Ordering Guide for Cisco WAAS Using Cisco WAVE and WAE Appliances and Cisco WAAS Network Modules Ordering Guide May 13, 2008
For further information, questions, and comments, please : [email protected].
© 2009 Cisco Systems, Inc. Cisco Confidential/Proprietary—Pricing for illustration purposes only. Pricing subject to change. April 20, 2009
Ordering Guide
Contents Overview ................................................................................................................................................. 3 Platforms ................................................................................................................................................ 3 Ordering Steps for Cisco WAVE and WAE Appliances .................................................................. 4 Options ................................................................................................................................. 5 Hardware and Software Options ....................................................................................................... 5
Hardware Options by Device....................................................................................................... 5 Software Options by Device ........................................................................................................ 5 Options Available as Spares ............................................................................................................. 6 Ordering Differences Between Cisco WAAS Software Versions 4.0 and 4.1 ................................ 6 Ordering Information by Platform ...................................................................................................... 6 Virtualization-Capable Cisco WAAS Appliances for the Branch Office .......................................... 7
Cisco WAVE-274 Ordering Information .................................................................................... 7 Cisco WAVE-474 Ordering Information .................................................................................... 8 Cisco WAVE-574 Ordering Information .................................................................................... 8 Cisco WAE-674 Ordering Information ....................................................................................... 9 Cisco WAAS Appliances for Branch Office and Data Center........................................................ 10
Cisco WAE-512 Ordering Information ..................................................................................... 10 Cisco WAE-612 Ordering Information ..................................................................................... 11 Cisco WAE-7341 Ordering Information................................................................................... 12 Cisco WAE-7371 Ordering Information................................................................................... 13 ............................................................................................................................................. 13
Hardware : Cisco SMARTnet Contract ....................................................................... 13 Software : SASU Contract ............................................................................................ 15 Ordering Steps for Cisco WAAS Network Modules....................................................................... 15 Cisco WAAS NME-WAE Spares ..................................................................................................... 16 Cisco WAAS NME-WAE and Cisco Integrated Services Routers WAN Optimization Bundles .. 16
NME-WAE-502-K9 Bundles..................................................................................................... 16 NME-WAE-302-K9 Bundles..................................................................................................... 17 NME-WAE Configured Under the Router or Other Bundles.................................................. 17 for Network Modules .......................................................................................................... 18 Ordering Steps for Cisco WAAS Mobile.......................................................................................... 18 Ordering Steps for Cisco WAAS FY09 Promotions....................................................................... 18
Cisco WAAS FY09 Promotion Bundles Ordering Information.............................................. 19 Additional Resources ......................................................................................................................... 19
© 2009 Cisco Systems, Inc. Cisco Confidential/Proprietary—Pricing for illustration purposes only. Pricing subject to change. April 20, 2009
Page 2 of 20
Ordering Guide
O ve rvie w ®
Cisco Wide Area Application Services (WAAS) products are ordered with products from one of following Cisco product families: ●
Cisco Wide Area Virtualization Engine (WAVE) appliance family
●
Cisco Wide Area Application Engine (WAE) appliance family
●
Cisco WAAS NME-WAE Network Module family for Cisco Integrated Services Routers
This document describes how to configure and order these products, including both hardware and software options. This document does not provide detailed pricing or sizing information, though some preliminary information may be included in certain sections of this document. This document also does not provide ordering information related to return material authorization (RMA) requests. Note:
All prices mentioned are list prices in U.S. dollars and are based on the global price list.
Please refer to the Cisco Online Pricing Tool for accurate prices. Please see the detailed sizing guidelines in the Cisco WAAS Sales Rack for specific platform recommendations.
Plat f orms Cisco WAAS products must be ordered with the appliances or network modules listed in Table 1. Network modules are available on a stand-alone basis or as part of Cisco Integrated Services Routers bundles. The list price includes both Cisco WAAS hardware and software. In the Cisco WAE Appliances and Cisco WAAS NME-WAE module families, Cisco WAAS Software needs to be added to the hardware SKU separately. In the recently introduced Cisco WAVE platforms, the Cisco WAAS Enterprise software license is included by default for easier configuration. Table 1.
Cisco WAAS Product Line: Appliances and Network Modules
Model
Maximum T Connectio ns*
Description
Starting Solut ion List Price (Hardware plus Software)
Network Modules in Cisco Integrated Services Routers for Branch Office NME-WAE-302-K9
250
Network module for Cisco Integrated Services Routers; s only Cisco WAAS Transport license
US$3750**
NME-WAE-502-K9
500
Network module for Cisco Integrated Services Routers; s Cisco WAAS Transport and Enterprise licenses
US$9500
NME-WAE-522-K9
800
Network module for Cisco Integrated Services Routers; s Cisco WAAS Transport and Enterprise licenses
US$12,000
Virtualization-Capable Cisco WAAS Appliances*** for Branch Office WAVE-274-K9
200
● Cisco WAVE-274 with chassis with 3 GB SDRAM. 250- US$6500 GB hard disk drive (HDD), 2-port inline module, and AC power supply; Cisco WAAS Enterprise license included ● No additional hardware upgrade options available
WAVE-474-K9
400
● Cisco WAVE-474 with chassis with 3 GB SDRAM, 250- US$9900 GB HDD, 2-port inline module, and AC power supply; Cisco WAAS Enterprise license included ● No additional hardware upgrade options available
WAVE-574-K9
750 - 1300
● Cisco WAVE-574 with chassis with 3 GB SDRAM, 500- US$12,500 GB HDD, and AC power supply; Cisco WAAS Enterprise license included ● Additional memory options and HDD available for higher optimized T connection count, increased number of virtual blades, and RAID-1 redundancy
© 2009 Cisco Systems, Inc. Cisco Confidential/Proprietary—Pricing for illustration purposes only. Pricing subject to change. April 20, 2009
Page 3 of 20
Ordering Guide
Model
Maximum T Connectio ns*
Description
Starting Solut ion List Price (Hardware plus Software)
WAE-674-K9
2000 - 6000
● Cisco WAE-674, 4 GB,SDRAM and 3 X 300-GB HDDs, US$22,000 and AC power supply; RAID-5 redundancy included ● Additional memory available for higher optimized T connection count and increased number of virtual blades ● Additional redundant power and cooling options available for data center deployment
Cisco WAAS Appliances for Branch Office and Data Center WAE-512-K9
750 - 1500
● Cisco WAE-512 with chassis with 1 GB SDRAM, 1 250-GB HDD, and AC power supply ● Additional memory and HDDs available for higher optimized T connection count and RAID-1 redundancy; virtual blades are not ed
US$12,500
WAE-612-K9
2000 - 6000
● Cisco WAE-612 with chassis with 2 GB SDRAM, 2 300-GB HDDs, and AC power supply ● Additional memory option available for higher optimized T connection count and RAID-1 redundancy included; virtual blades are not ed
US$22,000
WAE-7341-K9
12,000
● Cisco WAE-7341 includes 12 GB RAM, 4 X 300-GB HDDs, and 2 AC power supplies; RAID-5 redundancy included ● No additional hardware upgrade options available
US$59,000
WAE-7371-K9
50,000
● Cisco WAE-7371 includes 24 GB RAM, 6 X 300-GB HDDs, and 2 AC power supplies; RAID-5 redundancy included ● No additional hardware upgrade options available
US$135,000
Cisco WAAS Mobile Server and Client WAAS-MBL-SRVSW
Depends on hardware configuration****
● Cisco WAAS Mobile server software US$5000 ● Standard Microsoft Windows Server hardware required
WAAS-MBL-LIC25
25 concurrent s
● Cisco WAAS Mobile 25 concurrent licenses
US$8750
WAAS-MBL-LIC100
100 concurrent s
● Cisco WAAS Mobile 100 concurrent licenses
US$34,000
WAAS-MBL-LIC500
500 concurrent s
● Cisco WAAS Mobile 500 concurrent licenses
US$162,500
* Maximum number of T connections is presented only as a guideline. Please use detailed sizing information and guidelines that are available in the Cisco WAAS Sales Rack. ** NME-WAE-302-K9 s only the Cisco WAAS Transport license. *** All Cisco WAVE appliance SKUs include the Cisco WAAS Enterprise license for simplified configuration. The Cisco WAE Appliances family and Cisco WAAS NME-WAE module family need explicit configuration (that is, addition) of the Cisco WAAS Enterprise license. The list price in Table 1 reflects the starting price of the Cisco WAAS solution (including both hardware and software). **** Refer to the Cisco WAAS Mobile server hardware system requirements in the guide for hardware configuration.
O rde ri ng St e ps f or Ci s c o W AVE a nd WA E A ppli a nc es You can use either the Cisco Dynamic Configuration Tool or the Multi-line Configurator Tool to configure Cisco WAE Appliances with Cisco WAAS. When using the Dynamic Configuration Tool, follow these steps: 1.
Configure the Cisco WAVE, WAE, and NME-WAE devices with the appropriate software and hardware options.
2.
Click Check Configuration to validate the configuration. This action also displays available ®
Cisco SMARTnet SKUs.
© 2009 Cisco Systems, Inc. Cisco Confidential/Proprietary—Pricing for illustration purposes only. Pricing subject to change. April 20, 2009
Page 4 of 20
Ordering Guide
3.
Select the desired Cisco SMARTnet contract for hardware .
4.
Separately include the Software Application plus Upgrade (SASU) contract for software in the order.
Options options for Cisco WAE Appliances include Cisco SMARTnet for the hardware and SASU for the Cisco WAAS Software. The Multi-line Configurator Tool allows easy specification of both Cisco SMARTnet and SASU. With the Dynamic Configuration Tool, only Cisco SMARTnet can be specified as part of the configuration; the SASU contract needs to be separately included as part of the order. For SASU SKUs, see the section Software (SASU Contract). Hardware and Software Options The following hardware and software options are typically the most common. Not all options are listed here, and not all options may be available across all models. Details for each platform can be found in the tables in the section Ordering Information by Platform. Hardware Options by Device Not all hardware options are available on all models. ●
Memory
●
Hard disks
●
Peripheral Component Interconnect (PCI) inline card
●
Redundant power and cooling
Software Options by Device Not all software options are available on all models. ●
Cisco WAAS Software version; select only one option
◦ Cisco WAAS Software Version 4.0 ◦ Cisco WAAS Software Version 4.1 ●
Mandatory Cisco WAAS Software license; select only one option
◦ Cisco WAAS Enterprise license ◦ Cisco WAAS Transport license ◦ Cisco WAAS Central Manager license (applicable only with Cisco WAAS Software Version 4.0) ●
Optional (add-on) Cisco WAAS Software license (requires Cisco WAAS Enterprise license to be selected)
◦ Cisco WAAS Video license for Microsoft Windows Live video ◦ Cisco WAAS Virtual Blade license to create and enable virtual blades for branch-office services subject to appliance
◦ Microsoft Windows Server on Cisco WAAS with Virtual Blade license to create, enable, and install Microsoft Windows Server Core 2008 on a Cisco WAAS appliance (includes prepackaged Microsoft Windows Server Core 2008 software) The configurations listed here will be specified in the following sections with individual product SKUs on a per-platform basis.
© 2009 Cisco Systems, Inc. Cisco Confidential/Proprietary—Pricing for illustration purposes only. Pricing subject to change. April 20, 2009
Page 5 of 20
Ordering Guide
Options Available as Spares Some of the options listed in the preceding section are available as spares; you can order them separately on a standalone basis without the need to associate them with any base-platform SKU. The SKUs for spares display an = symbol at the end of the SKU name. If a particular option is not offered as a spare, the part is not available unless purchased along with a base-platform SKU. Ordering Differences Between Cisco WAAS Software Versions 4.0 and 4.1 This section covers the two high-level ordering differences when customers or partners order a platform with Cisco WAAS Software Version 4.1 instead of Cisco WAAS Software Version 4.0. ●
The Cisco WAVE platforms, Cisco WAVE-274, WAVE-474, and WAVE-574, include the Cisco WAAS Enterprise license by default. Thus, configuration is simplified for these platforms. Cisco WAVE platforms Cisco WAAS starting with Cisco WAAS Software Version 4.1.1.
●
For the Cisco WAAS NME-WAE network module and Cisco WAE Appliances families, the Cisco WAAS Enterprise license needs to be selected explicitly for Cisco WAAS Software Version 4.1 just as it does for Cisco WAAS Software Version 4.0.
●
There will be no standalone Cisco WAAS Central Manager license starting with Cisco WAAS Software Version 4.1; this license is included with the Cisco WAAS Enterprise license. The central manager functions will be available as a mode and require a Cisco WAAS Enterprise license. This change is applicable for all appliance platforms: both Cisco WAE and Cisco WAVE. This change reduces the number of license options that customers need to manage. Please note Cisco WAAS NME-WAE modules do not central manager functions with either Cisco WAAS Software Version 4.0 or 4.1. A platform configured in the central manager mode will allow customers to manage their Cisco WAAS deployments.
Table 2 summarizes the ordering differences between Cisco WAAS Software Versions 4.0 and 4.1. Table 2.
Main Ordering Differences Between Cisco WAAS Software Versions 4.0 and 4.1 Cisco W AAS S oftware Version 4.0
Cisco W AAS S oftware Version 4.1
Cisco WAAS Enterprise license
● Requires explicit selection for all platforms ● Platform configured with Enterprise license cannot be configured with any other software license
● Included by default for Cisco WAVE-274, WAVE-474, and WAVE-574 platforms; requires explicit selection for all other platforms ● Prerequisite for adding the optional software Video and Virtual Blade licenses on platforms that them
Cisco WAAS Central Manager license
● Requires explicit selection for all appliances ● Platform configured with Central Manager license cannot be configured with any other software license
● Standalone Central Manager license no longer applicable ● Central Manager function included as part of Cisco WAAS Enterprise license
Ordering Information by Platform This section provides platform-based ordering information. Hardware and software options are labeled as mandatory, optional, or auto-expand. ●
Mandatory: Selection of the relevant part number is required in the Dynamic Configuration Tool and Ordering Tool.
●
Optional: Selection of the relevant part number is up to discretion of the customer.
© 2009 Cisco Systems, Inc. Cisco Confidential/Proprietary—Pricing for illustration purposes only. Pricing subject to change. April 20, 2009
Page 6 of 20
Ordering Guide
●
Auto-expand: Selection of the relevant part number is not required because the part is automatically included at the end of the configuration process.
Virtualization-Capable Cisco WAAS Appliances for the Branch Office This section contains information about the Cisco WAAS appliances that hosting of branchoffice IT services on Cisco WAAS virtual blades. Cisco WAVE-274 Ordering Information Table 3 provides ordering information and part numbers for the Cisco WAVE-274 appliance. Table 3.
Cisco WAVE-274 Appliance Ordering Information
Platform Model and Optio ns
Mandatory, Optio nal, or Auto-Expand
Part Number
Description
Notes
Available as Spare
Cisco WAVE-274
Mandatory
WAVE-274-K9
Chassis with 3 GB RAM, 1 X 250-GB HDD, 2-port inline card, Cisco WAAS Enterprise license, and AC power supply
Optional
MNT-2PST-RACK
2-post rack shelf for Cisco WAVE-274
Optional
MNT-WALL-SLV
Wall sleeve mount for Cisco WAVE-274
Auto-Expand
AK-WAAS-HW
Hardware accessory kit
No
Auto-Expand
AK-WAAS-4.1-CD-K9
Cisco WAAS Software 4.1 CD recovery kit
No
Mandatory
Select appropriate cables from list.
Power cables
No
Hardware Options Mount options
Accessory kit
Power cable
Select only one of these mount options, not both.
Product SKUs are self-explanatory.
No No
No
Software Options Software version
Mandatory
SF-WAAS-4.1-K9
Cisco WAAS Software 4.1
Software license
Auto-Expand
WAAS-ENT-APL
Cisco WAAS Enterprise license
Included in WAVE-274-K9 base configuration
Yes
Optional
WAAS-VIDEO-WMAPL
Cisco WAAS Video license for Microsoft Windows Media Live streaming
Requires WAASENT-APL and SFWAAS-4.1-K9 selection
Yes
Optional
WAAS-VB-W2K8-LIC
Microsoft Windows Server 2008 on Cisco WAAS with Cisco WAAS Virtual Blade license
Requires WAASENT-APL and SFWAAS-4.1-K9 selection; Microsoft Windows Server 2008 rescue CD is included
Yes
Optional
WAAS-VB-LIC
Cisco WAAS Virtual Blade license only
Requires WAASENT-APL and SFWAAS-4.1-K9 selection
Yes
© 2009 Cisco Systems, Inc. Cisco Confidential/Proprietary—Pricing for illustration purposes only. Pricing subject to change. April 20, 2009
No
Page 7 of 20
Ordering Guide
Cisco WAVE-474 Ordering Information Table 4 provides ordering information and part numbers for the Cisco WAVE-474 appliance. Table 4.
Cisco WAVE-474 Appliance Ordering Information
Platform Model and Optio ns
Mandatory, Optio nal, or Auto-Expand
Part Number
Description
Cisco WAVE-474
Mandatory
WAVE-474-K9
Chassis with 3 GB RAM, 1 X 250-GB HDD, 2-port inline card, Cisco WAAS Enterprise license, and AC power supply
MNT-2PST-RACK
2-post rack shelf for Cisco WAVE-474
Notes
Available as Spare No
Hardware Options Mount options
Accessory kit
Power cable
Optional
No Select only one of these mount options, not both.
Optional
MNT-WALL-SLV
Wall sleeve mount for Cisco WAVE-474
Auto-Expand
AK-WAAS-HW
Hardware accessory kit
No
Auto-Expand
AK-WAAS-4.1-CD-K9
Cisco WAAS Software 4.1 CD recovery kit
No
Mandatory
Select appropriate cables from list.
Power cables
Product SKUs are self-explanatory.
No
No
Software Options Software version
Mandatory
SF-WAAS-4.1-K9
Cisco WAAS Software 4.1
No
Software license
Auto-Expand
WAAS-ENT-APL
Cisco WAAS Enterprise license
Included in WAVE-274-K9 base configuration
Yes
Optional
WAAS-VIDEO-WMAPL
Cisco WAAS Video license for Microsoft Windows Media Live streaming
Requires WAASENT-APL and SFWAAS-4.1-K9 selection
Yes
Optional
WAAS-VB-W2K8-LIC
Microsoft Windows Server 2008 on Cisco WAAS with Cisco WAAS Virtual Blade license
Requires WAASENT-APL and SFWAAS-4.1-K9 selection; Microsoft Windows Server 2008 rescue CD is included
Yes
Optional
WAAS-VB-LIC
Cisco WAAS Virtual Blade license only
Requires WAASENT-APL and SFWAAS-4.1-K9 selection
Yes
Cisco WAVE-574 Ordering Information Table 5 provides ordering information and part numbers for the Cisco WAVE-574 appliance. Table 5.
Cisco WAVE-574 Appliance Ordering Information
Platform Model and Optio ns
Mandatory, Optio nal, or Auto-Expand
Part Number
Description
Cisco WAVE-574
Mandatory
WAVE-574-K9
Chassis with 3 GB RAM, 1 X 500-GB HDD, Cisco WAAS Enterprise license, and AC power supply
DISK-SATA2-500GB
Additional 500-GB HDD
Notes
Available as Spare No
Hardware Options Hard disk
Optional
© 2009 Cisco Systems, Inc. Cisco Confidential/Proprietary—Pricing for illustration purposes only. Pricing subject to change. April 20, 2009
Select this part to get RAID-1 capability.
Yes
Page 8 of 20
Ordering Guide
Platform Model and Optio ns
Mandatory, Optio nal, or Auto-Expand
Part Number
Description
Notes
Available as Spare
Memory
Optional
MEM-WAVE-UPG
Memory upgrade for Cisco WAVE-574.
Select to get more T connections* and virtual blades.
Yes
PCI inline card
Optional
WAVE-INLN-2CG
2-port inline card
Select for inline deployment.
Yes
Optional
WAVE-INLN-4CG
4-port inline card
Select for inline deployment. This option s more than 1 WAN router.
Yes
Auto-Expand
AK-WAAS-HW
Hardware accessory kit
No
Auto-Expand
AK-WAAS-4.1-CD-K9
Cisco WAAS Software 4.1 CD recovery kit
No
Mandatory
Select appropriate cables from list.
Power cables
Accessory kit
Power cable
Product SKUs are self-explanatory.
No
Software Options Software version
Mandatory
SF-WAAS-4.1-K9
Cisco WAAS Software 4.1
No
Software license
Auto-Expand
WAAS-ENT-APL
Cisco WAAS Enterprise license
Included in WAVE-574-K9 part number
Yes
Optional
WAAS-VIDEO-WMAPL
Cisco WAAS Video license for Microsoft Windows Media Live streaming
Requires WAASENT-APL and SFWAAS-4.1-K9 selection
Yes
Optional
WAAS-VB-W2K8-LIC
Microsoft Windows Server 2008 on Cisco WAAS with Cisco WAAS Virtual Blade license
Requires WAASENT-APL and SFWAAS-4.1-K9 selection; Microsoft Windows Server 2008 rescue CD is included
Yes
Optional
WAAS-VB-LIC
Cisco WAAS Virtual Blade license only
Requires WAASENT-APL and SFWAAS-4.1-K9 selection
Yes
*Refer to the sizing guidelines and sizing tool for more information.
Cisco WAE-674 Ordering Information Table 6 provides ordering information and part numbers for the Cisco WAVE-674 appliance. Table 6.
Cisco WAVE-674 Appliance Ordering Information
Platform Model and Optio ns
Mandatory, Optio nal, or Auto-Expand
Part Number
Description
Cisco WAE674
Mandatory
WAE-674-K9
Chassis with 4 GB RAM, 3 X 300-GB HDDs, and AC power supply
Notes
Available as Spare No
Hardware Options Memory
Optional
MEM-WAE-4GB
Memory upgrade for Cisco WAE-674
Additional 4 GB RAM; select to get more T connections* and virtual blades
Yes
PCI inline card
Optional
WAE-INLN-4CG
4-port inline card
Select for inline deployment.
Yes
Accessory kit
Auto-Expand
AK-WAAS-HW
Hardware accessory kit
© 2009 Cisco Systems, Inc. Cisco Confidential/Proprietary—Pricing for illustration purposes only. Pricing subject to change. April 20, 2009
No
Page 9 of 20
Ordering Guide
Platform Model and Optio ns
Power cable
Mandatory, Optio nal, or Auto-Expand
Part Number
Description
Notes
Available as Spare
Auto-Expand
AK-WAAS-4.X-CD-K9
Cisco WAAS Software CD recovery kit
Recovery CD with the selected Cisco WAAS Software version
No
Mandatory
Select appropriate cables from list.
Power cables
Product SKUs are self-explanatory.
No
SF-WAAS-4.0-674-K9
Cisco WAAS Software 4.0
No
SF-WAAS-4.1-SAS-K9
Cisco WAAS Software 4.1
Select either Cisco WAAS Software 4.0 or 4.1 SKU, not both.
WAAS-ENT-APL
Cisco WAAS Enterprise license
Select only one license option.
Yes
WAAS-TRN-APL
Cisco WAAS Transport license
Yes
WAAS-CNTRL-MGR
Cisco WAAS Central Manager license
WAAS-CNTRLMGR is available only if SF-WAAS4.0-674-K9 is selected. For more information about the Central Manager license, see Table 2.
Optional
WAAS-VIDEO-WMAPL
Cisco WAAS Video license for Microsoft Windows Media Live streaming
Requires WAASENT-APL and SFWAAS-4.1-SASK9 selection
Yes
Optional
WAAS-VB-W2K8-LIC
Microsoft Windows Server 2008 on Cisco WAAS with Cisco WAAS Virtual Blade license
Requires WAASENT-APL and SFWAAS-4.1-SASK9 selection; Microsoft Windows Server 2008 rescue CD is included
Yes
Optional
WAAS-VB-LIC
Cisco WAAS Virtual Blade license only
Requires WAASENT-APL and SFWAAS-4.1-SASK9 selection
Yes
Software Options Software version
Mandatory
Software license
Mandatory
Software license
No
Yes
* Refer to the sizing guidelines and sizing tool for more information.
Cisco WAAS Appliances for Branch Office and Data Center Cisco WAE-512 Ordering Information Table 7 provides ordering information and part numbers for the Cisco WAE-512 appliance. Table 7.
Cisco WAE-512 Appliance Ordering Information
Platform Model and Optio ns
Mandatory, Optio nal, or Auto-Expand
Part Number
Description
Cisco WAE512
Mandatory
WAE-512-K9
Chassis with 1 GB RAM, 1 250-GB HDD, and AC power supply
Notes
Available as Spare No
Hardware Options Hard disk
Optional
DISK-SATA2-250GB
250-GB HDD
Select additional 250-GB HDD to get RAID-1 capability
Yes
Memory
Optional
MEM-WAE-1GB
Memory upgrade for Cisco WAE-512
Additional 1 GB RAM; select to get more T connections*
Yes
© 2009 Cisco Systems, Inc. Cisco Confidential/Proprietary—Pricing for illustration purposes only. Pricing subject to change. April 20, 2009
Page 10 of 20
Ordering Guide
Platform Model and Optio ns
Mandatory, Optio nal, or Auto-Expand
Part Number
Description
Notes
Available as Spare
PCI inline card
Optional
WAE-INLN-4CG
4-port inline card
Select for inline deployment
Yes
Accessory kit
Auto-Expand
AK-WAAS-HW
Hardware accessory kit
Auto-Expand
AK-WAAS-4.X-CD-K9
Cisco WAAS Software CD recovery kit
Recovery CD with the selected Cisco WAAS Software version
No
Mandatory
Select appropriate cables from list.
Power cables
Product SKUs are self-explanatory.
No
SF-WAAS-4.0-SA-K9
Cisco WAAS Software 4.0 Cisco WAAS Software 4.1
Select either the Cisco WAAS Software 4.0 or 4.1 version of these SKUs, not both.
No
SF-WAAS-4.1-SA-K9
WAAS-ENT-APL
Cisco WAAS Enterprise license
Select only one license option.
Yes
WAAS-TRN-APL
Cisco WAAS Transport license
Yes
WAAS-CNTRL-MGR
Cisco WAAS Central Manager license
WAAS-CNTRLMGR is available only if SF-WAAS4.0-SA-K9 is selected. For more information about the Central Manager license, see Table 2.
WAAS-VIDEO-WMAPL
Cisco WAAS Video license for Microsoft Windows Media Live streaming
Requires WAASENT-APL and SFWAAS-4.1-SA-K9 selection
Yes
Power cable
No
Software Options Software version
Mandatory
Software license
Mandatory
Software license
Optional
No
Yes
* Refer to the sizing guidelines and sizing tool for more information.
Cisco WAE-612 Ordering Information Table 8 provides ordering information and part numbers for the Cisco WAE-612 appliance. Table 8.
Cisco WAE-612 Appliance Ordering Information
Platform Model and Optio ns
Mandatory, Optio nal, or Auto-Expand
Part Number
Description
Notes
Available as Spare
Cisco WAE612
Mandatory
WAE-612-K9
Chassis with 2 GB RAM, 2 300-GB HDDs, and AC power supply
Provides RAID-1 capability
No
Hardware Options Memory
Optional
MEM-WAE-2GB
Memory upgrade for Cisco WAE-612
Additional 2 GB RAM; select to get more T connections*
Yes
PCI inline card
Optional
WAE-INLN-4CG
4-port inline card
Select for inline deployment.
Yes
Accessory kit
Auto-Expand
AK-WAAS-HW
Hardware accessory kit
Auto-Expand
AK-WAAS-4.X-CD-K9
Cisco WAAS Software CD recovery kit
Recovery CD with the selected Cisco WAAS Software version
No
Mandatory
Select appropriate cables from list.
Power cables
Product SKUs are self-explanatory.
No
Power cable
No
Software Options
© 2009 Cisco Systems, Inc. Cisco Confidential/Proprietary—Pricing for illustration purposes only. Pricing subject to change. April 20, 2009
Page 11 of 20
Ordering Guide
Platform Model and Optio ns
Mandatory, Optio nal, or Auto-Expand
Part Number
Description
Notes
Available as Spare
Software version
Mandatory
SF-WAAS-4.0-SS-K9
Cisco WAAS Software 4.0 Cisco WAAS Software 4.1
Select either the Cisco WAAS Software 4.0 or 4.1 version of these SKUs, not both.
No
SF-WAAS-4.1-SS-K9
Software license
Mandatory
WAAS-ENT-APL
Cisco WAAS Enterprise license
Select only one license option.
Yes
WAAS-TRN-APL
Cisco WAAS Transport license
Yes
WAAS-CNTRL-MGR
Cisco WAAS Central Manager license
WAAS-CNTRLMGR is available only if SF-WAAS4.0-SS-K9 is selected. For more information about the Central Manager license, see Table 2.
WAAS-VIDEO-WMAPL
Cisco WAAS Video license for Microsoft Windows Media Live streaming
Requires WAASENT-APL and SFWAAS-4.1-SS-K9 selection
Yes
Software license
Optional
No
Yes
* Refer to the sizing guidelines and sizing tool for more information.
Cisco WAE-7341 Ordering Information Table 9 provides ordering information and part numbers for the Cisco WAE-7341 appliance. Table 9.
Cisco WAE-7341 Appliance Ordering Information
Platform Model and Optio ns
Mandatory, Optio nal, or Auto-Expand
Part Number
Description
Cisco WAE7341
Mandatory
WAE-7341-K9
Chassis with 12 GB RAM, HDD, and AC power supply
Notes
Available as Spare No
Hardware Options PCI inline card
Optional
WAE-INLN-4CG
4-port inline card
Accessory kit
Auto-Expand
AK-WAAS-HW
Hardware accessory kit
Auto-Expand
AK-WAAS-4.X-CD-K9
Cisco WAAS Software CD recovery kit
Recovery CD with the selected Cisco WAAS Software version
No
Mandatory
Select appropriate cables from list.
Power cables
Product SKUs are self-explanatory.
No
SF-WAAS-4.0-K9
Cisco WAAS Software 4.0
No
SF-WAAS-4.1-SAS-K9
Cisco WAAS Software 4.1
Select either the Cisco WAAS Software 4.0 or 4.1 version of these SKUs, not both.
WAAS-ENT-APL
Cisco WAAS Enterprise license
Select only one license option.
Yes
WAAS-TRN-APL
Cisco WAAS Transport license
Yes
WAAS-CNTRL-MGR
Cisco WAAS Central Manager license
WAAS-CNTRLMGR is available only if SF-WAAS4.0-K9 is selected. For more information about the Central Manager license, see Table 2.
Power cable
Select for inline deployment.
Yes No
Software Options Software version
Mandatory
Software license
Mandatory
© 2009 Cisco Systems, Inc. Cisco Confidential/Proprietary—Pricing for illustration purposes only. Pricing subject to change. April 20, 2009
No
Yes
Page 12 of 20
Ordering Guide
Platform Model and Optio ns
Mandatory, Optio nal, or Auto-Expand
Part Number
Description
Notes
Available as Spare
Software license
Optional
WAAS-VIDEO-WMAPL
Cisco WAAS Video license for Microsoft Windows Media Live streaming
Requires WAASENT-APL and SFWAAS-4.1-SASK9 selection
Yes
Cisco WAE-7371 Ordering Information Table 10 provides ordering information and part numbers for the Cisco WAE-7371 appliance. Table 10.
Cisco WAE-7371 Appliance Ordering Information
Platform Model and Optio ns
Mandatory, Optio nal, or Auto-Expand
Part Number
Description
Cisco WAE7371
Mandatory
WAE-7371-K9
Chassis with 24 GB RAM, HDD, and AC power supply
Notes
Available as Spare No
Hardware Options PCI inline card
Optional
WAE-INLN-4CG
4-port inline card
Accessory kit
Auto-Expand
AK-WAAS-HW
Hardware accessory kit
Auto-Expand
AK-WAAS-4.X-CD-K9
Cisco WAAS Software CD recovery kit
Recovery CD with the selected Cisco WAAS Software version
No
Mandatory
Select appropriate cables from list.
Power cables
Product SKUs are self-explanatory.
No
SF-WAAS-4.0-K9
Cisco WAAS Software 4.0
No
SF-WAAS-4.1-SAS-K9
Cisco WAAS Software 4.1
Select either the Cisco WAAS Software 4.0 or 4.1 version of these SKUs, not both.
WAAS-ENT-APL
Cisco WAAS Enterprise license
Select only one license option.
Yes
WAAS-TRN-APL
Cisco WAAS Transport license
Yes
WAAS-CNTRL-MGR
Cisco WAAS Central Manager license
WAAS-CNTRLMGR is available only if SF-WAAS4.0-K9 is selected. For more information about the Central Manager license, see Table 2.
WAAS-VIDEO-WMAPL
Cisco WAAS Video license for Microsoft Windows Media Live streaming
Requires WAASENT-APL and SFWAAS-4.1-SASK9 selection
Yes
Power cable
Select for inline deployment.
Yes No
Software Options Software version
Mandatory
Software license
Mandatory
Software license
Optional
No
Yes
for the Cisco WAE and Cisco WAVE hardware is offered through the Cisco SMARTnet contract program. The available Cisco SMARTnet options are displayed on the Dynamic Configuration Tool when you click Check Configuration. To add service, you should use the Multiline Configurator Tool. Properly configured Cisco WAAS products include both Cisco SMARTnet and SASU service. The Dynamic Configuration Tool includes only one type of service: either Cisco SMARTnet or software , but not both. Hardware : Cisco SMARTnet Contract The Cisco WAE and Cisco WAVE platforms are all covered by Cisco’s standard 90-day warranty. For additional Cisco Technical Assistance Center (TAC) and hardware , the customer © 2009 Cisco Systems, Inc. Cisco Confidential/Proprietary—Pricing for illustration purposes only. Pricing subject to change. April 20, 2009
Page 13 of 20
Ordering Guide
should order Cisco Technical Services. Note that after you complete the configuration and click Check Configuration on the Dynamic Configuration Tool, appropriate Cisco SMARTnet SKUs are included based on the hardware service levels selected. Table 11 lists the services available for the Cisco WAE and Cisco WAVE platforms through the Cisco SMARTnet program. Table 11.
Cisco SMARTnet Services for Cisco WAE and Cisco WAVE
Part Number
Description
Price
CON-SNT-WAV274K
Cisco SMARTnet 8x5xNBD WAVE-274
US$100
CON-SNT-WAV474K
Cisco SMARTnet 8x5xNBD WAVE-474
US$304
CON-SNT-WAE512
Cisco SMARTnet 8x5xNBD WAE-512
US$480
CON-SNT-WAV574K
Cisco SMARTnet 8x5xNBD WAVE-574
US$480
CON-SNT-WAE612
Cisco SMARTnet 8x5xNBD WAE-612
US$1104
CON-SNT-WAE674K9
Cisco SMARTnet 8x5xNBD WAE-674
US$1280
CON-SNT-WAE7341
Cisco SMARTnet 8x5xNBD WAE-7341
US$4240
CON-SNT-WAE7371
Cisco SMARTnet 8x5xNBD WAE-7371
US$10,320
CON-SNTE-WAV274K
Cisco SMARTnet 8x5x4 WAVE-274
US$145
CON-SNTE-WAV474K
Cisco SMARTnet 8x5x4 WAVE-474
US$441
CON-SNTE-WAE512
Cisco SMARTnet 8x5x4 WAE-512
US$696
CON-SNTE-WAV574K
Cisco SMARTnet 8x5x4 WAVE-512
US$696
CON-SNTE-WAE612
Cisco SMARTnet 8x5x4 WAE-612
US$1601
CON-SNTE-WAE674K9
Cisco SMARTnet 8x5x4 WAE-674
US$1856
CON-SNTE-WAE7341
Cisco SMARTnet 8x5x4 WAE-7341
US$6148
CON-SNTE-WAE7371
Cisco SMARTnet 8x5x4 WAE-7371
US$14964
CON-SNTP-WAV274K
Cisco SMARTnet 24x7x4 WAVE-274
US$160
CON-SNTP-WAV474K
Cisco SMARTnet 24x7x4 WAVE-474
US$486
CON-SNTP-WAE512
Cisco SMARTnet 24x7x4 WAE-512
US$768
CON-SNTP-WAV574K
Cisco SMARTnet 24x7x4 WAVE-574
US$768
CON-SNTP-WAE612
Cisco SMARTnet 24x7x4 WAE-612
US$1766
CON-SNTP-WAE674K9
Cisco SMARTnet 24x7x4 WAE-674
US$2048
CON-SNTP-WAE7341
Cisco SMARTnet 24x7x4 WAE-7341
US$6784
CON-SNTP-WAE7371
Cisco SMARTnet 24x7x4 WAE-7371
US$16,512
CON-S2P-WAV274K
Cisco SMARTnet 24x7x2 WAVE-274
US$213
CON-S2P-WAV474K
Cisco SMARTnet 24x7x2 WAVE-474
US$646
CON-S2P-WAE512
Cisco SMARTnet 24x7x2 WAE-512
US$1020
CON-S2P-WAV574K
Cisco SMARTnet 24x7x2 WAVE-574
US$1020
CON-S2P-WAE612
Cisco SMARTnet 24x7x2 WAE-612
US$2346
CON-S2P-WAE674K9
Cisco SMARTnet 24x7x2 WAE-674
US$2720
CON-S2P-WAE7341
Cisco SMARTnet 24x7x2 WAE-7341
US$9010
CON-S2P-WAE7371
Cisco SMARTnet 24x7x2 WAE-
US$21,930
Cisco SMARTnet 8x5xNBD*
Cisco SMARTnet 8x5x4
Cisco SMARTnet 24x7x4
Cisco SMARTnet 24x7x2
* NBD: Next business day
© 2009 Cisco Systems, Inc. Cisco Confidential/Proprietary—Pricing for illustration purposes only. Pricing subject to change. April 20, 2009
Page 14 of 20
Ordering Guide
Software : SASU Contract Customers who want for the Cisco WAAS Software must purchase Software Application (SAS) or Software Applications with Upgrades (SAU) contracts. These contracts must be ordered separately and are not part of the product configuration on the Dynamic Configuration Tool. When virtual blade is ordered, the Multi-line Configurator Tool will include only one of the software part numbers (CON-SAU-WAASENAP or CON-SASWAASVBL). The missing software part number should be quoted separately. Table 12 lists the SASU contracts for Cisco WAAS Software. Table 12.
Cisco WAAS and Cisco WAAS Mobile Software SASU Contracts
Part Number
Description
Price
CON-SAU-WAASTRAP
SASU for Cisco WAAS Transport license for 1 Cisco WAE or Cisco WAVE appliance
US$200
CON-SAU-WAASENAP
SASU for Cisco WAAS Enterprise license for 1 Cisco WAE or Cisco WAVE appliance
US$500
CON-SAS-WAASVBL
Software application for Cisco WAAS Virtual Blade license
US$300
CON-SAS-WAASVBW2
Software application for Microsoft Windows Server 2008 for Microsoft Active Directory, Domain Name System (DNS), Dynamic Host Control Protocol (DH), and print only
US$525
SP-SAS-WAASVBL
Service provider (SP) SAS Cisco WAAS Virtual Blade license
US$300
SP-SAS-WAASVBW2
SP SAS plus Microsoft Windows Server 2008 for Microsoft Active Directory, DNS, DH, and print only
US$525
SP-SAU-WAASMBLS
SP SAU Cisco WAAS Mobile server software
US$1000
SP-SAU-WAASL25
SP SAU Cisco WAAS Mobile 25 concurrent licenses
US$1750
SP-SAU-WAASL100
SP SAU Cisco WAAS Mobile 100 concurrent licenses
US$6800
SP-SAU-WAASL500
SP SAU Cisco WAAS Mobile 500 concurrent licenses
US$32,500
Note that no SASU contract is available or required for the Cisco WAAS Central Manager license in WAAS 4.0. You need only the Cisco SMARTnet contract on the Cisco WAAS appliance running the Cisco WAAS Central Manager.
O rde ri ng St e ps f or Ci s c o W A AS N et w ork M odul es There are three SKUs for the Cisco WAAS network modules, listed in Table 13. The list price is the standalone hardware price. It does not include software or reflect bundle pricing. For accurate prices, please refer to the price list. For bundles, please refer to the Cisco WAAS FY09 Bundles Ordering Information section for more information. Table 13.
Ordering Information for Cisco WAAS Network Modules
Part Number
Description
Price
NME-WAE-522-K9
Cisco WAAS network module for Cisco 3800 Series Integrated Services Routers only; 2 GB RAM and 160-GB HDD
US$9000
NME-WAE-502-K9
Cisco WAAS network module for Cisco 2800 and 3800 Series Integrated Services Routers; 1 GB RAM and 120-GB HDD
US$6500
NME-WAE-302-K9
Cisco WAAS network module for Cisco Integrated Services Routers (s only Transport license); 512 MB RAM and 80-GB HDD
US$3750
The Cisco WAAS NME-WAE network modules can be ordered in three ways.
© 2009 Cisco Systems, Inc. Cisco Confidential/Proprietary—Pricing for illustration purposes only. Pricing subject to change. April 20, 2009
Page 15 of 20
Ordering Guide
Cisco WAAS NME-WAE Spares To order the Cisco WAAS NME-WAE as a spare, follow these steps: 1.
2.
3.
Enter the appropriate spare product part number in the Dynamic Configuration Tool: ●
NME-WAE-522-K9=
●
NME-WAE-502-K9=
●
NME-WAE-302-K9=
Select one of the Cisco WAAS Software options (mandatory): ●
SF-WAAS-4.0-NM-K9
●
SF-WAAS-4.1-NM-K9
Select one of these Cisco WAAS Software licenses (mandatory): ●
WAAS-ENT-NM (Cisco WAAS Enterprise license for NME-WAE-502-K9 and NME-WAE522-K9)
●
4.
WAAS-TRN-NM (Cisco WAAS Transport license for all three network modules)
Select a Cisco WAAS Software license option (optional): ●
WAAS-WMVID-NM (Cisco WAAS Video license for Microsoft Windows Media Live streaming; requires selection of WAAS-ENT-NM)
Cisco WAAS NME-WAE and Cisco Integrated Services Routers WAN Optimization Bundles The WAN optimization bundles include the Cisco WAAS network module and the Cisco Integrated Services Router at discounted prices. NME-WAE-502-K9 Bundles Five WAN optimization bundles are available for the NME-WAE-502-K9: ●
The bundles with the Cisco 2800 Series routers include the NME-WAE-502-K9, the Cisco ®
Integrated Services Router (Cisco 2811, 2821, or 2851), and the Cisco IOS Software advanced security image. ●
The bundles with the Cisco 3800 Series routers include the NME-WAE-502-K9, the Cisco Integrated Services Router (Cisco 3825 or 3845), Cisco IOS advanced security image, 256 to 512 MB RAM upgrade, and 64 to 128 MB compact flash memory upgrade.
●
The bundles are priced with the Cisco WAAS Transport license and offer a discounted the Cisco WAAS Enterprise license while configuring the bundle.
Table 14 provides ordering information for NME-WAE-502-K9 bundles. Table 14.
Ordering Information for NME-WAE-502-K9 WAN Optimization Bundles
Cisco Integrated Services Routers WA N O pti mizat ion Bund le
Bund le w ith Transport License
Bund le w ith Enterprise License
CISCO2811-WAE/K9
US$8,365
US$10,615
CISCO2821-WAE/K9
US$9,700
US$11,966
CISCO2851-WAE/K9
US$11,900
US$14,172
CISCO3825-WAE/K9
US$15,800
US$18,800
US$18,000
US$21,000
Incl. 128 MB Compact Flash and 512 MB RAM CISCO3845-WAE/K9 Incl. 128 MB Compact Flash and 512 MB RAM
© 2009 Cisco Systems, Inc. Cisco Confidential/Proprietary—Pricing for illustration purposes only. Pricing subject to change. April 20, 2009
Page 16 of 20
Ordering Guide
To order the WAN optimization bundles, follow these steps: 1.
Select the bundle based on the router you are ordering.
2.
In the router software options, select the Cisco IOS Software image IP BASEK9 or later and Cisco IOS Software Release 12.409T or later.
3.
For the Cisco WAAS Software license, select one of the options listed in Table 15.
Table 15.
Cisco WAAS Software License Options for WAN Optimization Bundles
Part Number
Description
Price
WAAS-ENT-NM-BUN
Cisco WAAS Enterprise license for 1 NME-WAE-502-K9 or NME-WAE-522-K9 network module
US$3000
WAAS-TRN-NM
Cisco WAAS Transport license for 1 network module
Included
WAAS-VIDEO-WM-NM
Cisco WAAS Video license for Microsoft Windows Live streaming
US$2500
4.
Select any other options that you want to order, such as any security options, voice features, or add-on cards or modules; these options can be configured under the bundle just as you would if you were configuring the router.
5.
If you select a Cisco 3800 Series bundle, under Network Module Options you will see the Cisco WAAS network modules listed again. Select another module only if you want two Cisco WAAS network modules for the same router. Usually a second WAAS network module is not needed on the same router.
6.
Select the appropriate power cord.
NME-WAE-302-K9 Bundles One bundle is available for the NME-WAE-302-K9, listed in Table 16. Table 16.
Ordering Information for NME-WAE-302-K9 WAN Optimization Bundle
Cisco Integrated Services Routers WA N O pti mizat ion Bu ndle
Bund le w ith Transport L icense
C2811-WAE-302/K9
US$5955
There is no option to the Cisco WAAS Enterprise license since the NME-WAE-302-K9 does not this license. Configure this bundle as described for the NME-WAE-502-K9 bundles. NME-WAE Configured Under the Router or Other Bundles The Cisco WAAS NME-WAE can be selected and configured under the Cisco 2800 or 3800 Series routers or added to other Cisco Integrated Services Routers bundles in the following way: 1.
Select the router or bundle you want to configure.
2.
Expand the network module options and select the NME-WAE-502-K9 or NME-WAE-302-K9 in the options pane.
3.
Expand the NME-WAE in the item category pane. a. Select the Cisco WAAS Software version desired. b. Select the Cisco WAAS Software license. You can choose between the Transport and Enterprise licenses for the NME-WAE-502-K9. c. Optionally, choose the Cisco WAAS Video license (Microsoft Windows Media Live video). This option is available only if the Enterprise license is selected.
© 2009 Cisco Systems, Inc. Cisco Confidential/Proprietary—Pricing for illustration purposes only. Pricing subject to change. April 20, 2009
Page 17 of 20
Ordering Guide
for Network Modules Full hardware and software for the Cisco WAAS network modules is provided by the purchase of the Cisco SMARTnet contract for the Cisco Integrated Services Router on which the module is deployed. No additional contracts are required.
O rde ri ng St e ps f or Ci s c o W A AS M obil e The Cisco WAAS Mobile solution requires Cisco WAAS Mobile server software and the concurrent licenses. Cisco WAAS Mobile server software is installed on a standard Microsoft Windows Server 2003; no hardware is shipped from Cisco. Please refer to the guide for server hardware requirements: http://www.cisco.com/en/US/products/ps9523/products_installation_and_configuration_guides_list. html Please select the Cisco WAAS Mobile server software (WAAS-MBL-SRV) and at least one concurrent license to complete the configuration. Concurrent licenses can also be ordered as spares.
O rde ri ng St e ps f or Ci s c o W A AS FY 09 Prom oti ons There are four bundle SKUs for the Cisco WAAS FY09 Promotions, listed in Table 17. The list price is the price for the entire bundle and cannot be modified to exclude any components. Table 17.
Cisco WAAS FY09 Bundles
Part Number
Description
Price
WAAS-VB-VID-PROMO
• Cisco WAAS Video license for Microsoft Windows Media Live Streaming
US$2500
• Cisco WAAS Virtual Blade license NME-WAE-VID-SM-K9
• NME-WAE-502-K9 network module
US$9000
• Cisco WAAS Enterprise license • Cisco WAAS Video license for Microsoft Windows Media Live Streaming NME-WAE-VID-LG-K9
• NME-WAE-522-K9 network module
US$10,000
• Cisco WAAS Enterprise license • Cisco WAAS Video license for Microsoft Windows Media Live Streaming NME-WAE-AXP-LG-K9
• NME-WAE-522-K9 network module
US$12,500
• Cisco WAAS Enterprise license • Cisco WAAS Video license for Microsoft Windows Media Live Streaming • NME-502-APPRE-K9 network module • Cisco Application eXtension Platform (AXP) software CISCO2811-WAE/K9 CISCO2821-WAE/K9
• Cisco 2800 Series Integrated Services Routers (ISRs) Bundle
CISCO2851-WAE/K9
• NME-WAE-502 network module
Free Video license with purchase of Cisco WAAS Enterprise license
• Cisco WAAS Enterprise license with Cisco WAAS Video license for Microsoft Windows Media Live Streaming CISCO3825-WAE/K9 CISCO3845-WAE/K9
• Cisco 3800 Series Integrated Services Routers (ISRs) Bundle • NME-WAE-502 network module
Free Video license with purchase of Cisco WAAS Enterprise license
• Cisco WAAS Enterprise license with Cisco WAAS Video license for Microsoft Windows Media Live Streaming
© 2009 Cisco Systems, Inc. Cisco Confidential/Proprietary—Pricing for illustration purposes only. Pricing subject to change. April 20, 2009
Page 18 of 20
Ordering Guide
Cisco WAAS FY09 Promotion Bundles Ordering Information Table 18 provides ordering information and part numbers for the promotional bundles. Bundle components that are listed in the Parts Included column are auto-expanded and do not need any additional configuration. Table 18.
Cisco WAAS FY09 Promotion Bundles Ordering Information
Part Number
WAAS-VB-VID-PROMO
App licable Platforms
Parts Included (Au to Expanded)
Description
WAVE-274-K9
WAAS-VIDEO-WM-APL WAAS-VB-LIC
Available as an option under the software license section in the configuration tool
Yes
WAVE-474-K9
Same configuration steps as for the NME-WAE-502-K9
Yes
Same configuration steps as for the NME-WAE-522-K9
Yes
Same configuration steps as for the NME-WAE-522-K9
Yes
Same configuration steps as for the NME-WAE-502-K9
–
Same configuration steps as for the NME-WAE-502-K9
–
WAVE-574-K9
Available as Spare
WAE-674-K9 NME-WAE-VID-SM-K9
NME-WAE-VID-LG-K9
NME-WAE-AXP-LG-K9
Cisco 2800 and 3800 Series Integrated Service Routers
NME-WAE-502-K9
Cisco 3800 Series Integrated Service Routers
NME-WAE-522-K9
Cisco 3800 Series Integrated Service Routers
NME-WAE-522-K9
WAAS-ENT-NM WAAS-VIDEO-WM-NM
WAAS-ENT-NM WAAS-VIDEO-WM-NM
WAAS-ENT-NM WAAS-VIDEO-WM-NM NME-APPRE-502-K9 SN-AXP-1.1-K9
CISCO2811-WAE/K9 CISCO2821-WAE/K9 CISCO2851-WAE/K9
Cisco 2800 Series Integrated Service Routers
Cisco 2800 Series ISR NME-WAE-502-K9 WAAS-ENT-NM WAAS-VIDEO-WM-NM
CISCO3825-WAE/K9 CISCO3845-WAE/K9
Cisco 3800 Series Integrated Service Routers
Cisco 3800 Series ISR NME-WAE-502-K9 WAAS-ENT-NM WAAS-VIDEO-WM-NM
Addi ti onal R es ource s This document is meant to be a guide for configurations and pricing. The latest and most accurate information is always online in the pricing and configuration tools. In the event of any discrepancy between what is contained in this document and online in the tools, the tools should be used as the ultimate source of information. ●
Cisco Dynamic Configuration Tool: http://www.cisco.com/appcontent/apollo/configureHomeGuest.html
●
Cisco WAE global price list: http://www.cisco.com/cgibin/front.x/pricing?ProductFamilyId=40950&Page=ViewCurrProdFamilyPage&ProductFamil y=Cisco+Wide+Area+Application+Engine& Request=ViewCurrentProdPriceList&PriceListId=889
●
Cisco WAAS Software Version 4.1 data sheet: http://www.cisco.com/en/US/prod/collateral/contnetw/ps5680/ps6870/data_sheet_c78445372.html
●
Cisco WAAS appliances data sheet: http://www.cisco.com/en/US/products/ps6474/products_data_sheets_list.html
© 2009 Cisco Systems, Inc. Cisco Confidential/Proprietary—Pricing for illustration purposes only. Pricing subject to change. April 20, 2009
Page 19 of 20
Ordering Guide
●
Cisco WAAS appliance overview slide (internal source: WAAS Sales Rack, in “Sales Guides” section): http://wwwintools.cisco.com/sales/go/salesrack/products/sw/contnetw/ps6870
●
Cisco WAAS Software Version 4.1 sizing guidelines (internal source: Cisco WAAS Sales Rack, in “Sales Guides” section): http://wwwintools.cisco.com/sales/go/salesrack/products/sw/contnetw/ps6870
●
Cisco WAAS Mobile data sheet: http://www.cisco.com/en/US/products/ps9523/products_data_sheets_list.html
●
Cisco WAAS Mobile sizing guidelines: http://zed.cisco.com/confluence/display/WAAS/WAAS+Mobile
Printed in USA
© 2009 Cisco Systems, Inc. Cisco Confidential/Proprietary—Pricing for illustration purposes only. Pricing subject to change. April 20, 2009
C07-532535-00 04/09
Page 20 of 20
For further information, questions, and comments, please : [email protected].
© 2009 Cisco Systems, Inc. Cisco Confidential/Proprietary—Pricing for illustration purposes only. Pricing subject to change. April 20, 2009
Ordering Guide
Contents Overview ................................................................................................................................................. 3 Platforms ................................................................................................................................................ 3 Ordering Steps for Cisco WAVE and WAE Appliances .................................................................. 4 Options ................................................................................................................................. 5 Hardware and Software Options ....................................................................................................... 5
Hardware Options by Device....................................................................................................... 5 Software Options by Device ........................................................................................................ 5 Options Available as Spares ............................................................................................................. 6 Ordering Differences Between Cisco WAAS Software Versions 4.0 and 4.1 ................................ 6 Ordering Information by Platform ...................................................................................................... 6 Virtualization-Capable Cisco WAAS Appliances for the Branch Office .......................................... 7
Cisco WAVE-274 Ordering Information .................................................................................... 7 Cisco WAVE-474 Ordering Information .................................................................................... 8 Cisco WAVE-574 Ordering Information .................................................................................... 8 Cisco WAE-674 Ordering Information ....................................................................................... 9 Cisco WAAS Appliances for Branch Office and Data Center........................................................ 10
Cisco WAE-512 Ordering Information ..................................................................................... 10 Cisco WAE-612 Ordering Information ..................................................................................... 11 Cisco WAE-7341 Ordering Information................................................................................... 12 Cisco WAE-7371 Ordering Information................................................................................... 13 ............................................................................................................................................. 13
Hardware : Cisco SMARTnet Contract ....................................................................... 13 Software : SASU Contract ............................................................................................ 15 Ordering Steps for Cisco WAAS Network Modules....................................................................... 15 Cisco WAAS NME-WAE Spares ..................................................................................................... 16 Cisco WAAS NME-WAE and Cisco Integrated Services Routers WAN Optimization Bundles .. 16
NME-WAE-502-K9 Bundles..................................................................................................... 16 NME-WAE-302-K9 Bundles..................................................................................................... 17 NME-WAE Configured Under the Router or Other Bundles.................................................. 17 for Network Modules .......................................................................................................... 18 Ordering Steps for Cisco WAAS Mobile.......................................................................................... 18 Ordering Steps for Cisco WAAS FY09 Promotions....................................................................... 18
Cisco WAAS FY09 Promotion Bundles Ordering Information.............................................. 19 Additional Resources ......................................................................................................................... 19
© 2009 Cisco Systems, Inc. Cisco Confidential/Proprietary—Pricing for illustration purposes only. Pricing subject to change. April 20, 2009
Page 2 of 20
Ordering Guide
O ve rvie w ®
Cisco Wide Area Application Services (WAAS) products are ordered with products from one of following Cisco product families: ●
Cisco Wide Area Virtualization Engine (WAVE) appliance family
●
Cisco Wide Area Application Engine (WAE) appliance family
●
Cisco WAAS NME-WAE Network Module family for Cisco Integrated Services Routers
This document describes how to configure and order these products, including both hardware and software options. This document does not provide detailed pricing or sizing information, though some preliminary information may be included in certain sections of this document. This document also does not provide ordering information related to return material authorization (RMA) requests. Note:
All prices mentioned are list prices in U.S. dollars and are based on the global price list.
Please refer to the Cisco Online Pricing Tool for accurate prices. Please see the detailed sizing guidelines in the Cisco WAAS Sales Rack for specific platform recommendations.
Plat f orms Cisco WAAS products must be ordered with the appliances or network modules listed in Table 1. Network modules are available on a stand-alone basis or as part of Cisco Integrated Services Routers bundles. The list price includes both Cisco WAAS hardware and software. In the Cisco WAE Appliances and Cisco WAAS NME-WAE module families, Cisco WAAS Software needs to be added to the hardware SKU separately. In the recently introduced Cisco WAVE platforms, the Cisco WAAS Enterprise software license is included by default for easier configuration. Table 1.
Cisco WAAS Product Line: Appliances and Network Modules
Model
Maximum T Connectio ns*
Description
Starting Solut ion List Price (Hardware plus Software)
Network Modules in Cisco Integrated Services Routers for Branch Office NME-WAE-302-K9
250
Network module for Cisco Integrated Services Routers; s only Cisco WAAS Transport license
US$3750**
NME-WAE-502-K9
500
Network module for Cisco Integrated Services Routers; s Cisco WAAS Transport and Enterprise licenses
US$9500
NME-WAE-522-K9
800
Network module for Cisco Integrated Services Routers; s Cisco WAAS Transport and Enterprise licenses
US$12,000
Virtualization-Capable Cisco WAAS Appliances*** for Branch Office WAVE-274-K9
200
● Cisco WAVE-274 with chassis with 3 GB SDRAM. 250- US$6500 GB hard disk drive (HDD), 2-port inline module, and AC power supply; Cisco WAAS Enterprise license included ● No additional hardware upgrade options available
WAVE-474-K9
400
● Cisco WAVE-474 with chassis with 3 GB SDRAM, 250- US$9900 GB HDD, 2-port inline module, and AC power supply; Cisco WAAS Enterprise license included ● No additional hardware upgrade options available
WAVE-574-K9
750 - 1300
● Cisco WAVE-574 with chassis with 3 GB SDRAM, 500- US$12,500 GB HDD, and AC power supply; Cisco WAAS Enterprise license included ● Additional memory options and HDD available for higher optimized T connection count, increased number of virtual blades, and RAID-1 redundancy
© 2009 Cisco Systems, Inc. Cisco Confidential/Proprietary—Pricing for illustration purposes only. Pricing subject to change. April 20, 2009
Page 3 of 20
Ordering Guide
Model
Maximum T Connectio ns*
Description
Starting Solut ion List Price (Hardware plus Software)
WAE-674-K9
2000 - 6000
● Cisco WAE-674, 4 GB,SDRAM and 3 X 300-GB HDDs, US$22,000 and AC power supply; RAID-5 redundancy included ● Additional memory available for higher optimized T connection count and increased number of virtual blades ● Additional redundant power and cooling options available for data center deployment
Cisco WAAS Appliances for Branch Office and Data Center WAE-512-K9
750 - 1500
● Cisco WAE-512 with chassis with 1 GB SDRAM, 1 250-GB HDD, and AC power supply ● Additional memory and HDDs available for higher optimized T connection count and RAID-1 redundancy; virtual blades are not ed
US$12,500
WAE-612-K9
2000 - 6000
● Cisco WAE-612 with chassis with 2 GB SDRAM, 2 300-GB HDDs, and AC power supply ● Additional memory option available for higher optimized T connection count and RAID-1 redundancy included; virtual blades are not ed
US$22,000
WAE-7341-K9
12,000
● Cisco WAE-7341 includes 12 GB RAM, 4 X 300-GB HDDs, and 2 AC power supplies; RAID-5 redundancy included ● No additional hardware upgrade options available
US$59,000
WAE-7371-K9
50,000
● Cisco WAE-7371 includes 24 GB RAM, 6 X 300-GB HDDs, and 2 AC power supplies; RAID-5 redundancy included ● No additional hardware upgrade options available
US$135,000
Cisco WAAS Mobile Server and Client WAAS-MBL-SRVSW
Depends on hardware configuration****
● Cisco WAAS Mobile server software US$5000 ● Standard Microsoft Windows Server hardware required
WAAS-MBL-LIC25
25 concurrent s
● Cisco WAAS Mobile 25 concurrent licenses
US$8750
WAAS-MBL-LIC100
100 concurrent s
● Cisco WAAS Mobile 100 concurrent licenses
US$34,000
WAAS-MBL-LIC500
500 concurrent s
● Cisco WAAS Mobile 500 concurrent licenses
US$162,500
* Maximum number of T connections is presented only as a guideline. Please use detailed sizing information and guidelines that are available in the Cisco WAAS Sales Rack. ** NME-WAE-302-K9 s only the Cisco WAAS Transport license. *** All Cisco WAVE appliance SKUs include the Cisco WAAS Enterprise license for simplified configuration. The Cisco WAE Appliances family and Cisco WAAS NME-WAE module family need explicit configuration (that is, addition) of the Cisco WAAS Enterprise license. The list price in Table 1 reflects the starting price of the Cisco WAAS solution (including both hardware and software). **** Refer to the Cisco WAAS Mobile server hardware system requirements in the guide for hardware configuration.
O rde ri ng St e ps f or Ci s c o W AVE a nd WA E A ppli a nc es You can use either the Cisco Dynamic Configuration Tool or the Multi-line Configurator Tool to configure Cisco WAE Appliances with Cisco WAAS. When using the Dynamic Configuration Tool, follow these steps: 1.
Configure the Cisco WAVE, WAE, and NME-WAE devices with the appropriate software and hardware options.
2.
Click Check Configuration to validate the configuration. This action also displays available ®
Cisco SMARTnet SKUs.
© 2009 Cisco Systems, Inc. Cisco Confidential/Proprietary—Pricing for illustration purposes only. Pricing subject to change. April 20, 2009
Page 4 of 20
Ordering Guide
3.
Select the desired Cisco SMARTnet contract for hardware .
4.
Separately include the Software Application plus Upgrade (SASU) contract for software in the order.
Options options for Cisco WAE Appliances include Cisco SMARTnet for the hardware and SASU for the Cisco WAAS Software. The Multi-line Configurator Tool allows easy specification of both Cisco SMARTnet and SASU. With the Dynamic Configuration Tool, only Cisco SMARTnet can be specified as part of the configuration; the SASU contract needs to be separately included as part of the order. For SASU SKUs, see the section Software (SASU Contract). Hardware and Software Options The following hardware and software options are typically the most common. Not all options are listed here, and not all options may be available across all models. Details for each platform can be found in the tables in the section Ordering Information by Platform. Hardware Options by Device Not all hardware options are available on all models. ●
Memory
●
Hard disks
●
Peripheral Component Interconnect (PCI) inline card
●
Redundant power and cooling
Software Options by Device Not all software options are available on all models. ●
Cisco WAAS Software version; select only one option
◦ Cisco WAAS Software Version 4.0 ◦ Cisco WAAS Software Version 4.1 ●
Mandatory Cisco WAAS Software license; select only one option
◦ Cisco WAAS Enterprise license ◦ Cisco WAAS Transport license ◦ Cisco WAAS Central Manager license (applicable only with Cisco WAAS Software Version 4.0) ●
Optional (add-on) Cisco WAAS Software license (requires Cisco WAAS Enterprise license to be selected)
◦ Cisco WAAS Video license for Microsoft Windows Live video ◦ Cisco WAAS Virtual Blade license to create and enable virtual blades for branch-office services subject to appliance
◦ Microsoft Windows Server on Cisco WAAS with Virtual Blade license to create, enable, and install Microsoft Windows Server Core 2008 on a Cisco WAAS appliance (includes prepackaged Microsoft Windows Server Core 2008 software) The configurations listed here will be specified in the following sections with individual product SKUs on a per-platform basis.
© 2009 Cisco Systems, Inc. Cisco Confidential/Proprietary—Pricing for illustration purposes only. Pricing subject to change. April 20, 2009
Page 5 of 20
Ordering Guide
Options Available as Spares Some of the options listed in the preceding section are available as spares; you can order them separately on a standalone basis without the need to associate them with any base-platform SKU. The SKUs for spares display an = symbol at the end of the SKU name. If a particular option is not offered as a spare, the part is not available unless purchased along with a base-platform SKU. Ordering Differences Between Cisco WAAS Software Versions 4.0 and 4.1 This section covers the two high-level ordering differences when customers or partners order a platform with Cisco WAAS Software Version 4.1 instead of Cisco WAAS Software Version 4.0. ●
The Cisco WAVE platforms, Cisco WAVE-274, WAVE-474, and WAVE-574, include the Cisco WAAS Enterprise license by default. Thus, configuration is simplified for these platforms. Cisco WAVE platforms Cisco WAAS starting with Cisco WAAS Software Version 4.1.1.
●
For the Cisco WAAS NME-WAE network module and Cisco WAE Appliances families, the Cisco WAAS Enterprise license needs to be selected explicitly for Cisco WAAS Software Version 4.1 just as it does for Cisco WAAS Software Version 4.0.
●
There will be no standalone Cisco WAAS Central Manager license starting with Cisco WAAS Software Version 4.1; this license is included with the Cisco WAAS Enterprise license. The central manager functions will be available as a mode and require a Cisco WAAS Enterprise license. This change is applicable for all appliance platforms: both Cisco WAE and Cisco WAVE. This change reduces the number of license options that customers need to manage. Please note Cisco WAAS NME-WAE modules do not central manager functions with either Cisco WAAS Software Version 4.0 or 4.1. A platform configured in the central manager mode will allow customers to manage their Cisco WAAS deployments.
Table 2 summarizes the ordering differences between Cisco WAAS Software Versions 4.0 and 4.1. Table 2.
Main Ordering Differences Between Cisco WAAS Software Versions 4.0 and 4.1 Cisco W AAS S oftware Version 4.0
Cisco W AAS S oftware Version 4.1
Cisco WAAS Enterprise license
● Requires explicit selection for all platforms ● Platform configured with Enterprise license cannot be configured with any other software license
● Included by default for Cisco WAVE-274, WAVE-474, and WAVE-574 platforms; requires explicit selection for all other platforms ● Prerequisite for adding the optional software Video and Virtual Blade licenses on platforms that them
Cisco WAAS Central Manager license
● Requires explicit selection for all appliances ● Platform configured with Central Manager license cannot be configured with any other software license
● Standalone Central Manager license no longer applicable ● Central Manager function included as part of Cisco WAAS Enterprise license
Ordering Information by Platform This section provides platform-based ordering information. Hardware and software options are labeled as mandatory, optional, or auto-expand. ●
Mandatory: Selection of the relevant part number is required in the Dynamic Configuration Tool and Ordering Tool.
●
Optional: Selection of the relevant part number is up to discretion of the customer.
© 2009 Cisco Systems, Inc. Cisco Confidential/Proprietary—Pricing for illustration purposes only. Pricing subject to change. April 20, 2009
Page 6 of 20
Ordering Guide
●
Auto-expand: Selection of the relevant part number is not required because the part is automatically included at the end of the configuration process.
Virtualization-Capable Cisco WAAS Appliances for the Branch Office This section contains information about the Cisco WAAS appliances that hosting of branchoffice IT services on Cisco WAAS virtual blades. Cisco WAVE-274 Ordering Information Table 3 provides ordering information and part numbers for the Cisco WAVE-274 appliance. Table 3.
Cisco WAVE-274 Appliance Ordering Information
Platform Model and Optio ns
Mandatory, Optio nal, or Auto-Expand
Part Number
Description
Notes
Available as Spare
Cisco WAVE-274
Mandatory
WAVE-274-K9
Chassis with 3 GB RAM, 1 X 250-GB HDD, 2-port inline card, Cisco WAAS Enterprise license, and AC power supply
Optional
MNT-2PST-RACK
2-post rack shelf for Cisco WAVE-274
Optional
MNT-WALL-SLV
Wall sleeve mount for Cisco WAVE-274
Auto-Expand
AK-WAAS-HW
Hardware accessory kit
No
Auto-Expand
AK-WAAS-4.1-CD-K9
Cisco WAAS Software 4.1 CD recovery kit
No
Mandatory
Select appropriate cables from list.
Power cables
No
Hardware Options Mount options
Accessory kit
Power cable
Select only one of these mount options, not both.
Product SKUs are self-explanatory.
No No
No
Software Options Software version
Mandatory
SF-WAAS-4.1-K9
Cisco WAAS Software 4.1
Software license
Auto-Expand
WAAS-ENT-APL
Cisco WAAS Enterprise license
Included in WAVE-274-K9 base configuration
Yes
Optional
WAAS-VIDEO-WMAPL
Cisco WAAS Video license for Microsoft Windows Media Live streaming
Requires WAASENT-APL and SFWAAS-4.1-K9 selection
Yes
Optional
WAAS-VB-W2K8-LIC
Microsoft Windows Server 2008 on Cisco WAAS with Cisco WAAS Virtual Blade license
Requires WAASENT-APL and SFWAAS-4.1-K9 selection; Microsoft Windows Server 2008 rescue CD is included
Yes
Optional
WAAS-VB-LIC
Cisco WAAS Virtual Blade license only
Requires WAASENT-APL and SFWAAS-4.1-K9 selection
Yes
© 2009 Cisco Systems, Inc. Cisco Confidential/Proprietary—Pricing for illustration purposes only. Pricing subject to change. April 20, 2009
No
Page 7 of 20
Ordering Guide
Cisco WAVE-474 Ordering Information Table 4 provides ordering information and part numbers for the Cisco WAVE-474 appliance. Table 4.
Cisco WAVE-474 Appliance Ordering Information
Platform Model and Optio ns
Mandatory, Optio nal, or Auto-Expand
Part Number
Description
Cisco WAVE-474
Mandatory
WAVE-474-K9
Chassis with 3 GB RAM, 1 X 250-GB HDD, 2-port inline card, Cisco WAAS Enterprise license, and AC power supply
MNT-2PST-RACK
2-post rack shelf for Cisco WAVE-474
Notes
Available as Spare No
Hardware Options Mount options
Accessory kit
Power cable
Optional
No Select only one of these mount options, not both.
Optional
MNT-WALL-SLV
Wall sleeve mount for Cisco WAVE-474
Auto-Expand
AK-WAAS-HW
Hardware accessory kit
No
Auto-Expand
AK-WAAS-4.1-CD-K9
Cisco WAAS Software 4.1 CD recovery kit
No
Mandatory
Select appropriate cables from list.
Power cables
Product SKUs are self-explanatory.
No
No
Software Options Software version
Mandatory
SF-WAAS-4.1-K9
Cisco WAAS Software 4.1
No
Software license
Auto-Expand
WAAS-ENT-APL
Cisco WAAS Enterprise license
Included in WAVE-274-K9 base configuration
Yes
Optional
WAAS-VIDEO-WMAPL
Cisco WAAS Video license for Microsoft Windows Media Live streaming
Requires WAASENT-APL and SFWAAS-4.1-K9 selection
Yes
Optional
WAAS-VB-W2K8-LIC
Microsoft Windows Server 2008 on Cisco WAAS with Cisco WAAS Virtual Blade license
Requires WAASENT-APL and SFWAAS-4.1-K9 selection; Microsoft Windows Server 2008 rescue CD is included
Yes
Optional
WAAS-VB-LIC
Cisco WAAS Virtual Blade license only
Requires WAASENT-APL and SFWAAS-4.1-K9 selection
Yes
Cisco WAVE-574 Ordering Information Table 5 provides ordering information and part numbers for the Cisco WAVE-574 appliance. Table 5.
Cisco WAVE-574 Appliance Ordering Information
Platform Model and Optio ns
Mandatory, Optio nal, or Auto-Expand
Part Number
Description
Cisco WAVE-574
Mandatory
WAVE-574-K9
Chassis with 3 GB RAM, 1 X 500-GB HDD, Cisco WAAS Enterprise license, and AC power supply
DISK-SATA2-500GB
Additional 500-GB HDD
Notes
Available as Spare No
Hardware Options Hard disk
Optional
© 2009 Cisco Systems, Inc. Cisco Confidential/Proprietary—Pricing for illustration purposes only. Pricing subject to change. April 20, 2009
Select this part to get RAID-1 capability.
Yes
Page 8 of 20
Ordering Guide
Platform Model and Optio ns
Mandatory, Optio nal, or Auto-Expand
Part Number
Description
Notes
Available as Spare
Memory
Optional
MEM-WAVE-UPG
Memory upgrade for Cisco WAVE-574.
Select to get more T connections* and virtual blades.
Yes
PCI inline card
Optional
WAVE-INLN-2CG
2-port inline card
Select for inline deployment.
Yes
Optional
WAVE-INLN-4CG
4-port inline card
Select for inline deployment. This option s more than 1 WAN router.
Yes
Auto-Expand
AK-WAAS-HW
Hardware accessory kit
No
Auto-Expand
AK-WAAS-4.1-CD-K9
Cisco WAAS Software 4.1 CD recovery kit
No
Mandatory
Select appropriate cables from list.
Power cables
Accessory kit
Power cable
Product SKUs are self-explanatory.
No
Software Options Software version
Mandatory
SF-WAAS-4.1-K9
Cisco WAAS Software 4.1
No
Software license
Auto-Expand
WAAS-ENT-APL
Cisco WAAS Enterprise license
Included in WAVE-574-K9 part number
Yes
Optional
WAAS-VIDEO-WMAPL
Cisco WAAS Video license for Microsoft Windows Media Live streaming
Requires WAASENT-APL and SFWAAS-4.1-K9 selection
Yes
Optional
WAAS-VB-W2K8-LIC
Microsoft Windows Server 2008 on Cisco WAAS with Cisco WAAS Virtual Blade license
Requires WAASENT-APL and SFWAAS-4.1-K9 selection; Microsoft Windows Server 2008 rescue CD is included
Yes
Optional
WAAS-VB-LIC
Cisco WAAS Virtual Blade license only
Requires WAASENT-APL and SFWAAS-4.1-K9 selection
Yes
*Refer to the sizing guidelines and sizing tool for more information.
Cisco WAE-674 Ordering Information Table 6 provides ordering information and part numbers for the Cisco WAVE-674 appliance. Table 6.
Cisco WAVE-674 Appliance Ordering Information
Platform Model and Optio ns
Mandatory, Optio nal, or Auto-Expand
Part Number
Description
Cisco WAE674
Mandatory
WAE-674-K9
Chassis with 4 GB RAM, 3 X 300-GB HDDs, and AC power supply
Notes
Available as Spare No
Hardware Options Memory
Optional
MEM-WAE-4GB
Memory upgrade for Cisco WAE-674
Additional 4 GB RAM; select to get more T connections* and virtual blades
Yes
PCI inline card
Optional
WAE-INLN-4CG
4-port inline card
Select for inline deployment.
Yes
Accessory kit
Auto-Expand
AK-WAAS-HW
Hardware accessory kit
© 2009 Cisco Systems, Inc. Cisco Confidential/Proprietary—Pricing for illustration purposes only. Pricing subject to change. April 20, 2009
No
Page 9 of 20
Ordering Guide
Platform Model and Optio ns
Power cable
Mandatory, Optio nal, or Auto-Expand
Part Number
Description
Notes
Available as Spare
Auto-Expand
AK-WAAS-4.X-CD-K9
Cisco WAAS Software CD recovery kit
Recovery CD with the selected Cisco WAAS Software version
No
Mandatory
Select appropriate cables from list.
Power cables
Product SKUs are self-explanatory.
No
SF-WAAS-4.0-674-K9
Cisco WAAS Software 4.0
No
SF-WAAS-4.1-SAS-K9
Cisco WAAS Software 4.1
Select either Cisco WAAS Software 4.0 or 4.1 SKU, not both.
WAAS-ENT-APL
Cisco WAAS Enterprise license
Select only one license option.
Yes
WAAS-TRN-APL
Cisco WAAS Transport license
Yes
WAAS-CNTRL-MGR
Cisco WAAS Central Manager license
WAAS-CNTRLMGR is available only if SF-WAAS4.0-674-K9 is selected. For more information about the Central Manager license, see Table 2.
Optional
WAAS-VIDEO-WMAPL
Cisco WAAS Video license for Microsoft Windows Media Live streaming
Requires WAASENT-APL and SFWAAS-4.1-SASK9 selection
Yes
Optional
WAAS-VB-W2K8-LIC
Microsoft Windows Server 2008 on Cisco WAAS with Cisco WAAS Virtual Blade license
Requires WAASENT-APL and SFWAAS-4.1-SASK9 selection; Microsoft Windows Server 2008 rescue CD is included
Yes
Optional
WAAS-VB-LIC
Cisco WAAS Virtual Blade license only
Requires WAASENT-APL and SFWAAS-4.1-SASK9 selection
Yes
Software Options Software version
Mandatory
Software license
Mandatory
Software license
No
Yes
* Refer to the sizing guidelines and sizing tool for more information.
Cisco WAAS Appliances for Branch Office and Data Center Cisco WAE-512 Ordering Information Table 7 provides ordering information and part numbers for the Cisco WAE-512 appliance. Table 7.
Cisco WAE-512 Appliance Ordering Information
Platform Model and Optio ns
Mandatory, Optio nal, or Auto-Expand
Part Number
Description
Cisco WAE512
Mandatory
WAE-512-K9
Chassis with 1 GB RAM, 1 250-GB HDD, and AC power supply
Notes
Available as Spare No
Hardware Options Hard disk
Optional
DISK-SATA2-250GB
250-GB HDD
Select additional 250-GB HDD to get RAID-1 capability
Yes
Memory
Optional
MEM-WAE-1GB
Memory upgrade for Cisco WAE-512
Additional 1 GB RAM; select to get more T connections*
Yes
© 2009 Cisco Systems, Inc. Cisco Confidential/Proprietary—Pricing for illustration purposes only. Pricing subject to change. April 20, 2009
Page 10 of 20
Ordering Guide
Platform Model and Optio ns
Mandatory, Optio nal, or Auto-Expand
Part Number
Description
Notes
Available as Spare
PCI inline card
Optional
WAE-INLN-4CG
4-port inline card
Select for inline deployment
Yes
Accessory kit
Auto-Expand
AK-WAAS-HW
Hardware accessory kit
Auto-Expand
AK-WAAS-4.X-CD-K9
Cisco WAAS Software CD recovery kit
Recovery CD with the selected Cisco WAAS Software version
No
Mandatory
Select appropriate cables from list.
Power cables
Product SKUs are self-explanatory.
No
SF-WAAS-4.0-SA-K9
Cisco WAAS Software 4.0 Cisco WAAS Software 4.1
Select either the Cisco WAAS Software 4.0 or 4.1 version of these SKUs, not both.
No
SF-WAAS-4.1-SA-K9
WAAS-ENT-APL
Cisco WAAS Enterprise license
Select only one license option.
Yes
WAAS-TRN-APL
Cisco WAAS Transport license
Yes
WAAS-CNTRL-MGR
Cisco WAAS Central Manager license
WAAS-CNTRLMGR is available only if SF-WAAS4.0-SA-K9 is selected. For more information about the Central Manager license, see Table 2.
WAAS-VIDEO-WMAPL
Cisco WAAS Video license for Microsoft Windows Media Live streaming
Requires WAASENT-APL and SFWAAS-4.1-SA-K9 selection
Yes
Power cable
No
Software Options Software version
Mandatory
Software license
Mandatory
Software license
Optional
No
Yes
* Refer to the sizing guidelines and sizing tool for more information.
Cisco WAE-612 Ordering Information Table 8 provides ordering information and part numbers for the Cisco WAE-612 appliance. Table 8.
Cisco WAE-612 Appliance Ordering Information
Platform Model and Optio ns
Mandatory, Optio nal, or Auto-Expand
Part Number
Description
Notes
Available as Spare
Cisco WAE612
Mandatory
WAE-612-K9
Chassis with 2 GB RAM, 2 300-GB HDDs, and AC power supply
Provides RAID-1 capability
No
Hardware Options Memory
Optional
MEM-WAE-2GB
Memory upgrade for Cisco WAE-612
Additional 2 GB RAM; select to get more T connections*
Yes
PCI inline card
Optional
WAE-INLN-4CG
4-port inline card
Select for inline deployment.
Yes
Accessory kit
Auto-Expand
AK-WAAS-HW
Hardware accessory kit
Auto-Expand
AK-WAAS-4.X-CD-K9
Cisco WAAS Software CD recovery kit
Recovery CD with the selected Cisco WAAS Software version
No
Mandatory
Select appropriate cables from list.
Power cables
Product SKUs are self-explanatory.
No
Power cable
No
Software Options
© 2009 Cisco Systems, Inc. Cisco Confidential/Proprietary—Pricing for illustration purposes only. Pricing subject to change. April 20, 2009
Page 11 of 20
Ordering Guide
Platform Model and Optio ns
Mandatory, Optio nal, or Auto-Expand
Part Number
Description
Notes
Available as Spare
Software version
Mandatory
SF-WAAS-4.0-SS-K9
Cisco WAAS Software 4.0 Cisco WAAS Software 4.1
Select either the Cisco WAAS Software 4.0 or 4.1 version of these SKUs, not both.
No
SF-WAAS-4.1-SS-K9
Software license
Mandatory
WAAS-ENT-APL
Cisco WAAS Enterprise license
Select only one license option.
Yes
WAAS-TRN-APL
Cisco WAAS Transport license
Yes
WAAS-CNTRL-MGR
Cisco WAAS Central Manager license
WAAS-CNTRLMGR is available only if SF-WAAS4.0-SS-K9 is selected. For more information about the Central Manager license, see Table 2.
WAAS-VIDEO-WMAPL
Cisco WAAS Video license for Microsoft Windows Media Live streaming
Requires WAASENT-APL and SFWAAS-4.1-SS-K9 selection
Yes
Software license
Optional
No
Yes
* Refer to the sizing guidelines and sizing tool for more information.
Cisco WAE-7341 Ordering Information Table 9 provides ordering information and part numbers for the Cisco WAE-7341 appliance. Table 9.
Cisco WAE-7341 Appliance Ordering Information
Platform Model and Optio ns
Mandatory, Optio nal, or Auto-Expand
Part Number
Description
Cisco WAE7341
Mandatory
WAE-7341-K9
Chassis with 12 GB RAM, HDD, and AC power supply
Notes
Available as Spare No
Hardware Options PCI inline card
Optional
WAE-INLN-4CG
4-port inline card
Accessory kit
Auto-Expand
AK-WAAS-HW
Hardware accessory kit
Auto-Expand
AK-WAAS-4.X-CD-K9
Cisco WAAS Software CD recovery kit
Recovery CD with the selected Cisco WAAS Software version
No
Mandatory
Select appropriate cables from list.
Power cables
Product SKUs are self-explanatory.
No
SF-WAAS-4.0-K9
Cisco WAAS Software 4.0
No
SF-WAAS-4.1-SAS-K9
Cisco WAAS Software 4.1
Select either the Cisco WAAS Software 4.0 or 4.1 version of these SKUs, not both.
WAAS-ENT-APL
Cisco WAAS Enterprise license
Select only one license option.
Yes
WAAS-TRN-APL
Cisco WAAS Transport license
Yes
WAAS-CNTRL-MGR
Cisco WAAS Central Manager license
WAAS-CNTRLMGR is available only if SF-WAAS4.0-K9 is selected. For more information about the Central Manager license, see Table 2.
Power cable
Select for inline deployment.
Yes No
Software Options Software version
Mandatory
Software license
Mandatory
© 2009 Cisco Systems, Inc. Cisco Confidential/Proprietary—Pricing for illustration purposes only. Pricing subject to change. April 20, 2009
No
Yes
Page 12 of 20
Ordering Guide
Platform Model and Optio ns
Mandatory, Optio nal, or Auto-Expand
Part Number
Description
Notes
Available as Spare
Software license
Optional
WAAS-VIDEO-WMAPL
Cisco WAAS Video license for Microsoft Windows Media Live streaming
Requires WAASENT-APL and SFWAAS-4.1-SASK9 selection
Yes
Cisco WAE-7371 Ordering Information Table 10 provides ordering information and part numbers for the Cisco WAE-7371 appliance. Table 10.
Cisco WAE-7371 Appliance Ordering Information
Platform Model and Optio ns
Mandatory, Optio nal, or Auto-Expand
Part Number
Description
Cisco WAE7371
Mandatory
WAE-7371-K9
Chassis with 24 GB RAM, HDD, and AC power supply
Notes
Available as Spare No
Hardware Options PCI inline card
Optional
WAE-INLN-4CG
4-port inline card
Accessory kit
Auto-Expand
AK-WAAS-HW
Hardware accessory kit
Auto-Expand
AK-WAAS-4.X-CD-K9
Cisco WAAS Software CD recovery kit
Recovery CD with the selected Cisco WAAS Software version
No
Mandatory
Select appropriate cables from list.
Power cables
Product SKUs are self-explanatory.
No
SF-WAAS-4.0-K9
Cisco WAAS Software 4.0
No
SF-WAAS-4.1-SAS-K9
Cisco WAAS Software 4.1
Select either the Cisco WAAS Software 4.0 or 4.1 version of these SKUs, not both.
WAAS-ENT-APL
Cisco WAAS Enterprise license
Select only one license option.
Yes
WAAS-TRN-APL
Cisco WAAS Transport license
Yes
WAAS-CNTRL-MGR
Cisco WAAS Central Manager license
WAAS-CNTRLMGR is available only if SF-WAAS4.0-K9 is selected. For more information about the Central Manager license, see Table 2.
WAAS-VIDEO-WMAPL
Cisco WAAS Video license for Microsoft Windows Media Live streaming
Requires WAASENT-APL and SFWAAS-4.1-SASK9 selection
Yes
Power cable
Select for inline deployment.
Yes No
Software Options Software version
Mandatory
Software license
Mandatory
Software license
Optional
No
Yes
for the Cisco WAE and Cisco WAVE hardware is offered through the Cisco SMARTnet contract program. The available Cisco SMARTnet options are displayed on the Dynamic Configuration Tool when you click Check Configuration. To add service, you should use the Multiline Configurator Tool. Properly configured Cisco WAAS products include both Cisco SMARTnet and SASU service. The Dynamic Configuration Tool includes only one type of service: either Cisco SMARTnet or software , but not both. Hardware : Cisco SMARTnet Contract The Cisco WAE and Cisco WAVE platforms are all covered by Cisco’s standard 90-day warranty. For additional Cisco Technical Assistance Center (TAC) and hardware , the customer © 2009 Cisco Systems, Inc. Cisco Confidential/Proprietary—Pricing for illustration purposes only. Pricing subject to change. April 20, 2009
Page 13 of 20
Ordering Guide
should order Cisco Technical Services. Note that after you complete the configuration and click Check Configuration on the Dynamic Configuration Tool, appropriate Cisco SMARTnet SKUs are included based on the hardware service levels selected. Table 11 lists the services available for the Cisco WAE and Cisco WAVE platforms through the Cisco SMARTnet program. Table 11.
Cisco SMARTnet Services for Cisco WAE and Cisco WAVE
Part Number
Description
Price
CON-SNT-WAV274K
Cisco SMARTnet 8x5xNBD WAVE-274
US$100
CON-SNT-WAV474K
Cisco SMARTnet 8x5xNBD WAVE-474
US$304
CON-SNT-WAE512
Cisco SMARTnet 8x5xNBD WAE-512
US$480
CON-SNT-WAV574K
Cisco SMARTnet 8x5xNBD WAVE-574
US$480
CON-SNT-WAE612
Cisco SMARTnet 8x5xNBD WAE-612
US$1104
CON-SNT-WAE674K9
Cisco SMARTnet 8x5xNBD WAE-674
US$1280
CON-SNT-WAE7341
Cisco SMARTnet 8x5xNBD WAE-7341
US$4240
CON-SNT-WAE7371
Cisco SMARTnet 8x5xNBD WAE-7371
US$10,320
CON-SNTE-WAV274K
Cisco SMARTnet 8x5x4 WAVE-274
US$145
CON-SNTE-WAV474K
Cisco SMARTnet 8x5x4 WAVE-474
US$441
CON-SNTE-WAE512
Cisco SMARTnet 8x5x4 WAE-512
US$696
CON-SNTE-WAV574K
Cisco SMARTnet 8x5x4 WAVE-512
US$696
CON-SNTE-WAE612
Cisco SMARTnet 8x5x4 WAE-612
US$1601
CON-SNTE-WAE674K9
Cisco SMARTnet 8x5x4 WAE-674
US$1856
CON-SNTE-WAE7341
Cisco SMARTnet 8x5x4 WAE-7341
US$6148
CON-SNTE-WAE7371
Cisco SMARTnet 8x5x4 WAE-7371
US$14964
CON-SNTP-WAV274K
Cisco SMARTnet 24x7x4 WAVE-274
US$160
CON-SNTP-WAV474K
Cisco SMARTnet 24x7x4 WAVE-474
US$486
CON-SNTP-WAE512
Cisco SMARTnet 24x7x4 WAE-512
US$768
CON-SNTP-WAV574K
Cisco SMARTnet 24x7x4 WAVE-574
US$768
CON-SNTP-WAE612
Cisco SMARTnet 24x7x4 WAE-612
US$1766
CON-SNTP-WAE674K9
Cisco SMARTnet 24x7x4 WAE-674
US$2048
CON-SNTP-WAE7341
Cisco SMARTnet 24x7x4 WAE-7341
US$6784
CON-SNTP-WAE7371
Cisco SMARTnet 24x7x4 WAE-7371
US$16,512
CON-S2P-WAV274K
Cisco SMARTnet 24x7x2 WAVE-274
US$213
CON-S2P-WAV474K
Cisco SMARTnet 24x7x2 WAVE-474
US$646
CON-S2P-WAE512
Cisco SMARTnet 24x7x2 WAE-512
US$1020
CON-S2P-WAV574K
Cisco SMARTnet 24x7x2 WAVE-574
US$1020
CON-S2P-WAE612
Cisco SMARTnet 24x7x2 WAE-612
US$2346
CON-S2P-WAE674K9
Cisco SMARTnet 24x7x2 WAE-674
US$2720
CON-S2P-WAE7341
Cisco SMARTnet 24x7x2 WAE-7341
US$9010
CON-S2P-WAE7371
Cisco SMARTnet 24x7x2 WAE-
US$21,930
Cisco SMARTnet 8x5xNBD*
Cisco SMARTnet 8x5x4
Cisco SMARTnet 24x7x4
Cisco SMARTnet 24x7x2
* NBD: Next business day
© 2009 Cisco Systems, Inc. Cisco Confidential/Proprietary—Pricing for illustration purposes only. Pricing subject to change. April 20, 2009
Page 14 of 20
Ordering Guide
Software : SASU Contract Customers who want for the Cisco WAAS Software must purchase Software Application (SAS) or Software Applications with Upgrades (SAU) contracts. These contracts must be ordered separately and are not part of the product configuration on the Dynamic Configuration Tool. When virtual blade is ordered, the Multi-line Configurator Tool will include only one of the software part numbers (CON-SAU-WAASENAP or CON-SASWAASVBL). The missing software part number should be quoted separately. Table 12 lists the SASU contracts for Cisco WAAS Software. Table 12.
Cisco WAAS and Cisco WAAS Mobile Software SASU Contracts
Part Number
Description
Price
CON-SAU-WAASTRAP
SASU for Cisco WAAS Transport license for 1 Cisco WAE or Cisco WAVE appliance
US$200
CON-SAU-WAASENAP
SASU for Cisco WAAS Enterprise license for 1 Cisco WAE or Cisco WAVE appliance
US$500
CON-SAS-WAASVBL
Software application for Cisco WAAS Virtual Blade license
US$300
CON-SAS-WAASVBW2
Software application for Microsoft Windows Server 2008 for Microsoft Active Directory, Domain Name System (DNS), Dynamic Host Control Protocol (DH), and print only
US$525
SP-SAS-WAASVBL
Service provider (SP) SAS Cisco WAAS Virtual Blade license
US$300
SP-SAS-WAASVBW2
SP SAS plus Microsoft Windows Server 2008 for Microsoft Active Directory, DNS, DH, and print only
US$525
SP-SAU-WAASMBLS
SP SAU Cisco WAAS Mobile server software
US$1000
SP-SAU-WAASL25
SP SAU Cisco WAAS Mobile 25 concurrent licenses
US$1750
SP-SAU-WAASL100
SP SAU Cisco WAAS Mobile 100 concurrent licenses
US$6800
SP-SAU-WAASL500
SP SAU Cisco WAAS Mobile 500 concurrent licenses
US$32,500
Note that no SASU contract is available or required for the Cisco WAAS Central Manager license in WAAS 4.0. You need only the Cisco SMARTnet contract on the Cisco WAAS appliance running the Cisco WAAS Central Manager.
O rde ri ng St e ps f or Ci s c o W A AS N et w ork M odul es There are three SKUs for the Cisco WAAS network modules, listed in Table 13. The list price is the standalone hardware price. It does not include software or reflect bundle pricing. For accurate prices, please refer to the price list. For bundles, please refer to the Cisco WAAS FY09 Bundles Ordering Information section for more information. Table 13.
Ordering Information for Cisco WAAS Network Modules
Part Number
Description
Price
NME-WAE-522-K9
Cisco WAAS network module for Cisco 3800 Series Integrated Services Routers only; 2 GB RAM and 160-GB HDD
US$9000
NME-WAE-502-K9
Cisco WAAS network module for Cisco 2800 and 3800 Series Integrated Services Routers; 1 GB RAM and 120-GB HDD
US$6500
NME-WAE-302-K9
Cisco WAAS network module for Cisco Integrated Services Routers (s only Transport license); 512 MB RAM and 80-GB HDD
US$3750
The Cisco WAAS NME-WAE network modules can be ordered in three ways.
© 2009 Cisco Systems, Inc. Cisco Confidential/Proprietary—Pricing for illustration purposes only. Pricing subject to change. April 20, 2009
Page 15 of 20
Ordering Guide
Cisco WAAS NME-WAE Spares To order the Cisco WAAS NME-WAE as a spare, follow these steps: 1.
2.
3.
Enter the appropriate spare product part number in the Dynamic Configuration Tool: ●
NME-WAE-522-K9=
●
NME-WAE-502-K9=
●
NME-WAE-302-K9=
Select one of the Cisco WAAS Software options (mandatory): ●
SF-WAAS-4.0-NM-K9
●
SF-WAAS-4.1-NM-K9
Select one of these Cisco WAAS Software licenses (mandatory): ●
WAAS-ENT-NM (Cisco WAAS Enterprise license for NME-WAE-502-K9 and NME-WAE522-K9)
●
4.
WAAS-TRN-NM (Cisco WAAS Transport license for all three network modules)
Select a Cisco WAAS Software license option (optional): ●
WAAS-WMVID-NM (Cisco WAAS Video license for Microsoft Windows Media Live streaming; requires selection of WAAS-ENT-NM)
Cisco WAAS NME-WAE and Cisco Integrated Services Routers WAN Optimization Bundles The WAN optimization bundles include the Cisco WAAS network module and the Cisco Integrated Services Router at discounted prices. NME-WAE-502-K9 Bundles Five WAN optimization bundles are available for the NME-WAE-502-K9: ●
The bundles with the Cisco 2800 Series routers include the NME-WAE-502-K9, the Cisco ®
Integrated Services Router (Cisco 2811, 2821, or 2851), and the Cisco IOS Software advanced security image. ●
The bundles with the Cisco 3800 Series routers include the NME-WAE-502-K9, the Cisco Integrated Services Router (Cisco 3825 or 3845), Cisco IOS advanced security image, 256 to 512 MB RAM upgrade, and 64 to 128 MB compact flash memory upgrade.
●
The bundles are priced with the Cisco WAAS Transport license and offer a discounted the Cisco WAAS Enterprise license while configuring the bundle.
Table 14 provides ordering information for NME-WAE-502-K9 bundles. Table 14.
Ordering Information for NME-WAE-502-K9 WAN Optimization Bundles
Cisco Integrated Services Routers WA N O pti mizat ion Bund le
Bund le w ith Transport License
Bund le w ith Enterprise License
CISCO2811-WAE/K9
US$8,365
US$10,615
CISCO2821-WAE/K9
US$9,700
US$11,966
CISCO2851-WAE/K9
US$11,900
US$14,172
CISCO3825-WAE/K9
US$15,800
US$18,800
US$18,000
US$21,000
Incl. 128 MB Compact Flash and 512 MB RAM CISCO3845-WAE/K9 Incl. 128 MB Compact Flash and 512 MB RAM
© 2009 Cisco Systems, Inc. Cisco Confidential/Proprietary—Pricing for illustration purposes only. Pricing subject to change. April 20, 2009
Page 16 of 20
Ordering Guide
To order the WAN optimization bundles, follow these steps: 1.
Select the bundle based on the router you are ordering.
2.
In the router software options, select the Cisco IOS Software image IP BASEK9 or later and Cisco IOS Software Release 12.409T or later.
3.
For the Cisco WAAS Software license, select one of the options listed in Table 15.
Table 15.
Cisco WAAS Software License Options for WAN Optimization Bundles
Part Number
Description
Price
WAAS-ENT-NM-BUN
Cisco WAAS Enterprise license for 1 NME-WAE-502-K9 or NME-WAE-522-K9 network module
US$3000
WAAS-TRN-NM
Cisco WAAS Transport license for 1 network module
Included
WAAS-VIDEO-WM-NM
Cisco WAAS Video license for Microsoft Windows Live streaming
US$2500
4.
Select any other options that you want to order, such as any security options, voice features, or add-on cards or modules; these options can be configured under the bundle just as you would if you were configuring the router.
5.
If you select a Cisco 3800 Series bundle, under Network Module Options you will see the Cisco WAAS network modules listed again. Select another module only if you want two Cisco WAAS network modules for the same router. Usually a second WAAS network module is not needed on the same router.
6.
Select the appropriate power cord.
NME-WAE-302-K9 Bundles One bundle is available for the NME-WAE-302-K9, listed in Table 16. Table 16.
Ordering Information for NME-WAE-302-K9 WAN Optimization Bundle
Cisco Integrated Services Routers WA N O pti mizat ion Bu ndle
Bund le w ith Transport L icense
C2811-WAE-302/K9
US$5955
There is no option to the Cisco WAAS Enterprise license since the NME-WAE-302-K9 does not this license. Configure this bundle as described for the NME-WAE-502-K9 bundles. NME-WAE Configured Under the Router or Other Bundles The Cisco WAAS NME-WAE can be selected and configured under the Cisco 2800 or 3800 Series routers or added to other Cisco Integrated Services Routers bundles in the following way: 1.
Select the router or bundle you want to configure.
2.
Expand the network module options and select the NME-WAE-502-K9 or NME-WAE-302-K9 in the options pane.
3.
Expand the NME-WAE in the item category pane. a. Select the Cisco WAAS Software version desired. b. Select the Cisco WAAS Software license. You can choose between the Transport and Enterprise licenses for the NME-WAE-502-K9. c. Optionally, choose the Cisco WAAS Video license (Microsoft Windows Media Live video). This option is available only if the Enterprise license is selected.
© 2009 Cisco Systems, Inc. Cisco Confidential/Proprietary—Pricing for illustration purposes only. Pricing subject to change. April 20, 2009
Page 17 of 20
Ordering Guide
for Network Modules Full hardware and software for the Cisco WAAS network modules is provided by the purchase of the Cisco SMARTnet contract for the Cisco Integrated Services Router on which the module is deployed. No additional contracts are required.
O rde ri ng St e ps f or Ci s c o W A AS M obil e The Cisco WAAS Mobile solution requires Cisco WAAS Mobile server software and the concurrent licenses. Cisco WAAS Mobile server software is installed on a standard Microsoft Windows Server 2003; no hardware is shipped from Cisco. Please refer to the guide for server hardware requirements: http://www.cisco.com/en/US/products/ps9523/products_installation_and_configuration_guides_list. html Please select the Cisco WAAS Mobile server software (WAAS-MBL-SRV) and at least one concurrent license to complete the configuration. Concurrent licenses can also be ordered as spares.
O rde ri ng St e ps f or Ci s c o W A AS FY 09 Prom oti ons There are four bundle SKUs for the Cisco WAAS FY09 Promotions, listed in Table 17. The list price is the price for the entire bundle and cannot be modified to exclude any components. Table 17.
Cisco WAAS FY09 Bundles
Part Number
Description
Price
WAAS-VB-VID-PROMO
• Cisco WAAS Video license for Microsoft Windows Media Live Streaming
US$2500
• Cisco WAAS Virtual Blade license NME-WAE-VID-SM-K9
• NME-WAE-502-K9 network module
US$9000
• Cisco WAAS Enterprise license • Cisco WAAS Video license for Microsoft Windows Media Live Streaming NME-WAE-VID-LG-K9
• NME-WAE-522-K9 network module
US$10,000
• Cisco WAAS Enterprise license • Cisco WAAS Video license for Microsoft Windows Media Live Streaming NME-WAE-AXP-LG-K9
• NME-WAE-522-K9 network module
US$12,500
• Cisco WAAS Enterprise license • Cisco WAAS Video license for Microsoft Windows Media Live Streaming • NME-502-APPRE-K9 network module • Cisco Application eXtension Platform (AXP) software CISCO2811-WAE/K9 CISCO2821-WAE/K9
• Cisco 2800 Series Integrated Services Routers (ISRs) Bundle
CISCO2851-WAE/K9
• NME-WAE-502 network module
Free Video license with purchase of Cisco WAAS Enterprise license
• Cisco WAAS Enterprise license with Cisco WAAS Video license for Microsoft Windows Media Live Streaming CISCO3825-WAE/K9 CISCO3845-WAE/K9
• Cisco 3800 Series Integrated Services Routers (ISRs) Bundle • NME-WAE-502 network module
Free Video license with purchase of Cisco WAAS Enterprise license
• Cisco WAAS Enterprise license with Cisco WAAS Video license for Microsoft Windows Media Live Streaming
© 2009 Cisco Systems, Inc. Cisco Confidential/Proprietary—Pricing for illustration purposes only. Pricing subject to change. April 20, 2009
Page 18 of 20
Ordering Guide
Cisco WAAS FY09 Promotion Bundles Ordering Information Table 18 provides ordering information and part numbers for the promotional bundles. Bundle components that are listed in the Parts Included column are auto-expanded and do not need any additional configuration. Table 18.
Cisco WAAS FY09 Promotion Bundles Ordering Information
Part Number
WAAS-VB-VID-PROMO
App licable Platforms
Parts Included (Au to Expanded)
Description
WAVE-274-K9
WAAS-VIDEO-WM-APL WAAS-VB-LIC
Available as an option under the software license section in the configuration tool
Yes
WAVE-474-K9
Same configuration steps as for the NME-WAE-502-K9
Yes
Same configuration steps as for the NME-WAE-522-K9
Yes
Same configuration steps as for the NME-WAE-522-K9
Yes
Same configuration steps as for the NME-WAE-502-K9
–
Same configuration steps as for the NME-WAE-502-K9
–
WAVE-574-K9
Available as Spare
WAE-674-K9 NME-WAE-VID-SM-K9
NME-WAE-VID-LG-K9
NME-WAE-AXP-LG-K9
Cisco 2800 and 3800 Series Integrated Service Routers
NME-WAE-502-K9
Cisco 3800 Series Integrated Service Routers
NME-WAE-522-K9
Cisco 3800 Series Integrated Service Routers
NME-WAE-522-K9
WAAS-ENT-NM WAAS-VIDEO-WM-NM
WAAS-ENT-NM WAAS-VIDEO-WM-NM
WAAS-ENT-NM WAAS-VIDEO-WM-NM NME-APPRE-502-K9 SN-AXP-1.1-K9
CISCO2811-WAE/K9 CISCO2821-WAE/K9 CISCO2851-WAE/K9
Cisco 2800 Series Integrated Service Routers
Cisco 2800 Series ISR NME-WAE-502-K9 WAAS-ENT-NM WAAS-VIDEO-WM-NM
CISCO3825-WAE/K9 CISCO3845-WAE/K9
Cisco 3800 Series Integrated Service Routers
Cisco 3800 Series ISR NME-WAE-502-K9 WAAS-ENT-NM WAAS-VIDEO-WM-NM
Addi ti onal R es ource s This document is meant to be a guide for configurations and pricing. The latest and most accurate information is always online in the pricing and configuration tools. In the event of any discrepancy between what is contained in this document and online in the tools, the tools should be used as the ultimate source of information. ●
Cisco Dynamic Configuration Tool: http://www.cisco.com/appcontent/apollo/configureHomeGuest.html
●
Cisco WAE global price list: http://www.cisco.com/cgibin/front.x/pricing?ProductFamilyId=40950&Page=ViewCurrProdFamilyPage&ProductFamil y=Cisco+Wide+Area+Application+Engine& Request=ViewCurrentProdPriceList&PriceListId=889
●
Cisco WAAS Software Version 4.1 data sheet: http://www.cisco.com/en/US/prod/collateral/contnetw/ps5680/ps6870/data_sheet_c78445372.html
●
Cisco WAAS appliances data sheet: http://www.cisco.com/en/US/products/ps6474/products_data_sheets_list.html
© 2009 Cisco Systems, Inc. Cisco Confidential/Proprietary—Pricing for illustration purposes only. Pricing subject to change. April 20, 2009
Page 19 of 20
Ordering Guide
●
Cisco WAAS appliance overview slide (internal source: WAAS Sales Rack, in “Sales Guides” section): http://wwwintools.cisco.com/sales/go/salesrack/products/sw/contnetw/ps6870
●
Cisco WAAS Software Version 4.1 sizing guidelines (internal source: Cisco WAAS Sales Rack, in “Sales Guides” section): http://wwwintools.cisco.com/sales/go/salesrack/products/sw/contnetw/ps6870
●
Cisco WAAS Mobile data sheet: http://www.cisco.com/en/US/products/ps9523/products_data_sheets_list.html
●
Cisco WAAS Mobile sizing guidelines: http://zed.cisco.com/confluence/display/WAAS/WAAS+Mobile
Printed in USA
© 2009 Cisco Systems, Inc. Cisco Confidential/Proprietary—Pricing for illustration purposes only. Pricing subject to change. April 20, 2009
C07-532535-00 04/09
Page 20 of 20
Related Documents 3m3m1z
Ordering Guide For Cisco Waas_wae_wave 6n1b4j
December 2019 45
Cisco Anyconnect Ordering Guide April 2016 5sg6a
December 2019 35
Cisco Customer Care Solutions Ordering Guide 4k613c
April 2022 0
Cisco Customer Solutions Ordering Guide 1g2x2
November 2019 49
Cisco Prime Infra 2.1 Ordering Guide 4w4h2w
November 2019 41
Cisco Cloudlock Quoting And Ordering Quick Guide 2e2j5k
December 2019 59More Documents from "neel" 4y4a1i
Abap Consultant Roles And Responsibilities - Sap Abap Consultant _ Sapnuts 552w50
November 2019 96
Steamcalc.xls 681i3b
October 2021 0
Indian Herbs For Healthy Body - Healing Properties Of Adalodakam, Arogya Pacha, Ashokam, Irattimadhu l1z5u
November 2019 76
October 2019 47
Alchemy 4z4b29
August 2022 0
