Lr Functions 5i6l4r

}", "Compare= ", "ExpectedValue={ }", "StopOnValidationError=<error_code>", LAST); Example See Also The lr_checkpoint function validates the value of a parameter against a checkpoint value. If the validation fails, the script aborts or continues, depending on the values of the StopOnValidationError argument and the Continue on Error? runtime setting. The Continue on Error? runtime setting takes precedence over the value of StopOnValidationError. Operators are case-sensitive. This function is not recorded. It can be added manually when enhancing the script. StepName The name of the step, as it appears in the test tree. Any text can be used. ActualValue Data to compare with the ExpectedValue argument. Can be a value or a LoadRunner parameter. Compare Operator used to compare the ActualValue and ExpectedValue values: Equals NotEquals Contains StartsWith EndsWith ExpectedValue Data to compare with the ActualValue argument. Can be a value or a LoadRunner parameter. StopOnValidationError Indication of whether all steps fail. Valid values: false: Steps do not fail. true: Steps fail. LAST This delimiter marks the end of the argument list. Page 52 of 337

lr_continue_on_error

Specifies an error handling method.

C Language

HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_continue_on_error

Return Values Parameterization

void lr_continue_on_error ( int value ); Example See Also The lr_continue_on_error function specifies how to handle errors. You can choose to continue running if an error occurs, or to abort the run execution. Normally, you specify how the test run component handles errors during script execution using the General section in VuGen's Runtime Settings dialog. By default, the script exits when an error occurs. To continue script execution even when errors occur, select the Continue on Error check box in VuGen's Runtime Settings. However, you can control error handling for a specific segment of the script, by inserting the lr_continue_on_error function before and after the desired segment (see the example for details). In addition to the lr_continue_on_error statements, you can use severity levels to control error handling for database operation errors in LoadRunner. value One of the Error Continuation Options. Page 53 of 337

lr_convert_string_encoding Converts a string to a different encoding.

C Language HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_convert_string_encoding


int lr_convert_string_encoding ( const char *sourceString, const char *fromEncoding, const char *toEncoding, const char *paramName); Example See Also lr_convert_string_encoding converts a string encoding between the following encodings: System locale, Unicode, and UTF-8. The function saves the result string, including its terminating NULL, in the parameter paramName. lr_convert_string_encoding is added manually to a script when needed. It is not recorded. Possi bl e val ues f or ' f r omEncodi ng' and ' t oEncodi ng' : sourceString The string to convert fromEncoding The encoding of the sourceString toEncoding The encoding to convert of the string saved in parameter paramName paramName The name of the parameter in which the destination string will be saved Constant Value LR_ENC_SYSTEM_LOCALE NULL LR_ENC_UTF8 "utf-8" LR_ENC_UNICODE "ucs-2"

Page 54 of 337

lr_db_connect Connects to a database.

C Language

HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_db_connect


int lr_db_connect("StepName", "ConnectionString= ", "ConnectionName= ", "ConnectionType= ", LAST); Example See Also The lr_db_connection function establishs the database connection used by other database related functions, such as lr_db_executeSQLStatement . Tip: Use the Connection Dialog to create a database specific connection string. Select the Database: Connect option in the Add Step dialog box and enter the connection parameters. When specifying the connection string for a specific SQL Server instance, use the server and instance name in the data source, escaping the backslashes in the path. For example: "Connect i onSt r i ng=Ser ver=soa-m16\ \ soa;Dat abase=. . . When specifying the connection string using SQL Server 2005 Express, use the server name syntax <SQL Server 2005 Express installation>\SQLEXPRESS. Add lr_db_connect to the v_init section of the script. Adding this function to the Action section can increase performance overhead during load testing. StepName The name of the step, as it appears in the test tree. Any text can be used. ConnectionString A string indicating the database to which to connect and other information needed to establish the connection. The syntax for the connection string varies depending on the data provider specified with the ConnectionType argument. For example, to connect to an SQL Server, ConnectionString could contain the value: Dat a Sour ce=mySer ver Addr ess; I ni t i al Cat al og=myDat abase I d=my ; wor d=mywor d; Note that the equal signs are part of the connection string. The cannot be encrypted. ConnectionName A logical name for the connection. ConnectionType Type of data provider. Valid values are: SQL (meaning, the Microsoft Native SQL Provider) OLEDB ODBC ORACLE LAST This delimiter marks the end of the argument list. Page 55 of 337

lr_db_dataset_action Performs an action on a dataset.

C Language

HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_db_dataset_action


int lr_db_dataset_action("StepName=<step_name>", "DatasetName= ", "Action= ", LAST); Example See Also The lr_db_dataset_action function sets the cursor to the first record of the dataset, removes it from memory, or prints the dataset to the Replay Log. When printing a dataset, only the first one hundred records are listed in the test report summaries. The total number of records is also listed. StepName The name of the step, as it appears in the test tree. Any text can be used. DatasetName Logical name for the dataset specified in lr_db_executeSQLStatement . Action The action to perform on the dataset: RESET: Set the cursor to the first record of the dataset. REMOVE: Releases the memory allocated for the dataset. PRINT: Prints the contents of the entire dataset to the Replay Log and other test report summaries. LAST This delimiter marks the end of the argument list. Page 56 of 337

lr_db_disconnect

Disconnects from a database.

C Language HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_db_disconnect


int lr_db_disconnect("StepName=<step_name>", "ConnectionName= ", LAST); Example See Also The lr_db_disconnect function disconnects a database connection. You must call lr_db_disconnect for each connection established by lr_db_connect to terminate the connection. Add lr_db_disconnect to the v_end section of the script. Adding this function to the Action section can increase performance overhead during load testing. StepName The name of the step, as it appears in the test tree. Any text can be used. ConnectionName The logical name for the connection specified in lr_db_connect . LAST This delimiter marks the end of the argument list. Page 57 of 337

lr_db_executeSQLStatement Submits an SQL statement to a database.

C Language

HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_db_executeSQLStatement


int lr_db_executeSQLStatement("StepName=<step_name>",

"ConnectionName= ", "SQLStatement=<statement>", ["DatasetName= ",] LAST); Example See Also The lr_db_executeSQLStatement submits an SQL statement to a database. When SQLStatement is a SELECT statement, DatasetName points to the resulting dataset. In this context, the term dataset is used to describe tables of data (formatted as rows and columns). The data in the dataset can be manipulated by subsequent steps in the script. When SQLStatement is either DELETE, INSERT, or UPDATE, a warning is issued to the Replay Log and the test results summary. After calling this function, the row is undefined. In this case, make sure to set Row to next or 1 if calling lr_db_getValue after this function. StepName The name of the step, as it appears in the test tree. Any text can be used. ConnectionName The logical name for the connection specified in lr_db_connect . SQLStatement The SQL statement, such as SELECT, INSERT, DELETE, and UPDATE. The syntax is database-dependent. SQLStatement can be parameterized. DatasetName Logical name for the resulting dataset from the SQL query, by which you can refer to the dataset in subsequent steps. For use only when SQLStatement is a SELECT statement. LAST This delimiter marks the end of the argument list. Page 58 of 337

lr_db_getValue Retrieves a value from a dataset.

C Language

HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_db_getValue


int lr_db_getValue("StepName=<step_name>", "DatasetName= ", "Column= ", "Row= ", "OutParam= ", LAST); Example See Also The lr_db_getValue function retrieves a value from the dataset created by an lr_db_executeSQLStatement. When this function reaches the last row of the dataset, the row is undefined. If Row=next is specified the next time lr_db_getValue is called, the script continues to the first record without issuing any errors. This function does not the print or output of binary data. Binary values retrieved from the dataset appear as . StepName The name of the step, as it appears in the test tree. Any text can be used. DatasetName Logical name for the dataset specified in lr_db_executeSQLStatement . Column The name of the column in the dataset from which to retrieve the value.

Row Sets the dataset cursor to the specifed row before fetching data. One of: The row number (1-based) current - does not move the cursor next - sets the cursor to the next row OutParam The LoadRunner parameter that will contain the value. LAST This delimiter marks the end of the argument list. Page 59 of 337

lr_debug_message Sends a debug message to the log file.

C Language

HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_debug_message


int lr_debug_message (unsigned int message_level, const char *format, ... ); Example See Also Java Language int lr.debug_message ( int message_level, String message ); Example See Also Java Syntax Visual Basic function lr.debug_message ( ByVal message_level as Integer, ByVal message as string ) as Integer Example See Also Visual Basic Syntax The lr_debug_message function sends a debug message when the specified message level is active. If the specified message level is not active, a message is not issued. You can set the active message level to MSG_CLASS_BRIEF_LOG or MSG_CLASS_EXTENDED_LOG from the interface or by using lr_set_debug_message. To determine the current level, use lr_get_debug_message. Note that you can also specify multiple message levels with an OR separator ("|"). If any one of the levels are active (from the UI), the message is issued to the Output window. If none of the levels are active, the message is not issued. The message is sent to the output window. To display the debug messages in the LoadRunner output window or Application Management agent log file, use the Expert Mode Settings. Activate Expert Mode (Tools > Expert Mode) and then choose Tools > Options > Debug Information and select the General check box. message_level One of the Message Log Run-Time Settings. Disabled does not apply. format A formatted string which is the message to be sent to the log file. You may use the standard Message Formatting that is available for printf. Page 60 of 337

lr_decrypt Decrypts an encoded string

C Language

HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_decrypt


char *lr_decrypt (const char *EncodedString); Example See Also Java Language String lr.decrypt ( String EncodedString ); Example See Also Java Syntax Visual Basic function lr.decrypt ( ByVal EncodedString as String ) as String Example See Also Visual Basic Syntax The lr_decrypt function decrypts an encoded string. This function is generated during recording to encode s. VuGen records the actual but displays an encoded version of the within the lr_decrypt function. When you run the script, the test run component decrypts the . Each time you record, VuGen encrypts the differently, even when you use the same . It is possible to create an lr_decrypt call from a recorded value in the script. Select an entire string between quote marks, not including the quote marks themselves. Right-click in the selected string and choose the ENCRYPT STRING option. The original string is replaced with an lr_decrypt call where the EncodedString argument is the original string after encoding. To get an encryped value from a recorded value for later use, copy the recorded value. Then run Start > Programs > LoadRunner > Tools > Encoder. Paste the value into the field, and click Generate. The encrypted string appears in the Encoded string box. Click the Copy button, then paste the encryped string into a parameter for later use, or assign the value to a string variable. VuGen uses 32 bit encryption. EncodedString The encoded string you want to decrypt. Page 61 of 337

lr_disable_ip_spoofing Disables IP Spoofing

C Language HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_disable_ip_spoofing


int lr_disable_ip_spoofing ( ); Example See Also lr_disable_ip_spoofing disables IP spoofing during a script run. Page 62 of 337

lr.empty

Returns an Variant whose value is Empty.

Java Script HP LoadRunner Online Function Reference > Utility Functions: Java Language (lr.) > lr.empty


Variant lr.empty (); Example See Also VB Script Function lr.empty () as Variant; Example See Also Use lr.empty to an Empty variant to a function that requires a Variant argument. In Visual Basic, VB.NET or C#, use the class or keyword Empty. Page 63 of 337

lr_enable_ip_spoofing Enables IP Spoofing

C Language HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_enable_ip_spoofing


int lr_enable_ip_spoofing ( ); Example See Also lr_enable_ip_spoofing enables IP spoofing during a script run. Page 64 of 337

lr_end_sub_transaction Marks the end of a sub-transaction.

C Language HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_end_sub_transaction


int lr_end_sub_transaction (const char *sub_transaction, int status ); Example See Also Java Language int lr.end_sub_transaction ( String sub_transaction, int status ); Example See Also Java Syntax Visual Basic function lr.end_sub_transaction ( sub_transaction as String, status as Integer ) as Integer Example See Also Visual Basic Syntax The lr_end_sub_transaction function marks the end of a sub-transaction. To mark the beginning of the sub-transaction, use the lr_start_sub_transaction function. You insert these functions immediately before and after the sub-transaction steps. Multiple sub-transactions can be nested within a parent transaction, but each

lr_end_sub_transaction statement must match an lr_start_sub_transaction statement or it will be interpreted as an illegal command. sub_transaction A string indicating the name of an existing sub-transaction. status The transaction status. Page 65 of 337

lr_end_timer Stops a timer.

C Language HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_end_timer

Example Return Values Parameterization See Also

double lr_end_timer (merc_timer_handle_t timer); Example See_Also lr_end_timer stops a timer that began timing when lr_start_timer was called. It returns the elapsed time in seconds. The resolution depends on the run-time environment. The maximum resolution is a microsecond. timer The handle of the timer returned by lr_start_timer. Page 66 of 337

lr_end_transaction Marks the end of a transaction.

C Language

HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_end_transaction


int lr_end_transaction (const char *transaction_name, int status ) ; Example See Also Java Language int lr.end_transaction ( String transaction_name, int status ); Example See Also Java Syntax Visual Basic function lr.end_transaction ( ByVal transaction_name as string, ByVal status as Integer ) as Integer Example See Also Visual Basic Syntax The lr_end_transaction function marks the end of a transaction and records the amount of time it took to perform the transaction. To indicate a transaction to be analyzed, place the lr_start_transaction function before the transaction, and the lr_end_transaction function after the transaction. You can manually set the status of the transaction or you can allow the script to detect it automatically. To manually set the status, you perform a manual check within the code of your script (see example) evaluating the return code of a function. For the "succeed" return code, set the status

to LR_. For a "fail" return code, set the status to LR_FAIL. For an "aborted" return code, set the status to LR_STOP. If status is LR_AUTO, then the value of status is automatically assigned. By default, this value is LR_ signifying a successful transaction. However, if prior to lr_end_transaction, you change the default value using lr_set_transaction_status, lr_set_transaction_status_by_name, lr_set_transaction_instance_status or lr_fail_trans_with_error, then this is the value which is ed as status in lr_end_transaction. If you make a series of calls to functions that modify the LR_AUTO status, then it is the last call before lr_end_transaction which effectively changes the status. transaction_name A string indicating the name of an existing transaction. status The Transaction Status Page 67 of 337

lr_end_transaction_instance Marks the end of a transaction instance.

C Language HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_end_transaction_instance


int lr_end_transaction_instance (long parent_handle, int status ); Example See Also The lr_end_transaction_instance function marks the end of a transaction instance and records the amount of time it took to perform the transaction. To indicate a transaction instance to be analyzed, place the lr_start_transaction_instance function before the transaction, and the lr_end_transaction_instance function after the transaction. You can manually set the status of the transaction instance or you can allow the script to detect it automatically. To manually set the status, you perform a manual check within the code of your script (see example) evaluating the return code of a function. For the "succeed" return code, set the transaction status to LR_. For a "fail" return code, set the status to LR_FAIL. For an "aborted" return code, set the status to LR_STOP. To instruct the script to automatically detect the status, specify LR_AUTO. The script returns the detected. parent_handle The handle returned by lr_start_transaction_instance at the creation of the instance. status The transaction status. Page 68 of 337

lr_error_message

Sends an error message with location details to the output windows, log files, and other test report summaries.

int lr_error_message (const char *format, exp1, exp2,...expn. ); HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_error_message


Example See Also Java Language int lr.error_message ( String message ); Example See Also Java Syntax Visual Basic function lr.error_message ( ByVal message as String ) as Integer Example See Also Visual Basic Syntax The lr_error_message function sends an error message to product output windows (such as the LoadRunner output window), log files (such as Vugen and the Application Management agent log file), and other test report summaries. For details regarding the output for each product, see the products' guides. To send a special notification that is not specifically an error message, use lr_output_message. If Run-time settings > General > Miscellaneous > Fail open transactions on lr_error_message is selected, calling lr_error_message will fail the transaction in addition to sending the message. If you want to save the elapsed time in spite of the transaction failure, capture the time with lr_get_transaction_duration before calling lr_error_message, then create a transaction to report the time with lr_set_transaction. It is not recommended that you send a message to the Output window in the middle of a transaction, as it will lengthen the execution time. Instead, use lr_log_message to send the message only to the V log file. This conserves the resources required for sending messages to the VuGen displays the message text of the lr_error_message function in the Execution red, using Error code 17999. Note that this function sends a message to the output even when logging is disabled in the run-time settings. In the V Execution log, this function lists the location and line number from where the message was issued. To issue a message without those details, use lr_message. Out put of l r _er r or _message( " out put message" ) ; - Act i on( 4) : out put message Out put of l r _message( "message" ) ; message format C Language A formatted string to send to the Output window. You may specify a literal string in quotation marks or use the standard Message Formatting that is available for printf.

exp 1 , exp 2 ,.. exp n C Language The expressions or variables to be formatted. message Java and Visual Basic A string containing the error message to send to the Output window. See VB String Arguments and Java String Arguments. Page 69 of 337

Page 70 of 337

lr.eval_double Returns the double value of the parameter.

Visual Basic and VB Script

HP LoadRunner Online Function Reference > Utility Functions: VB, VB Script (lr.) > lr.eval_double


function lr.eval_double (ByVal param_name as String ) as Double Example See Also Visual Basic Syntax The lr.eval_double function returns the value of the parameter as a double param_name The parameter to evaluate. Page 71 of 337

lr.eval_long

Returns the long value of the parameter.

Visual Basic and VB Script HP LoadRunner Online Function Reference > Utility Functions: VB, VB Script (lr.) > lr.eval_long


function lr.eval_long (ByVal param_name as String ) as long Example See Also Visual Basic Syntax The lr.eval_long function returns the value of the parameter as a Long. param_name The parameter to evaluate. Page 72 of 337

lr_eval_string Returns the string argument after evaluating embedded parameters.

C Language

HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_eval_string


char *lr_eval_string (const char *instring ); Example See Also Java Language String lr.eval_string ( String instring );

Example See Also Java Syntax Visual Basic function lr.eval_string (ByVal instring as String ) as String Example See Also Visual Basic Syntax The lr_eval_string function returns the input string after evaluating any embedded parameters. If the string argument contains only a parameter, the function returns the current value of the parameter. Embedded parameters must be in brackets. Note: lr_eval_string allocates memory internally. The memory is freed at the end of each iteration. If you evaluate a parameter or parameters in a loop, conserve memory by not using lr_eval_string . Instead, use lr_eval_string_ext and free the memory in each loop iteration with lr_eval_string_ext_free. instring The string to evaluate. Page 73 of 337

lr_eval_string_ext Creates a buffer and assigns it the input string after evaluating embedded parameters.

C Language HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_eval_string_ext


int lr_eval_string_ext (const char *in_string, unsigned long const in_len, char ** const out_str, unsigned long * const out_len, unsigned long const options, const char *file, long const line ); Example See Also The lr_eval_string_ext function evaluates in_str by replacing parameters with their string value. It creates a buffer containing the expanded string and sets out_str to point to that buffer. It also assigns the length of the buffer to out_len. Note that in_len is the length of the argument you , and not the length of the value of the parameter. For example, if parameter ABC contains the string "1234567890", the call is: l r _eval _s t r i ng_ext ( "{ABC}" , 5 After using lr_eval_string_ext, free the memory allocated for the output buffer with lr_eval_string_ext_free. This function is useful when correlating statements that use binary data, for example, data with embedded NULL characters. Use this function in conjunction with lr_eval_string_ext_free in preference to lr_eval_string when evaluating strings in a loop. Using lr_eval_string in a loop uses more memory. in_str The string to be evaluated.

in_len The length of the name of argument in_str +2 to for the parentheses. out_str A pointer to the output buffer. out_len The length of the output buffer. options Reserved for future use. Currently set to "0". file Reserved for future use. Currently set to "0". line Reserved for future use. Currently set to "-1". Page 74 of 337

lr_eval_string_ext_free Frees the buffer allocated by lr_eval_string_ext.

C Language

HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_eval_string_ext_free


void lr_eval_string_ext_free (const char **param); Example See Also The lr_eval_string_ext_free function frees the memory allocated by lr_eval_string_ext . param A pointer to the buffer. Page 75 of 337

lr_exit Exits from the script, action, or iteration.

C Language

HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_exit


void lr_exit (int continuation_option, int exit_status); Example See Also Java Language void lr.exit (int continuation_option, int exit_status); Example See Also Java Syntax The lr_exit function allows you to exit from the script run during execution. A transaction in which lr_exit is called does not appear in the LoadRunner controller in the Transaction Status box. It is ignored in the count of ed and failed transactions. If lr_exit is called several times in the same script, whether in different actions or different iterations, it is the exit status of the last call that determines the status of the V group running the script. The controller's Scenario Groups Status box displays the status. It is the column in which the group appears after the run stops. continuation_option The continuation option specifies how the script continues after the call to lr_exit exit_status The status of the scenario group as a result of calling lr_exit Page 76 of 337

lr_fail_trans_with_error Sets the default status of open transactions to LR_FAIL and sends an error message.

C Language HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_fail_trans_with_error

Example Return Values Parameterization See Also

int lr_fail_trans_with_error (const char *format, exp1, exp2,...expn.); The lr_fail_trans_with_error function sets the default exit status to LR_FAIL for all open transactions with LR_AUTO in their lr_end_transaction statement and sends an error message. The message is sent to the LoadRunner output window or Application Management agent log file. A transaction's final status is defined in the status parameter of the lr_end_transaction statement. If this status is LR_AUTO, then the value is automatically assigned. By default the value assigned is LR_, which signifies a successful transaction. lr_fail_trans_with_error changes this default value to LR_FAIL. Use the format and exp parameters in the same way as the standard Message Formatting that is available for printf. If it is a literal string, enclose it with quotation marks. format A string describing the format to use to write the optional remaining expressions exp 1 , exp 2 ,.. exp n . You may specify a literal string in quotation marks or use the standard Message Formatting that is available for printf. exp 1 , exp 2 ,.. exp n The optional expressions (variables) to be formatted and printed. Page 77 of 337

lr_get_attrib_double

Returns a value of the calling mdrv command's parameter as a double.

C Language HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_get_attrib_double


double lr_get_attrib_double (const char *parameter); Example See Also Java Language double lr.get_attrib_double ( String parameter );

Example See Also Visual Basic function lr.get_attrib_double ( ByVal parameter as String ) as double Example See Also Visual Basic Syntax The lr_get_attrib_double function returns the value of a command line parameter whose type is a double precision floating point when the script is run using the mdrv command. You place the command line parameter's name in the function's argument field and lr_get_attrib_double returns the value of that parameter. The function returns NULL if the mdrv command line was not used to run the script (for example, the script was run directly in VuGen or by LoadRunner). For more information on the running scripts using the mdrv command line, see the HP LoadRunner Virtual Generator Guide. The Command Line Parsing Functions functions eliminate the need to parse the command line manually. parameter The name of a parameter which can be interpreted as a double value. Page 78 of 337

lr_get_attrib_long

Returns a value of the calling mdrv command's parameter as a long integer.

C Language HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_get_attrib_long


long lr_get_attrib_long (const char *parameter); Example See Also Java Language long lr.get_attrib_long ( String parameter ); Example See Also Java Syntax Visual Basic function lr.get_attrib_long ( ByVal parameter as String ) as long Example See Also Visual Basic Syntax The lr_get_attrib_long function returns the value of a command line parameter whose type is long integer when the script is run using the mdrv command. You place the command line parameter name in the function's argument field and lr_get_attrib_long returns the value of that parameter. The function returns NULL if the mdrv command line was not used to run the script (for example, the script was run directly in VuGen or by LoadRunner). For more information on the running scripts using the mdrv command line, see the HP LoadRunner Virtual Generator Guide. The Command Line Parsing Functions functions eliminate the need to parse the command line manually. parameter The name of a parameter which can be interpreted as a double value. Page 79 of 337

lr_get_attrib_string Returns a value of the calling mdrv command's parameter as a string.

C Language

HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_get_attrib_string


char *lr_get_attrib_string (const char *argument); Example See Also Java Language String lr.get_attrib_string ( String parameter ); Example See Also Java Syntax Visual Basic function lr.get_attrib_string ( ByVal parameter as String ) as String Example See Also Visual Basic Syntax The lr_get_attrib_string function returns a command line argument string when the script is run using the mdrv command. You place the argument name in the function's argument field and lr_get_attrib_string returns the string values associated with that argument. The function returns NULL if the mdrv command line was not used to run the script (for example, the script was run directly in VuGen or by LoadRunner). For more information on the running scripts using the mdrv command line, see the HP LoadRunner Virtual Generator Guide. The function returns NULL if the argument you specify is invalid. This is useful for checking if a command line option or a specific value is valid. The Command Line Parsing Functions functions eliminate the need to parse the command line manually. argument A command line argument whose value is a string. Page 80 of 337

lr_get_debug_message

Returns the current message logging settings.

C Language HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_get_debug_message


unsigned int lr_get_debug_message ( ); Example See Also Java Language int lr.get_debug_message ( ); Example See Also Java Syntax Visual Basic function lr.get_debug_message ( ) as Integer Example See Also Visual Basic Syntax The lr_get_debug_message function returns the current log run-time settings . The settings determine what information is sent output. The log settings are specified with the run-time settings dialog, or by using the lr_set_debug_message function.

The debug messages are sent to the LoadRunner output window or Application Management agent log file. To evaluate the returned value, you can perform a bitwise AND operation. This allows you to determine which options are set. See the C syntax example. Page 81 of 337

lr_get_host_name Returns the name of the host.

C Language

HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_get_host_name


char *lr_get_host_name ( ); Example See Also Java Language String lr.get_host_name ( ); Example See Also Java Syntax Visual Basic function lr.get_host_name ( ) as String Example See Also Visual Basic Syntax The lr_get_host_name function returns the name of the machine executing the script. Page 82 of 337

lr_get_master_host_name Returns the name of the Controller host.

C Language HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_get_master_host_name


char *lr_get_master_host_name ( ); Example See Also Java Language String lr.get_master_host_name ( ); Example See Also Java Syntax Visual Basic function lr.get_master_host_name ( ) as String Example See Also Visual Basic Syntax The lr_get_master_host_name function returns the name of the machine running the Controller . Not applicable for products that do not run Vs. Page 83 of 337

lr_get_transaction_duration Returns the duration of a transaction.

C Language HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_get_transaction_duration


double lr_get_transaction_duration (const char *transaction); Example See Also Visual Basic function lr.get_transaction_duration ( String transaction ) as double Example See Also Visual Basic Syntax The lr_get_transaction_duration function returns the duration in seconds of the specified transaction to this point. You use this function to determine the total transaction time before the transaction has ended. lr_get_transaction_duration returns values greater than zero only for open transactions. This function returns the duration including Wasted Time. Therefore, the value may be slightly greater than the duration reported for the function when closed with lr_end_transaction. To determine other transaction statistics, such as think time and wasted time, use the Transaction Functions. transaction A string indicating the name of a transaction. Page 84 of 337

lr_get_transaction_status Returns the current status of a transaction.

C Language

HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_get_transaction_status


int lr_get_transaction_status ( const char *transaction_name ) ; Example See Also lr_get_transaction_status returns the current status of a transaction. lr_get_transaction_status cannot be invoked after lr_end_transaction. Since lr_get_transaction_status can only return the status of an open transaction, it cannot report the final transaction status. This function can be useful when a transaction, which is made up of a number of steps, can fail at various points. By checking the status and terminating the V, you can prevent unnecessary activity. transaction_name The name of the transaction. Page 85 of 337

lr_get_transaction_think_time Returns the think time of a transaction.

C Language

HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_get_transaction_think_time


double lr_get_transaction_think_time (const char *transaction); Example See Also Visual Basic

function lr.get_transaction_think_time ( String transaction ) as double Example See Also Visual Basic Syntax The lr_get_transaction_think_time function returns the think time of the specified transaction until this point. It returns values greater than zero only for open transactions. To determine other transaction statistics, such as think time and wasted time, use the appropriate Transaction Functions. transaction The transaction name . Page 86 of 337

lr_get_transaction_wasted_time

Returns the wasted time of a transaction by its name.

C Language HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_get_transaction_wasted_time


double lr_get_transaction_wasted_time (const char *transaction); Example See Also The lr_get_transaction_wasted_time function returns the Wasted Time in seconds of the specified transaction to this point. The lr_get_transaction_wasted_time function returns values greater than zero only for open transactions. To determine other transaction statistics, such as think time and wasted time, use the appropriate Transaction Functions. transaction The name of the transaction. Page 87 of 337

lr_get_trans_instance_duration Returns the duration of a transaction instance.

C Language

HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_get_trans_instance_duration


double lr_get_trans_instance_duration (long trans_handle); Example See Also The lr_get_trans_instance_duration function returns the duration of an open transaction instance in seconds until this point. Use this function to determine the total transaction time before the transaction has ended. The difference between this function and lr_get_transaction_duration is that here you specify a transaction instance by its handle. With lr_get_transaction_duration, you specify an independent transaction by its name. The trans_handle is the return value of a call to lr_start_transaction_instance .

lr_get_trans_instance_duration returns values greater than zero only for open transactions. To determine other transaction statistics, such as think time and wasted time, use the appropriate Transaction Functions. trans_handle A transaction handle. Page 88 of 337

lr_get_trans_instance_status Returns the current status of a transaction instance.

C Language

HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_get_trans_instance_status


int lr_get_trans_instance_status ( long transaction_handle ) ; Example See Also lr_get_trans_instance_status returns the current status of a transaction instance. lr_get_trans_instance_status cannot be invoked after lr_end_transaction_instance . It cannot report the final transaction instance status. The transaction_handle is the handle returned by the call to lr_start_transaction_instance that created the instance. This function can be useful when a transaction instance, which is made up of a number of steps, can fail at various points of its execution. By checking the status and terminating the V, you can prevent unnecessary activity. transaction_handle The name of the transaction. Page 89 of 337

lr_get_trans_instance_think_time Returns the think time of a transaction instance specified by its handle.

C Language

HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_get_trans_instance_think_time


double lr_get_trans_instance_think_time (long trans_handle); Example See Also The lr_get_trans_instance_think_time function returns the think time of the specified transaction until this point. The difference between this function and lr_get_transaction_think_time is that here you specify a transaction instance by its handle. With lr_get_transaction_think_time, you specify an independent transaction by its name. The trans_handle is the handle returned by the call to lr_start_transaction_instance that created the instance. The lr_get_trans_instance_think_time function returns values greater than zero only for open

transactions. To determine other transaction statistics, such as think time and wasted time, use the appropriate Transaction Functions. trans_handle A transaction handle. Page 90 of 337

lr_get_trans_instance_wasted_time Returns the wasted time of a transaction instance.

C Language HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_get_trans_instance_wasted_time


double lr_get_trans_instance_wasted_time (long trans_handle); Example See Also The lr_get_trans_instance_wasted_time function returns the Wasted Time of the specified transaction until this point. The difference between this function and lr_get_transaction_wasted_time is that here you specify a transaction instance by its handle. With lr_get_transaction_wasted_time, you specify an independent transaction by its name. The trans_handle is the handle returned by the call to lr_start_transaction_instance that created the instance. The lr_get_trans_instance_think_time function returns values greater than zero only for open transactions. To determine other transaction statistics, such as think time and wasted time, use the appropriate Transaction Functions. trans_handle A transaction handle. Page 91 of 337

lr_get_v_ip Returns the IP address of a V.

C Language

HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_get_v_ip


char *lr_get_v_ip( ); Example See Also Visual Basic function lr.get_v_ip() as String Example See Also Visual Basic Syntax The lr_get_v_ip function returns the IP address of a V. When performing IP spoofing, each V can use a different address. This function allows you to determine the current V's IP address.

If the IP was set with the web_set_sockets_option function using the IP_ADDRESS_BY_INDEX option, lr_get_v_ip returns that IP. Page 92 of 337

lr_load_dll

Loads an external DLL.

C Language HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_load_dll


int lr_load_dll (const char *library_name ); Example See Also The lr_load_dll function loads a DLL (Windows) or shared object (UNIX) allowing you to call an external function when replaying using the C interpreter. Once you load the DLL, you can call any function defined in the DLL, without having to declare it. You can specify a full path for the DLL. On Windows platforms, if you do not specify a path, lr_load_library searches for the DLL using the standard sequence used by the C++ function, LoadLibrary . On UNIX platforms, you can set the LD_LIBRARY_PATH environment variable (or the platform equivalent). The lr_load_dll function uses the same search rules as dlopen. For more information, see the man pages for dlopen or its equivalent. library_name The name of a DLL (Windows) or shared object (UNIX). Page 93 of 337

lr_log_message

Sends a message to the Application Management agent log file or the LoadRunner V log.

C Language

HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_log_message


int lr_log_message (const char *format, exp1, exp2,...expn.); Example See Also Java Language int lr.log_message ( String message ); Example See Also Java Syntax Visual Basic function lr.log_message ( ByVal message as String ) as Integer Example See Also Visual Basic Syntax The lr_log_message function sends a message to the V or agent log file (depending on the application), and not to the output window. You can use this function for debugging by sending error or other informational messages to the log file. You can avoid overloading the network by using this function to send messages to the log file rather

than sending messages to the Output window (with lr_error_message or lr_output_message). In a standalone program such as VuGen, lr_log_message sends the message to the viewer and output.txt. To send a message to the output file, you must enable logging in the run-time settings, and select Always send messages. If you select Send messages only when an error occurs, there is no output from this function. In the V Execution log, this function does not list the location and line number from where the message was issued. To issue a message with those details, use lr_output_message. format C Language A formatted string to send to the log file. If it is a literal string, enclose it with quotation marks. Use the standard Message Formatting that is available for printf to set the format for the expressions you want to print. exp1, exp2,.. expn C Language The expressions (variables) to be formatted and printed. message Object oriented languages A string containing the message to send to the log. See VB String Arguments and Java String Arguments.

statement Output

lr_log_message("a message") a message lr_output_message("message"); Action(4): a message Page 94 of 337

lr_message

Sends a message to the log and output window.

C Language HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_message


int lr_message (const char *format, exp1, exp2,...expn.); Example See Also Java Language int lr.message ( String message ); Example See Also Java Syntax Visual Basic function lr.message ( ByVal message as String ) as Integer Example See Also Visual Basic Syntax The lr_message function sends a message to the log file and output window. When run in VuGen, the output file is output.txt. Use lr_log_message instead of this function to send the message only to the log file. This conserves the network and controller resources required for sending messages to the output.

To send a message to the output file, you must enable logging in the run-time settings, and select Always send messages. If you select Send messages only when an error occurs, there is no output from this function. In the log file, this function does not list the location and line number from where the message was issued. To issue a message with those details, use lr_output_message. format C Language A formatted string. If it is a literal string, enclose it with quotation marks. Use the standard Message Formatting that are available for printf to set the format for the expressions you want to print. exp 1 , exp 2 ,.. exp n C Language The expressions (variables) to be formatted and printed. message Object oriented A string containing the message to send to the Output window. See VB String Arguments and Java String Arguments.

statement Output

lr_message("a message") a message lr_output_message("a message"); Action(4): a message Page 95 of 337

lr.missing

Returns an Variant whose value is Missing.

Java Script HP LoadRunner Online Function Reference > Utility Functions: Java Language (lr.) > lr.missing


Variant lr.missing (); Example See Also VB Script Function lr.missing () as Variant; Example See Also Use lr.empty to an Missing variant to a function that requires a Variant argument. In Visual Basic, VB.NET or C#, use the class or keyword MISSING. Page 96 of 337

lr_output_message

Sends a message to log files, output windows, and other test report summaries.

C Language

HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_output_message


int lr_output_message (const char *format, exp1, exp2,...expn.); Example See Also Java Language int lr.output_message ( String message ); Example See Also Java Syntax Visual Basic function lr.output_message ( ByVal message as String ) as Integer Example See Also Visual Basic Syntax The lr_output_message function sends a message with the script section and line number to output windows (such as the LoadRunner output window), log files (such as the Vugen log file and the Application Management Web site and agent log file), and other test report summaries. For details regarding the output for each product, see the products' guides. When a script is run in VuGen, the output file is output.txt. To send an error message to the LoadRunner output window or Application Management agent log, use the lr_error_message function. It is not recommended that you send a message to the output window or agent the middle of a transaction, as it will lengthen the execution time. To send a message to the V execution log or Application Management Web site, but not to the Output window, use lr_log_message. To send a message to the output file, you must enable logging in the run-time settings, and select Always send messages. If you select Send messages only when an error occurs, there is no output from this function. To issue a message without including the location details, use lr_message. format C Language A formatted string. If it is a literal string, enclose it with quotation marks. Use the standard Message Formatting that is available for printf to set the format for the expressions you want to print. exp 1 , exp 2 ,.. exp n C Language The expressions (variables) to be formatted and printed. message Object Oriented A string containing the message to send to the Output window. See VB String Arguments and Java String Arguments.

statement Output lr.log_message("a message") a message lr.output_message("a message"); Actions.java (4): a message Page 97 of 337

Note: Do not send null pointers as arguments to string formats e.g. char *str = NULL; lr_output_message("%s", str); Page 98 of 337

lr_paramarr_idx

Returns the value of the parameter at a specified location in a parameter array.

C Language HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_paramarr_idx


char * lr_paramarr_idx ( const char * paramArrayName, unsigned int index); Example See Also lr_paramarr_idx returns a string containing the value of the parameter at the specified position in a parameter array. If the parameter does not exist, the return value is the concatenation of "{", paramArrayName, "_", index, and "}", for example, "{myParam_4}". paramArrayName The name of the parameter array from which to return the value. index The one-based position of the parameter in the array. Page 99 of 337

lr_paramarr_len

Returns the number of elements in a parameter array.

C Language HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_paramarr_len


int lr_paramarr_len (const char * paramArrayName); Example See Also lr_paramarr_len returns the number of elements in a parameter array. paramArrayName The name of the parameter array. Page 100 of 337

lr_paramarr_random Returns the value of the parameter at a random location in a parameter array

C Language

HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_paramarr_random


char * lr_paramarr_random (const char * paramArrayName); Example See Also lr_paramarr_random returns a string containing the value of the parameter in a parameter array. The value is returned from the parameter at a position chosen randomly by LoadRunner.

paramArrayName The name of the parameter array. Page 101 of 337

lr_param_increment

Increments the value of a numerical parameter.

C Language HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_param_increment


int lr_param_increment (const char *destination_param, const char *source_param); Example See Also The lr_param_increment function retrieves the value of source_param, increments its value by one, and stores the incremented value as a null terminated string in destination_param. This function is useful only in protocols that have a numerical parameter type. For protocols that have only string parameters, increment with C functions. For example: i = at oi ( l r _eval _st r i ng( "{modi f i cat i on_num}" ) ) ; spr i nt f ( buf , "%d" , i +1) ; l r _save_st r i ng( buf , "next _modnum" ) ; For protocols that have a numerical parameter, lr_param_increment can be used: l r _par am_i nc r ement ( "next _modnum" , "{modi f i cat i on_num}" ) ; source_param must be initialized with an integer value prior to calling lr_param_increment. source_param's value should include only single-byte digit characters with an optional sign or leading zeros. When destination_param exists, its value is overwritten. When it doesn't exist, the parameter is created dynamically. The value of source_param is restricted to the maximum value of a long integer minus 1. destination_param The name of the parameter to store the incremented parameter source_param The name of the parameter whose value is incremented Page 102 of 337

lr_param_sprintf

Writes formatted output to a parameter.

C Language HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_param_sprintf


int lr_param_sprintf ( const char * paramName, const char * format [,args ... ] ); Example See Also lr_param_sprintf functions like the standard C function sprintf except that the formatted string is written to a LoadRunner parameter instead of a string buffer. These formatting characters are not ed: %E, %hd, %hhd, %lld, %ld, %hhi, %lli, %hhu , %llu, %hhf , %llf, %hhe, and %lle.

paramName The target parameter to which the string is written. format One or more formatting characters. args Optional print arguments. Page 103 of 337

lr_param_unique

Generates a unique string and assigns it to a parameter.

C Language HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_param_unique


int lr_param_unique (const char * paramName); Example See Also lr_param_unique generates a string of format: <ID> . The string contains no spaces. paramName The target parameter to which the string is written. Page 104 of 337

lr_peek_events Checks for events.

C Language HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_peek_events


void lr_peek_events ( ); Example See Also Java Language void lr.peek_events ( ); Example See Also Java Syntax Visual Basic sub lr.peek_events ( ) Example See Also Visual Basic Syntax The lr_peek_events function suspends the V script run and checks for events before resuming. Scripts written in C language perform this check internally. Therefore, there is no need to use the lr_peek_events function. Scripts written in Java or Visual Basic do not perform this check internally. Therefore, insert this function into your V script at the point at which you want the V to pause. Page 105 of 337

lr.read_xml Returns the contents of an XML file as a string. Your cannot use standard parameterization with this function.

Java and Java Script HP LoadRunner Online Function Reference > Utility Functions: Java Language (lr.) > lr.read_xml

String.lr.read_xml (String file_name); Example See Also

The lr.read_xml function returns the contents of the specified file as a String. If the call fails, it returns null. file_name The file to read and return as a string. The file must exist in the data\SerializedObjects directory under the script directory. Page 106 of 337

lr_rendezvous Creates a rendezvous point in the V script.

C Language

HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_rendezvous


int lr_rendezvous (const char *rendezvous_name); Example See Also Java Language int lr.rendezvous ( String rendezvous_name ); Example See Also Java Syntax Visual Basic function lr.rendezvous ( ByVal rendezvous_name as String ) as Integer Example See Also Visual Basic Syntax The lr_rendezvous function creates a rendezvous point in a V script. When this statement is executed, the V program stops and waits for permission from LoadRunner to continue. This function can only be used in action section, and not in v_init or v_end. The difference between lr_rendezvous and lr_rendezvous_ex is that lr_rendezvous always returns zero. rendezvous_name The name of the rendezvous. Page 107 of 337

lr_rendezvous_ex Creates a rendezvous point in the V script.

C Language

HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_rendezvous_ex


int lr_rendezvous_ex (const char *rendezvous_name); Example See Also The lr_rendezvous_ex function creates a rendezvous point in a V script. When this statement is executed, the Vs stop and wait for permission from LoadRunner to continue. The default timeout is 30 sec. The timeout is set in the scenario policy in the Controller. This function can only be used in an action section, and not in v_init or v_end. The difference between this function and lr_rendezvous is that lr_rendezvous returns only LR_ or LR_FAIL. rendezvous_name The name of the rendezvous.

Page 108 of 337

Rendezvous Return Values The return values of the lr_rendezvous function are defined in the Lrun.h file. On PC platforms, the function returns one of the values described in the table. On UNIX platforms, the function returns 0 for success and -1 for an illegal name: HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > Rendezvous Return Values

Return Code Name Code Meaning LR_REND_ALL_ARRIVED 0 V was released after all the designated Vs arrived. LR_REND_TIMEOUT 1 V was released after the timeout value was reached. LR_REND_DISABLED 2 The rendezvous was disabled from the Controller. LR_REND_NOT_FOUND 3 The rendezvous was not found. LR_REND_V_NOT_ MEMBER 4 V was not defined in the rendezvous. LR_REND_V_DISABLED 5 V was disabled for the rendezvous. LR_REND_BY_ 6 The rendezvous was released by the . Page 109 of 337

lr_resume_transaction

Resumes reporting transaction data within a script.

C Language HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_resume_transaction


void lr_resume_transaction (const char *transaction_name); Example See Also Visual Basic Sub lr.resume_transaction ( String transaction_name ) Example See Also Visual Basic Syntax This function is retained for backward compatibility. For more general ways of reporting partial transaction durations, see lr_start_sub_transaction, and lr_set_transaction. The lr_resume_transaction function resumes the reporting of transaction data within the script that was suspended by lr_stop_transaction. After a call to lr_stop_transaction, statistics returned by the "get" Transaction Functions reflect only the data up to that call, until this function is called. Data collection, however, is not interrupted. After the call to lr_resume_transaction, the "get" functions return all data since the start of the transaction. Furthermore, the final results when the test is analyzed will reflect the total values, including the periods in between the transaction stop and resume. If lr_resume_transaction is not called, the "get" functions and the final results reflect only the

duration from the transaction start to the lr_stop_transaction call. Thus, lr_stop_transaction and lr_resume_transaction can be used conditionally to collect information either about an entire transaction, or only the beginning. To accomplish this, call lr_resume_transaction only if your condition is met. Note: When data is collected this way, the data in analysis will reflect both the tests where the condition for lr_resume_transaction is met, and the tests where it is not. If the section you may wish to exclude ends before the end of the transaction, this technique does not apply. If you need to differentiate between occurrences where the lr_resume_transaction condition is met and those where it is not in the analysis data, this technique does not apply. For other ways of recording durations conditionally, see lr_start_sub_transaction, and lr_set_transaction. transaction_name The name of the transaction. Page 110 of 337

lr_resume_transaction_instance Resumes reporting transaction instance data within a script

C Language

HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_resume_transaction_instance


void lr_resume_transaction_instance ( long trans_handle ); Example See Also The lr_resume_transaction_instance function resumes the reporting of transaction data within the script that was suspended by lr_stop_transaction_instance. After a call to lr_stop_transaction_instance, statistics returned by the "get" Transaction Functions reflect only the data up to that call, until this function is called. Data collection, however, is not interrupted. After the call to lr_resume_transaction_instance, the "get" functions return all data since the start of the transaction. Furthermore, the final results when the test is analyzed will reflect the total values, including the periods in between the transaction instance stop and resume. If lr_resume_transaction_instance is not called, the final results reflect the statistics only until the call to lr_stop_transaction_instance. The parent_handle is the value returned from the call to lr_start_transaction_instance that created the instance. lr_stop_transaction_instance and lr_resume_transaction_instance can be used to conditionally collect information about either the beginning, or all of the transaction. Note that you will not be able to differentiate in analysis between iterations when

lr_stop_transaction_instance was called and iterations where it was not. For more flexible ways recording transaction times conditionally, see lr_start_sub_transaction, lr_set_transaction,and lr_start_timer trans_handle The transaction instance id that was returned by lr_start_transaction_instance Page 111 of 337

lr_save_datetime Assigns the current date and time to a parameter.

C Language

HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_save_datetime


void lr_save_datetime(const char *format, int offset, const char *name); Example See Also The lr_save_datetime function saves the current date and time, or the date and time with the specified offset into a parameter. The resulting string will be truncated once it reaches MAX_DATETIME_LEN characters. The format can be a format defined in an included header file, such as DATE_FM, which is defined in lrun.h. You can use theDatetime Format Codes to build a format with any combination of strings and codes. For example, depending on the definitions in your computer's locale, "The current month is %b" would return The current month is JAN. "%d%b%y" would return 29JAN97. format The format of the retrieved date/time information. offset Offset from the current date and time, using the constants: DATE_NOW, TIME_NOW, ONE_DAY, ONE_HOUR, ONE_MIN. For example, TIME_NOW + ONE_HOUR name The name of the parameter to store the date/time information. Page 112 of 337

lr.save_double Saves a double value as a parameter.


HP LoadRunner Online Function Reference > Utility Functions: VB, VB Script (lr.) > lr.save_double


Sub lr.save_double (ByVal param_name as String, value as Double ) Example See Also Visual Basic Syntax The lr.save_double function saves value to parameter param_name. It creates the parameter if it does not exist. param_name The parameter in which to save the value value A numeric value Page 113 of 337

lr_save_int .

Saves an integer to a parameter.

C Language

HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_save_int


int lr_save_int ( int value, const char *param_name); Example See Also The lr_save_int function converts an integer to a string and saves the string in a parameter. If the parameter does not exist, it is created. value The integer value to assign to the parameter. param_name The name of the parameter. Page 114 of 337

lr.save_long Saves a long value as a parameter.


HP LoadRunner Online Function Reference > Utility Functions: VB, VB Script (lr.) > lr.save_long


Sub lr.save_long (ByVal param_name as String, value as long ) Example See Also Visual Basic Syntax The lr.save_long function saves value to parameter param_name. It creates the parameter if it does not exist. param_name The parameter in which to save the value value An integer or long integer value Page 115 of 337

lr_save_searched_string Searches for an occurrence of a string in a buffer and saves a portion of the buffer after that string to a parameter.

C Language

HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_save_searched_string


int lr_save_searched_string (const char *buffer, long buf_size, unsigned int occurrence, const char *search_string, int offset, unsigned int string_len, const char *parm_name ); Example See Also The lr_save_searched_string function searches for string search_string inside string or character array buffer, and finds the nth occurrence of search_string, where n is occurrence plus 1. The substring to be saved starts at offset after the end of the nth occurrence of search_string, and has length string_len. For example:

char cBuf f [ ] = " abc Emma Woodhouse abc El i zabet h Bennet abc Wi l l i am Pr i ce" ; l r _s ave_s ear c hed_s t r i ng( cBuf f , st r l en( cBuf f ) , 2, " abc" , / / Sear ch f or t hi r d occur r ence of " abc" 1, / / Ski p t he space af t er " abc" 4, / / Put t he next f our char act er s. . . " Fannys_br ot her " ) ; / / . . . i n par amet er Fannys_br ot her . Af t er t he cal l , t he cont ent of par amet er Fannys_br ot her i s "Wi l l " . The search_string cannot contain null characters, but the buffer can contain null characters. Use the lr_save_string function to save strings from character arrays. Use lr_save_searched_string only when you need to save a portion of a character array relative to a string occurrence. buffer The STRING or CARRAY buffer, part of whose contents you want to save. buf_size The buffer size. occurrence The occurrence number of the search_string (0-based count). For example, if the search_string occurs three times, and you want the second occurrence, set occurrence to 1. search_string The string to search for in the buffer. offset The number of characters to skip after the end of the search string occurrence. string_len The number of characters to save. parm_name Parameter name to be used in subsequent lr statements to refer to the saved information. Name is enclosed in double-quotes. Page 116 of 337

lr_save_string Saves a null-terminated string to a parameter.

C Language

HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_save_string


int lr_save_string (const char *param_value, const char *param_name); Example See Also Java Language int lr.save_string ( String param_value , String param_name); Example See Also Java Syntax Visual Basic function lr.save_string ( ByVal param_name as String, ByVal param_value as String ) as Integer Example See Also Visual Basic Syntax The lr_save_string function assigns the specified null-terminated string to a parameter. This function is useful in correlating queries. To determine the value of the parameter, use the lr_eval_string function. param_value The value to assign to the parameter.

param_name The name of the parameter. Page 117 of 337

lr_save_var

Saves a variable length string to a parameter.

C Language HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_save_var


int lr_save_var (const char *param_value, unsigned long const value_len, unsigned long const options, const char *param_name); Example See Also The lr_save_var function assigns the specified variable length string to a parameter. This function is useful in correlating queries. To determine the value of the parameter, use the lr_eval_string function. param_value The value to assign to a parameter. value_len The length of the value in bytes. options A parameter option, currently 0. param_name The name of the parameter. Page 118 of 337

lr_set_debug_message Sets the message level for the script execution.

C Language

HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_set_debug_message


int lr_set_debug_message (unsigned int message_level, unsigned int on_off); Example See Also Java Language int lr.set_debug_message ( int message_level, int on_off ); Example See Also Java Syntax Visual Basic function lr.set_debug_message ( ByVal message_level as Integer, ByVal on_off as Integer ) as Integer Example See Also Visual Basic Syntax The lr_set_debug_message function sets the debug message level, message_lvl, for the script execution. By setting a message level, you determine which information is sent. The setting is enabled by ing LR_SWITCH_ON as on_off , and disabled with LR_SWITCH_OFF. The messages are sent to the Application Management agent log or the LoadRunner V output. Message levels are generally set in the script's Run-time Settings dialog box. The value can be changed from the current Run-time Settings value. For example, if the script's current message level in

the Run-time Settings is set at "Brief" mode, the value can be increased to "Extended log" (LR_MSG_CLASS_EXTENDED_LOG): l r _set _debug_message( LR_MSG_CLASS_EXTENDED_LOG, LR_SWI TCH_ON) and later decreased to "Brief" once again: l r _set _debug_message( LR_MSG_CLASS_EXTENDED_LOG, LR_SWI TCH_OFF) To enable logging that is disabled in the Run-time Settings, set the message level to another level. For example: l r . set _debug_message ( l r . MSG_CLASS_EXTENDED_LOG, l r . SWI TCH_ON) ; After enabling the logging, return to the disabled state by setting the debug level to zero (0) and activating the option using the lr.SWITCH_ON switch as the second parameter. The message levels Result Data, Parameter Substitution, and Full Trace, are specific details, or subsettings, of the Extended log setting. To set one of these sub-settings you can use logical Or's in your message_level argument. Using LR_SWITCH_DEFAULT as on_off sets the on/off status of message_level to the default value regardless of previous calls to lr_set_debug_message. Use LR_SWITCH_DEFAULT with a single message_level argument. It does not work with ORed message_level settings. message_level One of the Message Log Run-Time Settings. on_off A switch to activate or deactivate a specific message level setting. Use one of the On-Off Constants. Page 119 of 337

Page 120 of 337

lr_set_transaction

Creates a completed transaction.

C Language HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_set_transaction


int lr_set_transaction(const char *name, double duration, int status); Example See Also Java Language int lr.set_transaction( String name, double duration, int status); Example See Also Java Syntax Visual Basic Function lr.set_transaction( String name, double duration, int status) as integer Example See Also Visual Basic Syntax The lr_set_transaction function creates a transaction, its duration, and status in a single call. Use it where the business process you want to capture in a transaction does not consist of sequential steps, or where you may or may not want to create a transaction, depending on conditions that are known

only during the test. To create a transaction for non-sequential steps, capture the duration of each series of steps that participate in the business process. Sum the durations and create the transaction with lr_set_transaction. To capture durations in C language scripts, use lr_start_timer and lr_end_timer. For other languages, use the native language time functions. lr_set_transaction can also be used to report the duration of a failed transaction by saving the duration before the transaction fails with lr_get_transaction_duration then using lr_set_transaction to create a new transaction for reporting that time. lr_set_transaction creates and closes the transaction. Therefore, no functions that work only on open transactions are applicable. Note: Do not use the period character (.) in a transaction name. The period character delimits transactions and sub-transactions. In analysis, a transaction name with a period will be interpreted as two transactions. Name A name for the transaction. duration Transaction duration in seconds. status The transaction completion status. One of theTransaction Status constants for , fail, or stop. The auto status is not applicable. Page 121 of 337

lr_set_transaction_instance_status Sets the status of a transaction instance.

C Language

HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_set_transaction_instance_status


int lr_set_transaction_instance_status (int status, long trans_handle); Example See Also The lr_set_transaction_instance_status function sets the status of the open transaction with the transaction handle trans_handle. The handle was returned by lr_start_transaction_instance . This transaction's lr_end_transaction_instance statement must use automatic status assignment by ing a Transaction Status of auto as its status parameter. A transaction's status is defined in the status parameter of lr_end_transaction_instance. If this status is LR_AUTO the value is automatically assigned. By default, this value is LR_ signifying a successful transaction. lr_set_transaction_instance_status changes this default value to status. For more information on transaction instances, see lr_start_transaction_instance.

status One of theTransaction Status constants for , fail, or stop. The auto status is not applicable. trans_handle The handle to a transaction instance Page 122 of 337

lr_set_transaction_status

Sets the default end status of open transactions.

C Language HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_set_transaction_status


int lr_set_transaction_status (int status); Example See Also Java Language int lr.set_transaction_status ( int status); Example See Also Java Syntax The lr_set_transaction_status function sets the status of those transactions currently open which have LR_AUTO in their lr_end_transaction statement. A transaction's status is defined in the status parameter of lr_end_transaction. If this status is LR_AUTO, the value is automatically assigned. By default, this value is LR_, signifying a successful transaction. lr_set_transaction_status changes this default value to status. status One of theTransaction Status constants for , fail, or stop. The auto status is not applicable. Page 123 of 337

lr_set_transaction_status_by_name Sets the default end status of a single transaction.

C Language HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_set_transaction_status_by_name


int lr_set_transaction_status_by_name (int status, const char *trans_name); Example See Also The lr_set_transaction_status_by_name function sets the default status of the open transaction with name trans_name. This transaction's lr_end_transaction statement must use automatic status assignment by ing LR_AUTO as its status parameter. A transaction's status is defined in the status parameter of lr_end_transaction. If this status is LR_AUTO, the value is automatically assigned. By default, this value is LR_, signifying a successful transaction. lr_set_transaction_status_by_name changes this default value to status. status One of theTransaction Status constants for , fail, or stop. The auto status is not applicable. trans_name The transaction name

Page 124 of 337

lr_start_sub_transaction Starts a sub-transaction specified by its parent's name.

C Language

HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_start_sub_transaction


int lr_start_sub_transaction (const char *sub_transaction, const char *parent_transaction); Example See Also Java Language int lr.start_sub_transaction (String sub_transaction, String parent_transaction); Example See Also Java Syntax Visual Basic Function lr.start_sub_transaction (String sub_transaction, String parent_transaction) as Integer Example See Also Visual Basic Syntax The lr_start_sub_transaction function marks the beginning of a sub-transaction. To mark the end of the sub-transaction, use lr_end_sub_transaction. You insert these functions immediately before and after the sub-transaction actions. Sub-transactions are used for isolating parts of a business process. For example, a sub-transaction "electrical_purchases" may be nested within the larger transaction "purchases." The transaction "purchases" is the parent transaction and "electrical_purchases" the sub-transaction. Multiple sub-transactions can be nested within a parent transaction. A subtransaction may also be a parent to a smaller sub–transaction. The duration of a transaction or sub-transaction is the sum of the durations of all steps between its start and end, including the steps that are included in sub-transactions. Each lr_start_sub_transaction statement must be matched with an lr_end_sub_transaction statement within the script or it will be interpreted as an illegal command. Note: Do not use the period character (.) in a transaction or sub-transaction name. The period character delimits transactions and sub-transactions. In analysis, a transaction name with a period will be interpreted as two transactions. sub_transaction The name of the sub-transaction parent_transaction The name of the parent transaction in which the sub-transaction is nested. Page 125 of 337

lr_start_timer

Starts a timer.

C Language HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_start_timer


merc_timer_handle_t lr_start_timer (); Example See Also lr_start_timer starts a timer that calculates the age of time in seconds. The resolution depends on the run-time environment. The maximum resolution is a microsecond. lr_start_timer returns a handle to the timer. the handle to lr_end_timer to stop the timer. Page 126 of 337

lr_start_transaction Marks the beginning of a transaction.

C Language

HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_start_transaction


int lr_start_transaction ( const char *transaction_name ); Example See Also Java Language int lr.start_transaction ( String transaction_name ); Example See Also Java Syntax Visual Basic function lr.start_transaction ( ByVal transaction_name as String ) as Integer Example See Also Visual Basic Syntax The lr_start_transaction function marks the beginning of a transaction. To indicate a transaction to be analyzed, use the lr_start_transaction and lr_end_transaction functions. These functions are inserted immediately before and after the transaction. Transactions can be nested, but each lr_start_transaction statement must be associated with an lr_end_transaction statement or it will be interpreted as an illegal command. Note: Do not use the period character (.) in a transaction or sub-transaction name. The period character delimits transactions and sub-transactions. In analysis, a transaction name with a period will be interpreted as two transactions. transaction_name The name of the transaction. Page 127 of 337

lr_start_transaction_instance Starts a transaction instance.

C Language HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_start_transaction_instance


long lr_start_transaction_instance ( const char *transaction_name, long handle); Example See Also The lr_start_transaction_instance function marks the beginning of a transaction instance. A transaction instance is an occurrence of a transaction with transaction_name. Instances are identified by their handle which distinguishes them from other instances of the same transaction. This function enables multiple instances of a transaction to be created. Use transaction instances when the same transaction is required to be performed under different circumstances and an analysis of each circumstance is required. By ing the handle of a parent transaction instance, the new instance will be considered a subtransaction instance of the parent. zero as the handle if there is no parent. For more information on sub-transactions, see lr_start_sub_transaction. The function returns the handle of the transaction instance which identifies the instance. Note that each lr_start_transaction_instance statement must be matched with an lr_end_transaction_instance statement or it will be interpreted as an illegal command. Note: Do not use the period character (.) in a transaction or sub-transaction name. The period character delimits transactions and sub-transactions. In analysis, a transaction name with a period will be interpreted as two transactions. transaction_name The name of the transaction. handle The parent transaction's handle. A value of 0 instructs VuGen to create a new parent transaction. Page 128 of 337

lr_stop_transaction

Freezes reporting of transaction data.

C Language HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_stop_transaction


double lr_stop_transaction (const char *transaction_name); Example See Also Visual Basic Function lr.stop_transaction ( String transaction_name ) as Double Example See Also Visual Basic Syntax This function is retained for backward compatibility. For more general ways of reporting partial transaction durations, see lr_start_sub_transaction, and lr_set_transaction. After a call to lr_stop_transaction, statistics returned by the "get" Transaction Functions reflect only the data up to the call, until lr_resume_transaction is called. The specified transaction must have

been opened with lr_start_transaction. Data collection, however, is not interrupted. After the call to lr_resume_transaction, the "get" functions return all data since the start of the transaction. Furthermore, the final results when the test is analyzed will reflect the total values, including the periods in between the transaction stop and resume. If lr_resume_transaction is not called, the "get" functions and the final results reflect only the duration from the transaction start to the lr_stop_transaction call. Thus, lr_stop_transaction and lr_resume_transaction can be used conditionally to collect information either about an entire transaction, or only the beginning. To accomplish this, call lr_resume_transaction only if your condition is met. Note: When data is collected this way, the data in analysis will reflect both the tests where the condition for lr_resume_transaction is met, and the tests where it is not. If the section you may wish to exclude ends before the end of the transaction, this technique does not apply. If you need to differentiate between occurrences where the lr_resume_transaction condition is met and those where it is not in the analysis data, this technique does not apply. transaction_name The name of an open transaction. Page 129 of 337

lr_stop_transaction_instance

Freezes reporting statistics for a transaction instance specified by its handle.

C Language HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_stop_transaction_instance


double lr_stop_transaction_instance (long parent_handle); Example See Also After a call to lr_stop_transaction_instance, statistics returned by the "get" Transaction Functions reflect only the data up to the call, until lr_resume_transaction_instance is called. The specified transaction instance must have been opened with lr_start_transaction_instance. Data collection, however, is not interrupted. After the call to lr_resume_transaction_instance, the "get" functions return all data since the start of the transaction instance. Furthermore, the final results when the test is analyzed will reflect the total values, including the periods in between the transaction stop and resume. If lr_resume_transaction_instance is not called, the final results reflect the statistics only until the call to lr_stop_transaction_instance.

The parent_handle is the value returned from the call to lr_start_transaction_instance that created the instance. lr_stop_transaction_instance and lr_resume_transaction_instance can be used to conditionally collect information about either the beginning, or all of the transaction. Note that you will not be able to differentiate in analysis between iterations when lr_stop_transaction_instance was called and iterations where it was not. For more flexible ways recording transaction times conditionally, see lr_start_sub_transaction, lr_set_transaction,and lr_start_timer. lr_stop_transaction_instance returns the duration of the instance in seconds. parent_handle A unique transaction handle. Page 130 of 337

lr_think_time

Pauses execution between commands in a script.

C Language HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_think_time


void lr_think_time (double thinkTime); Example See Also Java Language void lr.think_time ( double thinkTime ); Example See Also Java Syntax Visual Basic sub lr.think_time ( ByVal thinkTime as Double ) Example See Also Visual Basic Syntax lr_think_time allows you to pause test execution during a run. This is especially useful in simulating think time, the time a real pauses to think between actions. thinkTime The length of the pause, in seconds. Page 131 of 337

lr__data_point Records a -defined data sample.

C Language

HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr__data_point


int lr__data_point (const char *sample_name, double value); Example See Also Java Language int lr._data_point ( String sample_name, double value ); Example See Also Java Syntax Visual Basic function lr._data_point ( ByVal sample_name as String, ByVal value as double ) as Integer

Example See Also Visual Basic Syntax The lr__data_point function allows you to record your own data for analysis. Each time you want to record a point, use this function to record the sample name and the value. The time that the sample is recorded automatically. After the execution, you can use the Defined Data Points graph to analyze the results. Note: The following prefixes in sample_name are reserved: HTTP NON_HTTP RETRY mic_ stream_ mms_ A data point with any of these prefixes, for example "HTTP_BT", will not appear on the graph. However, the prefixes are case-sensitive, therefore "http_BT" is a valid sample_name. sample_name The data point name. value The value to record. Page 132 of 337

lr__data_point_ex Records a -defined data sample and enables logging option.

C Language

HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr__data_point_ex


int lr__data_point_ex ( const char *sample_name, double value, int log_flag); Example See Also The lr__data_point_ex function is the same as lr__data_point except for the additional parameter log_flag. Logging means writing data to a file. lr__data_point_ex enables you to write a data point to the V log file. When run in VuGen, the output is output.txt You may want to write the data point conditionally according to how important the data to be logged is. It can either be part of a Standard level when only the most important information is logged or an Extended level, when fuller logging is required. log_flag denotes the log level and correlates to the settings found in VuGen's Log runtime setting which specifies how the script handles logging to a file during execution. If DP_FLAGS_EXTENDED_LOG is ed to lr__data_point_instance_ex then the data point is logged only when the Extended runtime Log setting is currently activate. If log_flag is DP_FLAGS_STANDARD_LOG then it will be logged

only if the Standard setting is active. DP_FLAGS_NO_dicates that this data point is never written to a log file. sample_name A string indicating the name of the sample type. value The value to record. log_flag Determines whether the data point should be logged or not: DP_FLAGS_NO_LOG (1) DP_FLAGS_STANDARD_LOG (2) DP_FLAGS_EXTENDED_LOG (3) Page 133 of 337

lr__data_point_instance

Records a -defined data sample and correlates it to a transaction instance.

C Language HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr__data_point_instance


long lr__data_point_instance (const char *sample_name, double value, long transaction_handle); Example See Also The lr__data_point_instance function is similar to lr__data_point except for its transaction_handle parameter which allows you to associate a data point with a specific transaction instance. This function is intended for use with applications integrated with LoadRunner that use transaction instances. For details on transaction instances, see lr_start_transaction_instance. sample_name A string indicating the name of the sample type. value The value to record. parent_handle A transaction instance identifier with which to associate the data_point. Page 134 of 337

lr__data_point_instance_ex

Records a -defined data sample and correlates it to a transaction instance.

C Language HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr__data_point_instance_ex


long lr__data_point_instance_ex (const char* sample_name, double value, long transaction_handle, int log_flag); Example See Also The lr__data_point_instance_ex function is the same as lr__data_point_instance except for the additional parameter log_flag. Logging means writing data to a file. lr__data_point_instance_ex enables you to write a data point to the V log file. When run in VuGen, the output is output.txt

You may want to write the data point conditionally according to the importance of the data to be logged. It can either be part of a Standard level when only the most important information is logged or an Extended level, when fuller logging is required. log_flag denotes the log level and correlates to the settings found in VuGen's Log runtime setting which specifies how the script handles logging to a file during script execution. If DP_FLAGS_EXTENDED_LOG is ed to lr__data_point_instance_ex then the data point is logged only when the Extended runtime Log setting is activate. If log_flag is DP_FLAGS_STANDARD_LOG then it will be logged only if the Standard setting is active. DP_FLAGS_NO_dicates that this data point is never written to a log file. sample_name A string indicating the name of the sample type. value The value to record. parent_handle A transaction instance identifier with which to associate the data_point. log_flag Determines whether the data point should be logged or not: DP_FLAGS_NO_LOG (1) DP_FLAGS_STANDARD_LOG DP_FLAGS_EXTENDED_LOG (3) Page 135 of 337

lr.v_group Returns the name of the V group.


HP LoadRunner Online Function Reference > Utility Functions: VB, VB Script (lr.) > lr.v_group


Function lr.v_group ( ) as String Example See Also Visual Basic Syntax The lr.v_group function returns the name of the V group to which the V belongs. Page 136 of 337

lr.v_id

Returns the V ID.

Visual Basic and VB Script HP LoadRunner Online Function Reference > Utility Functions: VB, VB Script (lr.) > lr.v_id


Function lr.v_id ( ) as Long Example See Also Visual Basic Syntax The lr.v_id function returns the ID of the running V. Page 137 of 337

lr_v_status_message

Sends a message to the V status area.

C Language HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_v_status_message


int lr_v_status_message (const char *format); Example See Also Java Language int lr.v_status_message ( String message ); Example See Also Java Syntax Visual Basic Function lr.v_status_message ( message As String ) as Integer Example See Also Visual Basic Syntax The lr_v_status_message function sends a string to the Status area of the Controller. It also sends this string to the V log. When run from VuGen, the message is sent to output.txt. Page 138 of 337

lr_wasted_time Removes wasted time from all open transactions.

C Language

HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_wasted_time


void lr_wasted_time (long wasteTime); Example See Also Other languages See lr_set_transaction for an alternative. lr_wasted_time allows you to subtract the time wasted on incidental or secondary actions from all open transactions. For more information, see Wasted Time. wasteTime The time in milliseconds to be removed from all open transactions. Page 139 of 337

lr_whoami Returns information about the V executing the script.

C Language

HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > lr_whoami


void lr_whoami (int *v_id, char **sgroup, int *scid); Example See Also The lr_whoami function gets information about the V. Note that the sgroup parameter is a pointer to constant data and should only be read, not altered. Memory for the string is allocated automatically. You do not have to allocate explicitly in the script. If you do not want to retrieve one or more of the parameters, replace the parameter name with NULL. Not applicable for products that do not run individual Vs. v_id A pointer to an output argument to store the V ID number. sgroup A pointer to an output argument to store the name of the V Group. scid A pointer to an output argument to store the Scenario or Session step ID number.

Page 140 of 337

Message Formatting The first character of the format parameter is always a percent sign (%). The last character of format is a letter code that determines the type of formatting. One or more format modifiers can appear between the first and last character of the format argument (see below). The possible letter codes are as follows: Note that a separate formatting specification must be provided for each expression to be printed. For example, the statement: printf("My name is %s%s\n", "Arthur", "Dent"); prints the statement "My name is Arthur Dent" to standard output. Without the second "%s," the second expression (Dent) would have been ignored. The output generated by a particular formatting code can be modified. Three types of modifiers can appear between the percent sign (%) and the format code character: HP LoadRunner Online Function Reference > Utility Functions: C Language (LR) > Message Formatting

Character Argument Type Printed As d,i int decimal number o int unsigned octal number without a leading zero x,X int unsigned hexadecimal number without a leading 0x u int unsigned decimal number c int single character s char * print characters until either `\0' or the number of characters given in the precision is reached e,E double engineering notation (m.dddddd e+exponent). If precision is greater than fractional part, prints trailing zeros g,G double engineering notation without trailing zeros or trailing decimal point % none print the character `%' (justification) A hyphen (-) indicates that the printed output is to be left justified in its field. field width A number, by itself or to the left of a decimal point, indicates how many characters the field should be padded. When this number is preceded by a 0, the padding occurs with zeros to the left of the printed value. precision A number to the right of a decimal point indicates the maximum width of the printed string or how many digits are printed to the right of the output decimal point. Page 141 of 337

Message Log Run-Time Settings There are three main settings for run-time message logging: The following are "ORed" with the Extended Log message setting used to further refine the setting:

This setting can be "ORed" with all other message setting: HP LoadRunner Online Function Reference > Utility Functions: Socket ID Functions > Message Log Run-Time Settings

Log Level C Language Constants Object Oriented Constants Value Disabled LR_MSG_CLASS_ DISABLE_LOG lr.MSG_CLASS_ DISABLE_LOG 0 Brief LR_MSG_CLASS_ BRIEF_LOG lr.MSG_CLASS_ BRIEF_LOG 1 Extended Log LR_MSG_CLASS_ EXTENDED_LOG lr.MSG_CLASS_ EXTENDED_LOG 16 Log Level C Language Constants Object Oriented Constants Value Result Data LR_MSG_CLASS_ RESULT_DATA lr.MSG_CLASS_ RESULT_DATA 2 Parameter Substitution LR_MSG_CLASS_ PARAMETERS lr.MSG_CLASS_ PARAMETERS 4 Full Run-Time Trace LR_MSG_CLASS_ FULL_TRACE lr.MSG_CLASS_ FULL_TRACE 8 Log Level C Language Constants Object Oriented Constants Value Only on error. Which messages sent on error depends on other settings. LR_MSG_CLASS_ JIT_LOG_ON_ ERROR

lr.MSG_CLASS_ JIT_LOG_ON_ ERROR 512 Page 142 of 337

On-Off Constants These are the constants for activating and deactivating settings: HP LoadRunner Online Function Reference > Utility Functions: Socket ID Functions > On-Off Constants

Action C Language Constants Object Oriented Constants Value Turns the setting off. LR_SWITCH_ OFF lr.SWITCH_ OFF 0 Turns the setting on. LR_SWITCH_ ON lr.SWITCH_ ON 1 Uses the defaults from the script's cfg file. LR_SWITCH_ DEFAULT lr.SWITCH_ DEFAULT 2 Page 143 of 337

Parameterization Background For information about the arguments that are available for parameterization, click the Parameterization button in that function. HP LoadRunner Online Function Reference > Utility Functions: Socket ID Functions > Parameterization Background

Page 144 of 337

Raw Body Attribute Binary content can be sent in the request using the BodyBinary attribute (or the Body attribute when "Binary=1" is also specified). However, this method requires that content is converted into ASCII text using escape backslashes for non–printable text. To enable a more simple representation of the raw data, the Raw Body attribute instead enables you to a pointer to the binary content. The syntax for sending raw body content is a set of 4 arguments to web_custom_request(). They must appear in the following order: The correct order is: RAW_BODY_START,

a poi nt er t o t he dat a buf f er , ( i nt ) l engt h, RAW_BODY_END The syntax is illustrated in the following example: char *abc= . . . / * a poi nt er t o t he r aw dat a */ web_cust om_r equest ( "St epName" , "URL=ht t p: / / some. ur l " , "Met hod=POST" , RAW_BODY_START, " abc" , 3, RAW_BODY_END, LAST) ; The pointer data buffer must not be NULL, even when the length is 0. The Raw Body group cannot be used with the Binary parameter set ("Binary=1"). The data buffer cannot be parameterized. That is, any parameter reference (e.g., "{MyParam}") in the data buffer will not be substituted with the corresponding parameter value, and will be used as is. HP LoadRunner Online Function Reference > Utility Functions: Socket ID Functions > Raw Body Attribute

Page 145 of 337

Script Continuation Options Scripts exit with one of these options for continuation: Note: The behavior of LR_EXI T_MAI N_I TERATION_AND_CONTI NUE and LR_EXI T_I TERATION_AND_CONTI NUE changed between versions 8.0 and 8.1. These options can be configured by using these run options: -main_iteration_exit: Both LR_EXI T_MAI N_I TERATION_AND_CONTI NUE and LR_EXI T_I TERATION_AND_CONTI NUE behave like LR_EXI T_MAI N_I TERATION_AND_CONTI NUE. Thi s was t he behavi or bef or e ver si on 8. 1. -block_iteration_exit: Both LR_EXI T_MAI N_I TERATION_AND_CONTI NUE and LR_EXI T_I TERATION_AND_CONTI NUE behave like LR_EXI T_I TERATION_AND_CONTI NUE Add these flags in the [action_logic] section in mdrv.dat: ExtCmdLine=-main_iteration_exit or ExtCmdLine=-block_iteration_exit HP LoadRunner Online Function Reference > Utility Functions: Socket ID Functions > Script Continuation Options

C Constants Object Oriented Constants Behavior LR_EXIT_V lr.EXIT_V Exit without any condition, and go directly to end action LR_EXIT_ACTION_ AND_CONTINUE lr.EXIT_ACTION_ AND_CONTINUE Stop current action, and go to the next action. LR_EXIT_MAIN_ ITERATION_

AND_CONTINUE lr.EXIT_MAIN_ ITERATION_ AND_CONTINUE Stop current global script run iteration, and go to the next iteration. LR_EXIT_ITERATION_ AND_CONTINUE lr.EXIT_ITERATION_ AND_CONTINUE Stop current iteration, and go to the next iteration. If called from within a block iteration, only the block iteration will be exited, and not the global iteration. LR_EXIT_V_ AFTER_ITERATION lr.EXIT_V_ AFTER_ITERATION Run until the end of the current iteration and then exit. LR_EXIT_V_ AFTER_ACTION lr.EXIT_V_ AFTER_ACTION Run until the end of the current action and then exit. Page 146 of 337

Script Exit Status

Scripts exit with one of these statuses: HP LoadRunner Online Function Reference > Utility Functions: Socket ID Functions > Script Exit Status

C Constants Object Oriented Constants LR_ lr. LR_FAIL lr.FAIL LR_AUTO lr.AUTO Page 147 of 337

Transaction Status

Transactions complete with one of these statuses. The status can be read before completion, but may change at any time until the transaction completes. HP LoadRunner Online Function Reference > Utility Functions: Socket ID Functions > Transaction Status

C Constants Object Oriented Constants LR_ lr. LR_FAIL lr.FAIL LR_AUTO lr.AUTO LR_STOP lr.STOP

Visual Basic Syntax String Arguments Argument Lists Special Characters

Lr Functions 5i6l4r

Overview 3e4r5l

More details w3441

Related Documents 3m3m1z

Lr Functions 5i6l4r

Manual James_lr 660e - Lr 790e - Lr 810e 1t3a62

Lr Konstitucija.pdf 2iw5

102014_m_east_pp_tech_bro_final+(lr) 1t2g1z

Ev Functions Vs Epm Functions 496a5c

Pip Tegreen Lr 1u4n10

More Documents from "Kuchi Nagabhushanam" 4d134w

Lr Functions 5i6l4r

Ssr 2017-18 Post Gst Effect 5v1oh

Cement And Steel Rates For The Month Of Aug-2015 5j6ij

Tirumala Accommodation Allotment Procedure, Online Booking, Availability 2y2p6c

Mba Hr Fresher Resume Free 58412l
