Horus Vision Brochure Raptor 136t1x

RAPTOR How Far Do You Want to Reach?

MODEL 2000

HORUS

TM

Don’t let those hard-to-reach trophies escape your grasp. Make clean, precise hits out to 1500+ yards. RAPTOR 4-16x50 Long-Range Non-Illuminated Scope TM

The Raptor gives hunters the long-range accuracy required to take home those coveted trophies. Long-range shots are becoming the norm, since those easyto-get trophies of twenty or more years ago are becoming just a fading memory. With the Raptor hunters can make clean, precise shots at extended range, using accurate elevation and wind holds based on their gun, ammo, and environmental conditions. The Raptor offers a great reticle/optic combination to match your favorite rifle’s performance during everyday use and those once-in-a-lifetime hunts.

Features  Lightweight and tough aircraft-grade aluminum body  Intentionally non-illuminated to comply with hunting regulations in many states  High quality glass and coatings typically found in scopes  Smooth side parallax adjustment for fine precision  Turret covers protect against the elements and unintentional adjustments  Reticle grid enables rapid Second Shot CorrectionTM

TReMoR2™ Reticle The TReMoR2 features single-step ranging for drop compensation and lightning-fast windage adjustments.

2.0”

6.0”

16.0” 2.0”

3.0”

3.0”

30 mm

1.36”

50 mm

Scope Specifications Power . . . . . . . . . . . . . . . . . . . . Length . . . . . . . . . . . . . . . . . . . . Weight . . . . . . . . . . . . . . . . . . . . Tube Diameter. . . . . . . . . . . . . . Wall Thickness . . . . . . . . . . . . . Material . . . . . . . . . . . . . . . . . . . Tube . . . . . . . . . . . . . . . . . . . . . Color . . . . . . . . . . . . . . . . . . . . . Exterior Finish . . . . . . . . . . . . . . Shockproof . . . . . . . . . . . . . . . . Water-resistant . . . . . . . . . . . . . Dustproof . . . . . . . . . . . . . . . . . . Fogproof . . . . . . . . . . . . . . . . . . Warranty . . . . . . . . . . . . . . . . . . Twilight Factor . . . . . . . . . . . . . . Reticle . . . . . . . . . . . . . . . . . . . . Reticle Position . . . . . . . . . . . . . Reticle Illumination . . . . . . . . . . Lenses . . . . . . . . . . . . . . . . . . . .

4-16x 16.0" (40.6 cm) 27.5 oz (780 g) 30 mm 1.5 mm aluminum 6061-T, 340 HV Hardness 1 piece black matte anodized 1200 g yes (3 meters) yes yes 1 year limited 14.1 @ 4x - 28.3 @ 16x H59, TReMoR2, or H25 1st Focal Plane no 11 + reticle

Lens Coating . . . . . . . . . . . . . . . Objective Lens. . . . . . . . . . . . . . Field of View . . . . . . . . . . . . . . . Eye Relief. . . . . . . . . . . . . . . . . . Exit Pupil . . . . . . . . . . . . . . . . . . Ocular Type . . . . . . . . . . . . . . . . Diopter Adjustment . . . . . . . . . . Elevation Increment. . . . . . . . . . Elevation Adj. Range . . . . . . . . . Windage Increments . . . . . . . . . Windage Adj. Range . . . . . . . . . Turret Caps . . . . . . . . . . . . . . . . Turret Type . . . . . . . . . . . . . . . . Power Selector Style . . . . . . . . . Parallax . . . . . . . . . . . . . . . . . . .

Optional Accessories Sun Shade. . . . . . . . . . . . . 3" (76 mm)(thread size: M52x0.75 mm) Flashkill (length) . . . . . . . . 3.03" (77 mm) ASLI

TReMoR2 at 12x

1

1

2

2

3

3

4

4

5

5

6

6

7

7

8

8

9 10

9

8

7

10

6

5

4

3

9 2

1

1

2

3

4

5

12

10

6

7

8

9

10

12

TReMoR2 Reticle Specifications Distance . . . . . . . . . . . . to 1500+ yards, depending on ammo Illumination . . . . . . . . . . non-illuminated reticle Horizontal Crosshair . . . . thin lined, calibrated in 0.2 mil graduations Range Finder. . . . . . . . . none, use central grid calibrated in mils Central Targeting Grid . . . calibrated in USMC mils* *(6283 mimls/circle) (1 mil = 3.60 inches at 100 yards)

multi-coated 50 mm 5.5 - 2.3 m (at 100 m) 4.3" - 3.5" (109-89 mm) 12.5 - 3.1 mm rapid European focus more than (-2,+1) 1 click = .10 mil radian more than 16.3 MILS (59 MOA) 1 click = .10 mil radian more than 16.3 MILS (59 MOA) yes high tactile power indicator side parallax variable 50 m to infinity

Horus Scopes

Why Horus? Horus scopes take an evolutionary leap forward in

FALCONTM 5-20x50 Illuminated A scope for all needs. Steel tubes ensure toughness for heavy field use and larger calibers out to 1500+ yards.

aiming technology. Our patented reticles replace outdated mil dots and obsolete crosshairs with a H59

combat proven grid. Wind and elevation adjustments are lightning fast. Simply sight your target at the correct grid coordinates, then pull

RAPTORTM 4-16X50 Non-Illuminated

the trigger. No more turning

For serious shooters wanting extra reach and precision up to 1500+ yards.

Your eyes and attention stay

knobs or counting clicks. focused right on target.  easy to use

T2

 lightning-fast adjustments  enhanced accuracy  absolute repeatability  reduced training time

HUNTER 3-12x50 Non-Illuminated TM

Versitile entry to Horus. This simple, no-nonsense scope is excellent for shots out to 700+ yards.

 features second shot  correction

DISCLAIMERS H130

H425

Product details, specifications and images may not reflect current features and are subject to change without notice. Though scope distances are shown in yards, all Horus scopes can be used in either the English or metric system. Full disclaimer at www.horusvision.com/.php. Horus reticle designs and products are covered by U.S. and foreign patents.  2015 Horus Vision, LLC. All rights reserved.

Extreme Technology. Extreme Precision. ion for precision propels us toward groundbreaking technology. Our revolutionary reticles make conventional reticles obsolete, delivering repeatable hits from close range to 1500 yards. Want to make your first shot under even the most extreme conditions? Our ATrag™ Ballistics Software instantly calculates precise hold points based on your exact atmospheric, ballistics, and target data. For ultimate accuracy at extreme range, fine-tune your skills and scope with our calibration accessories. When you own Horus technology, you own the field.

HORUS

TM

(650) 588-8862 Horus Vision, LLC 598 San Mateo Ave. San Bruno, CA 94066 [email protected] www.horusvision.com
