FATTY ULTRA DL 70
FATTY ULTRA DL 70 Specifications ID: Tapered alloy inner steerer at crown junction, black top cap, silver hex nut, can have canti mount - disc mount or both, Year
2000-2003
Travel (mm)
70
Damper
Oil damped, cartridge
Spring element
Air sprung, coil negative spring
Lockout
Button On/Off
KITS ITEM NUMBER
DESCRIPTION
HDUPDD60/
Cartridge Kit, DD60 upgrade
HD110/BLU
Spring Kit,DD60/MC60, medium
HD110/GRE
Spring Kit,DD60/MC60, soft
HD110/RED
Spring Kit,DD60/MC60, stiff
RECOMMENDED SAG B - A = SAG (mm) Measure the length of the fork as shown below – this as measurement A. B
A
With the help of a second person, seat the rider on the saddle with feet on pedals and hands on the handlebar. Again measure the length of the fork - this as measurement B.
SAG
To calculate sag subtract B from A . The recommended sag measurement (in millimeters) as a percentage of your forks total travel, should fall within the guidelines listed in the attached chart. To increase sag, release air. To decrease sag, add air.
PRESSURE LIMITS MINIMUM - 45 psi (3.1 bar) MAXIMUM - 120 psi (8.3 bar) DIAL
© 2009 Cannondale Europe • www.cannondale.com
RECOMMENDED SAG 10-20% = 8mm
FATTY ULTRA DL 70
KITS ITEM NUMBER
DESCRIPTION
HD181/
DL 70 oil cartridge unit
HD183/
FT70/DL70 air cartridge
HDUPDL/70
Cartridge kit, DL70 upgrade
HD312/
Kit, Piston, DD60 w/ Seals & Shims
HD313/
Kit, lockout shims/seals DL Cartridge
HD314/
Kit, 5 X negative spring Green DL70
QHDST/EBO
Headset Cannondale/Coda HeadShok Black
HD169/
Kit, Bearings, Headset - 2 / HeadShok
HD191/BLK
Slim Boot, 5-rib, Black
HD191/YEL
Slim Boot, 5-rib, Yellow
HD213/
Lock-Out lever
TOOLS ITEM NUMBER
DESCRIPTION
HD136/
Tool, HeadShok outer cap pin
HDTL149/
Tool, HeadShok fork installation
HDTL168/
Tool, bullet, Lefty and Fatty 12.7 mm
KT016/
Tool, HEADSHOK Bearing Reset
KT020/
Kit, Lefty Steerer install (also for Fattys)
KH031/
Super Castle Tool
© 2009 Cannondale Europe • www.cannondale.com
SUPER FATTY M 80
SUPER FATTY M 80 Specifications ID: Tapered alloy inner steerer at crown junction, black top cap, can have canti mount - disc mount or both, Year
1999-2005
Travel (mm)
80
Damper
Mechanical damper/Friction
Spring element
Coil sprung
Lockout
No
Rebound
No
KITS ITEM NUMBER
DESCRIPTION
HDUPDL/80
Cartridge Kit, DL80 upgrade
HD182/
DL80 Oil cartridge unit – Formerly DD80 Oil Cartridge
HD184/
FT80/DL80 Air cartridge
RECOMMENDED SAG B - A = SAG (mm) Measure the length of the fork as shown below – this as measurement A. B
A
With the help of a second person, seat the rider on the saddle with feet on pedals and hands on the handlebar. Again measure the length of the fork - this as measurement B.
SAG
To calculate sag subtract B from A .
PRESSURE SET UP Spring preload DIAL/TOP CAP
© 2009 Cannondale Europe • www.cannondale.com
The recommended sag measurement (in millimeters) as a percentage of your forks total travel, should fall within the guidelines listed in the attached chart. To increase sag, release air. To decrease sag, add air.
SUPER FATTY M 80
KITS ITEM NUMBER
DESCRIPTION
QHDST/EBO
Headset Cannondale/Coda HeadShok Black
HD169/
Kit, Bearings, Headset - 2/ HeadShok
HD191/BLK
Slim Boot, 5-rib, Black
HD191/YEL
Slim Boot, 5-rib, Yellow
HD213/
Lockout lever
HD155/BLU
Spring Kit, MC80, Medium
HD155/GRE
Spring Kit, MC80, Light
HD155/RED
Spring Kit, MC80, Stiff
TOOLS ITEM NUMBER
DESCRIPTION
HD136/
Tool, HeadShok outer cap pin
HDTL149/
Tool, HeadShok fork installation
KT016/
Tool, HeadShok bearing reset
KT020/
Kit, Lefty Steerer install (also for Fattys)
KH031/
Super castle tool
© 2009 Cannondale Europe • www.cannondale.com
SUPER FATTY D & DL
SUPER FATTY D & DL Specifications ID: Shorter air valve end (ca. 8,5mm), 4 pin spanner holes under lockout dial, tapered inner tube down to crown. Year
2001-2003
Travel (mm)
80
Damper
Oil damped
Spring element
Air sprung, coil negative spring
Lockout
On the fly
Rebound
No
KITS ITEM NUMBER
DESCRIPTION
HDUPDL/80
Cartridge Kit, DL80 upgrade
HD182/
DL80 Oil cartridge unit – Formerly DD80 Oil Cartridge
HD184/
FT80/DL80 Air cartridge
RECOMMENDED SAG B - A = SAG (mm) Measure the length of the fork as shown below – this as measurement A. B
A
With the help of a second person, seat the rider on the saddle with feet on pedals and hands on the handlebar. Again measure the length of the fork - this as measurement B.
SAG
To calculate sag subtract B from A .
DIAL
© 2009 Cannondale Europe • www.cannondale.com
The recommended sag measurement (in millimeters) as a percentage of your forks total travel, should fall within the guidelines listed in the attached chart. To increase sag, release air. To decrease sag, add air.
SUPER FATTY D & DL
KITS ITEM NUMBER
DESCRIPTION
QHDST/EBO
Headset Cannondale/Coda HeadShok Black
HD169/
Kit, Bearings, Headset - 2; HeadShok
HD191/BLK
Slim Boot, 5-rib, Black
HD191/YEL
Slim Boot, 5-rib, Yellow
HD213/
lockout lever
HDUPDL/80
CARTRIDGE KIT, DL80 UPGRADE
HD182/
DL80 Oil Cartridge Unit – Formerly DD80 Oil Cartridge
HD184/
FT80/DL80 Air Cartridge
HD166/
Seal Kit
HD212
Negative Spring
TOOLS ITEM NUMBER
DESCRIPTION
HD136/
Tool, HeadShok outer cap pin
HDTL149/
Tool, HeadShok fork installation
KT016/
Tool, HeadShok bearing reset
KT020/
Kit, Lefty Steerer install (also for Fattys)
KH031/
Super castle tool
HDTL168/
Bullet tool
© 2009 Cannondale Europe • www.cannondale.com
SUPER FATTY ULTRA DL (INCH THREAD)
SUPER FATTY ULTRA DL
(Inch thread)
Specifications ID: Shorter air valve end (ca. 8,5mm), 4 pin spanner holes under lockout dial, square inner tube down to crown. Year
2001-2003
Travel (mm)
80
Damper
Oil damped
Spring element
Air sprung, coil negative spring
Lockout
On the fly
Rebound
No
KITS ITEM NUMBER
DESCRIPTION
HD155/BLU
Spring Kit, MC80, Medium
HD155/GRE
Spring Kit, MC80, Light
HD155/RED
Spring Kit, MC80, Stiff
RECOMMENDED STARTING AIR PRESSURE Lbs
Kg
Psi
Bar
120 - 150
68
95
6.6
160
73
110
7.6
170
77
120
8.3
180
82
130
9.0
190
86
135
9.3
200
91
140
9.7
210
95
145
10.0
220
100
150
10.3
PRESSURE LIMITS MINIMUM - 70 psi (4.8 bar) MAXIMUM - 200 psi (13.8 bar) DIAL
© 2009 Cannondale Europe • www.cannondale.com
RECOMMENDED SAG 10-20% = 8 mm
VALVE
SUPER FATTY ULTRA DL (INCH THREAD) HD169/
HD213/BLK
20.0 Nm, 177 InLbs
27.0 Nm, 240 InLbs Loctite™ 242
HD191/BLK HD191/YEL
HD182/
HD171/
KF212/
KITS ITEM NUMBER
DESCRIPTION
QHDST/EBO
Headset Cannondale/Coda HeadShok Black
HD169/
Kit, Bearings, Headset - 2; HeadShok
HD191/BLK
Slim Boot, 5-rib, Black
HD191/YEL
Slim Boot, 5-rib, Yellow
HD213/
lockout lever
HDUPDL/80
CARTRIDGE KIT, DL80 UPGRADE
HD182/
DL80 Oil Cartridge Unit – Formerly DD80 Oil Cartridge
HD184/
FT80/DL80 Air Cartridge
TOOLS ITEM NUMBER
DESCRIPTION
HD136/
Tool, HeadShok outer cap pin
HDTL149/
Tool, HeadShok fork installation
KT016/
Tool, HeadShok bearing reset
KT020/
Kit, Lefty Steerer install (also for Fattys)
KH031/
Super castle tool
HDTL168/
Bullet tool
© 2009 Cannondale Europe • www.cannondale.com
SUPER FATTY ULTRA DLR MA gURA (INCH THREAD)
SUPER FATTY ULTRA DLR Magura Specifications ID: 13 mm higher outer tube (visual extension), hex nut for lock-out dial 15mm, red rebound dial with allen bolt in center, yellow/green cartridge body Year
2005 (2006 with metric thread)
Travel (mm)
80
Damper
Oil damped
Spring element
Air sprung, coil negative spring
Lockout
On the fly
Rebound
External adjustment
RECOMMENDED STARTING AIR PRESSURE Lbs
Kg
Psi
Bar
120
54
50
3.4
130
59
55
3.8
140
64
60
4.1
150
68
65
4.5
160
73
70
4.8
170
77
75
5.2
180
82
80
5.5
190
86
90
6.2
200
91
100
7.2
PRESSURE LIMITS MINIMUM - 45 psi (3.1 bar) MAXIMUM - 120 psi (8.3 bar) DIAL
© 2009 Cannondale Europe • www.cannondale.com
RECOMMENDED SAG 10-20% = 8 mm
INCH THREAD CARTRIDGE
SUPER FATTY ULTRA DLR Magura (INCH THREAD) KF229/
HD169/
KF228/
13mm Extension
HD191/BLK
KF226/ KF247/
KF232/
HD171/ KF230/ KF231/ KF245/ KF246/ HD170/
TOOLS ITEM NUMBER
DESCRIPTION
HDTL149/
Tool, HeadShok Fork Installation
KT016/
Tool, HeadShok Bearing Reset
HDTL187/
Shaft Clamp Tool for Lefty and DL70
KT020/
Kit, Lefty Steerer install (also for Fattys)
KH031/
Super castle tool
KITS ITEM NUMBER
DESCRIPTION
KF235/
Upgrade kit, Damper, BLUE DL80
KF263/
Upgrade kit, Damper, RED DLR80, SOFT
KF264/
Upgrade kit, Damper, RED DLR80, STD
KF265/
Upgrade kit, Damper, RED DLR80, FIRM
KH005/
Kit, Air cylinder including Negative springs
HDUPDL/80
Cartridge kit, DL80 upgrade
© 2009 Cannondale Europe • www.cannondale.com
SUPER FATTY ULTRA DLR MA gURA (METRIC THREAD)
SUPER FATTY ULTRA DLR Magura Specifications ID: Metric thread, 13 mm higher outer tube (visual extension), hex nut for lockout dial 15mm, red rebound dial with allen bolt in center, yellow/green cartridge body (cartridge Body has small groove above thread) Year
2006 with metric thread
Travel (mm)
80
Damper
Oil damped
Spring element
Air sprung, coil negative spring
Lockout
On the fly
Rebound
External adjustment
RECOMMENDED STARTING AIR PRESSURE Lbs
Kg
Psi
Bar
120
54
50
3.4
130
59
55
3.8
140
64
60
4.1
150
68
65
4.5
160
73
70
4.8
170
77
75
5.2
180
82
80
5.5
190
86
90
6.2
200
91
100
7.2
PRESSURE LIMITS MINIMUM - 45 psi (3.1 bar) MAXIMUM - 120 psi (8.3 bar) DIAL
© 2009 Cannondale Europe • www.cannondale.com
RECOMMENDED SAG 10-20% = 8 mm
METRIC THREAD CARTRIDGE
SUPER FATTY ULTRA DLR Magura (metric THREAD) KF229/
HD169/
KF228/
13mm Extension
HD191/BLK KF247/
KF232/
HD171/ KF230/ KF231/ KF245/ KF246/ HD170/
TOOLS ITEM NUMBER
DESCRIPTION
HDTL149/
Tool, HeadShok Fork Installation
KT016/
Tool, HeadShok Bearing Reset
HDTL187/
Shaft Clamp Tool for Lefty and DL70
KT020/
Kit, Lefty Steerer install (also for Fattys)
KH031/
Super castle tool
KITS ITEM NUMBER
DESCRIPTION
KF235/
Upgrade kit, Damper, BLUE DL80
KF263/
Upgrade kit, Damper, RED DLR80, SOFT
KF264/
Upgrade kit, Damper, RED DLR80, STD
KF265/
Upgrade kit, Damper, RED DLR80, FIRM
KH005/
Kit, Air cylinder including Negative springs
© 2009 Cannondale Europe • www.cannondale.com
SUPER FATTY ULTRA DL (METRIC THREAD)
SUPER FATTY ULTRA DL
(Metric thread)
Specifications ID: Metric thread, silver top cap under lockout dial, 2-pin spanner holes, longer valve end (10,6mm) Year
2005-2009
Travel (mm)
80
Damper
Oil damped
Spring element
Air sprung, coil negative spring
Lockout
On the fly
Rebound
No
KITS ITEM NUMBER
DESCRIPTION
KF263/
Kit, Damper, RED DLR80, SOFT - Upgrade possible
KF264/
Kit, Damper, RED DLR80, STD - Upgrade possible
KF265/
Kit, Damper, RED DLR80, FIRM - Upgrade possible
KH005/
Kit, Air cylinder including Negative springs
RECOMMENDED STARTING AIR PRESSURE Lbs
Kg
Psi
Bar
120 - 150
68
50
3.4
160
73
60
4.1
170
77
70
4.8
180
82
80
5.5
190
86
90
6.2
200
91
100
6.9
210
95
105
7.2
220
100
110
7.6
PRESSURE LIMITS MINIMUM - 40 psi (2.8 bar) MAXIMUM - 120 psi (8.3 bar) DIAL
© 2009 Cannondale Europe • www.cannondale.com
RECOMMENDED SAG 10-20% = 8 mm
VALVE
SUPER FATTY ULTRA DL (METRIC THREAD)
HD213/BLK
HD169/
20.0 Nm, 177 InLbs
27.0 Nm, 240 InLbs Loctite™ 242
KF235/ KF236/
HD191/BLK
KH005/
HD171/ KF238/ KF237/
KP067/
KITS HD170/
ITEM NUMBER
DESCRIPTION
KF235/
Kit, Damper, BLUE DL80
KF236/
Kit, Seal, BLUE DL80+05 DL50
KF237/
Kit, Schrader Plug, BLUE DL80, including Valve & Cap
KF238/
Kit, Air Piston, BLUE DL80, including Spring and holder
HD169/
Kit, Bearings, Headset - 2/ HeadShok
QHDST/EBO
Headset Cannondale/Coda HeadShok Black
HD191/BLK
Slim Boot, 5-rib, Black
HD191/YEL
Slim Boot, 5-rib, Yellow
KP067/
Air piston quad seal, bag of 10
HD213/BLK
Lockout lever
TOOLS ITEM NUMBER
DESCRIPTION
HD136/
Tool, HeadShok outer cap pin
HDTL149/
Tool, HeadShok fork installation
HDTL168/
TOOL, Bullet, Lefty and Fatty 12.7 mm
KT016/
Tool, HeadShok bearing reset
KH031
Super castle tool
KT020/
Kit, Lefty Steerer install (also for Fattys)
© 2009 Cannondale Europe • www.cannondale.com
SUPER FATTY ULTRA DLR (METRIC THREAD)
SUPER FATTY ULTRA DLR Specifications ID: Metric thread, long valve end, same lockout dial as Speed DLR, red rebound dial with set screw on side, conical top cap Year
2006 +
Travel (mm)
80
Damper
Oil damped/Cartridge
Spring element
Air sprung, coil negative spring
Lockout
On the fly
Rebound
External adjustment
RECOMMENDED STARTING AIR PRESSURE Lbs
Kg
Bar
120
54
50
3.4
130
59
55
3.8
140
64
60
4.1
150
68
65
4.5
160
73
70
4.8
170
77
75
5.2
180
82
80
5.5
190
86
90
6.2
200
91
100
7.2
PRESSURE LIMITS MINIMUM - 45 psi (3.1 bar) MAXIMUM - 120 psi (8.3 bar) DLR DIAL
© 2009 Cannondale Europe • www.cannondale.com
Psi
RECOMMENDED SAG 10-20% = 8 mm
SUPER FATTY ULTRA DLR (METRIC THREAD)
KF211/
HD169/
KF210/
KH005/
KF266/
HD191/BLK KF263/ KF264/ KF265/ KF236/ KH022/
HD171/
KF237/ KF267/
HD170/ KP067/
KITS ITEM NUMBER
DESCRIPTION
KF235/
Kit, Damper, BLUE DL80
KF236/
Kit, Seal, BLUE DL80+05 DL50
KF237/
Kit, Schrader Plug, BLUE DL80, including Valve & Cap
KF238/
Kit, Air Piston, BLUE DL80, including Spring and holder
HD169/
Kit, Bearings, Headset - 2/ HeadShok
QHDST/EBO
Headset Cannondale/Coda HeadShok Black
HD191/BLK
Slim Boot, 5-rib, Black
HD191/YEL
Slim Boot, 5-rib, Yellow
KP067/
Air piston quad seal, bag of 10
HD213/BLK
Lockout lever
© 2009 Cannondale Europe • www.cannondale.com
LEFTY DLR 100 STEEL
LEFTY DLR 100 Steel
Specifications ID: Welded steel spindle, no threads under lockout dial, machined clamps, not bonded Year
2000
Travel (mm)
100
Damper
Oil damped
Spring element
Air sprung, coil negative spring
Lockout
On the fly
Rebound
External adjustment
Compatilibities
All HeadShok Stems cartridge and aircylinder not compatible with 2001+ parts
RECOMMENDED SAG B
A
B - A = SAG (mm) Measure the length of the fork as shown below – this as measurement A. With the help of a second person, seat the rider on the saddle with feet on pedals and hands on the handlebar. Again measure the length of the fork - this as measurement B.
SAG
To calculate sag subtract B from A . The recommended sag measurement (in millimeters) as a percentage of your forks total travel, should fall within the guidelines listed in the attached chart. To increase sag, release air. To decrease sag, add air.
RECOMMENDED SAG XC DIAL
© 2009 Cannondale Europe • www.cannondale.com
20-30%
Lefty DLR 100 Steel
KITS ITEM NUMBER
DESCRIPTION
HD201/
Lefty DLR '00 Dial Holder Plug For Lockout/Damping ADJ
HD202/BLU
Lefty DLR '00 Oil Damper Cartridge, MEDIUM
HD202/GRN
Lefty DLR '00 Oil Damper Cartridge, SOFT
HD202/RED
Lefty DLR '00 Oil Damper Cartridge, HARD
HD203/
Lefty DLR '00 Air Cylinder and Air Piston
HD211/
Lefty DLR '00 Air Cylinder Saddle
HD214/
Lefty DLR '00 Damping Adjuster Knob
HD212/
Negative Spring KIT for Lefty 100 Oil Cart
HD212/WHT
Kit, Spring - Negative, Lefty, X-firm
HD011/
Kit, Band Clamp Cable Guide (2), Boot Lefty
HD205/
Lefty Upper clamp
HD206/
Lower crown/steerer, Lefty 100
TOOLS ITEM NUMBER
DESCRIPTION
HDTL200/
Tool, HeadShok Lefty cart castles '00 only
KT020/
Steerer instalation/removal
HDTL168/
1/2 bullet tool
HD187/
1/2 inch shaft clamps
QCTL108/
Tool, Lefty truing axle
KT016/
Tool, HeadShok Bearing Reset
© 2009 Cannondale Europe • www.cannondale.com
LEFTY DLR 100 (STEEL oR TITANIUM)
LEFTY DLR 100 Steel or Titanium Specifications ID: Titanium or steel spindel, threads and large lockring under lockout dial, forged clamps – not bonded Year
2000-2004
Travel (mm)
100
Damper
Oil damped
Spring element
Air sprung, coil negative spring
Lockout
On the fly
Rebound
External adjustment
Compatilibities
All HeadShok Stems Cartridge and aircylinder Not compatible with 2000 parts
RECOMMENDED SAG B
A
B - A = SAG (mm) Measure the length of the fork as shown below – this as measurement A. With the help of a second person, seat the rider on the saddle with feet on pedals and hands on the handlebar. Again measure the length of the fork - this as measurement B.
SAG
To calculate sag subtract B from A . The recommended sag measurement (in millimeters) as a percentage of your forks total travel, should fall within the guidelines listed in the attached chart. To increase sag, release air. To decrease sag, add air.
RECOMMENDED SAG XC DIAL
© 2009 Cannondale Europe • www.cannondale.com
20-30%
Lefty DLR 100 (Steel or titanium)
KITS ITEM NUMBER
DESCRIPTION
HD166/
KIT All Seals, FT, DL and Lefty 100 cartridges
HD001/
Kit, '01 DLR Dial holder/plug
HD002/
Kit, Air cylinder for '01 DLR
HD022/
Kit, Damp Adjust Knob-2nd. Lefty '01->
HD023/
Kit, 2001 DLR Damper - SM
HD026/
Kit, Perch-DL70/80, DLR 100
HD212/
Negative Spring Kit for Lefty 100 Oil Cart
HD212/WHT
Kit, Spring - Negative, Lefty, X-firm
HD011/
Kit, Band Clamp Cable Guide (2), Boot Lefty
HD205/
Lefty Upper clamp
HD206/
lower crown/steerer, Lefty 100
KT040/
Kit, Steerer, X-Long Lefty
HD016/
Steerer, Lefty
TOOLS ITEM NUMBER
DESCRIPTION
KT006/
Tool , lower cartridge Cap remover
KT020/
Steerer installation/removal
HDTL168/
1/2 bullet tool
HD187/
1/2 inch shaft clamps
KT004/
Tool, Lefty DLR/ELO Kidney tool '01 and +
QCTL108/
Tool, Lefty Truing Axle
KT016/
Tool, HeadShok Bearing Reset
© 2009 Cannondale Europe • www.cannondale.com
LEFTY CARboN ELo oR DL R 100
LEFTY CARBON DLR 100 Forged Steel or Titanium ELO or DLR Specifications ID: Titanium or steel spindle, threads and large lockring under lock-out dial, forged bonded clamps, carbon outer tube, first gen. has carbon inner tube Year
2001-2004
Travel (mm)
100
Damper
Oil damped
Spring element
Air sprung, coil negative spring
Lockout
On the fly or ELO (electronic lockout)
Rebound
External adjustment
Compatilibities
Cartridge and aircylinder not compatible with 2000 parts, fits Stem/steerer, (carbon) SL steeringtube and extra long steeringtube.
RECOMMENDED SAG B
A
B - A = SAG (mm) Measure the length of the fork as shown below – this as measurement A. With the help of a second person, seat the rider on the saddle with feet on pedals and hands on the handlebar. Again measure the length of the fork - this as measurement B.
SAG
To calculate sag subtract B from A . The recommended sag measurement (in millimeters) as a percentage of your forks total travel, should fall within the guidelines listed in the attached chart. To increase sag, release air. To decrease sag, add air.
RECOMMENDED SAG XC ELO DIAL
© 2009 Cannondale Europe • www.cannondale.com
20-30% DLR DIAL
Lefty Carbon ELO or DLR 100 HD003/
HD301/
KITS
HD002/
HD004/
ITEM NUMBER
DESCRIPTION
HD166/
KIT All Seals, FT, DL and Lefty 100 cartridges
HD001/
Kit, '01 DLR Dial holder/plug
HD002/
Kit, Air cylinder for '01 DLR
HD022/
Kit, Damp Adjust Knob-2nd. Lefty '01->
HD023/
Kit, 2001 DLR Damper - SM
HD026/
Kit, Perch-DL70/80, DLR 100
HD212/
Negative Spring Kit for Lefty 100 Oil Cart
HD212/WHT
Kit, Spring - Negative, Lefty, X-firm
HD011/
Kit, Band Clamp Cable Guide (2), Boot Lefty
HD205/
Lefty Upper clamp
HD206/
lower crown/steerer, Lefty 100
KT040/
Kit, Steerer, X-Long Lefty
HD016/
Steerer, Lefty
HD300/
Kit, Battery – ELO Li-Ion high power
HD301/
Kit, Elec. Cont. Unit - ELO
HD003/
Collar, Upper Carbon Lefty
HD004/
Collar, Lower, Lefty Carbon gold
HD005/
Kit, Air Cylinder Saddle-2002 Full Carbon Lefty
HD027/
Kit, Perch -Carbon ELO
HD010/
Kit, Spacers-Lefty Travel Reducers
TOOLS
HD205/
ITEM NUMBER
DESCRIPTION
KT006/
Tool , lower cartridge Cap remover
KT020/
Steerer installation/removal
HDTL168/
1/2 bullet tool
HD187/
1/2 inch shaft clamps
KT004/
Tool, Lefty DLR/ELO Kidney tool '01 and +
QCTL108/
Tool, Lefty Truing Axle
KT016/
Tool, HeadShok Bearing Reset
© 2009 Cannondale Europe • www.cannondale.com
LEFTY MA x 140 FFD
LEFTY MAX 140 FFD (Fluid Flow Damping) Only Alloy version Specifications ID: Black spindle, alloy outer tube, polished clamps, red rebound dial - no screw, bottom (images) Year
2006 + 2007
Travel (mm)
140
Damper
Oil damped
Spring element
Steel coil sprung, “Fluid Flow Damping”
Lockout
No
Rebound
External adjustment
Compatilibities
All stems (not stem/steerer) TPC + SPV upgrade possible
KITS ITEM NUMBER
DESCRIPTION
KF216/
Kit, Damper, Compression, MAX140, TPC
KF220/
Kit, Bladder only SPV, MAX140
KF223/
Kit, Damper, Compression, MAX140, SPV
KF218/
Kit, Damper, Rebound, MAX140, SPV
PRESSURE SET UP Spring preload RECOMMENDED SAG XC
20-30%
Trail
25-35%
DIAL
© 2009 Cannondale Europe • www.cannondale.com
Lefty Max 140 FFD
HD210/
KF233/
QL679/ KF206/
KF205/
KF225/ KF215/
QL680/
KF234/
HD209/BLK
KF217/
KF219/
22mm 10 Nm, 89 InLbs
2mm
KF222/
KITS KF354/
TOOLS
ITEM NUMBER
DESCRIPTION
KF215/
Kit, Damper, Compression, MAX140, FFD
KF217/
Kit, Damper, Rebound, MAX140, FFD/TPC
KF221/
Kit, Knob, Compression, MAX140, TPC
KF222/
Kit, Boot, Lefty MAX 140
KF219/
Kit, Damper, Control ASSY, MAX140
ITEM NUMBER
DESCRIPTION
KF224/
Kit, Damper, Piston Ring, MAX140-5
QCTL108/
Tool, Lefty Truing Axle
KF225/
Kit, Seal, Max140
KF233/
Kit, KNOB, REBOUND, MAX140
KF234/
Kit, PUSHROD, MAX140
SPRINGS ITEM NUMBER
DESCRIPTION
KF354/
KIT, TACHO MOUNT LEFTY FORKS
KF213/BLK
Kit, Spring, MAX140 FE, XFIRM
HD011/
Kit, Band Clamp Cable Guide (2), Boot Lefty
KF213/BLU
Kit, Spring, MAX140 FE, STD
HD210/
Lefty steerer tube plug
KF213/BRN
Kit, Spring, MAX140 FE, XXFIRM
QSMSEAL/
Upper HeadShok bearing seal
KF213/GRN
Kit, Spring, MAX140 FE, SOFT
HD209/BLK
Air filter hood and filter unit for Lefty, Black
KF213/RED
Kit, Spring, MAX140 FE, FIRM
KF205/
Kit, Split Ring, 2
KF214/BLU
Kit, Spring, MAX140 TI, STD
KF206/
Kit, Collar, Upper, Alloy, Speed110/MAX140
KF214/GRN
Kit, Spring, MAX140 TI, SOFT
QC679/ Kit, Clamp, Upper, MAX
KF214/RED
Kit, Spring, MAX140 TI, FIRM
QC680/ Kit, Clamp, Lower, MAX
© 2009 Cannondale Europe • www.cannondale.com
LEFTY MA x 140 TPC
LEFTY MAX 140 TPC Only Alloy version Specifications ID: black spindle, alloy outer tube, polished clamps, red rebound dial - no screw, blue dial with set screw at bottom (images) Year
2006 + 2007
Travel (mm)
140
Damper
Oil damped
Spring element
Steel coil sprung, “Twin Piston Chamber”
Lockout
No
Rebound
External adjustment
Compatilibities
All stems (not stem/steerer) SPV upgrade possible Kit for 120 travel available
KITS ITEM NUMBER
DESCRIPTION
KF220/
Kit, Bladder only SPV, MAX140
KF223/
Kit, Damper, Compression, MAX140, SPV
KF218/
Kit, Damper, Rebound, MAX140, SPV
PRESSURE SET UP Spring preload RECOMMENDED SAG Trail TPC DIAL
© 2009 Cannondale Europe • www.cannondale.com
25-35% TPC KNOB (BOTTOM)
Lefty Max 140 TPC HD210/
KF233/
QL679/
KF206/
KF205/ KF225/
KF216/
QL680/
22mm 10 Nm, 89 InLbs
HD209/BLK KF234/
KF217/ 2mm
KF219/ 2mm
KF222/
KF221/
KF224/
KF354/
KITS
TOOLS
ITEM NUMBER
DESCRIPTION
KF215/
Kit, Damper, Compression, MAX140, FFD
KF216/
Kit, Damper, Compression, MAX140, TPC
KF217/
Kit, Damper, Rebound, MAX140, FFD/TPC
KF221/
Kit, Knob, Compression, MAX140, TPC
KF222/
Kit, Boot, Lefty MAX 140
KF219/
Kit, Damper, Control ASSY, MAX140
ITEM NUMBER
DESCRIPTION
KF224/
Kit, Damper, Piston Ring, MAX140-5
QCTL108/
Tool, Lefty Truing Axle
KF225/
Kit, Seal, MAX140
KF233/
Kit, KNOB, Rebound, MAX140
KF234/
Kit, Pushrod, MAX140
SPRINGS ITEM NUMBER
DESCRIPTION
KF354/
KIT, Tacho Mount Lefty Forks
KF213/BLK
Kit, Spring, MAX140 FE, XFIRM
HD011/
Kit, Band Clamp Cable Guide (2), Boot Lefty
KF213/BLU
Kit, Spring, MAX140 FE, STD
HD210/
Lefty steerer tube plug
KF213/BRN
Kit, Spring, MAX140 FE, XXFIRM
QSMSEAL/
Upper HeadShok bearing seal
KF213/GRN
Kit, Spring, MAX140 FE, SOFT
HD209/BLK
Air filter hood and filter unit for Lefty, Black
KF213/RED
Kit, Spring, MAX140 FE, FIRM
KF205/
Kit, Split Ring, 2
KF214/BLU
Kit, Spring, MAX140 TI, STD
KF206/
Kit, Collar, Upper, Alloy, Speed110/MAX140
KF214/GRN
Kit, Spring, MAX140 TI, SOFT
QC679/ Kit, Clamp, Upper, MAX
KF214/RED
Kit, Spring, MAX140 TI, FIRM
QC680/ Kit, Clamp, Lower, MAX
© 2009 Cannondale Europe • www.cannondale.com
LEFTY MA x 140 SPV EVoLVE
LEFTY MAX 140 SPV evolve Carbon & Alloy version
(IMAGE SHOWS ALLOY)
Specifications ID: Titanium or steel spindle, threads and large lockring under lock-out dial, forged bonded clamps, carbon outer tube (for carbon version), first gen. has carbon inner tube Year
2006 + 2007
Travel (mm)
140
Damper
Oil damped
Spring element
Ti coil sprung, SPV
Lockout
Adjustable rebound
Rebound
External adjustment
Compatilibities
Alloy: All stems (not stem/steerer) Carbon: All stems and stem/steerer TPC downgrade possible Kit for 120 travel available
KITS ITEM NUMBER
DESCRIPTION
KF215/
Kit, Damper, Compression, MAX140, FFD
KF216/
Kit, Damper, Compression, MAX140, TPC
KF217/
Kit, Damper, Rebound, MAX140, FFD/TPC
RECOMMENDED STARTING AIR PRESSURE Lbs
Kg
Psi
Bar
SPRING
120
54
40
2.8
GREEN
130
59
50
3.4
GREEN
140
64
60
4.1
GREEN
150
68
50
3.4
BLUE
160
73
60
4.1
BLUE
170
77
60
4.1
RED
180
82
60
4.1
RED
190
86
60
4.1
BLACK
200
91
70
4.8
BLACK
210
95
70
4.1
BLACK
220
100
5.5
5.5
BLACK
PRESSURE LIMITS MINIMUM - 45 psi (3.1 bar) MAXIMUM - 120 psi (8.3 bar)
© 2009 Cannondale Europe • www.cannondale.com
RECOMMENDED SAG 25-35%
Lefty Max 140 SPV evolve HD210/
KF233/
QL679/ KF206/
KF218 KF205/ KF225/
QL680/
HD209/BLK
KF224/ KF219/ 4
KF222/
KITS
KF354/
TOOLS
ITEM NUMBER
DESCRIPTION
KF214/RED
Kit, Spring, MAX140 TI, FIRM
KF218/
Kit, Damper, Rebound, MAX140, SPV
KF219/
Kit, Damper, Control ASSY, MAX140
KF220/
Kit, Bladder only SPV, MAX140
KF221/
Kit, Knob, Compression, MAX140, TPC
KF222/
Kit, Boot, Lefty MAX 140
KF223/
Kit, Damper, Compression, MAX140, SPV
ITEM NUMBER
DESCRIPTION
KF224/
Kit, Damper, Piston Ring, MAX140-5
QCTL108/
Tool, Lefty Truing Axle
KF225/
Kit, Seal, Max140
KF233/
Kit, Knob, Rebound, MAX140
KF234/
Kit, Pushrod, MAX140
SPRINGS ITEM NUMBER
DESCRIPTION
KF354/
Kit, Tacho Mount Lefty Forks
KF213/BLK
Kit, Spring, MAX140 FE, XFIRM
HD011/
Kit, Band Clamp Cable Guide (2), Boot Lefty
KF213/BLU
Kit, Spring, MAX140 FE, STD
HD210/
Lefty steerer tube plug
KF213/BRN
Kit, Spring, MAX140 FE, XXFIRM
QSMSEAL/
Upper HeadShok bearing seal
KF213/GRN
Kit, Spring, MAX140 FE, SOFT
HD209/BLK
Air filter hood and filter unit for Lefty, Black
KF213/RED
Kit, Spring, MAX140 FE, FIRM
KF205/
Kit, Split Ring, 2
KF214/BLU
Kit, Spring, MAX140 TI, STD
KF206/
Kit, Collar, Upper, Alloy, Speed110/MAX140
KF214/GRN
Kit, Spring, MAX140 TI, SOFT
QC679/ Kit, Clamp, Upper, MAX
KF214/RED
Kit, Spring, MAX140 TI, FIRM
QC680/ Kit, Clamp, Lower, MAX
© 2009 Cannondale Europe • www.cannondale.com
LEFTY SPEED DLR 110
LEFTY SPEED DLR 110 Specifications ID: Color: black metal, clamps forged - not bonded to outer tube, outer tube alloy, black spindle, red rebound dial - set screw on side metal lockout dial, gold cartridge body Year
2006 + 2007
Travel (mm)
110
Damper
Oil damped
Spring element
Air sprung, coil negative spring
Lockout
On the fly
Rebound
External adjustment
Compatilibities
Cartridge NOT compatible with black SL110!
RECOMMENDED STARTING AIR PRESSURE Lbs
Kg
Psi
Bar
120
54
80
5.5
130
59
85
5.9
140
64
90
6.2
150
68
100
6.9
160
73
105
7.2
170
77
110
7.6
180
82
120
7.3
190
86
125
8.6
200
91
130
9.0
210
95
135
9.3
220
100
145
10.0
PRESSURE LIMITS MINIMUM - 50 psi (3.4 bar) MAXIMUM - 225 psi (15.5 bar) DLR DIAL
© 2009 Cannondale Europe • www.cannondale.com
RECOMMENDED SAG XC 20-30%
LEFTY SPEED DLR 110
KITS ITEM NUMBER
DESCRIPTION
KF202/
Kit, Seal, Speed 110
KF204/
Kit, Shim, Revavling, Speed110/MAX140
KF205/
Kit, Split Ring,2
KF206/
Kit, Collar, Upper, Alloy, Speed110/MAX140 (old style)
KF207/
Kit, Collar, Upper, Carbon, Speed110/MAX140
KF210/
Kit, Lever, Lockout, Speed110 w/nut
KF211/
Kit, Knob, Rebound, Speed 110
KF212/
Kit, Cap, Air Valve, Speed 110
KF213/
Kit, Piston, Air, Speed 110
HD169/
Kit, Bearings, Headset - 2; HeadShok
QHDST/EBO
Headset Cannondale/Coda HeadShok Black
QC678/
Kit, Boot, Lefty MAX /Jake, tailed
HD209/BLK
Air filter hood and filter unit for Lefty, Black only
HD210/
Lefty steerer tube plug
KT040/
Kit, Steerer, X-Long Lefty
HD016/
Steerer, Lefty
QSMSEAL/
Upper HeadShok bearing seal
HD011/
Kit, Band Clamp Cable Guide (2), Boot Lefty
HD205/
Lefty Upper clamp
HD206/
lower crown/steerer, lefty
TOOLS ITEM NUMBER
DESCRIPTION
KT020/
Steerer installation/removal
HDTL168/
1/2 bullet tool
QCTL108/
Tool, Lefty Truing Axle
KH031/
Super castle tool
Rider WT. (lbs) Rider WT. (kg)
Fork size
Bike Size
Neg. Spring
Kits
to 145
65
SOFT
PT/SM
GREEN
KF200/GRN
145-175
65 - 79
STANDARD
MD
BLUE
KF200/BLU
175-195
79 - 88
FIRM
LG
RED
KF200/RED
195 +
88 +
X-FIRM
XL
BLACK
KF200/BLK
© 2009 Cannondale Europe • www.cannondale.com
LEFTY SPEED DLR2 110 CARboN & ALLoY
LEFTY SPEED DLR2 110 Carbon & Alloy version
(IMAGE SHOWS ALLOY)
Specifications ID: Color: gun metal or carbon, clamps bonded, outer tube alloy or carbon, black spindle, red rebound dial, metal lockout dial, gold cartridge body. Year
Alloy Carbon
Travel (mm)
110
Damper
Oil damped
Spring element
Air sprung, coil negative spring
Lockout
On the fly
Rebound
External adjustment
Compatilibities
Fits all HeadShok stems and stem/steeres, Cartridge NOT compatible with SL110!
2006-2008 2006-2007
KITS ITEM NUMBER
DESCRIPTION
KH055/
Kit, Convert, DLRSL&DLR2 - Solo Air
RECOMMENDED STARTING AIR PRESSURE Lbs
Kg
Psi
Bar
120
54
85
5.9
130
59
90
6.2
140
64
100
6.9
150
68
105
7.2
160
73
110
7.6
170
77
115
8.0
180
82
125
8.6
190
86
130
9.0
200
91
140
9.7
210
95
145
10.0
220
100
155
10.7
PRESSURE LIMITS MINIMUM - 50 psi (3.4 bar) MAXIMUM - 225 psi (15.5 bar) DLR2 DIAL
© 2009 Cannondale Europe • www.cannondale.com
RECOMMENDED SAG 20 - 30% (22.0 - 23.0 mm)
LEFTY SPEED DLR2 110 CARBON & ALLOY 2.0 Nm, 18 InLbs KF211/
10 Nm, 89 InLbs Loctite™ 262
9.0 Nm, 80 InLbs
KF210/
Carbon version Alloy version
HD215/ HD011/
KF207/ KF206/
28.0 Nm, 248 InLbs
9.0 Nm, 80 InLbs
KF205/
KF201/*** KF202/ KF204/
HD209/BLK
KF200/***
0.23 Nm, 2.0 InLbs
QC678/ 28.0 Nm, 248 InLbs Loctite™ 242
HD175/BLK HD185/BLK
16mm LEFTYBOLTS
KH057/ KF272/
20.0 Nm, 177 InLbs
KF212/ KF213/
0.33 Nm, 3 InLbs
Rider WT. (lbs) Rider WT. (kg)
Fork size
Bike Size
Neg. Spring
Kits
to 145
65
SOFT
PT/SM
GREEN
KF200/GRN
145-175
65 - 79
STANDARD
MD
BLUE
KF200/BLU
175-195
79 - 88
FIRM
LG
RED
KF200/RED
195 +
88 +
X-FIRM
XL
BLACK
KF200/BLK
© 2009 Cannondale Europe • www.cannondale.com
LEFTY SPEED CARboN Fox TERRA LogIC
LEFTY SPEED
CARBON FOX Terra Logic Specifications ID: Color: carbon w/polished clamps, clamps bonded, outer tube carbon, black spindle, large red rebound dial, small silver cap in center, blue threshold knob at bottom. Year
2006
Travel (mm)
110
Damper
Oil damped
Spring element
Air sprung, float air negative spring
Lockout
Inertia valve lockout
Rebound
External adjustment
Compatilibities
Fits all HeadShok stems and stem/steeres, Cartridge NOT compatible with SL110 or DLR110 RLC 110 upgrade possible
RECOMMENDED STARTING AIR PRESSURE Lbs
Kg
Psi
Bar
140
64
35
2.4
150
68
40
2.8
160
73
45
3.1
170
77
50
3.4
180
82
60
4.1
190
86
70
4.8
PRESSURE LIMITS MINIMUM - 20 psi (1.4 bar) MAXIMUM - 120 psi (8.3 bar) DIAL
© 2009 Cannondale Europe • www.cannondale.com
RECOMMENDED SAG 20 - 30% (22.0 - 23.0 mm)
LEFTY SPEED Car bon FOX Terra Logic
KITS ITEM NUMBER
DESCRIPTION
KF250/
KIT, KNOB, REBOUND, Lefty-FOX Terra Logic IV
KF251/
KIT, SPRING, AIR ON TOP, Lefty-FOX Terra Logic IV
KF252/
Kit, D amper, Lefty-FOX Terra Logic IV
KF253/
Kit, Seal, Air on top, Lefty-FOX Terra Logic IV
HD169/
Kit, Bearings, Headset - 2; HeadShok
QHDST/EBO
Headset Cannondale/Coda HeadShok Black
QC678/
Kit, Boot, Lefty MAX /Jake, tailed
HD209/BLK
Air filter hood and filter unit for Lefty, Black only
HD210/
Lefty steerer tube plug
KT040/
KIT, STEERER, X-LONG LEFTY
HD016/
Steerer, Lefty
QSMSEAL/
Upper HeadShok bearing seal
HD011/
Kit, Band Clamp Cable Guide (2), Boot Lefty
TOOLS ITEM NUMBER
DESCRIPTION
KT020/
Steerer installation/removal
QCTL108/
Tool, Lefty Truing Axle
© 2009 Cannondale Europe • www.cannondale.com
LEFTY SPEED CARboN SL 110
LEFTY SPEED CARBON SL 110 Specifications ID: Blue lockout dial, SL laser etched on black spindle polished clamps - machined flat, black cartidge body. Year
2007-2009
Travel (mm)
110
Damper
Oil damped
Spring element
Air sprung, coil negative spring
Lockout
On the fly
Rebound
External adjustment
Compatilibities
Stems, steering tubes, stem/steeres
KITS ITEM NUMBER
DESCRIPTION
KH055/
Kit, Convert, DLRSL&DLR2 – Solo Air
RECOMMENDED STARTING AIR PRESSURE Lbs
Kg
Psi
Bar
120 130
54
80
5.5
59
85
5.9
140 150
64
90
6.2
68
100
6.9
160
73
105
7.2
170
77
110
7.6
180
82
120
7.3
190
86
125
8.6
200
91
130
9.0
210
95
135
9.3
220
100
145
10.0
PRESSURE LIMITS MINIMUM - 50 psi (3.4 bar) MAXIMUM - 225 psi (15.5 bar) DIAL
© 2009 Cannondale Europe • www.cannondale.com
RECOMMENDED SAG 20 - 30% = (22.0 - 23.0 mm)
Lefty Speed Car bon SL 110 2 Nm, 18 InLbs KF211/
KT031/
Apply NL GI-2 Synthetic grease to items marked
HD215/
KT027/ 28 Nm 248 InLbs HD011/
KT028/ 20Nm, 177 InLbs
KF205/
HD209/
KH055/ 29’er Travel reduction spacers 3 x 10 mm
QC678/
HO175/BLK HO185/BLK
KH026/
KITS ITEM NUMBER
DESCRIPTION
KT026/GRN
KIT, DAMPER LEFTY DLRSL (remove volume compensator)
KT026/BLU
KIT, DAMPER LEFTY DLRSL (remove volume compensator)
KT026/RED
KIT, DAMPER LEFTY DLRSL (remove volume compensator)
KT026/BLK
KIT, DAMPER LEFTY DLRSL (remove volume compensator)
KT213
KIT, AIR PISTON
Rider WT. (lbs) Rider WT. (kg)
Fork size
Bike Size
Neg. Spring
Kits
to 145
65
SOFT
PT/SM
GREEN
KT025/GRN
145-175
65 - 79
STANDARD
MD
BLUE
KT025/BLU
175-195
79 - 88
FIRM
LG
RED
KT025/RED
195 +
88 +
X-FIRM
XL
BLACK
KT025/BLK
© 2009 Cannondale Europe • www.cannondale.com
LEFTY SPEED CARboN SL2 110 (SoLo AIR)
LEFTY SPEED SL2 CARBON 110 (Solo Air) Specifications ID: Blue lockout dial, red rebound dial with set screw on side, polished clamps - machined flat, OPI laser etched on black spindle. Year
2009 +
Travel (mm)
110
Damper
Oil damped
Spring element
Air sprung, SOLO AIR self adjusting negative spring
Lockout
On the fly
Rebound
External adjustment
Compatilibities
Stems, steering tubes, Stem/steerer
RECOMMENDED STARTING AIR PRESSURE Lbs
Kg
Psi
Bar
120
54
85
5.9
130
59
90
6.2
140
64
100
6.9
150
68
105
7.2
160
73
110
7.6
170
77
115
8.0
180
82
125
8.6
190
86
130
9.0
200
91
140
9.7
210
95
145
10.0
220
100
155
10.7
PRESSURE LIMITS MINIMUM - 50 psi (3.4 bar) MAXIMUM - 225 psi (15.5 bar) DIAL
© 2009 Cannondale Europe • www.cannondale.com
RECOMMENDED SAG 20 - 30% = (22.0 - 23.0 mm)
OPI SPINDLE
Lefty Speed Car bon SL2 110 (Solo Air) 2 Nm, 18 InLbs KF211/
KT031/
Apply NL GI-2 Synthetic grease to items marked
HD215/
KT027/ 28 Nm 248 InLbs HD011/
KT028/ 20Nm, 177 InLbs
KF205/
KH055/ 29’er Travel reduction spacers 3 x 10 mm
HD209/
QC678/
KH026/
HO175/BLK HO185/BLK
* DRAWING DOES NOT SHOW OPI SPINDLE
KITS ITEM NUMBER
DESCRIPTION
KH052/
Kit, Air Piston, DLR SL, Solo Air
KT024/
Kit, Seals, DLR SL
KT051
Kit, Damper, Lefty DLR SL, Solo
© 2009 Cannondale Europe • www.cannondale.com
LEFTY MAx CARboN Fox RLC 130
LEFTY MAX CARBON FOX RLC 130 Specifications ID: Red rebound dial with allen screw in center, 2nd blue adjust wheel under lockout dial. Year
2008-2009 +
Travel (mm)
130
Damper
Oil damped
Spring element
Ti coil spring, Adjustable low-speed comp
Lockout
Yes, Adjustable lock-out threshold
Rebound
External Adjustment
Compatilibities
Stems, steering tubes, Stem/steerer
KITS ITEM NUMBER
DESCRIPTION
KH041/
Lefty PBR Damper
RECOMMENDED SAG B
A
B - A = SAG (mm) Measure the length of the fork as shown below – this as measurement A. With the help of a second person, seat the rider on the saddle with feet on pedals and hands on the handlebar. Again measure the length of the fork - this as measurement B.
SAG
To calculate sag subtract B from A . The recommended sag measurement (in millimeters) as a percentage of your forks total travel, should fall within the guidelines listed in the attached chart. To increase sag, release air. To decrease sag, add air.
RECOMMENDED SAG Trail DIAL
© 2009 Cannondale Europe • www.cannondale.com
25-35%
LEFTY MAX CARBON FOX RLC 130
SUPPLIED BY FOX
KH015/
KH025/
HD209/BLK
KH032/ 033/ 034/ 035/
KF222/
KITS
KH014/
ITEM NUMBER
DESCRIPTION
KH032/
Spring, soft, ti
KH033/
Spring, standard, ti
KH034/
Spring, firm, ti
KH035/
Spring, x-firm, ti
KH025/
FOX RLC preload tube
KH011/
FOX RLC upgrade kit
KH012/
FOX RLC seal kit
KH028/
FOX RLC rebound shaft
KH015/
FOX RLC compression damper
KH029/
FOX RLC seal head
KH026/
FOX RLC compression clamp
KH027/
FOX RLC retaining ring
KF205/
Split rings 2
KH016/
FOX RLC outer collar
HD169/
Kit, Bearings, Headset - 2; HeadShok
QHDST/EBO
Headset Cannondale/Coda HeadShok black
HD209/BLK
Air filter hood and filter unit for Lefty, Black only
HD210/
Lefty steerer tube plug
8A502/BLK
Frame protection bumper
KF354/
Kit, Tacho Mount Lefty Forks
KT040/
Kit, Steerer, X-Long Lefty
KF222/
Kit, Boot, Lefty MAX 140 © 2009 Cannondale Europe • www.cannondale.com
LEFTY MAx CARboN 130 Pb R
LEFTY MAX 130 PBR Carbon & Alloy version Specifications ID: Large red rebound dial w/ small blue lockout relase button, air valve at bottom, small blue lockout push button inside rebound dial, carbon outer tube. Year
2008-2009 +
Travel (mm)
130
Damper
Oil damped
Spring element
Air sprung, Solo Air self adjusting negative spring
Lockout
Adjustable lock-out threshold
Rebound
External Adjustment
Compatilibities
Stems, steering tubes
KITS ITEM NUMBER
DESCRIPTION
KH017/
Fox RLC 130 mm rebound damper
KH011/
Fox RLC upgrade kit
RECOMMENDED STARTING AIR PRESSURE Lbs
Kg
Psi
Bar
120
54
85
5.8
130
59
90
6.2
140
64
95
6.5
150
68
105
7.2
160
73
120
8.2
170
77
135
9.3
180
82
150
10.3
190
86
165
11.3
200
91
180
12.4
210
95
195
13.4
220
100
205
14.1
PRESSURE LIMITS MINIMUM - 50 psi (3.4 bar) MAXIMUM - 225 psi (15.5 bar) KH045/ PBR DIAL Carbon version
© 2009 Cannondale Europe • www.cannondale.com
RECOMMENDED SAG 25 - 30% = (32.5 - 39.0 mm)
KH046/ PBR DIAL Alloy version
LEFTY MAX CARBON 130 PBR 0.5 Nm, 4.4 InLbs Loctite™ 222
KH044/ 9.0 Nm, 80 InLbs
KH045/ KH046/
28.0 Nm, 248 InLbs HD215/ HD011/ 9.0 Nm, 80 InLbs
KF205/
KH042/ HD226/
HD209/BLK
KF222/
0.23 Nm, 2.0 InLbs
Loctite™ 401
28.0 Nm, 248 InLbs Loctite™ 242
KH061/ KH043/
HD175/BLK
16mm LEFTY BOLTS
KH057/ 3.4 Nm, 30 InLbs Loctite™ 242
20.0 Nm, 177 InLbs
KT028/
0.33 Nm, 3 InLbs
KITS ITEM NUMBER
DESCRIPTION
KH041/
Kit, Damper, Lefty PBR 130
KH042/
Kit, Seals, PBR 130 © 2009 Cannondale Europe • www.cannondale.com
FATTY ULTRA DL 70 Specifications ID: Tapered alloy inner steerer at crown junction, black top cap, silver hex nut, can have canti mount - disc mount or both, Year
2000-2003
Travel (mm)
70
Damper
Oil damped, cartridge
Spring element
Air sprung, coil negative spring
Lockout
Button On/Off
KITS ITEM NUMBER
DESCRIPTION
HDUPDD60/
Cartridge Kit, DD60 upgrade
HD110/BLU
Spring Kit,DD60/MC60, medium
HD110/GRE
Spring Kit,DD60/MC60, soft
HD110/RED
Spring Kit,DD60/MC60, stiff
RECOMMENDED SAG B - A = SAG (mm) Measure the length of the fork as shown below – this as measurement A. B
A
With the help of a second person, seat the rider on the saddle with feet on pedals and hands on the handlebar. Again measure the length of the fork - this as measurement B.
SAG
To calculate sag subtract B from A . The recommended sag measurement (in millimeters) as a percentage of your forks total travel, should fall within the guidelines listed in the attached chart. To increase sag, release air. To decrease sag, add air.
PRESSURE LIMITS MINIMUM - 45 psi (3.1 bar) MAXIMUM - 120 psi (8.3 bar) DIAL
© 2009 Cannondale Europe • www.cannondale.com
RECOMMENDED SAG 10-20% = 8mm
FATTY ULTRA DL 70
KITS ITEM NUMBER
DESCRIPTION
HD181/
DL 70 oil cartridge unit
HD183/
FT70/DL70 air cartridge
HDUPDL/70
Cartridge kit, DL70 upgrade
HD312/
Kit, Piston, DD60 w/ Seals & Shims
HD313/
Kit, lockout shims/seals DL Cartridge
HD314/
Kit, 5 X negative spring Green DL70
QHDST/EBO
Headset Cannondale/Coda HeadShok Black
HD169/
Kit, Bearings, Headset - 2 / HeadShok
HD191/BLK
Slim Boot, 5-rib, Black
HD191/YEL
Slim Boot, 5-rib, Yellow
HD213/
Lock-Out lever
TOOLS ITEM NUMBER
DESCRIPTION
HD136/
Tool, HeadShok outer cap pin
HDTL149/
Tool, HeadShok fork installation
HDTL168/
Tool, bullet, Lefty and Fatty 12.7 mm
KT016/
Tool, HEADSHOK Bearing Reset
KT020/
Kit, Lefty Steerer install (also for Fattys)
KH031/
Super Castle Tool
© 2009 Cannondale Europe • www.cannondale.com
SUPER FATTY M 80
SUPER FATTY M 80 Specifications ID: Tapered alloy inner steerer at crown junction, black top cap, can have canti mount - disc mount or both, Year
1999-2005
Travel (mm)
80
Damper
Mechanical damper/Friction
Spring element
Coil sprung
Lockout
No
Rebound
No
KITS ITEM NUMBER
DESCRIPTION
HDUPDL/80
Cartridge Kit, DL80 upgrade
HD182/
DL80 Oil cartridge unit – Formerly DD80 Oil Cartridge
HD184/
FT80/DL80 Air cartridge
RECOMMENDED SAG B - A = SAG (mm) Measure the length of the fork as shown below – this as measurement A. B
A
With the help of a second person, seat the rider on the saddle with feet on pedals and hands on the handlebar. Again measure the length of the fork - this as measurement B.
SAG
To calculate sag subtract B from A .
PRESSURE SET UP Spring preload DIAL/TOP CAP
© 2009 Cannondale Europe • www.cannondale.com
The recommended sag measurement (in millimeters) as a percentage of your forks total travel, should fall within the guidelines listed in the attached chart. To increase sag, release air. To decrease sag, add air.
SUPER FATTY M 80
KITS ITEM NUMBER
DESCRIPTION
QHDST/EBO
Headset Cannondale/Coda HeadShok Black
HD169/
Kit, Bearings, Headset - 2/ HeadShok
HD191/BLK
Slim Boot, 5-rib, Black
HD191/YEL
Slim Boot, 5-rib, Yellow
HD213/
Lockout lever
HD155/BLU
Spring Kit, MC80, Medium
HD155/GRE
Spring Kit, MC80, Light
HD155/RED
Spring Kit, MC80, Stiff
TOOLS ITEM NUMBER
DESCRIPTION
HD136/
Tool, HeadShok outer cap pin
HDTL149/
Tool, HeadShok fork installation
KT016/
Tool, HeadShok bearing reset
KT020/
Kit, Lefty Steerer install (also for Fattys)
KH031/
Super castle tool
© 2009 Cannondale Europe • www.cannondale.com
SUPER FATTY D & DL
SUPER FATTY D & DL Specifications ID: Shorter air valve end (ca. 8,5mm), 4 pin spanner holes under lockout dial, tapered inner tube down to crown. Year
2001-2003
Travel (mm)
80
Damper
Oil damped
Spring element
Air sprung, coil negative spring
Lockout
On the fly
Rebound
No
KITS ITEM NUMBER
DESCRIPTION
HDUPDL/80
Cartridge Kit, DL80 upgrade
HD182/
DL80 Oil cartridge unit – Formerly DD80 Oil Cartridge
HD184/
FT80/DL80 Air cartridge
RECOMMENDED SAG B - A = SAG (mm) Measure the length of the fork as shown below – this as measurement A. B
A
With the help of a second person, seat the rider on the saddle with feet on pedals and hands on the handlebar. Again measure the length of the fork - this as measurement B.
SAG
To calculate sag subtract B from A .
DIAL
© 2009 Cannondale Europe • www.cannondale.com
The recommended sag measurement (in millimeters) as a percentage of your forks total travel, should fall within the guidelines listed in the attached chart. To increase sag, release air. To decrease sag, add air.
SUPER FATTY D & DL
KITS ITEM NUMBER
DESCRIPTION
QHDST/EBO
Headset Cannondale/Coda HeadShok Black
HD169/
Kit, Bearings, Headset - 2; HeadShok
HD191/BLK
Slim Boot, 5-rib, Black
HD191/YEL
Slim Boot, 5-rib, Yellow
HD213/
lockout lever
HDUPDL/80
CARTRIDGE KIT, DL80 UPGRADE
HD182/
DL80 Oil Cartridge Unit – Formerly DD80 Oil Cartridge
HD184/
FT80/DL80 Air Cartridge
HD166/
Seal Kit
HD212
Negative Spring
TOOLS ITEM NUMBER
DESCRIPTION
HD136/
Tool, HeadShok outer cap pin
HDTL149/
Tool, HeadShok fork installation
KT016/
Tool, HeadShok bearing reset
KT020/
Kit, Lefty Steerer install (also for Fattys)
KH031/
Super castle tool
HDTL168/
Bullet tool
© 2009 Cannondale Europe • www.cannondale.com
SUPER FATTY ULTRA DL (INCH THREAD)
SUPER FATTY ULTRA DL
(Inch thread)
Specifications ID: Shorter air valve end (ca. 8,5mm), 4 pin spanner holes under lockout dial, square inner tube down to crown. Year
2001-2003
Travel (mm)
80
Damper
Oil damped
Spring element
Air sprung, coil negative spring
Lockout
On the fly
Rebound
No
KITS ITEM NUMBER
DESCRIPTION
HD155/BLU
Spring Kit, MC80, Medium
HD155/GRE
Spring Kit, MC80, Light
HD155/RED
Spring Kit, MC80, Stiff
RECOMMENDED STARTING AIR PRESSURE Lbs
Kg
Psi
Bar
120 - 150
68
95
6.6
160
73
110
7.6
170
77
120
8.3
180
82
130
9.0
190
86
135
9.3
200
91
140
9.7
210
95
145
10.0
220
100
150
10.3
PRESSURE LIMITS MINIMUM - 70 psi (4.8 bar) MAXIMUM - 200 psi (13.8 bar) DIAL
© 2009 Cannondale Europe • www.cannondale.com
RECOMMENDED SAG 10-20% = 8 mm
VALVE
SUPER FATTY ULTRA DL (INCH THREAD) HD169/
HD213/BLK
20.0 Nm, 177 InLbs
27.0 Nm, 240 InLbs Loctite™ 242
HD191/BLK HD191/YEL
HD182/
HD171/
KF212/
KITS ITEM NUMBER
DESCRIPTION
QHDST/EBO
Headset Cannondale/Coda HeadShok Black
HD169/
Kit, Bearings, Headset - 2; HeadShok
HD191/BLK
Slim Boot, 5-rib, Black
HD191/YEL
Slim Boot, 5-rib, Yellow
HD213/
lockout lever
HDUPDL/80
CARTRIDGE KIT, DL80 UPGRADE
HD182/
DL80 Oil Cartridge Unit – Formerly DD80 Oil Cartridge
HD184/
FT80/DL80 Air Cartridge
TOOLS ITEM NUMBER
DESCRIPTION
HD136/
Tool, HeadShok outer cap pin
HDTL149/
Tool, HeadShok fork installation
KT016/
Tool, HeadShok bearing reset
KT020/
Kit, Lefty Steerer install (also for Fattys)
KH031/
Super castle tool
HDTL168/
Bullet tool
© 2009 Cannondale Europe • www.cannondale.com
SUPER FATTY ULTRA DLR MA gURA (INCH THREAD)
SUPER FATTY ULTRA DLR Magura Specifications ID: 13 mm higher outer tube (visual extension), hex nut for lock-out dial 15mm, red rebound dial with allen bolt in center, yellow/green cartridge body Year
2005 (2006 with metric thread)
Travel (mm)
80
Damper
Oil damped
Spring element
Air sprung, coil negative spring
Lockout
On the fly
Rebound
External adjustment
RECOMMENDED STARTING AIR PRESSURE Lbs
Kg
Psi
Bar
120
54
50
3.4
130
59
55
3.8
140
64
60
4.1
150
68
65
4.5
160
73
70
4.8
170
77
75
5.2
180
82
80
5.5
190
86
90
6.2
200
91
100
7.2
PRESSURE LIMITS MINIMUM - 45 psi (3.1 bar) MAXIMUM - 120 psi (8.3 bar) DIAL
© 2009 Cannondale Europe • www.cannondale.com
RECOMMENDED SAG 10-20% = 8 mm
INCH THREAD CARTRIDGE
SUPER FATTY ULTRA DLR Magura (INCH THREAD) KF229/
HD169/
KF228/
13mm Extension
HD191/BLK
KF226/ KF247/
KF232/
HD171/ KF230/ KF231/ KF245/ KF246/ HD170/
TOOLS ITEM NUMBER
DESCRIPTION
HDTL149/
Tool, HeadShok Fork Installation
KT016/
Tool, HeadShok Bearing Reset
HDTL187/
Shaft Clamp Tool for Lefty and DL70
KT020/
Kit, Lefty Steerer install (also for Fattys)
KH031/
Super castle tool
KITS ITEM NUMBER
DESCRIPTION
KF235/
Upgrade kit, Damper, BLUE DL80
KF263/
Upgrade kit, Damper, RED DLR80, SOFT
KF264/
Upgrade kit, Damper, RED DLR80, STD
KF265/
Upgrade kit, Damper, RED DLR80, FIRM
KH005/
Kit, Air cylinder including Negative springs
HDUPDL/80
Cartridge kit, DL80 upgrade
© 2009 Cannondale Europe • www.cannondale.com
SUPER FATTY ULTRA DLR MA gURA (METRIC THREAD)
SUPER FATTY ULTRA DLR Magura Specifications ID: Metric thread, 13 mm higher outer tube (visual extension), hex nut for lockout dial 15mm, red rebound dial with allen bolt in center, yellow/green cartridge body (cartridge Body has small groove above thread) Year
2006 with metric thread
Travel (mm)
80
Damper
Oil damped
Spring element
Air sprung, coil negative spring
Lockout
On the fly
Rebound
External adjustment
RECOMMENDED STARTING AIR PRESSURE Lbs
Kg
Psi
Bar
120
54
50
3.4
130
59
55
3.8
140
64
60
4.1
150
68
65
4.5
160
73
70
4.8
170
77
75
5.2
180
82
80
5.5
190
86
90
6.2
200
91
100
7.2
PRESSURE LIMITS MINIMUM - 45 psi (3.1 bar) MAXIMUM - 120 psi (8.3 bar) DIAL
© 2009 Cannondale Europe • www.cannondale.com
RECOMMENDED SAG 10-20% = 8 mm
METRIC THREAD CARTRIDGE
SUPER FATTY ULTRA DLR Magura (metric THREAD) KF229/
HD169/
KF228/
13mm Extension
HD191/BLK KF247/
KF232/
HD171/ KF230/ KF231/ KF245/ KF246/ HD170/
TOOLS ITEM NUMBER
DESCRIPTION
HDTL149/
Tool, HeadShok Fork Installation
KT016/
Tool, HeadShok Bearing Reset
HDTL187/
Shaft Clamp Tool for Lefty and DL70
KT020/
Kit, Lefty Steerer install (also for Fattys)
KH031/
Super castle tool
KITS ITEM NUMBER
DESCRIPTION
KF235/
Upgrade kit, Damper, BLUE DL80
KF263/
Upgrade kit, Damper, RED DLR80, SOFT
KF264/
Upgrade kit, Damper, RED DLR80, STD
KF265/
Upgrade kit, Damper, RED DLR80, FIRM
KH005/
Kit, Air cylinder including Negative springs
© 2009 Cannondale Europe • www.cannondale.com
SUPER FATTY ULTRA DL (METRIC THREAD)
SUPER FATTY ULTRA DL
(Metric thread)
Specifications ID: Metric thread, silver top cap under lockout dial, 2-pin spanner holes, longer valve end (10,6mm) Year
2005-2009
Travel (mm)
80
Damper
Oil damped
Spring element
Air sprung, coil negative spring
Lockout
On the fly
Rebound
No
KITS ITEM NUMBER
DESCRIPTION
KF263/
Kit, Damper, RED DLR80, SOFT - Upgrade possible
KF264/
Kit, Damper, RED DLR80, STD - Upgrade possible
KF265/
Kit, Damper, RED DLR80, FIRM - Upgrade possible
KH005/
Kit, Air cylinder including Negative springs
RECOMMENDED STARTING AIR PRESSURE Lbs
Kg
Psi
Bar
120 - 150
68
50
3.4
160
73
60
4.1
170
77
70
4.8
180
82
80
5.5
190
86
90
6.2
200
91
100
6.9
210
95
105
7.2
220
100
110
7.6
PRESSURE LIMITS MINIMUM - 40 psi (2.8 bar) MAXIMUM - 120 psi (8.3 bar) DIAL
© 2009 Cannondale Europe • www.cannondale.com
RECOMMENDED SAG 10-20% = 8 mm
VALVE
SUPER FATTY ULTRA DL (METRIC THREAD)
HD213/BLK
HD169/
20.0 Nm, 177 InLbs
27.0 Nm, 240 InLbs Loctite™ 242
KF235/ KF236/
HD191/BLK
KH005/
HD171/ KF238/ KF237/
KP067/
KITS HD170/
ITEM NUMBER
DESCRIPTION
KF235/
Kit, Damper, BLUE DL80
KF236/
Kit, Seal, BLUE DL80+05 DL50
KF237/
Kit, Schrader Plug, BLUE DL80, including Valve & Cap
KF238/
Kit, Air Piston, BLUE DL80, including Spring and holder
HD169/
Kit, Bearings, Headset - 2/ HeadShok
QHDST/EBO
Headset Cannondale/Coda HeadShok Black
HD191/BLK
Slim Boot, 5-rib, Black
HD191/YEL
Slim Boot, 5-rib, Yellow
KP067/
Air piston quad seal, bag of 10
HD213/BLK
Lockout lever
TOOLS ITEM NUMBER
DESCRIPTION
HD136/
Tool, HeadShok outer cap pin
HDTL149/
Tool, HeadShok fork installation
HDTL168/
TOOL, Bullet, Lefty and Fatty 12.7 mm
KT016/
Tool, HeadShok bearing reset
KH031
Super castle tool
KT020/
Kit, Lefty Steerer install (also for Fattys)
© 2009 Cannondale Europe • www.cannondale.com
SUPER FATTY ULTRA DLR (METRIC THREAD)
SUPER FATTY ULTRA DLR Specifications ID: Metric thread, long valve end, same lockout dial as Speed DLR, red rebound dial with set screw on side, conical top cap Year
2006 +
Travel (mm)
80
Damper
Oil damped/Cartridge
Spring element
Air sprung, coil negative spring
Lockout
On the fly
Rebound
External adjustment
RECOMMENDED STARTING AIR PRESSURE Lbs
Kg
Bar
120
54
50
3.4
130
59
55
3.8
140
64
60
4.1
150
68
65
4.5
160
73
70
4.8
170
77
75
5.2
180
82
80
5.5
190
86
90
6.2
200
91
100
7.2
PRESSURE LIMITS MINIMUM - 45 psi (3.1 bar) MAXIMUM - 120 psi (8.3 bar) DLR DIAL
© 2009 Cannondale Europe • www.cannondale.com
Psi
RECOMMENDED SAG 10-20% = 8 mm
SUPER FATTY ULTRA DLR (METRIC THREAD)
KF211/
HD169/
KF210/
KH005/
KF266/
HD191/BLK KF263/ KF264/ KF265/ KF236/ KH022/
HD171/
KF237/ KF267/
HD170/ KP067/
KITS ITEM NUMBER
DESCRIPTION
KF235/
Kit, Damper, BLUE DL80
KF236/
Kit, Seal, BLUE DL80+05 DL50
KF237/
Kit, Schrader Plug, BLUE DL80, including Valve & Cap
KF238/
Kit, Air Piston, BLUE DL80, including Spring and holder
HD169/
Kit, Bearings, Headset - 2/ HeadShok
QHDST/EBO
Headset Cannondale/Coda HeadShok Black
HD191/BLK
Slim Boot, 5-rib, Black
HD191/YEL
Slim Boot, 5-rib, Yellow
KP067/
Air piston quad seal, bag of 10
HD213/BLK
Lockout lever
© 2009 Cannondale Europe • www.cannondale.com
LEFTY DLR 100 STEEL
LEFTY DLR 100 Steel
Specifications ID: Welded steel spindle, no threads under lockout dial, machined clamps, not bonded Year
2000
Travel (mm)
100
Damper
Oil damped
Spring element
Air sprung, coil negative spring
Lockout
On the fly
Rebound
External adjustment
Compatilibities
All HeadShok Stems cartridge and aircylinder not compatible with 2001+ parts
RECOMMENDED SAG B
A
B - A = SAG (mm) Measure the length of the fork as shown below – this as measurement A. With the help of a second person, seat the rider on the saddle with feet on pedals and hands on the handlebar. Again measure the length of the fork - this as measurement B.
SAG
To calculate sag subtract B from A . The recommended sag measurement (in millimeters) as a percentage of your forks total travel, should fall within the guidelines listed in the attached chart. To increase sag, release air. To decrease sag, add air.
RECOMMENDED SAG XC DIAL
© 2009 Cannondale Europe • www.cannondale.com
20-30%
Lefty DLR 100 Steel
KITS ITEM NUMBER
DESCRIPTION
HD201/
Lefty DLR '00 Dial Holder Plug For Lockout/Damping ADJ
HD202/BLU
Lefty DLR '00 Oil Damper Cartridge, MEDIUM
HD202/GRN
Lefty DLR '00 Oil Damper Cartridge, SOFT
HD202/RED
Lefty DLR '00 Oil Damper Cartridge, HARD
HD203/
Lefty DLR '00 Air Cylinder and Air Piston
HD211/
Lefty DLR '00 Air Cylinder Saddle
HD214/
Lefty DLR '00 Damping Adjuster Knob
HD212/
Negative Spring KIT for Lefty 100 Oil Cart
HD212/WHT
Kit, Spring - Negative, Lefty, X-firm
HD011/
Kit, Band Clamp Cable Guide (2), Boot Lefty
HD205/
Lefty Upper clamp
HD206/
Lower crown/steerer, Lefty 100
TOOLS ITEM NUMBER
DESCRIPTION
HDTL200/
Tool, HeadShok Lefty cart castles '00 only
KT020/
Steerer instalation/removal
HDTL168/
1/2 bullet tool
HD187/
1/2 inch shaft clamps
QCTL108/
Tool, Lefty truing axle
KT016/
Tool, HeadShok Bearing Reset
© 2009 Cannondale Europe • www.cannondale.com
LEFTY DLR 100 (STEEL oR TITANIUM)
LEFTY DLR 100 Steel or Titanium Specifications ID: Titanium or steel spindel, threads and large lockring under lockout dial, forged clamps – not bonded Year
2000-2004
Travel (mm)
100
Damper
Oil damped
Spring element
Air sprung, coil negative spring
Lockout
On the fly
Rebound
External adjustment
Compatilibities
All HeadShok Stems Cartridge and aircylinder Not compatible with 2000 parts
RECOMMENDED SAG B
A
B - A = SAG (mm) Measure the length of the fork as shown below – this as measurement A. With the help of a second person, seat the rider on the saddle with feet on pedals and hands on the handlebar. Again measure the length of the fork - this as measurement B.
SAG
To calculate sag subtract B from A . The recommended sag measurement (in millimeters) as a percentage of your forks total travel, should fall within the guidelines listed in the attached chart. To increase sag, release air. To decrease sag, add air.
RECOMMENDED SAG XC DIAL
© 2009 Cannondale Europe • www.cannondale.com
20-30%
Lefty DLR 100 (Steel or titanium)
KITS ITEM NUMBER
DESCRIPTION
HD166/
KIT All Seals, FT, DL and Lefty 100 cartridges
HD001/
Kit, '01 DLR Dial holder/plug
HD002/
Kit, Air cylinder for '01 DLR
HD022/
Kit, Damp Adjust Knob-2nd. Lefty '01->
HD023/
Kit, 2001 DLR Damper - SM
HD026/
Kit, Perch-DL70/80, DLR 100
HD212/
Negative Spring Kit for Lefty 100 Oil Cart
HD212/WHT
Kit, Spring - Negative, Lefty, X-firm
HD011/
Kit, Band Clamp Cable Guide (2), Boot Lefty
HD205/
Lefty Upper clamp
HD206/
lower crown/steerer, Lefty 100
KT040/
Kit, Steerer, X-Long Lefty
HD016/
Steerer, Lefty
TOOLS ITEM NUMBER
DESCRIPTION
KT006/
Tool , lower cartridge Cap remover
KT020/
Steerer installation/removal
HDTL168/
1/2 bullet tool
HD187/
1/2 inch shaft clamps
KT004/
Tool, Lefty DLR/ELO Kidney tool '01 and +
QCTL108/
Tool, Lefty Truing Axle
KT016/
Tool, HeadShok Bearing Reset
© 2009 Cannondale Europe • www.cannondale.com
LEFTY CARboN ELo oR DL R 100
LEFTY CARBON DLR 100 Forged Steel or Titanium ELO or DLR Specifications ID: Titanium or steel spindle, threads and large lockring under lock-out dial, forged bonded clamps, carbon outer tube, first gen. has carbon inner tube Year
2001-2004
Travel (mm)
100
Damper
Oil damped
Spring element
Air sprung, coil negative spring
Lockout
On the fly or ELO (electronic lockout)
Rebound
External adjustment
Compatilibities
Cartridge and aircylinder not compatible with 2000 parts, fits Stem/steerer, (carbon) SL steeringtube and extra long steeringtube.
RECOMMENDED SAG B
A
B - A = SAG (mm) Measure the length of the fork as shown below – this as measurement A. With the help of a second person, seat the rider on the saddle with feet on pedals and hands on the handlebar. Again measure the length of the fork - this as measurement B.
SAG
To calculate sag subtract B from A . The recommended sag measurement (in millimeters) as a percentage of your forks total travel, should fall within the guidelines listed in the attached chart. To increase sag, release air. To decrease sag, add air.
RECOMMENDED SAG XC ELO DIAL
© 2009 Cannondale Europe • www.cannondale.com
20-30% DLR DIAL
Lefty Carbon ELO or DLR 100 HD003/
HD301/
KITS
HD002/
HD004/
ITEM NUMBER
DESCRIPTION
HD166/
KIT All Seals, FT, DL and Lefty 100 cartridges
HD001/
Kit, '01 DLR Dial holder/plug
HD002/
Kit, Air cylinder for '01 DLR
HD022/
Kit, Damp Adjust Knob-2nd. Lefty '01->
HD023/
Kit, 2001 DLR Damper - SM
HD026/
Kit, Perch-DL70/80, DLR 100
HD212/
Negative Spring Kit for Lefty 100 Oil Cart
HD212/WHT
Kit, Spring - Negative, Lefty, X-firm
HD011/
Kit, Band Clamp Cable Guide (2), Boot Lefty
HD205/
Lefty Upper clamp
HD206/
lower crown/steerer, Lefty 100
KT040/
Kit, Steerer, X-Long Lefty
HD016/
Steerer, Lefty
HD300/
Kit, Battery – ELO Li-Ion high power
HD301/
Kit, Elec. Cont. Unit - ELO
HD003/
Collar, Upper Carbon Lefty
HD004/
Collar, Lower, Lefty Carbon gold
HD005/
Kit, Air Cylinder Saddle-2002 Full Carbon Lefty
HD027/
Kit, Perch -Carbon ELO
HD010/
Kit, Spacers-Lefty Travel Reducers
TOOLS
HD205/
ITEM NUMBER
DESCRIPTION
KT006/
Tool , lower cartridge Cap remover
KT020/
Steerer installation/removal
HDTL168/
1/2 bullet tool
HD187/
1/2 inch shaft clamps
KT004/
Tool, Lefty DLR/ELO Kidney tool '01 and +
QCTL108/
Tool, Lefty Truing Axle
KT016/
Tool, HeadShok Bearing Reset
© 2009 Cannondale Europe • www.cannondale.com
LEFTY MA x 140 FFD
LEFTY MAX 140 FFD (Fluid Flow Damping) Only Alloy version Specifications ID: Black spindle, alloy outer tube, polished clamps, red rebound dial - no screw, bottom (images) Year
2006 + 2007
Travel (mm)
140
Damper
Oil damped
Spring element
Steel coil sprung, “Fluid Flow Damping”
Lockout
No
Rebound
External adjustment
Compatilibities
All stems (not stem/steerer) TPC + SPV upgrade possible
KITS ITEM NUMBER
DESCRIPTION
KF216/
Kit, Damper, Compression, MAX140, TPC
KF220/
Kit, Bladder only SPV, MAX140
KF223/
Kit, Damper, Compression, MAX140, SPV
KF218/
Kit, Damper, Rebound, MAX140, SPV
PRESSURE SET UP Spring preload RECOMMENDED SAG XC
20-30%
Trail
25-35%
DIAL
© 2009 Cannondale Europe • www.cannondale.com
Lefty Max 140 FFD
HD210/
KF233/
QL679/ KF206/
KF205/
KF225/ KF215/
QL680/
KF234/
HD209/BLK
KF217/
KF219/
22mm 10 Nm, 89 InLbs
2mm
KF222/
KITS KF354/
TOOLS
ITEM NUMBER
DESCRIPTION
KF215/
Kit, Damper, Compression, MAX140, FFD
KF217/
Kit, Damper, Rebound, MAX140, FFD/TPC
KF221/
Kit, Knob, Compression, MAX140, TPC
KF222/
Kit, Boot, Lefty MAX 140
KF219/
Kit, Damper, Control ASSY, MAX140
ITEM NUMBER
DESCRIPTION
KF224/
Kit, Damper, Piston Ring, MAX140-5
QCTL108/
Tool, Lefty Truing Axle
KF225/
Kit, Seal, Max140
KF233/
Kit, KNOB, REBOUND, MAX140
KF234/
Kit, PUSHROD, MAX140
SPRINGS ITEM NUMBER
DESCRIPTION
KF354/
KIT, TACHO MOUNT LEFTY FORKS
KF213/BLK
Kit, Spring, MAX140 FE, XFIRM
HD011/
Kit, Band Clamp Cable Guide (2), Boot Lefty
KF213/BLU
Kit, Spring, MAX140 FE, STD
HD210/
Lefty steerer tube plug
KF213/BRN
Kit, Spring, MAX140 FE, XXFIRM
QSMSEAL/
Upper HeadShok bearing seal
KF213/GRN
Kit, Spring, MAX140 FE, SOFT
HD209/BLK
Air filter hood and filter unit for Lefty, Black
KF213/RED
Kit, Spring, MAX140 FE, FIRM
KF205/
Kit, Split Ring, 2
KF214/BLU
Kit, Spring, MAX140 TI, STD
KF206/
Kit, Collar, Upper, Alloy, Speed110/MAX140
KF214/GRN
Kit, Spring, MAX140 TI, SOFT
QC679/ Kit, Clamp, Upper, MAX
KF214/RED
Kit, Spring, MAX140 TI, FIRM
QC680/ Kit, Clamp, Lower, MAX
© 2009 Cannondale Europe • www.cannondale.com
LEFTY MA x 140 TPC
LEFTY MAX 140 TPC Only Alloy version Specifications ID: black spindle, alloy outer tube, polished clamps, red rebound dial - no screw, blue dial with set screw at bottom (images) Year
2006 + 2007
Travel (mm)
140
Damper
Oil damped
Spring element
Steel coil sprung, “Twin Piston Chamber”
Lockout
No
Rebound
External adjustment
Compatilibities
All stems (not stem/steerer) SPV upgrade possible Kit for 120 travel available
KITS ITEM NUMBER
DESCRIPTION
KF220/
Kit, Bladder only SPV, MAX140
KF223/
Kit, Damper, Compression, MAX140, SPV
KF218/
Kit, Damper, Rebound, MAX140, SPV
PRESSURE SET UP Spring preload RECOMMENDED SAG Trail TPC DIAL
© 2009 Cannondale Europe • www.cannondale.com
25-35% TPC KNOB (BOTTOM)
Lefty Max 140 TPC HD210/
KF233/
QL679/
KF206/
KF205/ KF225/
KF216/
QL680/
22mm 10 Nm, 89 InLbs
HD209/BLK KF234/
KF217/ 2mm
KF219/ 2mm
KF222/
KF221/
KF224/
KF354/
KITS
TOOLS
ITEM NUMBER
DESCRIPTION
KF215/
Kit, Damper, Compression, MAX140, FFD
KF216/
Kit, Damper, Compression, MAX140, TPC
KF217/
Kit, Damper, Rebound, MAX140, FFD/TPC
KF221/
Kit, Knob, Compression, MAX140, TPC
KF222/
Kit, Boot, Lefty MAX 140
KF219/
Kit, Damper, Control ASSY, MAX140
ITEM NUMBER
DESCRIPTION
KF224/
Kit, Damper, Piston Ring, MAX140-5
QCTL108/
Tool, Lefty Truing Axle
KF225/
Kit, Seal, MAX140
KF233/
Kit, KNOB, Rebound, MAX140
KF234/
Kit, Pushrod, MAX140
SPRINGS ITEM NUMBER
DESCRIPTION
KF354/
KIT, Tacho Mount Lefty Forks
KF213/BLK
Kit, Spring, MAX140 FE, XFIRM
HD011/
Kit, Band Clamp Cable Guide (2), Boot Lefty
KF213/BLU
Kit, Spring, MAX140 FE, STD
HD210/
Lefty steerer tube plug
KF213/BRN
Kit, Spring, MAX140 FE, XXFIRM
QSMSEAL/
Upper HeadShok bearing seal
KF213/GRN
Kit, Spring, MAX140 FE, SOFT
HD209/BLK
Air filter hood and filter unit for Lefty, Black
KF213/RED
Kit, Spring, MAX140 FE, FIRM
KF205/
Kit, Split Ring, 2
KF214/BLU
Kit, Spring, MAX140 TI, STD
KF206/
Kit, Collar, Upper, Alloy, Speed110/MAX140
KF214/GRN
Kit, Spring, MAX140 TI, SOFT
QC679/ Kit, Clamp, Upper, MAX
KF214/RED
Kit, Spring, MAX140 TI, FIRM
QC680/ Kit, Clamp, Lower, MAX
© 2009 Cannondale Europe • www.cannondale.com
LEFTY MA x 140 SPV EVoLVE
LEFTY MAX 140 SPV evolve Carbon & Alloy version
(IMAGE SHOWS ALLOY)
Specifications ID: Titanium or steel spindle, threads and large lockring under lock-out dial, forged bonded clamps, carbon outer tube (for carbon version), first gen. has carbon inner tube Year
2006 + 2007
Travel (mm)
140
Damper
Oil damped
Spring element
Ti coil sprung, SPV
Lockout
Adjustable rebound
Rebound
External adjustment
Compatilibities
Alloy: All stems (not stem/steerer) Carbon: All stems and stem/steerer TPC downgrade possible Kit for 120 travel available
KITS ITEM NUMBER
DESCRIPTION
KF215/
Kit, Damper, Compression, MAX140, FFD
KF216/
Kit, Damper, Compression, MAX140, TPC
KF217/
Kit, Damper, Rebound, MAX140, FFD/TPC
RECOMMENDED STARTING AIR PRESSURE Lbs
Kg
Psi
Bar
SPRING
120
54
40
2.8
GREEN
130
59
50
3.4
GREEN
140
64
60
4.1
GREEN
150
68
50
3.4
BLUE
160
73
60
4.1
BLUE
170
77
60
4.1
RED
180
82
60
4.1
RED
190
86
60
4.1
BLACK
200
91
70
4.8
BLACK
210
95
70
4.1
BLACK
220
100
5.5
5.5
BLACK
PRESSURE LIMITS MINIMUM - 45 psi (3.1 bar) MAXIMUM - 120 psi (8.3 bar)
© 2009 Cannondale Europe • www.cannondale.com
RECOMMENDED SAG 25-35%
Lefty Max 140 SPV evolve HD210/
KF233/
QL679/ KF206/
KF218 KF205/ KF225/
QL680/
HD209/BLK
KF224/ KF219/ 4
KF222/
KITS
KF354/
TOOLS
ITEM NUMBER
DESCRIPTION
KF214/RED
Kit, Spring, MAX140 TI, FIRM
KF218/
Kit, Damper, Rebound, MAX140, SPV
KF219/
Kit, Damper, Control ASSY, MAX140
KF220/
Kit, Bladder only SPV, MAX140
KF221/
Kit, Knob, Compression, MAX140, TPC
KF222/
Kit, Boot, Lefty MAX 140
KF223/
Kit, Damper, Compression, MAX140, SPV
ITEM NUMBER
DESCRIPTION
KF224/
Kit, Damper, Piston Ring, MAX140-5
QCTL108/
Tool, Lefty Truing Axle
KF225/
Kit, Seal, Max140
KF233/
Kit, Knob, Rebound, MAX140
KF234/
Kit, Pushrod, MAX140
SPRINGS ITEM NUMBER
DESCRIPTION
KF354/
Kit, Tacho Mount Lefty Forks
KF213/BLK
Kit, Spring, MAX140 FE, XFIRM
HD011/
Kit, Band Clamp Cable Guide (2), Boot Lefty
KF213/BLU
Kit, Spring, MAX140 FE, STD
HD210/
Lefty steerer tube plug
KF213/BRN
Kit, Spring, MAX140 FE, XXFIRM
QSMSEAL/
Upper HeadShok bearing seal
KF213/GRN
Kit, Spring, MAX140 FE, SOFT
HD209/BLK
Air filter hood and filter unit for Lefty, Black
KF213/RED
Kit, Spring, MAX140 FE, FIRM
KF205/
Kit, Split Ring, 2
KF214/BLU
Kit, Spring, MAX140 TI, STD
KF206/
Kit, Collar, Upper, Alloy, Speed110/MAX140
KF214/GRN
Kit, Spring, MAX140 TI, SOFT
QC679/ Kit, Clamp, Upper, MAX
KF214/RED
Kit, Spring, MAX140 TI, FIRM
QC680/ Kit, Clamp, Lower, MAX
© 2009 Cannondale Europe • www.cannondale.com
LEFTY SPEED DLR 110
LEFTY SPEED DLR 110 Specifications ID: Color: black metal, clamps forged - not bonded to outer tube, outer tube alloy, black spindle, red rebound dial - set screw on side metal lockout dial, gold cartridge body Year
2006 + 2007
Travel (mm)
110
Damper
Oil damped
Spring element
Air sprung, coil negative spring
Lockout
On the fly
Rebound
External adjustment
Compatilibities
Cartridge NOT compatible with black SL110!
RECOMMENDED STARTING AIR PRESSURE Lbs
Kg
Psi
Bar
120
54
80
5.5
130
59
85
5.9
140
64
90
6.2
150
68
100
6.9
160
73
105
7.2
170
77
110
7.6
180
82
120
7.3
190
86
125
8.6
200
91
130
9.0
210
95
135
9.3
220
100
145
10.0
PRESSURE LIMITS MINIMUM - 50 psi (3.4 bar) MAXIMUM - 225 psi (15.5 bar) DLR DIAL
© 2009 Cannondale Europe • www.cannondale.com
RECOMMENDED SAG XC 20-30%
LEFTY SPEED DLR 110
KITS ITEM NUMBER
DESCRIPTION
KF202/
Kit, Seal, Speed 110
KF204/
Kit, Shim, Revavling, Speed110/MAX140
KF205/
Kit, Split Ring,2
KF206/
Kit, Collar, Upper, Alloy, Speed110/MAX140 (old style)
KF207/
Kit, Collar, Upper, Carbon, Speed110/MAX140
KF210/
Kit, Lever, Lockout, Speed110 w/nut
KF211/
Kit, Knob, Rebound, Speed 110
KF212/
Kit, Cap, Air Valve, Speed 110
KF213/
Kit, Piston, Air, Speed 110
HD169/
Kit, Bearings, Headset - 2; HeadShok
QHDST/EBO
Headset Cannondale/Coda HeadShok Black
QC678/
Kit, Boot, Lefty MAX /Jake, tailed
HD209/BLK
Air filter hood and filter unit for Lefty, Black only
HD210/
Lefty steerer tube plug
KT040/
Kit, Steerer, X-Long Lefty
HD016/
Steerer, Lefty
QSMSEAL/
Upper HeadShok bearing seal
HD011/
Kit, Band Clamp Cable Guide (2), Boot Lefty
HD205/
Lefty Upper clamp
HD206/
lower crown/steerer, lefty
TOOLS ITEM NUMBER
DESCRIPTION
KT020/
Steerer installation/removal
HDTL168/
1/2 bullet tool
QCTL108/
Tool, Lefty Truing Axle
KH031/
Super castle tool
Rider WT. (lbs) Rider WT. (kg)
Fork size
Bike Size
Neg. Spring
Kits
to 145
65
SOFT
PT/SM
GREEN
KF200/GRN
145-175
65 - 79
STANDARD
MD
BLUE
KF200/BLU
175-195
79 - 88
FIRM
LG
RED
KF200/RED
195 +
88 +
X-FIRM
XL
BLACK
KF200/BLK
© 2009 Cannondale Europe • www.cannondale.com
LEFTY SPEED DLR2 110 CARboN & ALLoY
LEFTY SPEED DLR2 110 Carbon & Alloy version
(IMAGE SHOWS ALLOY)
Specifications ID: Color: gun metal or carbon, clamps bonded, outer tube alloy or carbon, black spindle, red rebound dial, metal lockout dial, gold cartridge body. Year
Alloy Carbon
Travel (mm)
110
Damper
Oil damped
Spring element
Air sprung, coil negative spring
Lockout
On the fly
Rebound
External adjustment
Compatilibities
Fits all HeadShok stems and stem/steeres, Cartridge NOT compatible with SL110!
2006-2008 2006-2007
KITS ITEM NUMBER
DESCRIPTION
KH055/
Kit, Convert, DLRSL&DLR2 - Solo Air
RECOMMENDED STARTING AIR PRESSURE Lbs
Kg
Psi
Bar
120
54
85
5.9
130
59
90
6.2
140
64
100
6.9
150
68
105
7.2
160
73
110
7.6
170
77
115
8.0
180
82
125
8.6
190
86
130
9.0
200
91
140
9.7
210
95
145
10.0
220
100
155
10.7
PRESSURE LIMITS MINIMUM - 50 psi (3.4 bar) MAXIMUM - 225 psi (15.5 bar) DLR2 DIAL
© 2009 Cannondale Europe • www.cannondale.com
RECOMMENDED SAG 20 - 30% (22.0 - 23.0 mm)
LEFTY SPEED DLR2 110 CARBON & ALLOY 2.0 Nm, 18 InLbs KF211/
10 Nm, 89 InLbs Loctite™ 262
9.0 Nm, 80 InLbs
KF210/
Carbon version Alloy version
HD215/ HD011/
KF207/ KF206/
28.0 Nm, 248 InLbs
9.0 Nm, 80 InLbs
KF205/
KF201/*** KF202/ KF204/
HD209/BLK
KF200/***
0.23 Nm, 2.0 InLbs
QC678/ 28.0 Nm, 248 InLbs Loctite™ 242
HD175/BLK HD185/BLK
16mm LEFTYBOLTS
KH057/ KF272/
20.0 Nm, 177 InLbs
KF212/ KF213/
0.33 Nm, 3 InLbs
Rider WT. (lbs) Rider WT. (kg)
Fork size
Bike Size
Neg. Spring
Kits
to 145
65
SOFT
PT/SM
GREEN
KF200/GRN
145-175
65 - 79
STANDARD
MD
BLUE
KF200/BLU
175-195
79 - 88
FIRM
LG
RED
KF200/RED
195 +
88 +
X-FIRM
XL
BLACK
KF200/BLK
© 2009 Cannondale Europe • www.cannondale.com
LEFTY SPEED CARboN Fox TERRA LogIC
LEFTY SPEED
CARBON FOX Terra Logic Specifications ID: Color: carbon w/polished clamps, clamps bonded, outer tube carbon, black spindle, large red rebound dial, small silver cap in center, blue threshold knob at bottom. Year
2006
Travel (mm)
110
Damper
Oil damped
Spring element
Air sprung, float air negative spring
Lockout
Inertia valve lockout
Rebound
External adjustment
Compatilibities
Fits all HeadShok stems and stem/steeres, Cartridge NOT compatible with SL110 or DLR110 RLC 110 upgrade possible
RECOMMENDED STARTING AIR PRESSURE Lbs
Kg
Psi
Bar
140
64
35
2.4
150
68
40
2.8
160
73
45
3.1
170
77
50
3.4
180
82
60
4.1
190
86
70
4.8
PRESSURE LIMITS MINIMUM - 20 psi (1.4 bar) MAXIMUM - 120 psi (8.3 bar) DIAL
© 2009 Cannondale Europe • www.cannondale.com
RECOMMENDED SAG 20 - 30% (22.0 - 23.0 mm)
LEFTY SPEED Car bon FOX Terra Logic
KITS ITEM NUMBER
DESCRIPTION
KF250/
KIT, KNOB, REBOUND, Lefty-FOX Terra Logic IV
KF251/
KIT, SPRING, AIR ON TOP, Lefty-FOX Terra Logic IV
KF252/
Kit, D amper, Lefty-FOX Terra Logic IV
KF253/
Kit, Seal, Air on top, Lefty-FOX Terra Logic IV
HD169/
Kit, Bearings, Headset - 2; HeadShok
QHDST/EBO
Headset Cannondale/Coda HeadShok Black
QC678/
Kit, Boot, Lefty MAX /Jake, tailed
HD209/BLK
Air filter hood and filter unit for Lefty, Black only
HD210/
Lefty steerer tube plug
KT040/
KIT, STEERER, X-LONG LEFTY
HD016/
Steerer, Lefty
QSMSEAL/
Upper HeadShok bearing seal
HD011/
Kit, Band Clamp Cable Guide (2), Boot Lefty
TOOLS ITEM NUMBER
DESCRIPTION
KT020/
Steerer installation/removal
QCTL108/
Tool, Lefty Truing Axle
© 2009 Cannondale Europe • www.cannondale.com
LEFTY SPEED CARboN SL 110
LEFTY SPEED CARBON SL 110 Specifications ID: Blue lockout dial, SL laser etched on black spindle polished clamps - machined flat, black cartidge body. Year
2007-2009
Travel (mm)
110
Damper
Oil damped
Spring element
Air sprung, coil negative spring
Lockout
On the fly
Rebound
External adjustment
Compatilibities
Stems, steering tubes, stem/steeres
KITS ITEM NUMBER
DESCRIPTION
KH055/
Kit, Convert, DLRSL&DLR2 – Solo Air
RECOMMENDED STARTING AIR PRESSURE Lbs
Kg
Psi
Bar
120 130
54
80
5.5
59
85
5.9
140 150
64
90
6.2
68
100
6.9
160
73
105
7.2
170
77
110
7.6
180
82
120
7.3
190
86
125
8.6
200
91
130
9.0
210
95
135
9.3
220
100
145
10.0
PRESSURE LIMITS MINIMUM - 50 psi (3.4 bar) MAXIMUM - 225 psi (15.5 bar) DIAL
© 2009 Cannondale Europe • www.cannondale.com
RECOMMENDED SAG 20 - 30% = (22.0 - 23.0 mm)
Lefty Speed Car bon SL 110 2 Nm, 18 InLbs KF211/
KT031/
Apply NL GI-2 Synthetic grease to items marked
HD215/
KT027/ 28 Nm 248 InLbs HD011/
KT028/ 20Nm, 177 InLbs
KF205/
HD209/
KH055/ 29’er Travel reduction spacers 3 x 10 mm
QC678/
HO175/BLK HO185/BLK
KH026/
KITS ITEM NUMBER
DESCRIPTION
KT026/GRN
KIT, DAMPER LEFTY DLRSL (remove volume compensator)
KT026/BLU
KIT, DAMPER LEFTY DLRSL (remove volume compensator)
KT026/RED
KIT, DAMPER LEFTY DLRSL (remove volume compensator)
KT026/BLK
KIT, DAMPER LEFTY DLRSL (remove volume compensator)
KT213
KIT, AIR PISTON
Rider WT. (lbs) Rider WT. (kg)
Fork size
Bike Size
Neg. Spring
Kits
to 145
65
SOFT
PT/SM
GREEN
KT025/GRN
145-175
65 - 79
STANDARD
MD
BLUE
KT025/BLU
175-195
79 - 88
FIRM
LG
RED
KT025/RED
195 +
88 +
X-FIRM
XL
BLACK
KT025/BLK
© 2009 Cannondale Europe • www.cannondale.com
LEFTY SPEED CARboN SL2 110 (SoLo AIR)
LEFTY SPEED SL2 CARBON 110 (Solo Air) Specifications ID: Blue lockout dial, red rebound dial with set screw on side, polished clamps - machined flat, OPI laser etched on black spindle. Year
2009 +
Travel (mm)
110
Damper
Oil damped
Spring element
Air sprung, SOLO AIR self adjusting negative spring
Lockout
On the fly
Rebound
External adjustment
Compatilibities
Stems, steering tubes, Stem/steerer
RECOMMENDED STARTING AIR PRESSURE Lbs
Kg
Psi
Bar
120
54
85
5.9
130
59
90
6.2
140
64
100
6.9
150
68
105
7.2
160
73
110
7.6
170
77
115
8.0
180
82
125
8.6
190
86
130
9.0
200
91
140
9.7
210
95
145
10.0
220
100
155
10.7
PRESSURE LIMITS MINIMUM - 50 psi (3.4 bar) MAXIMUM - 225 psi (15.5 bar) DIAL
© 2009 Cannondale Europe • www.cannondale.com
RECOMMENDED SAG 20 - 30% = (22.0 - 23.0 mm)
OPI SPINDLE
Lefty Speed Car bon SL2 110 (Solo Air) 2 Nm, 18 InLbs KF211/
KT031/
Apply NL GI-2 Synthetic grease to items marked
HD215/
KT027/ 28 Nm 248 InLbs HD011/
KT028/ 20Nm, 177 InLbs
KF205/
KH055/ 29’er Travel reduction spacers 3 x 10 mm
HD209/
QC678/
KH026/
HO175/BLK HO185/BLK
* DRAWING DOES NOT SHOW OPI SPINDLE
KITS ITEM NUMBER
DESCRIPTION
KH052/
Kit, Air Piston, DLR SL, Solo Air
KT024/
Kit, Seals, DLR SL
KT051
Kit, Damper, Lefty DLR SL, Solo
© 2009 Cannondale Europe • www.cannondale.com
LEFTY MAx CARboN Fox RLC 130
LEFTY MAX CARBON FOX RLC 130 Specifications ID: Red rebound dial with allen screw in center, 2nd blue adjust wheel under lockout dial. Year
2008-2009 +
Travel (mm)
130
Damper
Oil damped
Spring element
Ti coil spring, Adjustable low-speed comp
Lockout
Yes, Adjustable lock-out threshold
Rebound
External Adjustment
Compatilibities
Stems, steering tubes, Stem/steerer
KITS ITEM NUMBER
DESCRIPTION
KH041/
Lefty PBR Damper
RECOMMENDED SAG B
A
B - A = SAG (mm) Measure the length of the fork as shown below – this as measurement A. With the help of a second person, seat the rider on the saddle with feet on pedals and hands on the handlebar. Again measure the length of the fork - this as measurement B.
SAG
To calculate sag subtract B from A . The recommended sag measurement (in millimeters) as a percentage of your forks total travel, should fall within the guidelines listed in the attached chart. To increase sag, release air. To decrease sag, add air.
RECOMMENDED SAG Trail DIAL
© 2009 Cannondale Europe • www.cannondale.com
25-35%
LEFTY MAX CARBON FOX RLC 130
SUPPLIED BY FOX
KH015/
KH025/
HD209/BLK
KH032/ 033/ 034/ 035/
KF222/
KITS
KH014/
ITEM NUMBER
DESCRIPTION
KH032/
Spring, soft, ti
KH033/
Spring, standard, ti
KH034/
Spring, firm, ti
KH035/
Spring, x-firm, ti
KH025/
FOX RLC preload tube
KH011/
FOX RLC upgrade kit
KH012/
FOX RLC seal kit
KH028/
FOX RLC rebound shaft
KH015/
FOX RLC compression damper
KH029/
FOX RLC seal head
KH026/
FOX RLC compression clamp
KH027/
FOX RLC retaining ring
KF205/
Split rings 2
KH016/
FOX RLC outer collar
HD169/
Kit, Bearings, Headset - 2; HeadShok
QHDST/EBO
Headset Cannondale/Coda HeadShok black
HD209/BLK
Air filter hood and filter unit for Lefty, Black only
HD210/
Lefty steerer tube plug
8A502/BLK
Frame protection bumper
KF354/
Kit, Tacho Mount Lefty Forks
KT040/
Kit, Steerer, X-Long Lefty
KF222/
Kit, Boot, Lefty MAX 140 © 2009 Cannondale Europe • www.cannondale.com
LEFTY MAx CARboN 130 Pb R
LEFTY MAX 130 PBR Carbon & Alloy version Specifications ID: Large red rebound dial w/ small blue lockout relase button, air valve at bottom, small blue lockout push button inside rebound dial, carbon outer tube. Year
2008-2009 +
Travel (mm)
130
Damper
Oil damped
Spring element
Air sprung, Solo Air self adjusting negative spring
Lockout
Adjustable lock-out threshold
Rebound
External Adjustment
Compatilibities
Stems, steering tubes
KITS ITEM NUMBER
DESCRIPTION
KH017/
Fox RLC 130 mm rebound damper
KH011/
Fox RLC upgrade kit
RECOMMENDED STARTING AIR PRESSURE Lbs
Kg
Psi
Bar
120
54
85
5.8
130
59
90
6.2
140
64
95
6.5
150
68
105
7.2
160
73
120
8.2
170
77
135
9.3
180
82
150
10.3
190
86
165
11.3
200
91
180
12.4
210
95
195
13.4
220
100
205
14.1
PRESSURE LIMITS MINIMUM - 50 psi (3.4 bar) MAXIMUM - 225 psi (15.5 bar) KH045/ PBR DIAL Carbon version
© 2009 Cannondale Europe • www.cannondale.com
RECOMMENDED SAG 25 - 30% = (32.5 - 39.0 mm)
KH046/ PBR DIAL Alloy version
LEFTY MAX CARBON 130 PBR 0.5 Nm, 4.4 InLbs Loctite™ 222
KH044/ 9.0 Nm, 80 InLbs
KH045/ KH046/
28.0 Nm, 248 InLbs HD215/ HD011/ 9.0 Nm, 80 InLbs
KF205/
KH042/ HD226/
HD209/BLK
KF222/
0.23 Nm, 2.0 InLbs
Loctite™ 401
28.0 Nm, 248 InLbs Loctite™ 242
KH061/ KH043/
HD175/BLK
16mm LEFTY BOLTS
KH057/ 3.4 Nm, 30 InLbs Loctite™ 242
20.0 Nm, 177 InLbs
KT028/
0.33 Nm, 3 InLbs
KITS ITEM NUMBER
DESCRIPTION
KH041/
Kit, Damper, Lefty PBR 130
KH042/
Kit, Seals, PBR 130 © 2009 Cannondale Europe • www.cannondale.com
Related Documents 3m3m1z
Headshok / Lefty Forks Catalog (cannondale) 58131u
June 2020 2
Wiki Lefty Cannondale 564y3a
December 2019 35
Cannondale Lefty Fork Manual 511x2f
November 2019 127
2000 Headshok Lefty Owners Manual Supplement En 606d1f
June 2020 8
09 Cannondale Catalog 37193w
March 2023 0
1994 Cannondale Bicycle Catalog 193x16
December 2019 71More Documents from "Rully Llama" 5b5k5
Headshok / Lefty Forks Catalog (cannondale) 58131u
June 2020 2
900 Series Speedometer Calibration Switch Settings 4l4r6d
December 2019 16
M2 2007 Electrical Body Builder Manual Rev New.pdf 6l7119
December 2021 0
Ddec V.ppt q54p
March 2021 0
Kak Amp 5r4o3r
October 2020 0
