How to run a Modelsim using TCL script

How to run a ModelSim using TCL script Once you completed the HDL coding in ModelSim or any text editor with file extension ‘.vhd’for VHDL and ‘ .vo’ for Verilog then, we can use TCL script to run the entire project . For example I have a vhdl file of name “full_adder.vhd” and write a test bench to run the full adder with name “tb_full_adder.vhd”.we will check how this TCL work for this project. TCL script is

vlib work vmap work vcom full_adder.vhd vcom tb_full_adder.vhd vsim tb_full_adder add wave -radix decimal -r /* run 1 ms

Explanation Vlib work

 Creates a library with name work

Vmap work

 Mapping all the design units into work

Vcom full_adder.vhd

 Compile the full adder design unit

Vcom tb_full_adder.vhd

 Compile the test bench for the full adder

Vsim tb_full_adder

Simulate the test bench for the full adder (don’t add the file extension)

add wave -radix decimal -r /*  Adding all the signals to the wave window run 1 ms

 Running the full adder design unit to 1 ms with test bench that you write

Aneesh R Technical Officer Centre For Development of Advanced Computing Bangalore, India

How to run a Modelsim using TCL script if you found any difficulty in executing the TCL script please drop a mail to me [email protected]
