F
26 Mar 2002
Release 12.6.4 1101155-F
J. McDonald
P. Holloway C. Sloane B. Atchison
O. Traynor
H
07 Nov 2002
Release 12.6.6 1101155-H
J. McDonald
P. Holloway C. Sloane B. Atchison
O. Traynor
J
20 Dec 2002
Release 12.6.7 1101155-J
J. McDonald
A. West C. Sloane B. Atchison
O. Traynor
K
28 Mar 2003
Release 13.0.0 1101155-K
J. McDonald
A. West C. Sloane B. Atchison
P. Holloway
L
15 Sep 2003
Release 13.2.2 1101155-L
J. McDonald
C. Weaver A. Hanlon
P. Holloway
M
19 Dec 2003
Release 13.4.0 1101155-M
J. McDonald
C. Weaver A. Hanlon
P. Holloway
N
16 Sep 2004
Release 13.6.1 1101155-N
J. McDonald
C. Sloane A. West
P. Ellis
P
03 Feb 2005
Release 13.8.0 1101155-P
J. McDonald
C. Sloane A. West
C. Sloane
R
25 Mar 2008
Release 14.0.0. 1101155-R
J.P. Shukla
C. Sloane A. West
Shahid Ansari
R MR-1
30 Sep 2008
Release 14.0.0. 1101155-R MR-1
J.P. Shukla
C. Sloane A. West
Shahid Ansari
I/A Series Intelligent SCADA System
Page 3 of 7
RTU50/SCD5200 Software Release Note 1101155-R MR-1
Table of Contents 1.
INTRODUCTION .............................................................................................................................. 5
2.
FUNCTIONALITY AND COMPATIBILITY ....................................................................................... 5
2.1 2.2 2.3 2.4
NEW FUNCTIONALITY .......................................................................................................................... 5 ENHANCED FUNCTIONALITY ................................................................................................................. 5 DEFECT CORRECTION ......................................................................................................................... 6 SALL CALCULATIONS ......................................................................................................................... 6
3.
KNOWN PROBLEMS AND LIMITATIONS...................................................................................... 7
4.
INSTALLATION/UPGRADE INSTRUCTIONS ................................................................................ 7
5.
VALIDATION AND VERIFICATION STATEMENT ......................................................................... 7
6.
RELATED DOCUMENTATION ........................................................................................................ 7
7.
CONTENTS OF RELEASE MEDIA ................................................................................................. 7
I/A Series Intelligent SCADA System
Page 4 of 7
RTU50/SCD5200 Software Release Note 1101155-R MR-1
1. Introduction This release note describes a maintenance release of the SCD5200 and RTU50 Protected Mode Software and Utilities identified as part number 1101155, revision R MR-1 (built from internal baseline 14.0.0.MR1). This release note does not repeat information in the release note for 1101155-R, and is intended to be read in conjunction with that release note. . In particular, this note describes the corrections and changes provided in this maintenance release, and the upgrade procedure. s should be aware that, at the time of product release, there remain outstanding incidents. Project managers and customers requiring a more detailed assessment of the advantages and disadvantages of adopting 1101155-R MR-1 for their specific projects should IPS Global Product (GPS) (email: [email protected]).
2. Functionality and Compatibility This maintenance release is identified as version 14.0.0.MR1 in the Configuration Control System. This version number may be viewed on the first page of RTU information using RTV or TOOL32. This maintenance release is provided specifically for the purpose of providing the stated new and enhanced functionality, and correcting the stated faults. No other changes have been made from the baseline of 1101155-R (14.0.0).
2.1 New Functionality No new functionality has been added to the 1101155-R MR-1 release.
2.2 Enhanced Functionality Table 1 shows the enhanced functionality that is included in the 1101155-R MR-1 release. Change Request:
Subsystem:
Description
IFW#921
Diagnostics
RTU firmware has been added to allow clearing of diagnostic error messages ("complain" messages) shown in RTV.
IFW#960
Diagnostics
RTU complain messages now display the date as well as the time.
Table 1: Enhanced Functionality in 1101155-R MR-1
I/A Series Intelligent SCADA System
Page 5 of 7
RTU50/SCD5200 Software Release Note 1101155-R MR-1
2.3 Defect Correction Table 2 shows a list of the defects that have been corrected in the 1101155-R MR-1 release. Change Request:
Subsystem:
Description
IFW#871
DNP Master
RTV no longer loses communication with RTU when "Failover logical RTU" is activated in RTV DNP Master page.
IFW#916
OptoNet
Time synchronisation through OptoNet was delayed by 5 minutes at RTU start-up. This has been reduced to 30 seconds.
IFW#949
OptoNet
Raise/Lower commands sent as digital controls from a Master Station via DNP and OptoNet to a virtual (calc) Ai point now cause the target values to be updated correctly
IFW#953
T/IP
In previous versions of the RTU software a T/IP DNP interface might cause RTU page fault and RTU reset when a tentative socket is closed prematurely. This is now prevented.
IFW#954
DNP Slave
The buffer overflow flag in a DNP slave is now cleared when all event have been transmitted and acknowledged.
IFW#961
T/IP
ARP cache entries have been increased from 8 to 50.
IFW#962
IEC101 Slave
Double reporting of Digital input change across OptoNet has been fixed. It is now reported once for each Digital input change.
IFW#964
IEC101 Slave
IEC 101 Slave now reports events for flag changes received from DNP Master Digital SOE points. Previously, flag changes for these points were not reported. This fault was introduced in RTU software version 1101155-N.
IFW#965
T/IP
The RTU now accepts configurations having the Ethernet channel names configured to values other than the default channel names of "ChannelA" and "ChannelB". Previously any name other than the default prevented the RTU from booting up.
IFW#969
T/IP
The RTU now stores the last configured Ethernet speed in addition to IP address in NVRAM area.
IFW#972
T/IP
The RTU Firmware now defaults the Ethernet speed to 10Mbps when the T/IP port configuration version is 4.
IFW#975
T/IP
The RTU no longer reboots intermittently due to page fault. The problem was introduced in 1101155-R in conjunction with an update to the IP stack code.
IFW#978
T/IP
The T/IP communication no longer fails due to Receive FIFO overflow and Rx Packet dropping at high data traffic rates. Table 2: Defects Corrected in 1101155-R MR-1
2.4 SALL Calculations SALL calculation binaries compiled using the utilities supplied with 1101155-P MR-1 and later versions will load and function correctly with this release. Binaries compiled using the utilities supplied with any other previous RTU Software version will need to be recompiled to load and function correctly with this release.
I/A Series Intelligent SCADA System
Page 6 of 7
RTU50/SCD5200 Software Release Note 1101155-R MR-1
3. Known Problems and Limitations Please refer to for 1101155-R release note. One of these limitations has been removed in this maintenance release (Refer to CR IFW#965 above).
4. Installation/Upgrade Instructions Refer to 1101155-R release note. In addition, for successful installation of RTV and SYSCFG, installation should not be attempted when logged in as a Windows domain if the PC is not connected to the network on which the ’s domain resides (CR FW#609). The release media for this release contains complete installation programs for the RTU Software and associated utilities. The modified RTU software files for this maintenance release are available in the “patch” directory on the release media. If desired, the files in this directory can be used without installing the other contents of the release media.
5. Validation and Verification Statement A variety of verification and validation activities have been conducted on the 1101155-R MR-1 RTU Software and Utilities prior to their release. 1. Change Design and Code Reviews The design and source code of all baseline changes were documented and reviewed before acceptance into system integration. Reviews were performed by peer developers and by independent Software Verification Engineers. 2. Incident Retest For each incident addressed in this release, test cases were prepared and documented by an independent team to ensure that the incident was fixed satisfactorily and that no unintended sideeffects of the modification were evident. No outstanding problems were identified during testing or in incident reports from the field. However there may be defects that arise in project usage patterns that have not been identified during testing.
6. Related Documentation For further information on RTU50 and SCD5200 installation, configuration, programming and diagnostics, please refer to the documents listed in the release note for 1101155-R.
7. Contents of Release Media The RTU Software and Utilities are installed on a Windows PC using the installation program menu.exe, contained on release media 1101190-J MR-1. Typically this installation program will run automatically after loading the media. The installed RTU Software files have the following characteristics: File name:
File Size:
155RMR1.Z
275417 bytes
155RMR1.DLL
678940 bytes
I/A Series Intelligent SCADA System
Page 7 of 7
