LAB MANUAL

NETWORK SECURITY

Submitted To: Engr. Tauseef Ahmed Siddiqui

Department of Telecommunication Engineering University College of Engineering & Technology

The Islamia University of Bahawalpur

LABORATORY WORK BOOK

For The Course Network Security (TE-424)

Student Name: ______________ Roll No. __________________

Prepared By: Engr. Tauseef Ahmad Siddiqui Assistant Professor, Telecommunications Engineering

Department of Telecommunication Engineering University College of Engineering & Technology

The Islamia University of Bahawalpur, Pakistan

LIST OF EXPERIMENTS

Sr. No

Name of Experiment

Lab 01

Introduction To Cryptool

Lab 02

Implementation of ADFGVX Cipher

Lab 03

Implementation of Caesar Cipher

Lab 04

Implementation of Playfair Cipher

Lab 05

Implementation of Hill Cipher

Lab 06

Implementation of Vigenère Cipher

Lab 07

Implementation of Vernam Cipher

Lab 08

Implementation of Transposition Cipher

Lab 09

Implementation of Data Encryption Standard (DES)

Lab 10

Implementation of Advance Encryption Standard (AES)

Lab 11

Implementation of RC4 Algorithm

Lab 12

Implementation of MD5 Hash Algorithm

Lab 13

Implementation of Secure Hash Algorithm (SHA)

Lab 14

IP Access Control List Concepts

Lab 15

Standard IP Access Control List

Lab 16

Extended IP Access Control List

Lab 17

Virtual Private Network (VPN)

Lab 18

Windows Firewall

Network Security (TE-424)

Telecom 8th Semester

LAB EXPERIMENT NO.01 INTRODUCTION TO CRYPTOOL

Student Name:

Roll No:

Lab Instructor Signatures:

Date:

OBJECTIVE: Introduction of Cryptool Software. INTRODUCTION: The cryptool 2 is supplied free program with which each person installing the computer to experiment with encryption. Create their own provisions, to test the algorithms and study the results. BASIC DESCRIPTION: More specifically, a description of the basic steps are the following: Select an algorithm determines what kind of work will be performed (encryption - decryption), place the input data (text - file, picture , etc) appropriate type keys according to the algorithm , we form connections in the interface and the output connectors where the result will look and if everything is as it should be - if not, the program does not allow the completion of connections and not running - and then displayed after the execution result. The results obtained are thereafter studied, and compared or used in new encryption or decryption. ORIGINAL IMAGE:

Figure 1

Department of Telecommunication Engineering

1



Figure 1 shows the original image of the program before making any choice. The horizontal space on the upper side is the menu options on the known functions of storage, file selection, updates, settings, and program execution. The vertical left side is the toolbox of options the remaining space is the work area and the implementation of connecting the necessary parties. OPTIONS OF THE SOFTWARE:


2



Detail in Figure 2 is what is included in the toolbox on the left side. We see all the classic algorithms, all current algorithms, hash functions, steganography, protocols and types of inputs - outputs needed to run an algorithm. With the right "click" on all these elements, when introduced into the work area, given by the program even more information on how to use and operate. DETAILS OF ALGORITHMS:


3



The icons of the algorithms when the zoom in enabling us to deal with details of their settings. In Figure 3, the icons of DES and ADFGVX have options for the type of use (encryption - decryption), the channing mode associated with modes of algorithms parts (Electronic Code Book, Cipher Block Chaning, Cipher Feed Back, Output Feed Back and Counter) the padding mode (filling gaps), the keys used. DISPLAY CONNECTION:

Then in Figure 4, it seems a case of how connected all the necessary elements to perform the operation. Appears RSA with which you encrypted a age. Necessary figures in the left side are the public and private keys to encrypt data. OPERATION:


4



Previous Figure illustrates how becoming the "execution" of the program to export the result. Once you have given the 100% in the execution, we have completed, press the stop and we have the result.

In above Figure we see what gives us a text from the PLAYFAIR. It is obvious that the result (output) process can be used as input in a subsequent procedure. LANGUAGE STATISTICS:

So if you use the exit of PLAYFAIR we can make use of another function is the statistics of the language (Figure shown above). How often repeated that one letter. This is based on the specificity of each language is an element of cryptanalysis to extract the original message. Department of Telecommunication Engineering

5



CRYPTANALYSIS: Referring little earlier in language statistics and their usefulness should be noted that the potential of cryptool 2 are not limited to statistical incorporating other instruments (tests) cryptanalysis as the Friedman test (calculation process length possible keys to polyalphabetic substitution algorithm) and Kasinski test (is a process attack on polyalphabetic substitutions, based on an analysis of gaps in repeated sections cipher text). In Figure 9, we make use of the ENIGMA machine cryptanalyzing the result by applying the tests mentioned above.


6



LAB EXPERIMENT NO.02 IMPLEMENTATION OF ADFGVX CIPHER

Student Name:

Roll No:


Date:

OBJECTIVE: Implementation of ADFGVX cipher. TOOLS/ APPRATUS   

PC/Laptops Windows 7 and Windows 8. Cryptool 2

THEORY: The 'key' for a ADFGVX cipher is a 'key square' and a key word. e.g. p h 0 q g 6 4 m e a 1 y l 2 n o f d x k r 3 c v s 5 z w 7 b j 9 u t i 8

The key square is a 6 by 6 square containing all the letters and the numbers 0 - 9. The key word is any word e.g. GERMAN There are a number of steps involved: 1. Build a table like the following with the key square. This is known as a polybius square. A D F G V X A | p h 0 q g 6 D | 4 m e a 1 y F | l 2 n o f d G | x k r 3 c v V | s 5 z w 7 b X | j 9 u t i 8


1



2. Encode the plaintext using this matrix, to encode the letter 'a', locate it in the matrix and read off the letter on the far left side on the same row, followed by the letter at the top in the same column. In this way each plaintext letter is replaced by two cipher text letters. E.g. 'attack' -> 'DG XG XG DG GV GD'. The cipher text is now twice as long as the original plaintext. Note that so far, it is just a simple substitution cipher, and trivial to break. 3. Write the code word with the enciphered plaintext underneath e.g. G E R M A N D G X G X G D G G V G D

4. Perform a columnar transposition. Sort the code word alphabetically, moving the columns as you go. Note that the letter pairs that make up each letter get split apart during this step, this is called fractionating. A E G M N R X G D G G X G G D V D G

5. Read the final cipher text off in columns. -> XG GG DD GV GD XG PROCEDURE:


2



NOTE: Attach print outs of Cryptool file using another plain text along with this lab sheet. RSULTS/OBSERVATIONS: ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________


3



LAB EXPERIMENT NO.03 IMPLEMENTATION OF CAESAR CIPHER

Student Name:

Roll No:


Date:

OBJECTIVE: Implementation of CAESAR cipher. TOOLS/ APPRATUS   


THEORY: The Caesar cipher is one of the earliest known and simplest ciphers. It is a type of substitution cipher in which each letter in the plaintext is 'shifted' a certain number of places down the alphabet. For example, with a shift of 1, A would be replaced by B, B would become C, and so on. The method is named after Julius Caesar, who apparently used it to communicate with his generals. The Caesar cipher involves replacing each letter of the alphabet with the letter standing three places further down the alphabet. For example, plain: meet me after the toga party cipher: PHHW PH DIWHU WKH WRJD SDUWB

Note that the alphabet is wrapped around, so that the letter following Z is A. We can define the transformation by listing all possibilities, as follows: plain: a b c d e f g h i j k l m n o p q r s t u v w x y z cipher: D E F G H I J K L M N O P Q R S T U V W X Y Z A B C

Let us assign a numerical equivalent to each letter:


1



Then the algorithm can be expressed as follows. For each plaintext letter, substitute the cipher text letter C2: C = E(3, p) = (p + 3) mod 26 A shift may be of any amount, so that the general Caesar algorithm is C = E(k, p) = (p + k) mod 26 Where takes on a value in the range 1 to 25.The decryption algorithm is simply p = D(k, C) = (C - k) mod 26 PROCEDURE:

NOTE: Attach print outs of Cryptool file using another plain text along with this lab sheet. RSULTS/OBSERVATIONS: _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________


2



LAB EXPERIMENT NO.04 IMPLEMENTATION OF PLAYFAIR CIPHER

Student Name:

Roll No:


Date:

OBJECTIVE: Implementation of Playfair cipher. TOOLS/ APPRATUS   


THEORY: The Playfair cipher was the first practical digraph substitution cipher. The scheme was invented in 1854 by Charles Wheatstone, but was named after Lord Playfair who promoted the use of the cipher. The technique encrypts pairs of letters (digraphs), instead of single letters as in the simple substitution cipher. The Playfair is significantly harder to break since the frequency analysis used for simple substitution ciphers does not work with it. Frequency analysis can still be undertaken, but on the 25*25=625 possible digraphs rather than the 25 possible monographs. Frequency analysis thus requires much more ciphertext in order to work. The best-known multiple-letter encryption cipher is the Playfair, which treats digrams in the plaintext as single units and translates these units into ciphertext digrams. The Playfair algorithm is based on the use of a 5 × 5 matrix of letters constructed using a keyword. Here is an example, solved by Lord Peter Wimsey in Dorothy Sayers’s Have His Carcase:

In this case, the keyword is monarchy. The matrix is constructed by filling in the letters of the keyword (minus duplicates) from left to right and from top to bottom, and then filling in the remainder of the matrix with the remaining letters in alphabetic order. The letters I and J count as one letter. Plaintext is encrypted two letters at a time, according to the following rules: Department of Telecommunication Engineering

1



1. Repeating plaintext letters that are in the same pair are separated with a filler letter, such as x, so that balloon would be treated as ba lx lo on. 2. Two plaintext letters that fall in the same row of the matrix are each replaced by the letter to the right, with the first element of the row circularly following the last. For example, ar is encrypted as RM. 3. Two plaintext letters that fall in the same column are each replaced by the letter beneath, with the top element of the column circularly following the last. For example, mu is encrypted as CM. 4. Otherwise, each plaintext letter in a pair is replaced by the letter that lies in its own row and the column occupied by the other plaintext letter. Thus, hs becomes BP and ea becomes IM (or JM, as the encipherer wishes). Assume one wants to encrypt the digraph OR. There are three general cases: m * * a * * * * * * * * * * * l * * s * * * * * * Hence, al -> ms * * * * * * h y b d * * * * * * * * * * * * * * * Hence, hb -> yd * * n * * * * y * * * * * * * * * q * * * * w * * Hence, nq -> yw

An example encryption, "we are discovered, save yourself" using the key square shown at the beginning of this section: plaintext:

wearediscoveredsaveyourselfx

ciphertext: ugrmkcsxhmufmkbtoxgcmvatluiv Department of Telecommunication Engineering

2



PROCEDURE:



3



LAB EXPERIMENT NO.05 IMPLEMENTATION OF HILL CIPHER

Student Name:

Roll No:


Date:

OBJECTIVE: Implementation of Hill cipher. TOOLS/ APPRATUS   


THEORY: THE HILL Cipher is an encryption algorithm takes m successive plaintext letters and substitutes for them m cipher text letters. The substitution is determined by m linear equations in which each character is assigned a numerical value (a = 0, b = 1… z = 25). For m =3, the system can be described as;

c1 = (k11p1 + k12p2 + k13p3) mod 26 c2 = (k21p1 + k22p2 + k23p3) mod 26 c3 = (k31p1 + k32p2 + k33p3) mod 26 This can be expressed in of row vectors and matrices:

Or C = PK mod 26 Where C and P are row vectors of length 3 representing the plaintext and cipher text, and K is a 3 x 3 matrix representing the encryption key. Operations are performed mod 26. Department of Telecommunication Engineering

1



The key for a hill cipher is a matrix e.g.

In the above case, we have taken the size to be 3×3, however it can be any size (as long as it is square). Assume we want to encipher the message ATTACK AT DAWN. To encipher this, we need to break the message into chunks of 3. We now take the first 3 characters from our plaintext, ATT and create a vector that corresponds to the letters (replace A with 0, B with 1 ... Z with 25 etc.) to get: [0 19 19] (this is ['A' 'T' 'T']). To get our cipher text we perform a matrix multiplication (you may need to revise matrix multiplication if this doesn't make sense):

This process is performed for all 3 letter blocks in the plaintext. The plaintext may have to be padded with some extra letters to make sure that there is a whole number of blocks. Now for the tricky part, the decryption. We need to find an inverse matrix modulo 26 to use as our 'decryption key'. i.e. we want something that will take 'PFO' back to 'ATT'. If our 3 by 3 key matrix is called K, our decryption key will be the 3 by 3 matrix K-1 , which is the inverse of K.

To find K-1 we have to use a bit of maths. It turns out that K-1 above can be calculated from our key. A lengthy discussion will not be included here, but we will give a short example. The important things to know are inverses (mod m), determinants of matrices, and matrix adjugates. Let K be the key matrix. Let d be the determinant of K. We wish to find K-1 (the inverse of K), such that K × K-1 = I (mod 26), where I is the identity matrix. The following formula tells us how to find K1

given K:


2



Where d × d-1 = 1(mod 26), and adj(K) is the adjugate matrix of K. d (the determinant) is calculated normally for K (for the example above, it is 489 = 21 (mod 26)). The inverse, d-1 , is found by finding a number such that d × d-1 = 1 (mod 26) (this is 5 for the example above since 5*21 = 105 = 1 (mod 26)). The simplest way of doing this is to loop through the numbers 1..25 and find the one such that the equation is satisfied. There is no solution (i.e. choose a different key) if gcd(d,26) ≠ 1 (this means d and 26 share factors, if this is the case K cannot be inverted, this means the key you have chosen will not work, so choose another one).That is it. Once K-1 is found, decryption can be performed. PROCEDURE:



3



LAB EXPERIMENT NO.06 IMPLEMENTATION OF VIGENÈRE CIPHER

Student Name:

Roll No:


Date:

OBJECTIVE: Implementation of Vigenère cipher. TOOLS/ APPRATUS   


THEORY: The Vigenère cipher, was invented by a Frenchman, Blaise de Vigenère in the 16th century. It is a polyalphabetic cipher because it uses two or more cipher alphabets to encrypt the data. In other words, the letters in the Vigenère cipher are shifted by different amounts, normally done using a word or phrase as the encryption key. Unlike the mono-alphabetic ciphers, polyalphabetic ciphers are not susceptible to frequency analysis, as more than one letter in the plaintext can be represented by a single letter in the encryption. One of the main problems with simple substitution ciphers is that they are so vulnerable to frequency analysis. Given a sufficiently large cipher text, it can easily be broken by mapping the frequency of its letters to the know frequencies of, say, English text. Therefore, to make ciphers more secure, cryptographers have long been interested in developing enciphering techniques that are immune to frequency analysis. One of the most common approaches is to suppress the normal frequency data by using more than one alphabet to encrypt the message. A polyalphabetic substitution cipher involves the use of two or more cipher alphabets. Instead of there being a one-to-one relationship between each letter and its substitute, there is a one-to-many relationship between each letter and its substitutes. THE VIGENÈRE SQUARE: Blaise de Vigenère developed a square to help encode messages. Reading along each row, you can see that it is a really a series of Caesar ciphers the first has a shift of 1, the second a shift of 2 and so. Department of Telecommunication Engineering

1



The Vigenère cipher uses this table in conjunction with a key to encipher a message. So, if we were to encode a message using the key COUNTON, we write it as many times as necessary above our message. To find the encryption, we take the letter from the intersection of the Key letter row, and the Plaintext letter column.

To decipher the message, the recipient needs to write out the key above the cipher text and reverse the process. The maths behind the Vigenère cipher can be written as follows: To encrypt a message: Ca = Ma + Kb (mod 26) To decrypt a message: Ma = Ca – Kb (mod 26) (Where C = Code, M = Message, K = Key, and where a = the ath character of the message bounded by the message, and b is the bth character of the Key bounded by the length of the key.) Department of Telecommunication Engineering

2



PROCEDURE:



3



LAB EXPERIMENT NO.07 IMPLEMENTATION OF VERNAM CIPHER

Student Name:

Roll No:


Date:

OBJECTIVE: Implementation of Vernam cipher. TOOLS/ APPRATUS   


THEORY: Vernam cipher is an ultimate defense against such a cryptanalysis is to choose a keyword that is as long as the plaintext and has no statistical relationship to it. Such a system was introduced by an AT&T engineer named Gilbert Vernam in 1918. His system works on binary data (bits) rather than letters. The system can be expressed succinctly as follows in the figure;

c  p k i

i

i

Where pi=ith binary digit of plaintext ki=ith binary digit of key ci=ith binary digit of ciphertext  = exclusive-or (XOR) operation Compare above Equation with the Equation for Vigenère cipher given below; Ci = (pi + kimod m) mod 26


1



Thus, the ciphertext is generated by performing the bitwise XOR of the plaintext and the key. Because of the properties of the XOR, decryption simply involves the same bitwise operation: ci  p  k i i

Which compares with following Equation. Pi = (Ci - kimod m) mod 26 The essence of this technique is the means of construction of the key. Vernam proposed the use of a running loop of tape that eventually repeated the key, so that in fact the system worked with a very long but repeating keyword. Although such a scheme, with a long key, presents formidable cryptanalytic difficulties, it can be broken with sufficient cipher text, the use of known or probable plaintext sequences, or both. PROCEDURE:



2



LAB EXPERIMENT NO.08 IMPLEMENTATION OF TRANSPOSITION CIPHER

Student Name:

Roll No:


Date:

OBJECTIVE: Implementation of Transposition cipher. TOOLS/ APPRATUS   


THEORY: Transposition cipher, simple data encryption scheme in which plaintext characters are shifted in some regular pattern to form cipher text. In manual systems transpositions are generally carried out with the aid of an easily ed mnemonic. For example, a popular schoolboy cipher is the “rail fence,” in which letters of the plaintext are written alternating between rows and the rows are then read sequentially to give the cipher. In a depth-two rail fence (two rows) the message WE ARE DISCOVERED SAVE YOURSELF would be written;

Simple frequency counts on the cipher text would reveal to the cryptanalyst that letters occur with precisely the same frequency in the cipher as in an average plaintext and, hence, that a simple rearrangement of the letters is probable. The rail fence is the simplest example of a class of transposition ciphers, known as route ciphers, which enjoyed considerable popularity in the early history of cryptology. In general, the elements of the plaintext (usually single letters) are written in a prearranged order (route) into a geometric array (matrix)—typically a rectangle—agreed upon in advance by the transmitter and receiver and then read off by following another prescribed route through the matrix to produce the Department of Telecommunication Engineering

1



cipher. The key in a route cipher consists of keeping secret the geometric array, the starting point, and the routes. Clearly both the matrix and the routes can be much more complex than in this example; but even so, they provide little security. One form of transposition (permutation) that was widely used depends on an easily ed key word for identifying the route in which the columns of a rectangular matrix are to be read. For example, using the key word AUTHOR and ordering the columns by the lexicographic order of the letters in the key word

In decrypting a route cipher, the receiver enters the cipher text symbols into the agreed-upon matrix according to the encryption route and then reads the plaintext according to the original order of entry. A significant improvement in crypto-security can be achieved by re-encrypting the cipher obtained from one transposition with another transposition. Because the result (product) of two transpositions is also a transposition, the effect of multiple transpositions is to define a complex route in the matrix, which in itself would be difficult to describe by any simple mnemonic. In the same class also fall systems that make use of perforated cardboard matrices called grilles; descriptions of such systems can be found in older books on cryptography. In contemporary cryptography, transpositions serve principally as one of several encryption steps in forming a compound or product cipher. PROCEDURE:


2





3



LAB EXPERIMENT NO.09 IMPLEMENTATION OF DATA ENCRYPTION STANDARD (DES)

Student Name:

Roll No:


Date:

OBJECTIVE: Implementation of Data Encryption Standard. TOOLS/ APPRATUS   


THEORY: The Data Encryption Standard is a previously predominant symmetric-key algorithm for the encryption of electronic data. It was highly influential in the advancement of modern cryptography in the academic world. Developed in the early 1970s at IBM and based on an earlier design by Horst Feistel, the algorithm was submitted to the National Bureau of Standards (NBS) following the agency's invitation to propose a candidate for the protection of sensitive, unclassified electronic government data. In 1976, after consultation with the National Security Agency (NSA), the NBS eventually selected a slightly modified version, which was published as an official Federal Information Processing Standard (FIPS) for the United States in 1977. The publication of an NSA-approved encryption standard simultaneously resulted in its quick international adoption and widespread academic scrutiny. Controversies arose out of classified design elements, a relatively short key length of the symmetric-key block cipher design, and the involvement of the NSA, nourishing suspicions about a backdoor. The intense academic scrutiny the algorithm received over time led to the modern understanding of block ciphers and their cryptanalysis. DES FEATURES:  

Block size = 64 bits Key size = 56 bits (in reality, 64 bits, but 8 are used as parity-check bits for error control)


1

Network Security (TE-424)  


Number of rounds = 16 16 intermediary keys, each 48 bits

KEY LENGTH IN DES:  

In the DES specification, the key length is 64 bit. 8 bytes; in each byte, the 8th bit is a parity-check bit.

Each parity-check bit is the XOR of the previous 7 bits. DES ROUNDS:


2



PROCEDURE: In this excercize you can use the DES-component to encrypt an arbitrary text entered in the Input message-component on the left side. The resulting encrypted text is displayed in the Output messagecomponent on the right side after hitting the Play-button. The DES-component works on binary values, i.e. bytes. Thus, the inputed text is first converted to bytes with the Message decoder-component. With the current settings, it is interpreted as ASCII. The resulting bytes are then encrypted with DES, yielding another sequence of bytes. These bytes are then simply printed as hexadecimal values with the help of the Message encoder-component. Note that you can also decrypt messages with this template. To do so, you first copy the encrypted hexadecimal values to the Input message. Then you have to change the following:   

Set Input format of the Message decoder to Hexadecimal Set Action of DES to Decrpyt; Set Format of the Message encoder to Text and the encoding to ASCII.



3



LAB EXPERIMENT NO.10 IMPLEMENTATION OF ADVANCE ENCRYPTION STANDARD (AES)

Student Name:

Roll No:


Date:

OBJECTIVE: Implementation of Advance Encryption Standard. TOOLS/ APPRATUS   


THEORY: The Advanced Encryption Standard (AES) is a specification for the encryption of electronic data established by the U.S.National Institute of Standards and Technology (NIST) in 2001. AES is based on the Rijndael cipher developed by two Belgian cryptographers, Joan Daemen and Vincent Rijmen, who submitted a proposal to NIST during the AES selection process. Rijndael is a family of ciphers with different key and block sizes. For AES, NIST selected three of the Rijndael family, each with a block size of 128 bits, but three different key lengths: 128, 192 and 256 bits. AES has been adopted by the U.S. government and is now used worldwide. It supersedes the Data Encryption Standard (DES), which was published in 1977. The algorithm described by AES is a symmetric-key algorithm, meaning the same key is used for both encrypting and decrypting the data. In the United States, AES was announced by the NIST as U.S. FIPS PUB 197 (FIPS 197) on November 26, 2001.[4] This announcement followed a five-year standardization process in which fifteen competing designs were presented and evaluated, before the Rijndael cipher was selected as the most suitable. AES became effective as a federal government standard on May 26, 2002 after approval by the Secretary of Commerce. AES is included in the ISO/IEC 18033-3 standard. AES is available in many different encryption packages, and is the first publicly accessible and open cipher approved by the National Security Agency (NSA) for top secret information when used in an NSA approved cryptographic module. Department of Telecommunication Engineering

1




2



Much of the Rijndael algorithm is based on arithmetic on a finite field, or Galois field (after the mathematician). Regular arithmetic works on an infinite range of numbers – keep doubling a number and it will get ever bigger. Arithmetic in a finite field is limited to numbers within that field. The Rijndael algorithm works in GF(28), in which arithmetic results can always be stored within one byte – which is pretty convenient for computers. I can’t begin to understand the maths (considering that addition and subtraction are the same thing – an XOR operation – and multiplication is performed ‘modulo an irreducible polynomial’: doubling 0x80 in GF(28) gives 0x1b). The Rijndael algorithm lends itself to widely differing implementations, since the maths can be either coded directly, or pre-computed as lookup tables – directly parallel to using log tables for arithmetic. Different implementations can have varying pay-offs between speed, complexity, and storage requirements. Some may barely resemble each other. In this implementation, I have followed the standard closely; as per the standard, I have used a lookup table (‘S-box’) to implement the multiplicative inverse (i.e. 1/x) within a finite field (used for the SubBytes transformation), but other calculations are made directly rather than being pre-computed. PROCEDURE: In this excercize you can use the AES-component to encrypt an arbitrary text entered in the Input message-component on the left side. The resulting encrypted text is displayed in the Output messagecomponent on the right side after hitting the Play-button. The AES-component works on binary values, i.e. bytes. Thus, the inputed text is first converted to bytes with the Message decoder-component. With the current settings, it is interpreted as ASCII. The resulting bytes are then encrypted with AES, yielding another sequence of bytes. These bytes are then simply printed as hexadecimal values with the help of the Message encoder-component. Note that you can also decrypt messages with this template. To do so, you first copy the encrypted hexadecimal values to the Input message. Then you have to change the following:   

Set Input format of the Message decoder to Hexadecimal; Set Action of AES to Decrpyt; Set Format of the Message encoder to Text and the encoding to ASCII.


3





4



LAB EXPERIMENT NO.11 IMPLEMENTATION OF RC4 ALGORITHM

Student Name:

Roll No:


Date:

OBJECTIVE: Implementation of RC4 Algorithm. TOOLS/ APPRATUS   


THEORY: RC4 is a stream cipher designed in 1987 by Ron Rivest for RSA Security. It is a variable key size stream cipher with byte-oriented operations. The algorithm is based on the use of a random permutation. Analysis shows that the period of the cipher is overwhelmingly likely to be greater than 10100 [ROBS95a]. Eight to sixteen machine operations are required per output byte, and the cipher can be expected to run very quickly in software. RC4 is used in the Secure Sockets Layer/Transport Layer Security (SSL/TLS) standards that have been defined for communication between Web browsers and servers. It is also used in the Wired Equivalent Privacy (WEP) protocol and the newer WiFi Protected Access (WPA) protocol that are part of the IEEE 802.11 wireless LAN standard. RC4 was kept as a trade secret by RSA Security. In September 1994, the RC4 algorithm was anonymously posted on the Internet on the Cypher-punks anonymous remailers list. The RC4 algorithm is remarkably simple and quite easy to explain. A variable length key of from 1 to 256 bytes (8 to 2048 bits) is used to initialize a 256-byte state vector S, with elements S[0], S[1], c, S[255]. At all times, S contains a permutation of all 8-bit numbers from 0 through 255. For encryption and decryption, a byte k (see Figure 1) is generated from S by selecting one of the 255 entries in a systematic fashion. As each value of k is generated, the entries in S are once again permuted. Department of Telecommunication Engineering

1



Figure 1: Stream Cipher Diagram Initialization of S: To begin, the entries of S are set equal to the values from 0 through 255 in ascending order; that is, S[0] = 0, S[1] = 1, c, S[255] = 255 . A temporary vector, T, is also created. If the length of the key K is 256 bytes, then K is transferred to T. Otherwise, for a key of length keylen bytes, the first keylen elements of T are copied from K, and then K is repeated as many times as necessary to fill out T. These preliminary operations can be summarized as; /* Initialization */ for i = 0 to 255 do S[i] = i; T[i] = K[i mod keylen];

Next we use T to produce the initial permutation of S. This involves starting with S[0] and going through to S[255], and for each S[i], swapping S[i] with another byte in S according to a scheme dictated by T[i]: /* Initial Permutation of S */ j = 0; for i = 0 to 255 do j = (j + S[i] + T[i]) mod 256; Swap (S[i], S[j]);

Because the only operation on S is a swap, the only effect is a permutation. S still contains all the numbers from 0 through 255. Stream Generation: Once the S vector is initialized, the input key is no longer used. Stream generation involves cycling through all the elements of S[i], and for each S[i], swapping S[i] with another byte in S according to a scheme dictated by the current configuration of S. After S[255] is reached, the process continues, starting over again at S[0]: /* Stream Generation */ i, j = 0; while (true) i = (i + 1) mod 256; j = (j + S[i]) mod 256; Swap (S[i], S[j]); t = (S[i] + S[j]) mod 256; k = S[t];


2



To encrypt, XOR the value k with the next byte of plaintext. To decrypt, XOR the value k with the next byte of cipher text. Figure 2 illustrates the RC4 logic.

Figure 2: Working of RC4 PROCEDURE: After K has been created, K is XORed with a byte of plaintext for encryption and XORed with byte of ciphertext for decryption.

NOTE: Attach print outs of Cryptool file using another plain text along with this lab sheet. RSULTS/OBSERVATIONS: ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________


3



LAB EXPERIMENT NO.12 IMPLEMENTATION OF MD5 HASH ALGORITHM

Student Name:

Roll No:


Date:

OBJECTIVE: Implementation of MD5 Hash Algorithm. TOOLS/ APPRATUS   


THEORY: The MD5 message-digest algorithm is a widely used cryptographic hash function producing a 128bit (16-byte) hash value, typically expressed in text format as a 32 digit hexadecimal number. MD5 has been utilized in a wide variety of cryptographic applications, and is also commonly used to data integrity. MD5 was designed by Ronald Rivest in 1991 to replace an earlier hash function, MD4. The source code in RFC 1321 contains a "by attribution" RSA license. In 1996 a flaw was found in the design of MD5. While it was not deemed a fatal weakness at the time, cryptographers began recommending the use of other algorithms, such as SHA-1—which has since been found to be vulnerable as well. In 2004 it was shown that MD5 is not collision resistant.[5] As such, MD5 is not suitable for applications like SSL certificates or digital signatures that rely on this property for digital security. Also in 2004 more serious flaws were discovered in MD5, making further use of the algorithm for security purposes questionable; specifically, a group of researchers described how to create a pair of files that share the same MD5 checksum. Further advances were made in breaking MD5 in 2005, 2006, and 2007. In December 2008, a group of researchers used this technique to fake SSL certificate validity, and CMU Software Engineering Institute now says that MD5 "should be considered cryptographically broken and unsuitable for further use", and most U.S. government Department of Telecommunication Engineering

1



applications now require the SHA-2 family of hash functions. In 2012, the Flame malware exploited the weaknesses in MD5 to fake a Microsoft digital signature. ALGORITHM: MD5 processes a variable-length message into a fixed-length output of 128 bits. The input message is broken up into chunks of 512-bit blocks (sixteen 32-bit words); the message is padded so that its length is divisible by 512. The padding works as follows: first a single bit, 1, is appended to the end of the message. This is followed by as many zeros as are required to bring the length of the message up to 64 bits fewer than a multiple of 512. The remaining bits are filled up with 64 bits representing the length of the original message, modulo 264. The main MD5 algorithm operates on a 128-bit state, divided into four 32-bit words, denoted A, B, C, and D. These are initialized to certain fixed constants. The main algorithm then uses each 512-bit message block in turn to modify the state. The processing of a message block consists of four similar stages, termed rounds; each round is composed of 16 similar operations based on a non-linear function F, modular addition, and left rotation. Figure 1 illustrates one operation within a round. There are four possible functions F; a different one is used in each round:

Denote the XOR, AND, OR and NOT operations respectively.

Figure 1: Message Digest Algorithm Department of Telecommunication Engineering

2



One MD5 operation. MD5 consists of 64 of these operations, grouped in four rounds of 16 operations. F is a nonlinear function; one function is used in each round.     

Mi denotes a 32-bit block of the message input Ki denotes a 32-bit constant, different for each operation. s denotes a left bit rotation by s places; s varies for each operation. denotes addition modulo 232.

MD5 Hash Properties: The MD5 hash consists of a small amount of binary data, typically no more than 128 bits. All hash values share the following properties: Hash length The length of the hash value is determined by the type of the used algorithm, and its length does not depend on the size of the file. The most common hash value lengths are either 128 or 160 bits. Non-discoverability Every pair of non-identical files will translate into a completely different hash value, even if the two files differ only by a single bit. Using today's technology, it is not possible to discover a pair of files that translate to the same hash value. Repeatability Each time a particular file is hashed using the same algorithm, the exact same hash value will be produced. Irreversibility All hashing algorithms are one-way. Given a checksum value, it is infeasible to discover the . In fact, none of the properties of the original message can be determined given the checksum value alone. PROCEDURE: The MD5 function provides a 32 digit hexadecimal number. If we were to turn ‘makeuseof.com’ into into an MD5 hash value then it would look like:64399513b7d734ca90181b27a62134dc. It was built


3



upon a method called the Merkle”“DamgÃ¥rd structure (below), which is used to build what are known as “collision-proof” hash functions.

NOTE: Attach print outs of Cryptool file using another plain text along with this lab sheet. RSULTS/OBSERVATIONS: ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________


4



LAB EXPERIMENT NO.13 IMPLEMENTATION OF SHA HASH ALGORITHM (SHA)

Student Name:

Roll No:


Date:

OBJECTIVE: Implementation of SHA Algorithm. TOOLS/ APPRATUS   


THEORY: In cryptography, SHA-1 is a cryptographic hash function designed by the United States National Security Agency and is a U.S. Federal Information Processing Standard published by the United States NIST. SHA-1 produces a 160-bit (20-byte) hash value. A SHA-1 hash value is typically rendered as a hexadecimal number, 40 digits long. SHA stands for "secure hash algorithm". The four SHA algorithms are structured differently and are named SHA-0, SHA-1, SHA-2, and SHA-3. SHA-0 is the original version of the 160-bit hash function published in 1993 under the name "SHA": it was not adopted by many applications. Published in 1995, SHA-1 is very similar to SHA-0, but alters the original SHA hash specification to correct alleged weaknesses. SHA-2, published in 2001, is significantly different from the SHA-1 hash function.SHA1 is the most widely used of the existing SHA hash functions, and is employed in several widely used applications and protocols. In 2005, cryptanalysts found attacks on SHA-1 suggesting that the algorithm might not be secure enough for ongoing use. NIST required many applications in federal agencies to move to SHA-2 after 2010 because of the weakness. Although no successful attacks have yet been reported on SHA-2, it is algorithmically similar to SHA-1. In 2012, following a long-running competition, NIST selected an additional algorithm, Keccak, for standardization under SHA-3. In November 2013 Microsoft announced their deprecation policy on SHA-1 according to which Windows will stop accepting SHA-1 certificates in SSL by 2017. In September Department of Telecommunication Engineering

1



2014 Google announced their deprecation policy on SHA-1 according to which Chrome will stop accepting SHA-1 certificates in SSL in a phased way by 2017. Mozilla is also planning to stop accepting SHA-1-based SSL certificates by 2017.

ALGORITHM: SHA-1 produces a message digest based on principles similar to those used by Ronald L. Rivest of MIT in the design of theMD4 and MD5 message digest algorithms, but has a more conservative design. The original specification of the algorithm was published in 1993 under the title Secure Hash Standard, FIPS PUB 180, by U.S. government standards agency NIST (National Institute of Standards and Technology). This version is now often namedSHA-0. It was withdrawn by the NSA shortly after publication and was superseded by the revised version, published in 1995 in FIPS PUB 180-1 and commonly designated SHA-1. SHA-1 differs from SHA-0 only by a single bitwise rotation in the message schedule of its compression function; this was done, according to the NSA, to correct a flaw in the original algorithm which reduced its cryptographic security. However, the NSA did not provide any further explanation or identify the flaw that was corrected. Weaknesses have subsequently been reported in both SHA-0 and SHA-1. SHA-1 appears to provide greater resistance to attacks, ing the NSA’s assertion that the change increased the security.

Figure 1: Secure Hash Algorithm     

One iteration within the SHA-1 compression function: A, B, C, D and E are 32-bit words of the state; F is a nonlinear function that varies; n denotes a left bit rotation by n places; n varies for each operation;


2

Network Security (TE-424)   


Wt is the expanded message word of round t; Kt is the round constant of round t; denotes addition modulo 232.

PROCEDURE:



3



LAB EXPERIMENT NO.14 IP ACCESS CONTROL LIST CONCEPTS

Student Name:

Roll No:


Date:

OBJECTIVE: Routers use access lists to control incoming or outgoing traffic. You will know the following characteristics of an access list.       

Access lists Filter packets internally Access lists Protect the internal network from illegal Internet access Access lists Restrict access to virtual terminal ports Access lists describe the traffic type that will be controlled. Access list entries describe the traffic characteristics. Access list entries identify either permitted or denied traffic. Access list entries can describe a specific traffic type, or allow or restrict all traffic.

THEORY: Network s must be capable of denying unwanted access to the network while allowing appropriate access. Although security tools such as s, callback equipment, and physical security devices are helpful, they often lack the flexibility of basic traffic filtering and the specific controls that most s prefer. For example, a network might want to allow ’s access to the Internet but might not want external s Telnetting into the LAN. Routers provide basic traffic-filtering capabilities, such as blocking Internet traffic, with access control lists (ACLs). An ACL is a sequential collection of permit or deny statements that apply to addresses or upper-layer protocols. ACLs filter network traffic by controlling whether routed packets are forwarded or blocked at the router’s interfaces. The router examines each packet to determine whether to forward or drop it, based on the conditions specified in the ACL. ACL conditions could be the source address of the traffic, the destination address of the traffic, the upper-layer protocol, the port, or applications. Why Create ACLs? Many reasons exist for creating ACLs. ACLs can be used to perform the following operations: 

Limit network traffic and increase network performance. For example, ACLs can designate certain packets to be processed by a router before other traffic, on the basis of a protocol. This is referred to as queuing. Queuing ensures that routers will not process packets that are not needed. As a result, queuing limits network traffic and reduces network congestion.


1

Network Security (TE-424) 

 


Provide traffic flow control. For example, ACLs can restrict or reduce the contents of routing updates. These restrictions are used to limit information about specific networks from propagating through the network. Provide a basic level of security for network access. ACLs can allow one host to access a part of your network and prevent another host from accessing the same area. Decide which type of traffic is forwarded or blocked at the router interface. For example, you can permit e-mail traffic to be routed, but at the same time block All Telnet traffic.

There are two types of Access Lists; Standard ACL Range 1-99 General Source Address only Applied closed to the Destination Filter Complete Protocol Suite

Extended ACL Range 100-199 Specific Source and Destination Address Applied closed to the Source Can filter one Protocol out of complete suite


2



LAB EXPERIMENT NO.15 STANDARD IP ACCESS CONTROL LIST

Student Name:

Roll No:


Date:

OBJECTIVE: To implement Standard IP Access Control List on a Router. TOOLS/ APPRATUS   

PC/Laptops Windows 7 and Windows 8. Packet Tracer

THEORY: The standard IP access lists use only the source IP address in an IP packet to filter the Network. This basically permits or denies an entire protocol suite. They cannot distinguish between the any of the many type of IP traffic such as web, telnet, UDP etc. TOPOLOGY:


1



BASIC CONFIGURATION ON ROUTER 1: Router> enable Router#configure terminal Router(config)# hostname router1 router1(config)# interface serial 0/3/0 router1(config-if)#ip address 12.1.1.1 255.0.0.0 router1(config-if)#no shutdown router1(config-if)#exit router1(config)#interface loopback 0 router1(config-if)#ip address 1.1.1.1 255.0.0.0 router1(config-if)#exit router1(config)#exit router1# wr

BASIC CONFIGURATION ON ROUTER 2: Router> enable Router#configure terminal Router(config)# hostname router2 router2(config)# interface serial 0/3/0 router2(config-if)#ip address 12.1.1.2 255.0.0.0 router2(config-if)#no shutdown router2(config-if)#exit router2(config)# interface serial 0/3/1 router2(config-if)#ip address 23.1.1.2 255.0.0.0 router2(config-if)#no shutdown router2(config-if)#exit router2(config)#interface loopback 0 router2(config-if)#ip address 2.2.2.2 255.0.0.0 router2(config-if)#exit router2(config)#exit router2# wr


2



BASIC CONFIGURATION ON ROUTER 3: Router> enable Router#configure terminal Router(config)#hostname router3 router3(config)#interface serial 0/3/1 router3(config-if)#ip address 23.1.1.3 255.0.0.0 router3(config-if)#no shutdown router3(config-if)#exit router3(config)# interface serial 0/3/0 router3(config-if)#ip address 34.1.1.3 255.0.0.0 router3(config-if)#no shutdown router3(config-if)#exit router3(config)#interface loopback 0 router3(config-if)#ip address 3.3.3.3 255.0.0.0 router3(config-if)#exit router3(config)#exit router3# wr BASIC CONFIGURATION ON ROUTER 4: Router> enable Router#configure terminal Router(config)#hostname router4 router4(config)#interface serial 0/3/0 router4(config-if)#ip address 34.1.1.4 255.0.0.0 router4(config-if)#no shutdown router4(config-if)#exit router4(config)#interface loopback 0 router4(config-if)#ip address 4.1.1.1 255.255.0.0 router4(config-if)#exit router4(config)#interface loopback 1 router4(config-if)#ip address 4.2.2.2 255.255.0.0 router4(config-if)#exit Department of Telecommunication Engineering

3



router4(config)#interface loopback 2 router4(config-if)#ip address 4.3.3.3 255.255.0.0 router4(config-if)#exit router4(config)#exit router4# wr RUNNING RIP ON ROUTER 1: router1#configure terminal router1(config)#router rip router1(config-router)# do show ip route router1(config-router)# network 1.0.0.0 router1(config-router)# network 12.0.0.0 router1(config-router)#exit router1(config)#exit router1#wr

RUNNING RIP ON ROUTER 2: router2#configure terminal router2(config)#router rip router2(config-router)# do show ip route router2(config-router)# network 2.0.0.0 router2(config-router)# network 12.0.0.0 router2(config-router)# network 23.0.0.0 router2(config-router)#exit router2(config)#exit router2#wr

RUNNING RIP ON ROUTER 3: router3#configure terminal router3(config)#router rip router3(config-router)# do show ip route router3(config-router)# network 34.0.0.0 router3(config-router)# network 3.0.0.0


4



router3(config-router)# network 23.0.0.0 router3(config-router)#exit router3(config)#exit router3#wr RUNNING RIP ON ROUTER 4: router4#configure terminal router4(config)#router rip router4(config-router)# do show ip route router4(config-router)# network 34.0.0.0 router4(config-router)# network 4.1.0.0 router4(config-router)# network 4.2.0.0 router4(config-router)# network 4.3.0.0 router4(config-router)#exit router4(config)#exit router4#wr ROUTING TABLE OF ROUTER 1: router1#show ip route C

1.0.0.0/8 is directly connected, Loopback0

R

2.0.0.0/8 [120/1] via 12.1.1.2, 00:00:15, Serial0/3/0

R

3.0.0.0/8 [120/2] via 12.1.1.2, 00:00:15, Serial0/3/0

R

4.0.0.0/8 [120/3] via 12.1.1.2, 00:00:15, Serial0/3/0

C

12.0.0.0/8 is directly connected, Serial0/3/0

R

23.0.0.0/8 [120/1] via 12.1.1.2, 00:00:15, Serial0/3/0

R

34.0.0.0/8 [120/2] via 12.1.1.2, 00:00:15, Serial0/3/0

ROUTING TABLE OF ROUTER 2: router2#show ip route R

1.0.0.0/8 [120/1] via 12.1.1.1, 00:00:16, Serial0/3/0

C


R

3.0.0.0/8 [120/1] via 23.1.1.3, 00:00:16, Serial0/3/1

R

4.0.0.0/8 [120/2] via 23.1.1.3, 00:00:16, Serial0/3/1


5



C


C


R

34.0.0.0/8 [120/1] via 23.1.1.3, 00:00:16, Serial0/3/1


1.0.0.0/8 [120/2] via 23.1.1.2, 00:00:06, Serial0/3/1

R

2.0.0.0/8 [120/1] via 23.1.1.2, 00:00:06, Serial0/3/1

C


R

4.0.0.0/8 [120/1] via 34.1.1.4, 00:00:19, Serial0/3/0

R

12.0.0.0/8 [120/1] via 23.1.1.2, 00:00:06, Serial0/3/1

C


C



1.0.0.0/8 [120/3] via 34.1.1.3, 00:00:04, Serial0/3/0

R

2.0.0.0/8 [120/2] via 34.1.1.3, 00:00:04, Serial0/3/0

R

3.0.0.0/8 [120/1] via 34.1.1.3, 00:00:04, Serial0/3/0 4.0.0.0/16 is subnetted, 3 subnets

C

4.1.0.0 is directly connected, Loopback0

C


C


R

12.0.0.0/8 [120/2] via 34.1.1.3, 00:00:04, Serial0/3/0

R

23.0.0.0/8 [120/1] via 34.1.1.3, 00:00:04, Serial0/3/0

C


VERIFICATION: router4# router4#ping Protocol [ip]: Target IP address: 4.1.1.1 Repeat count [5]: Department of Telecommunication Engineering

6



Datagram size [100]: Timeout in seconds [2]: Extended commands [n]: yes Source address or interface: 1.1.1.1 Type of service [0]: Set DF bit in IP header? [no]: Validate reply data? [no]: Data pattern [0xABCD]: Loose, Strict, Record, Timestamp, Verbose[none]: Sweep range of sizes [n]: Type escape sequence to abort. Sending 5, 100-byte ICMP Echos to 4.1.1.1, timeout is 2 seconds: Packet sent with a source address of 1.1.1.1 !!!!! Success rate is 100 percent (5/5), round-trip min/avg/max = 3/3/3 ms VERIFICATION: router4#ping Protocol [ip]: Target IP address: 4.2.2.2 Repeat count [5]: Datagram size [100]: Timeout in seconds [2]: Extended commands [n]: yes Source address or interface: 1.1.1.1 Type of service [0]: Set DF bit in IP header? [no]: Validate reply data? [no]: Data pattern [0xABCD]: Loose, Strict, Record, Timestamp, Verbose[none]: Sweep range of sizes [n]: Type escape sequence to abort. Department of Telecommunication Engineering

7



Sending 5, 100-byte ICMP Echos to 4.2.2.2, timeout is 2 seconds: Packet sent with a source address of 1.1.1.1 !!!!! Success rate is 100 percent (5/5), round-trip min/avg/max = 3/5/16 ms CREATING STANDARD ACL ON ROUTER 4: Task: %% Block all the traffic Coming from the host 1.1.1.1 to router 4 router4#configure terminal router4(config)#access-list 5 deny 1.1.1.1 0.0.0.0 router4(config)#access-list 5 permit any APPLYING STANDARD ACL ON INTERFACE SERIAL 0/3/0 ON ROUTER 4: %% interface nearest to destination as possible router4(config)#interface serial 0/3/0 router4(config-if)#ip access-group 5 in router4(config-if)#exit

router4(config)#exit router4#wr VERIFICATION: router1#ping Protocol [ip]: Target IP address: 4.2.2.2 Repeat count [5]: Datagram size [100]: Timeout in seconds [2]: Extended commands [n]: yes Source address or interface: 1.1.1.1 Type of service [0]: Set DF bit in IP header? [no]: Validate reply data? [no]:


8



Data pattern [0xABCD]: Loose, Strict, Record, Timestamp, Verbose[none]: Sweep range of sizes [n]: Type escape sequence to abort. Sending 5, 100-byte ICMP Echos to 4.2.2.2, timeout is 2 seconds: Packet sent with a source address of 1.1.1.1 UUUUU Success rate is 0 percent (0/5) RSULTS/OBSERVATIONS: ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________


9



LAB EXPERIMENT NO.16 EXTENDED IP ACCESS CONTROL LIST

Student Name:

Roll No:


Date:

OBJECTIVE: To implement Extended IP Access Control List on a Router. TOOLS/ APPRATUS   

PC/Laptops Windows 7 and Windows 8. Packet Tracer

THEORY: Extended Access lists can evaluate many of the other fields in the layer 3 and layer 4 headers of an IP packet. They can evaluate source & destination IP address, the protocol field in the Network layer header, and port number at Transport layer header. TOPOLOGY:


1



BASIC CONFIGURATION ON ROUTER 1: Router> enable Router#configure terminal Router(config)# hostname router1 router1(config)# interface serial 0/3/0 router1(config-if)#ip address 12.1.1.1 255.0.0.0 router1(config-if)#no shutdown router1(config-if)#exit router1(config)#interface loopback 0 router1(config-if)#ip address 1.1.1.1 255.0.0.0 router1(config-if)#exit router1(config)#exit router1# wr CONFIGURING TELNET ON ROUTER 1: router1#configure terminal router1(config)#line vty 0 15 router1(config-line)# cisco router1(config-line)# router1(config-line)#exit router1(config)#enable cisco router1(config)#end BASIC CONFIGURATION ON ROUTER 2: Router> enable Router#configure terminal Router(config)# hostname router2 router2(config)# interface serial 0/3/0 router2(config-if)#ip address 12.1.1.2 255.0.0.0 router2(config-if)#no shutdown router2(config-if)#exit router2(config)# interface serial 0/3/1 Department of Telecommunication Engineering

2



router2(config-if)#ip address 23.1.1.2 255.0.0.0 router2(config-if)#no shutdown router2(config-if)#exit router2(config)#interface loopback 0 router2(config-if)#ip address 2.2.2.2 255.0.0.0 router2(config-if)#exit router2(config)#exit router2# wr

BASIC CONFIGURATION ON ROUTER 3: Router> enable Router#configure terminal Router(config)#hostname router3 router3(config)#interface serial 0/3/1 router3(config-if)#ip address 23.1.1.3 255.0.0.0 router3(config-if)#no shutdown router3(config-if)#exit router3(config)# interface serial 0/3/0 router3(config-if)#ip address 34.1.1.3 255.0.0.0 router3(config-if)#no shutdown router3(config-if)#exit router3(config)#interface loopback 0 router3(config-if)#ip address 3.3.3.3 255.0.0.0 router3(config-if)#exit router3(config)#exit router3# wr BASIC CONFIGURATION ON ROUTER 4: Router> enable Router#configure terminal Router(config)#hostname router4 router4(config)#interface serial 0/3/0 router4(config-if)#ip address 34.1.1.4 255.0.0.0 Department of Telecommunication Engineering

3



router4(config-if)#no shutdown router4(config-if)#exit router4(config)#interface loopback 0 router4(config-if)#ip address 4.1.1.1 255.255.0.0 router4(config-if)#exit router4(config)#interface loopback 1 router4(config-if)#ip address 4.2.2.2 255.255.0.0 router4(config-if)#exit router4(config)#interface loopback 2 router4(config-if)#ip address 4.3.3.3 255.255.0.0 router4(config-if)#exit router4(config)#exit router4# wr

RUNNING RIP ON ROUTER 1: router1#configure terminal router1(config)#router rip router1(config-router)# do show ip route router1(config-router)# network 1.0.0.0 router1(config-router)# network 12.0.0.0 router1(config-router)#exit router1(config)#exit router1#wr RUNNING RIP ON ROUTER 2: router2#configure terminal router2(config)#router rip router2(config-router)# do show ip route router2(config-router)# network 2.0.0.0 router2(config-router)# network 12.0.0.0 router2(config-router)# network 23.0.0.0 router2(config-router)#exit router2(config)#exit Department of Telecommunication Engineering

4



router2#wr RUNNING RIP ON ROUTER 3: router3#configure terminal router3(config)#router rip router3(config-router)# do show ip route router3(config-router)# network 34.0.0.0 router3(config-router)# network 3.0.0.0 router3(config-router)# network 23.0.0.0 router3(config-router)#exit router3(config)#exit router3#wr RUNNING RIP ON ROUTER 4: router4#configure terminal router4(config)#router rip router4(config-router)# do show ip route router4(config-router)# network 34.0.0.0 router4(config-router)# network 4.1.0.0 router4(config-router)# network 4.2.0.0 router4(config-router)# network 4.3.0.0 router4(config-router)#exit router4(config)#exit router4#wr ROUTING TABLE OF ROUTER 1: router1#show ip route C


R

2.0.0.0/8 [120/1] via 12.1.1.2, 00:00:15, Serial0/3/0

R

3.0.0.0/8 [120/2] via 12.1.1.2, 00:00:15, Serial0/3/0

R

4.0.0.0/8 [120/3] via 12.1.1.2, 00:00:15, Serial0/3/0

C


R

23.0.0.0/8 [120/1] via 12.1.1.2, 00:00:15, Serial0/3/0


5

Network Security (TE-424) R


34.0.0.0/8 [120/2] via 12.1.1.2, 00:00:15, Serial0/3/0


1.0.0.0/8 [120/1] via 12.1.1.1, 00:00:16, Serial0/3/0

C


R

3.0.0.0/8 [120/1] via 23.1.1.3, 00:00:16, Serial0/3/1

R

4.0.0.0/8 [120/2] via 23.1.1.3, 00:00:16, Serial0/3/1

C


C


R

34.0.0.0/8 [120/1] via 23.1.1.3, 00:00:16, Serial0/3/1


1.0.0.0/8 [120/2] via 23.1.1.2, 00:00:06, Serial0/3/1

R

2.0.0.0/8 [120/1] via 23.1.1.2, 00:00:06, Serial0/3/1

C


R

4.0.0.0/8 [120/1] via 34.1.1.4, 00:00:19, Serial0/3/0

R

12.0.0.0/8 [120/1] via 23.1.1.2, 00:00:06, Serial0/3/1

C


C



1.0.0.0/8 [120/3] via 34.1.1.3, 00:00:04, Serial0/3/0

R

2.0.0.0/8 [120/2] via 34.1.1.3, 00:00:04, Serial0/3/0

R

3.0.0.0/8 [120/1] via 34.1.1.3, 00:00:04, Serial0/3/0 4.0.0.0/16 is subnetted, 3 subnets

C


C


C


R

12.0.0.0/8 [120/2] via 34.1.1.3, 00:00:04, Serial0/3/0

R

23.0.0.0/8 [120/1] via 34.1.1.3, 00:00:04, Serial0/3/0


6

Network Security (TE-424) C



VERIFICATION: router4# router4#ping Protocol [ip]: Target IP address: 4.1.1.1 Repeat count [5]: Datagram size [100]: Timeout in seconds [2]: Extended commands [n]: yes Source address or interface: 1.1.1.1 Type of service [0]: Set DF bit in IP header? [no]: Validate reply data? [no]: Data pattern [0xABCD]: Loose, Strict, Record, Timestamp, Verbose[none]: Sweep range of sizes [n]: Type escape sequence to abort. Sending 5, 100-byte ICMP Echos to 4.1.1.1, timeout is 2 seconds: Packet sent with a source address of 1.1.1.1 !!!!! Success rate is 100 percent (5/5), round-trip min/avg/max = 3/3/3 ms VERIFICATION: router4#ping Protocol [ip]: Target IP address: 4.2.2.2 Repeat count [5]: Datagram size [100]: Timeout in seconds [2]: Extended commands [n]: yes Source address or interface: 1.1.1.1 Department of Telecommunication Engineering

7



Type of service [0]: Set DF bit in IP header? [no]: Validate reply data? [no]: Data pattern [0xABCD]: Loose, Strict, Record, Timestamp, Verbose[none]: Sweep range of sizes [n]: Type escape sequence to abort. Sending 5, 100-byte ICMP Echos to 4.2.2.2, timeout is 2 seconds: Packet sent with a source address of 1.1.1.1 !!!!! Success rate is 100 percent (5/5), round-trip min/avg/max = 3/5/16 ms VERIFICATION: router4#telnet 12.1.1.1 Trying 12.1.1.1 ...Open Access Verification : router1>

CREATING STANDARD ACL ON ROUTER 1: Task:

%% Block all the telnet traffic Coming from the host

34.1.1.4 to host 12.1.1.1 router1#configure terminal router1(config)#access-list 101 deny t 34.1.1.4 0.0.0.0 12.1.1.1 0.0.0.0 eq 23 router1(config)#access-list 101 permit ip any any APPLYING STANDARD ACL ON INTERFACE SERIAL 0/3/0 ON ROUTER 1: router1(config)#interface serial 0/3/0 router1(config-if)#ip access-group 101 in router1(config-if)#exit router1(config)#exit Department of Telecommunication Engineering

8



router1#wr

VERIFICATION: router4#telnet 12.1.1.1 Trying 12.1.1.1 ... % Connection timed out; remote host not responding

VERIFICATION: router2#telnet 12.1.1.1 Trying 12.1.1.1 ...Open Access Verification : router1> RSULTS/OBSERVATIONS: ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________


9



LAB EXPERIMENT NO.17 VIRTUAL PRIVATE NETWORK (VPN)

Student Name:

Roll No:


Date:

OBJECTIVE: Creating a Virtual Private Network (VPN). TOOLS/ APPRATUS  

PC/Laptops Windows 7 and Windows 8.

THEORY: A VPN is a network that uses a public telecommunication infrastructure, such as the Internet, to provide remote offices or individual s with secure access to their organization's network. A VPN ensures privacy through security procedures and tunneling protocols such as the Layer Two Tunneling Protocol ( L2TP ). Data is encrypted at the sending end and decrypted at the receiving end. But VPNs connect to the outside world over the Internet, and they can serve to secure general Internet traffic in addition to corporate assets. In fact, the lion's share of modern VPNs are encrypted, so computers, devices, and other networks that connect to them do so via encrypted tunnels. WHY WE WANT TO CREATE A VPN: You have at least four great reasons to start using a VPN. First, you can use it to connect securely to a remote network via the Internet. Most companies maintain VPNs so that employees can access files, applications, printers, and other resources on the office network without compromising security, but you can also set up your own VPN to safely access your secure home network while you're on the road. Second, VPNs are particularly useful for connecting multiple networks together securely. For this reason, most businesses big and small rely on a VPN to share servers and other networked resources among multiple offices or stores across the globe. Even if you don't have a chain of offices to worry


1



about, you can use the same trick to connect multiple home networks or other networks for personal use.

Figure 1: This diagram illustrates the difference between using an unencrypted connection and using a VPN-secured Internet connection at your average coffee shop. Third, if you're concerned about your online privacy, connecting to an encrypted VPN while you're on a public or untrusted network—such as a Wi-Fi hotspot in a hotel or coffee shop—is a smart, simple security practice. Because the VPN encrypts your Internet traffic, it helps to stymie other people who may be trying to snoop on your browsing via Wi-Fi to capture your s. Fourth and finally, one of the best reasons to use a VPN is to circumvent regional restrictions—known as geo blocking—on certain websites. Journalists and political dissidents use VPNs to get around statesponsored censorship all the time, but you can also use a VPN for recreational purposes, such as connecting to a British VPN to watch the BBC iPlayer outside the UK. Because your Internet traffic routes through the VPN, it looks as if you're just another British visitor. PICK YOUR PROTOCOL: When choosing a networking protocol for your VPN, you need worry only about the four most popular ones. Here's a quick rundown, including the strengths and weaknesses of each. Point-to-Point Tunneling Protocol (PPTP) is the least secure VPN method, but it’s a great starting point for your first VPN because almost every operating system s it, including Windows, Mac OS, and even mobile OSs. Layer 2 Tunneling Protocol (L2TP) and Internet Protocol Security (IPsec) are more secure than PPTP and are almost as widely ed, but they are also more complicated to set up and are susceptible to the same connection issues as PPTP is. Secure Sockets Layer (SSL) VPN systems provide the same level of security that you trust when you log on to banking sites and other sensitive domains. Most SSL VPNs are referred to as "clientless," Department of Telecommunication Engineering

2



since you don't need to be running a dedicated VPN client to connect to one of them. They're my favorite kind of VPN because the connection happens via a Web browser and thus is easier and more reliable to use than PPTP, L2TP, or IPsec.

Figure 2: An SSL VPN server is designed to be accessed via Web browser and creates encrypted channels so that you can safely access the server from anywhere. OpenVPN is exactly what it sounds like: an open-source VPN system that's based on SSL code. It's free and secure, and it doesn't suffer from connection issues, but using OpenVPN does require you to install a client since Windows, Mac OS X, and mobile devices don't natively it. In short: When in doubt, try to use SSL or OpenVPN. Keep in mind that some of the services highlighted in the next section don’t use these protocols. Instead, they use their own proprietary VPN technology. Now, let's talk about how to create and connect to your own VPN. If you want simple remote access to a single computer, consider using the VPN software built into Windows. If you’d like to network multiple computers together quickly through a VPN, consider installing stand-alone VPN server software. If you need a more reliable and robust arrangement (one that also s site-to-site connections), consider using a dedicated VPN router. And if you just want to use a VPN to secure your Internet traffic while you're on public Wi-Fi hotspots and other untrusted networks—or to access regionally restricted sites—consider subscribing to a third-party hosted VPN provider. SET UP A SIMPLE VPN WITH WINDOWS: Windows comes loaded with a VPN client that s the PPTP and L2TP/IPsec protocols. The setup process is simple: If you're using Windows 8, just bring up the Search charm, type VPN, and then launch the VPN wizard by clicking Set up a virtual private network (VPN) connection. Department of Telecommunication Engineering

3



You can use this client to connect securely to other Windows computers or to other VPN servers that the PPTP and L2TP/IPsec protocols—you just need to provide the IP address or domain name of the VPN server to which you want to connect. If you're connecting to a corporate or commercial VPN, you can the to learn the proper IP address. If you're running your own VPN server via Windows, you can figure out the server's IP address by typing CMD in the Search charm, launching the Command Prompt, and typing ipconfig. This simple trick comes in handy when you're setting up your Windows PC as a VPN server, and then connecting to it so that you can securely, remotely access your files from anywhere.

Figure 3: Windows has a built-in VPN client, but you'll need to provide the connection information (namely, the IP address) for the VPN server you want to use. Quick Note: When setting up incoming PPTP VPN connections in Windows, you must configure your network router to forward VPN traffic to the Windows computer you want to access remotely. You can do this by logging in to the router’s control —consult the manufacturer's instructions on how to do this—and configuring the port-forwarding or virtual-server settings to forward port 1723 to the IP address of the computer you wish to access. In addition, PPTP or VPN -through options need to be enabled in the firewall settings, but usually they're switched on by default. HOW TO SET UP VPN IN WINDOWS 7: Windows 7 comes preloaded with the Agile VPN client, which makes setting up either kind of connection relatively easy. Step by Step: Connecting to a VPN (Outgoing)

Step 1 Click the Start button. In the search bar, type VPN and then select Set up a virtual private network (VPN) connection. Department of Telecommunication Engineering

4



Step 2 Enter the IP address or domain name of the server to which you want to connect. If you're connecting to a work network, your IT can provide the best address. Step 3 If you want to set up the connection, but not connect, select Don't connect now; otherwise, leave it blank and click Next. Step 4 On this next screen, you can either put in your name and , or leave it blank. You'll be prompted for it again on the actual connection. Click Connect. Step 5 To connect, click on the Windows network logo on the lower-right part of your screen; and then select Connect under VPN Connection. Step 6 In the Connect VPN Connection box, enter the appropriate domain and your log-in credentials; and then click Connect.

Step 7 If you can't connect, the problem could be due to the server configuration. (There are different types of VPN.) Check with your network to see what kind is in use--such as PPTP--then, on the Connect VPN Connection screen, select Properties. Step 8 Navigate to the Security tab and select the specific Type of VPN from the drop-down list. You may also have to unselect Include Windows logon domain under the Options tab. Then click OK and Connect. Step by Step: Building a VPN (Incoming):

Step 1 Click the Start button, and, in the search bar, type Network and Sharing. Step 2 Click Change Adapter Settings in the left-hand menu. Step 3 Click File, and then New Incoming Connection. Step 4 Select the s you'd like to give access to and click Next. Department of Telecommunication Engineering

5



Step 5 Click Through the Internet and select Next. Step 6 Select the Internet Protocol you'd like to use. (The default T/IPv4--the line highlighted in the screenshot below--will work fine.)

Step 7 Finally, click Allow access; you've now set up an incoming VPN connection. RSULTS/OBSERVATIONS: ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________


6



LAB EXPERIMENT NO.18 WINDOWS FIREWALL

Student Name:

Roll No:


Date:

OBJECTIVE: Configure Windows firewall settings. TOOLS/ APPRATUS  

PC/Laptops Windows 7 and Windows 8.

THEORY: A firewall is software or hardware that checks information coming from the Internet or a network, and then either blocks it or allows it to through to your computer, depending on your firewall settings. A firewall can help prevent hackers or malicious software from gaining access to your computer through a network or the Internet. A firewall can also help stop your computer from sending malicious software to other computers. Configure Windows Firewall You can customize most settings of your Windows Firewall through left pane of the Firewall applet in Control .


1



Turn on Windows Firewall. This setting is selected by default. When Windows Firewall is on, most programs are blocked from communicating through the firewall. If you want to allow a program to communicate through the firewall, you can add it to the list of allowed programs. For example, you might not be able to send photos in an instant message until you add the instant messaging program to the list of allowed programs. To add a program to the list, see Allow a program to communicate through Windows Firewall. Block all incoming firewall connections, including those in the list of allowed programs This setting blocks all unsolicited attempts to connect to your computer. Use this setting when you need maximum protection for your computer, such as when you connect to a public network in a hotel or airport, or when a computer worm is spreading over the Internet. With this setting, you are not notified when Windows Firewall blocks programs, and programs in the list of allowed programs are ignored. When you block all incoming connections, you can still view most webpages, send and receive e-mail, and send and receive instant messages. Turn off Windows Firewall Avoid using this setting unless you have another firewall running on your computer. Turning off Windows Firewall might make your computer more vulnerable to damage from hackers and malicious software. Allow a program to communicate through Windows Firewall By default, most programs are blocked by Windows Firewall to help make your computer more secure. To work properly, some programs might require you to allow them to communicate through the firewall. Here’s how to do that: Click Allow a program or feature through Windows Firewall. If you are prompted for an or confirmation, type the or provide confirmation. Click Enable all controls. If you are prompted for an or confirmation, type the or provide confirmation. Select the check box next to the program you want to allow, select the network location types you want to allow communication on, and then click OK. How to open a port in Windows Firewall If Windows Firewall is blocking a program and you want to allow that program to communicate through the firewall, you can usually do that by selecting the program in the list of allowed programs (also called the exceptions list) in Windows Firewall. To learn how to do this, see Allow a program to communicate through Windows Firewall. However, if the program isn’t listed, you might need to open a port. For example, to play a multiplayer game with friends online, you might need to open a port for the game so that the firewall allows the game information to reach your computer. A port stays open all the time, so be sure to close ports that you don’t need anymore. Click to open Windows Firewall. In the left pane, click Advanced settings. Department of Telecommunication Engineering

2



In the Windows Firewall with Advanced Security dialog box, in the left pane, click Inbound Rules, and then, in the right pane, click New Rule.


3



Next, follow the instructions on your screen to its logical conclusion. RSULTS/OBSERVATIONS: ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________


4

Network Security Lab Manual 5n1s6n

Overview 3e4r5l

More details w3441

Related Documents 3m3m1z

Network Security Lab Manual 5n1s6n

Network Security Lab Manual 5n1s6n

Network Security 425u41

Network Security 425u41

Computer Network Lab Manual 3r1d21

Network Programming Lab Manual 2i6568

More Documents from "Saad Khaliq" 3y5132

Satellite Communication Lab Manual 1q6137

Network Security Lab Manual 5n1s6n

Fpga Class Notes (student Copy) 3x1j3u

Essentials Of Negotiations Chapter8 -6th-edition 2z6m1q

Kpogdcl 11o5t

Financial Statement Analysis Of Aci Ltd. 355b3p
