John Deere ­ Parts Catalog ­ Frame 5

John Deere ­ Parts Catalog

Close Window

Printer Friendly Page   Catalog: 2690 | Grid: 0 | Section: 70 | Page: 170

Catalog Name:

240 and 250 Skid­Steer Loaders

Page Name:

CONTROL VALVE SPOOL AND SEALS (240 SN ­349999) (250 SN ­359999)

Direction of Travel:

key

PART NO.

PART NAME

1

......

Bolt

QTY SERIAL NO. 3

240 X

250 REMARKS X

(A) (B)

2

......

Snap Ring

2

X

X

(A)

3

......

Spacer

1

X

X

4

......

Sleeve

1

X

X

(A)

5

......

Sleeve

2

X

X

(A)

6

......

Washer

2

X

X

(A)

7

......

Spring

3

X

X

(A)

8

......

Plate

4

X

X

(A) (B)

9

......

Ball

2

X

X

(A)

10

......

Ball

4

X

X

(A)

http://jdpc.deere.com/jdpc/servlet/com.deere.u90490.partscatalog.view.servlets.PrintPageServlet?printParams=Illustration,+Keylines

1/2

6/4/2017

John Deere ­ Parts Catalog ­ Frame 5

key

PART NO.

PART NAME

11

......

Plug

QTY SERIAL NO. 2

X

X

12

KV12879

Spacer

3

X

X

13

KV12887

Seal

7

X

X

14

......

Seal

5

X

X

(C)

15

......

Seal

5

X

X

(C)

16

......

Cap

1

X

X

(B)

17

......

Spacer

1

X

X

(A)

18

......

Sleeve

1

X

X

(A)

19

......

Spool

1

X

X

20

......

Spool

key

PART NO.

PART NAME

21

......

Spool

1

X

X

22

......

Screw

1

X

X

23

KV12885

Spacer

1

X

X

24

KV12884

Spacer

2

X

X

25

KV12888

Cap Screw

4

X

X

26

19H2992

Screw

2

X

X

1/4" X 1­1/4" (SUB FOR KV12886)

27

......

O­Ring

1

X

X

(C)

28

KV20871

Adapter Fitting

2

X

X

29

KV21245

Seal

2

X

X

30

KV20872

Adapter Fitting

2

X

key

PART NO.

PART NAME

31

KV23082

Solenoid

2

X

X

(SUB FOR KV20802)

32

34H280

Spring Pin

2

X

X

3/16" X 7/8"

33

R26448

O­Ring

2

X

X

34

24M7054

Washer

4

X

X

35

19H3844

Screw

2

X

X

X

X

X

X

1

240

X

QTY SERIAL NO.

QTY SERIAL NO.

240

240

250 REMARKS (A)

X 250 REMARKS (B)

X 250 REMARKS

6.400 X 12 X 1.600 mm

19H3845

Screw

2

36

KV21241

Wiring Harness

1

..

KV12881

Spool

1

X

X

(INCL ITEMS MARKED (A)) (HAND/FOOT ONLY)

..

KV17329

Spool Kit

1

X

X

(HANDS ONLY) LIFT

..

KV12880

Spool

1

X

X

(INCL ITEMS MARKED (B))

key

PART NO.

PART NAME

..

KV12882

Seal Kit

1

X

X

(INCL ITEMS MARKED (C))

..

KV17328

Kit

1

X

X

(HANDS ONLY) BUCKET

­917751

QTY SERIAL NO.

240

1/4" X 3­1/4"

250 REMARKS
