1S3253356F001 制动管路-干燥器组件(带消声器) Braking pipeline- air dryer assembly (with muffler) ..................................................................................................... - 2 1S4253356A001 制动管路-继动阀组件 Brake pipeline-relay valve module ...................................................................................................................................................... - 4 1S4253356B001 制动管路-差动阀组件-1（差动阀总成(脚制动)） Braking pipeline- differential valve module-1 (Differential valve assy (foot braking))......................... - 6 1S4253356B001 制动管路-差动阀组件-2（差动阀总成(手制动)） Braking pipeline- differential valve module-2(Differential valve assy (hand braking)) ........................ - 8 1S325139403H3 铭牌(普通出口车用) Nameplate (for ordinary export vehicle) .................................................................................................................................... - 10 1S325313100H1 散热器 Radiator................................................................................................................................................................................................................... - 12 1S325313300H1 散热器软管 Radiator hose ...................................................................................................................................................................................................... - 14 1S325322001H1 传动轴（2 根，110X6，6X4）Propeller shaft （2，110X6，6X4） ................................................................................................................................. - 16 1S325816100H1 离合器装置（潍柴）Clutch device (WD) .............................................................................................................................................................................. - 18 1S11333644002 前部灯具-底盘部分 Front lamp (Chassis Portion) ............................................................................................................................................................ - 20 1S12403110000 车轮及轮胎 Wheel and tyre ............................................................................................................................................................................................. - 22 1S12413670000 信号装置 Signal device........................................................................................................................................................................................................ - 24 1S12413910000 随车工具及附件 Vehicle-born tools and accessories .......................................................................................................................................................... - 26 1S12511200001 排气装置 Air exhaust device................................................................................................................................................................................................ - 28 1S12533530001 驻车制动操纵机构-驾驶室部分 Parking brake control device (cabin) .............................................................................................................................. - 32 1S13813610001 蓄电池 Battery....................................................................................................................................................................................................................... - 35 1S32413650000 后位灯具 Rear lamps ........................................................................................................................................................................................................... - 37 1S32413660000 开关 Switch ............................................................................................................................................................................................................................ - 39 1S32511010103 动力总成悬置 Power train assy suspension............................................................................................................................................................................. - 41 1S32511010103 动力总成悬置 Power train assy suspension............................................................................................................................................................................. - 42 1S32511110104 燃油箱 Fuel tank..................................................................................................................................................................................................................... - 44 1S32511140104 供油系管路 Fuel supply system pipeline 1S32511150104 燃油滤清器 Fuel filter.............................................................................................................. - 46 1S32511190301 进气装置-1 Air intake device-1.............................................................................................................................................................................................. - 48 1S32511190301 进气装置-2 Air intake device-2........................................................................................................................................................................................ - 50 1S32512950202 后悬架（加强） Rear suspension(reinforced) ........................................................................................................................................................................ - 52 -

-5-

1S32512950202 后悬架（加强） Rear suspension(reinforced) ........................................................................................................................................................................ - 53 1S32513150101 备胎架 Spare wheel carrier .................................................................................................................................................................................................... - 55 1S32513561304 制动管路-储气筒组件 Braking pipeline - air reservoir module............................................................................................................................................ - 57 1S32531030101 防护装置 Protective device.................................................................................................................................................................................................... - 60 1S32531620102 离合器操纵装置 Clutch operation device ............................................................................................................................................................................. - 62 1S32531721501 变速器操纵机构 Gearbox operation mechanism..................................................................................................................................................................... - 65 1S32531751501 变速器悬置 Gearbox suspension ........................................................................................................................................................................................... - 67 1S32532801501 车架总成 Frame assy ............................................................................................................................................................................................................. - 69 1S32532920401 前悬架(右舵) Front suspension （RHD） ......................................................................................................................................................................... - 72 1S32532920401 前悬架(右舵) Front suspension （RHD） ......................................................................................................................................................................... - 73 1S32532920401 前悬架(右舵) Front suspension （RHD） ......................................................................................................................................................................... - 74 1S32533400401 转向器及附件 Steering gear and accessories......................................................................................................................................................................... - 76 1S32533400401 转向器及附件 Steering gear and accessories......................................................................................................................................................................... - 77 1S32533560006 制动管路-底盘部分(非 ABS)-2 Braking pipeline- chassis (non ABS)-2............................................................................................................................ - 79 1S32533560006 制动管路-底盘部分(非 ABS)-2 Braking pipeline- chassis (non ABS)-2............................................................................................................................ - 80 1S32533560006 制动管路-底盘部分(非 ABS)-3 Braking pipeline- chassis (non ABS)-3.............................................................................................................................. - 82 1S32533560006 制动管路-底盘部分(非 ABS)-4 Braking pipeline- chassis (non ABS)-4................................................................................................................................. - 86 1S32533561103 制动管路-空压机至干燥器组件 Braking pipeline, from air compressor to dryer module ................................................................................................... - 88 1S32533620419 底盘线束 Chassis wire harness ................................................................................................................................................................................................ - 90 1S32533620419 底盘线束 Chassis wire harness ................................................................................................................................................................................................ - 91 1S32534031001 前防撞杠及牵引装置 Front anti-collision and towing device............................................................................................................................................... - 93 1S32534032001 后牵引装置 Rear towing device ............................................................................................................................................................................................ - 95 1S32583564104 制动管路－排气碟阀组件 Braking pipeline - exhaust butterfly valve module ...................................................................................................................... - 97 1S41703561500 四回路保护阀组件 Four-circuit protection valve assy............................................................................................................................................................ - 99 1S42531170701 加速传动装置 Acceleration transmission device................................................................................................................................................................... - 101 1S42531181201 加速传动装置-底盘部分(右舵车) Acceleration transmision device-chassis(RHD) .............................................................................................................. - 103 1S42531630801 离合器操纵机构 Clutch operation mechanism.................................................................................................................................................................... - 105 1S42531730801 变速操纵机构 Gearbox operation mechanism ...................................................................................................................................................................... - 107 1S42533540001 踏板及吊挂 Pedal and hanger................................................................................................................................................................................................ - 109 1S42533550002 真空助力器及制动总泵 Vacuum booster and brake master cylinder ....................................................................................................................................- 111 -

-6-

1S52533420201 转向传动装置 Steering drive device...................................................................................................................................................................................... - 113 1SB2206810501 驾驶员座椅 Driver seat ......................................................................................................................................................................................................... - 115 1SB2493710113 前围灯具 Front wall lamps.................................................................................................................................................................................................... - 117 1SB2493730408 开关-车身部分 Switch- body part......................................................................................................................................................................................... - 119 1SB2493730408 开关-车身部分 Switch- body part......................................................................................................................................................................................... - 120 1SB2493740419 车身线束 Body wire.............................................................................................................................................................................................................. - 122 1SB2493751280 继电器控制器及车身总线(豪华车型用)Relay control and body assy (for luxury vehicle model) ...................................................................................... - 125 1SB2493760140 仪表装置 Instrument device .................................................................................................................................................................................................. - 127 1SB2493780107 电气附件 Electric accessories ............................................................................................................................................................................................... - 129 1SB2495000116 车身本体 Vehicle body........................................................................................................................................................................................................ - 131 1SB2495020302 车身悬置翻转锁止机构(右舵自卸)Vehicle body tilting and locking mechanism(RH driving, self-unloading) （1B24950200199 前悬置安装图）Front Suspension Installation drawing .................................................................................................................................................... - 136 1SB2495020302 车身悬置翻转锁止机构(右舵自卸)Vehicle body tilting and locking mechanism(RH driving, self-unloading) （1B24950200199 前悬置安装图）Front Suspension Installation drawing .................................................................................................................................................... - 137 1SB2495020302 车身悬置翻转锁止机构(右舵自卸)Vehicle body tilting and locking mechanism(RH driving, self-unloading) （1B24950200199 前悬置安装图）Front Suspension Installation drawing .................................................................................................................................................... - 138 1SB2495020302 车身悬置翻转锁止机构(右舵自卸)Vehicle body tilting and locking mechanism(RH driving, self-unloading) （1B24950240001 翻转操纵机构总成(右置)）Tilting operation mechanism assy (RH)................................................................................................................................ - 140 1SB2495020302 车身悬置翻转锁止机构(右舵自卸)Vehicle body tilting and locking mechanism(RH driving, self-unloading) （1B24950240001 翻转操纵机构总成(右置)）Tilting operation mechanism assy (RH)................................................................................................................................ - 141 1SB2495020302 车身悬置翻转锁止机构(右舵自卸) Vehicle body tilting and locking mechanism(RH driving, self-unloading) （1B24950280026 后悬置总成）Rear suspension assy ................................................................................................................................................................................... - 143 1SB2495020302 车身悬置翻转锁止机构(右舵自卸) Vehicle body tilting and locking mechanism(RH driving, self-unloading) （1B24950280026 后悬置总成）Rear suspension assy ................................................................................................................................................................................... - 144 1SB2495062113 车身标志（AUMAN 9 290W）Body label-AUMAN 9 290W1SB2495061007 车身标志(车前标志 ETX 出口车) Vehicle mark (vehicle front mark ETX for export)............................................................................................................................................................................................. - 146 1SB2495120501 地板装饰件（右置车）-1 Floor decorative fitting (RHD)-1 ........................................................................................................................................... - 148 1SB2495120501 地板装饰件（右置车）-1 Floor decorative fitting (RHD)-1 ........................................................................................................................................... - 149 1SB2495120501 地板装饰件（右置车）-2 Floor decorative fitting (RHD)-2 ................................................................................................................................................ - 151 1SB2495210101 风窗零部件 Windshield parts................................................................................................................................................................................................ - 153 -

-7-

1SB2495250701 刮水器及洗涤器 Wiper and scrubber ................................................................................................................................................................................... - 155 1SB2495310501 前围附件-1 Front wall accessories-1...................................................................................................................................................................................... - 159 1SB2495310501 前围附件-2 Front wall accessories-2................................................................................................................................................................................. - 162 1SB2495350503 仪表板 Dashboard ................................................................................................................................................................................................................. - 165 1SB2495410603 侧围附件 Side wall accessories............................................................................................................................................................................................. - 167 1SB2495610101 后围附件 Rear wall accessories ............................................................................................................................................................................................ - 171 1SB2495720404 顶盖附件 Roof accessories.................................................................................................................................................................................................... - 173 1SB2496120603 前侧车门附件 Front side vehicle door accessories ............................................................................................................................................................. - 175 1SB2496120603 前侧车门附件 Front side vehicle door accessories ............................................................................................................................................................. - 176 1SB2496120603 前侧车门附件 Front side vehicle door accessories ............................................................................................................................................................. - 177 1SB2496140101 玻璃升降机构(手动) Glass lifter mechanism(manual) .......................................................................................................................................................... - 179 1SB2496150101 门锁 Door lock..................................................................................................................................................................................................................... - 181 1SB2496150101 门锁 Door lock..................................................................................................................................................................................................................... - 182 1SB2497040502 卧铺装置 Sleeper device ....................................................................................................................................................................................................... - 184 1SB2497910109 音响装置 Audio device .......................................................................................................................................................................................................... - 186 1SB2498110709 暖气装置 Heater ................................................................................................................................................................................................................ - 188 1SB2498110709 暖气装置 Heater ................................................................................................................................................................................................................ - 189 1SB2498210502 后视镜 Rear-view mirror....................................................................................................................................................................................................... - 191 1SB2498220101 安全带 Seat belt 1SB2498250101 灭火器 Fire extinguisher ................................................................................................................................................. - 193 1SB2498240404 遮阳装置 Visor device......................................................................................................................................................................................................... - 195 1SB2498430212 挡泥板-车架部分 Mudguard - frame .................................................................................................................................................................................... - 197 1SB2498430405 挡泥板－车身部分 Mudguard-body part............................................................................................................................................................................... - 199 1SB2498450403 脚踏板-车身部分 Step board-body part................................................................................................................................................................................. - 201 1SB2498450404 脚踏板-自卸车 Step board -for dumping truck ...................................................................................................................................................................... - 203 1S325110002H8WD615.50 发动机总成（213kW 国产泵工程版）-单缸空气压缩机 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - Single-cylinder air compressor................................................................... - 205 1S325110002H8WD615.50 发动机总成（213kW 国产泵工程版）-活塞连杆 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - piston connecting rod ................................................................................. - 207 1S325110002H8WD615.50 发动机总成（213kW 国产泵工程版）-火焰预热系统 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - Flame preheating system............................................................................ - 209 -

-8-

1S325110002H8WD615.50 发动机总成（213kW 国产泵工程版）-机油泵 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - oil pump ..................................................................................................... - 211 1S325110002H8WD615.50 发动机总成（213kW 国产泵工程版）-机油滤清器和机油冷却器 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - oil filter and oil cooler................................................................................ - 213 1S325110002H8WD615.50 发动机总成（213kW 国产泵工程版）-进气系统 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - intake system.............................................................................................. - 215 1S325110002H8WD615.50 发动机总成（213kW 国产泵工程版）-冷却系统 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - cooling system............................................................................................ - 217 1S325110002H8WD615.50 发动机总成（213kW 国产泵工程版）-联轴器 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - Coupling..................................................................................................... - 219 1S325110002H8WD615.50 发动机总成（213kW 国产泵工程版）-排气系统 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version )- exhaust system ............................................................................................ - 221 1S325110002H8WD615.50 发动机总成（213kW 国产泵工程版）-配气机构 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - valve timing mechanism............................................................................. - 223 1S325110002H8WD615.50 发动机总成（213kW 国产泵工程版）-喷油泵和高压油管 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - fuel injection-pump and high-pressure oil pipe.......................................... - 226 1S325110002H8WD615.50 发动机总成（213kW 国产泵工程版）-气缸盖 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - cylinder head .............................................................................................. - 229 1S325110002H8WD615.50 发动机总成（213kW 国产泵工程版）-气缸体（二） 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - cylinder block（II） .................................................................................. - 232 1S325110002H8WD615.50 发动机总成（213kW 国产泵工程版）-气缸体（三） 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) -cylinder block（III）.................................................................................. - 234 1S325110002H8WD615.50 发动机总成（213kW 国产泵工程版）-气缸体（一） 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - cylinder block （I） ................................................................................. - 237 1S325110002H8WD615.50 发动机总成（213kW 国产泵工程版）-曲轴飞轮 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - crankshaft flywheel .................................................................................... - 240 1S325110002H8WD615.50 发动机总成（213kW 国产泵工程版）-水泵 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - water pump................................................................................................. - 242 1S325110002H8WD615.50 发动机总成（213kW 国产泵工程版）-油底壳 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - oil pump ..................................................................................................... - 244 -

-9-

1S325110002H8WD615.50 发动机总成（213kW 国产泵工程版）-油管 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - fuel oil pipe ................................................................................................ - 246 1S325110002H8WD615.50 发动机总成（213kW 国产泵工程版）-张紧轮 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - tensioner ..................................................................................................... - 248 1S325124002H1 后桥（5.73，加宽，铸钢）-后桥壳及主减（二） 1S325124002H1 Rear axle (5.73, widened, cast steel) - rear axle housing and main reducer（II）................................................................................................................. - 250 1S325124002H1 后桥（5.73，加宽，铸钢）-后桥壳及主减（一） 1S325124002H1(5.73, widened, cast steel) - rear axle housing and main reducer (I) ....................................................................................................................................... - 251 1S325124002H1 后桥（5.73，加宽，铸钢）-后桥制动器 1S325124002H1 Rear axle (5.73, widened, cast steel) - rear axle brake.......................................................... - 254 1S325124002H1 后桥（5.73，加宽，铸钢）-轮边减速器组件 1S325124002H1 Rear axle (5.73, widened, cast steel) - hub reduction gear module............................ - 256 1S325125002H1 中桥（5.73，加宽，铸钢）-轮边减速器组件 1S325125002H1 Intermediate axle (5.73, widened, cast steel)- hub reduction gear module ................... - 258 1S325125002H1 中桥（5.73，加宽，铸钢）-中桥制动器 1S325125002H1 Intermediate axle (5.73, widened, cast steel) - intermediate axle brake................................ - 262 1S325125002H1 中桥（5.73，加宽，铸钢）-中桥主减及贯通轴 1S325125002H1 Intermediate axle (5.73, widened, cast steel)- intermediate axle main reduction and -through shaft ........................................................................... - 265 1S325125002H1 中桥（5.73，加宽，铸钢）-中桥总成含差速锁及减振器壳 1S325125002H1 Intermediate axle (5.73, widened, cast steel) - intermediate axle assy including differential lock and shock absorber housing............................................ - 269 1S32533000401 前轴(7.5T,手调臂,转向节臂右置)-1 1S32533000401 Front axle (7.5T, w/hand adjusting arm, RH knuckle arm)-1 ........................................................... - 271 1S32533000401 前轴(7.5T,手调臂,转向节臂右置)-2 1S32533000401 Front axle (7.5T, w/hand adjusting arm, RH knuckle arm )-2 ..................................................... - 275 -

- 10 -

1S3253356F001制动管路-干燥器组件(带消声器) Braking pipe line- air dryer assembly (with muffler) 3 6

5

4

3 2

7 1

8 10

9

12

14 13

11 8 9 10 15

-1-

1S3253356F001 制动管路-干燥器组件(带消声器)

Braking pipeline- air dryer assembly (with muffler) 适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）

标号 No.

零件代号

零件名称及规格

用量

Part Name and Spec.

Part Code

Total Braking pipeline- air dryer assembly

1

1S3253356F001

制动管路-干燥器组件(带消声器)

1

1417035600071

干燥器角形支架

Dryer angular bracket

1

2

Q40312

弹簧垫圈

Spring washer

3

3

Q151C1230

六角头螺栓-细牙

Hexagon head bolt- fine thread

6

4

Q40112

平垫圈

Flat washer

3

5

Q40512

重型弹簧垫圈

Heavy-duty spring washer

3

6

Q340B12

1 型六角螺母

Hexagon nut - Type 1

3

7

1513335609006

组合式空气干燥器总成

Combined air dryer assy

1

8

NMO20×2.65G

O 型橡胶密封圈

Rubber O-ring seal

2

9

1417035600120

密封垫

Gasket

2

10

Q351B22T15

六角薄螺母-细牙

Hexagon thin nut-fine thread

2

11

1417035600031

测试接头

Test connector

1

12

1417035643002

卡套式三通接头体

Ferrule-type tee union (body)

1

13

Q80408

卡套式端直通接头

Ferrule-type straight pipe connector

1

14

1417035600159

密封垫

Gasket

1

15

1417035600058

卡套式隔壁直角接头体

(with muffler)

Ferrule-type bulkhead right-angle connector (body)

1

-2-

车型 Vehicle Model 3253DLPJE0RZA01

用量 Total

车型 Vehicle Model

用量 Total


用量 Total


1S4253356A001 制动管路-继动阀组件 Brake pipeline-relay valve module

7 7

4

4

6

6 1 5

4

3

2

8 18

9

9 10

10

11 17

9 12 13

10

10 9

9 14

16

-3-

15

1S4253356A001 制动管路-继动阀组件 Brake pipeline-relay valve module 适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）标

零件代号

号

用零件名称及规格

No.

量

Part Name and Spec.

Part Code

1S4253356A00

Tot

车型

al

Vehicle Model

1

1

制动管路-继动阀组件

Brake pipeline-relay valve module

1

1125135680099

继动阀支架

Relay valve

1

2

Q150B1045

六角头螺栓

Hexagon head bolt

2

3

Q40310

弹簧垫圈

Spring washer

2

4

Q40110

平垫圈

Flat Washer

4

5

Q340B10

1 型六角螺母


2

6

Q40308

弹簧垫圈

Spring washer

2

7

Q340B08

1 型六角螺母


2

8

1417035600174

卡套式端直通异径接头体

Ferrule-type straight reducing connector (body)

1

9

1417035600120

密封垫

Gasket

4

10

NMO20X2.65G


Rubber O-ring seal

4

11

NMO14×2.65G


Rubber O-ring seal

1

12

Q351B16T15



1

13

1417035600172

卡套式直角接头

Ferrule-type right-angle connector

1

14

Q351B22T15



3

15

1324035680019

卡套式端直角接头体

Straight t-ferrule type

1

16

1417035600020

卡套式三通接头

Ferrule-type Tee union

1

17

1425335601038

中桥继动阀(带消声器)

Middle axle relay valve (w/muffler )

1

18

Q617B22

六角头螺塞

Hexagon head plug screw

1

-4-

3253DLPJE-0RZA 01

用量

车型

用量

车型

用量

车型

Total

Vehicle

Total

Vehicle

Total

Vehicle

Model

Model

Model

1S4253356B001制动管路-差动阀组件-1（差动阀总成(脚制动)） Brake pipe line- differential valve module-1 (Differential valve assy (foot braking))

1

3 4

5 6

左纵梁 LH longitudinal member

5

2

6

10 8

7

15 11 8

8

7

7

11 13

9

7 8

7 8 11

11

12

14

-5-

1S4253356B001 制动管路-差动阀组件-1（差动阀总成(脚制动)） Braking pipeline- differential valve module-1 (Differential valve assy (foot braking)) 标号 No.

适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）零件代号


用量

Part Name and Spec.

Part Code

Total


1S4253356B001

制动管路-差动阀组件

Braking pipeline- differential valve module

1

3253DLPJE-

1425335628001

差动阀总成(脚制动)

Differential valve assy (foot braking)

1

0RZA01

1

Q150B1035

六角头螺栓

Hexagon head bolt

2

2

1425335601036

继动阀支架

Relay valve

1

3

Q40310

弹簧垫圈

Spring washer

2

4

Q340B10

1 型六角螺母


2

5

Q340B08

1 型六角螺母


2

6

Q40308

弹簧垫圈

Spring washer

2

7

NMO20×2.65G


Rubber O-ring seal

5

8

1417035600120

密封垫

Gasket

6

9

1324035600006



1

10

1417035600177

卡套式端直通接头体

Ferrule-type straight connector

1

11

Q351B22T15



3

12

1324035680019



1

13

14183356B2801

双向继动阀(带消声器)

Two-way relay valve (w/muffler )

1

14

1417035600020

卡套式三通接头

Ferrule-type Tee union

1

15

1417035600174



1

-6-

用量 Total


用量 Total


用量 Total


1S4253356B001制动管路-差动阀组件-2（差动阀总成(手制动)） Brake pipe line- differential valve module-2(Differential valve assy (hand braking))

3 4 1 5 6 5

2

6

9

8 7

10 8

7

7

8 11 13

9

7

7

8

8

11

10

12

-7-

1S4253356B001 制动管路-差动阀组件-2（差动阀总成(手制动)） Braking pipeline- differential valve module-2(Differential valve assy (hand braking)) 适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）标号 No.

零件代号


用量

Part Name and Spec.

Part Code

Total


1S4253356B001

制动管路-差动阀组件

Braking pipeline- differential valve module

1

3253DLPJE-

1425335628002

差动阀总成(手制动)

Differential valve assy (hand braking)

1

0RZA01

1

Q150B1035

六角头螺栓

Hexagon head bolt

2

2

1425335601036

继动阀支架

Relay valve

1

3

Q40310

弹簧垫圈

Spring washer

2

4

Q340B10

1 型六角螺母


2

5

Q340B08

1 型六角螺母


2

6

Q40308

弹簧垫圈

Spring washer

2

7

NMO20X2.65G


Rubber O-ring seal

5

8

1417035600120

密封垫

Gasket

5

9

1324035600006



2

10

1417035600174



2

11

Q351B22T15



2

12

1417035600027

卡套式端直角异径接头体

Ferrule-type right-angled reducing connector

1

13

14183356B2801

双向继动阀(带消声器)

Two-way relay valve (w/muffler )

1

-8-

用量 Total


用量 Total


用量 Total


1S325139403H3铭牌(普通出口车用) Nameplate (for ordinary export vehicle)

1

2

-9-

1S325139403H3 铭牌(普通出口车用)

Nameplate (for ordinary export vehicle) 适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）

标号

零件代号零件名称及规格

No.

车型用量

Part Name and Spec.

用量车型

Part Code Total 1S325139403H3

铭牌(普通出口车用)

Nameplate (for ordinary export vehicle)

1

3253DLPJE-

1

1325139480038

铭牌(普通出口车用)

Nameplate (for ordinary export vehicle)

1

0RZA01

2

Q4400310

开口型扁圆头抽芯铆钉

Self-plugging rivet , split type (w/round head)

4

- 10 -

Vehicle Total

Vehicle Model

车型用量 Vehicle Total

Model

车型用量 Vehicle Total

Model

Model

1S325313100H1散热器

Radiator

1

3 14 4

5

2

12

10

9 6 7

11

8

3

4

4

13 15

5 17

5

16

2

7

8

18

1 4

5 19 19

20

4

7

5

23 8

21 22

- 11 -

5 3

4

24

1S325313100H1 散热器

Radiator 适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）

标号 No.

零件代号

Part Code


Part Name and Spec.

用量 Total

1S325313100H1

散热器

Radiator

1

1

1125113106001

散热器带护风罩总成

Radiator with fan cowl assy

1

2

1417013100019

管箍

Pipe hoop

2

3

Q340B08

1 型六角螺母


2

4

Q40308

弹簧垫圈

Spring washer

21

5

Q40108

平垫圈

Flat Washer

17

6

Q150B1050

六角头螺栓

Hexagon head bolt

1

7

Q40310

弹簧垫圈

Spring washer

4

8

Q40110

平垫圈

Flat Washer

4

9

Q150B0840

六角头螺栓

Hexagon head bolt

1

10

1417013100008

水管固定支架

Fixing bracket , water pipe

1

11

Q150B0830

六角头螺栓

Hexagon head bolt

1

12

1417013100012

托架

Bracket

1

13

1417013100018

垫块一

Backing pad I

2

14

1417013100020

垫块二

Backing pad II

1

15

Q150B0860

六角头螺栓

Hexagon head bolt

1

16

Q150B1080

六角头螺栓

Hexagon head bolt

1

17

1417013100022

水管限位套

Water pipe stop collar

1

18

1124113100005

塑料副水箱

Plastic auxiliary water tank

1

19

Q150B0825

六角头螺栓

Hexagon head bolt

8

20

Q150B1020

六角头螺栓

Hexagon head bolt

2

21

1124113100006

副水箱支撑板

Auxiliary radiator board

1

22

Q340B10

1 型六角螺母


2

23

1124113100004

副水箱支架

Auxiliary water tank bracket

1

24

Q150B0816

六角头螺栓

Hexagon head bolt

6

- 12 -

车型 Vehicle Model 3253DLPJE-0RZA01

用量 Total


用量 Total


用量 Total


1S325313300H1散热器软管 Radiator hose 17

7 8 9

7 8 9

4

11 12

1

1

17 3

14

10

1

3

13

17

10 2

17 3

15

5 3

1 6

1 20 10 19 9

8

7

16 17

17 18

- 13 -

1S325313300H1 散热器软管 Radiator hose 标号 No.



Part Code

Part Name and Spec.

用量

车型

用量

Total

Vehicle Model

Total

3253DLPJE-0RZA01

1S325313300H1

散热器软管

Radiator hose

1

1

Q67516

A 型蜗杆传动式软管环箍

Worm driven hose hoop, type A

8

2

1322813300005

散热器出气软管

Radiator vent hose

1

3

Q67545



4

4

1325113302003

发动机出水软管

Engine water outlet hose

1

5

1424113380007

冷却水软管 1

Cooling water hose 1

1

6

1417113300316

发动机出气软管

Engine exhaust hose

1

7

Q340B08

1 型六角螺母


6

8

Q40308

弹簧垫圈

Spring washer

6

9

Q40108

平垫圈

Flat Washer

6

10

Q150B0820

六角头螺栓

Hexagon head bolt

6

11

1424113380010

出气软管

Vent hose

1

12

Q67407200

塑料紧固带

Plastic tightening belt

6

Q67407300

塑料紧箍带


3

13

1325113380101

副水箱出水管

Auxiliary radiator water outlet pipe

1

14

1325313380001

冷却水管

Cooling water pipe

1

15

1417013301001

发动机进水软管

Engine water inlet hose

1

16

1417013301002

发动机进水管焊合

Engine water intake pipe welded part

1

17

Q67560



6

18

1325113302002

散热器出水软管

Radiator water-outlet hose

1

19

1138113300011

冷却水软管支架

Cooling water hose

1

20

1138113300012

单管夹片

Pipe clamp

1

- 14 -


用量 Total


用量 Total


1S325322001H1传动轴（2根，110X6，6X4）Propeller shaft （2，110X6，6X4） Input flange end，rear axle assy

intermediate axle assy

Output flange end, gearbox

- 15 -

1S325322001H1 传动轴（2 根，110X6，6X4）Propeller shaft （2，110X6，6X4）适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）

标

零件代号

号


Part Code

No.

1S325322001H 1

传动轴（2 根，110X6，6X4）

Part Name and Spec.

用量

车型

用量

Total

Vehicle Model

Total

1

Propeller shaft（2，110X6，6X4）

1

Q151B1455TF2


Hexagon head bolt, fine thread

12

2

1417122080005

自锁螺母

Self-locking nut

12

3

1325322080001

前传动轴带中间支撑总成

Front propeller shaft with middle assy

1

4

Q151B1435



2

5

Q151C1230



3

6

1125122080062

支承角板

Bearing angle plate

1

7

1117022000006

自锁螺母

Self-locking nut

3

8

Q40114

平垫圈

Flat Washer

4

9

1117022000005

自锁螺母

Self-locking nut

2

10

1424122080032

传动轴总成

Propeller shaft assy

1

11

1417022000003

六角螺栓

Hexagon bolt

16

12

1417022000004

自锁螺母

Self-locking nut

16

13

1424222000003

中后桥传动轴总成

Rear middle axle propeller shaft assy

1

- 16 -

3253DLPJE-0RZA 01


用量 Total


用量 Total


1S325816100H1离合器装置（潍柴）Clutch device (WD)

3 4

1

2

5 3 6

- 17 -

1S325816100H1 离合器装置（潍柴）Clutch device (WD) 标号 No.



Part Name and Spec.

Part Code

用量

车型

用量

Total

Vehicle Model

Total

3253DLPJE-0RZA01

1S325816100H1

离合器装置（潍柴）

Clutch device (WD)

1

1417116180401

离合器从动盘总成

Clutch driven disc assy

1

2

1417116100402

离合器盖及压盘总成

Clutch cover and pressure plate assy

1

3

Q41810

波形弹垫

Wave spring washer

12

4

Q150B1085

六角螺栓

Hexagon bolt

10

5

Q1201090F3

双头螺柱

Stud

2

6

Q340B10

1 型六角螺母


2

- 18 -


用量 Total


用量 Total


1S11333644002前部灯具-底盘部分 Front lamp (Chassis Portion) 5 7 6

4

2

3

1

- 19 -

3

2

1S11333644002 前部灯具-底盘部分标号 No.

零件代号

Front lamp (Chassis Portion) 适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）


Part Code

Part Name and Spec.

用量

车型

用量

车型

用量

车型

用量

车型

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

1S11333644002

前部灯具-底盘部分

Front lamp (Chassis Portion)

1

3253DLPJE-

1

1512336400006

右侧转向灯总成

RH Side steering lamp assy

1

0RZA01

2

Q40105

平垫圈

Flat washer

4

3

Q40305

弹簧垫圈

Spring washer

4

4

Q360B05

六角螺母

Hexagon nut

4

5

Q1461035

六角头螺栓、弹簧垫圈

Hexagon

和平垫圈组合件

and flat washer combination

1113336404001

左前组合灯总成

LH front combination lamp assy

1

1113336404002

右前组合灯总成

RH front combination lamp assy

1

1512336400005

左侧转向灯总成

LH Side steering lamp assy

1

6 7

bolt, spring washer

8

- 20 -

1S12403110000车轮及轮胎 Wheel and tyre

4

3 2

1

- 21 -

1S12403110000 车轮及轮胎标号 No.

零件代号

Wheel and tyre

适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）零件名称及规格

Part Code

Part Name and Spec.

用量

车型

用量

车型

用量

车型

用量

车型

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

1S12403110000

车轮及轮胎

Wheel and tyre

1

3253DLPJE-

1

1331131180001

螺母护罩

Nut shield

20

0RZA01

2

1417031100001

车轮总成

Wheel assy

11

3

1417031100003

气嘴延伸管及护帽

Air tap extension and cap

4

4

L12.00-2018G

轮胎总成

Tyre assy

11

- 22 -

1S12413670000信号装置

Signal device

4 1 2 3

1 2

5

3 4

6

3 2 1

7

4

2

4

3

1

- 23 -

1S12413670000 信号装置

Signal device

适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）标号 No.

零件代号


Part Code

Part Name and Spec.

用量

车型

用量

车型

用量

Total

Vehicle Model

Total

Vehicle Model

Total

3253DLPJE-0RZA01

1S12413670000

信号装置

Signal device

1

1

Q150B0825

六角头螺栓

Hexagon head bolt

4

2

Q40308

弹簧垫圈

Spring washer

4

3

Q40108

平垫圈

Flat Washer

4

4

Q340B08

1 型六角螺母


4

5

1124136700003

倒车蜂鸣器

Reverse buzzer

1

6

1124136700005

喇叭安装支架

Horn mounting bracket

1

7

1124136700001

高音喇叭

High sound horn

1

- 24 -


用量 Total


1S12413910000随车工具及附件 Vehicle-born tools and accessories 3 1

4

2 5

7 8

6

9 10

14

13 11

15

12

- 25 -

1S12413910000 随车工具及附件标号 No.

Vehicle-born tools and accessories 适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）

零件代号


Part Name and Spec.

Part Code

用量 Total


1S12413910000

随车工具及附件

Vehicle-born tools and accessories

1

3253DLPJE-0RZA

1

1124139180002

斯太尔后桥轴头螺母套筒

STYER rear axle end nut socket

1

01

2

1417039100025

轮胎撬棒

Tyre tommy bar

1

3

1417039100029

手动式液压千斤顶

Hand-operated hydraulic jack

1

4

1417039100030

千斤顶摇杆

Jack rocker

1

5

1417039100031

工具袋

Kit bag

1

6

1417039100059

工作灯

Hand lamp

1

7

1417039100060

黄油枪

Grease gun

1

8

1417039100065

三角警告牌总成

Delta Warning plate assy

1

9

1417139180001

485 后桥轴头螺母套筒

485 rear axle spindle head nut socket

1

10

NG1A300

活扳手

Monkey wrench

1

11

NGD200*1.2*8

一字槽螺钉旋具

Screwdriver, slotted head

1

12

NGS11001PB

十字槽螺钉旋具

Screwdriver, cross-slotted head

1

13

NGT32×12.5L

车轮螺母套筒

Wheel nut socket

1

NGT64×12.5L

轴头螺母套筒六角 64

NGY200

鲤鱼钳

14 15

Front axle shaft end nut socket hexagon 64

1

Slip t pliers

1

- 26 -

用量 Total


用量 Total


用量 Total


1S12511200001排气装置 Air exhaust device A 11 17

22 4

16 15

16 20

11

14

17 1

16

21

15

18

B 14

2

4

3 10

19 11

6

8 4

12 4

13 A

B

21

4

4

11

5 10

7 9 4

- 27 -

11

1S12511200001 排气装置

Air exhaust device 适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）

标号 No.

零件代号


用量

Part Name and Spec.

Part Code

Total


1S12511200001

排气装置

Air exhaust device

1

3253DLPJE-

1

1417012000002

密封垫

Gasket

1

0RZA01

2

1125112080011

排气管焊合 1

Air outlet pipe welded part I

1

3

Q150B1095

六角头螺栓

Hexagon head bolt

4

4

Q33210

2 型全金属六角锁紧螺母

Full-metal Hexagon locking nut, type 2

19

5

Q150B1050

六角头螺栓

Hexagon bolt

4

6

1417012080006

软管总成

Hose assy

1

7

1125112080012

排气管焊合 2

Air outlet pipe welded part II

1

8

1417012000009

排气消声器

Exhaust muffler

1

9

1417012000013

卡箍

Hoop

2

10

1417012000012

托架总成

Bracket assy

2

11

Q150B1030

六角头螺栓

Hexagon head bolt

10

12

1124112080007

U 型螺栓

U bolt

2

13

1124112080005

支座

ing base

2

14

Q150B1025

六角头螺栓

Hexagon head bolt

3

15

1417012000016

橡胶金属软垫

Rubber metal soft washer

4

16

Q40110

平垫圈

Flat Washer

10

17

Q40310

弹簧垫圈

Spring washer

8

18

1327112080005

排气尾管吊架

Hanging bracket, air exhaust tail-pipe

1

19

1324012000011

排气尾管

Exhaust tail pipe

1

20

Q150B1035

六角头螺栓

Hexagon head bolt

2

21

1417011900026

卡箍

Hoop

2

22

1125112000003

排气管支架

Air exhaust pipe

1

- 28 -

用量 Total


用量 Total


用量 Total


1S12511320103散热器悬置 Radiator suspension

15

6 5 4 3

14 13 1

15 14 7 13 8 16

6 12

5

11

4

10

3

9 12 11

2

10

7

9 8

- 29 -

1

1S12511320103 散热器悬置标号 No.

Radiator suspension 适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）

零件代号


Part Name and Spec.

Part Code

用量 Total

1S12511320103 1

Q1460820

2

散热器悬置

Radiator suspension

1

Hexagon head bolt, spring washer

2

六角头螺栓、弹簧垫圈和平垫组合件


1125113200001

散热器左拉杆

Radiator pull rod (LH)

1

3

1115013200003

散热器拉杆软垫

Radiator pull-rod soft washer

2

4

Q40208

大垫圈

Big washer

2

5

Q40308

弹簧垫圈

Spring washer

2

6

Q173B0838

六角头螺杆带孔螺栓

Eye bolt, hexagon head screw

2

7

Q387B08

六角开槽薄螺母

Thin hexagon slotted nut

2

8

Q5002025

开口销

Split pin

2

9

Q173B1275

六角头螺杆带孔螺栓

Eye bolt, hexagon head screw

2

10

Q40108

平垫圈

Flat Washer

4

11

1115013200001

散热器软垫

Radiator soft washer

2

12

1124113200003

套筒

Socket

2

13

1124113200002

散热器上软垫

Radiator upper soft washer

2

14

Q381B12

1 型六角开槽螺母-细牙

Hexagon slotted nut, fine thread, type 1

2

15

Q5003232

开口销

Split pin

2

16

1125113200002

散热器右拉杆

Radiator RH pull-rod

1

- 30 -


用量 Total


用量 Total


用量 Total


1S12533530001驻车制动操纵机构-驾驶室部分 Parking brake control device (cabin) 2 3

1

14

12

15

3 13

16 17

4

18 5 11 19

20

30

22 21

6 29 23

7 25

24

26 31 8 9 10

- 31 -

16 28

27

1S12533530001 驻车制动操纵机构-驾驶室部分标号 No.

Parking brake control device (cabin) 适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）

零件代号


用量

Part Name and Spec.

Part Code

Total 1S12533530001

驻车制动操纵机构-驾驶室部分

Parking brake control device (cabin)

1

1

1315035300005

手制动阀总成

Hand brake valve assy

1

2

Q150B825

六角头螺栓

Hexagon head bolt

2

3

Q40308

弹簧垫圈

Spring washer

3

4

1417035600167

密封垫

Gasket

3

5

1417035600176

卡套式端直通变径接头

Ferrule-type straight reducing connector

3

6

1124135600034

尼龙管总成-隔壁直角至手

Nylon pipe assy, from bulkhead angle to

阀1口

hand brake valve port 1

7

1124135600035

尼龙管总成-隔壁直角至手

Nylon pipe assy, from bulkhead angle to

阀 21 口

hand brake valve vent 21

8

1417035600205


9

Q40314

弹簧垫圈

Spring washer

1

10

Q351B14T15



6

11

Q340B08

1 型六角螺母


1

12

1417135600164

三管夹下支架

3-pipe lower

2

13

Q40108

平垫圈

Flat Washer

1

14

Q150B0845

六角头螺栓

Hexagon head bolt

1

15

Q150B0625

六角头螺栓

Hexagon head bolt

2

16

Q40306

弹簧垫圈

Spring washer

6

17

Q40106

平垫圈

Flat Washer

2

18

1124135600044

支架板

ing plate

1

19

Q340B06

1 型六角螺母


2

Ferrule-type connector

bulkhead

right-angle

(body)

- 32 -

1 1 3


用量 Total


用量 Total


用量 Total


标号 No.



Part Name and Spec.

Part Code

20

1124135600043

21

1425335607010

22

1425335607008

23

用量

车型

用量

Total

Vehicle Model

Total

1

支架板

ing plate

钢管总成-手制动阀 21 口至

Steel pipe assy ¨- manual brake valve port

支架

21 to

钢管总成-软管支架至手制

Steel pipe assy, from hose to hand

动阀 1 口

brake valve port 1

1417035600159

密封垫

Gasket

1

24

1124135600024

卡套式隔壁三通接头体

Bulkhead Tee union--body

1

25

1124135600020


26

1425335607011

支架板

ing plate

1

27

Q174B0625

十字槽凹穴六角螺栓

Hexagon bolt (w/ cross slot£©

2

28

Q40006

小垫圈

Small washer

2

29

1124135680100

堵盖

Cap

1

30

1320835680314

卡套式隔壁四通接头体

31

1425335607015

尼龙管总成-支架至四通

Ferrule-type bulkhead right-angle connector

1 1

2

(body)

Ferrule-type bulkhead stRH connector (body) Nylon pipe assy, to four-way t

- 33 -

1 1


用量 Total


用量 Total


1S13813610001 蓄电池 Battery

16

15

12 11 16

15

16

10 9 11

5

8 6 7

14

6

12 13 2 1 18

5

17

2 3 1

- 34 -

4

1S13813610001 蓄电池

Battery


零件代号


Part Name and Spec.

Part Code

用量

车型

用量

Total

Vehicle Model

Total

1S13813610001

蓄电池

Battery

1

3253DLPJE-

1

1417036100009

紧固拉杆

Tightening pull rod

4

0RZA01

2

1417036100010

橡胶缓冲块

Rubber buffer block

4

3

Q40008

小垫圈

Small washer

4

4

Q33408


Full-metal Hexagon locking nut, Type 1

4

5

1417036100018

夹紧支架

Clamping

2

6

1417036100017

蓄电池

Battery

2

7

1417036100005

隔板

Baffler

1

8

Q5005060

开口销

Split pin

2

9

1417036100007

蓄电池箱盖

Battery case cover

1

10

1417036100008

拉钩

Pull hook

2

11

Q150B1645

六角头螺栓

Hexagon head bolt

6

12

Q40116

平垫圈

Flat Washer

8

13

Q150B16200

六角头螺栓

Hexagon head bolt

2

14

1417036100003

蓄电池箱体

Battery case

1

15

1417036100016

蓄电池支架

Battery bracket

2

16

Q33416

Ⅰ型全金属六角锁紧螺母


8

17

1417036100006

橡胶垫板

Rubber backing plate

1

18

1417036100014

穿线护套

Wire shield bush

1

- 35 -


用量 Total


用量 Total


1S32413650000后位灯具 Rear lamps

6 5

6

4

3 2

5

1

4

20

20

6

5

4 19

5

65 4

4 21

18 17 16

15

- 36 -

5

4

1S32413650000 后位灯具

Rear lamps


零件代号 Part Code 1S32413650000


Part Name and Spec.

用量 Total

1

1124136500006

后位灯具后雾灯

Rear fog lamp

1

2

Q150B0625

六角头螺栓

Hexagon head bolt

8

3

1417036500016

后雾灯固定支架

Fixing bracket, rear fog lamp

1

4

Q40106

平垫圈

Flat washer

20

5

Q40306

弹簧垫圈

Spring washer

20

6

Q340B06

1 型六角螺母


16

7

1124136500011

侧标志灯

Side mark lamp

4

8

Q34006

螺母

Nut

4

9

Q40308

弹簧垫圈

Spring washer

4

10

Q40108

平垫圈

Flat Washer

4

11

1325136500011 Q150B0630

后示廓灯

Rear clearance lamps

六角头螺栓

Hexagon head bolt

2 4

1B24937176003

细波纹管线夹

Fine corrugated pipe clamp

2

1B24937176006

细波纹管线夹

Fine corrugated pipe clamp

4

14

1324136500001

倒车灯

Reversing lamp

1

15

左组合后灯

LH combined rear lamp

1

16

1324036500001 Q34010

1 型六角螺母


6

17

Q40310

弹簧垫圈

Spring washer

6

18

Q40110

平垫圈

Flat Washer

6

19

Q150B1030

六角头螺栓

Hexagon head bolt

6

20

Q340B08

1 型六角螺母


4

21

1325136500001

左后组合灯固定支架

Fixing , LH rear combined lamp

1

22

1325136500002

右后组合灯固定支架

Fixing , RH rear combined lamp

1

23

1324036500002

右组合后灯

RH combined rear lamp

1

12 13

Rear lamps

- 37 -


用量 Total


用量 Total


用量 Total


1S32413660000开关 Switch 6

11

1 5

5 7

8

2

2

9 4

10

4

3

3

5 4

3 14 13

17

15 16

20

12 19

18

- 38 -

21

22

1S32413660000 开关

Switch 适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）

标号 No.

零件代号


用量

车型

用量

Total

Vehicle Model

Total

Part Name and Spec.

Part Code 1S32413660000

开关

Switch

1

3253DLPJE-

1

1120836600001

电磁阀组件

Solenoid valve module

1

0RZA01

2

Q150B0830

六角头螺栓

Hexagon head bolt

4

3

Q40108

平垫圈

Flat Washer

6

4

Q40308

弹簧垫圈

Spring washer

6

5

Q340B08

1 型六角螺母


6

6

1124136600001

起动继电器

Startup relay

2

7

Q2140616

十字槽盘头螺钉

Pan head screw (w/cross slot)

4

8

Q40106

平垫圈

Flat washer

4

9

Q40306

弹簧垫圈

Spring washer

4

10

Q340B06

1 型六角螺母


4

11

1124136600010

电磁阀组件

Solenoid valve module

1

12

1417036600001

蓄电池总开关

Battery main switch

1

13

Q150B0835

六角头螺栓

Hexagon head bolt

2

14

1417036600008

轮间闭锁指示灯开关

Differential lock switch between wheels

3

15

1417036600003

空档开关

Neutral position switch

1

16

1417036600009

空滤器堵塞报警开关

Alarm switch for air filter blocking

1

17

1417036600005

倒档开关

Reverse gear switch

2

18

1417036600007

高低档开关

Range gear switch

1

19

1124136600011

副起动开关

Auxiliary start switch

1

20

1124136600004

车身锁止报警开关

Alarm switch, body tilting lock

1

21

1325836600005

密封罩

Seal hood

1

22

1124136600012

水位报警开关

Water level alarm switch

1

- 39 -


用量 Total


用量 Total


1S32511010103动力总成悬置 Power train assy suspension 21 2

21 2

22

23 11

1

2

26 3

11 27

24 24

10

11

12

11

2

4 8

23

25 2 5

9 10

7

2

14

3

6

25 17

8

15 12 11

20 18

3

19 28 2 16

- 40 -

1S32511010103 动力总成悬置 Power train assy suspension 适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）标号 No.

零件代号


Part Code

用量

Part Name and Spec.

Total


1S32511010103

动力总成悬置

Power train assy suspension

1

3253DLPJE-

1

Q340B12

1 型六角螺母


10

0RZA01

2

Q40512

重型弹簧垫圈


20

3

Q40112

平垫圈

Flat washer

12

4

1122910180002

发动机前悬右支架

Engine front mounting (RH)

1

5

Q150B0820

六角头螺栓

Hexagon head bolt

4

6

Q40308

弹簧垫圈

Spring washer

4

7

Q40108

平垫圈

Flat washer

4

8

1417010100003

发动机前支撑

Engine front strut

2

9

1325110102004

前悬右支撑

RH strut, front suspension

1

10

Q150B1435

六角头螺栓

Hexagon head bolt

1

11

Q40514

重型弹簧垫圈


8

12

Q40114

平垫圈

Flat washer

2

13

Q150B1230

六角头螺栓

Hexagon head bolt

2

14

1122910180003

发动机前悬左支架

LH , Engine front mounting

1

15

1325110102005

前悬左支撑

LH strut, front suspension

1

16

Q150B1255

六角头螺栓

Hexagon head bolt

2

17

Q33216



4

18

Q33214



1

19

Q150B1650

六角头螺栓

Hexagon head bolt

2

20

Q150B1470

六角头螺栓

Hexagon head bolt

1

Q150B1640

六角头螺栓

Hexagon head bolt

2

Q151C1245TF2



4

21

- 41 -

用量 Total


用量 Total


用量 Total


1S32511010103 动力总成悬置 Power train assy suspension 标号 No.



Part Code

Part Name and Spec.

用量

车型

用量

Total

Vehicle Model

Total

22

1325110102003

右支撑托架

RH strut bracket

1

23

Q151B1440TF2



4

24

1417010100006

楔形支撑总成

Cuneiform assy

2

25

Q151C1250TF2



4

26

1325110102002

左支撑托架

LH strut bracket

1

27

Q151B1435TF2



2

28

Q150B1455

六角头螺栓

Hexagon head bolt

1

- 42 -


用量 Total


用量 Total


1S32511110104燃油箱 Fuel tank 6 A

7 6 6

8

5

4

7 6

14

8

9 10 4

5

3

11 9

10

11

3

A

12

2 1

12

13

- 43 -

1S32511110104 燃油箱标号

零件代号

零件名称及规

No.

Part Code

格

Fuel tank

适用车型及用量（件）Applicable vehicle model and needed quantity（PCS） Part Name and Spec.

用量

车型

用量

车型

用量

车型

用量

车型

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

3253DLPJE-0RZA01

1S32511110104

燃油箱

Fuel tank

1

1

1325811180002

燃油箱

Fuel tank

1

2

1124111100003

燃油箱锁总成

Fuel tank lock assy

1

3

1120611180005

橡胶带垫

Rubber strap cushion

2

4

1332111180004

紧固带总成

Tightening belt assy

2

5

Q5101085

销轴

Axis pin

2

6

Q151B1655TF2

六角头螺栓

Hexagon head bolt

4

7

Q5003214

开口销

Split pin

2

8

Q40110

平垫圈

Flat Washer

2

9

Q40316

弹簧垫圈

Spring washer

4

10

Q341B16

1 型六角螺母


4

11

1120611180003

支架总成

assy

2

12

Q340B10

1 型六角螺母


4

13

1417011100008

油箱垫板 I

Fuel tank backing plate I

2

14

1B24937600072

燃油传感器

Fuel sensor

1

- 44 -

1S32511140104供油系管路Fuel supply system pipeline 1S32511150104燃油滤清器 Fuel filter 1S32511150104燃油滤清器 Fuel filter

A 10

6 7

11

9 8

7 6 A

- 45 -

1S32511140104 供油系管路 Fuel supply system pipeline 标号 No.

1S32511150104 燃油滤清器 Fuel filter



Part Code

Part Name and Spec.

用量

车型

用量

Total

Vehicle Model

Total

1S32511140104

供油系管路

Fuel supply system pipeline

1

3253DLPJE-0RZA

1S32511150104

燃油滤清器

Fuel filter

1

01

1

1325111404002

供油管-燃油箱至滤清器

Fuel supply pipe, from fuel tank to filter

1

2

1325811480004

回油管

Oil return pipe

1

3

Q67407100

塑料紧箍带


3

4

1420836290002

过孔胶圈

Hole rubber grommet

2

5

1325111404003

供油管-滤清器至油泵

Fuel supply pipe, from filter to fuel pump

1

6

NRL14X1.5

铰接螺栓

Hinge bolt

2

7

Q40114T4F

平垫圈

Flat washer

2

8

Q340B10

1 型六角螺母


2

9

Q40310

弹簧垫圈

Spring washer

2

10

Q150B1095

六角头螺栓

11

1417011580002

燃油滤清器

Fuel filter

1

12

1417011400003

放气管

Vent pipe

1

Hexagon head bolt

2

- 46 -


用量 Total


用量 Total


1S32511190301进气装置-1 Air intake device-1 17 16 15

9

1

12

14 13

11 2

8 10 3

9 4 5 8

- 47 -

6

7

1S32511190301 进气装置-1 标号 No.

Air intake device-1 适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）

零件代号


Part Code

Part Name and Spec.

Air intake device

用量

车型

用量

车型

用量

车型

用量

车型

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

1

3253DLPJE-

1S32511190301

进气装置

1

1325111981224

高位进气管带支架总成

2

1325111981220

沙漠空滤器总成

Desert air filter assy

1

3

1325111981221

沙漠空滤器支架总成

Desert air filter assy

1

4

Q150B1445

六角头螺栓

Hexagon head bolt

4

5

Q40114

平垫圈

Flat washer

4

6

Q40314

弹簧垫圈

Spring washer

4

7

Q340B14

1 型六角螺母


4

8

Q67535



1

9

1327134000005

圆管夹

Circular-pipe clamp

1

10

1325111903038

空压机进气软管

Air compressor intake hose

1

11

1424211900002

卡箍

Hoop

5

12

Q675140



1

13

1325111910009

空滤器出气管

Outlet pipe, air filter

1

14

Q150B0830

六角头螺栓

Hexagon head bolt

1

15

Q40108

平垫圈

Flat washer

1

16

Q40308

弹簧垫圈

Spring washer

1

17

Q340B08

1 型六角螺母


1

High-mounted air intake pipe w/ bracket assy

1

- 48 -

0RZA01

1S32511190301进气装置-2 Air intake device-2

15

13 14 13

1 2

1 3

4

5 6

8

10

1 9 1 3

4

5

3

4

5 7

- 49 -

1S32511190301 进气装置-2 标号 No.

零件代号

Air intake device-2 适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）


Part Name and Spec.

Part Code

用量

车型

用量

车型

用量

车型

用量

车型

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

1S32511190301

进气装置

Air intake device

1

3253DLPJE-

1

1424211900002

卡箍

Hoop

5

0RZA01

2

1325111903004

中冷器出气软管

Charge air cooler air exhaust pipe

1

3

Q150B0820

六角头螺栓

Hexagon head bolt

12

4

Q40308

弹簧垫圈

Spring washer

12

5

Q40108

平垫圈

Flat washer

12

6

1325111980050

中冷器固定支架

Charge air cooler fixing bracket

1

7

1325111903050

中冷器固定支架

Charge air cooler fixing bracket

1

8

1325111980045

中冷器总成

Charge air cooler assy

1

9

1331111930032

连接软管

Connecting hose

1

10

1325111903005

中冷器进气钢管

Charge air cooler air intake pipe

1

11

Q150B1040

六角头螺栓

Hexagon head bolt

2

12

1325111903010

中冷器管固定支架

Fixing , charge air cooler

2

13

1320611980013

T 型卡箍

T type hoop

2

14

1417111981306

橡胶软管

Rubber hoses

1

15

Q340B10

1 型六角螺母


2

16

Q40310

弹簧垫圈

Spring washer

2

17

Q40110

平垫圈

Flat washer

2

18

1324211900009

中冷器管卡箍

Charge air cooler pipe hoop

2

- 50 -

1S32512950202后悬架（加强）Rear suspension(reinforced) 3 1 36

2

4

5

2

37

16 6

15 7

15

8

14

9 13

38

39 18

10

34 40

15 19

11

17

20 12

35

25

13

21

21 22

14

22

33

24

32 31

23

30 26 23 29

27 A

A 28

15 16

15

18

24 15

15

41

17

25 29 28

- 51 -

1S32512950202 后悬架（加强） Rear suspension(reinforced) 标号

零件代号

No.

Part Code


Part Name and Spec.

用量

车型

用量

车型

用量

车型

用量

车型

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

3253DLPJE-0RZA01

1S32512950202

后悬架（加强）

Rear suspension(reinforced)

1

1

Q151C1255



8

2

Q40312

弹簧垫圈

Spring washer

16

3

Q151C1250



8

4

1124029500018

调整板(三)

Adjusting plate (3)

4

5

1124029500016

调整板(一)

Adjusting plate (1)

8

6

1124029500017

调整板(二)

Adjusting plate (2)

4

7

1325129502011

导向板

Guide plate

4

8

1325129502012

后 U 型螺栓

U bolt (rear)

4

9

1325129502010

板簧压板

Leaf spring pressure plate

2

10

1124029500004

双头螺栓

Stud

28

11

1325129502009

平衡轴总成

Balance shaft assy

1

12

Q341B18

1 型六角螺母-细牙

Hexagon nut - type 1-fine thread

28

13

1325129502027

推力杆连接螺栓

Thrusting rod connecting bolt

2

14

1325129502016

上推力杆总成

Upper thrusting rod assy

2

15

1325129502024

自锁螺母

Self-locking nut

18

16

1325129502025



4

17

1325129502026



8

18

1325129502017

下推力杆总成

Lower thrusting rod assy

4

19

1325129502013

后钢板弹簧

Rear leaf spring

2

20

1325129502028



4

21

1124029500006

垫圈

Washer

8

22

1124029500007

自锁螺母

Self-locking nut

8

- 52 -

1S32512950202 后悬架（加强） Rear suspension(reinforced) 标号

零件代号

No.

Part Code


Part Name and Spec.

用量

车型

用量

车型

用量

车型

用量

车型

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

23

1417029500016

螺栓

Bolt

6

24

Q40116

平垫圈

Flat washer

6

25

1417022000004

自锁螺母

Self-locking nut

6

26

Q151C12100

六角螺栓－细牙

Hexagon bolt- fine thread

4

27

1117022000006

自锁螺母

Self-locking nut

4

28

1325129580007

后稳定杆胶套

Rear stabilizer rod bush bush

2

29

1417029500014

U 形连接板

U type connecting plate

2

30

1417029500018

后稳定杆吊架

Rear stabilizer rod hanger

2

31

1417029500015

后稳定杆衬套

Rear stabilizer rod bush

4

32

1417029500017

衬套

Bush

2

33

1325129580008

后稳定杆总成

Rear stabilizer rod assy

1

34

1325129502015

限位块支架

Limit stop

4

35

1325129502014

限位块

Limit stop

4

36

Q341B10


37

Q40310

38

Hexagon nut - type 1fine thread

16

弹簧垫圈

Spring washer

16

1117022000005

自锁螺母

Self-locking nut

16

39

Q151B1465



8

40

Q151B1460



8

41

1124029580016

T 型调整板

Adjusting plate,T type

8

- 53 -

1S32513150101备胎架 Spare wheel holder

2

1

3

- 54 -

1S32513150101 备胎架

Spare wheel carrier


零件代号


Part Code

Part Name and Spec.

用量

车型

用量

Total

Vehicle Model

Total

3253DLPJE-0RZA01

1S32513150101

备胎架

Spare wheel carrier

1

1

1117031580035

侧置备胎架总成

Side-set spare wheel carrier assy

1

2

Q151C1240

六角头螺栓－细牙


6

3

1117022000006

自锁螺母

Self-locking nut

6

- 55 -


用量 Total


用量 Total


1S32513561304制动管路-储气筒组件 Brake pipe line - air reservoir module 7

18

14

8

4 19

4

14

13 蓄电池箱体

3

3

15 16 17

12 9

4

7 3

9

22 23 24

22 23 24

A 22 23 24

5 4

3

2

4

3

29

28 27 7 26 D

30 C

D

1 B C

A

25

B

10

4

20 21

11 8

3

2

3

4

4 31

33 32 25 28 27 26

34

3

4 7

3

4 31 2

29

33

- 56 -

3

4

4 3 6

3

2

1S32513561304 制动管路-储气筒组件标号 No.

Braking pipeline - air reservoir module 适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）

零件代号


Part Name and Spec.

Part Code

用量

车型

用量

Total

Vehicle Model

Total

3253DLPJE-0RZA01

1S32513561304

制动管路-储气筒组件

Braking pipeline - air reservoir module

1

1

1324035600006



1

2

Q351B22T15



4

3

1417035600120

密封垫

Gasket

13

4

NMO20.0X2.65G

O 型密封圈

O-ring seal

13

5

1417035600040

再生储气筒

Regeneration air-reservoir

1

6

1417035600034

手动放水阀

Manual water drain valve

2

7

1417035680005

六角头螺塞


4

8

Q340B08

1 型六角螺母


7

9

Q40308

弹簧垫圈

Spring washer

7

10

Q150B0820

六角头螺栓

Hexagon head bolt

3

11

1417035600036

20L 储气筒固定支架

Fixing bracket, 20L air reservoir

1

12

Q40108

平垫圈

Flat washer

4

13

Q150B825

六角头螺栓

Hexagon head bolt

4

14

1417035600033

20L 储气筒紧箍带

Tightening belt, 20L air reservoir

2

15

Q218B0880

内六角螺栓

Hexagon socket-head bolt

2

16

1417035600038

拉紧销

Tightening pin

2

17

1417035600039

张紧销

Tensioning pin

2

18

1417035600174



1

19

1327135680018

20L 储气筒

20L air reservoir

1

20

1417035600178

直通接头

Straight t

1

21

1417035600031

测试接头

Test connector

1

22

Q340B10

1 型六角螺母


4

- 57 -


用量 Total


用量 Total


标号 No.



Part Name and Spec.

Part Code

用量

车型

用量

Total

Vehicle Model

Total

23

Q40310

弹簧垫圈

Spring washer

4

24

Q40110

平垫圈

Flat washer

4

25

Q150B0620

六角头螺栓

Hexagon head bolt

4

26

Q340B06

1 型六角螺母


4

27

Q40306

弹簧垫圈

Spring washer

4

28

Q40106

平垫圈

Flat washer

4

29

1417035600035

30L 储气筒垫块

Seat pad, 30L air reservoir

2

30

1417035600027

卡套式端直角异径接头体

Ferrule-type right-angled reducing connector

1

31

1417035600032

30L 储气筒紧箍带

Tightening belt, 30L air reservoir

2

32

1327135680017

40L 储气筒

40L air reservoir

2

33

1310835600031

三通接头

Tee union

2

34

1324035680020

卡套式异径直通接头


1

- 58 -


用量 Total


用量 Total


1S32531030101防护装置 Protective device 1 2 3 4 5

6 5

4

1

3

6 2

3 4 5

3 4 5 7 3 4 5 3

7

- 59 -

4

5

1S32531030101 防护装置

适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）

标号

零件代号

零件名称及规

Part Name and

No.

Part Code

格

Spec.

用量

车型

用量

车型

用量

车型

用量

车型

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

1S32531030101

防护装置

Protective device

Q150B1455

六角头螺栓

Hexagon head bolt

2

1325310301003

防护栏支架 1

Guard rail bracket 1

1

1325310301004

防护栏支架 2

Guard rail bracket 2

1

3

Q40114

平垫圈

Flat washer

8

4

Q40314

弹簧垫圈

Spring washer

8

5

Q340B14

1 型六角螺母


8

6

Q150B1440

六角头螺栓

Hexagon head bolt

4

7

1325310301002

防护栏

Guard rail

1

1 2

Protective device

3253DLPJE-0RZA01

- 60 -

1S32531620102离合器操纵装置 Clutch operation device B

14

15

16

8 7

D

13

6 4 5

11

1A

C 27 28

12 B

C

10

2

9

D

10 17

A 14 18

1

21 19

22 23 20

- 61 -

24 25 26

1S32531620102 离合器操纵装置

Clutch operation device 适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）

标号 No.

零件代号


Part Name and Spec.

Part Code

用量 Total


1S32531620102

离合器操纵装置

Clutch operation device

1

3253DLPJE-

1

1124116200005

前联接软管总成

Front connecting hose assy

1

0RZA01

2

1325316204002

分泵油管总成

Slave cylinder oil pipe assy

1

3

Q80220

卡套式管接头用六角薄螺母

Hexagon thin nut-ferrule type pipe connector

3

4

Q68608

单管夹片

Pipe clamp

1

5

Q150B0625

六角头螺栓

Hexagon head bolt

1

6

Q40106

平垫圈

Flat washer

1

7

Q40306

弹簧垫圈

Spring washer

1

8

Q340B06

1 型六角螺母


1

9

Q81814

卡套式铰接六角螺栓

Ferrule type hinge-ted Hexagon bolt

1

10

Q72314

密封垫圈

Gasket

2

11

Q150B1040

六角头螺栓

Hexagon head bolt

4

12

1325816280003

离合助力器总成

Clutch booster assy

1

13

1125116200004

助力缸支架

Clutch pressure cylinder

1

14

Q40110

平垫圈

Flat washer

6

15

Q40310

弹簧垫圈

Spring washer

4

16

Q340B10

1 型六角螺母


4

17

1417116200304

离合摇臂

Clutch rocker arm

1

18

Q33210



2

19

Q5101030

销轴

Axis pin

1

20

Q5003222

开口销

Split pin

1

21

Q150B0825

六角头螺栓

Hexagon head bolt

1

22

1417016200004

后软管支架

Rear hose

1

- 62 -

用量 Total


用量 Total


用量 Total


标号 No.



Part Name and Spec.

Part Code

用量

车型

用量

Total

Vehicle Model

Total

23

1417116200305

后联接软管总成

Rear connecting hose assy

1

24

Q40108

平垫圈

Flat washer

1

25

Q40308

弹簧垫圈

Spring washer

1

26

Q340B08

1 型六角螺母


1

27

Q40314

弹簧垫圈

Spring washer

2

28

Q151B1435



2

- 63 -


用量 Total


用量 Total


1S32531721501变速器操纵机构 Transmission operation mechanism

8 7

6

5 4

9

11 10

4

1 3 16

11.2

17

13

11.1

14 12 5

15

6 5

6

- 64 -

18

20

1S32531721501 变速器操纵机构 Gearbox operation mechanism 适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）标号 No.

零件代号


Part Name and Spec.

Part Code

用量 Total

车型 Vehicle Model 3253DLPJE-

1S32531721501

变速器操纵机构

Gearbox operation mechanism

1

1325317204005

伸缩杆总成

Retractable rod assy

1

2

Q33010

全金属六角法兰面锁紧螺母

Full metal hexagon flange locking-nut

1

3

Q1841080TF2

六角法兰面螺栓

Hexagon flange bolt

1

4

Q33410



5

5

Q5002022

开口销

Split pin

3

6

Q387B10

六角开槽薄螺母

Thin hexagon slotted nut

3

7

1325317207011

选档支架

Gear-selection

1

8

1424217200010

选档后支撑杆总成

Gear-selection rear struting rod assy

1

9

1125317207009

换档拉杆总成

Gearshift pull rod assy

1

10

1424217200007

选档拉杆总成

Gearselection pull rod assy

1

11

1425317207006

换档摇臂总成

Gearshift rocker arm assy

1

11.1

1424217200062

直衬套

Straight bush

1

11.2

1424217200063

L 型衬套

L-type bush

1

12

1424217200012

减噪垫圈

Noise-reducing washer

1

13

Q150B1055

六角头螺栓

Hexagon head bolt

1

14

Q40310

弹簧垫圈

Spring washer

6

15

1425317207008

四角支架总成

Four corner assy

1

16

1424217200013

厚垫圈

Thick washer

1

17

1424217300008

密封垫片

Gasket

1

18

Q1801070TF2

六角法兰面承面带齿螺栓

Indented bolt, w/hexagon flange bearing surface

2

19

Q150B1050

六角头螺栓

Hexagon head bolt

5

20

Q1801050TF2



1

1

- 65 -

0RZA01

用量 Total


用量 Total


用量 Total


1S32531751501变速器悬置 Gearbox suspension

2 3

5 1 10

8 7

11

3

12 3

12 5

4 6

- 66 -

11 9

10

1S32531751501 变速器悬置标号 No.

零件代号

Gearbox suspension


Part Code

Part Name and Spec.

用量

车型

用量

车型

用量

车型

用量

车型

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

3253DLPJE-0RZA01

1S32531751501

变速器悬置

Gearbox suspension

1

1

1122917500011

弹簧梁

Spring beam

1

2

Q350B12

六角薄螺母

Hexagon thin nut

1

3

Q340B12

1 型六角螺母


7

4

Q40212

大垫圈

Big washer

2

5

1115013200001

散热器软垫

Radiator soft washer

2

6

Q150B12110

六角头螺栓

Hexagon head bolt

1

7

1325317581009

弹簧梁连接支架

Spring beam connecting bracket

1

8

1325117510007

左托架

LH bracket

1

9

1325117500003

弹簧梁托架

Spring beam bracket

1

10

Q150B1245

六角头螺栓

Hexagon head bolt

6

11

Q40112

平垫圈

Flat washer

6

12

Q40312

弹簧垫圈

Spring washer

6

- 67 -

1S32532801501车架总成 Frame assy 12

12 11

9

11

13 10

10

29

B

A

29 6 29 4 5 3 A1

A2

18

17

20

B

19 1 2

15

- 68 -

21

33

1S32532801501 车架总成

Frame assy 适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）

标号 No.

零件代号


Part Name and Spec.

Part Code

用量

车型

用量

Total

Vehicle Model

Total

3253DLPJE-0RZA 1S32532801501

车架总成

Frame assy

1

1325328015001

车架总成

Frame assy

1

1

1417028000016

后稳定杆支座

Rear stabilizer rod seat

2

2

1325128002052

管状横梁总成

Tubular cross member assy

1

3

Q150B1440

六角头螺栓

Hexagon head bolt

2

4

Q340B14

1 型六角螺母


2

5

Q150B1645

六角头螺栓

Hexagon head bolt

2

6

Q340B16

1 型六角螺母


2

7

1325328015002

左纵梁总成

LH longitudinal member assy

1

8

1325328015003

右纵梁总成

RH longitudinal member assy

1

9

1325128080080

第一加强横梁总成

#1 cross beam assy

2

10

Q151B1445



24

11

Q40314

弹簧垫圈

Spring washer

24

12

Q341B14


Hexagon nut - type 1-fine thread

24

13

1325128080086

第六横梁总成

Sixth cross-member assy

1

14

1325128080092

第三加强横梁总成

#3 cross beam assy

1

15

1331128000038

中间支座 2-M16

Middle supprting base 2-M16

2

16

1325128080098

加强侧连接板

Reinforced side connecting plate

2

17

1325128002051

双头螺柱

18

1331128000040

六角头螺栓-非标

Hexagon head bolt- non-standand

14

19

Q40316

弹簧垫圈

Spring washer

24

20

Q151B1650



16

21

Q341B16

1 型六角螺母


8

Stud

8

- 69 -

01


用量 Total


用量 Total


1S32532801501 车架总成

Frame assy 适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）

标号 No.

零件代号


Part Code

Part Name and Spec.

用量

车型

用量

Total

Vehicle Model

Total

22

1325128080099

后加强横梁总成

Rear reinforcement beam assy

1

23

Q150B1445

六角头螺栓

Hexagon head bolt

12

24

Q40314

弹簧垫圈

Spring washer

12

25

Q33414

1 型全金属六角自锁螺母

26

Q150B1240

六角头螺栓

Hexagon head bolt

4

27

Q40312

弹簧垫圈

Spring washer

14

28

Q340B12

1 型六角螺母


4

29

Q4501446

半圆头铆钉

Half circular head rivet

42

30

Q4501458

半圆头铆钉


82

31

Q4501450

半圆头铆钉


46

32

Q4501242

半圆头铆钉


6

33

Q4501655

半圆头铆钉


6

Full-metal Hexagon self-locking

12

nut, Type 1

- 70 -


用量 Total


用量 Total


1S32532920401 前悬架(右舵)

Front suspension （RHD）

前

舵

B

A 2 3

1 9 10

3

11

14

4

31

7

6

19

15

10

9

32 50

8

33

30

34

50

21

B

30

8

8

35 8

A

36

22 37

8

8 28

51

A

39

8

18

22

23 24

18

23

18

28

41 42

48 19

19

22 40

17

29

38

49

23

20

18

12

8

8 10

13

5

8

16 17

47

43

46

44 45 44

- 71 -

27

25

9 26

10

1S32532920401 前悬架(右舵)

Front suspension （RHD）适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）

标号 No.

零件代号


Part Code

用量

Part Name and Spec.

Total


1S32532920401

前悬架(右舵)

Front suspension （RHD）

1

3253DLPJE-0RZA0

1

1424229200006

前稳定杆吊座

Front stabilizer rod hanging seat

2

1

2

1124129200009

上连接螺栓

Upper connecting bolt

2

3

1417029200032

前稳定杆衬套

Front stabilizer rod bush

2

4

1424229200007

前稳定杆吊架

Front stabilizer rod suspension bracket

2

5

1124129200008

U 形连接板

U type connecting plate

2

6

Q151C1290

六角螺栓-细牙


4

7

1417029200026

前稳定杆胶垫

Front stabilizer rod rubber mat

2

8

1117022000006

自锁螺母

Self-locking nut

40

9

Q40116

平垫圈

Flat Washer

6

10

1417022000004

自锁螺母

Self-locking nut

14

11

1417029200013

加强板

Reinforced plate

4

12

1325129202010

元宝梁

Silver ingot girder

1

13

Q151C1270



4

14

1417029200010

前 U 形螺栓

Front U bolt

4

15

Q151C1255



14

16

Q151B1650



8

17

Q151B1450



8

18

1117022000005

自锁螺母

Self-locking nut

16

19

Q151C1275



4

1325129202003

左前簧后支架

Rear bracket, LH front spring

1

1325129202004

右前簧后支架

Rear bracket, RH front spring

1

1532129200003

前板簧左吊耳

LH lifting eye, front leaf spring

1

20 21

- 72 -

用量 Total


用量 Total


用量 Total


1S32532920401 前悬架(右舵)


标号 No.

零件代号


Part Name and Spec.

Part Code

用量

车型

用量

Total

Vehicle Model

Total

1532129200004

前板簧右吊耳

RH lifting eye, front leaf spring

1

22

1417029200011

板簧销轴

Leaf spring axis pin

6

23

Q701B90

弯颈式滑脂嘴

Gooseneck type lubricating nipple

6

24

1417029200014

调整垫片

Adjusting shim

15

25

1124029200005

前减振器总成

Front shock absorber assy

2

26

1417029200019

减振器接叉

Fork of shock absorber

2

27

1417029200020

螺栓

Bolt

2

28

Q700B08

直通式滑脂嘴

Straight type lubricating nipple

4

29

1417029200008

前簧压板

Front leaf spring pressure plate

2

30

Q151C1235



8

31

Q150B1030

六角头螺栓

Hexagon head bolt

4

32

1338129200012

缓冲块总成

Buffer block assy

2

33

Q40110

平垫圈

Flat Washer

4

34

Q33210


35

1417029200023

螺栓

Bolt

2

36

1325129202005

减振器支架

Shock absorber

2

37

1417029200017

加强板

Reinforced plate

4

38

1124129200010

杆头连接螺栓

Rod end connecting bolt

2

39

1124129200006

稳定杆杆头连接件

Stabilizer rod head connecting part

2

40

Q40114

平垫圈

Flat Washer

2

41

1417029200009

球面垫圈

Spherical surface washer

8

42

1417029200035

自锁螺母

Self-locking nut

8

43

Q151B1670

六角螺栓-细牙


4

Full-metal Hexagon locking nut,

4

Type 2

- 73 -


用量 Total


用量 Total


1S32532920401 前悬架(右舵)


标号 No.

零件代号


Part Code

Part Name and Spec.

用量

车型

用量

Total

Vehicle Model

Total

44

Q43134

轴用弹性挡圈

Spring retainer ring for shaft

4

45

1124129200005

共用连接轴

Shared connecting shaft

2

46

Q40316

弹簧垫圈

Spring washer

4

1325329204001

左前钢板弹簧总成

LH front leaf spring assy

1

1325329204002

右前钢板弹簧总成

RH front leaf spring assy

1

48

1325129202002

前簧前支架

Front bracket, front spring

2

49

Q151B1465



6

50

Q151C1250



6

51

1124129200004

前稳定杆总成

Front stabilizer rod assy

1

47

- 74 -


用量 Total


用量 Total


1S32533400401转向器及附件-1 Steering gear and accessories

Oil suction pipe assy

9

5

- 75 -

1S32533400401 转向器及附件标号 No.

Steering gear and accessories 适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）

零件代号


用量

Part Name and Spec.

Part Code

Total


1S32533400401

转向器及附件

Steering gear and accessories

1

3253DLPJE-0RZA

1

1417034000011

转向油罐总成

Steering reservoir assy

1

01

2

Q340B10

1 型六角螺母


2

3

Q40310

弹簧垫圈

Spring washer

2

4

Q150B1030

六角头螺栓

Hexagon head bolt

2

5

Q67638

B 型蜗杆传动式软管环箍

Worm driven hose hoop, type B

2

6

Q67627

B 型蜗杆传动式软管环箍

Worm driven hose hoop, type B

2

7

1325334004005

吸油软管

Oil suction hose

1

8

1425334008010

过渡接头

Transition connector

1

9

Q351B27

六角薄螺母

Hexagon thin nut

1

10

1425334008003

回油管

Oil return pipe

1

11

1124134000009

铰接螺栓

Hinge bolt

1

12

Q72318

密封垫圈

Gasket

6

13

1425334008006

回油管接头

Oil return pipe t

1

14

1425334008013

转向器总成

Steering gear assy

1

15

1425330008003

转向直拉杆总成

Steering drag link assy

1

16

1425334008014

转向垂臂

Steering arm

1

17

1325334004002

转向机支架

Steering gear

1

18

1417022000004

自锁螺母

Self-locking nut

5

19

Q151B1670TF2



2

20

Q151B1650TF2



3

21

Q151B2045TF2

六角头螺栓

Hexagon head bolt

5

22

Q340B06

1 型六角螺母


1

- 76 -

用量 Total


用量 Total


用量 Total


1S32533400401 转向器及附件标号 No.

Steering gear and accessories 适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）

零件代号


用量

Part Name and Spec.

Part Code

Total

23

Q40306

弹簧垫圈

Spring washer

1

24

Q68625F4

单管夹片

Pipe clamp

1

25

Q150B0640

六角头螺拴

Hexagon head bolt

1

26

1417034000025

卡套式铰接螺栓

Ferrule type hinge-ted bolt

2

27

1417034000016

卡套式铰接接头体

Ferrule type hinge-ted connector (body)

2

28

Q67405300

塑料紧箍带


6

29

1325334004004

吸油管总成

Oil suction pipe assy

1

30

1325334004003

高压油管总成

High-pressure oil pipe assy

1

31

1425334008009

管接头

Pipe t

1

32

Q72327

密封垫圈

Gasket

2

33

1417034000008

转向泵铰接螺栓

Ferrule type hinge-ted bolt

1

34

Q150B0830

六角头螺栓

Hexagon head bolt

2

35

Q40308

弹簧垫圈

Spring washer

2

36

1124134000021

转向油泵总成

Steering pump assy

1

37

1325334004006

橡胶双管夹

Rubber double pipe clamp

5

38

1113835680408

扎线带

Tie wrap

2

39

1325334004007

橡胶单管夹

Rubber single pipe clamp

2

- 77 -


用量 Total


用量 Total


用量 Total


1S32533560006制动管路-底盘部分(非ABS)-2 Brake pipe line- chassis (non ABS)-2 A 8 7

4

17 18

9

1 6 5 4 3

10 11 12 13 14 22 15 23

24 25

18

11

17 10

27

4 28

12 13 14

9 16 15

- 78 -

1S32533560006 制动管路-底盘部分(非 ABS)-2

Braking pipeline- chassis (non ABS)-2

标号 No



Part Name and Spec.

Part Code

用量 Total

.


1S32533560402

制动管路-底盘部分(非 ABS)

Braking pipeline- chassis (non ABS)

1

3253DLPJE-0R

1

1425135607080

三通接头组件

Tee-union module

1

ZA01

2

1425135680091

过孔胶圈

Hole rubber grommet

1

3

1110835600066

卡套式直角接头体

Ferrule-type right-angle connector (body)

1

4

Q351B18T15



3

5

1110835600071

密封垫

Gasket

1

6

NMO18*2.65G


Rubber O-ring seal

1

7

Q40306

弹簧垫圈

Spring washer

2

8

Q150B0825

六角头螺栓

Hexagon head bolt

2

9

1417035600186

前气室胶管总成

Front chamber rubber tube assy

2

10

1131135602051

卡套式直通接头体


11

1131135602049

钢管总成-前气室胶管至前气室

12

NMO20*2.65G


Rubber O-ring seal

2

13

1417035600120

密封垫

Gasket

2

14

Q351B22T15



2

15

1131135602050

端式直角接头体

End-type right-angled connector

2

16

1417035600031

测试接头

Test connector

1

17

Q40318

弹簧垫圈

Spring washer

2

18

Q81412

卡套式隔壁直角接头

Ferrule-type right-angled connecter,bulkhead

2

1113835680408

扎线带

Tie wrap

20

1417035600187

扎线带

Tie wrap

10

1417035600188

扎线带

Tie wrap

5

19

(body)

Tube assy - from front air chamber tube to front aie chamber

- 79 -

2 2

用量 Total


用量 Total


用量 Total


1S32533560006 制动管路-底盘部分(非 ABS)-2 标号 No

Braking pipeline- chassis (non ABS)-2 适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）

零件代号


Part Name and Spec.

Part Code

用量 Total

. 1417035600189

扎线带

Tie wrap

10

1417035600190

扎线带

Tie wrap

10

1324035600052

橡胶垫块

Rubber washer

15

1417035600225

橡胶护套

Rubber shield bush

4

21

1325335604033

制动管束

Brake pipe bundle

1

22

1120035610032

双管夹片

Dual-pipe clamp

4

23

1120835600032

三通接头支架

Tee union bracket

4

24

1417035600007

圆管夹

Circular-pipe clamp

2

25

1417035600080

圆管夹 2

Circuit pipe clamp 2

4

26

1417035600095

螺旋护套

Screwed sheath

20

27

NMO08*1.8G


Rubber O-ring seal

1

28

NMO10*2.65G


Rubber O-ring seal

12

20

- 80 -


用量 Total


用量 Total


用量 Total


1S32533560006制动管路-底盘部分(非ABS)-3 Brake pipe line- chassis (non ABS)-3 A

24 24 23

20 23 22

33

19

1

17

25

23

26

31 23

27

C

18

D

31

18

23

E 16 B

2

15

F 14

36 39

40

- 81 -

H 13 12

1S32533560006 制动管路-底盘部分(非 ABS)-3

Braking pipeline- chassis (non ABS)-3

标


号

零件代号

No

Part Code


Part Name and Spec.

. 1S32533560402



1

1417035600204

多通接头

Multi-way t

2

1417035600045

单管夹支架

Pipe clamp bracket

3

1325135602811

钢管总成--后储三通至后储

4

1325135602815

钢管总成-四 24 三通至隔三通

5

1417035600059

四路阀 24-单向三通钢管总成

6

1325335600009

钢管总成-四 23 至隔直角

7

1417035600055

四路阀-储气筒钢管总成

8

1424135680037

钢管总成-调压阀至干燥筒

9

1419135680021

尼龙管总成-干燥器至四回路

10

1327135680016

钢管总成-单向阀至挂车筒

11

1327135680010

钢管总成-前储至直通

12

1417035600098

密封垫

Gasket

13

1417035600074

端面密封套

End section sealing bush

14

1327135680020


车型

用量

Total

Vehicle Model

Total

3253DLPJE-0 RZA01

Pipe assy - from Tee union of rear reservoir to rear reservoir Steel pipe assy - four-circuit valve 24 tee to bulkhead tee Steel pipe assy- from four-circuit valve port 24 to single-way tee Steel pipe assy - from four-circuit valve 23 to two-way connector Steel pipe assy, from four-circuit valve to air reservoir Steel pipe assy, from regulation valve to drying tank Nylon pipe assy- from dryer to four-circuit valve Pipe assy - from one-way valve to trailer cylinder Steel pipe assy-from front reservoir to straight t

Ferrule-type

用量

bulkhead right-angle connector

(body)

- 82 -


用量 Total


用量 Total


1S32533560006 制动管路-底盘部分(非 ABS)-3 标号 No


零件代号


Part Name and Spec.

Part Code

15

Q351B14T15


16

1417035600205


17

Q351B16T15



18

1424135680043

卡套式变径三通接头体

Ferrule-type reducing Tee union (body)

19

Q150B0650

六角头螺栓

Hexagon bolt

20

1417035700002

卡套式端直角接头

Straight thread elbow--Body

21

1417035600224

压紧螺母

Compression nut

22

NMO12*2.65G


Rubber O-ring seal

23

1417035600159

密封垫

Gasket

24

1417035600163



25

Q150B0820

六角头螺栓

Hexagon bolt

26

1320835600002

多通支架

Multi-way

27

Q33008



28

Q340B06

1 型六角螺母


29

Q40306

弹簧垫圈

Spring washer

30

1417035680006

六角头螺塞


31

Q80408



32

1417035600165

压紧螺母

Compression nut

33

1417035600219

压紧螺母

Compression nut

34

1417035600171



35

1417035600176



36

1417035600216



Hexagon thin nut-fine thread Ferrule-type


(body)

- 83 -

用量

车型

用量

Total

Vehicle Model

Total


用量 Total


用量 Total


1S32533560006 制动管路-底盘部分(非 ABS)-3 标号 No.


零件代号


Part Code

Part Name and Spec.

37

1417035600210

卡套式锥螺纹直通接头

Ferrule-type conic threaded straight connector

38

1417035600202

卡套式锥螺纹直通接头

Ferrule-type conic threaded straight connector

39

Q81408



40

Q80912

卡套式三通接头体

Ferrule-type Tee union (body)

41

Q351B12T15

六角薄螺母--细牙


- 84 -

用量

车型

用量

Total

Vehicle Model

Total


用量 Total


用量 Total


1S32533560006制动管路-底盘部分(非ABS)-4 Brake pipe line- chassis (non ABS)-4 A 5 4

B

3

12 13 14

3 4 5 1 C

D 10 9

11 8 7

- 85 -

1S32533560006 制动管路-底盘部分(非 ABS)-4 Braking pipeline- chassis (non ABS)-4 标号 No.



用量

Part Name and Spec.

Part Code

Total


1S32533560402



1

3253DLPJE-0RZA

1

1324035600011

橡胶管总成

Rubber pipe assy

4

01

2

1417035600085

制动缸-制动缸尼龙管

Brake cylinder- brake cylinder nylon pipe

4

3

NMO14*2.65G


Rubber O-ring seal

10

4

1417035600121

密封垫

Gasket

10

5

Q351B16T15



10

6

1417035600002

卡套式端直角变径接头

Ferrule-type right-angle reducing connector

2

7

Q150B0630

六角头螺栓

Hexagon head bolt

2

8

Q81412



2

9

Q351B18T15



2

10

1417035600046

单管夹角形支架

Angular , single pipe clamp

2

11

Q340B06

1 型六角螺母


2

12

1417035600052

卡套式端三通变径接头体

Ferrule-type reducing Tee connector

4

13

1417035600031

测试接头

Test connector

1

14

1424135680043

卡套式变径三通接头体

Ferrule-type reducing Tee union

2

- 86 -

用量 Total


用量 Total


用量 Total


1S32533561103制动管路-空压机至干燥器组件 Braking pipeline, from air compressor to dryer module C

A 12

12

11

11 10

9

9

7

5 6

A B

4 17

8 D

C

B

4 7

- 87 -

1S32533561103 制动管路-空压机至干燥器组件标号 No.

Braking pipeline, from air compressor to dryer module 适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）

零件代号


Part Name and Spec.

Part Code

用量 Total

1S32533561103

Braking pipeline, from air compressor to dryer 制动管路-空压机至干燥器组件

module

1

1

1417035600074

端面密封套

End section sealing bush

2

2

1417035600098

密封垫

Gasket

2

3

1417135600027

钢管总成-空压机至直通

4

1417035600184

卡套式直通接头体


(body)

1

5

1325335604004

钢管总成-直通至胶管

Steel pipe assy, from straight t to hose

1

6

1114135680105

橡胶管总成

Rubber pipe assy

1

7

Q351B22T15



1

8

1325135602073

钢管总成-软管至干燥器 1 口

Pipe assy - from hose to dryer port 1

1

9

Q33006



4

10

1417035600046

单管夹角形支架

Angular , single pipe clamp

4

11

1332135680019

管夹(上)

Pipe clamp (upper)

4

12

Q174B0616

十字槽盘头六角螺钉

Pan head hexagon screw (w/cross slot)

4

Steel pipe assy, from compressor to straight t

- 88 -

1

车型 Vehicle Model 3253DLPJE-0R ZA01

用量 Total


用量 Total


用量 Total


1S32533620419底盘线束-1 Chassis wire harness 3 16 3

17

2 1

4 5 6

11

A

11 11

26

24

25

B 4

22 23

21

- 89 -

8

7

6 9

1S32533620419 底盘线束 Chassis wire harness 标号 No.



Part Code

用量

Part Name and Spec.

Total


1S32533620419

底盘线束

Chassis wire harness

1

3253DLPJE-0RZ

1

1420836281033

线束固定夹片

Wire harness fixing clip

1

A01

2

1420836281032

线束固定夹片

Wire harness fixing clip

1

3

Q150B0816

六角头螺栓

Hexagon head bolt

2

4

Q40108

平垫圈

Flat Washer

8

5

Q40306

弹簧垫圈

Spring washer

3

6

Q340B06

1 型六角螺母


3

7

Q40308

弹簧垫圈

Spring washer

8

8

Q1840620


Hexagon flange bolt

2

9

1124136200020

起动继电器固定支架

Starting relay fixing bracket

1

1B24937171280

圆头扎带

Round head tie wrap

20

1417035600187

扎线带

Tie wrap

30

1417035600188

扎线带

Tie wrap

12

1417136290001

过孔胶圈

Hole rubber grommet

2

1417136290003

过孔胶圈

Hole rubber grommet

3

1417136290005

过孔胶圈

Hole rubber grommet

2

1420836290002

过孔胶圈

Hole rubber grommet

4

12

1124136200009

变速箱线束

Gear box wire harness

1

13

1124136200010

翻转机构线束

Tilting mechanism wire harness

1

14

1325336204054

车架线束 1

Frame wire harness 1

1

15

Q150B0830

六角头螺栓

Hexagon head bolt

2

16

1418136208013

单管夹片

Pipe clamp

1

17

Q1840820


Hexagon flange bolt

4

10

11

- 90 -

用量 Total


用量 Total


用量 Total


1S32533620419 底盘线束 Chassis wire harness 标号 No.



Part Code

用量

Part Name and Spec.

Total

18

1125836281024

驾驶室搭铁线

Cab body ground wire

1

19

1414236200005

发动机搭铁线

Engine ground wire

1

20

1124136200018

熔断丝盒固定支架

Fuse case fixing bracket

2

21

Q150B0835

六角头螺栓

Hexagon head bolt

3

22

Q41208

外锯齿锁紧垫圈

External sawtoothed locking washer

3

23

1138113300012

单管夹片

Pipe clamp

2

24

Q150B0620

六角头螺栓

Hexagon head bolt

3

25

Q68625F4

单管夹片

Pipe clamp

1

26

1417036100014

穿线护套

Wire shield bush

2

27

1417136200003

电源线（蓄电池总开关至起动机）

Power wire(battery switch to starter)

1

28

1124136200001

电源线（“+”至蓄电池总开关）

Power wire("+" to battery switch)

1

29

1124136200002

电源线（“+”至“-”）

Power wire("+" to "-")

1

30

1424236200001

电源线（蓄电池“-”至车架）

Power wire(battery "-" to frame)

1

31

1125836281020

侧标志灯线束(7200)

Wire harness of side mark lamp (7200)

1

32

1325336280007

车架线束 2

Frame wire harness 2

1

- 91 -


用量 Total


用量 Total


用量 Total


1S32534031001前防撞杠及牵引装置 Front anti-collision and towing device

4 3

2

5

6 7

2

1

12 6

4

- 92 -

1S32534031001 前防撞杠及牵引装置

Front anti-collision and towing device 适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）

标号 No.

零件代号


Part Code

Part Name and Spec.

用量 Total


1S32534031001

前防撞杠及牵引装置

Front anti-collision and towing device

1

3253DLPJE-0RZA0

1

1325340314005

前加强横梁总成

Front reinforcement beam assy

1

1

2

Q150B1445

六角头螺栓

Hexagon head bolt

8

3

Q150B1490

六角头螺栓

Hexagon head bolt

4

4

Q150B1475

六角头螺栓

Hexagon head bolt

4

5

Q40114

平垫圈

Flat Washer

16

6

Q40314

弹簧垫圈

Spring washer

16

7

1325340314003

右托架

RH bracket

1

8

1525340300010

前拖车钩防脱环

Anti-drop ring,front towing hook

2

9

1525340300009

拖车钩垫板

Tow hook backing plate

2

10

1525340300008

拖车钩

Tow hook

2

11

Q340B14

1 型六角螺母


16

12

1325340314002

左托架

LH bracket

1

- 93 -

用量 Total


用量 Total


用量 Total


1S32534032001后牵引装置 Rear towing device

4

6

7

5

8

1 2

9

3

- 94 -

1S32534032001 后牵引装置标号

零件代号

No.

Part Code

Rear towing device


Part Name and Spec.

用量

车型

用量

车型

用量

车型

用量

车型

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

1S32534032001

后牵引装置

Rear towing device

1

3253DLPJE-

1

Q332B16

六角锁紧螺母

Hexagon locking nut

4

0RZA01

2

Q40116

平垫圈

Flat Washer

4

3

Q151B1655



4

4

1417040300060

后牵引钩总成

Rear tow hook assy

1

5

1417040300005

后牵引钩座

Rear tow hook saddle

1

6

1417040300064

后牵引销

Rear haul pin

1

7

1417040300062

大链环

Big link

1

8

1417040300063

小链环

Small link

16

9

1417040300061

挂钩

Hook

1

- 95 -

1S32583564104制动管路－排气碟阀组件 Braking pipeline - exhaust butterfly valve module

6

5

4 3 2

1

- 96 -

7

1S32583564104 制动管路－排气碟阀组件 Braking pipeline - exhaust butterfly valve module 适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）

标

零件代号

号

1S32583564104

2

1425135680020 NMO8.00X2.65 G

用量

Part Name and Spec.

Part Code

No.

1


Braking pipeline - exhaust butterfly valve 制动管路－排气碟阀组件

module

排气制动蝶阀

Exhaust brake butterfly-valve

O 型密封圈

Tota

车型

l

Vehicle Model

1 1 1

O-ring seal

3

1417035600219

压紧螺母

Compression nut

1

4

1417035600216



1

5

1417135600050

蝶阀橡胶管总成

Butterfly-valve rubber tube assy

1

6

Q351B12

六角薄螺母

Hexagon thin nut

1

7

Q81406


Ferrule-type


(body)

- 97 -

1

3253DLPJE-0R ZA01

用量

车型

Tota

Vehicle

l

Model

用量 Total


用量 Total


1S41703561500四回路保护阀组件 Four-circuit protection valve assy 2

3 4 5 1

6 7 8

8 7 6

8

8

7

7

6

9

- 98 -

1S41703561500 四回路保护阀组件 Four-circuit protection valve assy 标号 No.

1



用量

Part Name and Spec.

Part Code

Total


1S41703561500

四回路保护阀组件

Four-circuit protection valve assy

1

3253DLPJE-0

1417035600053

四回路保护阀

Four-circuit protection valve

1

RZA01

Ferrule-type


2

1419135680022


(body)

1

3

Q351B22T15



1

4

1417035600120

密封垫

Gasket

1

5

NMO20X2.65G


Rubber O-ring seal

1

6

1417035600175

7


3

体


1417035600121

密封垫

Gasket

4

8

NMO14×2.65G


Rubber O-ring seal

4

9

1417035600057



1

- 99 -

用量 Total


用量 Total


用量 Total


1S42531170701加速传动装置 Acceleration transmission device

5 3

4 B 6 8 9

A

10

1

B 2

A

- 100 -

7

1S42531170701 加速传动装置 Acceleration transmission device 标号 No.



Part Name and Spec.

Part Code

用量

车型

用量

Total

Vehicle Model

Total

1S42531170701

加速传动装置

Acceleration transmission device

1

3253DLPJE-

1

Q1800620



2

0RZA01

2

1124111700004

油门限位支架总成

Throttle limiting bracket assy

1

3

Q32008

六角法兰面螺母

Hexagon flange nut

2

4

1425311707003

垫板

Backing plate

1

5

1124111700006

手油门拉索总成

Hand-operated throttle pull wire assy

1

6

1425311707002

油门操纵支架总成

Throttle manipulator assy

1

7

1418111700005

油门踏板总成

Throttle pedal assy

1

8

Q174B0625

十字槽凹穴六角螺栓

Hexagon bolt (w/ cross slot)

2

9

Q40306

弹簧垫圈

Spring washer

2

10

Q40106

平垫圈

Flat washer

2

- 101 -


用量 Total


用量 Total


1S42531181201 加速传动装置-底盘部分(右舵车) Acceleration transmision device-chassis(RHD) )

2

1 2

3 4

5

8 3 4 5 6 7

7

7

- 102 -

1S42531181201 加速传动装置-底盘部分(右舵车) Acceleration transmision device-chassis(RHD) 标号 No.



用量

Part Name and Spec.

Part Code

Total 1S42531181201

加速传动装置-底盘部分(右舵车)

Acceleration transmision device-chassis(RHD)

1

1

1425311812002

油门拉线总成

Throttle pull cable assy

1

2

Q67407100

塑料紧箍带


3

3

1124111800010

油门回位弹簧

Throttle retracting spring

1

4

1417011800030

杠杆总成

Lever assy

1

5

Q43110

轴用弹性挡圈

Spring retainer ring for shaft

1

6

Q150B0640

六角头螺拴

Hexagon head bolt

1

7

Q340B06

1 型六角螺母


4

8

1417011800004

停油缸

Cut-out cylinder

1

- 103 -


用量 Total


用量 Total


用量 Total


1S42531181201 加速传动装置-底盘部分(右舵车) Acceleration transmision device-chassis(RHD

- 104 -

1S42531630801 离合器操纵机构

Clutch operation mechanism 适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）

标号 No.

零件代号


用量

Part Name and Spec.

Part Code

Total


1S42531630801

离合器操纵机构

Clutch operation mechanism

1

3253DLPJE-0R

1

Q150B0820

六角头螺栓

Hexagon head bolt

4

ZA01

2

Q40308

弹簧垫圈

Spring washer

4

3

Q40108

平垫圈

Flat Washer

4

4

1124116300006

油罐总成

Oil tank assy

1

5

Q340B10

1 型六角螺母


2

6

Q40310

弹簧垫圈

Spring washer

4

7

Q40110

平垫圈

Flat Washer

4

8

1432116380003

离合总泵

Clutch Master cylinder

1

9

Q150B1060

六角头螺栓

Hexagon head bolt

2

10

Q72314

密封垫圈

Gasket

2

11

Q81814

卡套式铰接六角螺栓

Ferrule type hinge-ted hexagon bolt

1

12

1425316307003

离合总泵出油管

Oil outlet pipe, clutch master cylinder

1

13

Q33008



8

14

1425316307005

挡尘板

Dust-proof board

1

15

1425316307002

离合器踏板总成

Clutch pedal assy

1

16

1425316307004

离合总泵进油管

Oil inlet pipe of clutch master cylinder

1

17

Q67522



2

18

Q150B1020

六角头螺栓

Hexagon head bolt

2

- 105 -

用量 Total


用量 Total


用量 Total


1S42531730801变速操纵机构 Gearbox operation mechanism A 3

20

17

18

4

B

5

B

22 22

22

1 2

17

B 14

6 7 8

19 15

11 12

C

13 12

22

A

9

10

11

22

16

- 106 -

1S42531730801 变速操纵机构 Gearbox operation mechanism 标号 No.



用量

Part Name and Spec.

Part Code

Total 1S42531730801

变速操纵机构

Gearbox operation mechanism

1

1

Q340B10

1 型六角螺母


1

2

Q40310

弹簧垫圈

Spring washer

1

3

1425317303003

手柄带气阀总成

Handle w/ valve assy

1

4

1424217300003

上防尘罩

Upper dust cover

1

5

1424217300004

上压板

Upper pressure plate

1

6

Q150B0625

六角头螺栓

Hexagon head bolt

1

7

Q40106

平垫圈

Flat washer

1

8

Q40306

弹簧垫圈

Spring washer

1

9

1425317303002

操纵器总成

Operation mechanism assy

1

10

1424217300005

下压板

Lower pressure plate

1

11

1424217300008

密封垫片

Gasket

2

12

1424217300007

复合衬套

Compound bush

1

13

1424217300006

中间隔套

Middle spacer bush

1

14

Q1440865

六角头螺栓和外锯齿锁紧垫

Hexagon head bolt and external

圈组合件

sawtoothed locking-washer combination

15

Q40108

平垫圈

Flat washer

1

16

Q33008


Full metal hexagon flange locking-nut v

1

17

1B24981200026

单管夹片

Pipe clamp

4

18

Q150B0820

六角头螺栓

Hexagon head bolt

3

19

Q2214216

自攻螺钉

Self-tapping screw

1

20

Q150B0830

六角头螺栓

Hexagon head bolt

1

21

Q340B08

1 型六角螺母


1

22

1417035600187

扎线带

Tie wrap

1

- 107 -

1

车型 Vehicle Model 3253DLPJ E-0RZA01

用量 Total


用量 Total


用量 Total


1S42533540001踏板及吊挂 Pedal and hanger

4.3

1

2

3

4.1 4

1

- 108 -

2

3

1S42533540001 踏板及吊挂 Pedal and hanger 适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）标号 No.

零件代号


Part Code

Part Name and Spec.

用量 Total

1S42533540001

踏板及吊挂

Pedal and hanger

1

1

Q1150B1035

六角头螺栓

Hexagon head bolt

7

2

Q40310

弹簧垫圈

Spring washer

7

3

Q40110

平垫圈

Flat Washer

7

4

1425335400005

制动阀安装底板总成

Brake valve mounting plate assy

1

4.1

1425335400003

密封垫-踏板

Sealing gasket - pedal

1

4.2

1425335400002

密封垫-转向柱

Gasket - Steering column

1

4.3

1425335400001

制动阀安装底板

Brake valve mounting plate

1

- 109 -

车型 Vehicle Model 3253DLPJE-0RZA01

用量 Total


用量 Total


用量 Total


1S42533550002真空助力器及制动总泵 Vacuum booster and brake master cylinder

14 1

13

7 6

14 13 15

19 18 17

2 3

13

16

6

4 5

14 13

7

8

7

9 11

8 9 11

8 9

9 10

7 7

8

12

- 110 -

1S42533550002 真空助力器及制动总泵 Vacuum booster and brake master cylinder 适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）

标

零件代号

号


Part Code

No.

用量

Part Name and Spec.

Total 1S4253355000

1

2

真空助力器及制动总泵

Vacuum booster and brake master cylinder

1

1425335500005

直踏式制动总泵(带消声器)

Straightly step brake master cylinder(w/ muffler)

1

2

Q40110

平垫圈

Flat washer

4

3

Q40310

弹簧垫圈

Spring washer

4

4

Q150B1035

六角头螺栓

Hexagon head bolt

4

5

1417035600159

密封垫

Gasket

2

6

1124135600022

过渡接头


2

7

NMO14×2.65G


Rubber O-ring seal

8

8

1417035600121

密封垫

Gasket

8

9

Q351B16T15



4

10

1325835680009

气室接头

Gas chamber t

1

11

1417035600002

卡套式端直角变径接头

Ferrule-type right-angle reducing connector

2

12

1425335607005

制动阀接头

Brake valve connector

1

13

1417035600167

密封垫

Gasket

4

14

Q617B16

六角头螺塞


3

15

1124135600030

过渡接头


1

16

Q150B0835

六角头螺栓

Hexagon bolt

4

17

Q40108

平垫圈

Flat washer

4

18

Q40308

弹簧垫圈

Spring washer

4

19

Q340B08

1 型六角螺母


4

- 111 -

车型 Vehicle Model 3253DLPJE-0 RZA01

用量 Total


用量 Total


用量 Total


1S52533420201转向传动装置 Steering drive device

1 7 8

9

2 3 10

11

5

4

6

- 112 -

1S52533420201 转向传动装置 Steering drive device 适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）

标

零件代号

号


Part Code

No.

用量

Part Name and Spec.

Total 1S5253342020 1

转向传动装置

1

Steering drive device

1

1525334202002

方向盘总成

Steering wheel assy

1

2

Q353B20

六角较薄螺母

Hexagon thinner nut

1

3

Q40320

弹簧垫圈

Spring washer

1

4

1124134200002

转向管柱带可调机构总成

Steering column with adjusting mechanism assy

1

5

Q1840820


Hexagon flange bolt

4

6

1124134200003

防尘套

Dust boot

1

7

1124134200004

护管总成

Protection pipe assy

1

8

1124134200005

护管连接螺栓

Protection connecting bolt

2

六角头螺栓、弹簧垫圈和平

Hexagon bolt, spring washer and flat washer

Q1460630

垫圈组合件

combination

10

Q33006



2

11

1124134200006

转向传动轴总成

Steering drive shaft assy

1

9

- 113 -

2


用量 Total


用量 Total


用量 Total


1SB2206810501驾驶员座椅, Driver seat 1SB2496910501前排座椅 Front row seat

10

3

12

11 9 13 14

2 7 6 8

- 114 -

1SB2206810501 驾驶员座椅 Driver seat 标号 No.



Part Name and Spec.

Part Code

用量 Total


1SB2206810501

驾驶员座椅

Driver seat

1

3253DLPJE

1

1B22068105001

驾驶员座椅总成

Driver seat assy

1

-0RZA01

2

1B24968100028

液压减振座椅座垫总成

Hydraulic shock absorbing seat & seat cushion assy

1

3

1B24968100029

液压减振座椅靠背总成

Hydraulic shock absorbing seat & backrest assy

1

4

1B24968180011

液压减振机构总成

Hydraulic shock absorbing mechanism assy

1

5

1B24968180012

座椅支座及调节机构总成

Seat ing base and adjusting mechanism assy

1

6

Q1461025


Hexagon bolt, spring washer and flat

垫圈组合件

washer combination

7

Q32010


Hexagon flange nut

2

8

1124135680100

堵盖

Cap

1

1SB2496910501

前排座椅

Front row seat

1


Hexagon bolt, spring washer and flat

垫圈组合件

washer combination

2

2

9

Q1461025

10

1B24969105002

副驾驶员座椅总成

Codriver seat assy

1

11

Q32010


Hexagon flange nut

2

12

1B24969105004

中间座总成

Middle seat assy

1

13

Q32008


Hexagon flange nut

2


Hexagon head bolt, spring washer and flat

垫组合件

washer combination

14

Q1460825

- 115 -

2

用量 Total


用量 Total


用量 Total


1SB2493710113前围灯具 Front wall lamps

1

1

1

1 2

2 3 4 5

3 4 5

3 4 5

3 4 5

6

54

3

54 3

8 9 9

- 116 -

1SB2493710113 前围灯具 Front wall lamps 标号 No.



Part Name and Spec.

Part Code

用量 Total

1SB2493710113

前围灯具

Front wall lamps

1

Q1840625


Hexagon flange bolt

4

2

1B24937100005

示廓灯

Clearance lamp

2

3

Q40105

平垫圈

Flat Washer

12

4

Q40305

弹簧垫圈

Spring washer

12

5

Q360B05

六角螺母

Hexagon nut

12

6

1B24937108013

左装饰灯总成

LH decorative lamp assy

1

1B24937108009

左侧标志灯总成

LH side mark lamp assy

1

1B24937108011

右侧标志灯总成

RH side mark lamp assy

1

1B24937100003

左踏步灯

LH step lamp

1

1B24937100009

右踏步灯

RH step lamp

1

9

Q2714222

十字槽盘头自攻螺钉

Pan head self-tapping screw (w/cross slot)

4

10

1B24937108015

右装饰灯总成

RH decorative lamp assy

1

11

Q1460625

六角头螺栓、弹簧垫圈和

Hexagon

平垫圈组合件

washer

12

1B24937100010

室内灯

Indoor lamp

1

13

1B24937100001

车速灯

Vehicle speed light

3

7 8

车型 Vehicle Model 3253DLPJ

bolt, spring washer and flat combination

- 117 -

6

E-0RZA01

用量 Total


用量 Total


用量 Total


1SB2493730408开关-车身部分 Switch- body part 9

10 1 12

11 13

15 7

14

6 8 5

16

2 21

4

19

3

18

17

22 20

23

24

25

26

- 118 -

27

28

1SB2493730408 开关-车身部分 Switch- body part 标号 No.



Part Name and Spec.

Part Code

用量

车型

Tota

Vehicle

l

Model

1SB2493730408

开关-车身部分

Switch- body part

1

3253DLPJE-

1

1B24937300042

组合开关右护罩

RH protection cover, combined switch

1

0RZA01

2

Q2726320



4

3

1B24937300044

塑料螺钉

Plastic screw

2

4

1B24937300045

塑料螺钉卡片

Plastic screw clip

2

5

Q40106

平垫圈

Flat washer

4

6

1B24937300043

组合开关前护罩

Front protection cover, combined switch

1

7

1B24937300135

组合开关总成

Combined switch assy

1

8

1B24937300041

组合开关左护罩

LH protection cover, combined switch

1

9

1B24937300046

点火锁总成

Ignition switch assy

1

10

Q174B0830

六角头头部带十字槽螺栓

Hexagon head bolt,w/cross slot on head

2

11

Q40108

平垫圈

Flat washer

2

12

Q40308

弹簧垫圈

Spring washer

2

13

1B24937300058

制动灯开关

Brake lamp switch

1

14

1B24937300021

离合器开关

Clutch switch

1

15

1B24237300026

驻车制动指示灯开关

Parking brake lamp switch

1

16

1B24937300035

车门开关

Vehicle door switch

1

17

Q2204816

十字槽盘头自攻螺钉和平垫

Pan head screw(w/cross slot) and flat washer

圈组合件

combination

18

Q2140616

十字槽盘头螺钉

Pan head screw (w/cross slot)

4

19

Q3974820

A 型簧片螺母

Spring nut type A

4

20

1B24937300036

车门开关堵塞

Vehicle door switch capplug

1

21

1B24937300011

假开关

Dummy switch

20

- 119 -

1

用量 Total


用量 Total


用量 Total


1SB2493730408 开关-车身部分 Switch- body part 标号 No.



Part Code

用量

Part Name and Spec.

Total


22

1B24937300002

ABS 诊断接口闷盖

ABS diagnosis interface blank cover

1

23

1B24937300025

后雾灯开关

Rear fog lamp switch

1

24

1B24937300026

仪表调光开关

Instrument light-adjustment

25

1B24937300127

轴间闭锁开关


1

26

1B24937300126

轮间闭锁开关


1

27

1B24937300123

PTO 开关

PTO switch

1

28

1B24937300124

空档取力开关

Neutral power take-off switch

1

switch

- 120 -

1

用量 Total


用量 Total


用量 Total


1SB2493740419车身线束 Body wire

22

23

14 12

1

12

13 24

15

21

11 8

20

19

9 10

16

18

7

17

2 3 3 6 4 5

- 121 -

1SB2493740419 车身线束 Body wire 标号 No.



Part Code

Part Name and Spec.

用量

车型

用量

Total

Vehicle Model

Total

1SB2493740419

车身线束

Body wire

1

3253DLPJE-

1

1B24937402024

驾驶室顶棚线束

Cab ceiling wire

1

0RZA01

2

1B24937404064

车身主线束

Vehicle body main wire

1

3

1B24937173080

插孔扎带

Wrap strip for hole

10

4

Q67405200

塑料紧箍带


1

5

Q2214216

自攻螺钉

Self-tapping screw

2

6

1K16937400016

塑料线束夹

Plastic clamp for wire harness

1

7

1K16937400015

塑料线束夹

Plastic clamp for wire harness

1

8

Q150B0620

六角头螺栓

Hexagon head bolt

2

9

Q41205



1

10

Q40105

平垫圈

Flat washer

1

11

1B24937408011

车身线束固定支架

Fixing bracket of body wire harness

1

12

Q1840620


Hexagon flange bolt

1

13

Q41208



1

14

1B24937408013

车身线束固定支架 2

Fixing bracket, body wire harness 2

1

15

1B24937400111

线束固定支架

Fixing bracket, wire harness

2

16

1B24937400019

U 型条

U-type bar

6

17

Q68620F4

单管夹片

Pipe clamp

1

18

Q340B05

1 型六角螺母


1

19

Q1460625

六角头螺栓、弹垫和平垫


组合件

washer combination

20

Q40106

平垫圈

Flat washer

2

21

Q150B0520

六角头螺栓

Hexagon head bolt

1

- 122 -

2


用量 Total


用量 Total


1SB2493740419 车身线束 Body wire 标号 No.



Part Code

Part Name and Spec.

用量

车型

用量

Total

Vehicle Model

Total

22

Q41206



2

23

Q40108

平垫圈

Flat washer

2

24

Q150B0825

六角头螺栓

Hexagon bolt

2

- 123 -


用量 Total


用量 Total


1SB2493751280继电器控制器及车身总线(豪华车型用)Relay control and body assy (for luxury vehicle model) 5

2

4 3

6

7 8

11

9 1 12

10 13

14

- 124 -

15

1SB2493751280 继电器控制器及车身总线(豪华车型用)Relay control and body assy (for luxury vehicle model) 适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）

标号 No

零件代号


Part Name and Spec.

Part Code

用量 Total

.


1SB2493751280

继电器控制器及车身总线(豪华车

Relay control and body assy (for luxury

型用)

vehicle model)

电器安装架总成

Electric mounting bracket assy

十字槽盘头自攻螺钉和平垫圈组

Pan head screw(w/cross slot) and flat

合件

washer combination

熄火控制器

ICO (Ignition-cut-off) controller

十字槽盘头螺钉、弹垫和平垫组合

Pan head screw(w/cross slot), spring

件

washer and flat washer combination

1

1

1B24951205032

2

Q2204216

3

1B24937500004

4

Q2360510

5

1B24937500006

预热控制器

Preheating controler

1

6

1B24937500002

断丝报警控制器

Fuse break warn controller

1

7

1B24937500105

二合一控制器

Dual-function controller

1

8

Q1460620

六角头螺栓、弹簧垫圈和平垫组合


件

washer combination

9

1B24937500038

二合一控制器安装支架

Dual-function controller mounting

1

10

1B24953000450

继电器支架

Relay bracket

1

11

1B24937500031

闪光器

Flasher

1

12

1B24937500005

通用继电器

General purpose relay

21

13

1B24982404072

ST4.2 簧片螺母

ST4.2 Spring nut

4

14

1B24937504008

继电器、保险丝不干胶标示

Sticky label of relays and fuses

1

15

1B24937500001

预热继电器

Preheating relay

1

- 125 -

1 10 1 2

3

3253DLPJE-0R ZA01

用量 Total


用量 Total


用量 Total


1SB2493760140仪表装置 Instrument device （在保修期内,本标识损坏后不予赔偿。

5

No compensate , if this

mark would be mangled in guarantee time.)

4

3 7

6 8

1

2

13

12

11

10

9

- 126 -

1SB2493760140 仪表装置 Instrument device 适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）

标

零件代号

号 No.


Part Code

Part Name and Spec.

用量

车型

用量

Total

Vehicle Model

Total

3253DLPJE-0RZA01

1SB2493760140

仪表装置

Instrument device

1

1

1B24937600014

组合仪表总成

Combined instrument assy

1

2

Q2204216


Pan head screw(w/cross slot)

和平垫圈组合件


3

1B24937500098

拨码器不干胶标识

Dial device sticker

1

4

Q910

铅封

Lead seal

1

5

1B24937500096

仪表拨码器

Instrument dial device

1

6

1B24937500099

拨码器盖板

Dial device cover

1

7

Q50512150

钢丝锁线

Locking wire

1

8

1B24937680304

车速里程表传感器

Odometer sensor

1

9

1B24237600004

水温传感器

Water temperature sensor

1

10

Q72308

密封垫圈

Gasket

1

11

1B24237600005

机油压力传感器

Oil pressure sensor

1

12

Q72314

密封垫圈

Gasket

1

13

1B24937600040

气压传感器

Air preesure sensor

2

6

- 127 -


用量 Total


用量 Total


1SB2493780107电气附件 Electric accessories

- 128 -

1SB2493780107 电气附件 Electric accessories 标号 No.

1


零件代号

零件名称及规

Part Name and

Part Code

格

Spec.

用量

车型

用量

车型

用量

车型

用量

车型

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

3253DLPJE-0RZA01

1SB2493780107

电气附件

Electric accessories

1

1B24937800021

点烟器总成

Cigarette lighter assy

1

- 129 -

1SB2495000116车身本体-1 Vehicle body

1.3 1.2

1.1

1.4

1

1.6

- 130 -

1SB2495000116 车身本体标号 No.

Vehicle body 适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）

零件代号


Part Name and Spec.

Part Code

用量 Total

1SB2495000116

1

车身本体

Vehicle body

1B24950001006

白车身调整总成

Adjusting assy , BIW

1

1

1B24950000014

白车身焊接总成

Welded assy., BIW

1

1.1

1B24954000416

右侧围焊接总成

RH side welded assy

1

1.2

1B24957000001

顶盖焊接总成

Roof welded part assy

1

1.3

1B24957000050

顶盖前横梁总成

Roof front beam assy.

1

1.4

1B24953000003

前围焊接总成

Front wall welded assy

1

1.5

1B24954000415

左侧围焊接总成

LH side wall welded assy

1

1.6

1B24956000001

后围焊接总成

Rear wall welded assy

1

1.7

1B24951000007

地板焊接总成

Floor welded assy

1

2

1B24953000481

仪表板左端支架总成

Dashboard leftt assy

1

3

Q1460616


Hexagon

平垫圈组合件

washer combination

4

1B24953000420

仪表板上横梁总成

Dashboard upper cross member assy

1

5

Q32008


Hexagon flange nut

4

6

1B24953000449

仪表板上横梁支架(6)

7

Q1460616

8

1B24953000479

9

Q1460616

10

1B24953000448

bolt, spring washer and flat

Dashboard upper cross member bracket (6)


Hexagon


平垫圈组合件

washer combination

仪表板右支架总成

Dashboard RH assy


Hexagon

平垫圈组合件

washer combination

手油门支架总成

Hand-operated throttle assy

3

1 1 1


- 131 -

2 1


用量 Total


用量 Total


用量 Total




零件代号


Part Name and Spec.

Part Code

用量 Total

六角头螺栓、弹簧垫圈和平垫圈

Hexagon

组合件

washer combination

Q32006


Hexagon flange nut

1

13

1B24953000441

音响架总成

Audio rack assy

1

14

Q1460620

六角头螺栓、弹簧垫圈和平垫组


合件

washer combination

15

1B24953000265

前把手支架总成

Front handrail bracket assy

16

Q1460620


Hexagon

组合件

washer combination

17

1B24951000429

中平台前部支架(左)

Middle platform front (¨LH)

18

Q1460616


Hexagon

组合件

washer combination

19

1B24951000423

中平台前部支架（右）总成

Middle platform front (RH)

20

Q1460616


Hexagon

组合件

washer combination

21

1B24951000431

中平台支架总成

Middle platform assy

22

Q1460820



合件

washer combination

23

1B24953000410

前围前面板总成

Front wall front assy

24

Q1460820



合件

washer combination

25

1B24954000093

11

Q1460616

12

顶置物盒支架总成左


1

5 2




4 1 2 1 4 1 5 1

(LH) top-mounted commodity box bracket assy.

- 132 -

16 1


用量 Total


用量 Total


用量 Total




零件代号


Part Name and Spec.

Part Code

用量 Total

26

Q1460620

27

1B24954000094

28

Q1460620

29


Hexagon

组合件

washer combination

顶置物盒支架总成

右


(RH) Top-mounted commodity box bracket assy.

1


Hexagon

组合件

washer combination

1B24957000037

后加强梁支架

Bracket, rear reinforcing beam

2

30

Q40206

大垫圈

Big washer

10

31

Q1420620

六角头螺栓和弹簧垫圈组合件

32

1B24957000033

前加强梁支架板左

Front reinforced beam ing plate, left

33

Q1460620



合件

washer combination

34

1B24957000034

35

Q1460620

36

1B24957004160

37

Q1460620

38

1B24957000070

39

Q1460620

前加强梁支架板右


2

Hexagon head bolt and spring washer component

Front reinforced beam ing plate, right



合件

washer combination

平顶置物架总成

Flat topping commodity shelf assy



合件

washer combination

置物架中支架总成

Commodity shelf central assy



合件

washer combination

- 133 -

2

10 1 5 1 5 1 4 1 2


用量 Total


用量 Total


用量 Total




零件代号


Part Code

用量

Part Name and Spec.

Total

40

1B24961000401

左前车门装配总成

LH front door fitting assy

1

41

1B24961000402

右前车门装配总成

RH front door fitting assy

1

42

Q1800830


Indented

bolt,

w/hexagon

bearing surface

- 134 -

flange

8


用量 Total


用量 Total


用量 Total


1SB2495020302车身悬置翻转锁止机构(右舵自卸)Vehicle body tilting and locking mechanism(RH driving, self-unloading) （1B24950200199 前悬置安装图）Front Suspension Installation drawing

23 16 10

22

21 16 20

16

15

17 11

15

12

14 19

14

18 19

11 15

13

14 14

26 15 16

15

7 6

15

18 13

5

1 2 3

14

14

11

8 9

12

4

25

21 22 23 16 16

11 10 8 7 1 2 3

24 5 4

- 135 -

1SB2495020302 车身悬置翻转锁止机构(右舵自卸)Vehicle body tilting and locking mechanism(RH driving, self-unloading) （1B24950200199 前悬置安装图）Front Suspension Installation drawing 标号 No.



Part Name and Spec.

Part Code

Vehicle body tilting and locking

用量

车型

用量

Total

Vehicle Model

Total

1

1SB2495020302

车身悬置翻转锁止机构(右舵自卸)

1B24950200199

前悬置安装图

Front Suspension Installation drawing

1

1

Q150B1450

六角头螺栓

Hexagon head bolt

8

2

Q40314

弹簧垫圈

Spring washer

8

3

Q40114

平垫圈

Flat washer

8

4

Q340B14

1 型六角螺母


8

5

1B24950200205

翻转轴

Tilting axle

2

6

1B24950200212

右前固定座

RH front fixing seat

1

7

Q40216

大垫圈

Big washer

2

8

Q381B16

螺母

Nut

2

9

Q5004036

开口销

Split pin

2

10

1B24250100037

止动垫片

Stop washer

2

11

1B24250100022

限位挡圈总成

Limit retaining ring assy

4

12

1B24250100032

橡胶套总成

Rubber sleeve assy

2

13

Q150B10110

六角头螺栓

Hexagon head bolt

2

14

Q40310

弹簧垫圈

Spring washer

8

15

Q40110

平垫圈

Flat washer

8

16

Q340B10

1 型六角螺母


8

17

1B24950280033

驾驶室前横梁加强板右

Front cross beam reinforced plate (RH), cab

1

18

Q150B10100

六角头螺栓

Hexagon head bolt

2

mechanism(RH driving, self-unloading)

- 136 -

3253DLPJE-0RZA01


用量 Total


1SB2495020302 车身悬置翻转锁止机构(右舵自卸)Vehicle body tilting and locking mechanism(RH driving, self-unloading) （1B24950200199 前悬置安装图）Front Suspension Installation drawing 适用车型及用量（件）Applicable vehicle model and needed 标号 No.

quantity（PCS）

零件代号


Part Name and Spec.

Part Code

用量 Total


19

Q150B10105

六角头螺栓

Hexagon head bolt

4

20

1B24950200204

右前悬置支架

RH front mounting bracket

1

21

Q150B1030

六角头螺栓

Hexagon head bolt

4

22

Q33010



4

23

Q40110

平垫圈

Flat washer

8

24

1B24950200202

左前固定座

LH front fixing seat

1

25

1B24950280032

驾驶室前横梁加强板左

Front cross beam reinforced plate (LH), cab

1

26

1B24950200203

左前悬置支架

LH front mounting bracket

1

27

1B24950200206

连接管总成

t pipe assy

1

28

Q150B1435

六角头螺栓

Hexagon head bolt

2

29

Q40314

弹簧垫圈

Spring washer

2

30

Q40114

平垫圈

Flat Washer

2

31

Q150B1435

六角头螺栓

Hexagon head bolt

4

32

Q40114

平垫圈

Flat Washer

4

33

Q40314

弹簧垫圈

Spring washer

4

34

Q340B14

1 型六角螺母


4

35

Q150B1035

六角头螺栓

Hexagon head bolt

6

36

Q40310

弹簧垫圈

Spring washer

6

37

Q40110

平垫圈

Flat Washer

6

38

Q150B1235

六角头螺栓

Hexagon head bolt

4

- 137 -

用量 Total


用量 Total


1SB2495020302 车身悬置翻转锁止机构(右舵自卸)Vehicle body tilting and locking mechanism(RH driving, self-unloading) （1B24950200199 前悬置安装图）Front Suspension Installation drawing 适用车型及用量（件）Applicable vehicle model and needed 标号 No.

quantity（PCS）

零件代号


Part Name and Spec.

Part Code

用量 Total


39

Q40312

弹簧垫圈

Spring washer

4

40

Q40112

平垫圈

Flat Washer

4

41

Q340B12

1 型六角螺母


4

42

Q150B1035

六角头螺栓

Hexagon head bolt

13

43

Q40310

弹簧垫圈

Spring washer

13

44

Q40110

平垫圈

Flat Washer

13

45

Q150B0835

六角头螺栓

Hexagon head bolt

7

46

Q40308

弹簧垫圈

Spring washer

7

47

Q40108

平垫圈

Flat Washer

7

48

1B24950200121

油缸上支座

upper pedestal, oil cylider

1

49

1B24950200119

右上连接板总成

RH upper connecting plate assy

1

50

1B24950200111

左上连接板总成

LH upper connecting plate assy

1

- 138 -

用量 Total


用量 Total


1SB2495020302车身悬置翻转锁止机构(右舵自卸)Vehicle body tilting and locking mechanism(RH driving, self-unloading)（1B24950240001翻转操纵机构总成(右置)）Tilting operation mechanism assy (RH) 24 1

B

4

5

26 25

8

3 2

6 5

4

19

9

19

7 21

27 19

20

19 10

23

34 22 22

2

12

29 28

19 11 18

15 14

17

13

- 139 -

30 31 32 33

1SB2495020302 车身悬置翻转锁止机构(右舵自卸)Vehicle body tilting and locking mechanism(RH driving, self-unloading) （1B24950240001 翻转操纵机构总成(右置)）Tilting operation mechanism assy (RH) 适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）

标号 No

零件代号


Part Name and Spec.

Part Code

用量 Total

.


Vehicle body tilting and locking

1

1SB2495020302

车身悬置翻转锁止机构(右舵自卸)

1B24950240001

翻转操纵机构总成(右置)

Tilting operation mechanism assy (RH)

1

1

1B24950200149

后悬置上锁体总成

Upper lock body assy, rear suspend

1

2

Q1461025

六角头螺栓、弹簧垫圈和平垫圈组合

Hexagon

件

washer combination

3

1B24950200169

后悬置下锁体总成

Lower lock body assy, rear suspend

1

4

1B24950200065

油管卡子

Oil pipe clip

2

5

Q1460820



6

1B24950200061

硬管

Hard pipe

1

7

1B24950200063

二通接头

Two- way t

1

8

1B24950200064

二通接头固定板

Fixing plate of two-way connector

1

9

Q1460820



10

1B24950200183

连接软管

Connecting hose

1

11

1B24950200181

手动泵总成

Manual oil pump assy

1

12

1B24950200182

手动油泵支架

Manual oil pump bracket

1

13

Q150B1030

六角头螺栓

Hexagon head bolt

4

14

Q40310

弹簧垫圈

Spring washer

4

15

Q40110

平垫圈

Flat washer

4

16

Q340B10

1 型六角螺母


4

mechanism(RH driving, self-unloading)


washer combination

washer combination

- 140 -

12

2

2

3253DLPJE -0RZA01

用量 Total


用量 Total


用量 Total


1SB2495020302 车身悬置翻转锁止机构(右舵自卸)Vehicle body tilting and locking mechanism(RH driving, self-unloading) （1B24950240001 翻转操纵机构总成(右置)）Tilting operation mechanism assy (RH) 适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）

标号 No

零件代号


Part Name and Spec.

Part Code

车型

用量

Vehicle

Total

.

Model

17

1B24950200421

油缸拉线总成

Oil cylinder pull cable assy

1

18

Q1460820



19

Q67407100

塑料紧箍带


15

20

1B24950250002

油缸连接油管

Connecting oil pipe, oil cylinder

2

21

1B24950280031

翻转油缸总成 H3 系列

Tilting cylinder assy,H3 series

1

22

Q40120

平垫圈

Flat washer

2

23

Q5005056

开口销

Split pin

1

24

1B24950200241

脱钩油缸连接油管

Connecting oil pipe, unhooking oil cylinder

1

25

1B24950200242

脱钩油缸直通接头

Straight t, unhooking oil cylinder

1

26

Q72310

密封垫圈

Gasket

1

27

1124136600006

下止点开关

Lower dead center switch

1

28

1124136700004

翻转蜂鸣器

Tilting buzzer

1

29

Q150B0820

六角头螺栓

Hexagon head bolt

1

30

Q40108

平垫圈

Flat washer

3

31

Q40308

弹簧垫圈

Spring washer

3

32

Q340B08

1 型六角螺母


3

33

Q150B0825

六角头螺栓

Hexagon head bolt

1

34

1B24950260001

举升缸支架总成

Lifting cylinder bracket assy

1

washer combination

- 141 -

2

`

用量 Total


用量 Total


用量 Total


1SB2495020302车身悬置翻转锁止机构(右舵自卸) Vehicle body tilting and locking mechanism(RH driving, self-unloading)（1B24950280026后悬置总成）Rear suspension assy

1 2 3 4 5

2021 19 19

A 21 20 2 3 4

8 6 22 7

11

10

15

1

19

5

20

22

21

7

12

24

9

13

21

6

14

20 19 15

15

16

17

22

9 11 18

23

2526 27

12

2726 25

13 10

A

23 22 22

23

17 15 16

23

14

22

- 142 -

28

29 30

24

1SB2495020302 车身悬置翻转锁止机构(右舵自卸) Vehicle body tilting and locking mechanism(RH driving, self-unloading) （1B24950280026 后悬置总成）Rear suspension assy 适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）

标号 No

零件代号


Part Name and Spec.

Part Code

用量

车型

Total

.

Vehicle Model 1SB2495020302

车身悬置翻转锁止机构(右舵

Vehicle body tilting and locking mechanism(RH

1

自卸)

driving, self-unloading)

1B24950280026

后悬置总成

Rear suspension assy

1

1

1B24950200175

后支撑座总成

Rear strutting base assy

2

2

Q150B0830

六角头螺栓

Hexagon head bolt

8

3

Q40308

弹簧垫圈

Spring washer

8

4

Q40108

平垫圈

Flat washer

8

5

1B24950200022

减震垫总成

Damping cushion assy

2

6

1B24950200073

缓冲块固定座总成

Buffer block fixing clip seat assy

2

7

1B24950280034

后悬限位橡胶块总成

8

1B24950200012

后悬上框焊接总成

Rear suspend upper frame welded assy

1

9

1B24950200081

摇臂总成

Rocker arm assy

2

10

1B24950200132

后减震器总成

Rear absorber assy

2

11

1B24950200021

上缓冲块总成

Upper buffer block assy

2

12

1B24950200082

螺旋弹簧

Spiral spring

2

13

1B24950200168

下缓冲块总成

Lower buffer block assy

2

14

1B24950200038

延伸梁

Extended beam

2

15

Q150B1030

六角头螺栓

Hexagon head bolt

8

16

Q40310

弹簧垫圈

Spring washer

8

17

Q40110

平垫圈

Flat washer

8

18

1B24950200334

后悬下框焊接总成

Rear suspension lower frame welded assy

1

Rear suspension limit rubber block assy

- 143 -

2

3253DLPJE-0R ZA01

用量 Total


用量 Total


用量 Total


1SB2495020302 车身悬置翻转锁止机构(右舵自卸) Vehicle body tilting and locking mechanism(RH driving, self-unloading) （1B24950280026 后悬置总成）Rear suspension assy 适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）

标号 No

零件代号


Part Name and Spec.

Part Code

用量

车型

Total

.

Vehicle Model

19

Q40110

平垫圈

Flat washer

8

20

Q40310

弹簧垫圈

Spring washer

8

21

Q340B10

1 型六角螺母


8

22

1B24950200275

后悬连接板

Rear suspension connecting plate

2

23

1B24950200323

后悬过渡支架

Rear suspension transition

4

24

Q150B1460

六角头螺栓

Hexagon head bolt

8

25

Q40114

平垫圈

Flat washer

8

26

Q40314

弹簧垫圈

Spring washer

8

27

Q340B14

1 型六角螺母


8

28

Q5101275

销轴

Axis pin

1

29

Q40112

平垫圈

Flat washer

1

30

Q50112

锁销

Lock pin

1

- 144 -

`

用量 Total


用量 Total


用量 Total


1SB2495062113车身标志（AUMAN 9 290W）Body mark-AUMAN 9 290W1SB2495061007车身标志(车前标志ETX 出口车)Vehicle mark (vehicle front mark ETX for export)

3 2

- 145 -

1SB2495062113 车身标志（AUMAN 9 290W）Body label-AUMAN 9 290W1SB2495061007 车身标志(车前标志 ETX 出口车)Vehicle mark (vehicle front mark ETX for export) 标号 No.



Part Name and Spec.

Part Code

用量 Total

1SB2495062113

车身标志（AUMAN 9 290W

Body label-AUMAN 9 290W

1

1SB2495061007

车身标志(车前标志 ETX 出口车)

Body label (vehicle front mark ETX for export)

1

1

1B24950620113

AUMAN 9 290W

AUMAN 9 290W

2

2

1B24950600400

AUMAN 前标(H3)

Front label, "AUMAN" (H3)

1

3

1B24950600401

FOTON 前标(H3)

FOTON front label (H3)

1

4

1B24950600030

格栅标志总成

Grille label assy

1

5

Q40105

平垫圈

Flat washer

3

6

Q40305

弹簧垫圈

Spring washer

3

7

Q340B05

1 型六角螺母


3

- 146 -


用量 Total


用量 Total


用量 Total


1SB2495120501 地板装饰件（右置车）-1

Floor decorative fitting (RHD)-1

7

6 4 1 5

4

11

20

3

13 20

14

2 11

15

21

8

13

16

22 4

11 4

18 19

15

18 19

19

15

19 20

18

13

4

25

17

23 24

- 147 -

12

4 9 10

4 9 10

4 9 10

1SB2495120501 地板装饰件（右置车）-1 标号 No.

Floor decorative fitting (RHD)-1 适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）

零件代号


Part Name and Spec.

Part Code

用量

车型

用量

Total

Vehicle Model

Total

1

1SB2495120501

地板装饰件（右置车）

Floor decorative fitting (RHD)

1

1B24951205051

鼓包隔热垫

Heat insulating mat, floor jut

1

2

1B24951205053

鼓包隔热垫左支架

Heat insulating mat LH , floor jut

1

3

Q1460630



平垫组合件

washer combination

4

Q40210

大垫圈

Big washer

5

Q1460625



平垫组合件

washer combination

6

1B24951205054

鼓包隔热垫右支架

Heat insulating mat RH , floor jut

1

7

1B24951205100

地毯总成

Carpet assy

1

8

1B24951200252

后地板隔热垫

Rear floor insulating mat

1

9

Q40206

大垫圈

Big washer

3

10

Q2714830

自攻螺钉

Self-tapping screw

3

11

1B24937300045

塑料螺钉卡片

Plastic screw clip

6

12

1B24951200063

鼓包后橡胶板

Rear rubber plate, floor jut

1

13

1B24937300044

塑料螺钉

Plastic screw

6

14

1B24951201053

左前隔音板

LH front acoustic

1

15

1B24951200061

卡扣—隔音板

Snap button - acoustic

9

16

1B24951201255

左前隔热垫

LH front heat insulating mat

1

17

1B24951201054

右前隔音板

RH front acoustic

1

18

Q40106

平垫圈

Flat washer

8

19

Q1460825



平垫组合件

washer combination

2 16

- 148 -

3

18

3253DLPJE-0RZA0 1


用量 Total


用量 Total


1SB2495120501 地板装饰件（右置车）-1 标号 No.

Floor decorative fitting (RHD)-1 适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）

零件代号


Part Code

Part Name and Spec.

用量

车型

用量

Total

Vehicle Model

Total

20

Q360B08

2 型六角螺母


8

21

1B24951201057

左后隔音板

LH rear acoustic

1

22

1B24951201259

左后隔热垫

LH rear heat insulating mat

1

23

1B24951200260

右后隔热垫

RH rear heat insulating mat

1

24

1B24951280002

右后隔音板

RH rear acoustic

1

25

1B24951200256

右前隔热垫

RH front heat insulating mat

1

- 149 -


用量 Total


用量 Total


1SB2495120501 地板装饰件（右置车）-2 Floor decorative fitting (RHD)-2

9

11

9

9

9 10

10

10

2

1 2

4

7 4

4

2

4

2 2 3

6 6 2 2

地板总成

2 9 10 10

9 9 9 10

15 14 13 12

- 150 -

8 4

4 5

9 10

4

4

1SB2495120501 地板装饰件（右置车）-2 Floor decorative fitting (RHD)-2 标号 No.



Part Name and Spec.

Part Code

用量

车型

用量

Total

Vehicle Model

Total

1SB2495120501

地板装饰件（右置车）

Floor decorative fitting (RHD)

1

3253DLPJE-

1

1B24951205038

电动后视镜开关闷盖

Blank cover, electric rear-view mirror switch

1

0RZA01

2

Q2214216

自攻螺钉

Self-tapping screw

13

3

1B24951205024

中平台前部总成

Middle platform front assy

1

4

1B24951200041

塑料螺母

Plastic nut

9

5

1B24951205045

中平台后部总成

Middle platform rear assy

1

6

1B24951205035

螺钉闷盖

Screw-type blank cover

6

7

1B24951200008

右地毯压条

RH carpet press strip

1

8

1B24951200007

左地毯压条

LH floor pressing strip

1

9

1B24951200009

压条堵盖

Treadle bar cap

9

10

Q2204816

十字槽盘头自攻螺钉和


平垫圈组合件

combination

11

1B24982404072

ST4.2 簧片螺母

ST4.2 Spring nut

7

12

1B24951200044

地板左侧长圆孔盖

Long circular hole cover on the floor LH side

2

13

1B24951200047

PVC 堵盖 35

PVC Cap 35

1

14

1B24951280001

地板鼓包长圆孔大堵盖

Long circular hole big cover on the floor jut

1

15

Q2204832

十字盘头自攻螺钉和平

Self-tapping screw, w/cross slot and flat

垫圈组合件

washer combination

- 151 -

8

5


用量 Total


用量 Total


1SB2495210101风窗零部件 Windshield parts

福田

监

督

2

- 152 -

热线

1SB2495210101 风窗零部件 Windshield parts 适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）标号 No.

零件代号


Part Code

Part Name and Spec.

用量

车型

Total

Vehicle Model 1SB2495210101

风窗零部件

Windshield parts

1

3253DLPJE-0RZA

1

1B24952100001

前风窗玻璃

Front windshield glass

1

01

2

1B24952100012

前风窗玻璃密封条

Front windshield weatherstrip

1

3

1B24952100005

风窗排水管总成

Windshield drain pipe assy

2

4

1B24952100006

客户服务呼叫卡

Customer service calling card

1

- 153 -

用量 Total


用量 Total


用量 Total


1SB2495250701刮水器及洗涤器 Wiper and scrubber

1

1

4 2 2

7

3 2

5

2 6

10 8

2

9

2

12 11

9 9 9

- 154 -

1SB2495250701 刮水器及洗涤器 Wiper and scrubber 标号 No.



Part Code

Part Name and Spec.

用量 Total


1SB2495250701

刮水器及洗涤器

Wiper and scrubber

1

3253DLPJE

1

1B24952505022

左刮臂刮片总成

Blade assy, LH Blade Arm

2

-0RZA01

2

Q1460820


3

Q33008



4

4

1B24952505025

刮水电机总成

Wiper motor assy

1

5

1B24952505023

右刮臂刮片总成

Blade assy, RH Blade Arm

1

6

1B24952505026

雨刮连杆机构总成

Wiper link installation assy

1

7

1B24952508004

水管总成

Water pipe assy

1

8

1B24952500058

管夹

Pipe clamp

6

9

Q1460620


10

1B24952505001

洗涤罐总成

Washing tank assy

1

11

1B24937480110

粘线卡

Wire clamp, adhesive

1

12

1B24952500055

直角二通

Right-angle two-way connector

3

Hexagon head bolt, spring washer and flat washer combination


- 155 -

6

4

用量 Total


用量 Total


用量 Total


1SB2495310212保险杠组件 Bumper module 1

2

3

8

9

4

10 11 10 12

14 14

7 5 6

13 5

14

- 156 -

1SB2495310212 保险杠组件 Bumper module 标号 No.



Part Name and Spec.

Part Code

用量 Total

1SB2495310212

Vehicle

Model

l

Model



件

washer combination

2

Q40208

大垫圈

Big washer

2

3

1B24953100413

保险杠脚踏板

Bumper foot board

1

4

1B24953100484

保险杠分装总成

Bumper sub-mounting assy

1

5

Q1460820



件

washer combination

1B22053100114

左大灯固定支架总成

LH headlamp fixing assy

1

1B22053100115

右大灯固定支架总成

RH headlamp fixing assy

1

六角头螺栓、弹簧垫圈和平垫圈组

Hexagon

合件

washer combination


Hexagon

合件

washer combination Bumper foot board fixing assy


4

10

7

Q1461035

8

Q1461025

9

1B22053100117

保险杠脚踏板固定支架总成

10

Q1461440

六角头螺栓平垫弹垫组合件

11

1B24953100414

保险杠支撑管总成

Bumper strutting pipe assy

1

1B24953100417

左大灯支架连接支架

Connecting bracket, LH headlamp bracket

1

1B24953100418

右大灯支架连接支架

Connecting bracket, RH headlamp bracket

1

1B24953100415

左车架连接支架

Connecting bracket, LH frame

1

1B24953100416

右车架连接车架

Connecting bracket, RH frame

1

Q340B10

1 型六角螺母


8

14

Vehicle 3253DLPJ

2

13

车型

Tota

E-0RZA01

Q1460825

12

用量

Bumper module

保险杠组件

1

6

车型



- 157 -

4 2 10

用量 Total


用量 Total


1SB2495310501前围附件-1 Front wall accessories-1 5

9

8

15

1

5

5

5

3

2

7 28,29

14

5 5

15 9

4

9

10 31 9

19 14

20 21

9

28,29

11,12 27

9

5 5

22

10

16 17

5 5

23 26

25

18 5 5

23 9 9

9

6

30 9

- 158 -

9

24

24

25

1SB2495310501 前围附件-1 Front wall accessories-1 标号 No.



Part Name and Spec.

Part Code

用量 Total


1SB2495310501

前围附件

Front wall accessories

1

3253DLPJ

1

1B24953104010

前盖板装饰板

Front cover plate trim

1

E-0RZA01

2

1B24953105019

雨刷固定板焊接总成

Wiper fixing plate welded assy

1

3

1B24953100054

右前围扶手及铰链总成

RH front wall handrail and hinge assy

1

4

1B24953100053

左前围扶手及铰链总成

LH front wall handrail and hinge assy

1

5

Q2204816

十字槽盘头自攻螺钉和平垫圈组合


件

combination

6

1B24953104042

左装饰角板总成

LH decorative angle plate assy

1

7

1B24953104001

前翻转盖板总成

Front tilting cover plate assy

1

8

1B24953104029

右装饰角板总成

RH decorative angle plate assy

1

9

Q1460820


10

1B24953104043

翻转盖板锁扣总成

Turning cover plate locking button assy

11

Q2713513

十字槽盘头自攻螺钉-C 型（上下壳

Pan head self-tapping screw ¨C Type (upper

体）

and lower shell)

12

Q40204

大垫圈

Big washer

25

13

Q1840616


Hexagon flange bolt

2

14

Q32006


Hexagon flange nut

2

15

Q1460620


16

1B24953104032

左上罩网

LH upper screen

1

17

1B24953104036

左中罩网

Middle LH veil mats

1

18

1B24953104038

左下罩网

LH lower screen

1



- 159 -

12

10 2 25

4

用量 Total


用量 Total


用量 Total


1SB2495310501 前围附件-1 Front wall accessories-1 标号 No.



Part Name and Spec.

Part Code

用量 Total


19

1B24953104035

右上罩网

RH upper screen

1

20

1B24953104037

右中罩网

RH middle screen

1

21

1B24953104039

右下罩网

RH lower screen

1

22

1B24953100014

限位锁钩柱销总成

Locking hook limit pin assy

1

23

Q40106

平垫圈

Flat Washer

2

24

Q40306

弹簧垫圈

Spring washer

2

25

Q174B0612

六角头头部带十字槽螺栓

Hexagon head bolt,w/cross slot on head

2

26

1B24953104061

左角板下支架焊接总成

Lower bracket welded assy, LH angle plate

1

27

1B24953104062

右角板下支架焊接总成

Lower bracket welded assy, RH angle plate

1

28

Q2723516



13

29

Q40104

平垫圈

Flat Washer

13

30

1B24953104052

缓冲块右支架

Buffer block RH

1

31

1B24953104051

缓冲块左支架

Buffer block LH

1

- 160 -

用量 Total


用量 Total


用量 Total


1SB2495310501前围附件-2

Front wall accessories-2

11

3

12 13

14

2

8

15

16

6

15

18

4

15 5 9 10

15

- 161 -

1SB2495310501 前围附件-2

Front wall accessories-2 适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）

标号

零件代号

No

Part Code


Part Name and Spec.

.

用量

用量

Tota

Tota

l 1SB24953105 01

1

前围附件

Front wall accessories

雨刷固定板密封条总成

Windshield wiper fixing plate weathstrip assy

1

撑杆及支架总成

Stay pole and bracket assy

1

限位锁钩总成

Limit locking hook assy

1

操纵机构总成

Operation mechanism assy

1

拉丝右支架总成

Pulling wire RH bracket assy

1

拉丝左支架总成

Pulling wire LH bracket assy

1

右侧密封条总成

RH weatherstrip assy

1

左侧密封条总成

LH weatherstrip assy

1

右中密封条总成

RH middle weatherstrip assy

1

左中密封条总成

LH middle weatherstrip assy

1

下缓冲块

Lower Buffer block

4

1B249531040 1

46 1B249531040

2

12 1B249531000

3

13 1B249531040

4

15 1B249531050

5

17 1B249531050

6

16 1B249531040

7

23 1B249531040 25 1B249531040

8

24 1B249531040 26 1B249531000

9

56

- 162 -

车型 Vehicle Model 3253DLPJE-0RZ A01

l

车型 Vehicl e Model

用量 Tota l


用量 Tota l


1B249531050 10

01

防雨帘

Rainproof curtain

1

不干胶孔贴￠25

Hole-capping sticker ￠25

11

不干胶孔贴￠35

Hole-capping sticker ￠35

2

拉丝夹子

Pulling wire clip

3

堵盖-前围

Cap - front wall

1

雨刷固定板夹子

Windshield wiper fixing plate clamp

14


Hexagon head bolt, spring washer and flat washer

件

combination


Hexagon

合件

combination

1B249531000 11

47 1B249531000 48 1B249531000

12

44 1B249531000

13

31 1B249531000

14

59

15

Q1460816

16

Q1460616

17

Q32010


Hexagon flange nut

2

18

Q1460624

六角头组合螺栓

Hexagon head combined bolt

2

bolt, spring washer and flat washer

- 163 -

6 1

1SB2495350503仪表板 Dashboard 1

5

5

5 7

4

5 2

18

5

11

5

15

5 5

13 5

5 5

5 5

- 164 -

1SB2495350503 仪表板 Dashboard 标号 No.



Part Code

Part Name and Spec.

用量 Total


1SB2495350503

仪表板

Dashboard

1

3253DLP

1

1B22053504090

左喇叭面罩总成

LH horn mask assy

1

JE-0RZA

2

Q1461030

六角头螺栓、弹簧垫圈和平垫圈组合件

3

1B24953505120

仪表板分装总成

Dashboard sub-mounting assy

1

4

1B22053504095

右喇叭面罩总成

RH horn mask assy

1

5

Q2214216

自攻螺钉

Self-tapping screw

35

6

1B24953505055

右角板总成

RH angle plate assy

1

7

1B24953505021

左角板总成

LH angle plate assy

1

8

Q2204216

十字槽盘头自攻螺钉和平垫圈组合件

9

1B24953505014

中间面板总成

Middle assy

1

10

1B24953505031

驾驶侧饰条总成

Driver side trimming assy

1

11

1B24953505039

副驾驶侧裙板总成

Codriver side skirt plate assy

1

12

1B24953505037

中下裙板总成

Lower Middle skirt plate assy

1

13

1B24953505033

中间饰条总成

Middle trimmings assy

1

14

1B24953505001

仪表板面罩总成

Dashboard mask assy

1

15

1B24953505035

副驾驶侧饰条总成

Codriver side trimming assy

1

16

1B24953505017

中右面板总成

Middle RH assy

1

17

1B24953505028

继电器盒盖总成

Relay case cover assy

1

18

1B24982404072

ST4.2 簧片螺母

ST4.2 Spring nut

13

Hexagon

bolt, spring washer and

flat washer combination

Pan head screw(w/cross slot) and flat washer combination

- 165 -

6

4

01

用量 Total


用量 Total

车型

用量

车型

Vehicle

Tota

Vehicle

Model

l

Model

1SB2495410603侧围附件 Side wall accessories

37 28 38

38

7

18

10

36

7 10

4

40 40

5 19 19

17 19

5 19 12 17

- 166 -

3

1SB2495410603 侧围附件 Side wall accessories 标号 No.



Part Code

Part Name and Spec.

用量 Total

侧围附件

Side wall accessories

1

1B22082400014

大卡扣

Big snap button

10

2

1B24954100012

门框防护条总成

Door frame protection bar assy

2

3

1B24953100031

堵盖-前围

Cap - front wall

2

4

1B24954100060

堵盖-侧围

Cap-side pannel

2

5

1B24954100033

后侧上车扶手

Rear side handrail for getting on vehicle

2

6

1B24954104101

前支柱内护板左

Front pillar inner guard board, LH

1

1B24954100003

左侧围前内饰板

LH wall front inner trim

1

1B24954100004

右侧围前内饰板

RH wall front inner trim

1

1B24954104025

左后侧窗玻璃密封条

LH rear side window glass weatherstrip

1

1B24954104026

右后侧窗玻璃密封条

RH rear side window glass weatherstrip

1

1B24954104123

左后侧窗玻璃总成

LH rear side window glass assy

1

1B24954104124

右后侧窗玻璃总成

RH rear side window glass assy

1

1B24954100007

左侧围上内护板

LH wall upper inner guard board

1

1B24954100008

右侧围上内护板

RH wall upper inner guard board

1

1B24954100010

左侧围下内护板

LH wall lower inner guard board

1

1B24954100011

右侧围下内护板

RH wall lower inner guard board

1

1B24954100026

左后侧围支架

LH rear wall

1

1B24954100027

右后侧围支架

RH rear wall

1

1B24954104031

左前支柱扶手总成

LH front pillar handrail assy

1

1B24954104032

右前支柱扶手总成

RH front pillar handrail assy

1

1B24954100034

左支柱扶手支架

LH pillar handrail

1

1B24954100035

右支柱扶手支架

RH pillar handrail

1

1B24954104001

防溢胶条左

LH spill rubber bar

1

8 9

10

11 12

13

14 15

Vehicle Model 3253DLPJE-

1SB2495410603

7

车型

- 167 -

0RZA01

用量 Total


用量 Total


用量 Total


标号 No.



Part Name and Spec.

Part Code

用量 Total

1B24954104002

防溢胶条右

RH spill rubber bar

1

16

1B24954100009

卡扣―侧护板

Snap button - side guard board

6

17

1B24954100048

孔贴 50

Hole-capping sticker 50

2

18

1B24954104102

前支柱内护板右

Front pillar inner guard board, RH

1

19

Q1460620


20

Q40208

大垫圈

Big washer

1

21

1B24953100044

拉丝夹子

Pulling wire clip

1

22

1B24954105031

前支柱扶手总成

Front pillar handrail assy

2

23

1B24954104056

拉线控制扳手总成

Pull-wire control lever assy

1

24

1B24954104067

工具箱扳手装饰罩

Tool box spanners decorative cover

1

25

1B24954104053

工具箱铰链总成

Tool box hinge assy

1

26

1B24954104055

工具箱开启拉线总成

Tool box opening pull wire assy

1

27

Q2360612

螺钉、平垫和弹垫组合件

Screw, spring washer and flat washer combination

2

28

Q2360620

十字槽盘头螺钉、弹垫和平垫组合件

29

1B24954104054

工具箱盖总成

Tool box cover assy

1

30

Q340B06

1 型六角螺母


2

31

1B24954104063

工具箱本体总成

Tool box body assy

1

32

Q1420820

六角头螺栓和弹簧垫圈组合件

Hexagon head bolt and spring washer component

1

33

1B24954100013

门框防水条总成左

Door frame water-proof weathstrip assy, LH

1

34

1B24954100028

门框防水条总成右

Door frame water-proof weathstrip assy, RH

1

35

Q32006


Hexagon flange nut

2

36

1B24954100005

左后装饰板

LH rear trim

1

1B24954100006

右后装饰板

RH rear trim

1


Pan head screw(w/cross slot), spring washer and flat washer combination

- 168 -

6

13


用量 Total


用量 Total


用量 Total


标号 No.



Part Code

Part Name and Spec.

用量 Total

37

1B24957224052

高顶拉手

High roof handle

1

38

1B24954100054

卡扣－侧护板(黑色)

Snap button - side guard board (black)

4

39

Q1460820


40

Q2300620

盘头十字槽螺钉

Hexagon head bolt, spring washer and flat washer combination Pan head screw (w/cross slot)

- 169 -

2 4


用量 Total


用量 Total


用量 Total


1SB2495610101后围附件 Rear wall accessories

5

1

1 2

7 10

6

7 6 10

7 6

7 6

7 6 10

3

10 8

4

- 170 -

9

5

1SB2495610101 后围附件 Rear wall accessories 适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）标号 No.

零件代号


Part Code

用量

Part Name and Spec.

Total


1SB2495610101

后围附件

Rear wall accessories

1

3253DLPJE-0RZ

1B24956100004

后围右上装饰板

Upper trim , Rear wall

1

A01

1B24956100003

后围左上装饰板

LH upper trim , rear wall

1

2

1B24956100013

后围内饰板

Rear wall inner trim

1

3

1B24956100007

后窗玻璃密封条

Rear window glass weatherstrip

1

4

1B24956100006

后窗玻璃

Rear window glass

1

5

1B24956100005

后围隔音板

Rear wall acoustic

2

6

1B24956100002

塑料螺栓

Plastic bolt

5

7

1B24956100001

塑料螺扣

Plastic screw jaw

5

8

1B24956100008

堵盖-后围

Cap, rear wall

1

9

Q1460820

六角头螺栓、弹簧垫

Hexagon head bolt, spring washer and

圈和平垫组合件

flat washer combination

10

1B24954100009

卡扣—侧护板

Snap button -side guard board

1

3 4

- 171 -

用量 Total


用量 Total


用量 Total


1SB2495720404顶盖附件 Top cover accessories

15

15 15 7

15

6 11 16

- 172 -

1SB2495720404 顶盖附件 Roof accessories 适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）标号 No.

零件代号 Part Code 1SB2495720404

顶盖附件

Roof ries

1

1

1B24957200011

左前窗帘导轨总成

LH front window curtain rail assy

1

2

1B24957200024

顶盖前扶手总成

Roof front handrail assy

1

1B24957200006

前顶盖左外饰板

Front roof LH external trim

1

4

1B24957200007 1B24957200004

前顶盖右外饰板前顶盖中外饰板

Front roof RH external trim Front roof middle external trim

1 1

5

1B24957200025

前顶盖内饰板

Front roof internal trim

1

1B24957200001

中顶盖内饰板总成

Middle roof internal trim assy

1

3

6


Part Name and Spec.

用量 Total

1B24957200002

后顶盖内饰板总成

Inner trim assy, rear roof

1

7

1B24957200013

中窗帘导轨总成

Middle window curtain rail assy

1

8

1B24957200014

后窗帘导轨总成

Rear curtain guide rail assy

1

9

1B24957200012

右前窗帘导轨总成

Front window curtain rail assy

1

10

Q1460625

六角头螺栓、弹簧垫圈和平垫圈组合件

Hexagon bolt, spring washer and flat washer combination

2

11

1B24957200015

塑料螺母-导轨

Plastic nut - rail

32

12

1B24957200005

卡扣座—顶饰板

Snap button - roof trim

4

13

1B24954100018

卡扣—通风罩

Snap button - vent cover

8

14

1B24954100019

卡扣座—通风罩

Snap button - vent cover

4

15

1B24954100009

卡扣—侧护板

Snap button - side guard board

15

16

Q2204819

十字槽盘头自攻螺钉和平垫圈组合件

Pan head screw(w/cross slot) and flat washer combination

32

17

Q1460820



8

18

1B24957200010

塑料护套

Plastic bushing

3

19

1B24957200019

平顶窗帘总成

Flat roof curtain assy

1

- 173 -


用量 Total


用量 Total


用量 Total


1SB2496120603前侧车门附件

Front side vehicle door accessories

2 用户须知

- 174 -

1SB2496120603 前侧车门附件标号 No.

Front side vehicle door accessories 适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）

零件代号


用量

Part Name and Spec.

Part Code

Total


1SB2496120603

前侧车门附件

Front side vehicle door accessories

1

3253DLPJ

1

1B24961204112

右车门内护板总成

RH door inner guard board assy.

1

E-0RZA01

2

1B24961200069

烟灰缸总成右

Ashtray assy, RH

1

1B24961200022

左车门玻璃总成

LH door glass assy.

1

1B24961200023

右车门玻璃总成

RH door glass assy.

1

1B24961200041

左车门玻璃密封条总成

LH door glass weathstrip assy.

1

1B24961200042

右车门玻璃密封条总成

RH door glass weathstrip assy.

1

5

1B24961200016

烟灰缸总成左

Ashtray assy, LH

1

6

1B24961200017

烟灰缸支架

Ashtray

2

1B24961200018

左内扶手总成

LH inner handrail assy

1

1B24961200019

右内扶手总成

RH inner handrail assy

1

1B24961200020

左内扶手支架

LH inner handrail

1

1B24961200021

右内扶手支架

RH inner handrail

1

1B24961200036

左限位夹片

LH limit clip

1

1B24961200066

右限位夹片

RH limit clip

1

1B24961204111

左车门内护板总成

LH door inner guard board assy.

1

1B24961200043

左车门密封条

LH door weatherstrip

1

1B24961200044

右车门密封条

RH door weatherstrip

1

1B24961204109

左车门下装饰板衬板

LH door lower decorative lining plate

1

1B24961204110

右车门下装饰板衬板

RH door lower decorative lining plate

1

1B24961204101

左车门下装饰板总成

LH door lower decoration plate assy

1

1B24961204102

右车门下装饰板总成

Lower trim assy of RH door

1

1B24961200037

左车门窗台外密封条总成

LH door window sill outer weathstrip assy.

1

3 4

7 8

9 10 11 12

13 14

- 175 -

用量 Total


用量 Total


用量 Total




零件代号


Part Code

用量

Part Name and Spec.

Total 1B24961200038

右车门窗台外密封条总成

RH door window sill outer weathstrip assy.

1

1B24961200049

左车门窗台贴片

LH window sill sticker

1

1B24961200050

右车门窗台贴片

RH window sill sticker

1

1B24961200039

左车门窗台内密封条总成

LH door window sill inner weathstrip assy.

1

1B24961200040

右车门窗台内密封条总成

RH door window sill inner weathstrip assy.

1

17

1B24961200063

卡扣-车门下饰板

Snap button - vehicle door lower trim

8

18

1B24261200027

内护板卡扣

Inner guard board snap button

2

19

1B24961200120

用户须知

Advice for Consumers

1

20

1B24961200079

左内扶手闷盖 A

LH inner handrail blank cover A

1

21

1B24961200082

扶手护罩夹片

Handrail cover clip

2

1B24961200027

左前车门导轨总成

LH front door rail assy

1

1B24961200028

右前车门导轨总成

RH front door rail assy

1

1B24961200029

左后车门导轨总成

LH rear door rail assy

1

1B24961200030

右后车门导轨总成

RH rear door rail assy

1

23

1B24961200081

右内扶手闷盖

RH inner handrail blank cover cover

1

24

1B24961200080

左内扶手闷盖 B

LH inner handrail blank cover B

1

1B24961200045

左车门前防水薄膜

Water proof diaphragm, before LH door

1

1B24961200046

右车门前防水薄膜

Water proof diaphragm, before RH door

1

26

1B24961200047

车门后防水薄膜

Door rear water proof diaphragm

2

27

1B24961200053

半圆头堵片

Half-round head end cover

2

28

1B24961200013

卡扣—车门护板

Snap button - door guard board

10

29

1B24961200051

圆形缓冲垫

Circular buffer pad

4

30

1B24957200005

卡扣座—顶饰板

Snap button seat - roof trim

2

15 16

22

25

- 176 -


用量 Total


用量 Total


用量 Total




零件代号


用量

Part Name and Spec.

Part Code

Total

31

1B24951200041

塑料螺母

Plastic nut

17

32

1B24954100019

卡扣座—通风罩

Snap button seat - vent cover

6

33

1B24961200054

下通风口堵盖

Cap, lower ventilation openning

1

34

1B24984300029

卡扣—挡泥板

Snap button - mudguard

8

35

1B24984300030

卡扣座—挡泥板

Snap button seat - mudguard

8

36

1B24961200035

前门长钉

Front door long nail

4

37

1B22061200015

塑料卡扣

Plastic snap button

8

38

Q2204812

十字槽自攻螺钉

Self-tapping screw (w/cross slot)

8

39

Q2204816



圈组合件

combination

40

Q2712913

十字盘头自攻螺钉

Self-tapping screw (w/cross slot)

4

41

1B24961200067

卡扣座-车门下饰板

Snap button seat- vehicle door lower trim

8

1B24961204211

ETX 车门窗台贴片左

(LH) ETX window sill sticker

1

1B24961204212

ETX 车门窗台贴片右

(RH) ETX window sill sticker

1

1B24961204213

ETX 车门侧标贴片左

(LH) ETX door side mark sill sticker

1

1B24961204214

ETX 车门侧标贴片右

(RH) ETX door side mark sill sticker

1

42

- 177 -

10


用量 Total


用量 Total


用量 Total


1SB2496140101玻璃升降机构(手动) Glass lifter mechanism(manual)

5 2

2 1

- 178 -

1SB2496140101 玻璃升降机构(手动) Glass lifter mechanism(manual) 适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）标号 No.

零件代号


Part Code

Part Name and Spec.

用量 Total


1SB2496140101

玻璃升降机构(手动)

Glass lifter mechanism(manual)

1

3253DLPJE-0RZA0

1B24961400101

左玻璃升降器总成

LH Glass lifter assy

1

1

1B24961400102

右玻璃升降器总成

RH Glass lifter assy

1

2

Q32006


Hexagon flange nut

2

3

Q2360612

螺钉、平垫和弹垫组合件

4

1B24961400004

升降器摇把总成

Lifter crank assy

2

1B24961400002

左升降器支板总成

LH lifter ing plate assy

1

1B24961400003

右升降器支板总成

RH lifter bracket assy

1

1

5

Screw, spring washer and flat washer combination

6

- 179 -

用量 Total


用量 Total


用量 Total


1SB2496150101门锁

Door lock 15

14

1

13

9

2 11

12

9

8

3 10

7 4 5

6

5

- 180 -

1SB2496150101 门锁标号 No.

Door lock 适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）

零件代号


Part Name and Spec.

Part Code

用量 Total

1SB2496150101

门锁

Door lock

1

十字槽沉头螺钉和锥形垫圈

Sunk screw(w/cross slot)and conical washer

组合件

combination

4

1

Q2400820

2

1B24961500051

锁扣总成

Lock catch assy

2

1B24961500111

左前门锁体总成

LH front door lock assy

1

1B24961500211

右前门锁体总成

RH front door lock assy

1

十字槽沉头螺钉和锥形锁紧

Sunk screw(w/cross slot)and conical locking-washer

垫圈组合件

combination

3

6

4

Q2400620

5

Q2400610

十字槽沉头螺钉

Sunk screw (w/cross slot)

6

6

1B24961500011

固定夹片

Fixing clip

2

1B24961500091

左锁芯总成

LH lock core assy

1

1B24961500092

右锁芯总成

RH lock core assy

1

1B24961500041

左外开把手总成

LH inwars opening handle assy

1

1B24961500042

右外开把手总成

RH outwards opening handle assy

1

Q32006


Hexagon flange nut

4

1B24961500081

左传动机构总成

LH driving mechanism assy

1

1B24961500082

右传动机构总成

RH driving mechanism assy

1

1B24961500012

固定卡座

Fixing seat

4

1B24961500071

左内开拉杆

LH inwards opening pull rod

1

1B24961500072

右内开拉杆

LH inwards opening pull rod

1

1B24961500061

左内锁止拉杆

LH I/S locking rod

1

1B24961500062

右内锁止拉杆

RH I/S locking rod

1

1B24961500031

左内开把手总成

LH inwards opening handle assy

1

7

8 9 10 11 12 13 14

- 181 -

车型 Vehicle Model 3253DL PJE-0RZ A01

用量 Total


用量 Total


用量 Total


1SB2496150101 门锁标号 No.



用量

Part Name and Spec.

Part Code

Total 1B24961500032

15

Door lock

Q2214816

右内开把手总成

RH inwards opening handle assy

十字槽盘头自攻螺钉、大垫圈

Pan

组合件

combination

head

screw(w/cross

slot)

1 and

- 182 -

flat

washer

2


用量 Total


用量 Total


用量 Total


1SB2497040502卧铺装置 Sleeper device

1

- 183 -

1SB2497040502 卧铺装置 Sleeper device 适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）

标号

零件代号

零件名称及规

Part Name and

No.

Part Code

格

Spec.

1

用量

车型

用量

车型

用量

车型

用量

车型

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

3253DLPJE-0RZA01

1SB2497040502

卧铺装置

Sleeper device

1

1B24970405001

下卧铺总成

Lower sleeper assy

1

- 184 -

1SB2497910109音响装置Audio device

3 2

1

4

6

5

7

- 185 -

1SB2497910109 音响装置 Audio device 标号 No.



用量

Part Name and Spec.

Part Code

Total


1SB2497910109

音响装置

Audio device

1

3253DLPJE-0RZ

1

1B24979100030

扬声器

Speaker

2

A01

2

1B24953100044

拉丝夹子

Pulling wire clip

8

3

1B24979100060

护孔圈

Grommet

1

4

1B24979100040

天线总成

Antanna assy

1

5

1B24979100070

天线电缆

Antenna cable

1

6

1B24979100100

收放机总成

Radio & player assy

1

7

Q2204216



圈组合件

washer combination

- 186 -

12

用量 Total


用量 Total


用量 Total


1SB2498110709暖气装置

Heater 3

A

3

23 1

16 2

6

20

15

3

11

13

13

4

13 18

5 9

A 5 21

2

5

5 22 17

5

14

B

5 5

8 B

1

5

24

3 7

10 8

8 4

- 187 -

6

1SB2498110709 暖气装置标号 No.

Heater 适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）

零件代号


用量

Part Name and Spec.

Part Code

Total 1SB2498110709

暖气装置

Heater

1

六角头螺栓、弹簧垫圈和平垫

Hexagon

圈组合件

combination

管路支架

Pipeline



组合件

washer combination

bolt, spring washer and flat washer

4

1

Q1460830

2

1B24981210044

3

Q1460620

4

Q32008


Hexagon flange nut

4

5

Q676B25

C 型蜗杆传动式软管卡箍

Worm driven hose hoop, type C

8

6

Q32006


Hexagon flange nut

12

7

1B22081110036

支架

2

8

1B22081210022

支架

2

9

1B24981194042

底盘暖风管路总成

Chassis warm air pipeline assy

1

10

1B24981190342

底盘暖风管路总成

Chassis warm air pipeline assy

1

11

Q68616F4

单管夹片

Pipe clamp

1

12

Q1460820



组合件

washer combination

13

1B24981190031

暖风总成

Air heater assy

1

14

1B24981190300

前围管路总成

Front wall pipeline assy

1

15

1B24981190077

支架

1

16

1B24981190105

驾驶侧下出风管总成

Driver side lower vent assy

1

17

1B24981200069

左下风管固定板

LH lower air duct fixing plate

1

18

1B24981190102

中部下出风管总成

Middle lower air outlet pipe

1

19

1B24981190103

副驾驶侧下出风管总成

Codriver side lower air outlet pipe

1

1

- 188 -

12

2


用量 Total


用量 Total


用量 Total


1SB2498110709 暖气装置标号 No.

Heater 适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）

零件代号


Part Code

用量

Part Name and Spec.

Total

20

1B24981190004

蒸发器管路护罩总成

Evaporator pipeline shield assy

1

21

1B24981190002

暖风水管护罩

Warm air water pipe shield

1

22

1B24981190027

空调控制面板

Airconditioner control plate

1

23

1B24981290074

鼓风机总成

Blower assy

1

24

Q2214216

自攻螺钉

Self-tapping screw

4

- 189 -


用量 Total


用量 Total


用量 Total


1SB2498210502后视镜 Rear-view mirror

1B24957200025Front roof internal trim

RH door assy

LH door assy

- 190 -

1SB2498210502 后视镜 Rear-view mirror 标号 No.



用量

Part Name and Spec.

Part Code

Total


1SB2498210502

后视镜

Rear-view mirror

1

3253DLP

1

Q32008


Hexagon flange nut

8

JE-0RZA

2

1B22082105005

前下视镜总成

Front under - view mirror assy

1

01

3

1B24982105001

左后视镜总成

LH back - view mirror assy

1

3.1

1B24982104009

左后视镜下底座装饰盖板

3.2

1B24982105008

左广角镜本体总成

LH Wide-angle mirror body assy

1

3.3

1B24982184003

左后视镜支架总成

Rear-view mirror assy (RH)

1

3.4

1B24982104011

左手动后视镜本体总成

4

Q218B0830

内六角圆柱头螺钉

Hexagon socket cheese-head screw

4

5

1B24982105004

侧下视镜总成

Side under-view mirror assy

1

6

1B24982105002

右后视镜总成

RH rear-view mirror assy

6.1

1B24982104010

右后视镜下底座装饰盖板

6.2

1B24982104012

右手动后视镜本体总成

RH Manual-operated rear-view mirror body assy

1

6.3

1B24982184006

H3 广角镜本体

H3Wide-angle mirror body

1

6.4

1B24982184004

右后视镜支架总成

Rear-view mirror assy (RH)

1

Lower base decorative cover plate, LH rear view mirror

LH Manual-operated rear-view mirror body assy

Lower base decorative cover plate, RH rear view mirror

- 191 -

1

1

1

用量 Total


用量 Total


用量 Total


1SB2498220101安全带Seat belt 1SB2498250101灭火器Fire extinguisher

3 2

1.1

6 1

5

4

1.4 1.3

5

1.2

- 192 -

1SB2498220101 安全带 Seat belt 1SB2498250101 灭火器 Fire extinguisher 标号 No.



用量

Part Name and Spec.

Part Code

Total


1SB2498220101

安全带

Seat belt

1

1SB2498250101

灭火器

Fire extinguisher

1

1

1B24982200000

安全带总成

Seat belt assy

1

1.1

1B24982200004

安全带卷收器总成

Seat belt retractor assy

2

1.2

1B24982200006

中间座锁扣总成

Middle seat lock-catch assy

1

1.3

1B24982200003

司机座锁扣总成

Driver seat lock-catch assy

1

1.4

1B24982200005

乘客座及中间座锁扣总成

2

1B24982200011

塑料螺栓―安全带

Plastic bolt¨Dseat belt

2

3

1B24982200001

塑料螺扣―安全带

Plastic screw jaw, seat belt

2

4

1B24982500002

灭火器支架总成

Fire extinguisher bracket assy

1

5

Q1460625

六角头螺栓、弹垫和平垫


组合件

washer combination

6

1B24982500005

灭火器

Fire extinguisher

enger seat and middle seat lock catch assy

1

2 1

- 193 -

3253DLPJE-0RZA01

用量 Total


用量 Total


用量 Total


1SB2498240404遮阳装置

Visor device

1

1

5

4 5

4

8

6

6

- 194 -

1SB2498240404 遮阳装置标号 No.

Visor device 适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）

零件代号


Part Name and Spec.

Part Code

用量 Total


1SB2498240404

遮阳装置

Visor device

1

3253DLPJ

1

1B24982404072

ST4.2 簧片螺母

ST4.2 Spring nut

2

E-0RZA01

2

1B24982400100

左顶置文件柜分总成

LH top-mounted filing cabinet subassy.

1

3

1B24982404079

平顶文件柜中部面板总成

4

Q2204216

5

Q40105

6

Q1460616

7

Middle assy, top-mounted filing cabinet

1

十字槽盘头自攻螺钉和平垫圈组


合件

washer combination

平垫圈

Flat washer


Hexagon

合件

washer combination

1B24982404085

开关面板总成

Switch assy

1

8

Q2300616

螺钉组合件

Screw combination

8

9

1B24982400101

右顶置文件柜分总成

RH top-mounted filing cabinet subassy.

1

2 2


- 195 -

12

用量 Total


用量 Total


用量 Total


1SB2498430212挡泥板-车架部分 Mudguard - frame

- 196 -

1SB2498430212 挡泥板-车架部分 Mudguard - frame 标号 No.



Part Name and Spec.

Part Code

用量 Total

1SB2498430212

1

挡泥板-车架部分

Mudguard - frame



组合件

combination



合件

washer combination

2

1

Q1461030

2

Q1460820

3

1B24984310034

内连接支架 I

Inner connecting bracket I

2

4

Q40208

大垫圈

Big washer

10

5

Q340B08

1 型六角螺母


10

6

Q340B06

1 型六角螺母


6

7

Q40206

大垫圈

Big washer

6

8

1B24984381065

后翼子板下挡泥板

Rear fender lower mudguard

2

9

Q1460620



合件

washer combination

10

1B24984381048

压板

Pressure plate

2

11

1B24984310037

后翼子板支架总成

Rear fender assy

2

1B24984381063

左后翼子板

LH rear fender

1

1B24984381064

右后翼子板

RH rear fender

1

13

Q340B10

1 型六角螺母


6

14

Q1461025



组合件

combination

1B24984381061

左后翼子板总成

(LH) Rear fender assy

1

1B24984381062

右后翼子板总成

(RH) Rear fender assy

1

12

15

- 197 -

10

6

4


用量 Total


用量 Total


用量 Total


1SB2498430405挡泥板－车身部分Mudguard-body part 2

8

1 2

1

2

2

3

1

2 2

3

13

11

3 2 2 4

12

3

13

3

12

6 5 6 9

6

6

8

8

14

7 2

2 1

8

1

9

9

8

8

9

10

2 1 9

15

14

8 2 1

2 2

1

2 16

- 198 -

1SB2498430405 挡泥板－车身部分 Mudguard-body part 适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）标号 No.

零件代号


Part Name and Spec.

Part Code

用量

车型

Total

Vehicle Model

1SB2498430405

挡泥板－车身部分

Mudguard-body part

1

3253DLPJE-0RZA0

1

Q1840616


Hexagon flange bolt

34

1

2

Q40106

平垫圈

Flat Washer

46

3

Q1840612

螺栓

Bolt

12

1B24984304005

左翼子板支架总成

LH fender assy

1

1B24984304006

右翼子板支架总成

RH fender assy

1

1B24984304001

左翼子板

LH fender

1

1B24984304002

右翼子板

RH fender

1

Q31206

B 型板簧螺母

Leaf spring nut, type B

18

1B24984304317

左副轮罩

LH auxiliary wheel house

1

1B24984304318

右副轮罩

RH auxiliary wheel house

1

8

Q40108

平垫圈

Flat Washer

24

9

Q1840825


Hexagon flange bolt

14

1B24984304051

左轮前上挡泥板

LH wheel front upper mudguard

1

1B24984304052

右轮前上挡泥板

RH wheel front upper mudguard

1

1B24984304027

左轮上挡泥板

LH wheel upper mudguard

1

1B24984304028

右轮上挡泥板

RH wheel upper mudguard

1

12

1B24984300030

卡扣座―挡泥板

Snap button seat - mudguard

6

13

1B24984300029

卡扣―挡泥板

Snap button - mudguard

6

14

Q340B08

1 型六角螺母


10

1B24984304011

左翼子板密封条

Weathstrip, LH fender

1

1B24984304012

右翼子板密封条

Weathstrip, RH fender

1

1B24984304013

左翼子板后密封条

1B24984304014

右翼子板后密封条

4 5 6 7

10

11

15 16

Rear weathstrip, LH fender Rear weathstrip, RH fender

1 1

- 199 -

用量 Total


用量 Total


用量 Total


1SB2498450403脚踏板-车身部分 Pedal-body part

- 200 -

1SB2498450403 脚踏板-车身部分 Step board-body part 标号 No.

适用车型及用量（件）Applicable vehicle model and needed quantity（PCS）零件代号 Part Code

2 3 4 5 6 7

Part Name and Spec.

用量 Total

1SB2498450403 1


脚踏板-车身部分

Step board-body part



组合件

washer combination

1B24984504005

左上脚踏板前支架总成

Front bracket assy, LH upper step board

1

1B24984504006

右上脚踏板前支架总成

Front bracket assy, RH upper step board

1

1B24984504007

左上脚踏板后支架总成

Rear bracket assy, LH upper step board

1

1B24984504008

右上脚踏板后支架总成

Rear bracket assy, RH upper step board

1

1B24984504035

左上脚踏板护罩(抬高 30)

LH upper step board hood (raised by 30)

1

1B24984504036

右上脚踏板护罩(抬高 30)

RH upper step board hood (raised by 30)

1



组合件

washer combination

1B24984504003

左上踏板垫

LH upper step board pad

1

1B24984504004

右上踏板垫

RH upper step board pad

1

Q32008


Hexagon flange nut

4

Q1460825

Q1460620

1

- 201 -

26

4


用量 Total


用量 Total


用量 Total


1SB2498450404脚踏板-自卸车Pedal -for dumping truck

6

6

- 202 -

1SB2498450404 脚踏板-自卸车 Step board -for dumping truck 标号 No.



Part Code

Part Name and Spec.

用量 Total


1SB2498450404

脚踏板-自卸车

Step board -for dumping truck

1

3253DLPJ

1B24984504063

左支撑管总成-自卸车

LH strutting pipe assy- for dumping truck

1

E-0RZA01

1B24984504064

右支撑管总成-自卸车

RH strutting pipe assy- for dumping truck

1

2

Q1461235

组合螺栓

Combined bolt

8

3

1B24982600172

螺栓安装块

Bolt mounting block

2

4

Q14612100



合件

washer combination

5

Q340B12

1 型六角螺母


6

Q1460825



合件

washer combination

7

1B24984504071

下吊挂踏板-自卸车

Lower hanger & step board - self-dumping

2

8

1B24984504073

下支撑管

Lower strutting pipe

2

1B24984504011

左下踏板垫

LH lower step board pad

1

1B24984504012

右下踏板垫

RH lower step board pad

1

1B24984504061

左下脚踏板护罩-自卸车

LH lower step board cover -for dumping truck

1

1B24984504062

右下脚踏板护罩-自卸车

RH lower step board cover -for dumping truck

1

1

9 10

2 4

- 203 -

24

用量 Total


用量 Total


用量 Total


1S325110002H8WD615.50发动机总成（213kW国产泵工程版）-单缸空气压缩机 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - Single-cylinder air compressor

- 204 -

1S325110002H8WD615.50 发动机总成（213kW 国产泵工程版）-单缸空气压缩机 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - Single-cylinder air compressor 标号 No.

零件代号 Part Code 1S325110002H8

1 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 25 26 27 28

612600130177 612600130173 609070161 612600130001 612600130124 612600130122 612600130123 90003320154 61500080158 612600130047 612600130073 612600130046 61500080165 90003802432S AZ1560130064 409020045 612600130045 192320002 90003070092 61500130097 90003802561 90003800458 90003802419 90003802415 90003932023 90003098014

零件名称及规格 WD615.50 发动机总成（213kW 国产泵工程版）空压机总成空压机齿轮支撑环六角螺母传动轴总成传动轴压紧块圆柱滚子轴承径向止推滚珠轴承衬套挡油盘夹紧螺母盖六角头螺栓喷油泵齿轮垫片六角螺母密封圈油封油封座六角头螺栓六角头螺栓六角头螺栓六角头螺栓波形弹性垫圈密封垫圈

Part Name and Spec. WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) Air compressor assy Air compressor gear ing ring Hexagon nut Propeller shaft assy Propeller shaft Pressing block Cylindrical roller bearing Radial thrust ball bearing Bush Oil-retaining pan Clamping nut Cover Hexagon head bolt Fuel injection-pump gear Shim Hexagon nut Seal gasket Oil seal Oil seal seat Hexagon head bolt Hexagon head bolt Hexagon head bolt Hexagon head bolt Wave spring washer Seal gasket

- 205 -

适用车型及用量（件） Applicable VehicleModel and needed quantity（PCS）用量车型用量车型用量车型用量车型 Total Vehicle Model Total Vehicle Model Total Vehicle Model Total Vehicle Model 3253DLPJE1 0RZA01 1 1 1 1 1 1 1 1 1 1 1 1 1 4 1 1 1 1 1 1 6 1 7 4 12 1

1S325110002H8WD615.50发动机总成（213kW国产泵工程版）-活塞连杆 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - piston connecting rod

- 206 -

1S325110002H8WD615.50 发动机总成（213kW 国产泵工程版）-活塞连杆 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - piston connecting rod 适用车型及用量（件）标号

零件代号

No.

Part Code

Applicable VehicleModel and needed quantity（PCS）

Part Name and Spec.


用量

车型

用量

车型

用量

车型

用量

车型

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

WD615.50 发动机总成

WD615.50 engine assy (with 213 kw

（213kW 国产泵工程版）

domestic pump, engineering-version )

61500030009

连杆总成

Connecting rod assy

1

1

612600030010

活塞

Piston

1

2

61560030013

活塞销

Piston pin

1

3

81560030012

活塞销挡圈

Piston pin retaining ring

2

4

61560030047

梯形环

Trapezoid ring

1

5

612600030019

锥面环

Taper-face ring

1

6

61560030045

油环

Oil ring

1

7

61500030008

连杆体

Connecting rod body

1

8

61500030022

连杆盖

Connecting rod cover

1

9

61500030077

连杆衬套

Connecting rod bushing

1

10

61560030033

连杆轴瓦

Connecting rod bearing shell

1

11

612600030020

连杆轴瓦（上瓦）

Connecting rod bearing shell (upper one)

1

12

81500030023

连杆螺栓

Connecting rod bolt

2

1S325110002H8

1

- 207 -

3253DLPJE0RZA01

1S325110002H8WD615.50发动机总成（213kW国产泵工程版）-火焰预热系统 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - Flame preheating system

- 208 -

1S325110002H8WD615.50 发动机总成（213kW 国产泵工程版）-火焰预热系统 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - Flame preheating system 适用车型及用量（件）标号

零件代号

No.

Part Code

1S325110002H8


Part Name and Spec.





Applicable VehicleModel and needed quantity（PCS）用量

车型

用量

车型

用量

车型

用量

车型

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

1

1

612600090080

温度传感器

Temperature sensor

1

2

612600090082

电磁阀

Solenoid valve

1

3

612600090081

火焰预热电热塞

Flame preheating glow plug

2

7

90003962607

空心螺栓

Hollow bolt

2

8

81560080212

空心螺栓

Hollow bolt

1

9

609E110070

联接螺栓

Connecting bolt

1

13

612600090075

角形支架

Angular bracket

1

- 209 -

3253DLPJE0RZA01

1S325110002H8WD615.50发动机总成（213kW国产泵工程版）-机油泵 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - oil pump

- 210 -

1S325110002H8WD615.50 发动机总成（213kW 国产泵工程版）-机油泵 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - oil pump 零件名称及规格标号

零件代号

No.

Part Code

Part Name and Spec.

适用车型及用量（件） Applicable VehicleModel and needed quantity（PCS）用量

车型

用量

车型

用量

车型

用量

车型

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

AZ1500070021A

机油泵总成

Oil pump assy

1

6

614070055

机油泵垫片

Oil pump gasket

1

7

61500070082

集滤器总成

Strainer assy

1

8

614070078

垫片

Shim

1

9

614070061

机油泵中间齿轮

Oil pump intermediate gear

1

10

90003311410

向心球轴承

Radial ball bearing

2

11

614070049

中间隔圈

Middle spacer ring

1

12

90003934732

带凸齿的孔用挡圈

Toothed circlip for hole

1

13

6140756

中间齿轮轴

Intermediate gear shaft

1

14

614070155

密封圈

Seal gasket

1

AZ1500070097

机油泵限压阀总成

15

AZ1500070096

阀体

Valve body

1

16

407070032

限压阀

Pressure limiting valve

1

17

4139070059

弹簧

Spring

1

22

90003802578S

六角头螺栓

Hexagon head bolt

1

25

90003930271

平垫圈

Flat washer

2

26

90003862443



2

28

90003931122

弹簧垫圈

Spring washer

1

Pressure limiting valve assy, oil pump

3253DLPJE0RZA01

1

- 211 -

1S325110002H8WD615.50发动机总成（213kW国产泵工程版）-机油滤清器和机油冷却器 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - oil filter and oil cooler

- 212 -

1S325110002H8WD615.50 发动机总成（213kW 国产泵工程版）-机油滤清器和机油冷却器 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - oil filter and oil cooler 标号 No.

零件代号 Part Code 1S325110002H8

1 2 3 3 4 5 7 8 9 12 13 14 15 16 17

61500070051 61000070005 61500010334 61800010113 81400010032 90003962051 614070068 614070069 AZ1500070097 AZ1500070096 4139070059 407070034 AZ9003930012 90003862443 90003932023 90003862482

零件名称及规格 WD615.50 发动机总成（213kW 国产泵工程版）机油滤清器底座组件旋转式机油滤芯总成机油冷却器（8 片）机油冷却器芯总成(9 片) 密封圈轻型六角头圆柱螺塞安全阀弹簧安全阀主油道限压阀总成阀体弹簧弹簧座弹性挡圈内六角圆柱头螺钉波形弹性垫圈内六角圆柱头螺钉

Part Name and Spec.

用量 Total

WD615.50 engine assy (with 213 kw domestic pump, engineering-version ) Oil filter Pedestal module Rotary oil filter element assy Oil cooler (8 pcs) Oil cooler cartridge (9 pcs) Seal gasket Light-duty hexagon head cheese-head plug screw Safety valve spring Safety valve Pressure limiting valve assy, main oilway Valve body Spring Spring seat Circlip Hexagon socket cheese-head screw Wave spring washer Hexagon socket cheese-head screw

1 1 2 1 2 1 1 1 1 1 1 1 1 2 12 2

- 213 -


适用车型及用量（件） Applicable VehicleModel and needed quantity（PCS）用量车型用量车型 Total Vehicle Model Total Vehicle Model

用量 Total


1S325110002H8WD615.50发动机总成（213kW国产泵工程版）-进气系统

1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - intake system

- 214 -

1S325110002H8WD615.50 发动机总成（213kW 国产泵工程版）-进气系统 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - intake system 适用车型及用量（件）标号

Part Name and Spec.

零件名称及规格 No.


零件代号 Part Code

用量

车型

用量

车型

用量

车型

用量

车型

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model


WD615.50 engine assy (with 213 kw domestic


pump, engineering-version )

612600111809

进气管

Intake pipe

1

612600111808

进气管

Intake pipe

1

2

90003962014

六角头螺塞


1

3

90003098010

复合密封垫圈

Composite seal gasket

8

4

61500110024

进气管垫片

Gasket, intake pipe

6

5

90003800465

六角头螺栓

Hexagon head bolt

1

7

614110064

进气管紧固螺栓

Intake pipe tightening bolt

4

8

90003800497

六角头螺栓

Hexagon head bolt

2

9

90003932023

波形弹性垫圈

Wave spring washer

12

10

612600118895

HX50 增压器

HX50 turbocharger

1

12

61560110226

夹子

Clamp

1

13

190320035

密封圈

Seal gasket

1

14

612600111808

压气机进气管总成

Air compressor intake pipe assy

1

20

609E110036

调整垫圈

Adjusting washer

2

21

90003802411

六角头螺栓

Hexagon head bolt

1

27

99100570015

悬臂总成

Cantilever assy

1

612600110455

盖板

Cover plate+

1

61560050046A

盖板

Cover plate

1

90003802424

六角头螺栓

Hexagon head bolt

17

1S325110002H8 1

40

1

- 215 -

3253DLPJE-0RZA01

1S325110002H8WD615.50发动机总成（213kW国产泵工程版）-冷却系统

1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - cooling system

- 216 -

1S325110002H8WD615.50 发动机总成（213kW 国产泵工程版）-冷却系统 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - cooling system 适用车型及用量（件）标号

零件代号

No.

Part Code

1S325110002H8



Part Name and Spec.


WD615.50 engine assy (with 213 kW



用量

车型

用量

车型

用量

车型

用量

车型

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

1

1

61560060050

水泵总成

Water pump assy

1

3

612600060446

φ640 环形风扇

Annular fan(φ640)

1

4

614060024

水管接头垫片

Water pipe t washer

1

5

61560060022A

水管接头

Water pipe t

1

9

90003989308

软管卡箍

Hose hoop

4

10

61000060276

胶管

Rubber tube

1

11

614060135

节温器总成

Thermostat assy

1

12

612600060518

冷却水软管

Cooling water hose

1

13

614060008

水泵密封垫

water pump gasket

1

16

614010040

空压机齿轮盖垫片

Washer, air compressor gear cover

1

17

61560010069

空压机齿轮盖

Air compressor gear cover

1

18

61560060069

张紧轮总成

tensioner assy

1

19

90011400001


Hexagon flange bolt

1

23

90003802424

六角头螺栓

Hexagon head bolt

17

24

90003800467

六角头螺栓

Hexagon head bolt

5

25

90003888452



3

26

90003888451



6

27

90003932023

波形弹性垫圈

Wave spring washer

12

28

90003931102

弹簧垫圈

Spring washer

3

- 217 -

3253DLPJE0RZA01

1S325110002H8WD615.50发动机总成（213kW国产泵工程版）-联轴器 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - Coupling

- 218 -

1S325110002H8WD615.50 发动机总成（213kW 国产泵工程版）-联轴器 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - Coupling 适用车型及用量（件）标号

零件代号

No.

Part Code

Part Name and Spec.



车型

用量

车型

用量

车型

用量

车型

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model



3253DLPJE-



0RZA01

81560080266

联轴器法兰

Coupling flange

2

81560080275

联轴器法兰

Coupling flange

1

2

61560080194

角度调节板

Angle adjusting plate

1

3

AZ1560080001

六角头螺栓

Hexagon head bolt

1

4

61560080219

弹性连接片

Spring connecting sheet

12

5

81560080271

垫圈

Washer

8

6

81560080273

衬套

Bush

8

7

90003802637

六角头螺栓

Hexagon head bolt

4

9

90003800160

六角头螺栓

Hexagon head bolt

2

10

90003871344

1 型六角螺母


8

11

90003930282

小垫圈

Small washer

8

1S325110002H8 1

- 219 -

1S325110002H8WD615.50发动机总成（213kW国产泵工程版）-排气系统 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version )- exhaust system

- 220 -

1S325110002H8WD615.50 发动机总成（213kW 国产泵工程版）-排气系统 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version )- exhaust system 适用车型及用量（件）标号




1S325110002H8

Part Name and Spec.





用量

车型

用量

车型

用量

车型

用量

车型

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

1

1

612600111290

前排气歧管

Front exhaust manifold

1

2

612600111280

后排气歧管

Rear exhaust manifold

1

3

612600110856

前隔热罩

Front thermal shroud

1

4

612600110857

后隔热罩

Rear thermal shroud

1

6

61260110162

排气管密封环

Exhaust pipe seal ring

4

7

61560110242

排气管垫片

Gasket, exhaust pipe

6

8

61560110104

排气管固定螺栓

Fixing bolt - air exhaust pipe

11

13

612600118895

HX50 增压器

HX50 turbocharger

1

14

61560110210

增压器密封垫

Turbocharger gasket

6

17

612600110060

进油管

Oil inlet pipe

1

18

81560110152

进油管法兰

Oil inlet pipe flange

1

19

609E110050

进油管垫片

Washer, oil inlet pipe

1

20

90003862428



22

22

612600110345

回油管

Oil return pipe

1

23

61260110048

回油管法兰垫片

Washer, oil return pipe flange

1

24

61460070014

回油管螺栓

Oil return pipe bolt

2

- 221 -

3253DLPJE0RZA01

1S325110002H8WD615.50发动机总成（213kW国产泵工程版）-配气机构 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - valve timing mechanism

- 222 -

1S325110002H8WD615.50 发动机总成（213kW 国产泵工程版）-配气机构 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - valve timing mechanism 适用车型及用量（件）标号

Part Name and Spec.




用量

车型

用量

车型

用量

车型

用量

车型

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model





61500050096

凸轮轴

Camshaft

1

612600050085

凸轮轴

Camshaft

1

2

614050053

凸轮轴正时齿轮

Camshaft timing gear

1

3

614050133

凸轮轴止推片

Camshaft stop washer (pair)

1

4

61560050044

中间齿轮轴

Intermediate gear shaft

1

5

61560050053

中间齿轮总成

Intermediate gear assy

1

6

61560050058

轴

Shaft

1

7

61560050045

挡板

Baffle

1

8

90003120602

密封圈

Seal gasket

1

9

61560050046A

盖板

Cover plate

1

10

612600050027

气门摇臂座

Valve rocker arm seat

6

11

614050048

进气门摇臂

Rocker arm, intake valve

6

12

612600050059

排气门摇臂

Rocker arm, exhaust valve

6

13

61500050105

气门帽

Valve cap

12

14

61500050025

气门锁夹

Intake valve locker

24

15

61500050109

气门弹簧上座

Valve spring upper seat

12

16

61500050002

气门外弹簧

Valve outer spring

12

17

61500050001

气门内弹簧

Valve inner spring

12

18

614050017

进气门弹簧下座

Intake valve spring lower seat

6

19

612600050073

进气门

Intake valve

6

1S325110002H8 1

1

- 223 -

3253DLPJE0RZA01

适用车型及用量（件）标号




Part Name and Spec. 用量

车型

用量

车型

用量

车型

用量

车型

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

20

61500050032

气门挺柱

Valve tappet

12

21

81500050070

气门推杆总成

Valve push rod assy

12

22

614050010

气门间隙调整螺钉

Adjusting screw, valve clearance

12

23

2130050065

气门间隙调整螺母

Adjusting nut, valve clearance

12

24

61500040014

排气门弹簧下座

Exhaust valve spring lower seat

1

25

61560050041

排气门

Exhaust valve

25

612600050025

排气门

Exhaust valve

6

27

61560050059S

六角头螺栓

Hexagon head bolt

4

28

90003862419



1

30

90003871252

1 型六角螺母


6

31

90003932023

波形弹性垫圈

Wave spring washer

12

32

90003802411

六角头螺栓

Hexagon head bolt

1

34

90003901409

圆柱销

Cylindrical pin

1

- 224 -

1S325110002H8WD615.50发动机总成（213kW国产泵工程版）-喷油泵和高压油管 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - fuel injection-pump and high-pressure oil pipe

- 225 -

1S325110002H8WD615.50 发动机总成（213kW 国产泵工程版）-喷油泵和高压油管 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - fuel injection-pump and high-pressure oil pipe 适用车型及用量（件）标号

零件代号

No.

Part Code

1S325110002H8

Part Name and Spec.







车型

用量

车型

用量

车型

用量

车型

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

1

1

612600081175

高压油泵

High-pressure fuel pump

1

3

612600080200

密封垫圈

Seal gasket

1

4

81560080275

法兰组件

Flange module

1

5

614080074

波许喷油泵托架

Bosch fuel injection pump bracket

1

6

90003802650

六角头螺栓

Hexagon head bolt

4

7

90003931142

弹簧垫圈

Spring washer

4

8

90003901600

圆柱销

Cylindrical pin

2

9

90003862566



4

10

90003930271

平垫圈

Flat washer

2

11

612600080563

联轴器总成

Coupling assy

1

12

61560080305

喷油器总成

Injector assy

6

13

614080082

垫圈

Washer

6

14

609070080

密封垫圈

Seal gasket

6

15

61500080094A

紧固压板

Tightening pressure plate

6

16

612600080383

六角头螺栓

Hexagon head bolt

12

17

61500080090

空心螺栓

Hollow bolt

6

18

90003098018

复合密封垫圈


12

19

612600080568

高压油管组

High-pressure oil pipe group

1

20

61560080172

支撑架

Strut

4

29

AZ1560070025

润滑油回油管总成

Lube oil return pipe

1

- 226 -

3253DLPJE0RZA01

30

90003962621

空心螺栓

Hollow bolt

6

- 227 -

1S325110002H8WD615.50发动机总成（213kW国产泵工程版）-气缸盖

1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - cylinder head

- 228 -

1S325110002H8WD615.50 发动机总成（213kW 国产泵工程版）-气缸盖 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - cylinder head 适用车型及用量（件）标号

零件代号

No.

Part Code


Part Name and Spec.


车型

用量

车型

用量

车型

用量

车型

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model





612600040284

汽缸盖总成

Cylinder head assy

6

612600040283

气缸盖

Cylinder head

1

612600040282

气缸盖

Cylinder head

1

2

61560040057

进气门座

Intake valve seat

1

3

81560040037

排气门座

Exhaust valve seat

1

4

612600040113

气门导管

Valve guide

2

5

406060010

环状密封圈

Circular seal ring

1

6

612600040099

喷油器衬套

Injector bush

1

7

90003989294

碗形塞

Bowl-shaped plug

4

8

90003989277

碗形塞

Bowl-shaped plug

1

9

90003989721

碗形塞

Bowl-shaped plug

1

10

90003989725

碗形塞

Bowl-shaped plug

1

11

61500040049

气缸盖衬垫

Cylinder head gasket

6

12

612600040149

气缸盖罩

Cylinder head hood

6

13

614040021

气缸盖罩衬垫

Cylinder head hood gasket

6

14

61500040102

出水管

Water outlet pipe

1

15

612600040233

管接头组件

Pipe t module

1

16

61200040027

夹紧块

Clamping block

2

17

61200040034

带肩螺母

Shouldered nut

21

18

61500040012

吊环夹紧块

Lifting ring clamping block

2

1S325110002H8

1

1

- 229 -

3253DLPJE0RZA01


零件代号

No.

Part Code


Part Name and Spec.


车型

用量

车型

用量

车型

用量

车型

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

19

614010388

吊环螺钉

Lifting ring screw

2

20

612600040114

气门阀杆密封套

Valve stem sealing bush

12

21

61500040023

气缸盖主螺栓

Cylinder head main bolt

24

22

61500040009

夹紧块

Clamping block

5

23

61200040023

夹紧块

Clamping block

5

24

90003800466

六角头螺栓

Hexagon head bolt

12

25

90003932023

波形弹性垫圈

Wave spring washer

12

- 230 -

1S325110002H8WD615.50发动机总成（213kW国产泵工程版）-气缸体（二） 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - cylinder block （II）

- 231 -

1S325110002H8WD615.50 发动机总成（213kW 国产泵工程版）-气缸体（二） 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - cylinder block（II）标号 No.

适用车型及用量（件） Applicable VehicleModel and needed quantity（PCS）



1S325110002H8

WD615.50 发动机总成（213kW 国产泵工程版）

WD615.50 engine assy (with 213 kw domestic pump, engineering-version )

1

612600010932

正时齿轮室

Timing gear chamber

1

2

61560010069

空压机齿轮盖

Air compressor gear cover

1

3

614010040

空压机齿轮盖垫片

Washer, air compressor gear cover

1

4

612600010928

前油封座

Front oil seal seat

1

5

61500010037

前油封

Front oil seal

1

6

61500010008A

凸轮轴齿轮盖

Camshaft gear cover

1

7

614010070

凸轮轴齿轮盖垫片

Camshaft gear cover washer

1

Part Name and Spec.

用量 Total 1

9

90003932023

波形弹性垫圈

Wave spring washer

12

10

90003909626

弹性圆柱销

Spring cylindrical pin

6

11

90003802576

六角头螺栓

Hexagon head bolt

1

12

90003932024

波形弹性垫圈

Wave spring washer

1

13

90003800571

六角头螺栓

Hexagon head bolt

1

14

90003931122

弹簧垫圈

Spring washer

1

16

90003862524



2

17

90003932025

鞍形弹性垫圈

Saddle spring washer

2

18

90003871252

1 型六角螺母

6

20

90003962051

轻型六角头圆柱螺塞

Hexagon nut - Type 1 Light-duty hexagon head cheese-head plug screw

21

90003901507

圆柱销

Cylindrical pin

4

22

90003802523

六角头螺栓

Hexagon head bolt

3

25

90003888453



8

27

90003098018

密封垫圈

Seal gasket

12

28

612600010934

前油封座垫片

Front oil seal seat gasket

1

29

90003930271

平垫圈

Flat washer

2

30

90003802561

六角头螺栓

Hexagon head bolt

6

1

- 232 -


用量 Total


用量 Total


用量 Total


1S325110002H8WD615.50发动机总成（213kW国产泵工程版）-气缸体（三） 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) -cylinder block （III）

- 233 -

1S325110002H8WD615.50 发动机总成（213kW 国产泵工程版）-气缸体（三） 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) -cylinder block（III）适用车型及用量（件）标号 No.


零件代号

Part Name and Spec.


Part Code

用量 Total

1S325110002H8


WD615.50 engine assy (with 213 kw domestic


pump, engineering-version )

1

1

612600011654

机油冷却器盖

Oil cooler cover

1

2

614010084B

机油冷却器盖垫片

Oil cooler cover gasket

1

3

612600010575

飞轮壳

Flywheel house

1

4

1800210011

观察孔盖

Sight hole cover

1

5

612600011910

油标尺

Oil level indicator

1

7

612600010638

橡胶管箍

Rubber hose hoop

1

8

612600010647

单管夹片

Pipe clamp

1

10

614010086

加油短管垫片

Gasket, short oil filler pipe

1

14

612600010611

机油加油管

Oil filler pipe

1

15

612600010489

加油管盖总成

Fuel filler pipe cover assy

1

16

614010279

通风弯管

Vent bend pipe

1

17

90003069303

垫片

Shim

1

18

612600010267

油气分离器组件

Oil-gas separator module

1

19

90003989336

软管卡箍

Hose hoop

4

25

90003802411

六角头螺栓

Hexagon head bolt

1

26

90003800467

六角头螺栓

Hexagon head bolt

5

26

90003800465

六角头螺栓

Hexagon head bolt

1

27

90003802424

六角头螺栓

Hexagon head bolt

17

- 234 -


用量 Total


用量 Total


用量 Total


适用车型及用量（件）标号 No.


零件代号

Part Name and Spec.


Part Code

用量 Total

Light-duty hexagon head cheese-head plug

29

90003962020

轻型六角头圆柱螺塞

31

90003802511

六角头螺栓

Hexagon head bolt

1

32

614010417

飞轮壳螺栓

Flywheel house bolt

6

32

61500010101

飞轮壳螺栓

Flywheel house bolt

6

34

90003871305

1 型六角螺母


2

35

90003813527

双头螺柱

Stud

3

36

90003888452



3

37

90003802321

六角头螺栓

Hexagon head bolt

4

38

90003862427



2

39

90003901604

圆柱销

Cylindrical pin

2

40

90003932023

波形弹性垫圈

Wave spring washer

12

41

90003098014

复合密封垫圈


1

42

90003931122

弹簧垫圈

Spring washer

1

43

90003931082

重型弹簧垫圈


4

44

90003936101

垫圈

Washer

1

screw

- 235 -

1


用量 Total


用量 Total


用量 Total


1S325110002H8WD615.50发动机总成（213kW国产泵工程版）-气缸体（一） 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - cylinder block （I）

- 236 -

1S325110002H8WD615.50 发动机总成（213kW 国产泵工程版）-气缸体（一） 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - cylinder block （I）适用车型及用量（件）标号

零件代号

No.

Part Code



Part Name and Spec.

用量

车型

用量

车型

用量

车型

用量

车型

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model





612600010815

汽缸体总成

Cylinder head assy

1

1

612600010806

气缸体

Cylinder block

1

2

61500010366

曲轴箱

Crankcase

1

3

61500010344

气缸套

Cylinder liner

6

4

90003982121

碗形塞

Bowl-shaped plug

4

5

90003989480

碗形塞

Bowl-shaped plug

2

6

90003989204

碗形塞

Bowl-shaped plug

1

7

61560010029

凸轮轴衬套

camshaft module

6

7

612600010990

凸轮轴衬套

camshaft module

1

8

90003901604A

圆柱销

Cylindrical pin

3

9

81500010046

主轴瓦

main shell

7

10

81500010125

止推片

Stop washer

2

11

614010114

主轴承螺栓

main bearing bolt

13

12

90003802493

六角头螺栓

Hexagon head bolt

5

13

90003962050

内六角圆柱头螺塞

Hexagon socket cheese-head plug screw

1

15

61000010134

密封圈

Seal gasket

1

16

614010217

主轴承螺栓

main bearing bolt

1

17

612600070097

回油弯管

Oil return bended tube

1

18

90003862428



22

1S325110002H8

1

- 237 -

3253DLPJE0RZA01


零件代号

No.

Part Code


Part Name and Spec.


车型

用量

车型

用量

车型

用量

车型

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

19

188250083

自锁垫圈

Self-locking washer

22

20

90003989215

碗形塞

Bowl-shaped plug

3

21

90003989289

碗形塞

Bowl-shaped plug

4

22

90003962621

空心螺栓

Hollow bolt

6

23

90003098015

复合密封垫圈


6

24

61560010090

喷嘴组件

Nozzle module

1

25

90003909603

弹性圆柱销


6

26

61500010100

后油封

Rear oil seal

1

27

90003989288

碗形塞

Bowl-shaped plug

1

28

61460070011

主油道后螺塞

Main oilway rear plug screw

1

29

612600010735

复合垫圈

Composite washer

1

30

90003901604

圆柱销

Cylindrical pin

2

31

61500010185S

气缸盖螺栓

Cylinder head bolt

21

32

90003989210

碗形塞

Bowl-shaped plug

6

33

90003909626

弹性圆柱销


6

- 238 -

1S325110002H8WD615.50发动机总成（213kW国产泵工程版）-曲轴飞轮 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - crankshaft flywheel

- 239 -

1S325110002H8WD615.50 发动机总成（213kW 国产泵工程版）-曲轴飞轮 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - crankshaft flywheel 适用车型及用量（件）标号

零件代号

No.

Part Code

Part Name and Spec.



车型

用量

车型

用量

车型

用量

车型

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model





61500020071

曲轴总成

crankshaft assy

1

1

61500020012

曲轴

Crankshaft

1

2

614020038

曲轴齿轮

Crankshaft gear

1

3

61500020070

法兰

Flange

1

4

90003901418

圆柱销

Cylindrical pin

1

6

90003960569

普通平键

Common flat key

1

8

61560020010

减振器

Shock absorber

1

9

61560020017

皮带轮

Pulley

1

10

612600020220

飞轮

Flywheel

1

11

612600020208

飞轮齿圈

Flywheel gear ring

1

12

90011620022

双头螺柱

Stud

2

14

90003871305

1 型六角螺母


2

15

90003932024

波形弹性垫片

Wave spring washer

1

16

90003311416

球轴承

Ball bearing

1

17

90003934310

孔用弹性挡圈

Hole circlip

1

18

61500020046

六角头螺栓

Hexagon head bolt

9

19

61500060217

三角皮带

V-Belt

2

1S325110002H8

1

- 240 -

3253DLPJE0RZA01

1S325110002H8WD615.50发动机总成（213kW国产泵工程版）-水泵 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - water pump

- 241 -

1S325110002H8WD615.50 发动机总成（213kW 国产泵工程版）-水泵 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - water pump 适用车型及用量（件）标号

零件代号

No.

Part Code

Part Name and Spec.



车型

用量

车型

用量

车型

用量

车型

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model





61560060050

水泵总成

Water pump assy

1

1

61500060234

水泵体

Water pump body

1

2

61500060249

叶轮

Impeller

1

3

61500060124

皮带轮

Pulley

1

4

612600060539

水封总成

Water seal assy

1

5

612600060584

水泵加黄油装置

Grease-adding device, water pump

1

6

61500060248

泵轴

Pump shaft

1

7

61500060251

支撑套

ing bush

1

8

612600060538

锥端紧定螺钉

Tightening screw, at cone end

2

9

90003310067

向心球轴承

Radial ball bearing

2

10

90016040012

圆柱滚子轴承

Cylindrical roller bearing

1

11

61500060237

防护圈

Guard ring

1

1S325110002H8

1

- 242 -

3253DLPJE0RZA01

1S325110002H8WD615.50发动机总成（213kW国产泵工程版）-油底壳 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - oil pump

- 243 -

1S325110002H8WD615.50 发动机总成（213kW 国产泵工程版）-油底壳 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - oil pump 适用车型及用量（件）标号

零件代号

No.

Part Code


Part Name and Spec.


车型

用量

车型

用量

车型

用量

车型

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model





612600150229

油底壳总成

Oil sump Assembly

1

1

612600150219

油底壳

Oil sump

1

2

614150004

密封垫

Seal gasket

1

3

612600150108

磁性螺塞总成

Magnetic plug screw assy

1

4

612600150106

密封垫圈

Seal gasket

1

8

614150046

油底壳托块

Oil sump holding block

12

1S325110002H8

1

- 244 -

3253DLPJE0RZA01

1S325110002H8WD615.50发动机总成（213kW国产泵工程版）-油管 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - fuel oil pipe

- 245 -

1S325110002H8WD615.50 发动机总成（213kW 国产泵工程版）-油管 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - fuel oil pipe 标号 No.


Part Name and Spec.

适用车型及用量（件） Applicable VehicleModel and needed quantity（PCS）


1S325110002H8


用量

车型

用量

车型

用量

车型

用量

车型

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model


WD615.50 engine assy (with 213 kW domestic pump, engineering-version )

1 1

1

614080295A

燃油滤清器总成

Fuel oil filter assy

3

61560080094

燃油滤托架组件

Fuel oil filter bracket

4

AZ1560080017

燃油管

Fuel oil pipe

1

5

AZ1560080018

燃油管

Fuel oil pipe

1

6

612600080597

回油管总成

Oil return pipe assy

1

7

61560070012A

润滑油管总成

Lube oil pipe assy

1

8

61560070011A

润滑油管总成

Lube oil pipe assy

1

9

61560080284

空气管

Air pipe

1

10

90003802627

六角头螺栓

Hexagon head bolt

2

11

90003802523

六角头螺栓

Hexagon head bolt

3

12

90003932016

波形弹性垫圈

Wave spring washer

2

13

90003932024

波形弹性垫圈

Wave spring washer

1

14

90003930012

垫圈

Washer

2

15

90003962621

空心螺栓

Hollow bolt

6

16

90003962612

空心螺栓

Hollow bolt

2

17

Z61560070012

空心螺栓

Hollow bolt

1

18

90003962607

空心螺栓

Hollow bolt

2

19

90003962603

空心螺栓

Hollow bolt

1

20

609080037

空心螺栓

Hollow bolt

1

21

612600080200

密封垫圈

Seal gasket

1

22

90003098012

复合密封垫圈


4

24

612600080201

密封垫圈

Seal gasket

2

module

1

- 246 -

3253DLPJE0RZA01

1S325110002H8WD615.50发动机总成（213kW国产泵工程版）-张紧轮 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - tensioner

- 247 -

1S325110002H8WD615.50 发动机总成（213kW 国产泵工程版）-张紧轮 1S325110002H8 WD615.50 engine assy (with 213 kW domestic pump, engineering-version ) - tensioner 适用车型及用量（件）标号

零件代号

No.

Part Code


Part Name and Spec.


车型

用量

车型

用量

车型

用量

车型

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model





61560060069

张紧轮总成

Tensioner assy

1

1

61560060070

张紧轮

Tensioner

1

4

61560060074

防护圈

Guard ring

2

5

90016020017

深沟球轴承

Deep groove ball bearing

1

6

61560060073

隔套

Spacer bush

1

1S325110002H8

1

- 248 -

3253DLPJE0RZA01

1S325124002H1后桥（5.73，加宽，铸钢）-后桥壳及主减（二） 1S325124002H1 Rear axle (5.73, widened, cast steel) - rear axle housing and main reducer （II）

- 249 -

1S325124002H1 后桥（5.73，加宽，铸钢）-后桥壳及主减（二） 1S325124002H1 Rear axle (5.73, widened, cast steel) - rear axle housing and main reducer（II）标号 No.

1 2 3 4 5 6 8 9 10 11 12 13 14 15 17 18 19 20 21 24 30 31 32 33



Part Name and Spec.

用量 Total

1S325124002H1

后桥（5.73，加宽，铸钢）

Rear axle (5.73, widened, cast steel)

1

AK99012320124/035 AK99012320197/008 Q181B1635TF2 Q151B1635TF2 Q151B1480TF2 AK79000320013 AK99012320110 AK1800320131/132 AK99012320009 AK99012320010 AK99014320091-1 AK3809320159 AK79000320027-1 AK3809320155 AK3809320158 7312EX-GB297 AK99012320184 AK99112320030 7615EX-GB298 AK99012320150 7516EX-GB297 AK3809320157 AK3809320156 HFF2400111CK3F HFF2400112CK3F AK99012340067

主、被动锥齿轮（5.73）差速器壳总成六角头螺栓（连接被齿）六角头螺栓六角头螺栓凸缘螺母凸缘总成 φ165 半轴齿轮垫片半轴齿轮差速器行星轮十字轴差速器轴承调整螺母止动片固定啮合套锁止垫片圆锥滚子轴承轴密封圈轴密封圈圆锥滚子轴承差速器行星轮垫片单列圆锥滚子轴承(主减) 圆螺母滑动啮合套半轴（左）（L=1117）半轴（右）（L=1117）油封

Driving/driven cone gear （5.73） Differential housing assy Hex head bolt(to driven gear) Hexagon head bolt Hexagon head bolt Flange nut Flange assy, φ165 Shim, half-axle gear Half-axle gear Differential planetary wheel Crosspin Adjusting nu, differential bearing Stop plate Fixing sliding sleeve Locking washer Conical roller bearing Seal gasket Seal gasket Conical roller bearing Differential planetary wheel washer Single-row conical roller bearing (main reducer) Round nut Guide sliding sleeve Half-axle（LH）（L=1117） Half-axle（RH）（L=1117） Oil seal

1 1 16 20 8 1 1 2 2 4 1 2 2 1 1 1 1 1 1 4 2 1 1 1 1 2

- 250 -

适用车型及用量（件） Applicable VehicleModel and needed quantity（PCS）车型车型车型用量用量用量 Vehicle Vehicle Vehicle Total Total Total Model Model Model 3253DLPJE0RZA01


1S325124002H1后桥（5.73，加宽，铸钢）-后桥壳及主减（一） 1S325124002H1(5.73, widened, cast steel) - rear axle housing and main reducer (I)

1S32512 - 251 -

4002H1 后桥（5.73，加宽，铸钢）-后桥壳及主减（一） 1S325124002H1(5.73, widened, cast steel) - rear axle housing and main reducer (I) 适用车型及用量（件）标号 No.


Applicable VehicleModel and needed quantity（PCS） Part Name and Spec.


用量 Total

1S325124002H1



1

1

HFF2401010CK9GFTZGS

后桥壳总成

Rear axle housing assy

1

5

Q72222

碗形堵塞

Bowl-shaped plug

1

6

AK81500010163

加油螺塞

Oil filler plug screw

1

7

AK5863315

磁性螺塞总成

Magnetic plug screw assy

1

11

AK99000330006

通气孔总成

Air vent hole assy

1

15

HFF2406023CK9GFTZG

压力开关

Pressure switch

1

22

HFF2402251CK4GZG

双头螺栓

Stud

16

29

HFF2402020CK9GFTZG

主减速器壳总成

Main reducer housing assy

1

53

AK99012320103

主减速器轴承座

Main reducer bearing seat

1

56

AK99012320173-0176

调整垫片

Adjusting shim

57

AK99012320121

油封座

Oil seal seat

As required 1

- 252 -


用量 Total


用量 Total


用量 Total


1S325124002H1后桥（5.73，加宽，铸钢）-后桥制动器 1S325124002H1 Rear axle (5.73, widened, cast steel) - rear axle brake

- 253 -

1S325124002H1 后桥（5.73，加宽，铸钢）-后桥制动器 1S325124002H1 Rear axle (5.73, widened, cast steel) - rear axle brake 适用车型及用量（件）标号 No.


Applicable VehicleModel and needed quantity（PCS）零件名称及规格

Part Name and Spec.

用量 Total

1S325124002H1



1

1

AK99112340006

制动鼓

Brake drum

2

19

HFF3502023CK9GFTZG

制动凸轮轴（左）

Brake camshaft (LH)

1

20

HFF3502024CK9GFTZG

制动凸轮轴（右）

Brake camshaft (RH)

1

22

AK880340023

O 形密封圈

O-ring seal

2

23

AK880440010

附加垫片

Additional shim

4

26

HFF3502120CK9GFTZG

间隙调整臂总成（左）

Clearance adjusting arm assy (LH)

1

27

HFF3502130CK9GFTZG

间隙调整臂总成（右）

Clearance adjusting arm assy (RH)

1

32

AK99014340041

凸轮轴支架

Camshaft

2

35

Q151B1490

六角螺栓

Hexagon nut

2

36

Q151B1440

六角螺栓

Hexagon nut

2

37

HFF2401042CK9GFTZGS

气室支架(六孔)

Air chamber ing (6-hole)

1

40

Q151B2040TF2

六角螺栓

Hexagon nut

6

- 254 -


用量 Total


用量 Total


用量 Total


1S325124002H1后桥（5.73，加宽，铸钢）-轮边减速器组件 1S325124002H1 Rear axle (5.73, widened, cast steel) - hub reduction gear module

- 255 -

1S325124002H1 后桥（5.73，加宽，铸钢）-轮边减速器组件 1S325124002H1 Rear axle (5.73, widened, cast steel) - hub reduction gear module 标号 No.

1 2 3 6 7 8 9 11 13 14 15 16 18 19 23 27 28 29 30 31 32 33 36 37 39 45



Part Name and Spec.

用量 Total

1S325124002H1



1

AK99012340082 AK99012340068 AK99012340123-FT Q30022 AK99012340029 AK99012340021 AK99012340020 Q150B0820 AK99012340017 AK99012340027 AK99012340093 AK99012340094 7222-GB297 7522-GB297 HFF3502011CK1A HFF2041043CKFT A22×27-DIN603Cu Q151C1295TF2 Q5211435 AK99012340122 AK-99-934-013 AK99012340075 AK99012340077 AK99012340004 AK880420014 AK99012340119 HFF2400113CKFT 99012340009/11 HFF2500121CK9GFTZGS

后轮毂总成后轮毂车轮螺栓车轮螺母密封圈挡油罩密封垫片六角头螺栓隔圈密封圈轴密封圈轴密封圈单列向心圆锥滚子轴承单列向心圆锥滚子轴承放油螺塞端盖垫圈六角头螺栓圆柱销轮边行星轮滚针轴承轮边行星轮垫片垫圈行星齿轮轴轴用挡圈齿圈支架总成锁紧螺母(外) 轮边及行星架合件六角头螺栓

Rear hub assy Rear hub Wheel bolt Wheel nut Seal gasket Splash cover Seal gasket Hexagon head bolt Spacer ring Seal gasket Shaft seal gasket Shaft seal gasket Single row radial conical roller bearing Single row radial conical roller bearing Oil drain plug screw End cover Washer Hexagon head bolt Cylindrical pin Hub planetary wheel Needle bearing Hub planetary wheel washer Washer Planetary gear shaft Shaft retaining ring Ring gear bracket assy Locking nut (external) Hub and planet carrier combination Hexagon head bolt

2 2 20 20 4 2 2 20 2 2 2 2 2 2 4 2 4 10 10 10 20 20 10 10 2 2 2 2 8

- 256 -



1S325125002H1中桥（5.73，加宽，铸钢）-轮边减速器组件 1S325125002H1 Intermediate axle (5.73, widened, cast steel)- hub reduction gear module

- 257 -

1S325125002H1 中桥（5.73，加宽，铸钢）-轮边减速器组件 1S325125002H1 Intermediate axle (5.73, widened, cast steel)- hub reduction gear module 适用车型及用量（件）标号 No.




1S325125002H1

中桥（5.73，加宽，铸钢）

Intermediate axle (5.73, widened, cast steel)

1

Part Name and Spec.

用量 Total

1

AK99012340068

后轮毂

Rear hub

2

2

AK99012340123-FT

车轮螺栓

Wheel bolt

20

3

Q30022

车轮螺母

Wheel nut

20

6

AK99012340029

密封圈

Seal gasket

4

7

AK99012340021

挡油罩

Splash cover

2

8

AK99012340020

密封垫片

Seal gasket

2

9

Q150B0820

六角头螺栓

Hexagon head bolt

20

11

AK99012340017

隔圈

Spacer ring

2

14

AK99012340093

轴密封圈

Shaft seal gasket

2

14

AK99012340094

轴密封圈

2

15

7222-GB297

单列向心圆锥滚子轴承

16

7522-GB297

单列向心圆锥滚子轴承

Shaft seal gasket Single row radial conical roller bearing Single row radial conical roller bearing

18

HFF3502011CK1A

放油螺塞

Oil drain plug screw

4

19

HFF2041043CKFT

端盖

End cover

2

23

A22×2DIN7603Cu

垫圈

Washer

4

27

Q151C1295TF2

六角头螺栓

Hexagon head bolt

10

28

Q5211435

圆柱销

Cylindrical pin

10

29

AK99012340122

轮边行星轮（Z=16）

Hub planetary wheel （Z=16）

10

30

AK-99-934-013

滚针轴承

Needle bearing

20

31

AK99012340075

轮边行星轮垫片

Hub planetary wheel washer

10

32

AK99012340077

垫圈

Washer

10

33

AK99012340004

行星齿轮轴

Planetary gear shaft

10

- 258 -

2 2


用量 Total


用量 Total


用量 Total





Part Name and Spec.


用量 Total

35

AK99012340121

内齿圈（Z=57）

Internal gear ring （Z=57）

2

36

AK880420014

轴用挡圈

Shaft retaining ring

2

37

AK99012340119

齿圈支架总成

Ring gear bracket assy

2

40

HFF2400115CKFT

轴头锁片

Gudgeon locking plate

2

42

AK99012340005

太阳轮（Z=23）

Sun gear （Z=23）

2

43

AK99012340076

太阳轮垫圈

Sun gear washer（Z=23）

2

45

99012340009/11

轮边及行星架合件

Hub and planet carrier combination

1

HFF2401295CK9GFTZGS

下推力杆支座（左）

HFF2401296CK9GFTZGS

下推力杆支座（右）

HFF2402251CK4GZG

双头螺栓

AK99014320165

中桥轮间差速器总成

HFF2406020CK9GFTZG

差速锁总成

AK99014320166CK4GFT

中桥轴间差速器总成

HFF2510113/130CK4GFT

其他 others Lower thrusting rod base (LH) Lower thrusting rod base (RH)

1 1

Stud Inter- intermediate axle differential assy

16

Differential lock assy Inter- intermediate gear differential assy

1

轴间差速器壳总成

Inter-axle differential housing assy

1

HFF24050106A

轮边减速器总成

Hub reduction gear assy

1

AK99012340082

后轮毂总成

Rear hub assy

2

HFF2406003CK1BZ

差速锁缸体

Differential lock cylinder block

1

HFF2406013CK1BZ

活塞

Piston

1

HFF2406014CK1BZ

O 型密封圈

O-ring seal

1

HFF2406016CK1BZ

汽缸衬垫

Cylinder gasket

1

HFF2406024CK9GFTZG

拨叉轴

Shift rail

1

HFF2406023CK9GFTZG

压力开关

Pressure switch

1

- 259 -

1

1


用量 Total


用量 Total


用量 Total






Part Name and Spec.

用量 Total

HFF2406022CK9GFTZG

拨叉回位簧

Shift fork retracting spring

1

HFF2406021CK9GFTZG

拨叉

Shift fork

1

Q350B10

六角头薄螺母

1

Q2821025

开槽平端紧定螺钉

Hexagon head thin nut Tightening screw, w/ slotted flat end

Q150B0865TF2

六角头螺栓

Hexagon head bolt

3

Q40308

弹簧垫圈

Spring washer

3

- 260 -

1


用量 Total


用量 Total


用量 Total


1S325125002H1中桥（5.73，加宽，铸钢）-中桥制动器 1S325125002H1 Intermediate axle (5.73, widened, cast steel) - intermediate axle brake

- 261 -

1S325125002H1 中桥（5.73，加宽，铸钢）-中桥制动器 1S325125002H1 Intermediate axle (5.73, widened, cast steel) - intermediate axle brake 适用车型及用量（件）标号 No.



Part Name and Spec.

用量 Total

Intermediate axle (5.73,

1

1S325125002H1


HFF35020109GOMJG

后制动器总成（左）

Rear brake assy (LH)

1

HFF35020209GOMJG

后制动器总成(右）

Rear brake assy (RH)

1

1

AK99112340006

制动鼓

Brake drum

2

11

HFF3502323CK1G

摩擦片

Friction lining

2

11

HFF3502324CK1G

摩擦片

Friction lining

2

19

HFF3502023CK9GFTZG

制动凸轮轴（左）

Brake camshaft (LH)

1

20

HFF3502024CK9GFTZG

制动凸轮轴（右）

Brake camshaft (RH)

1

22

AK880340023

O 形密封圈

O-ring seal

2

23

AK880440010

附加垫片

Additional shim

4

26

HFF3502120CK9GFTZG

间隙调整臂总成（左）

Clearance adjusting arm assy (LH)

1

27

HFF3502130CK9GFTZG

间隙调整臂总成（右）

Clearance adjusting arm assy (RH)

1

32

AK99014340041

凸轮轴支架

Camshaft

2

35

Q151B1490

六角螺栓

Hexagon nut

2

36

Q151B1440

六角螺栓

Hexagon nut

2

37

HFF2401042CK9GFTZGS

气室支架(六孔)

Air chamber (6-hole)

1

40

Q151B2040TF2

固定气室支架用

Hexagon bolt for fixing air

六角螺栓（20*40）

chamber (20 × 40)

widened, cast steel)

6 按需

50

AK99012320173-176

调整垫片

Adjusting shim

As required

- 262 -


用量 Total


用量 Total


用量 Total


- 263 -

1S325125002H1中桥（5.73，加宽，铸钢）-中桥主减及贯通轴 1S325125002H1 Intermediate axle (5.73, widened, cast steel)- intermediate axle main reduction and -through shaft

- 264 -

1S325125002H1 中桥（5.73，加宽，铸钢）-中桥主减及贯通轴 1S325125002H1 Intermediate axle (5.73, widened, cast steel)- intermediate axle main reduction and -through shaft 适用车型及用量（件）标号 No.


1S325125002H1 HFF2502100CK9GFTZGB （I=5.73）



Part Name and Spec.

Intermediate axle (5.73,

用量

车型

用量

Total

Vehicle Model

Total

1

widened, cast steel)

中桥主减速器总成

Intermediate axle reduction gear assy

1

Inter-wheel differential housing assy

1

1

AK99014320127/008

轮间差速器壳总成

2

AK99014320091-1

轮间差速器十字轴(小孔)

4

AK99012320009

半轴齿轮

Half-axle gear

6

AK1800320131/132

半轴齿轮垫片

Shim, half-axle gear

7

AK99014320125/126

主、从动锥齿轮

Driving/driven cone gear

1

8

Q181B1635TF2

六角头螺栓

Hexagon head bolt

16

9

7516EX-GB297

单列圆锥滚子轴承

Single-row conical roller bearing

2

10

Q151B1480TF2

六角头螺栓

Hexagon head bolt

8

11

AK3809320159

差速器轴承调整螺母

Adjusting nu, differential bearing

2

12

AK79000320027-1

止动片

Stop plate

2

15

AK3809320155

固定啮合套

Fixing sliding sleeve

1

16

AK3809320157

圆螺母

Round nut

1

17

AK3809320158

锁止垫片

Locking washer

1

18

AK99014320136

主、从动圆柱齿轮

Driving/driven cylindrical gear

1

19

AK99014320137

主、从动圆柱齿轮

Driving/driven cylindrical gear

1

Inter-wheel differential

1

cross-pin (small hole)

2 按需 As required

- 265 -

3253DLPJE0RZA01


用量 Total


用量 Total




零件代号


Part Code

Part Name and Spec.

用量

车型

用量

Total

Vehicle Model

Total

20

AK99014320257

滚柱轴承

Roller bearing

1

20

AK99014320256

钢丝挡圈

Steel wire retaining ring

1

21

7311-GB297

单列圆锥滚子轴承

Single-row conical roller bearing

2

22

50312-GB277

一面带止动槽的

Single row radial ball bearing,

向心球轴承

w/ stop groove at one side

23

60119-GB278

一面带防尘罩的

Single row radial ball bearing,

向心球轴承

w/ dust cover at one side

24

AK99014320174

挡油片

Grease baffle

1

25

AK99014320140

隔圈

Spacer ring

1

26

AK780320088

轴承压板

Bearing pressure plate

1

27

AK99014320129

轴承座

Bearing seat

1

28

AK99014320128

轴承外环压板

Press plate, bearing outer race

1

29

AK99014320131

调整垫片

Adjusting shim

33

AK99014320135

空心轴

Hollow shaft

1

34

AK99012250031

开槽螺母

Slotted nut

1

35

Q433130

轴用压扁钢丝挡圈

Flattened steel wire retaining ring, shaft

1

38

AK99014320091

轴间差速器十字轴(大孔)

39

AK99114320059

半轴齿轮（后）

Half-axle gear (rear)

1

40

AK99114320032

半轴齿轮（前）

Half-axle gear (front)

1

41

AK99012320010

行星齿轮

Planetary gear

4

42

AK99012320150

行星齿轮垫片

Planetary gear shim

4

1 1

按需 As required

Inter-axle differential cross-pin (large hole)

- 266 -

1


用量 Total


用量 Total




零件代号

Part Name and Spec.


Part Code

用量

车型

用量

Total

Vehicle Model

Total

按需 43

AK99014320067/70

半轴齿轮前垫片

Front shim, half-axle

As

gear

required 按需 44

AK99014320071/74

半轴齿轮后垫片

As

Rear shim, half-shaft gear

required 46

AK288320105

差速锁环

Differential lock ring

1

47

AK288320106

差速锁销

Differential locking pin

10

48

AK99014320061

轴间差速器垫片

Inter-axle differential washer

1

49

HFF2402150CK4GFT

凸缘总成（中前）

Flange assy（front middle）

1

50

AK79000320013

凸缘螺母

Flange nut

1

53

AK99014320053

拨叉

Shift fork

1

55

AK3809320156

滑动啮合套

Guide sliding sleeve

1

57

AK1800320077

拨叉活动块

Movable block, shift fork

1

61

AK99014320031

贯通轴

-through shaft

1

62

AK99014320205

凸缘总成（中后）

Flange assy（rear middle）

1

64

212-GB276

深沟球轴承

Deep groove ball bearing

1

67

HFF2400111CK3F

半轴（左）（L=1117）

Half-axle（LH）（L=1117）

1

68

HFF2400112CK3F

半轴（右）（L=1117）

Half-axle（RH）（L=1117）

1

69

AK99012340067

油封

Oil seal

2

- 267 -


用量 Total


用量 Total


1S325125002H1中桥（5.73，加宽，铸钢）-中桥总成含差速锁及减振器壳 1S325125002H1 Intermediate axle (5.73, widened, cast steel) - intermediate axle assy including differential lock and shock absorber housing

- 268 -

1S325125002H1 中桥（5.73，加宽，铸钢）-中桥总成含差速锁及减振器壳 1S325125002H1 Intermediate axle (5.73, widened, cast steel) - intermediate axle assy including differential lock and shock absorber housing 标号 No.

1 2 2 5 6 8 15 15 26 39 40 43 44 46 47 51 57 63



1S325125002H1


1325125031104

中桥总成含差速锁及减振器壳

HFF2501010CK9GFTZGS HFF2400113CKFT HFF2400114CKFT Q72222 AK99000330006 AK5863315 HFF2406023CK9GFTZG AK79100710003 HFF2502010CK9GFTZG AK99014320259 AK99014320118 AK99014320141 AK99014320144 AK99014320175 AK81500010163 AK99014320076 AK99014320156 AK79100360018

中桥壳总成锁紧螺母(外) 锁紧螺母(内）碗形堵塞通气孔总成磁性螺塞总成压力开关压力开关主减速器壳总成过桥箱接油板总成轴承座过桥箱盖轴承壳端盖加油螺塞差速锁摇臂总成托架总成工作缸

Part Name and Spec.

Intermediate axle (5.73, widened, cast steel) Intermediate axle (containing differential lock and shock absorber housing) Intermediate axle housing assy Locking nut (external) Locking nut (internal) Bowl-shaped plug Air vent hole assy Magnetic plug screw assy Pressure switch Pressure switch Main reducer housing assy Gap bridge box Oil receiving plate assy Bearing seat Gap bridge box cover Bearing housing end-cover Oil filler plug screw Differential lock rocker arm assy Bracket assy Working cylinder

- 269 -

用量 Total 1 1 1 2 2 1 1 1 1 1 1 1 1 1 1 1 2 1 1 1



1S32533000401前轴(7.5T,手调臂,转向节臂右置)-1 1S32533000401 Front axle (7.5T, w/hand adjusting arm, RH knuckle arm)-1

19

28

22

20 21

23 24

25

27 26

29

30 31

32

33

17 18 34 15

16 11

12

9

10 7

7 6 5 4

43

44 45 46 47 48 49 50

14 13 12

39 40

38 41 42

8

7

7 6 5

1

3

3 2

2

- 270 -

4

37

36

35

1S32533000401 前轴(7.5T,手调臂,转向节臂右置)-1 1S32533000401 Front axle (7.5T, w/hand adjusting arm, RH knuckle arm)-1 适用车型及用量（件）标号


零件代号 Part Name and Spec.


Part Code

前轴(7.5T,手调臂, 1S32533000401

Front axle (7.5T, w/hand adjusting

转向节臂右置)

arm, RH knuckle arm )

用量

车型

用量

车型

用量

车型

用量

车型

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

1

1

HFF3001011 CK 1G

前轴

Front axle

1

2

AK880.41.0031

转向节销

Knuckle pin

2

3

AK880.41.0049

推力滚柱轴承

Thrust roller bearing

2

4

AK880.41.0052

O 型密封圈

O-ring seal

2

5

AK880.41.0094~97,104~108

附加垫片

Additional shim

6

AK880.41.0035

衬套

Bush

2

7

AK880.34.0017

衬套

Bush

4

8

AK880.41.0033

支架（左）

(LH)

1

9

AK880.41.0037

支架（右）

(RH)

1

10

AK880.41.0075

双头螺栓

Stud

8

11

M14X1.5-GB889

全金属自锁螺母

Full-metal self-locking nut

8

12

Q700B01

直通式滑脂嘴

Straight type lubricating nipple

2

13

Q5005050

开口销

Split pin

4

14

AK90003872377

六角槽形扁螺母

Hexagon slotted flat nut

4

15

HFF3003067 CK 1G

转向横拉杆臂（左）

Steering lateral pull rod arm (LH)

1

16

HFF3003068 CK 1G

转向横拉杆臂（右）

Steering lateral pull rod arm (RH)

1

17

M18X1.5-GB889

全金属自锁螺母

Full-metal self-locking nut

2

18

AK880.41.0060

双头螺栓

Stud

2

19

HFF3001011 CK 1GFTBY

转向直拉杆臂

Steering drag link arm

1

按需 As required

- 271 -

3253DLPJE0RZA01





Part Code

用量

车型

用量

车型

用量

车型

用量

车型

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

20

AK880.41.0059

调整螺钉

Adjusting screw

2

21

Q351B14T15

六角薄螺母

Hexagon thin nut

2

22

Q5211014

圆柱销

Cylindrical pin

2

23

AK880.41.0030

转向节

Knuckle

2

24

AK295.42.0033

O 型密封圈

O-ring seal

2

25

AK990.0041.0114

隔环

Spacer ring

2

26

AK990.0041.0061

轴密封圈

Shaft seal gasket

2

27

7614EX-GB297

圆锥滚子轴承

Conical roller bearing

2

28

AK990.0041.0104-FT

车轮螺栓

Wheel bolt

20

29

HFF3501128 CK 1GOM-1

前轮毂

Front wheel hub

2

30

Q30022

车轮螺母

Wheel nut

20

31

7610EX-GB297

圆锥滚子轴承

Conical roller bearing

2

32

Q5006380

开口销

Split pin

2

33

AK880.41.0043

罩

Hood

2

34

Q150B0816

六角头螺栓

Hexagon head bolt

16

35

Q40308

弹簧垫圈

Spring washer

16

36

HFF3001141 2B

六角槽型螺母

Hexagon slotted nut

2

37

HFF3001142 2B

垫片

Shim

2

38

AK880.41.0038

支销

ing pin

4

39

Q151C1220

六角头螺栓

Hexagon head bolt

4

40

AK880.41.0029

衬套

Bush

2

41

AK880.41.0100

盖

Cover

2

42

Q43056

孔用弹性挡圈

Hole circlip

2

43

HFF3003021 CK 1G

转向横拉杆

Steering lateral pull rod

1

44

AK544.114.08

紧固夹

Tightening clamp

2

- 272 -





Part Code

Flat washer

用量

车型

用量

车型

用量

车型

用量

车型

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

45

Q40112

平垫圈

2

46

Q32812

I 型非金属六角锁紧螺母

47

Q151C1265

六角头螺栓

Hexagon head bolt

48

CQ19-3003320/CQ19-3003420

万向球接头总成（左/右）

Universal ball t assy (LH/RH)）

49

AK90003872377

六角槽形扁螺母


2

50

Q5005050

开口销

Split pin

2

Non-metal Hexagon slotted

2

locknut, type I

2 各1 1 each

- 273 -

1S32533000401前轴(7.5T,手调臂,转向节臂右置)-2 1S32533000401 Front axle (7.5T, w/hand adjusting arm, RH knuckle arm )-2

- 274 -

1S32533000401 前轴(7.5T,手调臂,转向节臂右置)-2 1S32533000401 Front axle (7.5T, w/hand adjusting arm, RH knuckle arm )-2 适用车型及用量（件）标号

零件代号

No.

Part Code

1S32533000401


前轴(7.5T,手调臂,

Part Name and Spec.


车型

用量

车型

用量

车型

用量

车型

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

转向节臂右置)

Front axle (7.5T, w/hand adjusting arm, RH knuckle arm )

1

Shaft circlip

2

1

Q43125

轴用弹性挡圈

2

AK880.32.0028~30,0046

调整垫圈

3

AK880.34.0022

垫圈

Washer

2

4

AK880.34.0040

制动调整臂

Brake adjusting arm

2

5

Q5004030

开口销

Split pin

2

6

Q40114

平垫圈

Flat washer

2

7

Q5101440

销轴

Axis pin

2

8

Q340B16

六角螺母

Hexagon nut

4

9

Q41216

外锯齿锁紧螺母

External sawtoothed locking nut

4

10

AK880.36.0132

膜片式制动气室

Diaphragm brake chamber

2

11

AK880.44.0010

附加垫片

Additional shim

4

12

AK880.44.0015

隔套

Spacer bush

2

13

AK880.34.0023

O 型密封圈

O-ring seal

4

14

AK880.44.0002\3

制动凸轮轴

15

AK880.34.0037

密封塞

Seal plug

4

16

AK880.44.0007

制动器防尘罩

Brake dust cover

2

17

Q40308

弹簧垫圈

Spring washer

8

18

Q150B0816

六角头螺栓

Hexagon head bolt

8

19

AK990.0034.0027

滚轮

Roller

4

20

AK990.0044.0018

制动蹄

Brake shoe

4

21

AK880.44.0011

制动摩擦片

Brake friction lining

4

按需 Adjusting washer

As required

各1 Brake camshaft

1 each

- 275 -

3253DLPJE0RZA01


零件代号

No.

Part Code

Part Name and Spec.



车型

用量

车型

用量

车型

用量

车型

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

Total

Vehicle Model

22

AK880.34.0039

铆钉

Rivet

56

23

AK880.44.0012

回位弹簧

Retracting spring

2

24

AK880.44.0032

回位弹簧销

Retracting spring pin

4

25

AK990.0044.0017

制动摩擦片

Brake friction lining

4

26

AK880.44.0006

衬套

Bush

4

27

AK880.44.0008

限位板

Limit plate

2

28

AK90003872369

六角槽型扁螺母


4

29

Q5005050

开口销

Split pin

4

30

HFF3501128 CK 1GOM-1

制动鼓

Brake drum

2

31

Q2541028

沉头螺钉

Countersink screw

4

- 276 -

北汽福田汽车股份有限公司 Beiqi Foton MotorCo., Ltd, 地址：北京市昌平区沙河 Add ： Shahe Town, Changping District, Beijing 邮政编码：102206 Postal Code：102206 配件销售电话：***-******** Sales Phone for accessories: ***-******** 传真：***-******** Fax：***-******** 服务电话：***-******** Service phone：***-********

- 277 -

Parts Catalogue Foton Truck Version：9 Series -tc-19 174q2m

Overview 3e4r5l

More details w3441

Related Documents 3m3m1z

Hino Truck Bus Parts Catalogue 3b3l4

Sinotruk Howo Truck Parts Catalogue b251q

Foton 3475d

V80703 Detroit Diesel Series 40 Parts Catalogue 573x6b

Truck Light Series 900 Switch 5y6q2d

Itr Parts Catalogue 2y54k

More Documents from "Sawal Wal" fh5e

6l6m1j

Fundamental Of Hydraulic.pdf 5i4t

6l6m1j

Format Of Noc To Be Obtained From Society / 3p3h1x

Odontologia g5k2u
