PROFIS Anchor 2.0.9
www.hilti.us Company: Specifier: Address: Phone I Fax: E-Mail:
Page: Project: Sub-Project I Pos. No.: Date:
-|-
1
11/1/2010
Specifier's comments:
1. Input data
Anchor type and diameter: Effective embedment depth: Material: Evaluation Service Report:: Issued I Valid: Proof: Stand-off installation: Anchor plate: Profile Base material: Installation: Reinforcement:
HIT-RE 500-SD + HAS, 1 h ef,act = 8.260 in. (h ef,limit = - in.) ASTM F 568M Class 5.8 ESR 2322 11/1/2007 | design method ACI 318 / AC308 without clamping (anchor); restraint level (anchor plate): 2.0; eb = 1.000 in.; t = 1.000 in. lx x l y x t = 10.000 x 14.000 x 1.000 in. (Recommended plate thickness: not calculated) W shape (AISC); (L x W x T x FT) = 12.200 in. x 8.080 in. x 0.370 in. x 0.640 in. uncracked concrete , 4000, fc ' = 4000 psi; h = 29.520 in., Temp. short/long: 32/32°F hammer drilled hole, installation condition: dry condition A; no supplemental splitting reinforcement present edge reinforcement: none or < No. 4 bar
Geometry [in.] z
y
x
1
3
2
4
14.000
t=1.000 e b=1.000 h ef =8.260 x
h = 29.520
24.950
6.000
10.000
lx = 10.000 20.420
6.000
Loading [lb, in.-lb] Governing loads
Governing loads (Load case 1) N
28486
Vx
-3955
Vy
15047
Mx
0.000
My
0.000
Mz
0.000
Eccentricity (structural section) [in.] e x = 0.000; ey = 0.000 Seismic loads (cracked concrete assumed; categories C, D, E, or F): no
Input data and results must be checked for agreement with the existing conditions and for plausibility! PROFIS Anchor ( c ) 2003-2009 Hilti AG, FL-9494 Schaan Hilti is a ed Trademark of Hilti AG, Schaan
PROFIS Anchor 2.0.9
www.hilti.us Company: Specifier: Address: Phone I Fax: E-Mail:
Page: Project: Sub-Project I Pos. No.: Date:
-|-
2
11/1/2010
2. Load case/Resulting anchor forces Load case (governing): Anchor reactions [lb] Tension force: (+Tension, -Compression) Anchor
Tension force
Shear force
Shear force x
Shear force y
1
7122
3889
-989
3762
2
7122
3889
-989
3762
3
7122
3889
-989
3762
4
7122
3889
-989
3762
y 3
1 Tension
x max. concrete compressive strain [‰]: 0.00 max. concrete compressive stress [psi]: 0 resulting tension force in (x/y)=(0.000/0.000) [lb]: 28483 resulting compression force in (x/y)=(0/0) [lb]: 0
2
4
3. Tension load Load Nua [lb]
Capacity fN n [lb]
Utilization bN [%] = Nua /fNn
Status
Steel Strength*
7121
28542
25
OK
Bond Strength**
28486
44002
65
OK
Concrete Breakout Strength**
28486
36137
79
OK
Proof
* most unfavorable anchor **anchor group (anchors in tension) Steel Strength Nsa [lb]
f
fNsa [lb]
Nua [lb]
43910
0.650
28542
7121
ANa [in²]
ANa0 [in²]
s cr,Na [in.]
c cr,Na [in.]
c [in.]
c ac [in.]
850.50
536.54
23.163
11.582
20.420
12.390
k c,uncr
t k,uncr,2500 [psi]
k dry
t k,uncr [psi]
t k,max,uncr [psi]
y g,Na0
y g,Na
24
1945
1.00
1945
1389
1.000
1.000
e c1,N [in.]
y ec1,Na
e c2,N [in.]
y ec2,Na
y p,Na
y ed,Na
0.000
1.000
0.000
1.000
1.000
1.000
Na0 [lb]
f
fNag [lb]
Nua [lb]
50471
0.550
44002
28486
Bond Strength
Concrete Breakout Strength ANc [in²]
ANco [in²]
c [in.]
c ac [in.]
947.41
614.05
20.420
12.390
e c1,N [in.]
y ec1,N
e c2,N [in.]
y ec2,N
y ed,N
y ,N
k uncr
0.000
1.000
0.000
1.000
1.000
1.000
24.000
Nb [lb]
f
fNcbg [lb]
Nua [lb]
36034
0.650
36137
28486
