TECHNICAL SERVICE BULLETIN 08/20/2008
BULLETIN NUMBER: D009/D011/D012/D013 – 020 APPLICABLE MODEL: GESTETNER – MP 4000B/MP 4000/MP 5000B/MP 5000 LANIER – LD040B/LD040/LD050B/LD050 RICOH – AFICIO MP 4000B/MP 4000/MP 5000B/MP 5000 SAVIN – 9040b/9040/9050b/9050
COPY QUALITY
SUBJECT: Poor Copy Quality – SC350
SYmPTOM:
The transfer belt release lever is 180 degrees out of position. This prevents the transfer belt from releasing from the drum during ID sensor patch development.
Incorrect Position
MECHANICAL
CAUSE:
The image quality of copies is dark and overtoned. An SC350 (ID Sensor pattern Test Error) may also occur.
Correct Position
NOTE: The Drive Gear has been removed for clarity in the above photographs.
SOLUTION: Reposition the transfer belt release. With the transfer belt facing upward, pull up on the transfer belt release lever and re-position the lever so the lever is positioned toward the electrical s, as shown in the “Correct Position” photograph above.
Copyright © 2008 RICOH Americas Corporation. All rights reserved.
tpc@ri coh-usa.com
Page 1 of 1
BULLETIN NUMBER: D009/D011/D012/D013 – 020 APPLICABLE MODEL: GESTETNER – MP 4000B/MP 4000/MP 5000B/MP 5000 LANIER – LD040B/LD040/LD050B/LD050 RICOH – AFICIO MP 4000B/MP 4000/MP 5000B/MP 5000 SAVIN – 9040b/9040/9050b/9050
COPY QUALITY
SUBJECT: Poor Copy Quality – SC350
SYmPTOM:
The transfer belt release lever is 180 degrees out of position. This prevents the transfer belt from releasing from the drum during ID sensor patch development.
Incorrect Position
MECHANICAL
CAUSE:
The image quality of copies is dark and overtoned. An SC350 (ID Sensor pattern Test Error) may also occur.
Correct Position
NOTE: The Drive Gear has been removed for clarity in the above photographs.
SOLUTION: Reposition the transfer belt release. With the transfer belt facing upward, pull up on the transfer belt release lever and re-position the lever so the lever is positioned toward the electrical s, as shown in the “Correct Position” photograph above.
Copyright © 2008 RICOH Americas Corporation. All rights reserved.
tpc@ri coh-usa.com
Page 1 of 1
