MEMS Oscillator Overview

Integrated Device Technology POWER MANAGEMENT

|

|

ANALOG & RF The Analog and Digital Company™

INTERFACE & CONNECTIVITY

|

TIMING & SYNCHRONIZATION

|

MEMORY & LOGIC

4M SERIES

4E SERIES

4H SERIES

• Short Lead Times Enables Just-In-Time inventory management

• Includes additional CMOS output Synchronous to main LVDS/LVPECL output

• 100fs Phase Jitter (1.875MHz to 20MHz)

• Standard Differential Outputs LVDS, LVPECL

• ±50ppm accuracy

• Standard Package Sizes – 7.0 x 5.0 mm – 5.0 x 3.2 mm

• Quad Frequencies – Generate up to four different frequencies in a single oscillator – Consolidates Inventory

• Low Phase Jitter < 1.0 ps rms • ±50 ppm Frequency Stability

• 50-625 MHz frequency range

|

DATA CONVERSION

• Plus-PPM Frequency Margining Up to ±1000ppm on-the-fly frequency tuning • Any Frequency between: 50-625 MHz range • LVDS / LVPECL Output

• Backward Compatible Fits over standard 6-pin 7050 package footprints (unused pins turned off)

All IDT MEMS Oscillators Offer Up to 40x Higher Reliability than Quartz No Activity Dips | No Zero Time Failures | High Shock and Vibration Resistance

TECHNICAL EMAIL: [email protected]

WEBSITE: www.idt.com/go/MEMS
