Install SAP HANA Studio & HANA Client on a Windows System 

     

At the end of this tutorial, you will know: How to Client How to Studio How to SAPCAR Extract the SAR Files to desktop Install SAP HANA CLIENT Installing SAP HANA Studio on a Windows Box To Install SAP HANA Studio on a Windows System, we will first install the client which provides connectivity from the windows box to the HANA Server. On top of the client, we can install HANA Studio which provides graphical interface to create tables, create view, and so on and so forth. So, first we will the client files, then we will studio files, and then we will SAPCAR which is a utility tool to expand those ed files, and finally we will install the files.

SAP HANA Client To start installing the application, we have to first go to “Internet Explorer”. And then type http://service.sap.com in the URL which will open the homepage for “Service Marketplace” (figure 1). Figure 1

On the “Service Marketplace”, we need to go to the “SAP Portal” which will take us to the “ Portal” homepage (figure 2). From the “ Portal” homepage, we need to two sets of installation files. Figure 2

To install the files, we need to go to “Software s” which is the third tab in the portal which will open the “SAP Software Center”. Next, we need to click on “ Packages and Patches” from the left-hand side menu (figure 3). Figure 3

Then, we need to click on “A-Z Index” from the dropdown under “ Packages and Patches” which will bring us to the next screen (figure 4). Figure 4

Next, we click on “H” as we have to install SAP HANA components (figure 4) which will bring us to the next screen with the list of all tools beginning with “H”. From the list, we have to click on the “SAP HANA PLATFORM EDITION” (figure 5) which will bring us to the “SAP HANA PLATFORM EDITION” menu. Figure 5

On this screen, we need to click on “SAP HANA PLATFORM EDIT. 1.0” which will take us to the next screen “SAP HANA PLATFORM EDIT. 1.0”.

Since we don’t want to the whole product but only the client component for the windows machine so we can connect to a Linux server, we will click on “Comprised Software Component Versions” which will expand the list of various components. Now Click on Entry by Component From the above screen, we need to two tools. Firstly, we need to be able to connect to ODBC and JDBC from the Windows machine to the Linux server. To do that, we will use the “SAP HANA CLIENT 1.0” (figure 7) and click on the “Windows on x64 64bit” option to the 64 bit version for Windows. CLick on HANA CLIENT (figure 7) Figure 6

After clicking on the “Windows on x64 64bit” option, we will scroll down to see the various files we can (figure 2.15). We do not these by right-clicking but by using the “ Basket”. On the above screen we will see the “Patch Level” also called the “Version Level” mentioned against every version. In some cases, we may need to the specific version for the specific server. In this scenario, we will the “IMDB CLIENT 100 Patch Level 34”. To do this, we select the “IMDB CLIENT 100 Patch Level 34” (figure 7) and select “Add to Basket” (figure 7).

Figure 7

This will bring us to the screen where we can see that the version has been added to the basket.

SAP HANA Studio After the version has been added to the basket, we need to add the actual SAP HANA Studio file. So, we scroll up and come back to the list of various components (figure 2.19). To the HANA Studio File we click on “SAP HANA Studio 2.0” from the list (figure 8). Figure 8

From the dropdown, we select “Windows on x64 64bit” and then scroll down to select the relevant version. Figure 9

In this case, it is the last version in the list IMC STUDIO2 122”. After selecting the required version, we will add it to the “ Basket”. Next, we need to the SAPCAR tool which is an executable to extract data from the ed “SAR” files.

SAPCAR Tool To SAPCAR, go Back to the " Packages & Patches" we need to click on “By Catalogue” Figure 10

On this page, we need to click on “Additional Components” and from the list select “SAPCAR”. On the next screen, we need to select the latest version of SAPCAR which in this case is 7.21 (figure 11). Figure 11

From the next dropdown, we need to select the version compatible with the existing windows environment which in this case is “Windows on x64 64bit” (figure 11). After clicking on the required version, scroll down to select and add the relevant version to the basket which in this case is “SAPCAR 5” (figure 11). Add it to the “ Basket” by following to procedure mentioned before. To check the content of the basket, click on the link “my BASKET” from the left-hand side menu which will open a screen with all the components we have added to the basket (figure 2.33). In this scenario, there will be three files – SAPCAR, HANA Studio, and HANA Client. From the above screen, we need to take the cursor to one file at a time, right-click, and then select “Save Target As…” and save it to the desired location which in this case is the desktop. Repeat the procedure for saving the HANA Studio and HANA Client file on the desktop as well. After we minimize the browser window, we should see the three files ed on our desktop. So, this is the way that we can get the content from service market place in order to install the SAP HANA Client or the Studio on a Windows Box which is connecting to a HANA server on a Linux Machine.

Installing the Applications – Extracting the SAR Files To begin the installation process, the first thing we to do is to extract the data from the SAR files. To do this we would go to “start” and then type “cmd” in the command line. Now change to the directory where you have downlaod the files and extract all files with the cmd

So, we scroll down to the end of the screen again and type SAPCAR –xvf “I*.sar” it will extract any file that starts with “I” and ends with .sar on the desktop folder. >sapcar -xvf "I*.sar" Figure 12

It will now extrack all the files in the relavent folders Now Exit the CMD prompt. So, we can see now that the .sar files are getting extracted to those folders 1. SAP_HANA_STUDIO 2. SAP_HANA_CLIENT After the extraction, we can exit the command line by typing “exit” in the command box.

SAP HANA Client Installation To install the SAP HANA CLIENT, we will first go to the SAP HANA CLIENT FOLDER and install the client by clicking on the “hdbinst.exe" Figure 13

And, then we will allow it to install (figure 13).

Next, it will prompt if we can install the client and which version so we will simply click “enter” to install version 1 for 64-bit which will then install the client. Figure 14

After the file stops installing, the command box will ask us to press any key. After pressing a random key, we need to confirm that the client has been installed. To check that, go to “Start” and click on “Control ”. Next, click on “System and Security” from the control (figure 15) and then click on “istrative Tools” (figure 15). Figure 15

Next, go to “Data Sources ODBC”, go to the second tab “System DSN”, and click on “Add” (figure16). Figure 16

We should be able to see “HDBODBC” connectivity and its version (figure 17). Figure 17

Install SAP HANA Studio The next step is to install the studio, go to the other folder “SAP HANA STUDIO” and again click on “hdbinst.exe” and allow it to install. Next, a command box will open which will try to detect if the Studio is already installed. In this case, we will have to install the studio and to do that we just need to click “Enter” and it will automatically . It takes a few seconds to install as at first it will install the Microsoft C++ Runtime environment (figure18). Figure 18

Then, it will install the Equinox P2 Director which is used for the front end and lastly, it will derive that the installation file has been installed. Figure 19

To see if the Studio has been installed, go to “Start” and click on “All programs”. Next, click on “SAP HANA” and then on “SAP HANA STUDIO”. The next screen will confirm that the SAP HANA STUDIO has been installed.
