MILITARY WORKBOOK
CONTENTS ASSAULT PACKS
4-7
BLACKJACK PACKS
20 - 23
NICE FRAME
8 - 11
JUMP PACKS
24 - 27
OVERLOAD
12 - 13
O.E.M.
28 - 29
MEDICAL
14 - 17
ACCESSORIES
30 - 33
COMM 3
18 - 19
PRODUCT BY VOLUME
34 - 35
TECHNOLOGY FRAMING
NF
IF
FS
MLF
NICE Frame
A rigid yet dynamic system that moves with you. The NICE frame consists of three vertical and three horizontal carbon fiber stays and a full fabric between the stays that absorbs shock and increases the flexibility of the frame. This patented construction allows the frame to flex with your body, resulting in top-down load transfer to comfortably carry heavy loads. Our patented Futura Yoke system enables you to macro adjusts the torso length and is a crucial piece of the structure of the pack.
COLORS All packs are built from custom spec’d 500D CORDURA® with Teflon® and PU coatings for maximum durability, UV, and weather protection. All packs are available in MULTICAM and COYOTE unless otherwise noted.
COYOTE
MULTICAM
Internal Frame
The Internal Frame consists of composite stays, and an HDPE (high-density polyethylene) sheet that provides rigidity yet is flexible. Our patented Futura Yoke system enables you to macro adjusts the torso length and is a crucial piece of the structure of the pack.
Frame Sheet
An HDPE (high-density polyethylene) sheet that provides rigidity yet is flexible. Our patented Futura Yoke system enables you to macro adjusts the torso length and is a crucial piece of the structure of the pack.
Military Light Frame
The MLF consists of four vertical and three horizontal carbon fiber stays and a reduced fabric using stiffer, more structured CORDURA® Dyneema laminate at the points of connection resulting in shock absorption and increase in the flexibility of the frame. Our patented Futura Yoke system enables you to macro adjusts the torso length and is a crucial piece of the structure of the pack.
BLACK
Only available for ASAP, RATS
SYSTEMS
BVS IR
Bolstered Ventilation and Stability The BVS system increases stability of the pack over armor.
IR-Compliant Zippers
Water repellent YKK® zippers
Futura Yoke System
Our patented Futura Yoke system enables you to macro adjusts the torso length and is a crucial piece of the structure of the pack.
Most MYSTERY RANCH products are covered by US and Foreign Patents, and other Patents Pending. US Patents include: US 6,626,342 B1; US 7,673,777 B2; US 8,381,956 B2; US 8,561,866 B2; US 8,950,644 B2; US 8,348,114 B2; US 8,579,171 B2; US 9,173,473 B2; US 9,271,559 B2; US 8,162,194 B2 ; US 8,955,792 B2
MYSTERY RANCH builds the best load-bearing equipment in the world. We build for a different kind of customer, for folks who inspire us, and men and women with a job to do. We build with the best materials available and the most durable construction methods that exist so that you know our gear will your mission whether it’s on the front line, the fire line, the cleanest line, or the steepest line. We don’t cut corners. Every pack that we build is designed with you in mind – from function and fit to design and comfort. We want to be sure that you can get it done, whatever your mission may be.
MYSTERY RANCH
ASSAULT PACKS This line is designed to be the last word in assault packs. Engineered for quick access, comfort, and loaded with features, these packs are built for short or extended missions.
Photo: Tac Gas
ASSAULT PACKS
3 DAY ASSAULT
ASAP
Weight:
2 kg (4.4 lbs)
Weight:
1.4 kg (3 lbs)
Vol:
33L (2038 cu-in)
Vol:
20L (1208 cu-in)
Size:
S M/L XL
Size:
S M/L XL
Tech:
FS
Tech:
FS
IR
BVS
IR
Our 3 DAY ASSAULT PACK has room for sustainment gear, ammo, IFAKs and tactical radios. For versatility and mobility, there’s nothing better.
For the shortest of missions, the ASAP is our smallest assault pack. Its 3-ZIP design allows quick access to the bag’s interior and can easily carry a radio.
++
++
++ ++ ++ ++
6
BVS
Two, zippered pockets on lid PALS webbing on interior and exterior accommodates MOLLE accessories Internal sleeves and ports integrate up to three hydration reservoirs Urethane coated zipper ports at top of body opens from either side for antennae, cables, and/or hydration Waist belt stows away when not in use
++ ++ ++
Single, zippered lid pocket PALS webbing on interior and exterior accommodates MOLLE accessories Two internal sleeves with compression straps each accommodate water bladders up to 3L each Urethane coated zipper ports at top of body opens from either side for antennae, cables, and/or hydration
++
Removable 1” web waist belt
++
ASAP available in Coyote, MultiCam, Black, and Foliage
KOMODO DRAGON
SATL
Weight:
2.1 kg (4.7 lbs)
Weight:
3.1 kg (6.8 lbs)
Vol:
38L (2288 cu-in)
Vol:
56L (3500 cu-in)
Size:
S M/L XL
Size:
Tech:
FS
BVS
IR
S M L XL XXL
Tech:
IF
BVS
IR
Slightly larger than the 3 Day Assault, the KOMODO DRAGON is our mid-size assault pack. The interior has a MOLLE for radio mounts plus detail pockets and hydration sleeves.
The standard-issue assault pack for SOCOM for nearly a decade. This updated version features removable BVS, and a comfortable redirect waist belt for effective weight transfer, even when wearing the pack over body armor.
++
++
++ ++ ++ ++
Two, zippered pockets on lid PALS webbing on interior and exterior accommodates MOLLE accessories Internal sleeves and ports integrate up to three hydration reservoirs Urethane coated zipper ports at top of body opens from either side for antennae, cables, and/or hydration Waist belt stows away when not in use
++
Top-loading design and center-zip main access PALS webbing on exterior accommodates MOLLE accessories
++
Vertical back long pockets
++
Removable lid
++ ++ ++
Internal harness compartment secures radio to the body to minimize shifting Urethane coated zipper ports at top of body opens from either side for antennae, cables, and/or hydration Removable Redirect waist belt
Assault Packs - 7
NICE FRAME The NICE frame is the core of our solution for serious load-hauling and stability under load. Its durability, stability and custom fit make it uniquely suited for Military use. The Futura Yoke easily adjusts to the length of the body’s area allowing the proper amount of stand off between the back and bag, resulting in comfort and effective load transfer. With the addition of the Bolstered Ventilation and Stability (BVS) system, it securely carries loads over body armor.
8
Photo: Tac Gas Nice Frame -9
NICE FRAME
LOAD SLING
CREWCAB
Weight:
2.5 kg (5.5 lbs)
Weight:
3.4 kg (7.4 lbs)
Vol:
N/A
Vol:
26L (1592 cu-in)
Size:
S M L XL XXL
Tech:
NF
BVS
Size:
S M L XL XXL
Tech:
NF
IR
The LOAD SLING is the most basic method to lash objects to the NICE Frame. This simple design has two adjustable straps to the top and each side. Its wide range of adjustability will conform to any load you can carry.
The CREWCAB is our variable-capacity, do-anything military pack. It can be compressed into a low-profile, 1592 cu-in pack or expanded to carry EOD gear, Pelican cases, robots, Load Cells, ammo cans, even CASEVAC in a pinch.
++
PALS webbing on front accommodates MOLLE accessories
++
++
Compatable with Load Cells (pg 32)
++ ++ ++ ++
10
BVS
loading pocket for full access to internal contents Flat front pocket and internal mesh detail pocket for essentials Two, tubular pockets Dedicated hydration pocket with toggle loop for any type of bladder Zippered back pocket accommodates up to three 100 oz water bladders
MOUNTAIN RUCK
6500
Weight:
3.5 kg (7.8 lbs)
Weight:
4.5 kg (9.9 lbs)
Vol:
86L (5248 cu-in)
Vol:
106L (6500 cu-in)
Size:
S M L XL XXL
Tech:
NF
BVS
IR
Size:
S M L XL XXL
Tech:
NF
BVS
IR
The MOUNTAIN RUCK is our interpretation of the classic military ruck design. This pack combines the desirable shape of the original with the superior fit, quality and function of a MYSTERY RANCH product.
For extended RECCE missions or bulkier items, the 6500 is our classic top loading tactical expedition pack. It features our Speedzip™ sleeping bag compartment on the bottom and a removable Day Pack lid.
++
New top-zip pockets replace the previous rip-zip front pockets
++
PALS webbing accommodates MOLLE accessories
++
PALS webbing accommodates MOLLE accessories
++
Speedzip™ compartment for quick access to sleeping bag
++
Two internal hydration pockets
++
Zippered radio port allows easy access to controls
++
Compatible with Daypack Lid
++
Removable Daypack Lid
++
Vertical back long pockets
++
Side zipper access
++
Redirect waist belt
Nice Frame - 11
Photo: Tac Gas
OVERLOAD The OVERLOAD features quick-access, 3-ZIP design and the ability to secure sniper and crew-served weapons or Pelican cases between the pack and frame without decreasing capacity for mission essentials or sustainment gear.
OVERLOAD Weight:
3.5 kg (7.8 lbs)
Vol:
49L (2990 cu-in)
Size:
S M L XL XXL
Tech:
NF
IR
++
Two, zippered pockets on lid
++
Two internal sleeves each accommodate bladders up to 3L
++ ++ ++
Overload with Pelican case
BVS
PALS webbing on interior and exterior accommodates MOLLE accessories Rifle Sock and weapon compression straps Urethane coated zipper ports at top of body opens from either side for antennae, cables, and/or hydration
Weapon compression straps
Assault Packs - 13
MEDICAL Our medical line is designed for quick access to the most important items and equipment. With removable pockets and color coded handles, these packs are designed for ultimate organization.
MEDICAL
RATS
NICE RATS
Weight:
3 kg (6.6 lbs)
Weight:
4.4 kg (9.8 lbs)
Vol:
23L (1400 cu-in)
Vol:
23L (1400 cu-in)
Size:
S M/L XL
Size:
S M L XL XXL
Tech:
FS
Tech:
NF
BVS
IR
BVS
IR
The Rapid Access Trauma System (RATS) pack is our front line medic bag. Designed for quick, one-handed access to organized medical supplies, removable internal pockets with clear vinyl windows and two IV bag pockets. Attach the RATS to a NICE Frame for additional capacity to carry litters or combi tools.
The NICE RATS pack is our front line medic bag that comes completed with a NICE FRAME which adds additional capacity for carrying litters or combi tools. Designed for quick, one-handed access to organized medical supplies, removable internal pockets with clear vinyl windows and two IV bag pockets.
++
++
Back stores a closed-cell foam pad to insulate patients from the ground
Back stores a closed-cell foam pad to insulate patients from the ground
++
PALS webbing accommodates MOLLE accessories
++
PALS webbing accommodates MOLLE accessories
++
Redundant zipper retainers
++
Redundant zipper retainers
++
Internal trash pocket to keep track of items used
++
Internal trash pocket to keep track of items used
++
Two internal sleeves for splints and long items
++
Two internal sleeves for splints and long items
++
Two 150 cu-in front pockets for blowout kits
++
Two 150 cu-in front pockets for blowout kits
++
Top lid features internal bandage and gauze loops
++
Top lid features internal bandage and gauze loops
++
300 cu-in zippered bottom pocket
++
300 cu-in zippered bottom pocket
++
Available in MultiCam, Coyote, and Black
RFAK The RFAK is a compact individual first aid kit that attaches via MOLLE to your assault vest or body armor. It has a unique, detachable inner that can be adjusted to carry a multitude of items.
16
ROUS
MOLE
Weight:
5 kg (11 lbs)
Weight:
2.2 kg (4.9 lbs)
Vol:
56L (3500 cu-in)
Vol:
22L (1342 cu-in)
Size:
OS
Tech:
FS
Size:
S M L XL XXL
Tech:
NF
BVS
IR
IR
The ROUS is our largest medic bag. The front has multiple storage options and the main compartment contains six removable pockets and two IV bag pockets, all with clear s for fast identification.
The MOLE is our smallest med pack. Its comfortable shoulder straps are removable for easy body armor attachment vai the body armor mount system. It features a Stick-it for bulky items or a helmet.
++
PALS webbing accommodates MOLLE accessories
++
PALS webbing accommodates MOLLE accessories
++
Internal trash pocket for easy inventory resupply
++
Body armor mount system
++
Two internal sleeves for splints and long items
++
Six removable pockets
++
Top lid features internal bandage and gauze loops
++
Two internal sleeves for splints and long items
++
Internal top handle for hanging opened pack
++
Top lid features internal bandage and gauze loops
++
Internal top handle for hanging opened pack
++
Removable Stick-it
VLAK The VLAK is designed to address medical resupply storage in vehicles. It features a detachable strap for carrying cross-body or can be slung over a headrest or attached via MOLLE. It can also be attached to an assault vest and body armor.
Medical - 17
COMMS This modular communication pack system features components that can be carried together on a NICE Frame or on their own. The COMM 3 easily carries a variety of communications gear and accessories.
COMM 3
Radio Bag
Weight:
3.4 kg (7.5 lbs)
Vol:
Comms
Size:
S M L XL XXL
Tech:
NF
BVS
IR
++
Modular pack system
++
PALS webbing accommodates MOLLE accessories
++
Clear view port over keypad and display
++
Fits PRC117F, G, or similar-sized radio
++
Compatible with Daypack Lid and Hitchhiker
++
Includes: NICE COMM 3 Radio Bag & NICE COMM 3 Battery Pocket
Battery Pocket
Comms - 19
BLACKJACK The BLACKJACK Series is designed after the new standard-issue packs for USSOCOM, the SPEAR ASSAULT. They feature lightweight, full carbon frames, Dyneema-CORDURA® laminate, IR-compliant zippers, and lightweight bolsters.
Photo: Tac Gas
BLACKJACK
BLACKJACK 50
BLACKJACK 80
Weight:
3.3 kg (7.2 lbs)
Weight:
3.8 kg (8.3 lbs)
Vol:
50L (3051 cu-in)
Vol:
80L (4880 cu-in)
Size:
S M L XL XXL
Size:
S M L XL XXL
Tech:
MLF
Tech:
MLF
IR
BVS
IR
The BLACKJACK 50 is a 50 L, top-loading pack with two external pockets that each have internal, mesh pockets. The pack has full-length zippers on each side for fast access to the main compartment.
The BLACKJACK 80 is an 80 L pack with four external pockets featuring top zips. It has full-length zippers on each side for fast access to the main compartment.
++
Quick-release Futura Yoke
++
Quick-release Futura Yoke
++
PALS webbing accommodates MOLLE accessories
++
PALS webbing accommodates MOLLE accessories
++
22
BVS
Urethane coated zipper ports at top of body opens from either side for antennae, cables, and/or hydration
++
++
Top-loading access has a spindrift collar
++
++
1” compression webbing and buckles
++
++
Full-length zippers on each side
Urethane coated zipper ports at top of body opens from either side for antennae, cables, and/or hydration Top-loading access has a spindrift collar Removable lid pocket with 2” straps that enable it to be used as a bolt/E&E pack
++
Full-length zippers on each side
++
1” compression webbing and buckles
BLACKJACK 100 Weight:
4.2 kg (9.2 lbs)
Vol:
100L (6102 cu-in)
Size:
S M L XL XXL
Tech:
MLF
BVS
IR
The BLACKJACK 100 is a 100 L pack including a 23 L Speedzip™ compartment at the bottom for easy access to your sleeping bag. It features four external pockets with top-open zippers. To help the taller pack, the BLACKJACK 100 uses a unique frame extension to stabilize larger loads.
++
Quick-release Futura Yoke
++
PALS webbing accommodates MOLLE accessories
++ ++ ++
Urethane coated zipper ports at top of body opens from either side for antennae, cables, and/or hydration Top-loading access has a spindrift collar Removable lid pocket with 2” straps that enable it to be used as a bolt/E&E pack
++
Full-length zippers on each side
++
1” compression webbing and buckles
++
Speedzip™ compartment
Blackjacks - 23
JUMP PACKS Designed for the sharpest tip of the spear, MYSTERY RANCH Jump Packs are genuinely mission focused. Features Jump-rated Type 7 webbing on all jump connections, Tex 138 thread on all Jump web for reinforcement and higher break strength, Dual-point release system to attach to jump harness, Reinforced tie-in loops, Lowering line attachment points, and D-rings for securing the toggle zippers. Every construction method and detail focuses on quick rigging, safe flight, and fast movement off the X.
Photo: Tac Gas
JUMP PACKS
JUMP RATS
JUMP KOMODO
DATL
Weight:
3.2 kg (7 lbs)
Weight:
2.3 kg (5.1 lbs)
Weight:
2 kg (4.5 lbs)
Vol:
23L (1400 cu-in)
Vol:
38L (2288 cu-in)
Vol:
37L (2200 cu-in)
S M/L XL
Size:
S M/L XL
BVS
Tech:
Size: Tech:
++ ++ ++ ++ ++ ++ ++ ++ ++ 26
S M/L XL
Size:
BVS
Tech:
FS
IR
Back stores a closed-cell foam pad to insulate patients from the ground PALS webbing accommodates MOLLE accessories Redundant zipper retainers Internal trash pocket to keep track of items used Two internal sleeves for splints and long items Two 150 cu-in front pockets for blowout kits Top lid features internal bandage and gauze loops 300 cu-in zippered bottom pocket NICE Frame compatible - not included
++ ++ ++ ++
FS
IR
IF
BVS
IR
Two, zippered pockets on lid
++
Vertical back long pockets
PALS webbing on interior and exterior accommodates MOLLE accessories
++
Removable Daypack Lid
Internal sleeves and ports integrate up to three hydration reservoirs Urethane coated zipper ports at top of body opens from either side for antennae, cables, and/or hydration
++ ++
Internal MOLLE for radios or other accessories Redirect waist belt
JUMP OVERLOAD
JUMP MOUNTAIN RUCK
Weight:
3.8 kg (8.4 lbs)
Weight:
3.7 kg (8.2 lbs)
Vol:
49L (2990 cu-in)
Vol:
86L (5248 cu-in)
Size:
S M/L XL
Size:
S M/L XL
Tech:
NF
BVS
Tech:
NF
++ ++ ++
++ ++
IR
Two internal sleeves each accommodate bladders up to 3L MOLLE on exterior, belt, and interior body for attaching accessories Urethane coated zipper ports at top of body opens from either side for antennae, cables, and/or hydration
++ ++
BVS
IR
New top-zip pockets replace the previous rip-zip front pockets PALS webbing accommodates MOLLE accessories
++
Two internal hydration pockets
++
Compatible with Daypack Lid
Two zippered pockets on lid for keeping small items accessible Side water bottle pockets
Jump Packs - 27
O.E.M. One of the things we are thanksful for at The Ranch is the interesting problems our customers bring to us. That includes packaging weapons, comm gear, optics, sensors, connectors and cabling. We have designed built-in systems to carry jammers, receivers and robots. If it needs to be carried by a human - let’s talk.
O.E.M - 29
ACCESSORIES MYSTERY CINCH Weight:
0.1 kg (0.2 lb)
Color: A modular cinch strap designed to reroute the shoulder pads of a pack down the front of your body armor to ease chafe, bleeding and nerve damage by keeping the pressure off your armpits. You can quickly drop your pack with a single, quick release buckle. PATENT: US 9,173,473 B2
HITCHHIKER 20
REMOVABLE STICK-IT
Vol:
24L (1464 cu-in)
Vol:
Expandable
Weight:
1 kg (2 lbs)
Weight:
0.3 kg (0.6 lb)
Tech:
IR
The HITCHHIKER 20 is attachable storage featuring our tri-zip opening. Its designed to work with the NICE RATS, ROUS and COMM 3 packs.
The REMOVABLE STICK-IT adds capacity expansion and easy access to any of our packs with bottom daisy chains. It has contouring pleats to accommodate larger volume items such as a helmet.
ACCESSORIES - 31
ACCESSORIES
LOAD CELL
RIP ZIP
These cube-shaped stuff sacks help organize your gear. Available in two sizes, they fit perfectly in the Load Sling and the Crewcab.
These tall pockets mount to any MOLLE and feature quick access to contents with its quick-rip design.
Vol:
S
2L (122 cu-in)
L
4L (244 cu-in)
Vol:
S
2L (122 cu-in)
L
4L (244 cu-in)
NVG POCKET
SCOUT POUCH
152 POUCH
This attachable pocket is designed to secure and protect the AN/PVS-14 monocular. The foam-lined pouch also includes a battery sleeve.
Standard-issue for USMC Scout Snipers, the SCOUT POUCH keeps a Kestrel unit secure and mounts to any MOLLE .
The 152 POUCH is a simple, no-frills secure storage for AN/PRC 152 radios. Quick, one-handed release gains the operator access to keypad and screen.
32
SOCOM BOTTLE POCKET This pocket mounts anywhere with MOLLE and accommodates most bottles or sundries. The simplistic elastic closure secures its contents.
FLASH BANG
TRIPLE BANG
KAB POUCH
The FLASH BANG is the SOCOM-issue pouch for holding stun grenades. Velcro flap closure tucks in behind the grenade for quick access.
The TRIPLE BANG holds three stun grenades in a secure MOLLE attach pouch with a Velcro lid flap that tucks in behind the grenade for quick access.
Protect your Kestrel 5700 with the KAB POUCH. This simple design attaches via MOLLE and keeps your applied ballistics device secure.
ACCESSORIES - 33
PRODUCT LINE BY VOLUME
ASAP
RATS
CREWCAB
20L | pg 6
23L | pg 16
26L | pg 10
3 DAY ASSAULT
DATL 37L | pg 26
33L | pg 6
ROUS
SATL
56L | pg 17
56L | pg 7
MOUNTAIN RUCK
BACKJACK 80 80L | pg 22
86L | pg 10
BERRY COMPLIANT All products in this catalog are in compliance with the Berry Amendment (10 U.S.C. 2533a).
Wood Carving: Team Room Designs llc
KOMODO DRAGON
OVERLOAD
BLACKJACK 50
49L | pg 13
50L | pg 22
38L | pg 7
OUTLIERS
BACKJACK 100
6500
100L | pg 23
106L | pg 11
COMM 3
LOAD SLING
N/A | pg 19
N/A | pg 10
MYSTERY RANCH BACKPACKS
1750 EVERGREEN DRIVE BOZEMAN MT 59715 833-548-1999 WWW.MYSTERYRANCH.COM CAGE CODE: 3HXV1 COPYRIGHT © MYSTERY RANCH LTD 2019
The appearance of U.S. Department of Defense (DoD) visual information does not imply or constitute DoD endorsement.
MILITARY WORKBOOK
CONTENTS ASSAULT PACKS
4-7
BLACKJACK PACKS
20 - 23
NICE FRAME
8 - 11
JUMP PACKS
24 - 27
OVERLOAD
12 - 13
O.E.M.
28 - 29
MEDICAL
14 - 17
ACCESSORIES
30 - 33
COMM 3
18 - 19
PRODUCT BY VOLUME
34 - 35
TECHNOLOGY FRAMING
NF
IF
FS
MLF
NICE Frame
A rigid yet dynamic system that moves with you. The NICE frame consists of three vertical and three horizontal carbon fiber stays and a full fabric between the stays that absorbs shock and increases the flexibility of the frame. This patented construction allows the frame to flex with your body, resulting in top-down load transfer to comfortably carry heavy loads. Our patented Futura Yoke system enables you to macro adjusts the torso length and is a crucial piece of the structure of the pack.
COLORS All packs are built from custom spec’d 500D CORDURA® with Teflon® and PU coatings for maximum durability, UV, and weather protection. All packs are available in MULTICAM and COYOTE unless otherwise noted.
COYOTE
MULTICAM
Internal Frame
The Internal Frame consists of composite stays, and an HDPE (high-density polyethylene) sheet that provides rigidity yet is flexible. Our patented Futura Yoke system enables you to macro adjusts the torso length and is a crucial piece of the structure of the pack.
Frame Sheet
An HDPE (high-density polyethylene) sheet that provides rigidity yet is flexible. Our patented Futura Yoke system enables you to macro adjusts the torso length and is a crucial piece of the structure of the pack.
Military Light Frame
The MLF consists of four vertical and three horizontal carbon fiber stays and a reduced fabric using stiffer, more structured CORDURA® Dyneema laminate at the points of connection resulting in shock absorption and increase in the flexibility of the frame. Our patented Futura Yoke system enables you to macro adjusts the torso length and is a crucial piece of the structure of the pack.
BLACK
Only available for ASAP, RATS
SYSTEMS
BVS IR
Bolstered Ventilation and Stability The BVS system increases stability of the pack over armor.
IR-Compliant Zippers
Water repellent YKK® zippers
Futura Yoke System
Our patented Futura Yoke system enables you to macro adjusts the torso length and is a crucial piece of the structure of the pack.
Most MYSTERY RANCH products are covered by US and Foreign Patents, and other Patents Pending. US Patents include: US 6,626,342 B1; US 7,673,777 B2; US 8,381,956 B2; US 8,561,866 B2; US 8,950,644 B2; US 8,348,114 B2; US 8,579,171 B2; US 9,173,473 B2; US 9,271,559 B2; US 8,162,194 B2 ; US 8,955,792 B2
MYSTERY RANCH builds the best load-bearing equipment in the world. We build for a different kind of customer, for folks who inspire us, and men and women with a job to do. We build with the best materials available and the most durable construction methods that exist so that you know our gear will your mission whether it’s on the front line, the fire line, the cleanest line, or the steepest line. We don’t cut corners. Every pack that we build is designed with you in mind – from function and fit to design and comfort. We want to be sure that you can get it done, whatever your mission may be.
MYSTERY RANCH
ASSAULT PACKS This line is designed to be the last word in assault packs. Engineered for quick access, comfort, and loaded with features, these packs are built for short or extended missions.
Photo: Tac Gas
ASSAULT PACKS
3 DAY ASSAULT
ASAP
Weight:
2 kg (4.4 lbs)
Weight:
1.4 kg (3 lbs)
Vol:
33L (2038 cu-in)
Vol:
20L (1208 cu-in)
Size:
S M/L XL
Size:
S M/L XL
Tech:
FS
Tech:
FS
IR
BVS
IR
Our 3 DAY ASSAULT PACK has room for sustainment gear, ammo, IFAKs and tactical radios. For versatility and mobility, there’s nothing better.
For the shortest of missions, the ASAP is our smallest assault pack. Its 3-ZIP design allows quick access to the bag’s interior and can easily carry a radio.
++
++
++ ++ ++ ++
6
BVS
Two, zippered pockets on lid PALS webbing on interior and exterior accommodates MOLLE accessories Internal sleeves and ports integrate up to three hydration reservoirs Urethane coated zipper ports at top of body opens from either side for antennae, cables, and/or hydration Waist belt stows away when not in use
++ ++ ++
Single, zippered lid pocket PALS webbing on interior and exterior accommodates MOLLE accessories Two internal sleeves with compression straps each accommodate water bladders up to 3L each Urethane coated zipper ports at top of body opens from either side for antennae, cables, and/or hydration
++
Removable 1” web waist belt
++
ASAP available in Coyote, MultiCam, Black, and Foliage
KOMODO DRAGON
SATL
Weight:
2.1 kg (4.7 lbs)
Weight:
3.1 kg (6.8 lbs)
Vol:
38L (2288 cu-in)
Vol:
56L (3500 cu-in)
Size:
S M/L XL
Size:
Tech:
FS
BVS
IR
S M L XL XXL
Tech:
IF
BVS
IR
Slightly larger than the 3 Day Assault, the KOMODO DRAGON is our mid-size assault pack. The interior has a MOLLE for radio mounts plus detail pockets and hydration sleeves.
The standard-issue assault pack for SOCOM for nearly a decade. This updated version features removable BVS, and a comfortable redirect waist belt for effective weight transfer, even when wearing the pack over body armor.
++
++
++ ++ ++ ++
Two, zippered pockets on lid PALS webbing on interior and exterior accommodates MOLLE accessories Internal sleeves and ports integrate up to three hydration reservoirs Urethane coated zipper ports at top of body opens from either side for antennae, cables, and/or hydration Waist belt stows away when not in use
++
Top-loading design and center-zip main access PALS webbing on exterior accommodates MOLLE accessories
++
Vertical back long pockets
++
Removable lid
++ ++ ++
Internal harness compartment secures radio to the body to minimize shifting Urethane coated zipper ports at top of body opens from either side for antennae, cables, and/or hydration Removable Redirect waist belt
Assault Packs - 7
NICE FRAME The NICE frame is the core of our solution for serious load-hauling and stability under load. Its durability, stability and custom fit make it uniquely suited for Military use. The Futura Yoke easily adjusts to the length of the body’s area allowing the proper amount of stand off between the back and bag, resulting in comfort and effective load transfer. With the addition of the Bolstered Ventilation and Stability (BVS) system, it securely carries loads over body armor.
8
Photo: Tac Gas Nice Frame -9
NICE FRAME
LOAD SLING
CREWCAB
Weight:
2.5 kg (5.5 lbs)
Weight:
3.4 kg (7.4 lbs)
Vol:
N/A
Vol:
26L (1592 cu-in)
Size:
S M L XL XXL
Tech:
NF
BVS
Size:
S M L XL XXL
Tech:
NF
IR
The LOAD SLING is the most basic method to lash objects to the NICE Frame. This simple design has two adjustable straps to the top and each side. Its wide range of adjustability will conform to any load you can carry.
The CREWCAB is our variable-capacity, do-anything military pack. It can be compressed into a low-profile, 1592 cu-in pack or expanded to carry EOD gear, Pelican cases, robots, Load Cells, ammo cans, even CASEVAC in a pinch.
++
PALS webbing on front accommodates MOLLE accessories
++
++
Compatable with Load Cells (pg 32)
++ ++ ++ ++
10
BVS
loading pocket for full access to internal contents Flat front pocket and internal mesh detail pocket for essentials Two, tubular pockets Dedicated hydration pocket with toggle loop for any type of bladder Zippered back pocket accommodates up to three 100 oz water bladders
MOUNTAIN RUCK
6500
Weight:
3.5 kg (7.8 lbs)
Weight:
4.5 kg (9.9 lbs)
Vol:
86L (5248 cu-in)
Vol:
106L (6500 cu-in)
Size:
S M L XL XXL
Tech:
NF
BVS
IR
Size:
S M L XL XXL
Tech:
NF
BVS
IR
The MOUNTAIN RUCK is our interpretation of the classic military ruck design. This pack combines the desirable shape of the original with the superior fit, quality and function of a MYSTERY RANCH product.
For extended RECCE missions or bulkier items, the 6500 is our classic top loading tactical expedition pack. It features our Speedzip™ sleeping bag compartment on the bottom and a removable Day Pack lid.
++
New top-zip pockets replace the previous rip-zip front pockets
++
PALS webbing accommodates MOLLE accessories
++
PALS webbing accommodates MOLLE accessories
++
Speedzip™ compartment for quick access to sleeping bag
++
Two internal hydration pockets
++
Zippered radio port allows easy access to controls
++
Compatible with Daypack Lid
++
Removable Daypack Lid
++
Vertical back long pockets
++
Side zipper access
++
Redirect waist belt
Nice Frame - 11
Photo: Tac Gas
OVERLOAD The OVERLOAD features quick-access, 3-ZIP design and the ability to secure sniper and crew-served weapons or Pelican cases between the pack and frame without decreasing capacity for mission essentials or sustainment gear.
OVERLOAD Weight:
3.5 kg (7.8 lbs)
Vol:
49L (2990 cu-in)
Size:
S M L XL XXL
Tech:
NF
IR
++
Two, zippered pockets on lid
++
Two internal sleeves each accommodate bladders up to 3L
++ ++ ++
Overload with Pelican case
BVS
PALS webbing on interior and exterior accommodates MOLLE accessories Rifle Sock and weapon compression straps Urethane coated zipper ports at top of body opens from either side for antennae, cables, and/or hydration
Weapon compression straps
Assault Packs - 13
MEDICAL Our medical line is designed for quick access to the most important items and equipment. With removable pockets and color coded handles, these packs are designed for ultimate organization.
MEDICAL
RATS
NICE RATS
Weight:
3 kg (6.6 lbs)
Weight:
4.4 kg (9.8 lbs)
Vol:
23L (1400 cu-in)
Vol:
23L (1400 cu-in)
Size:
S M/L XL
Size:
S M L XL XXL
Tech:
FS
Tech:
NF
BVS
IR
BVS
IR
The Rapid Access Trauma System (RATS) pack is our front line medic bag. Designed for quick, one-handed access to organized medical supplies, removable internal pockets with clear vinyl windows and two IV bag pockets. Attach the RATS to a NICE Frame for additional capacity to carry litters or combi tools.
The NICE RATS pack is our front line medic bag that comes completed with a NICE FRAME which adds additional capacity for carrying litters or combi tools. Designed for quick, one-handed access to organized medical supplies, removable internal pockets with clear vinyl windows and two IV bag pockets.
++
++
Back stores a closed-cell foam pad to insulate patients from the ground
Back stores a closed-cell foam pad to insulate patients from the ground
++
PALS webbing accommodates MOLLE accessories
++
PALS webbing accommodates MOLLE accessories
++
Redundant zipper retainers
++
Redundant zipper retainers
++
Internal trash pocket to keep track of items used
++
Internal trash pocket to keep track of items used
++
Two internal sleeves for splints and long items
++
Two internal sleeves for splints and long items
++
Two 150 cu-in front pockets for blowout kits
++
Two 150 cu-in front pockets for blowout kits
++
Top lid features internal bandage and gauze loops
++
Top lid features internal bandage and gauze loops
++
300 cu-in zippered bottom pocket
++
300 cu-in zippered bottom pocket
++
Available in MultiCam, Coyote, and Black
RFAK The RFAK is a compact individual first aid kit that attaches via MOLLE to your assault vest or body armor. It has a unique, detachable inner that can be adjusted to carry a multitude of items.
16
ROUS
MOLE
Weight:
5 kg (11 lbs)
Weight:
2.2 kg (4.9 lbs)
Vol:
56L (3500 cu-in)
Vol:
22L (1342 cu-in)
Size:
OS
Tech:
FS
Size:
S M L XL XXL
Tech:
NF
BVS
IR
IR
The ROUS is our largest medic bag. The front has multiple storage options and the main compartment contains six removable pockets and two IV bag pockets, all with clear s for fast identification.
The MOLE is our smallest med pack. Its comfortable shoulder straps are removable for easy body armor attachment vai the body armor mount system. It features a Stick-it for bulky items or a helmet.
++
PALS webbing accommodates MOLLE accessories
++
PALS webbing accommodates MOLLE accessories
++
Internal trash pocket for easy inventory resupply
++
Body armor mount system
++
Two internal sleeves for splints and long items
++
Six removable pockets
++
Top lid features internal bandage and gauze loops
++
Two internal sleeves for splints and long items
++
Internal top handle for hanging opened pack
++
Top lid features internal bandage and gauze loops
++
Internal top handle for hanging opened pack
++
Removable Stick-it
VLAK The VLAK is designed to address medical resupply storage in vehicles. It features a detachable strap for carrying cross-body or can be slung over a headrest or attached via MOLLE. It can also be attached to an assault vest and body armor.
Medical - 17
COMMS This modular communication pack system features components that can be carried together on a NICE Frame or on their own. The COMM 3 easily carries a variety of communications gear and accessories.
COMM 3
Radio Bag
Weight:
3.4 kg (7.5 lbs)
Vol:
Comms
Size:
S M L XL XXL
Tech:
NF
BVS
IR
++
Modular pack system
++
PALS webbing accommodates MOLLE accessories
++
Clear view port over keypad and display
++
Fits PRC117F, G, or similar-sized radio
++
Compatible with Daypack Lid and Hitchhiker
++
Includes: NICE COMM 3 Radio Bag & NICE COMM 3 Battery Pocket
Battery Pocket
Comms - 19
BLACKJACK The BLACKJACK Series is designed after the new standard-issue packs for USSOCOM, the SPEAR ASSAULT. They feature lightweight, full carbon frames, Dyneema-CORDURA® laminate, IR-compliant zippers, and lightweight bolsters.
Photo: Tac Gas
BLACKJACK
BLACKJACK 50
BLACKJACK 80
Weight:
3.3 kg (7.2 lbs)
Weight:
3.8 kg (8.3 lbs)
Vol:
50L (3051 cu-in)
Vol:
80L (4880 cu-in)
Size:
S M L XL XXL
Size:
S M L XL XXL
Tech:
MLF
Tech:
MLF
IR
BVS
IR
The BLACKJACK 50 is a 50 L, top-loading pack with two external pockets that each have internal, mesh pockets. The pack has full-length zippers on each side for fast access to the main compartment.
The BLACKJACK 80 is an 80 L pack with four external pockets featuring top zips. It has full-length zippers on each side for fast access to the main compartment.
++
Quick-release Futura Yoke
++
Quick-release Futura Yoke
++
PALS webbing accommodates MOLLE accessories
++
PALS webbing accommodates MOLLE accessories
++
22
BVS
Urethane coated zipper ports at top of body opens from either side for antennae, cables, and/or hydration
++
++
Top-loading access has a spindrift collar
++
++
1” compression webbing and buckles
++
++
Full-length zippers on each side
Urethane coated zipper ports at top of body opens from either side for antennae, cables, and/or hydration Top-loading access has a spindrift collar Removable lid pocket with 2” straps that enable it to be used as a bolt/E&E pack
++
Full-length zippers on each side
++
1” compression webbing and buckles
BLACKJACK 100 Weight:
4.2 kg (9.2 lbs)
Vol:
100L (6102 cu-in)
Size:
S M L XL XXL
Tech:
MLF
BVS
IR
The BLACKJACK 100 is a 100 L pack including a 23 L Speedzip™ compartment at the bottom for easy access to your sleeping bag. It features four external pockets with top-open zippers. To help the taller pack, the BLACKJACK 100 uses a unique frame extension to stabilize larger loads.
++
Quick-release Futura Yoke
++
PALS webbing accommodates MOLLE accessories
++ ++ ++
Urethane coated zipper ports at top of body opens from either side for antennae, cables, and/or hydration Top-loading access has a spindrift collar Removable lid pocket with 2” straps that enable it to be used as a bolt/E&E pack
++
Full-length zippers on each side
++
1” compression webbing and buckles
++
Speedzip™ compartment
Blackjacks - 23
JUMP PACKS Designed for the sharpest tip of the spear, MYSTERY RANCH Jump Packs are genuinely mission focused. Features Jump-rated Type 7 webbing on all jump connections, Tex 138 thread on all Jump web for reinforcement and higher break strength, Dual-point release system to attach to jump harness, Reinforced tie-in loops, Lowering line attachment points, and D-rings for securing the toggle zippers. Every construction method and detail focuses on quick rigging, safe flight, and fast movement off the X.
Photo: Tac Gas
JUMP PACKS
JUMP RATS
JUMP KOMODO
DATL
Weight:
3.2 kg (7 lbs)
Weight:
2.3 kg (5.1 lbs)
Weight:
2 kg (4.5 lbs)
Vol:
23L (1400 cu-in)
Vol:
38L (2288 cu-in)
Vol:
37L (2200 cu-in)
S M/L XL
Size:
S M/L XL
BVS
Tech:
Size: Tech:
++ ++ ++ ++ ++ ++ ++ ++ ++ 26
S M/L XL
Size:
BVS
Tech:
FS
IR
Back stores a closed-cell foam pad to insulate patients from the ground PALS webbing accommodates MOLLE accessories Redundant zipper retainers Internal trash pocket to keep track of items used Two internal sleeves for splints and long items Two 150 cu-in front pockets for blowout kits Top lid features internal bandage and gauze loops 300 cu-in zippered bottom pocket NICE Frame compatible - not included
++ ++ ++ ++
FS
IR
IF
BVS
IR
Two, zippered pockets on lid
++
Vertical back long pockets
PALS webbing on interior and exterior accommodates MOLLE accessories
++
Removable Daypack Lid
Internal sleeves and ports integrate up to three hydration reservoirs Urethane coated zipper ports at top of body opens from either side for antennae, cables, and/or hydration
++ ++
Internal MOLLE for radios or other accessories Redirect waist belt
JUMP OVERLOAD
JUMP MOUNTAIN RUCK
Weight:
3.8 kg (8.4 lbs)
Weight:
3.7 kg (8.2 lbs)
Vol:
49L (2990 cu-in)
Vol:
86L (5248 cu-in)
Size:
S M/L XL
Size:
S M/L XL
Tech:
NF
BVS
Tech:
NF
++ ++ ++
++ ++
IR
Two internal sleeves each accommodate bladders up to 3L MOLLE on exterior, belt, and interior body for attaching accessories Urethane coated zipper ports at top of body opens from either side for antennae, cables, and/or hydration
++ ++
BVS
IR
New top-zip pockets replace the previous rip-zip front pockets PALS webbing accommodates MOLLE accessories
++
Two internal hydration pockets
++
Compatible with Daypack Lid
Two zippered pockets on lid for keeping small items accessible Side water bottle pockets
Jump Packs - 27
O.E.M. One of the things we are thanksful for at The Ranch is the interesting problems our customers bring to us. That includes packaging weapons, comm gear, optics, sensors, connectors and cabling. We have designed built-in systems to carry jammers, receivers and robots. If it needs to be carried by a human - let’s talk.
O.E.M - 29
ACCESSORIES MYSTERY CINCH Weight:
0.1 kg (0.2 lb)
Color: A modular cinch strap designed to reroute the shoulder pads of a pack down the front of your body armor to ease chafe, bleeding and nerve damage by keeping the pressure off your armpits. You can quickly drop your pack with a single, quick release buckle. PATENT: US 9,173,473 B2
HITCHHIKER 20
REMOVABLE STICK-IT
Vol:
24L (1464 cu-in)
Vol:
Expandable
Weight:
1 kg (2 lbs)
Weight:
0.3 kg (0.6 lb)
Tech:
IR
The HITCHHIKER 20 is attachable storage featuring our tri-zip opening. Its designed to work with the NICE RATS, ROUS and COMM 3 packs.
The REMOVABLE STICK-IT adds capacity expansion and easy access to any of our packs with bottom daisy chains. It has contouring pleats to accommodate larger volume items such as a helmet.
ACCESSORIES - 31
ACCESSORIES
LOAD CELL
RIP ZIP
These cube-shaped stuff sacks help organize your gear. Available in two sizes, they fit perfectly in the Load Sling and the Crewcab.
These tall pockets mount to any MOLLE and feature quick access to contents with its quick-rip design.
Vol:
S
2L (122 cu-in)
L
4L (244 cu-in)
Vol:
S
2L (122 cu-in)
L
4L (244 cu-in)
NVG POCKET
SCOUT POUCH
152 POUCH
This attachable pocket is designed to secure and protect the AN/PVS-14 monocular. The foam-lined pouch also includes a battery sleeve.
Standard-issue for USMC Scout Snipers, the SCOUT POUCH keeps a Kestrel unit secure and mounts to any MOLLE .
The 152 POUCH is a simple, no-frills secure storage for AN/PRC 152 radios. Quick, one-handed release gains the operator access to keypad and screen.
32
SOCOM BOTTLE POCKET This pocket mounts anywhere with MOLLE and accommodates most bottles or sundries. The simplistic elastic closure secures its contents.
FLASH BANG
TRIPLE BANG
KAB POUCH
The FLASH BANG is the SOCOM-issue pouch for holding stun grenades. Velcro flap closure tucks in behind the grenade for quick access.
The TRIPLE BANG holds three stun grenades in a secure MOLLE attach pouch with a Velcro lid flap that tucks in behind the grenade for quick access.
Protect your Kestrel 5700 with the KAB POUCH. This simple design attaches via MOLLE and keeps your applied ballistics device secure.
ACCESSORIES - 33
PRODUCT LINE BY VOLUME
ASAP
RATS
CREWCAB
20L | pg 6
23L | pg 16
26L | pg 10
3 DAY ASSAULT
DATL 37L | pg 26
33L | pg 6
ROUS
SATL
56L | pg 17
56L | pg 7
MOUNTAIN RUCK
BACKJACK 80 80L | pg 22
86L | pg 10
BERRY COMPLIANT All products in this catalog are in compliance with the Berry Amendment (10 U.S.C. 2533a).
Wood Carving: Team Room Designs llc
KOMODO DRAGON
OVERLOAD
BLACKJACK 50
49L | pg 13
50L | pg 22
38L | pg 7
OUTLIERS
BACKJACK 100
6500
100L | pg 23
106L | pg 11
COMM 3
LOAD SLING
N/A | pg 19
N/A | pg 10
MYSTERY RANCH BACKPACKS
1750 EVERGREEN DRIVE BOZEMAN MT 59715 833-548-1999 WWW.MYSTERYRANCH.COM CAGE CODE: 3HXV1 COPYRIGHT © MYSTERY RANCH LTD 2019
The appearance of U.S. Department of Defense (DoD) visual information does not imply or constitute DoD endorsement.
Related Documents 3m3m1z
Mr Military Workbook 19 Small 6d5y6q
November 2022 0
Elementary English For The Military Workbook 45jw
December 2019 50
Small 69l6g
December 2019 2,062
Military School 356p1l
December 2019 51
Military Triage 18642o
April 2022 0
Military Briefings 214e3v
December 2019 54More Documents from "Adiputra Iskandar" 271fn
Mr Military Workbook 19 Small 6d5y6q
November 2022 0
Acid Dye Instructions 6u5659
April 2023 0
Rpp Kimia Kurikulum 2013 Kelas Xii Semester 2 535i69
August 2020 0
Virgon.docx 4o413
November 2019 73
Power Point Kimia Unsur Periode 3 1l1s
April 2020 34
