Ossec 6t1q

Server @localhost SSLEngine On SSLCertificateFile /etc/apache2/apache.pem DocumentRoot /var/www/ Tell apache2 to use HTTPS instead HTTP Edit /etc/apache2/ports.conf Listen 443 Restart apache2 /etc/init.d/apache2 restart Now every website that apache2 hosts will be using SSL.

Page 1 of 123 ---- Generated from

OSSIM

by FUDforum 2.7.7

Subject: Re: Use HTTPS instead of HTTP Posted by phishphreek on Fri, 23 May 2008 14:32:42 GMT View Forum Message <> Reply to Message Change NTOP to use SSL Note: This part isn't 100% yet. Have to figure out how to get the dashboard to redirect to the new link without having to change every dashboard piece separately. NTOP is running it's own web server. Let's tell it to run over SSL too. I can't figure out where the NTOP is so lets reset it. ntop -A Set a new . Copy the apache.pem certificate to the ntop config folder. /etc/apache2/apache.pem /etc/ntop/ntop-cert.pem Configure NTOP to use HTTPS Open NTOP in your web browser. http://ossim.ip:3000 Go to the tab and choose startup options. Enter the for the id and the you just assigned to it. Change the HTTP Server (-w) field from 3000 to 0. Change the HTTPS Server (-W) field from 0 to 3000. Scroll down and click Save Preferences. Shutdown NTOP Click on the tab and then click on shutdown. This will stop NTOP. OSSIM is running a monitor for this service, so you can just simply wait and OSSIM will restart it. Change the OSSIM configuration to point to the new ssl site. Edit /etc/ossim/framework/ossim.conf and change the ntop_link field from # to https://serverip:3000 Run the reconfig.pl script chmod 700 /home/ossim/dist/reconfig.pl /home/ossim/dist/reconfig.pl

Now if you go into the ossim web based config utility, the link will be changed and grayed out. Unfortunately, that still doesn't change the dashboard links... I'm still trying to find out how to change those.


OSSIM

by FUDforum 2.7.7

Subject: Installing the OSSEC Web Interface on OSSIM Posted by gsporter on Fri, 30 May 2008 04:02:37 GMT View Forum Message <> Reply to Message I found I can see the OSSEC output directly as a cross check by install the web ui Start by following the general instructions here. I have provided the changes I had to make to install on the OSSIM all-in-one from the installer: http://www.ossec.net/wiki/index.php/OSSECWUI:Install Changes: Step 3 # mv ossec-wui-0.3 /var/www/htdocs/ossec-wui to # mv ossec-wui-0.3 /var/www/ossec-wui Step 5 # nano /etc/group .. From: ossec:x:1002: To: ossec:x:1002:www-data

Step 6 # chmod 770 tmp/ # chgrp www-data tmp/ # /etc/init.d/apache2 restart You can access the interface thru http:// /ossec-wui

Subject: Re: Use HTTPS instead of HTTP Posted by henry01 on Fri, 06 Jun 2008 11:00:34 GMT View Forum Message <> Reply to Message any luck on this?


OSSIM

by FUDforum 2.7.7

Thanks

Subject: Re: Use HTTPS instead of HTTP Posted by jimsmithkka on Fri, 06 Jun 2008 17:57:09 GMT View Forum Message <> Reply to Message I followed these steps and my pages are now secure, but when i try to use the links in the sidebar of the availability tab (Nagios) i get a page not found, the issue i know is that the links are for http, not https. My question is where is the file that has these links so i can update it or is there a config change i can make in apache auto forward http requests to https for each page. The system is a almost bare bones install from the install cd i got from AlienVault. I am not to familiar with apache, i use lighttpd most of the time instead, so any help would be gratefully accepted.

Subject: Re: Use HTTPS instead of HTTP Posted by phishphreek on Fri, 06 Jun 2008 21:35:45 GMT View Forum Message <> Reply to Message I haven't had an opportunity to mess with it too much more. I ended up changing the links via Dashboard, edit and then editing the s separately. This works OK for me as I am the only . These dashboards are configured on a per basis, so if you have multiple s, each will have to change their links. The config files are located in /etc/framework//configs The main dashboard page is /etc/framework//configs/_1 The dashboard page with the ntop data is /etc/framework//configs/_5_1 Each time I try to manually edit those files to update the links, it get OSSIM throwing an error complaining about bad data. From looking at their reconfig script in /home/ossim/dist/reconfig.pl I found they are using a file called edit_serialized_ips_s_conf.php which they use to replace the ip address if you change it and use the reconfig script.


OSSIM

by FUDforum 2.7.7

I haven't yet had the free time to modify this script to have it grab the ntop_link field from /etc/framework/ossim.conf if it has been modified and store it in some variable. Then have the script go through and change it in the *_1 and *_5_1 files. jimsmithkka: I think you're running into a little different issue. My nagios is actually running on a separate server. I changed my links to point to the server and all worked fine for me... I'll have to look into it in vmware and see why yours won't work.

Subject: Re: Use HTTPS instead of HTTP Posted by phishphreek on Fri, 06 Jun 2008 21:53:13 GMT View Forum Message <> Reply to Message jimsmithkka: You can do it in one of two places. Either in the web configuration --> main --> nagios link Change from /nagios2/ to https://serverip/nagios2/ Or, edit /etc/ossim/framework/ossim.conf and change the link to nagios. #nagios_link nagios_link=https://serverip/nagios2/ Then run /home/ossim/dist/reconfig.pl It will update to the correct link. Sorry about that!

Subject: Re: Use HTTPS instead of HTTP Posted by jimsmithkka on Mon, 09 Jun 2008 13:30:11 GMT View Forum Message <> Reply to Message It all works now, Thanks Figured it would be help others as well so i posted the question here. Once Again thanks

Subject: NagiosQL Walktrough Posted by umarzuki on Mon, 09 Jun 2008 14:48:25 GMT View Forum Message <> Reply to Message


OSSIM

by FUDforum 2.7.7

Note: This was done on installer version 1.0.4, so as they say, YMMV. After you got OSSIM up and running, install php-pear then execute pear install HTML_Template_IT After that the latest NagiosQL from http://www.nagiosql.org/index.php/component/content/article/ 44 then extract in your /var/www cd into the extracted directory Create mysql database mysql -uroot -p < nagiosQL_v2_db_mysql.sql if asked for , find it somewhere in /etc/ossim/ossim_setup.conf put these into Apache2 config file: httpd.conf Order allow,deny Deny from all then edit setting.ini and change value in it accordingly root = /nagiosql-2.0.2/ physical = /var/www/nagiosql-2.0.2/ config = "/etc/nagios2/" confighosts = "/etc/nagios2/conf.d/" configservices = "/etc/nagios2/conf.d/" binary = "/usr/sbin/nagios2" cmdfile = "/var/lib/nagios2/rw/nagios.cmd" pidfile = "/var/run/nagios2/nagios2.pid" lang = lang_en then try browsing to: server_IP/nagiosql-directory/testQL.php if you got permission read/write error, chmod -R 777 it if you got error about folder missing o something like that, make one by referring to setting.ini Don't forget to import config files: Tools > Data Import Corrections are most welcome :)

Subject: Re: NagiosQL Walktrough Page 6 of 123 ---- Generated from

OSSIM

by FUDforum 2.7.7

Posted by eflinton on Mon, 09 Jun 2008 18:27:28 GMT View Forum Message <> Reply to Message can't find nagios.cmd on a freshly installed system v1.0.4 and upgraded through ossim-update.pl. any ideas? thanks.

Subject: Re: NagiosQL Walktrough Posted by jvblanco on Mon, 09 Jun 2008 20:56:41 GMT View Forum Message <> Reply to Message Check at /etc/nagios2/nagios.cfg if you have external commands enabled. BTW, this is a very interesting Nagios addon. I'm going to give it a try. Juan.

Subject: Re: NagiosQL Walktrough Posted by umarzuki on Tue, 10 Jun 2008 00:02:12 GMT View Forum Message <> Reply to Message it's a pipe file, to make it mknod nagios.cmd p but it'll give error anyway thru testQL.php. Actually, a pipe file will only be there when nagios run.

Subject: Re: NagiosQL Walktrough Posted by eflinton on Tue, 10 Jun 2008 14:44:45 GMT View Forum Message <> Reply to Message Thanks had the external command value set on the prod. unit and saw the file but hadn't move the configs to the test unit. Its there after adjusting the value -- thanks jvblanco!

Subject: Re: NagiosQL Walktrough Page 7 of 123 ---- Generated from

OSSIM

by FUDforum 2.7.7

Posted by umarzuki on Tue, 10 Jun 2008 23:57:42 GMT View Forum Message <> Reply to Message wow you guys got it up and running? Nice, since i never setup manual nagios before, stuck when creating host (the pull downs don't have value) rouven from ngiosql said something about timeperiods.cfg which is isn't available at fist so probably i'll have to create it.

Subject: Re: NagiosQL Walktrough Posted by eflinton on Wed, 11 Jun 2008 00:29:47 GMT View Forum Message <> Reply to Message haven't gotten the prod_configs into nagiosql yet but things are working out will post any information that may be of value. i didn't know this was available so trying it out. in regards to nagios -- i keep the host file simple, than group with hostgroup. I have several *.cfg depending on the system type and required checks. not sure if default ossim is setup like that as I have just been moving prod_configs over.

Subject: Re: NagiosQL Walktrough Posted by umarzuki on Wed, 18 Jun 2008 06:32:56 GMT View Forum Message <> Reply to Message actually, i had to import the config files :)

Subject: Re: NagiosQL Walktrough Posted by eflinton on Wed, 18 Jun 2008 14:42:28 GMT View Forum Message <> Reply to Message If starting from scratch there were a lot of dependencies between hosts, s, services. I would agree import your configs.

Subject: Re: Installing the OSSEC Web Interface on OSSIM Posted by umarzuki on Wed, 25 Jun 2008 08:31:22 GMT View Forum Message <> Reply to Message this tutorial works..i can confirm that. But no fancy graphs... 8)


OSSIM

by FUDforum 2.7.7

Subject: Re: NagiosQL Walktrough Posted by redbarron on Fri, 27 Jun 2008 01:55:10 GMT View Forum Message <> Reply to Message So, from the last few posts it sounds like I should NOT attempt this if I haven't set up nagios at all yet? Or is it just the couple extra steps as mentioned? If it's going to make configuring nagios harder for a nagios noob, I'll just stick with straight nagios until I feel like I've got that under my belt. Thanks, Joe

Subject: Re: NagiosQL Walktrough Posted by umarzuki on Mon, 30 Jun 2008 14:12:04 GMT View Forum Message <> Reply to Message Quote:If it's going to make configuring nagios harder for a nagios noobyeah, absolutely. Most of 'em are.

Subject: OSSIM: Configuration steps Posted by ajcborges on Mon, 14 Jul 2008 19:21:28 GMT View Forum Message <> Reply to Message HI, I have been wokning on Security Information around 8yrs. I know several SIM products, including Sentinel from Novell. I am currently putting together a monitoring project with Open Source Products and OSSIM caught my attention. I know Linux (debian, among others), Windows, Unix, etc. OSSIM has many virtues which I do not know where to start. If anyone knows or has done a guide to perform a basic configuration of OSSIM, it will be widely appreciated. Already the ISO. And I installed it without any problems ... I think I am ok. :!: I would learn to configure it. I think it is a solution with a high market potential. 8) TIA.

Subject: Re: OSSIM: Configuration steps Page 9 of 123 ---- Generated from

OSSIM

by FUDforum 2.7.7

Posted by kristian_paul on Mon, 14 Jul 2008 20:50:00 GMT View Forum Message <> Reply to Message i may help http://www.ossim.com/blog/dk/ossim/tutorials/tut3_intro.html

Subject: Re: OSSIM: Configuration steps Posted by guihen01 on Fri, 18 Jul 2008 01:50:21 GMT View Forum Message <> Reply to Message use tutorial on ossim web site

Subject: Re: OSSIM: Configuration steps Posted by kristian_paul on Fri, 18 Jul 2008 14:16:19 GMT View Forum Message <> Reply to Message did you get running snort and ossim for windows? are you're collecting data to your master server? couse i never did it :cry: , so far ;) any way, if you can help i apreciate

Subject: Re: OSSIM: Configuration steps Posted by gsporter on Sun, 27 Jul 2008 03:29:35 GMT View Forum Message <> Reply to Message Once you have gone through DK's inital setup try reading: Wiki http://www.ossim.net/dokuwiki/doku.php

General Description http://www.ossim.net/dokuwiki/doku.php?id=documentation:gene ral_description s Manual http://www.ossim.net/dokuwiki/doku.php?id=_manual:introd uction


OSSIM

by FUDforum 2.7.7

It helped me to understand the structure and "work flow" of OSSIM GP

Subject: OSSEC Quick Start Guide Posted by Ahriakin on Sun, 07 Sep 2008 00:34:03 GMT View Forum Message <> Reply to Message Hi Folks, This is not a detailed tutorial on OSSEC just a getting started guide. I highly recommend Syngress "OSSEC - Host Based Intrusion Detection Guide" http://www.amazon.com/OSSEC-Host-Based-Intrusion-Detection-G uide/dp/159749240X/ref=pd_bbs_sr_1?ie=UTF8&s=books&q id=1220745267&sr=8-1 if you intend to seriously use this excellent tool. I'm still a Linux beginner myself and from the other posts I see here I'm not the only one so I'm going to try and make these instructions as verbose as possible command-wise so that even beginners can perform them. I'll try and follow this up with some tips that I've found useful in later posts. If anyone has any comments or improvements let me know (like I said I am no expert, or a script-god like PhishPhreak ;), this is just an attempt to help others at my level so any comments are welcome) Anyway : **** Upgrade the master server: As of posting OSSIM includes OSSEC 1.4 and 1.6 has just become available. Thankfully upgrading is a very simple process. 1. the latest source from www.ossec.net to your TMP folder - cd /tmp - wget http://www.ossec.net/files/ossec-hids-1.6.tar.gz (for later versions simply open a browser and go to the OSSEC.net page and right-click the link to the file you want, then copy-link-location and paste it after "wget " 2. Extract the file - tar -zxvf ossec-hids-1.6.tar.gz 3. Enter the newly extracted folder - cd ossec-hids-1.6 4. Run the install script - ./install.sh


OSSIM

by FUDforum 2.7.7

--- It will detect the existing install and ask if you want to upgrade: YES --- It will ask if you want to upgrade the rules: YES 5. Add OSSEC to the agent plugin list - nano /etc/ossim/agent/config.cfg --- under the [plugins] section add the following line ossec=/etc/ossim/agent/plugins/ossec.cfg 6. Restart the OSSIM agent - /etc/init.d/ossim-agent restart

That's it the OSSEC server is now on the latest version and OSSIM is monitoring it. This upgrade will keep any existing client details, historical data etc. and is backward compatible with older clients so you won't break anything by doing it. ** Adding clients to the OSSEC server All important files for OSSEC are located in /var/ossec, the control utilities are in /var/ossec/bin 1. Add a new client: - cd /var/ossec/bin - ./manage_agents --- Choose A to add an agent, enter the client IP and ID you'd like to use (accepting the defaults is fine, ID's are how OSSEC keeps track of clients internally so it doesn't have to match anything else it just has to be unique) Personally I prefer to pre-configure all of my clients here at once so I add each and every host that will have OSSEC agents installed now. I'm going to presume you do the same and don't have RSS injuries when you're done :). So from this point on I will act as if you have added every agent to the master server. 2. Restart the OSSEC server to make the changes (in this case new agents) active. - ./ossec-control stop - ./ossec-control start

**** Installing the OSSEC agent on Windows Hosts Get the latest agent from www.ossec.net 1. Run the installer executable and accept all defaults. 2. When presented with the 'OSSEC Agent Manager' enter the IP of your OSSIM/OSSEC Master Server. 3. Enter the Client/Server authentication key - SSH to your Master Server and run the manage_agent utility - /var/ossim/bin/manage_agents --- choose 'E' to extract a client key


OSSIM

by FUDforum 2.7.7

--- Enter the ID for this client (if you are not sure of the ID then first choose 'L' to list the agents and record the ID number). --- Copy the entire text below the line "Agent key Information for "ID" is:" and paste it into the Authentication Key line on the client's OSSEC Manage Agent window, then hit Save IMPORTANT when you hit save it will show a small popup window with this client's IP, name and ID, make sure they are all correct as this is the data it has extracted from the key you just pasted in and it is what the server is expecting to see, if they do not match then the client will not authenticate to the server and it won't work. If they do match just hit Okay, if not go back and check how the agent was setup on the server and that you pasted the extracted key properly. 4. Start the OSSEC service - From the client OSSEC Manage Agent utility click Manage / Start OSSEC and then refresh, make sure it says it is running. * An alternative of course is to extract all keys and IDs into a text file that you can access from each client but if you do make sure it is absolutely secure, and ideally secure delete it when done. ** Installing on Linux Hosts 1. the agent software to the TMP folder: - cd /tmp - wget http://www.ossec.net/files/ossec-hids-1.6.tar.gz (it uses the same package for all 3 types of Linux installs so you could just copy the file you used on the server) 2. Extract the package - tar -zxvf ossec-hids-1.6.tar.gz 3. Install it - cd ossec-hids-1.6 - ./install.sh --- When prompted for the installation type choose "agent" --- When prompted for the OSSEC server IP use the OSSIM/OSSEC Master server --- Accept all other defaults. 4. Configure the agent authentication from the client - /var/ossec/bin/manage_agent --- choose 'I' to import the key --- follow the steps described in the Windows agent install to copy the client's key from the Master Server and paste it into the Import Key prompt. 5. Restart the agent - /var/ossec/bin/ossec-control stop - /var/ossec/bin/ossec-control start ** Replacing the full OSSEC server on OSSIM-Child servers with agent only reporting to your master server, and also upgrading


OSSIM

by FUDforum 2.7.7

Follow the steps above for the Linux agent installation but at the start OSSEC will detect the existing installation: --- When prompted to upgrade say 'No' --- When prompted to delete the folder say 'Yes' Otherwise it is identical to a normal Linux Agent install. (and to restart with "/var/ossec/bin/ossec-control stop+start" when done. **** Testing the connection between client and server Firstly you can install OSSEC's own Web interface alongside OSSIM's. There is a guide on how to do this here https://www.ossim.net/forum/index.php?t=msg&th=62&st art=0&S=d92e33f115348ff90f531433414935e0 . The only thing I'd add is I had issues with some of the other functions like NTop and Snort graphs until I changed the permissions on /TMP to anyone full control (chmod 777 /tmp) which is not the most secure but it solved my issues. Most of the UI's functions are intact except some searches and graphs. Anyway to directly test the client connection: From the Master Server: 1. List active all clients - /var/ossec/bin/agent_control -l --- Look for the clients you have connected and make sure they are Active 2. Get more detail from the client - /var/ossec/bin/agent_control -i (ID of client) --- This will tell you the last scan times, client version etc. If your client is shown as active you should be good to go....

Subject: Re: OSSEC Quick Start Guide Posted by DK on Wed, 10 Sep 2008 19:03:38 GMT View Forum Message <> Reply to Message Cheers on the nice update guide, will be releasing an update with OSSEC 1.6 pretty soon.

Blame Daniel for not getting it into 1.0.6 :) (Just kidding, OSSEC is awesome.)

Subject: Re: OSSEC Quick Start Guide Posted by Ahriakin on Wed, 10 Sep 2008 19:42:15 GMT View Forum Message <> Reply to Message


OSSIM

by FUDforum 2.7.7

No problem, I ask enough questions here and obviously use OSSIM enough that I'm glad to be able to give even a little back. Thanks for all your great work.

Subject: ossim for newbies Posted by ashar on Sat, 20 Sep 2008 09:59:00 GMT View Forum Message <> Reply to Message Hi, I have started to document configuration of the various parts, for newbies. I aim to get people started quickly - there is a huge amount to figure out. Let me know if there are any mistakes, and what I should do next. http://sites.google.com/site/ossimnewbie/Home

Subject: Re: OSSEC Quick Start Guide Posted by gsporter on Sat, 20 Sep 2008 23:48:01 GMT View Forum Message <> Reply to Message I also have to give you kudos’s. Sometimes training and documentation doesn't seem that exciting But it can mean the success or failure of a project!

Subject: Re: ossim for newbies Posted by gsporter on Sat, 20 Sep 2008 23:48:46 GMT View Forum Message <> Reply to Message I have to give you kudos’s. Sometimes training and documentation doesn't seem that exciting But it can mean the success or failure of a project!

Subject: Re: ossim for newbies Posted by DK on Fri, 03 Oct 2008 20:54:48 GMT View Forum Message <> Reply to Message Cheers on this, please keep up the awesome work.


OSSIM

by FUDforum 2.7.7

I'd suggest opening an own thread for this (please give me a shout should you want special rights) and updating it frequently, including dates :p

Subject: Documentation Overhaul Posted by gsporter on Sat, 04 Oct 2008 19:01:14 GMT View Forum Message <> Reply to Message If you did not see this in DK's blog PLEASE read before posting questons!!! http://www.alienvault.com/blog/dk Documentation Overhaul Thu, 02 Oct 2008 "Just a quick note to throw some attention at the major changes we are making to the OSSIM documentation section. We're sort-of hiding deprecated or non-important documentation, reorganizing existing one and releasing new stuff such as configuration instructions forthird party devices. "

Configuration http://www.ossim.net/dokuwiki/doku.php?id=documentation:conf iguration

Subject: Re: NagiosQL Walktrough Posted by gsporter on Wed, 08 Oct 2008 23:57:57 GMT View Forum Message <> Reply to Message Quick question. Which versions did you use nagiosql-2.0.2.tar.gz /installer 1.04/6? Thanks GP

Subject: Osiris - Quick Guide Posted by Ahriakin on Sun, 12 Oct 2008 01:54:15 GMT View Forum Message <> Reply to Message Hi folks,


OSSIM

by FUDforum 2.7.7

Just like the OSSEC guide this is just to get you going, if you want to delve into Osiris properly I highly recommend "Host Integrity Monitoring using Osiris and Samhain" by Brian Wotring ( http://www.amazon.com/Integrity-Monitoring-Using-Osiris-Samh ain/dp/1597490180/ref=sr_1_1?ie=UTF8&s=books&qid=122 3771961&sr=8-1). Firstly why would you want to use Osiris when you use OSSEC? OSSEC is more fully featured in that it performs system file, registry, service, , rootkit checks, parses Syslog etc. with some event correlation whereas Osiris is mainly a file integrity (change) monitor with some extra modules for detecting changes in services, ports and s. If you had to choose between the 2 then OSSEC is a better bet for intensive monitoring (it also works brilliantly within allowing you to use it to filter Syslog and other events from it's own engine before placing them in the Database which can save you a lot of U cycles if your OSSEC server is a child OSSIM server), but that's just it it is intensive whereas Osiris is more easily tuned and less resource intensive. \ By default OSSEC agents run their system checks every 6 hours (you can change this but I'll place that note in the OSSEC thread). If you increase the frequency you run the risk of degrading host performance but at the same time I think you need more granularity in the logs, at least for the more important files. What I like to do is running Osiris every 2 hours to bridge the gaps between the more intensive OSSEC scans. I may change this in the future but for now I think it works well. I'm also planning on setting up a second scan weekly that does not purge the databases so I have a 7 day snapshot of the files for my records but I'm getting a but beyond the scope of this guide, just trying to make it clear why I still use Osiris in conjunction with OSSEC. Anyway on to the installation/config: **************************************************** Osiris agents work differently to OSSEC. With OSSEC you created keys on the server and imported them to the agents, from then on the agents run on their own schedule with their own configs and report the results back to the server based on the xxxxx value in ossec.conf. Osiris agents work differently in that they are essentially like remote sockets to which the Server will push the scan config and request scans when needed, i.e. the agent will do nothing on it's own, it always waits for instructions from the Master server. You do not need to manually create and import authentication keys it uses certificates, when you install an agent it will listen for and trust the first master server that s it, after that it will only accept communications from that server as it saves it's certificate. You still have to create clients on the Master Server

Server Configuration - Configs Before configuring within Osiris itself you will want to view and perhaps modify the configs it will use on the agents. Since Osiris keeps all of it's config data within flat files you can edit them with nano, though many can be configured within Osiris CLI itself I prefer to do it


OSSIM

by FUDforum 2.7.7

manually outside. The host config files are located in /var/lib/osirismd/configs/ . In the following example I will read and modify the Server 2003 config to change the file hash method to SHA1 and add the optional module for reading port changes, add scanning of C:\Windows (Osiris defaults to using c:\winnt as the Windows folder, adding a folder that does not exist (i.e. having both Winnt and Windows) will not cause any issues as it will just skip the one that isn't there) and include .bat and .scr files in the scan filetypes, finally I will add an exclusion to ignore my Symantec AV definition folder aswell as the OCS Inventory Agent folder (as they change a lot and yield log-noise false positives). enter the config folder 1. cd /var/lib/osirismd/configs/ run 'ls' to read the directory and then 'nano' your config file 2. nano default.windowsserver2003 change the hash method to SHA1 3. Change 'Hash md5' to 'Hash sha1' add the port module 4. Under <system> add 'Include mod_ports' add .bat and .scr to the filetypes to scan 5. Under add 'Include suffix("bat")' and 'Include suffix("scr")' Add the same scanning options for c:\windows 6. Highlight the entire section (including , press CTRL+C, move the cursor to below that Directory section and right-click to paste (most terminal emulators follow that convention, if yours doesn't then find how to paste). Edit the new line to read Exclude the Symantec definition and OCS folders 7. Under add : NoEntry OCS Inventory Agent NoEntry Common Files\Symantec Shared\VirusDefs NoEntry Common Files\Symantec Shared\SymcData NoEntry Symantec\Symantec Endpoint Protection Manager\Inetpub\content NoEntry SAV\I2_LDVP.VDB NoEntry Symantec AntiVirus\I2_LDVP.VDB Save and exit 8. Press CTRL+X, Y to save changes and accept the same filename. OPTIONAL: Use the same config for your Windows 2000 Servers 9. Rename the existing Server 2000 config mv default.windows2000 default.windows2000.old. Copy your modified 2003 config to replace it default.windowsserver2003 default.windows2000 When you look at the config files you'll see they are very intuitive so adding files, including/excluding folders etc. is quite easy. Just that if you modify a config and want to manually scan an existing client you need to push the config first, if you manually start a scan it does not send the new config (however the scheduled scans always push the current config first so they are covered).


OSSIM

by FUDforum 2.7.7

********** Installing the Linux agent 1. apt-get install osiris That's it :) - if you are doing this on an existing server like an OSSIM child server remove it first (apt-get remove osiris). ********** Installing the Windows Agent 1. Get the executable from OSSIM / TOOLS / S and run it. When presented with the installation options only leave the Osiris agent ticked and continue until complete. ********** Adding clients to the Master Server 1. From the server CLI just run the command osiris (Its in the path so you don't need to specify any folders), / = (make sure to change the when inside) 2. Press ? for help. Again you will see the layout is very intuitive. 3. Edit basic server parameters: edit-mhost (mainly here if you plan on using email alerts outside of OSSIM add your default address, you can override this on each client if you wish but it can save sometime just to do it here, add your SMTP host and if you wish modify the Authorized management hosts (I advise you to just leave it on the default of 127.0.0.1 so it can only be edited when logged into the server directly). 4. Edit s: edit-s Add a new or change the - WARNING it does not prompt you to your changes so make sure you get it right :), it's a good idea to add a backdoor for this reason. 5. Add new clients - I'm going with the OSSIM recommended setup, only changing the email options and scheduling. new-host - Name (only significant to Osiris, but it's a good idea to match it to the hostname or functional name you use in all of OSSIM's other tools (I like to use (location)-(type)-(hostname) e.g. A server called SuperServer in Orlando would be orl-SRVR-SuperServer). The name is similar to IDs in OSSEC, it is how you identify the client through the console for all operations. - Hostname/IP (yes you can use the DNS FQDN here if you wish) - Description (up to you) - agent-port (do not change) - enable log files for this host? (Since we are logging to OSSIM no need, and they take up space) - Keep archives of scan databases? (Definitely no as it will keep databases even if no changes are detected...what's the point unless you want a nice warm fuzzy feeling that nothing has changed?) - auto accept changes? (Yes, let it set the new baselines when changes are detected)


OSSIM

by FUDforum 2.7.7

- purge databases? (Again since we are logging to OSSIM leave this as Yes, if disabled each scan of each host is kept on the server and they can pretty soon eat up your storage space this is not your only option for keeping historical data outside of OSSIM though, see the email section below) - enable email notifications for this host? (Here's where I deviate from the OSSIM recommendations as I want historical data available to my colleagues without having them access OSSIM/Osiris directly). I set it to Yes but it's your call. -- send notification on scheduled scan failures? (Yes, I want to know if it didn't run). - send scan notification, even when no changes detected? (No, again I think this is pointless unless it is required by your security policy). - send notification when agent has lost session key? (I set it to Yes, Clients use the same session key with the Server until their Osirisd service is restarted. It will happen naturally when the client is rebooted, but if the client lost it's session key and it wasn't rebooted then someone restarted the service and that is a wee bit suspicious to me and you may need the event later for correlation). - notification email? (here you can override the default email address you entered when you used 'edit-most' earlier to set some basic server parameters, leaving it blank just uses that default address) - configure scan scheduling information? (yes) - enter the start date and time - enter the scan frequency (enter the time between scans in minutes. The default is 4 hours, I prefer 2 - I am using Osiris to fill the gaps between the OSSEC scans (6 hours). If you are entering a lot of hosts at once I recommend varying your scan frequency a little, e.g. 1st = 120, next = 121, next = 119 etc. This way over time the scans will move apart and you randomize the scan times a bit to reduce the load on your Master Server) - enable this host (Yes). The server will the client and provided it is a clean install of Osiris it will show you the OS type and ask if you want to use the default config (since we edited that config earlier we can accept it). And finally initialize and begin scanning the host. ******** Getting OSSIM to read the Osiris events - Credit to Crislato for clarifying this for me 1. Edit the agent configuration on the Master Server nano /etc/ossim/agent/plugins/osiris.cfg Under the [translation] section add all of the clients you added previously with the same Names and IP addresses you used within Osiris. 2. Restart the OSSIM agent /etc/init.d/ossim-agent restart ************************************************ I mentioned setting up email alerts earlier and the reason I do is my default address is a mailbox that my colleagues also have access to. They can quickly read the email alerts for the servers they need details on for the time period in question right from their email clients rather


OSSIM

by FUDforum 2.7.7

than me having to show them how to navigate OSSIM (and restoring archived data for older events). I find it pretty handy. Also I advise setting up a Plugin group called HIMS, adding only Osiris, and adding it as an Event filter so you can quickly just view Osiris events from within OSSIM. Anyway I hope this helps.

Subject: Re: Installing the OSSEC Web Interface on OSSIM Posted by gmicalzoma on Mon, 03 Nov 2008 22:25:22 GMT View Forum Message <> Reply to Message Thanks gsporter, it works like a charm, cheers!!!!

Subject: Installing Webmin Posted by kristian_paul on Thu, 06 Nov 2008 14:57:21 GMT View Forum Message <> Reply to Message Installing Webmin Webmin is a great tool for manage a gnu/linux system using a web framework ( don't leave the powerful console)

1. Edit the /etc/apt/sources.list file on your system and add the line : deb http://.webmin.com//repository sarge contrib 2. You should also fetch and install a GPG key with which the repository is signed : cd /root wget http://www.webmin.com/jcameron-key.asc apt-key add jcameron-key.asc 3. You will now be able to install: apt-get update apt-get install webmin

Adding Webmin to OSSIM Framework 1. edit: /usr/share/ossim/www/top.php


OSSIM

by FUDforum 2.7.7

add: if (Session::menu_perms("MenuConfiguration", "ConfigurationSystem")) $menu["Configuration"][] = array( "name" => gettext("System"), "id" => "System", "url" => "https://ossimip:10000" ); 2. edit: /usr/share/ossim/include/ossim_acl.inc add: "ConfigurationMaps" => array ( "name" => "Configuration -> System", "default_perm" => true ),

Go => reload ACl Done, know you can access webmin at Configuration => System

Subject: Re: NagiosQL Walktrough Posted by umarzuki on Mon, 17 Nov 2008 23:25:10 GMT View Forum Message <> Reply to Message that was 1.0.4

Subject: Re: ossim for newbies Posted by umarzuki on Mon, 17 Nov 2008 23:34:20 GMT View Forum Message <> Reply to Message ashar wrote on Sat, 20 September 2008 03:59Hi, I have started to document configuration of the various parts, for newbies. I aim to get people started quickly - there is a huge amount to figure out. Let me know if there are any mistakes, and what I should do next.


OSSIM

by FUDforum 2.7.7

http://sites.google.com/site/ossimnewbie/Home How about one that I'm trying to figure out here https://www.ossim.net/forum/index.php?t=msg&goto=1522&am p;S=82542d405b07209204333f984f11d169#msg_1522 and the right way for sending sms and e-mail alert (my last attempt on 1.0.4 didn't work) or would it be possible for a (annoying) pop-up message?

Subject: Re: Installing Webmin Posted by kurtsecure on Tue, 18 Nov 2008 17:40:11 GMT View Forum Message <> Reply to Message This is excellent although a couple of typos: apt-get install should be apt-get install webmin /usr/share/ossim/include/ossim.acl.inc should be /usr/share/ossim/include/ossim_acl.inc

Thanks Kurt

Subject: Re: ossim for newbies Posted by dropadrop on Wed, 19 Nov 2008 12:53:50 GMT View Forum Message <> Reply to Message Thanks, nice instructions. There is a typo on your interfaces page concerning eth1 though: Quote: down ifconfig down

for eth2 it's correct.

Subject: Bare metal back up and restore Posted by here2serve on Fri, 21 Nov 2008 20:30:48 GMT Page 23 of 123 ---- Generated from

OSSIM

by FUDforum 2.7.7

View Forum Message <> Reply to Message We wanted a fool proof back up and restore. That would not require any real thought or skill. Restoring from scratch with this method took less than 25 minutes. Backup script #!/bin/bash #Proccesses to shut down before backup,apache2,arpwatch,cron,munin-node #mysql,mysql-ndb,mysql-ndb-mgm,nagios2,nessusd,ntop,openvpn, osirisd #osirismd,ossec,ossim-agent,ossim-framework,ossim-server,pad s,snmpd,snmptrapfmt #snort,ssh,webmin /etc/init.d/arpwatch stop /etc/init.d/ntop stop /etc/init.d/munin-node stop /etc/init.d/apache2 stop /etc/init.d/nagios2 stop /etc/init.d/openvpn stop /etc/init.d/osirisd stop /etc/init.d/osirismd stop /etc/init.d/ossec stop /etc/init.d/ossim-agent stop /etc/init.d/ossim-framework stop /etc/init.d/ossim-server stop /etc/init.d/pads stop /etc/init.d/snmpd stop /etc/init.d/snmptrapfmt stop /etc/init.d/snort stop /etc/init.d/ssh stop /etc/init.d/webmin stop /etc/init.d/cron stop /etc/init.d/mysql stop /etc/init.d/mysql-ndb stop /etc/init.d/mysql-ndb-mgm stop tar cvpzf /mnt/backup/backup.tgz --exclude=/proc --exclude=/lost+found --exclude=/mnt --exclude=/sys / reboot -n Restore Script !#/bin/bash #restore Script /media/cdrom0/*.tgz /backup.tgz tar xvpfz /backup.tgz -C /


OSSIM

by FUDforum 2.7.7

reboot -n

Directions for the Tech OSSIM Restore In case of a system failure you will need the OSSIM cd and the most recent full back up and restore script. The full system back up and script can be found on (what ever location) 1. Unplug the NIC, Boot from the OSSIM cd 2. Enter what ever values you like at any prompt. Except under partitioning accept the defaults. 3. After the install is complete put in the backup cd with the restore script. 4. at the prompt as root with whatever you set during the install. 5. type " mount /dev/hda " 6. type "/media/cdrom0/./restore.sh " 7. After it is finished restoring it will reboot. Remove the cd, plug in the NIC, and test out your restored system. All s,original s, data and programs should be available.

I don't know if you really need to kill all the services in the back up script but it works. The Idea came from a forum somewhere. Just don't know which one.

Subject: Re: Bare metal back up and restore Posted by kristian_paul on Fri, 21 Nov 2008 20:42:17 GMT View Forum Message <> Reply to Message need to add monit process or you'll get all ossim process stuff running again

Subject: Important configuration files Posted by umarzuki on Sat, 22 Nov 2008 14:53:01 GMT View Forum Message <> Reply to Message This is sort of a quick info page for ossim s. The main reason I posted it here so I can check on it back later. I'm a very forgetful person ;) You all can add up and correct me if I'm wrong. Highly appreciate it. /home/ossim/dist/ossim-update.pl is to update your OSSIM to current version.


OSSIM

by FUDforum 2.7.7

/etc/ossim/ossim_setup.conf is where you can configure information on various things such as mysql's root , sensor, main NIC and such. /home/ossim/dist/reconfig.pl is to update informations on interfaces and related configurations that you had done manually.

Subject: Re: Bare metal back up and restore Posted by here2serve on Tue, 25 Nov 2008 09:49:11 GMT View Forum Message <> Reply to Message I tested it 3 times and it worked like a champ. I kind of thought I was killing more stuff than needed.

Subject: Re: OSSEC Quick Start Guide Posted by redbarron on Mon, 01 Dec 2008 15:45:44 GMT View Forum Message <> Reply to Message So, if I upgrade my OSSEC via this guide, what happens when 1.07 (presumably) comes out with 1.6 and I run ossim-update.pl on my 1.06 box. Do I need to be concerned with breakage? Thanks!

DK wrote on Wed, 10 September 2008 15:03Cheers on the nice update guide, will be releasing an update with OSSEC 1.6 pretty soon.


Subject: Install Oinkmaster and update snort rules Posted by umarzuki on Wed, 03 Dec 2008 13:13:14 GMT View Forum Message <> Reply to Message This is some sort of a walktrough in hope anyone can benefit from my past experience Install oinkmaster packageaptitude install oinkmaster at snort's site to get access and the rules from http://www.snort.org/ Get the oinkcode


OSSIM

by FUDforum 2.7.7

Edit oinkmaster.confvi /etc/oinkmaster.conf commentQuote:url = http://www.snort.org/dl/rules/snortrules-snapshot-2_2.tar.gzand place under itQuote:url = http://www.snort.org/pub-bin/oinkmaster.cgi/your-oinkcode/sn ortrules-snapshot-2.7.tar.gz To make list of what rules have been disabled/usr/share/oinkmaster/makesidex.pl /etc/snort/rules/ >autodisable.conf As normal , update rules withoinkmaster -C /etc/oinkmaster.conf -C /etc/autodisable.conf -o /etc/snort/rules/ Run create_sidmap.pl (Generates the priority and reliability level for every snort rule)perl /usr/share/ossim/scripts/create_sidmap.pl /etc/snort/rules/ Restart ossim-server/etc/init.d/ossim-server restart *The last two steps were pointed out by juanma Credits to http://internetsecurityguru.com/ and ossim forum . Note: Later the next day, I got mysql error about not be able to access certain socket (I forgot to copy the error message) but I don't know if this related to oinkmaster. A quick reconfig withperl /home/ossim/dist/reconfig.plwould fix that. At least visually :)

note: I've modified the post so it points to the correct scripts, thank you. Juanma

Subject: Re: Install Oinkmaster and update snort rules Posted by juanma on Fri, 05 Dec 2008 03:56:10 GMT View Forum Message <> Reply to Message Hi umarzuki Thanks a lot for writing this tutorial. Just two notes, every time you add new snort rules in ossim you have to run: perl /usr/share/ossim/scripts/create_sidmap.pl /etc/snort/rules/ and restart the ossim-server. This is going to insert into the database the priority and reliability information for all the new rules into the database.Without this info the server is not going to store any event coming from the new snort rules. Also as a note, you do not have to run reconfig.pl after ing new rules. It would be nice if you could update your tutorial, if you can not do that just let me know and I'll edit your post. Thank you Juanma


OSSIM

by FUDforum 2.7.7

***Note: I've edited my post, I was talking about create_sidmap.pl, but the command I was running was reconfig.pl

Subject: Re: Bare metal back up and restore Posted by here2serve on Sat, 06 Dec 2008 14:23:39 GMT View Forum Message <> Reply to Message I was having some trouble with rrd_threshold. I took your suggestion to add monit to the processes that need to be stopped during backup. rrd is back up again. I'll continue monitoring to see if this fixed my rrd problem or not. Looks good for now. Thanks- Would love to know why it came back but it's just good to have it working again. The box I am using started off with the 1.04 installer and has all it's up dates. I may be able to free up another box to run up with the 1.06. After adding monit to to script I tried to restore from backup. Mysqld fails to start. Had to go back to dec 6 backup/Troubleshoot Mysqld.

Subject: Re: Bare metal back up and restore Posted by here2serve on Sat, 06 Dec 2008 14:43:54 GMT View Forum Message <> Reply to Message Spoke to soon rrd is down. Back to the rrd forum.

Subject: OSSIM@VMWARE Posted by udom on Mon, 08 Dec 2008 10:16:29 GMT View Forum Message <> Reply to Message Hi, in version 1.0.6 of ossim-installer = debian 2.6.18 at vmware esx 2.5.1 and 2.5.4 and probably some more versions) the clock is not synchronized. I solved the problem by using vmware-tools but the configuration of the vmware-tools is not working without doing some changes. Here is the full list of the necessary commands: apt-get install autoconf automake make psmisc gcc apt-get install linux-headers-`uname -r` build-essential


OSSIM

by FUDforum 2.7.7

tar -xzvf VMwareTools-######.tar.gz cd vmware-tools-distrib ./vmware-install.pl #all default-values are ok, but do not configure at the end of the install-script! cd /usr/src/linux-headers-`uname -r`/include/linux cat utsrelease.h >> version.h vmware-tools-config.pl # all default-values are ok reboot and the clock ist synchronized

Subject: SNORT - Fast Sensor Up to date Posted by sapling on Wed, 10 Dec 2008 20:09:53 GMT View Forum Message <> Reply to Message First of all I would like to say that although I like OSSIM and its abilities I do not like the agent. I seem to have nothing but issues trying to get the agent to properly give OSSIM servers data from agents. The other problem I have is that by default the OSSIM installer for a server is way to slow and not easy to customize for my needs. Not the speed of which it installs but its ability to handle data and create alerts. This is why I decided that I would build a snort sensor that was capable of handling a large flow of data. My snort sensor is capable of handling all of the rules turned on if I so desired and capture full packets from a our bandwidth which is 3xT1's. I am not logging in unified format and send the data directly into mysql. On top of all of this I am running it on a Pentium 4 Single Core 2.4Ghz desktop machine with 1.5Gb's of RAM without any dropped packets. I have a single 80Gb 7200RPM IDE drive.

So with that in mind let me begin my tutorial... Insert a minimal installer disk for debian. Install debian with no additional packages selected. So in other words when it asks if you want Server files, Desktop files, etc... unselect all the options so that it installs only the minimal


OSSIM

by FUDforum 2.7.7

packages. Next for my purpose of I decided to give my system 4Gb's of Swap space and formatted the system using ext 2 file system. The reason I decided on ext 2 was for the speed of the reading and writing. Once my system has rebooted and I have my new command line server I get to work. First I edit the sources from etch to testing distribution because I want the newest packages. #nano /etc/apt/sources.list Change everywhere it says etch to testing... #apt-get update #apt-get upgrade #apt-get dist-upgrade #apt-get upgrade reboot Double check to make sure your system is fully up to date and there are no newer versions out there. Install some required files onto the system for the packages I will be installing. #apt-get install gcc g++ make flex gawk automake bison byacc \ libc6 libc6-dev build-essential libtool autoconf mysql-common \ libmysqlclient15-dev libnet1 libnet1-dev libpcre3 libpcre3-dev \ ssh

Now that we have the required packages for snort it's time to install a special version of libpcap. This version of libpcap has mmap enabled. This means that instead of snort waiting for libpcap to move or copy the packets into land memory it enables snort to pull directly from memory where the packets are first written. So lets go ahead and it. #wget http://public.lanl.gov/w/libpcap-0.9.8.20081022.tar.gz #mv libpcap-0.9.8.20081022.tar.gz /usr/src #cd /usr/src #tar xvzf libpcap-0.9.8.20081022.tar.gz #cd libpcap-0.9.8.20081022 #bash bootstrap answer with a lowercase y I like to use c flags for optimization when I install libpcap and snort so feel free to ignore this if you dont want to use my c flats #CFLAGS=-O3 ./configure --enable-shared make make install Copy the following files to the following directories # ./libs/libpcap-0.9.8.so /lib/libpcap.so # ./libs/libpcap-0.9.8.so /lib/libpcap-0.9.8.so # pcap.h /usr/include # pcap-bpf.h /usr/include Now you will need to and install snort I am using the latest stable version at this time 2.8.3.1....


OSSIM

by FUDforum 2.7.7

#cd /usr/src #wget http://www.snort.org/dl/snort-2.8.3.1.tar.gz #tar -xvzf snort-2.8.3.1.tar.gz #cd snort-2.8.3.1 #CFLAGS=-O3 ./configure --with-mysql --enable-dynamilugin #make #make install #mkdir /etc/snort #mkdir /etc/snort/rules #mkdir /var/log/snort #addgroup snort #add -g snort snort #chown snort:snort /var/log/snort # etc/*.conf* /etc/snort/ # etc/*.map /etc/snort/ I use oinkmaster for my rules because its easier when using the emerging threat rules as they change sometimes daily and it updates your sids for you. #apt-get install oinkmaster Edit oinkmaster to the latest free ruleset and enter your oinkcode assuming your ed at snort.org add in the following url to get the emerging threat rules http://www.emergingthreats.net/rules/emerging.rules.tar.gz #oinkmaster -o /etc/snort/rules In the future if you want to backup your rules you can always use the -b flag to specify a directory to backup the old rule sets. I create a simple little script for the purpose of starting snort and the key here is that. ========/etc/init.d/snort========== #!/bin/bash ifconfig eth0 up #change this to whatever sniffing interface you so desire to use PCAP_MEMORY=650000 snort -c /etc/snort/snort.conf -D -i eth0 -M -u snort -g snort -P 65000 =================================== Explanation of the above: Check to make sure the interface is up Dedicate 650,000kb to snort and use that config in Daemon mode, sniff on interface eth0, Log messages to /var/log/syslog to gather information back, use snort and group snort, and capture the first 65000 bytes. Now I know I said I do full packet captures and I do sorta, I dont capture the tail because of a bug in something I did earlier I can actually run that command with 65412 which isn't the maximum size a packet can be but you will be hard pressed to find packets this large most of the time.


OSSIM

by FUDforum 2.7.7

#chmod +x /etc/init.d/snort Modify your snort config to include your emerging threat rules and configure it to log to your database on your ossim server. ======================================= output database: log, mysql, =root =your dbname=snort host=ossim server ip sensor_name=I use local ip addresses here output database: alert, mysql, =root =your dbname=snort host=ossim server ip sensor_name=I use local ip addresses here ======================================= Now we need to make a change on the ossim server so that it will allow us to log to the database. First modify the mysql server to listen on an accessible ip address... Through the /etc/mysql/my.cnf and just to make sure that it doesnt get changed I went ahead and modified the file /etc/ossim/ossim_setup.conf Then make sure you tell the database that the is allowed to access things from that ip address. I stuck with using the root for this tutorial because I wanted to keep things simple but you could always create other s that have limited access in mysql. #mysql -u root -p mysql> GRANT create,insert,select,update,delete on snort.* to root@$mysensor1IPaddress identified by 'my'; mysql>GRANT create,insert,select,update,delete on snort.* to root@$mysensor2IPaddress identified by 'my'; #make sure your is the one from the ossim_setup.conf if you use root Modify the snort database so that it can be used by the latest version of snort... mysql> use snort; mysql> ALTER TABLES signature ADD sig_gid INT UNSIGNED; mysql> INSERT INTO `schema` (vseq, ctime) VALUES ('107', now()); mysql> DELETE FROM `schema` WHERE vseq=106; That should take care of it all. Now if you want to determine how many packets your dropping based on all of this you can do the following. You can enable all rules if you like through this oinkmaster command... #oinkmaster -e -o /etc/snort/rules Now all your rules are turned on which I dont recommend because there are some noisy ones. Just try and keep things to what might happen on your network. Then go ahead and start snort up in another screen without the -D So use this command...


OSSIM

by FUDforum 2.7.7

#apt-get install screen #screen -S snort #PCAP_MEMORY=650000 snort -c /etc/snort/snort.conf -i eth0 -M -u snort -g snort -P 65000 Hit Ctrl+a+d to minimize that screen and allow snort to run during a busy time on your network. Go back into the screen snorts running on with... #screen -x snort Ctrl+c to kill the process and if you like restart it again this time you can use the -D if you want it to run in the background without issues. Ctrl+a+d again and now run this command #cat /var/log/syslog |grep Dropped This should show you how many packets if any snort dropped mine always says 0% 0 Enjoy!

Subject: Re: OSSEC Quick Start Guide Posted by javieralbarra on Wed, 10 Dec 2008 21:42:12 GMT View Forum Message <> Reply to Message Problem Update #ossim:/tmp/ossec-hids-1.6.1# ./install.sh

os_xml_writer.c:74: error: for each function it appears in.) os_xml_writer.c:74: error: 'fp_in' undeclared (first use in this function) os_xml_writer.c:75: error: 'fp_out' undeclared (first use in this function) os_xml_writer.c:85: warning: implicit declaration of function 'fopen' os_xml_writer.c:96: warning: implicit declaration of function 'fclose' os_xml_writer.c:101: warning: implicit declaration of function '_WReadElem' os_xml_writer.c:115: warning: implicit declaration of function 'fseek' os_xml_writer.c:115: error: 'SEEK_END' undeclared (first use in this function) os_xml_writer.c:116: warning: implicit declaration of function 'fprintf' os_xml_writer.c:116: warning: incompatible implicit declaration of built-in function 'fprintf' os_xml_writer.c: At top level: os_xml_writer.c:153: error: expected ')' before '*' token os_xml_writer.c:204: error: expected ')' before '*' token make[1]: *** [xml] Error 1 make[1]: Leaving directory `/tmp/ossec-hids-1.6.1/src/os_xml' Error Making os_xml make: *** [all] Error 1


OSSIM

by FUDforum 2.7.7

Error 0x5. Building error. Unable to finish the installation.

Subject: Re: SNORT - Fast Sensor Up to date Posted by kristian_paul on Tue, 16 Dec 2008 21:23:42 GMT View Forum Message <> Reply to Message are you sure sending events to snort database is the best way to improcve? i remenber ossim earlies it used that method, and was replaced for the unfied format (kind of formate binary info) with the intention of be able to send more data faster on high trafic network (ej: 500 mbs) in my point of view, put snort write to databse alone with acidabase is ok, but remeber that ossim exists (if u think snort + spade + ossim system) - also all that info is saved on mysql databases for future analisis other point is: if ur trying improve package capture there are experimental approaches out there like PF RING and Streamline (FFPF), or just begin disabling device polling, in fact there is a big work to do around that area (http://sc08.supercomputing.org/)

Subject: Re: SNORT - Fast Sensor Up to date Posted by sapling on Tue, 23 Dec 2008 19:28:22 GMT View Forum Message <> Reply to Message You bring up some very good things and I am here to address them. First yes on heavier networks you should absolutely use Binary output aka unified in conjunction with Barnyard sending the alerts to Mysql. Why? Well if you want snort to move a quickly as possible and capture everything it takes less time for it to keep everything in binary format. AKA Snort doesnt have to convert anything to readable formats. But why barnyard? Well because taking the burden off of snort by using an additional program to convert from unified format over to readable and inserting into our database... Cant OSSIM do this? Well ossim will send the unified format over to the OSSIM_Server however when I attempted this I ran into a many issues. Also it put more burden on my already


OSSIM

by FUDforum 2.7.7

heavily loaded OSSIM_server. Second PF_RING: Well you have to first understand PF_RING and MMAP on a more indepth basis before you go assuming one is better. The benefits of PF_RING are... It handles more volume and its not as sloppy and it doesnt require the kernel as much which means kernel related tasks are now free to continue... MMAP - Allows us to get our packets directly out of RAM so we can analyze them immediately. So when does it really have an advantage over PF_RING? When your dealing with larger packets. In the article I am assuming you read Advanced Packet Capturing he touched the surface of how PF_RING is generally only about .5% slower than MMAP when the packet is 1500bytes long and the bandwidth is full... Well how about when you have a larger packet come across? Tried it? Yes I have... MMAP due to the fact I am giving it Direct Memory allocation can handle it while PF_RING begins to lose focus. So its greatest benefit is for Lots of Packets which are smaller. Making it perfect for NTOP, and other systems that only pull the first 1000 bytes or so. Any other benefits to MMAP? yes its easier to install and get working if your not running RED-HAT... What about PF_RING? Not only is it a kernel patch meaning there is no longer and interaction, but from what I understand you shouldnt need to do anything extra to make it work. As long as your libpcap version s PF_RING then you dont have to worry about your applications being allocated x memory. In the articles I have been reading as well I dont like that they only use MMAP at its basic stages... using PCAP_PACKETS=max is not the best solution if your trying to make sure nothing gets dropped like in my case. I want EVERYTHING. So I use PCAP_MEMORY= (meaning I tell it instead of allocating the based on maximum packets Allocate me a chunk of memory which is the more ideal solution if your are capturing larger packets) How do I know if my packets are that large? If your NTOP is running it will tell you... On my network its not as common but I do see packets above 1500 bytes because we dont restrict it on the routers. I am not the network dont ask me... So if your not seeing a lot of packets over 1500 yes PF_RING will be a great solution.

So they apparently have been improving the PF_RING work as I read but I can't say for sure if it is the ultimate solution. What I can say is for most of us try both and try and turn on everything. If all goes smoothly on a lower class machine on one way than the other then you have your solution.

Now what I have also read is that adding in a few other patches such as the RTIRQ patch will increase even further the amount you can capture with PF_RING. Again test it out... My tutorial is just so you can understand how I am doing it and to improve your homegrown ossim solution.


OSSIM

by FUDforum 2.7.7

I do recommend though if you are concerned with the mysql solution adding in barnyard and have it perform the MYSQL transfers as I do still believe you should get it into mysql as well.

Subject: Re: SNORT - Fast Sensor Up to date Posted by DK on Fri, 09 Jan 2009 10:12:37 GMT View Forum Message <> Reply to Message I'd like to this interesting discussion :) Personally I've had very good experiences using PF_RING, getting to a <1% package loss with 2 interfaces sniffing at around 900Mbps each. As for the database output part, last time I checked into it snort was single-threaded; capture / analysis and output sharing a single thread. That would mean it's not optimal for any type of serious capture. On the other hand, since you're talking about 3xT1 (4.5Mbps), you really don't have to check onto PF_RING and such. But as said, I disagree with direct database output and, if you having issues with the agent, barnyard should be the way to go. Fixing the issues you've got with the agent would be even better ;)

Subject: Re: OSSEC Quick Start Guide Posted by DK on Fri, 09 Jan 2009 10:14:11 GMT View Forum Message <> Reply to Message javieralbarra wrote on Wed, 10 December 2008 22:42Problem Update #ossim:/tmp/ossec-hids-1.6.1# ./install.sh

os_xml_writer.c:74: error: for each function it appears in.) os_xml_writer.c:74: error: 'fp_in' undeclared (first use in this function) os_xml_writer.c:75: error: 'fp_out' undeclared (first use in this function) os_xml_writer.c:85: warning: implicit declaration of function 'fopen' os_xml_writer.c:96: warning: implicit declaration of function 'fclose' os_xml_writer.c:101: warning: implicit declaration of function '_WReadElem' os_xml_writer.c:115: warning: implicit declaration of function 'fseek' os_xml_writer.c:115: error: 'SEEK_END' undeclared (first use in this function)


OSSIM

by FUDforum 2.7.7

os_xml_writer.c:116: warning: implicit declaration of function 'fprintf' os_xml_writer.c:116: warning: incompatible implicit declaration of built-in function 'fprintf' os_xml_writer.c: At top level: os_xml_writer.c:153: error: expected ')' before '*' token os_xml_writer.c:204: error: expected ')' before '*' token make[1]: *** [xml] Error 1 make[1]: Leaving directory `/tmp/ossec-hids-1.6.1/src/os_xml' Error Making os_xml make: *** [all] Error 1 Error 0x5. Building error. Unable to finish the installation.

This looks like either an OSSEC issue or a compilation environment issue to me. The installer isn't meant to be a complete development environment :)

Subject: Re: OSSEC Quick Start Guide Posted by DK on Fri, 09 Jan 2009 10:16:47 GMT View Forum Message <> Reply to Message redbarron wrote on Mon, 01 December 2008 16:45So, if I upgrade my OSSEC via this guide, what happens when 1.07 (presumably) comes out with 1.6 and I run ossim-update.pl on my 1.06 box. Do I need to be concerned with breakage? Thanks!

DK wrote on Wed, 10 September 2008 15:03Cheers on the nice update guide, will be releasing an update with OSSEC 1.6 pretty soon.


No, an ossec update shouldn't break that becasue either we include the new one (it would overwrite yours) or don't touch it.

Subject: Re: OSSEC Quick Start Guide Posted by blucas on Sun, 08 Feb 2009 22:20:31 GMT View Forum Message <> Reply to Message


OSSIM

by FUDforum 2.7.7

Hello all, I'm newbie at linux and even more at OSSIM, i try to do the ossec, but i always get this msg. ossim:/tmp/ossec-hids-1.6.1# ./install.sh ** Para instalaÃ§Ã£o em portuguÃªs, escolha [br]. ** è¦ä½¿ç¨ä¸-æè¿¡å®è£ , è¯·éæ© [cn]. ** Fur eine deutsche Installation wohlen Sie [de]. ** ÎÎ¹Î± ÎµÎ³ÎºÎ±Ï Î¬ÏÏ Î±ÏÎ· ÏÏ Î± ÎÎ»Î»Î·Î½Î¹ÎºÎ¬, ÎµÏÎ¹Î»Î-Î¾Ï Îµ [el]. ** For installation in English, choose [en]. ** Para instalar en EspaÃ±ol , eliga [es]. ** Pour une installation en franÃ§ais, choisissez [fr] ** Per l'installazione in Italiano, scegli [it]. ** æ¥æ¬èªã§ã¤ã³ã¹ãã¼ã«ãã¾ãï¼é¸æãã¦ä¸ãã ï¼[jp]. ** Aby instalowaÄ w jÄzyku Polskim, wybierz [pl]. ** ÐÐ»Ñ Ð¸Ð½ÑÑÑÑÐºÑÐ¸Ð¹ Ð¿Ð¾ ÑÑÑÐ°Ð½Ð¾Ð²ÐºÐµ Ð½Ð° ÑÑÑÑÐºÐ¾Ð¼ ,Ð²Ð²ÐµÐ´Ð¸ÑÐµ [ru]. ** Za instalaciju na srpskom, izaberi [sr]. ** TÃ¼rkÃ§e kurulum iÃ§in seÃ§in [tr]. (en/br/cn/de/el/es/fr/it/jp/pl/ru/sr/tr) [en]:

Error 0x3. You need a compiler (like gcc or cc) to continue with the with the installation. ossim:/tmp/ossec-hids-1.6.1# I even tried with ver. 1.6, and i got the same error. Does anyone know why this happen? Thanks for the great work. Regards Blucas


OSSIM

by FUDforum 2.7.7

Subject: Re: OSSEC Quick Start Guide Posted by gsporter on Mon, 09 Feb 2009 01:11:39 GMT View Forum Message <> Reply to Message I assume you are working with a install from the installer? It should have gcc included. Try running this to check and see if gcc is installed

# dpkg -l | grep gcc You should get an output similar to this: ii gcc-4.1-base package) ii libgcc1

4.1.1-21

The GNU Compiler Collection (base

4.1.1-21

GCC library

Since OSSIM is an appliance rather than a development environment it does not have all the development tools installed. Try running this: apt-get install build-essential then retrying the install script. GP

Subject: Re: OSSEC Quick Start Guide Posted by hidoa on Fri, 13 Feb 2009 21:56:32 GMT View Forum Message <> Reply to Message I have OSSIM 1.06. I see the OSSEC version is 1.4. I tried running the update. I am in /ossec/tmp. I have it extracted to folder. I run ./install.sh. I tell it 'en', then tell it to upgrade, it fails with this error. Error making os_xml make: *** [all] Error 1 Error 0x5 Building error. Unable to finish the installation.


OSSIM

by FUDforum 2.7.7

Takes me back to prompt.... Any ideas?

Subject: Re: Installing the OSSEC Web Interface on OSSIM Posted by hidoa on Fri, 13 Feb 2009 22:03:09 GMT View Forum Message <> Reply to Message I followed the instructions and I get the error below when I try to browse to the site.... My step 5 was ossec:x:113:www-data not ossec:x:1002:www-data. Not sure if that matters or not... Warning: opendir(/var/ossec) [function.opendir]: failed to open dir: Permission denied in /var/www/ossec-wui/lib/os_lib_handle.php on line 94 Unable to access ossec directory.

Subject: Ethernet capture Posted by gsporter on Sun, 15 Feb 2009 00:52:02 GMT View Forum Message <> Reply to Message In talking with my students I realized there is a need to discuss the need for a method of capturing Ethernet traffic. As the industry moves away from shared media (hubs) it becomes more complicated than simply putting your nic in promiscuous mode. The principle methods in use are Taps / Span-Mirroring / Hubs / Inline Machine There is a well written basic discussion on Wireshark site discussing the various methods of capturing Ethernet along with the pros and cons of each method. http://wiki.wireshark.org/CaptureSetup/Ethernet If you to the Snort site there are a number of articles under IDS Deployment Guides” on the requirements for different types of taps http://www.snort.org/docs/ These even include a guide for building your own “ive tap”. This can be important for proto-types, labs etc since commercial taps start at @ $300 and go up. A follow up article on building a ive tap which also covers how to set up nic


OSSIM

by FUDforum 2.7.7

bonding/trunking which is necessary if you want to hear full duplex traffic http://altsec.info/ive-network-tap.html I am including a couple of additional referances on nic bonding also (Note: since OSSIM is based on Debian I have stuck to that distro.) http://www.howtoforge.com/nic_bonding http://packages.debian.org/stable/net/ifenslave

I hope forums readers will post their solutions and ideas here!

Subject: Re: Installing the OSSEC Web Interface on OSSIM Posted by gsporter on Sun, 15 Feb 2009 01:23:00 GMT View Forum Message <> Reply to Message To be honest I can't seem to lay my hands on my orginal documentation. I checked the original OSSEC wiki documentation here: http://www.ossec.net/wiki/index.php/OSSECWUI:Install I checked grep ossec /etc/groups grep ossec /etc/wd I received the same group (113) you did. I believe the problem is to be sure the ossec has permissions to the web directory which is accomplished by making it a part of the apache (www-data) group. I had updated ossec (1.4 to 1.6)on the ossim server using the tutorial on the forums which may for the differance in the group. https://www.ossim.net/forum/index.php?t=msg&th=290&s tart=0&S=449d8eaaa2181cd6b7a6db10b81a833f When I get a few minutes I will do the upgrade/web install and see if I can reproduce the issue.


OSSIM

by FUDforum 2.7.7

GP

Subject: Re: Installing the OSSEC Web Interface on OSSIM Posted by wintech on Mon, 23 Feb 2009 08:24:40 GMT View Forum Message <> Reply to Message Hi, While i try to enable OSSEC WUI i get the following error. Please do help me. I have installed in Centos 5.2 with Apache 2.x.x Version ./setup.sh which: no htwd in (/usr/kerberos/sbin:/usr/kerberos/bin:/usr/local/sbin:/usr/l ocal/bin:/sbin:/bin:/usr/sbin:/usr/bin:/root/bin) which: no htwd2 in (/usr/kerberos/sbin:/usr/kerberos/bin:/usr/local/sbin:/usr/l ocal/bin:/sbin:/bin:/usr/sbin:/usr/bin:/root/bin) Setting up ossec ui... name: name: root ** ERROR: Could not find htwd. No set. :( Regards Wintech

Subject: Re: Installing the OSSEC Web Interface on OSSIM Posted by DK on Mon, 23 Feb 2009 17:41:36 GMT View Forum Message <> Reply to Message OSSEC is searching htwd in your path, try a "find / -name htwd" or "find / -name htwd2", then add that path to your $PATH or link it to some of the paths searched by the wui installer.

Subject: Re: Installing the OSSEC Web Interface on OSSIM Posted by wintech on Tue, 24 Feb 2009 11:37:41 GMT View Forum Message <> Reply to Message Hi,


OSSIM

by FUDforum 2.7.7

Thanks for the reply.. I have rectified the issue. Should i add the Ossec-WUI in Apache Virtual Host directory... When i try to access the site i get "You don't have permission to access /ossec-wui/index.php on this server.". Kindly help on this issue. Regards Wintech

Subject: Re: Installing the OSSEC Web Interface on OSSIM Posted by DK on Tue, 24 Feb 2009 11:43:08 GMT View Forum Message <> Reply to Message You should check your apache logs, I don't know where they are located on CentOS. Maybe it's indeed a permission problem, a symlink problem or it's just trying to reach the wrong site.

Subject: Basic OSSIM 1.0.6 Sensor set up Posted by paul_psmith on Wed, 25 Feb 2009 20:03:32 GMT View Forum Message <> Reply to Message Created this document to build a basic OSSIM sensor on 1.0.6 installer. Shows how to basic configurations to make the sensor just do that and send info to a main server. Assumes main server is DB, Server, webgui, main policy host. Please post changes, ideas, corrections, etc. PS

File Attachments 1) Build OSSIM 1.0.6 sensor.doc, ed 650 times

Subject: Re: Install Oinkmaster and update snort rules Posted by binaryman on Wed, 25 Feb 2009 20:44:39 GMT View Forum Message <> Reply to Message Hi,


OSSIM

by FUDforum 2.7.7

Thanks for this. I was able to perform these steps with a few minor adjustments: 1. I first had to do an "apt-get update" before I could do "aptitude install oinkmaster" 2. You said "Get the oinkcode" which confused me, but I figured out you need to perform the following steps: - Create an at https://www.snort.org - Once you , you will see a section "Oinkmaster Codes" click the "Get Code" button at the very bottom - Follow the instructions in "Configuration Changes:" section 3. You need to make sure you include (/etc) before autodisable.conf if you are not in the /etc directory when running the command: /usr/share/oinkmaster/makesidex.pl /etc/snort/rules/ >/etc/autodisable.conf

Subject: Re: Basic OSSIM 1.0.6 Sensor set up Posted by binaryman on Wed, 25 Feb 2009 21:54:10 GMT View Forum Message <> Reply to Message Thanks Paul, good job. Some comments: 1. According to DK in this post, this is not necessary: Modify the /etc/ossim/ossim_setup.conf file and change two profile= lines to sensor. No other changes needed. a. profile=sensor 2. For step #7, you put "I can’t if I hit “Insert New Sensor” or I clicked the modify button. Will need to fix this." I can confirm you do not need to "Insert New Sensor" it shows up automatically. 3. Can you add the oinkmaster thread (or a link to it). It would be great if we can update this thread on how to configure the sensor for each agent (ie. Nessus, Ntop, OSSEC, etc.), or at least include a link if it is somewhere else in the forum.

Subject: Re: OSSIM@VMWARE Posted by binaryman on Wed, 25 Feb 2009 21:56:25 GMT View Forum Message <> Reply to Message


OSSIM

by FUDforum 2.7.7

Thanks, I needed this.

Subject: Re: Basic OSSIM 1.0.6 Sensor set up Posted by paul_psmith on Wed, 25 Feb 2009 22:32:05 GMT View Forum Message <> Reply to Message Thanks b-man. Ah. i see what you mean on the ossim_setup.conf. i think you might want to change it anyway for forward compatibility with the upgrade? DK could possible answer that. Seems to me after i did that things changed, but maybe that was on the server. i know when i changed it there, the agent stuff went away. I also think this file gets used on boot to tell ossim what this system is used for. So you might be able to remove or add agents there in the sensor area. on step 7, what i meant to say was that the sensor showed up without me doing anything, but had a state of Active=no. i don;t what i did to change it to active=yes. if you let me know. Thanks!!

Subject: Re: Installing the OSSEC Web Interface on OSSIM Posted by wintech on Thu, 26 Feb 2009 08:38:02 GMT View Forum Message <> Reply to Message Hi, I have some other sites accessing same location... All sites works perfect and when i try ossec-wui i can able access the site and i get prompt and after that i get "You don't have permission to access /ossec-wui/index.php on this server.". Please help in this to resolve the issue once for all

Subject: Re: Installing the OSSEC Web Interface on OSSIM Posted by gsporter on Thu, 26 Feb 2009 13:31:25 GMT View Forum Message <> Reply to Message


OSSIM

by FUDforum 2.7.7

I don't have the ossec-wui installed anywhere right now to check but let me see if I understand the problem. When you access the ossec-wui from another box you get the prompt and permission error? If that is what is happening is you didn't assign the apache permissions to the folder. If it is a ossim installer box the apache is www-data. Please let me know if I am not following the problem correctly. GP

Subject: Re: Installing the OSSEC Web Interface on OSSIM Posted by hidoa on Thu, 26 Feb 2009 15:29:54 GMT View Forum Message <> Reply to Message gsporter wrote on Sat, 14 February 2009 18:23To be honest I can't seem to lay my hands on my orginal documentation. I checked the original OSSEC wiki documentation here: http://www.ossec.net/wiki/index.php/OSSECWUI:Install I checked grep ossec /etc/groups grep ossec /etc/wd I received the same group (113) you did. I believe the problem is to be sure the ossec has permissions to the web directory which is accomplished by making it a part of the apache (www-data) group. I had updated ossec (1.4 to 1.6)on the ossim server using the tutorial on the forums which may for the differance in the group. https://www.ossim.net/forum/index.php?t=msg&th=290&s tart=0&S=449d8eaaa2181cd6b7a6db10b81a833f When I get a few minutes I will do the upgrade/web install and see if I can reproduce the issue.

GP GP, I do have the ossec in the www-data group.


OSSIM

by FUDforum 2.7.7

This line in etc/group - ossec:x:113:www-data. My exact error is-------------Warning: opendir(/var/ossec) [function.opendir]: failed to open dir: Permission denied in /var/www/ossec-wui/lib/os_lib_handle.php on line 94 Unable to access ossec directory. ---------------------------I did a ls -l in /var/www, here are the results. drwxr-xr-x 8 ossec 1000 4096 2009-02-13 15:10 ossec-wui

I also did a ls -l in /var/www/ossec-wui, here are the results. -rwxr-xr-x 1 ossec 1000 278 2008-02-27 18:38 CONTRIB drwxr-xr-x 3 ossec 1000 4096 2008-03-04 12:24 css -rw-r--r-- 1 ossec 1000 218 2008-02-29 13:21 htaccess_def.txt drwxr-xr-x 2 ossec 1000 4096 2008-03-04 12:24 img -rwxr-xr-x 1 ossec 1000 5225 2008-02-27 18:38 index.php drwxr-xr-x 2 ossec 1000 4096 2008-03-04 12:24 js drwxr-xr-x 3 ossec 1000 4096 2009-02-13 15:10 lib -rw-r--r-- 1 ossec 1000 35745 2008-03-03 08:27 LICENSE -rw-r--r-- 1 ossec 1000 462 2007-03-19 21:36 ossec_conf.php -rw-r--r-- 1 ossec 1000 1157 2008-02-27 18:38 REE -rw-r--r-- 1 ossec 1000 923 2008-02-27 18:38 REE.search -rwxr-xr-x 1 ossec 1000 1824 2008-02-29 13:21 setup.sh drwxr-xr-x 2 ossec 1000 4096 2009-02-13 15:10 site drwxrwx--- 2 root www-data 4096 2009-02-13 15:10 tmp ------------------------------------------I did a vi /etc/group and couldn't find the 1000 group anywhere...not sure who/what that is.

Thanks

Subject: Re: Installing the OSSEC Web Interface on OSSIM Posted by wintech on Fri, 27 Feb 2009 10:38:55 GMT View Forum Message <> Reply to Message Hi, You are correct... As per the Wiki docs i have installed and configured, But still i get the error


OSSIM

by FUDforum 2.7.7

Regards Wintech

Subject: Re: Basic OSSIM 1.0.6 Sensor set up Posted by binaryman on Fri, 27 Feb 2009 16:09:06 GMT View Forum Message <> Reply to Message Yeah, it would be good if DK can confirm if this is needed or not. I do not recall the exact step I did to make the sensor active in console, but I it was a single click such as "activate"

Subject: Re: Basic OSSIM 1.0.6 Sensor set up Posted by DK on Fri, 27 Feb 2009 17:40:02 GMT View Forum Message <> Reply to Message Hey, both of you are right but the best idea is to set it to sensor. Indeed I intend to release the next version with the multi-profile reconfig script. Aaah, and cheers on the doc. I'm afraid I didn't have the time to check it out yet, am very busy with the release right now :)

Subject: Re: Installing the OSSEC Web Interface on OSSIM Posted by gsporter on Sat, 28 Feb 2009 05:28:57 GMT View Forum Message <> Reply to Message I just got the OSSIM OSSEC server output into a standalone Splunk server working. I think this is a better way to analysis the OSSEC output than to OSSEC-WUI since you can do more granular searchs plus the ablity to do "pretty" graphs. I will be putting together a tutorial soon. GP

Subject: OSSIM listing Posted by DK on Sat, 28 Feb 2009 09:33:33 GMT View Forum Message <> Reply to Message


OSSIM

by FUDforum 2.7.7

I want to summarize the default s used inside ossim, where they are located and how to change them. This is work in progress as new stuff with s is being added and behaviour may change. It will always refer to the latest AlienVault installer version, which right now is: - 1.2beta1 (public testing release) Basic behaviour is that the installer creates a random that gets stored into /etc/ossim/ossim_setup.conf. An automated way to extract it would be: grep /etc/ossim/ossim_setup.conf | cut -f 2 -d "="

This is used for: - ntop(it's inside a db file under /var/lib/ntop/) - mysql database (mysql.s table) - ossim (/etc/ossim/framework/ossim.conf) - snort database access (somewhere in the table ossim.config) - phpgacl database access (somewhere in the table ossim.config) - osvdb database access (somewhere in the table ossim.config) - nessus (for the ossim /var/lib/nessus/s/ossim/auth/hash) - ossim server, various entries (/etc/ossim/server/config.xml) - SEM crypto g key (same server config.xml, only applies to the pro version) - Jasperserver mysql access (/var/tomcat/conf/Catalina/localhost/jasperserver.xml) - Forensics console, former BASE (/usr/share/ossim/www/forensics/base.conf and /etc/acidbase/database.php) Then there's the OSSIM interface / combination "/" by default. This is stored as an md5 hash with a -configured salt under ossim.s. Other s are stored in here too. OCS uses a default / too (we need to code single sign on for this). This is stored inside the ocs_inventory DB ( DB/table). The jasperserver console defaults to jasper/jasper. Ditto with single sign on. This is configured in the jasper DB. Tomcat management access defaults to /, configured under /var/tomcat/conf/(self note: ENTER FILE). Ditto. Note: it's on top of our todo list to unify management for all the /jasper stuff. If you're missing any place or see something incorrect please post below and I'll edit this post :)


OSSIM

by FUDforum 2.7.7

Subject: Re: Installing the OSSEC Web Interface on OSSIM Posted by wintech on Mon, 02 Mar 2009 06:52:05 GMT View Forum Message <> Reply to Message HI GP, Thanks for the reply.... Please let me know once the document is ed... Regards Wintech

Subject: Re: Use HTTPS instead of HTTP Posted by kingwah on Tue, 03 Mar 2009 07:58:14 GMT View Forum Message <> Reply to Message I found a way to update the graphs in Executive while running HTTPS. Steps are: 1. Go to "Executive " page 2. Click [Edit] at the top right hand corner 3. Click [config] next to the graph which cannot be shown 4. In “Sub-category”, change the image src from http to https, then click “Accept config”.

Subject: Re: Basic OSSIM 1.0.6 Sensor set up Posted by binaryman on Tue, 03 Mar 2009 17:02:34 GMT View Forum Message <> Reply to Message Thank you for the clarification DK

Subject: Re: Installing the OSSEC Web Interface on OSSIM Posted by wintech on Thu, 05 Mar 2009 11:56:24 GMT View Forum Message <> Reply to Message HI, Please let us know once you ed the document... Thanks -Wintech


OSSIM

by FUDforum 2.7.7

Subject: Re: OSSIM listing Posted by mime on Thu, 05 Mar 2009 19:15:05 GMT View Forum Message <> Reply to Message Thanks a lot DK

Subject: Re: Installing the OSSEC Web Interface on OSSIM Posted by ecuison on Wed, 11 Mar 2009 16:51:49 GMT View Forum Message <> Reply to Message I have this setup on CentOS 5.2. The is apache if anyone comes across any problems as I found this out the hard way.

Subject: Re: Installing the OSSEC Web Interface on OSSIM Posted by wintech on Thu, 12 Mar 2009 09:57:10 GMT View Forum Message <> Reply to Message Hi, Not only for you.. Everyone faces the same issue :blush: .... Regards Wintech 8o

Subject: Re: Installing the OSSEC Web Interface on OSSIM Posted by gsporter on Thu, 12 Mar 2009 12:42:46 GMT View Forum Message <> Reply to Message Correct the apache may vary by distro. See step 5 of the OSSEC documentation I referanced in my orginal post: http://www.ossec.net/wiki/index.php/OSSECWUI:Install I was assuming everyone would be using the installer therefore Debian. I like the splunk method alot better (see post else where) and it has pretty graphs! Great for management. GP For Splunk:


OSSIM

by FUDforum 2.7.7

Down and dirt OSSIM OSSEC >> Splunk [message #2543 is a reply to message #2285 ] https://www.ossim.net/forum/index.php?t=msg&goto=2543&am p;S=d30366386f5cd9ca818860c7bac52009#msg_2543

Subject: Re: ossim for newbies Posted by attrib75 on Thu, 12 Mar 2009 18:27:07 GMT View Forum Message <> Reply to Message I tried this method and the result after checking ifconfig is: ip: unknown host failed to bring up eth1

I installed this as a virtual machine with two host attached nics.

Subject: Re: ossim for newbies Posted by paul_psmith on Thu, 12 Mar 2009 18:43:40 GMT View Forum Message <> Reply to Message Are your IF's named eth ? Also there is a typo in the doc. This has been noted before. For my sensor IF I used: #The sensor interface eth1 iface eth1 inet manual up ifconfig $IFACE up up ifconfig $IFACE promisc up ifconfig $IFACE -arp down ifconfig $IFACE down And it works fine.

Subject: Re: ossim for newbies Posted by gsporter on Thu, 12 Mar 2009 22:48:12 GMT View Forum Message <> Reply to Message


OSSIM

by FUDforum 2.7.7

If you are using the new 1.2 installer try using ossim-setup from the cli for netwwork configuration. Makes it network configuration menu driven. GP

Subject: Re: ossim for newbies Posted by attrib75 on Sat, 14 Mar 2009 17:33:08 GMT View Forum Message <> Reply to Message Ok, after configuring it the way described in the above turorial, the web interface went down. So I tried it a lot of ways, and it seemed to work when I configured it like this: auto lo eth0 eth1 iface lo inet loopback

iface eth0 inet static address ... netmask ... network ... broadcast ... gateway ... iface eth1 inet manual up ifconfig $iface up up ifconfig $iface promisc up ifconfig $iface -arp down ifconfig $iface down as in I could get to the web interface again, but I got an error when running the network restart command: UP: error fetching interface infomrmation: device not found Failed to bring up eth1 So when I configured the eth1 info in the same format as eth0, I didnt get any errors but I still couldnt see any non broadcast traffic in the web interface. (eth1 is on a mirrored switch port)

Subject: Re: ossim for newbies Page 53 of 123 ---- Generated from

OSSIM

by FUDforum 2.7.7

Posted by gsporter on Sat, 14 Mar 2009 18:10:12 GMT View Forum Message <> Reply to Message From you post it is hard to determine the cause. I would narrow it down. First your nic itself:

Can you post the output of: ifconfig -a # this should show all the nics the OS sees and lspci |grep Ethernet # Information about your nic hardware Another tool you can use to get info is ethtool <device> # ie. eth0 or eth1

Referances: Low level nic/ip http://www.debian.org/doc/manuals/reference/ch-gateway.en.ht ml

Subject: Re: ossim for newbies Posted by attrib75 on Mon, 16 Mar 2009 12:50:21 GMT View Forum Message <> Reply to Message Sorry I'm a Windows guy, new at this shell. I don't know how to prevent the info from scrolling past the window. Is there an equivalent to /p?

Subject: Re: ossim for newbies Posted by umarzuki on Mon, 16 Mar 2009 13:19:47 GMT View Forum Message <> Reply to Message if you want to 'stop/freeze' say, certain info from a command like ifconfig to flow just pipe it to lessifconfig | less or you could scroll up by holding shift and pressing page up.


OSSIM

by FUDforum 2.7.7

Subject: Re: ossim for newbies Posted by attrib75 on Mon, 16 Mar 2009 15:32:50 GMT View Forum Message <> Reply to Message Ok, the ifconfig -a shows

eth0 Link encap:Ethernet HWaddr .... inet addr:....

eth1 Link encap:Ethernet HWaddr .... inet addr ......

so it sees the interface when I configure the interface file as I mentioned. When I configure it like iface eth1 inet manual up ifconfig $IFACE up up ifconfig $IFACE promisc up ifconfig $IFACE -arp down ifconfig $IFACE down I get an error thanks for all your help so far!

Subject: Re: ossim for newbies Posted by gsporter on Mon, 16 Mar 2009 19:20:49 GMT View Forum Message <> Reply to Message attrib75 What I was trying to find out is if OSSIM was seeing your nic's and if so correctly. For example I am running a number of systems on Intel D945GCLF/D945GCLF2 with older debian kernels. They have Realtek 8168/8111 nics which are incorrectly detected as 8169's. The 8169 driver loads and may even run for awhile then stops. You have to the correct driver and build it.


OSSIM

by FUDforum 2.7.7

I understand about the learning curve for linux when coming from windows. I would sugguest installing putty and wins on a windows box if you have one available. Then it is very easy to run cli commands in putty (you can even cut and paste from these forums) or edit files in a windows type environment with wins. lspci | grep Ethernet or lshw -C network

Will show what nics are physically in your machine. That way we can tell more what is going on

By the way which installer are you running? OSSIM 1.0.X is running an older kernel and does not have as much hardware .

P.S. For output that runs off the page you can either lsmod | less # q to quit or lsmod | more # similar to the windows more pipe

GP

Subject: Re: ossim for newbies Posted by attrib75 on Tue, 17 Mar 2009 12:58:54 GMT View Forum Message <> Reply to Message lspci|grep ethernet returns a blank line. lspci by itself returns a list that contains two ethernet controllers. I am running ossim 1.0.6 in Sun virtual box on a Dell Poweredge 2950 that has 4 ethernet ports, (gigabit), and two Intel(R) Xeon(R) U E5405 @ 2.00GHz processors. I dont have the hardware available to run this on a dedicated machine. I tried installing ossim 1.2 and it


OSSIM

by FUDforum 2.7.7

returned an error that I had the wrong processor type. It said it was looking for x86 and found I86. I suspect this is because the server has two processors. lshow returned command not found. ethtool returned command not found. I posted the ifconfig -a already. I really like Ossim and would love to get it to work. Thanks again for the help everyone.

Subject: Re: ossim for newbies Posted by paul_psmith on Fri, 20 Mar 2009 20:22:53 GMT View Forum Message <> Reply to Message Try getting a copy of putty that you can install on your PC assuming you are using Windows. Then you can SSH to the OSSIM box and cut and paste things from the comfort of your desk. Note: highlighting text in putty is like copy.

you wrote: '>lspci by itself returns a list that contains two ethernet controllers.' Dell uses Intel NICs on the motherboard and it looks like those two are showing up since you say you see two NICs. Your two other NICs in PCI slots are not being recognized is my guess. This is all based upon your comments. Do you know what model the other two NICs are? If they are Intel do something like this dmesg | grep -i eth

Also, when you define NICs in /etc/network/interfaces you will need to add settings for each adapter, but change the iface name on the first line of each section and put them all in the auto line at the top. auto lo eth0 eth1 eth2 eth3 iface eth1 inet manual up ifconfig $IFACE up up ifconfig $IFACE promisc up ifconfig $IFACE -arp down ifconfig $IFACE down


OSSIM

by FUDforum 2.7.7

iface eth2 inet manual up ifconfig $IFACE up up ifconfig $IFACE promisc up ifconfig $IFACE -arp down ifconfig $IFACE down iface eth3 inet manual up ifconfig $IFACE up up ifconfig $IFACE promisc up ifconfig $IFACE -arp down ifconfig $IFACE down

Subject: Re: ossim for newbies Posted by anton on Fri, 20 Mar 2009 23:01:15 GMT View Forum Message <> Reply to Message attrib75 wrote on Tue, 17 March 2009 08:58lspci|grep ethernet returns a blank line. lspci by itself returns a list that contains two ethernet controllers. Most everything in Linux/Unix type systems is case sensitive, that's why "lspci | grep ethernet" didn't work (non-capitalized Ethernet), but "lspci" by itself did.. Quote:I am running ossim 1.0.6 in Sun virtual box on a Dell Poweredge 2950 that has 4 ethernet ports, (gigabit), and two Intel(R) Xeon(R) U E5405 @ 2.00GHz processors. I dont have the hardware available to run this on a dedicated machine. I tried installing ossim 1.2 and it returned an error that I had the wrong processor type. It said it was looking for x86 and found I86. I suspect this is because the server has two processors. I think I know why this happened: OSSIM 1.0.6 is 32bit, while 1.2 is 64bit. I suspect the "Sun virtual box" (I'm not familiar with it) will not run 64bit OS's? Is the host OS 64bit? The Xeon E5405 most certainly is 64bit. If you're having trouble because it's 1.2 is 64bit, OSSIM 1.1 should be available sometime reasonably soon I think, and it should pretty much be a 32bit version of 1.2, so that may be good. Quote:lshow returned command not found. ethtool returned command not found. The command is "lshw", not "lshow"... It stands for "list hardware" by the way ( everything is case sensitive also). You can install these tools as follows:


OSSIM

by FUDforum 2.7.7

apt-get install ethtool lshw Tip: you can use tab completion - for example, type "lsh", then hit the 'tab' key (after lshw is installed). It saves on typing (and typos...). 8) Anton

Subject: Re: Installing Webmin Posted by gutzba on Tue, 24 Mar 2009 18:04:49 GMT View Forum Message <> Reply to Message Thnks Excellent How To Install WebMin

Subject: Re: ossim for newbies Posted by attrib75 on Wed, 25 Mar 2009 15:31:49 GMT View Forum Message <> Reply to Message Awesome answer! I think I figured out what the problem was. I think I was typing $Iface instead of $IFACE. Anyway it shows the nic in promiscuous mode. I look forward to Ossim 1.1. I'm not sure if you can run 64 bit OS in virtual box. Now its just a matter of tackling the rest of the configuration for Ossim. You would think I could see all of the destination addresses for remote traffic in Nmap, since the promiscuous port is attached to a switch port where traffic for the whole network is mirrored. But so far I only see local broadcast and unicast traffic. How disappointing! I'm still only seeing what I would see on a non mirrored switch port.

Subject: Tuning OSSIM for Your Environment Posted by gsporter on Thu, 26 Mar 2009 02:57:35 GMT View Forum Message <> Reply to Message For those of you who have kept up with the 1.2beta’s you know there are LOT’s of alerts and incidents. The trick is which ones are important and translating it into some thing usable.


OSSIM

by FUDforum 2.7.7

I am trying to work out a process to start cutting down the “white noise” or false positives generated by my network. I am running a heterogeneous network with several distro’s of linux, Windows (AD domain), a number of vmware guest and the miscellaneous other OS. My test network is behind both a hardware and software firewall that are configured fairly strictly and all host run current AV. Therefore so I started under the idea most of the alerts/incidents I was seeing were generated by my network. Note: For the purpose of base lining my network I have not set the two firewalls to log to OSSIM. That will be the next step. The trick as I see it is identifying “normal” traffic from your network, and the traffic generated by OSSIM (plus sensors etc) in order to implement a way to filter out normal traffic. First I have to establish a baseline and “normalize” my data. Then I can look at ways to configure OSSIM correctly

The areas I see for identifying reported traffic include: I.The “Forensics Console” If I select “Unique Alerts” (by the way click on the little graph box to the left for a time trend of that specific alert) My system is current showing 621 total unique alerts. The vast majority of the volume of alerts is generated by 5 signatures’: portscan: Open Port unclassified 261798(47%) Spade: Closed dest port used unclassified 185224(33%) Spade: Source used odd dest port unclassified 145818(26%) MISC UPnP malformed ment unclassified 127904(23%) WEB-MISC Invalid HTTP Version String" unclassified 50706(9%) Note: the percentages do not seem to total up to 100% at this time The first three are generated by OSSIM itself. In fact OSSIM is listed reports a the “attacker” 97% of the time. The UPnP is being generated by Vista and I can disable it. II. Incidents I am hoping that by “tagging” incidents that are benign in my network as OSSIM_INTERNAL_FALSE_POSITIVE or things I need to harden/disable etc OSSIM_INTERNAL_PENDING I will be able to use the jasper server and iReports to generate a more detailed implementation plan.


OSSIM

by FUDforum 2.7.7

III

Reports

Host Report Alarm Report

Security Report Incident Report

From those reports I found some of the other things to look into : Identify IP addresses you do not recognize ( both source /attacker and destination /target). Note: I put a referance of special use IP ranges used for things like routing protocols at the end of this document 202.47.28.150#still unknown not ed 239.255.255.250#special use broad cast UPnP Vista 192.0.2.42 673#unknown 207.46.197.32 633#unknown 202.47.28.150

#unknown

213.30.161.23 241#mondo.hpintelco.net mondo project ok 68.1.17.1# my ISP 208.67.222.222 208.67.220.220 212.211.132.32 35.9.37.225 195.20.242.89

# OpenDNS server # OpenDNS server # villa.debian.org # ike.egr.msu.edu debian repository # wieck.debian.org debian repository

64.50.238.52 534#ftp-atl.osuosl.org debian repository


OSSIM

by FUDforum 2.7.7

Note: I had already identified some of the IP’s as my DNS servers or debian repositories and added them as host and created a policy to drop them. I use nslookup, whois and a browser to try and identify the rest. The IP’s that show up on your box maybe different. Check them out and be sure they are suppose to be showing up. P.S. Any help identifying the unknowns would be appreciated Identify ports you do not recognize ( both source/ destination ). And the service that use them ( and if you are suppose to be running them!!)

From the alarms report I had listed the following ports : __________________________________________________________ 59313 unknown 32768-61000tip-local-port-rangelocal-client-port-linuxlocal clients ports for outgoing traffic on LinuxKurt SeifriedThis port range can be configured on Linux by using the "sysctl" command and the "net.ipv4.ip_local_port_range" variable. 32768-61000udpip-local-port-rangelocal-client-port-linuxlocal clients ports for outgoing traffic on LinuxKurt SeifriedThis port range can be configured on Linux by using the "sysctl" command and the "net.ipv4.ip_local_port_range" variable. Note: need to confirm __________________________________________________________ 25611 unknown #see above __________________________________________________________ 49804 unknown #see above __________________________________________________________ 47149 unknown#see above __________________________________________________________ Now look at the events section: __________________________________________________________ Top 15 Events Occurrences MISC UPnP malformed ment 130208


OSSIM

by FUDforum 2.7.7

portscan: Open Port 115145 "WEB-MISC Invalid HTTP Version String" 46777 "BLEEDING-EDGE POLICY Nagios HTTP Monitoring Connection" 43469 POLICY VNC server response 32335 "COMMUNITY WEB-MISC mod_jrun overflow attempt" 26873 ossec: session closed. 24631 ossec: session opened. 24382 DNS SPOOF query response with ttl: 1 min. and no authority 16132 portscan: T Portsweep 10667 p0f: OS Change 9101 directive_event: An important host (SRC_IP) has changed its OS 8933 portscan: T Portscan 8529 directive_event: T Portscan against DST_IP 7047 Spade: Closed dest port used 6047 Note: some of these values are skewed since I have deleted some events and put policies not to store others. __________________________________________________________ Top 15 Events by risk directive_event: T Portscan against DST_IP 3 directive_event: Recurrent Snort event 2 directive_event: NMAP portscan against DST_IP 2 directive_event: Possible DST_PORT intrusion against DST_IP 2 directive_event: Possible portscan against DST_IP 1 directive_event: Possible Worm port 80. Origin: SRC_IP 1 directive_event: Possible Worm port DST_PORT/PROTOCOL 1 EXPLOIT ntpdx overflow attempt1 FTP command overflow attempt 1 SNMP AgentX/t request 1 directive_event: HTTP Tunnel through web proxy 1 WEB-CGI cgiforum.pl access 0 WEB-MISC changepw.exe access 0 "BLEEDING-EDGE POLICY Yahoo Chat Activity Inside Webmail" 0 WEB-CGI ez.cgi access0 __________________________________________________________ Now that I have a “baseline” or an idea of “normal” traffic on my network I can consider how to tune OSSIM The incident report also give me a list of Vulnerabilities to work on __________________________________________________________


OSSIM

by FUDforum 2.7.7

Now what do I do? DK mentions “There are at least three ways of doing this: a.Filtering at origin (disabling a snort rule, setting a tdump-style filter at p0f, etc...) b.Policy c.Agent Consolidation (undocumented)” Ref: Re: Hyperthreading [message #1913 is a reply to message #1912 ] I believe “directives” maybe another approach to this I think that might be a good place to stop for now. As always any comments, suggestions’ or ideas are appreciated. P.S. I just noticed the team has added an installation guide for “rolling your own” on lenny debian to the DOCs section. Cool! Plus I was reminded what a great tool the “architecture diagrams” are towards understanding the logic behind OSSIM (same page under Misc) https://www.ossim.net/docs.php GP Special use IP ranges (case you are running routers,VOIP etc) _________________________________________________________

Multicast IP Addresses There are a number of addresses that are set aside for special purposes, such as the IP's used in OSPF, Multicast, and experimental purposes that cannot be used on the Internet. Class D Start End 224.0.0.0 239.255.255.255 Special Use Addresses - Table from RFC 3330 Address Block CIDR Mask Used for Reference 0.0.0.0 /8 Used to communicate with "This" network RFC1700, p. 4 10.0.0.0 /8 Private-Use Networks RFC 1918 14.0.0.0 /8 Public-Data Network RFC1700, p.181 24.0.0.0 /8 Cable TV Networks -39.0.0.0 /8 Previously Reserved Available for Regional Allocation RFC1797 127.0.0.0 /8 Loopback address RFC1700, p. 5 128.0.0.0 /16 Previously Reserved Available for Regional Allocation --


OSSIM

by FUDforum 2.7.7

169.254.0.0 /16 Link Local (eg. Microsoft XP systems use Automatic Private IP Addressing (APIPA) which selects addresses in this range.) 172.16.0.0 /12 191.255.0.0 /16 192.0.0.0 /16 192.88.99.0 /16 192.168.0.0 /16

Subject: Setting Up Logcheck on OSSIM Posted by gsporter on Sun, 29 Mar 2009 18:12:01 GMT View Forum Message <> Reply to Message I have been trying to keep up with the new 1.2 beta's. If you have not tried them I really suggest you install beta4 even if it is in a vm. It has a lot of great new features and if it is any indication OSSIM is moving to a whole new level. Any time I install a beta or new program I am VERY interested in what is going on in the background. Traditionally sys s have used log files for this purpose. They allow you to locate bugs, errors, bottlenecks and even sometimes rogue processes or program you do not want running. I have always hated trying to have to wade through log files from the command line. So I chose to install logcheck to email my OSSIM log files to me. That way I can go thru them on a workstation with a gui at my leisure. "What is Logcheck? Logcheck parses system logs and generates email reports based on anomalies. Anomalies can be defined by s with 'violations' files. It differentiates between 'Active System Attacks' , 'Security Violations', and 'Unusual Activity', and is smart enough to where in the log it stopped processing to improve efficiency. It can also warn when log files shrink, and does not report errors when they are rotated." (1)

Since OSSIM is going to be our "Central Security Repository" it is important that we stay on top of potential problems and intrusions. Therefore it is a good idea to install both a HIDS (ossec) and move copies of the log files to another hopefully secure location. One of the first steps any intruder is going to take is to hide their tracks and one of the ways to do this is alter or delete log files.


OSSIM

by FUDforum 2.7.7

#apt-get install logcheck Main Configuration file for logcheck located at /etc/logcheck/logcheck.conf nano /etc/logcheck/logcheck.conf First thing to change REPORTLEVEL="server" # if you set paranoid you will be buried! # Should be set to an offsite " [email protected]" SENDMAILTO="root" I create an offsite email similar to [email protected] Then I create the following filters/directories on the logcheck, optional - firewall, OSSIM (for my OSSIM notification) Logcheck If From contains 'logcheck' move to logcheck; firewall If From contains 'firewall' move to firewall;

I prefer my logs to be sent as an attachment. To do this you need to install nail apt-get install nail Then change this in the logcheck.conf # Send the results as attachment or not. # 0=not as attachment; 1=as attachment # Default is 0 MAILASATTACH=1 There is alot more that can be done such as installing logtail when added, allows any number of log files on one or more machines on a network to be transfered. Logtail - Logs which transfer to new files are automatically followed, and an option allows translation of numeric Internet addresses into the corresponding hostnames where possible. Log items can be relayed to one or more other


OSSIM

by FUDforum 2.7.7

hosts on the network, permitting a machine's local log files to be monitored there. (2)

References: (1) http://www.debianhelp.co.uk/logcheck.htm (2) http://www.fourmilab.ch/webtools/logtail/ GP The future is here. It's just not widely distributed yet. - William Gibson

Subject: Re: OSSIM listing Posted by dantasrotole on Fri, 03 Apr 2009 18:23:20 GMT View Forum Message <> Reply to Message Dear DK, What did you mean ? nessus (for the ossim (insert File Location)? Insert which file and where? Thanks!

Subject: Re: OSSIM listing Posted by DK on Fri, 03 Apr 2009 18:28:11 GMT View Forum Message <> Reply to Message Sorry, expected to fill that in as soon as I got access to an installed ossim :) Just updated a couple of missing lines, still have to find the / for tomcat.

Subject: Use DVD Backup >Full Restore OSSIM 1.2 Posted by gsporter on Sun, 12 Apr 2009 02:25:07 GMT View Forum Message <> Reply to Message I have wanted a full hopefully bare metal backup/restore for OSSIM and had trouble installing


OSSIM

by FUDforum 2.7.7

mondo on OSSIM on lenny. Found the correct deb files and here is the down and dirty install process. Hope it is helpfull to some of you: DISCLAIMER: I ran this on a system setup using the OSSIM 1.2beta5 installer. If you are using any other distro or installer you may have issues. Add mondo repositories to /etc/apt/sources.list deb ftp://ftp.mondorescue.org/debian 5.0 contrib deb-src ftp://ftp.mondorescue.org/debian 5.0 contrib busybox and mindi ftp://ftp.mondorescue.org/debian/5.0/mindi-busybox_1.7.3-1_a md64.deb ftp://ftp.mondorescue.org/debian/5.0/mindi_2.0.5_amd64.deb Install dependancies apt-get install binutils bzip2 dosftools mkisofs syslinux parted mtools Install busybox and mindi dpkg -i mindi-busybox_1.7.3-1_amd64.deb dpkg -i mindi_2.0.5_amd64.deb Test mindi # mindi

Install additional dependancies for mondo apt-get install afio buffer dpkg -i mondo_2.2.8_amd64.deb Install cd/dvd burning tools apt-get install cdrecord dvd+rw-tools dvdrtools Run mondo mondoarchiver I have not covered every step but there is alot of mondo documentation out there.


OSSIM

by FUDforum 2.7.7

Subject: Re: Use HTTPS instead of HTTP Posted by idealids on Mon, 13 Apr 2009 18:58:43 GMT View Forum Message <> Reply to Message I tried to make ntop work by following the above instructions and as a result, i am now unable to even to my dashboard. as soon as i , i get the following errors: Warning: session_start() [function.session-start]: open(/var/lib/php4/sess_ef715ed3e933e7492b0fbb88c872c13d, O_RDWR) failed: Permission denied (13) in /usr/share/ossim/include/classes/Session.inc on line 13 Warning: session_start() [function.session-start]: Cannot send session cookie - headers already sent by (output started at /usr/share/ossim/include/classes/Session.inc:13) in /usr/share/ossim/include/classes/Session.inc on line 13 Warning: session_start() [function.session-start]: Cannot send session cache limiter - headers already sent (output started at /usr/share/ossim/include/classes/Session.inc:13) in /usr/share/ossim/include/classes/Session.inc on line 13 Warning: Cannot modify header information - headers already sent by (output started at /usr/share/ossim/include/classes/Session.inc:13) in /usr/share/ossim/www/session/.php on line 94 Warning: Unknown(): open(/var/lib/php4/sess_ef715ed3e933e7492b0fbb88c872c13d, O_RDWR) failed: Permission denied (13) in Unknown on line 0 Warning: Unknown(): Failed to write session data (files). Please that the current setting of session.save_path is correct (/var/lib/php4) in Unknown on line 0

Can anyone offer some assitance. thx

Subject: Re: Use HTTPS instead of HTTP Posted by DK on Tue, 14 Apr 2009 07:24:05 GMT View Forum Message <> Reply to Message Looks like you somehow got php4 into your running apache. Look at this line: Warning: Unknown(): Failed to write session data (files). Please that the current setting of session.save_path is correct (/var/lib/php4) in Unknown on line 0


OSSIM

by FUDforum 2.7.7

(chown www-data /var/lib/php4 or chmod 1777 /var/lib/php4 should fix that for you)

Subject: Re: Use HTTPS instead of HTTP Posted by idealids on Wed, 15 Apr 2009 20:21:23 GMT View Forum Message <> Reply to Message Thanks DK, that worked!

Subject: Re: Use HTTPS instead of HTTP Posted by crimondi on Fri, 01 May 2009 17:29:21 GMT View Forum Message <> Reply to Message Have you had a chance to reconfigure that php script to update the IPs? I would like to see what you did. Thanks.

Subject: Re: ossim for newbies Posted by deaqo on Wed, 06 May 2009 15:49:38 GMT View Forum Message <> Reply to Message Hi, i'm a newbie and i found out that your documentation is good but i want to have an example of correlate event interpretation, because in the whole forum i just can't find anything about the correlation event DB or it's interpretation and for me personally i don't understand very well about how to work with that. Sorry, but i recently install this product and i don't know about it. Thank you!

Subject: Set second OSSIM server as sensor/agent only Posted by umarzuki on Wed, 27 May 2009 12:51:08 GMT View Forum Message <> Reply to Message This how to is on configuring a second ossim server as a sensor (agent only) console = 192.168.1.10 sensor = 192.168.1.11 Install ossim as console (lets set its hostname as console)


OSSIM

by FUDforum 2.7.7

Install ossim as sensor (same here, hostname = sensor) Check on sensor ossim_setup.conf so it will act as sensor Check sensor's interface(s) in /etc/network/interfaces so it's configuration is consistent with /etc/ossim/ossim_setup.conf, one as default, other set in promiscuous mode if it have more than 1 interface Configure snortdpkg-reconfigure snort Configure ntopdpkg-reconfigure ntop Stop mysql and remove it from starting at boot timepgrep mysql | xargs kill -9 update-rc.d remove mysqld Run ossim-reconfigossim-reconfig Note: I figured that on 1.0.6, without configuring snort and ntop correctly, ossim-reconfig would fail and the sensor won't be listed on the console's sensor list. Feel free to comment or add correction.

Subject: OSSIM + XMPP - mini howto Posted by fyfy on Thu, 11 Jun 2009 04:17:21 GMT View Forum Message <> Reply to Message Heya! I don't know if there's much interest in building XMPP/Jabber stuff on the top of OSSIM on order to simply monitoring process and facilitate the collaboration between OSSIM node operators. Anyway, if you think it is a fun project to play around, let me know, I'll post up on writing ossim-xmpp agents and plugins later. This howto hopefully should get you started. == OSSIM + OpenFire MiniHOWTO == By integrating ossim with openfire we get to have a collaboration framework where you could have groups of operators use Jabber messaging client as primary means of communication and collaboration. Of course you can do even more than that. XMPP is an extendable protocol. You can build security monitoring services on the top of it, so you could use your messaging client (with extensions) as primary security monitoring interface. The monitoring part can be easily done with XMPP based agents, which could talk to OSSIM database or other components directly, and maybe we could talk about it later some time. The cool thing ing agents, that it runs over standard XMPP protocol so you could technically even use your gmail.com client, or mobile phone jabber client to collaborate with your ossim system. However, when you run into huge number of s, scallability might become an issue... There's also another really neat way of adding things up by extending OpenFire server with


OSSIM

by FUDforum 2.7.7

custom plugins, then you won't really need agents anymore. But you'll need customized Jabber clients. You can read more about this appraoch here: http://java.sys-con.com/node/232087 anyway, we'll start with the basics. Right now we simply want OSSIM s to be able to into our XMPP server using ossim framework authentication credentials. I used ossim installer here to install the base system. Once you get that stuff done, you'll need to install Java's JRE on your box. Ossim installer is based on debian, so you'll have to install sun-java6-jre package on it. echo " deb http://www.backports.org/debian/ etch-backports main non-free" >> /etc/apt/sources.list apt-get get update apt-get install sun-java6-jre if this went smooth, go to http://www.igniterealtime.org/s/index.jsp and .deb package. Once you've got it, install it: dpkg -i openfire_3.6.4_all.deb you can try to run openfire server at this point: /etc/init.d/openfire start now you should have openfire running on your box with console on ports 9090 and 9091(ssl'ed). One thing you will need to do now is to configure the mysql database for openfire to use. echo "create database openfire" | mysql -p cat /usr/share/openfire/resources/database/openfire_mysql.sql | mysql -p openfire (you'll need to peek at root for mysql, which can be found in /etc/ossim/ossim_setup.conf)

Once you're done w/ this stuff, launch your browser to ossim:9090 and complete the setup. Select external database, and choose mysql database for it. Then correct the url for the mysql database thing. You can skip the setup part at the end. Once you're done with this stuff, you'll need to save this into a file, i.e. custom.sql and make some changes. At the very least you'll want to change the connection string and set the id and to those you use to connect to your ossim database. You may also want to change .authorizedJIDS to list s, who would be allowed to into openfire console:


OSSIM

by FUDforum 2.7.7

--/cut here/-/* make modifications */ update ofProperty set propValue = 'org.jivesoftware.openfire.auth.JDBCAuthProvider' where name = 'provider.auth.className'; update ofProperty set propValue = 'org.jivesoftware.openfire..JDBCProvider' where name = 'provider..className';

/* connection */ insert into ofProperty (name, propValue) values ('jdbrovider.driver', 'com.mysql.jdbc.Driver'); insert into ofProperty (name, propValue) values ('jdbrovider.connectionString', ' jdbc:mysql://localhost:3306/ossim?=root&=you r');

/* authentication */ insert into ofProperty (name, propValue) values ('jdbcAuthProvider.SQL', 'select from s where =?'); insert into ofProperty (name, propValue) values ('jdbcAuthProvider.Type', 'md5'); insert into ofProperty (name, propValue) values ('.authorizedJIDs', 'yourleet, ');

/* */ insert into ofProperty (name, propValue) values ('jdbcProvider.loadSQL', 'select name, email from s where =?'); insert into ofProperty (name, propValue) values ('jdbcProvider.CountSQL', 'select count(*) from s'); insert into ofProperty (name, propValue) values ('jdbcProvider.allsSQL', 'select from s'); insert into ofProperty (name, propValue) values ('jdbcProvider.searchSQL', 'select from s where');


OSSIM

by FUDforum 2.7.7

insert into ofProperty (name, propValue) values ('jdbcProvider.nameField', ''); insert into ofProperty (name, propValue) values ('jdbcProvider.nameField', 'name'); insert into ofProperty (name, propValue) values ('jdbcProvider.emailField', 'email'); --/cut here/-once you're done with this stuff, save it and then do something like: cat custom.sql | mysql -p openfire then restart your openfire server and you're done ;) For the agents and stuff, maybe I'll make another post :) Sources: http://www.igniterealtime.org/builds/openfire/docs/latest/do cumentation/database.html http://www.igniterealtime.org/community/thread/38646

Subject: Re: NagiosQL Walktrough Posted by hayfa on Mon, 15 Jun 2009 09:03:52 GMT View Forum Message <> Reply to Message hello can't find /etc/nagios2

Subject: Re: NagiosQL Walktrough Posted by umarzuki on Mon, 15 Jun 2009 14:19:23 GMT View Forum Message <> Reply to Message i'm sorry for your lost but it is not possible since i can find /etc/nagios2 in my ossim server did you accidentally removed it? you can view past command with history history you can also try to locate nagios2 folder (though i doubt it'll anywhere else) updatedb locate nagios2 best of luck. If all fails, reinstallation isn't that hard.


OSSIM

by FUDforum 2.7.7

Subject: Re: Use HTTPS instead of HTTP Posted by rul3z on Tue, 16 Jun 2009 07:51:17 GMT View Forum Message <> Reply to Message Hello guys, I did all the stuff here, but now the big problem is that Nagios and others are not seen through the ossim, I couldn't manage to do /home/ossim/dist/reconfig.pl The perl script is not found on my system. I have no report server now !!! Any help shall be appreciated.

Subject: Re: OSSEC Quick Start Guide Posted by hayfa on Wed, 17 Jun 2009 15:21:15 GMT View Forum Message <> Reply to Message hello i have a small problem i configured a linux host like this tuto but in the server it's shown never connected !!!!!!!!!!!!!!!!!!!

Subject: Re: Install Oinkmaster and update snort rules Posted by gsporter on Wed, 08 Jul 2009 03:34:58 GMT View Forum Message <> Reply to Message Modification to allow for the upgrade of Snort to 2.8 Line 4 http://www.snort.org/pub-bin/oinkmaster.cgi/ /snortrules-snapshot-2.8.tar.gz Line 5 Change /usr/share/oinkmaster/makesidex.pl /etc/snort/rules/ >autodisable.conf to


OSSIM

by FUDforum 2.7.7

/usr/share/oinkmaster/makesidex.pl /etc/snort/rules/ >/etc/autodisable.conf GP

Subject: Re: OSSIM listing Posted by catchacold on Fri, 10 Jul 2009 11:59:01 GMT View Forum Message <> Reply to Message Nevermind

Subject: Method to check and see what OSSEC is logging (without the web gui) Posted by gsporter on Wed, 22 Jul 2009 23:47:41 GMT View Forum Message <> Reply to Message In case you have not had a chance to check it out OSSEC v2.0 added a command-line "reporting" tool. It is great for checking to see if agents, syslog etc is actually making it into OSSEC|OSSIM without having to install the web gui on OSSIM. Note: These commands are from the OSSEC tutorial but I have made a change in the path to the ossec-reportd binary: _________________________________________________________ Show all IP addresses/s that logged in during the day cat /var/ossec/logs/alerts/alerts.log | /var/ossec/bin/ossec-reportd -n “s summary” -f group authentication_success _________________________________________________________ Show all IP addresses/s that logged in during the day and related srcips locations for each cat /var/ossec/logs/alerts/alerts.log | /var/ossec/bin/ossec-reportd -n “s summary” -f group authentication_success -r srcip -r location _________________________________________________________ Show all multiple authentication failures (brute force attacks) cat /var/ossec/logs/alerts/alerts.log | /var/ossec/bin/ossec-reportd -n “Failures summary” -f group authentication_failures


OSSIM

by FUDforum 2.7.7

_________________________________________________________ Show a summary for the month (or day) <July 2009> zcat /var/ossec/logs/alerts/2009/Jul/*.gz | /var/ossec/bin/ossec-reportd -n “Month Summary” Referance: http://www.ossec.net/dcid/?p=153

GP

Subject: OSSIM 1.1 - Configuracion después de la Instalacion Posted by willians on Tue, 11 Aug 2009 15:02:41 GMT View Forum Message <> Reply to Message esta es una pequeña contribucion. es un manual he instalado muchas veces el ossim y por fin decidi hacer este pequeño manual que comparto para ustedes.

Willians Herrera.

File Attachments 1) OSSIM 1.1 - Configuracion después de la Instalacionx.pdf, ed 718 times

Subject: HOWTO: Get Snort 2.8.X on Ubuntu feeding to OSSIM Posted by cringe on Wed, 30 Sep 2009 20:26:32 GMT View Forum Message <> Reply to Message So you have a stand-alone snort box that you want to start sending data to your OSSIM server. You may be in luck. The instructions below are for snort on Ubuntu. ON SNORT SERVER 1. Install ossim-agent (apt-get install ossim-agent) - You may have to add the repositories. You


OSSIM

by FUDforum 2.7.7

can find these on your OSSIM server in /etc/apt/sources.list 2. the legacy snort.cfg plugin at http://os-sim.cvs.sourceforge.net/viewvc/*checkout*/os-sim/a gent/etc/agent/plugins/snort.cfg?revision=1.7 3. Copy the plugin to your /etc/ossim/agent/plugins folder as snort.cfg 4. Edit your /etc/ossim/agent/config.cfg and 4a. Add this line under [plugins]: snort=/etc/ossim/agent/plugins/snort.cfg 4b. Point the agent to your ossim server under [output-server]: ip= 5. Edit your /etc/snort/snort.debian.conf 5a. Add the snort option to log to alert file: DEBIAN_SNORT_OPTIONS="-A full" 6. Restart snort and ossim-agent services OSSIM Server 1. In the Web Interface - Go to Policy > Sensors 2. Add the stand-alone snort box as a sensor (hostname/IP) 3. Reload sensors You should be receiving alerts under the SIM Events page now. On the OSSIM server, you may have to restart ossim-server and/or the ossim-agent. I don't if it was necessary or not. Good Luck!

Subject: Re: Set second OSSIM server as sensor/agent only Posted by kevint on Mon, 19 Oct 2009 13:42:29 GMT View Forum Message <> Reply to Message Thanks for the tutorial here. I'd like to add that in step 7 to remove mysqld from starting at boot time, the command to remove it is close, but not exactly correct. It should read as: pgrep mysql | xargs kill -9 update-rc.d mysqld remove -f


OSSIM

by FUDforum 2.7.7

Subject: Re: HOWTO: Get Snort 2.8.X on Ubuntu feeding to OSSIM Posted by last1ghost on Wed, 04 Nov 2009 17:01:45 GMT View Forum Message <> Reply to Message Hi Sir, I do exactly as you said but i got the below error when i start ossim-agent 2009-11-04 19:09:30,129 Conn [ERROR]: (32, 'Broken pipe') 2009-11-04 19:09:31,135 Conn [ERROR]: (104, 'Connection reset by peer') 2009-11-04 19:09:32,137 Conn [ERROR]: (104, 'Connection reset by peer') 2009-11-04 19:09:33,144 Conn [ERROR]: (104, 'Connection reset by peer') 2009-11-04 19:09:34,149 Conn [ERROR]: (104, 'Connection reset by peer') 2009-11-04 19:09:35,155 Conn [ERROR]: (104, 'Connection reset by peer') 2009-11-04 19:09:36,161 Conn [ERROR]: (104, 'Connection reset by peer') 2009-11-04 19:09:37,166 Conn [ERROR]: (104, 'Connection reset by peer') 2009-11-04 19:09:38,172 Conn [ERROR]: (104, 'Connection reset by peer') 2009-11-04 19:09:39,177 Conn [ERROR]: (104, 'Connection reset by peer') 2009-11-04 19:09:40,178 Conn [ERROR]: Error receiving data from server: (104, 'Connection reset by peer') and the ossim-server sensor give me X on my sensor when i remove snort from agent plugin it works again but of course i still need snort alerts, any recommendation

Subject: Re: OSSEC Quick Start Guide Posted by jplee3 on Wed, 04 Nov 2009 19:18:48 GMT View Forum Message <> Reply to Message Hey guys, will this still work with the latest versions of OSSEC and OSSIM? I was trying to tie the two together but could not figure it out. I'll have to play around with it more when I have the time.

Subject: Re: Set second OSSIM server as sensor/agent only Posted by dropadrop on Tue, 10 Nov 2009 20:59:02 GMT View Forum Message <> Reply to Message Doesn't monit include mysql as one of the monitored applications? If yes, it should probably be removed from there too. Also what about the ossim-server / ossim-framework services, are they needed in such a set up?


OSSIM

by FUDforum 2.7.7

Subject: Re: Install Oinkmaster and update snort rules Posted by dropadrop on Tue, 10 Nov 2009 21:01:33 GMT View Forum Message <> Reply to Message I was playing around with oinkmaster today, and it seemed very nice. The big question for me was that it refused to modify / disable all the sids I wanted it to. Are part of the rule sets included with ossim such that oinkmaster won't touch them (community / emerging threats)?

Subject: OSSIM Installation Guide Posted by juanma on Fri, 27 Nov 2009 16:38:48 GMT View Forum Message <> Reply to Message English: http://ossim.net/dokuwiki/doku.php?id=installation Spanish: http://ossim.net/dokuwiki/doku.php?id=installationES

If you want to help translating it to your own language please send an email to jmlorenzo at alienvault.com.

Juanma

Subject: Instalação do Ossim em Português (Brazilian) - Part I Posted by jailsonjan on Tue, 15 Dec 2009 14:10:55 GMT View Forum Message <> Reply to Message

Guia de Instalação do OSSIM (AlienVault Open Source SIM ) – Parte I Link for JailsonJan Blog:http://www.previsioni.com.br/jailsonjan/?p=147 Introdução O Ossim (Open Source AlienVault)


OSSIM

by FUDforum 2.7.7

é um sistema de segurança detalhado que cobre do nível da deteção até um nível executivo, gerando métricas e relatórios. OSSIM é oferecido como um produto da segurança que permite que você integre em um único console todos os dispositivos e ferramentas de segurança disponíveis em sua rede, assim como a instalação de ferramentas de segurança prestigiadas de fonte aberta (open source) como Snort, OpenVas, Ntop and OSSEC. Uma vez que os eventos gerados por ferramentas e por dispositivos diferentes são coletados pelo OSSIM, o sistema executa uma avaliação de risco para cada evento e a correlação destes. Durante o processo de correlação, de uma série de testes padrões, o OSSIM gera novos eventos para detectar ataques ou problemas na sua rede. Para ar toda a informação coletada e gerada pelo sistema, o OSSIM inclui uma interface Web que nós permite configurar todo o sistema e ver o estado total da rede em tempo real. Antes de começar OSSIM é um produto constantemente em desenvolvimento. Por este motivo nós usaremos a versão mais estável do instalador do OSSIM neste guia de instalação. As versões as mais novas estão sempre disponíveis na Web no site do projeto OSSIM – http://www.AlienVault.com Finalidades deste documento A finalidade deste documento é fornecer um o a o, um guia de como instalar o OSSIM. Cobrindo conceitos básicos e uma breve explanação do papel de cada perfil que uma instalação de OSSIM pode adotar. Por que um instalador? OSSIM é um produto que integra mais de 30 ferramentas de Open Source. O sistema operacional (Linux – Debian) e muitas ferramentas internas foram modificados para melhorar seu funcionamento dentro do sistema. Isso ocorre devido ao fato dque para instalar o OSSIM do código fonte exige um pouco mais de conhecimento e muito tempo para fazer a compilação de mais de 40 ferramentas diferentes. Para simplificar o processo complexo de compilação, instalação e configuração todas estas ferramentas, a equipe de desenvolvimento distribui o instalador de OSSIM que inclui sistema operacional, todos os componentes e uma configuração poderosa e sistema a atualização. O instalador de OSSIM é baseado no sistema operacional Debian GNU/Linux e está disponível em edições de 32 bits e 64-bit, edições 32 Bits vs 64 Bits Se seu processador é de 64-bits então você pode aproveitar todo desempenho desta arquitetura.


OSSIM

by FUDforum 2.7.7

Em determinadas estruturas (”backbones”), baseado na produção e no número de eventos, você pode precisar de um “hardware” capaz de ar grandes volumes de dados. A arquitetura 64-bit igualmente permite o uso de uma quantidade maior de memória física. OSSIM Operações Básicas Os seguintes processos ocorrem dentro de OSSIM: 1. As aplicações geram eventos da segurança 2. Os eventos são coletados e normalizados 3. Os eventos são enviados a um servidor central 4. Avaliação de risco 5. Correlação do evento 6. Armazenamento dos eventos 7. o aos eventos armazenados 8. o à configuração 9. Alcance as métricas (medidores) e aos relatórios 10. Informação em tempo real do status de sua rede As aplicações e os dispositivos da rede geram eventos da segurança. Estes eventos são coletados e normalizados pelo agente do OSSIM, que é o responsável por enviá-los ao servidor do OSSIM. Em uma instalação OSSIM pode-se ter quantos agentes forem necessários. Em alguns casos, se tem um agente em cada posição da rede da empresa, ou um agente dentro do DMZ ou um outro agente dedicado para coletar todos os registros do “firewall”. O agente do OSSIM inclui um jogo das ferramentas (Snort, Ntop, Ttrack, Arpwatch), para analisar o tráfego de rede à procura dos problemas e das anomalias de segurança. Para aproveitar-se desta funcionalidade do OSSIM, o agente do OSSIM deve receber todo o tráfego na rede, usando uma conexão, configurar uma porta espelhada ou usando uma porta de extensão nos dispositivos da rede. Todos os agentes de OSSIM enviam seus eventos a um único servidor de OSSIM. Este servidor carrega a avaliação de risco e a correlação. Uma vez que estes processos ocorreram, os eventos são armazenados na base de dados de OSSIM. Para ar estas informações, o OSSIM inclui uma interface gráfica (web), que pode ser usada para modificar parâmetros da configuração e para gerar o métricas e os relatórios. A interface gráfica (web), igualmente, fornecerá o o as informações, em tempo real, de um grande número de aplicações, que analisam o status global de nossa rede (Ntop, Nagios, etc). Perfis Uma vez que a instalação terminou, o OSSIM, permite mudar o perfil da instalação . Por


OSSIM

by FUDforum 2.7.7

padrão o perfil completo será instalado automaticamente. Perfil Completo O perfil completo é uma combinação de todos os perfis em uma única máquina. Inclui a interface do sensor, um servidor, uma base de dados e uma interface gráfica (web). O sensor no perfil completo, habilitará o Snort, o OpenVas, o Ntop, o Arpwatch, o P0f e o Pads. O perfil completo é o padrão da instalação do Ossim. Sensor O Sensor é o responsável pela captura e pela normalização dos eventos. Para permitir a captura e coleção de todos os registros (log) pelo Sensor, teremos que enviar todos os eventos ao Sensor usando Syslog, ftp, samba, Snare, etc. Cada uma destas ferramentas está associada a um “plugin” no OSSIM, que define como coletar os eventos dos registros de logs. Os eventos normalizados são enviados ao servidor. Snort, Ntop, Arpwatch, P0f e Pads são igualmente habilitados no perfil do Sensor somente. Para fazer estas ferramentas úteis, nós devemos usaar uma conexão, configurar uma porta espelhada ou usar uma porta de extensão nos dispositivos da rede (geralmente no Switch). Servidor O perfil do Servidor é preparar o OSSIM (box) para coletar os registros (logs) de todos os Sensores OSSIM. Uma vez que os eventos foram processados, todas as informações são armazenadas na base de dados. O Servidor incluirá um agente de OSSIM para monitorar a segurança do sistema (Pam Unix, SSH) Banco de Dados O “Servidor de Bancos de Dados”, possui uma base de dados MySQL para armazenar os eventos, configurações e informações de inventário. Requirementos Requirementos de Hardware As exigências de hardware do OSSIM dependerão basicamente do número de eventos por segundo e da produção da rede que queremos proteger.


OSSIM

by FUDforum 2.7.7

A exigência mínima aconselhad, é ter pelo menos 2GB da ram. É possível que se tenha que aumentar a memória de RAM disponível, baseada na produção da rede, no número de eventos que o Servidor OSSIM está processando e na quantidade de dados que precisam de ser armazenados na base de dados. Para um melhor desempenho é essencial usar somente as aplicações e componentes que serão úteis em cada caso ou na sua rede. Em termos de desempenho, há uma diferença enorme entre processadores de 32 bit and 64 bit, se você estiver comprando um novo hardware, escolha o de 64-Bits. A maioria de componentes do OSSIM am “multithreading”, fazendo com que os servidores que usam os processadores de 64-Bits, obtenham uma grande melhoria no desempenho. Ao falar sobre placas de rede, você deve tentar escolher aqueles ados pelo “driver” e1000. O modelo do desenvolvimento de Open Source deste “drive” assegura a boa compatibilidade destas placas com o Debian GNU/Linux. As placas de rede de menor desempenho podem ser usadas nos OSSIM (box) para coletar eventos de outros dispositivos ou como interfaces de gerênciamento. Requerimentos de Rede A fim de apresentar o OSSIM corretamente, você deverá ter um grande conhecimento dos dispositivos da sua rede. Você terá que configurar uma porta espelhada naqueles dispositivos de rede que em esta característica. Para configurar uma porta espelhada corretamente, você terá que manter na mente que deve evitar estas duas situações: * Tráfego de rede duplicado: Isto aconteceu quando nós estamos enviando o mesmo tráfego de rede mais de uma vez em diferentes dispositivos da rede. * Tráfego de rede criptografado: Em alguns casos não tem nenhum sentido configurar uma porta espelhada naqueles dispositivos que mostram somente o tráfego criptografado (VPN, SSH), porque este tráfego não pode ser facilmente analizedo por algumas aplicações. Ainda sobre porta espelhada, nós precisamos ter endereços de IP prontos para todas os OSSIM (box). Alguns OSSIM (box), que funcionam como Sensores podem exigir mais de uma placa de rede, porque o Sensor poderá ter o à redes diferentes (Nessus, Nagios, Nmap) Como exemplo, OpenVas (exploração da vulnerabilidades), terá que ter o para alcançar as “redes alvo”, quando a varredura acontecer. Ao usar OpenVas, Nagios ou Nmap nós igualmente temos que nos certificar de que nossos “firewalls” estão configurados corretamente, permitindo o o de nossos sensores às redes ou aos servidores das “redes alvo”. Os eventos têm que ser normalizados antes de processados pelo Servidor OSSIM, o sensor


OSSIM

by FUDforum 2.7.7

do OSSIM exigirá o o ao servidor de DNS da rede local . Fonte Original: http://ossim.net/dokuwiki/doku.php?id=installation Artigo Original: Juan Manuel Lorenzo (jmlorenzo at AlienVault dot com) Tradução e complementos: Jailson Jan (jailsonjan at yahoo dot com dot br / jailsonjan at previsioni dot com dot br) Jailson Jan é o tradutor do Ossim para o português do Brasil (pt_BR)

Subject: Instalação do Ossim em Português (Brazilian) - Part II Posted by jailsonjan on Tue, 15 Dec 2009 14:17:12 GMT View Forum Message <> Reply to Message Guia de Instalação do OSSIM (AlienVault Open Source SIM ) – Parte II Fonte: Jailson Jan Blog (http://www.previsioni.com.br/jailsonjan/?p=153)

Visão geral da instalação 1- Você terá que certificar-se de que seu computador pode ser inicializado pelo CDROM/DVD (boot). Procure pela documentação do sistema para mais informações. Isto pode exigir a alteração das configurações do BIOS. Para começar o programa de instalação, inicialize o computador e aguarde o boot pelo CDROM. Atenção: O instalador APAGARÁ todos os dados armazenados em seu disco rígido. 2-Escolha a língua usada para o processo de instalação. A língua escolhida será usada também para o sistema instalado. 3-Escolha sua localização 4-Escolha o layout de teclado 5-Neste ponto você terá que configurar a placa de rede. Se você tem mais de uma placa de rede, terá que escolher qual será usada como a interface de gerenciamento. Em caso de ter múltiplas placas de rede, o instalador perguntará que placa de rede deverá ser usada como a interface de gerenciamento. Esta interface deve ter o à Internet durante o processo da instalação. Entre com o endereço IP para continuar 6-Insira a máscara do endereço


OSSIM

by FUDforum 2.7.7

7-Insira o endereço IP do gateway. Todo tráfego que vai para fora da sua LAN será enviado através desta rota. 8-Entre com os endereços IP dos servidores de nomes (DNS), separados por espaços. Se você tem um servidor de nomes (DNS) local em sua rede deverá ser o primeira nesta configuração. Você pode entrar com quantos servidores de nomes (DNS) que desejar. 9-Entre com um nome para o servidor do OSSIM (hostname) 10-If you are using a domain name in the computers of your network, enter the domain name 10-Se você está usando um servidores de nomes (DNS) nos computadores de sua rede, entre com as informações do servidores de nomes (DNS) 11-Selecione o fuso horário (timezone) 12-Ocorre neste momento o particionamento do disco. Selecione a primeira opção: Usar o disco inteiro. 13-Selecione “Guiado: Use a partição inteira do disco”, isto apagará todos os dados armazenados em seu disco rígido. 14 -Neste momento você escolhe se deseja armazenar tudos os arquivos da instalação em uma só partição ou em partições separadas. Selecione todos os arquivos em uma só partição. 15-Agora o instalador mostrará a partição sugerida. Aplique as mudanças e continue. 16-Todos os pacotes do software serão configurados agora. O Postfix (software de correio eletrônico) perguntará sobre a configuração do servidor de email, configure-o conforme as suas necessidades. Se você não tem um servidor de email na sua rede ou se você deseja ter um próprio no OSSIM Box, selecionamos “Site de Internet”. Se você já tem um servidor de email na sua rede, pode selecionar o “Sistema Satélite”. 17-Aceite o contrato de licência de Java. 18-Uma vez que todo o software esteja instalado e configurado (isto poderá demorar alguns minutos), o sistema pedirá a senha da raiz (senha de root). Você terá que digitar duas vezes a senha da raiz (senha de root). 19-Antes de terminar o processo de instalação, o sistema Ossim verificará se há novas versões do software disponíveis ou novas correções. É muito importante que você tenha uma conexão com a internet durante o processo de instalação, para que seu sistema possa ser atualizado.


OSSIM

by FUDforum 2.7.7

A máquina será recarregada automaticamente (rebotada). Uma vez iniciado, o sistema carregará todas as aplicações que estarão configuradas de acordo com os ajustes padrões. Para terminar o processo de instalação, espere a carga automática da Ossim. Uma vez que você termina o processo de carga, poderá prosseguir, configurando todas as aplicações de acordo com os ajustes necessários para a sua rede e conforme a suas vontades. Fonte original: http://ossim.net/dokuwiki/doku.php?id=installation Artigo Original: Juan Manuel Lorenzo (jmlorenzo at AlienVault dot com) Tradução e complementos: Jailson Jan (jailsonjan at yahoo dot com dot br / jailsonjan at previsioni dot com dot br) Jailson Jan é o tradutor do Ossim para o português do Brasil (pt_BR)

Subject: Guia de Instalação do OSSIM – Parte III (Brazilian) Posted by jailsonjan on Mon, 21 Dec 2009 15:22:21 GMT View Forum Message <> Reply to Message Guia de Instalação do OSSIM (AlienVault Open Source SIM ) – Parte III Configuração do Sistema Para simplificar a configuração do grande número de ferramentas incluídas no OSSIM, a configuração é centralizada em um único arquivo. Cada vez que você modificar esta configuração, deverá rodar um comando para atualizá-la, atualizando assim, a configuração de cada aplicação baseada na configuração centralizada (principal). A configuração centralizada é armazenada na seguinte arquivo: /etc/ossim/ossim_setup.conf Nós podemos editar este arquivo usando um editor de texto (vim, nano, pico, kate). os usuários inexperimentes devem usar o seguinte comando para editar este arquivo: ossim-setup Para aplicar a configuração centralizada em um arquivo de configuração você terá rodar o seguinte comando: ossim-reconfig


OSSIM

by FUDforum 2.7.7

Trocando o perfil Todos os perfis são habilitados por padrão, após ter funcionado o instalador. Você poderá mudar o perfil usando o “ossim-setup” (script de configuração) da instalação do Ossim, selecionando a segunda opção (”Trocar Configurações do Perfil”/”Change Profile Settings”) Baseado no perfil escolhido você terá que configurar diferentes parâmetros de configuração: completo * Escolha interfaces: Entre com todas as interfaces (separadas pela vírgula) que estão recebendo todo o tráfego da sua rede. * Perfil de redes: Entre com as redes (redes locais) no formato CIDR, separado por vírgula, estas redes são as que o Sensor poderá ver (ar) em sua interface de escuta (por exemplo: 192.168.0.0 /24, 10.0.0.0 /8) * Nome do Sensor do OSSIM: Dê um nome para o Sensor instalado na máquina. * Escolha os plugins: Selecione aqueles plugins que devem ser habilitados neste Sensor. Os plugins do monitor somente serão habilitados sob pedidos (requisições) do Servidor do OSSIM, durante a correlação. Os plugins do detetor estarão coletando eventos em tempo real dos arquivos, bases de dados e soquetes. Sensores * Nome do Sensor do OSSIM: Dê um nome para o Sensor instalado na máquina. * Escolha interfaces: Entre com todas as interfaces (separadas pela vírgula) que estão recebendo todo o tráfego da sua rede. * Perfil de Redes: Entre com as redes (redes locais) no formato CIDR, separado por vírgula, estas redes são as que o Sensor poderá ver (ar) em sua interface de escuta (por exemplo: 192.168.0.0 /24, 10.0.0.0 /8) * Endereço IP do Servidor do OSSIM: Entre com o Endereço IP do Servidor do OSSIM está escutando. * Escolha os plugins: Selecione aqueles plugins que devem ser habilitados neste Sensor. Os plugins do monitor somente serão habilitados sob pedidos (requisições) do Servidor do OSSIM, durante a correlação. Os plugins do detetor estarão coletando eventos em tempo real dos arquivos, bases de dados e soquetes. Servidor


OSSIM

by FUDforum 2.7.7

* Endereço IP do servidor de banco de dados do OSSIM (Mysql): Entre com o Endereço IP do Servidor OSSIM que está rodando a base de dados (servidor MySql). Certifique-se de que você tem as permissão corretas para ar o servidor da base de dados e que pode conectar de uma máquina do remota. * Porta do servidor de banco de dados do MySql: Porta de escuta para o MySql. (A porta padrão é 3306) * Usuário do servidor de banco de dados do MySql: O padrão no Ossim é o “root” (usuário principal) * Senha do servidor de banco de dados do MySql: Senha para o “root” (usuário principal) no servidor de banco de dados do Mysql. Danco de Dados * Senha do servidor de banco de dados do MySql: Senha para o usuário “root” do servidor de banco de dados do Mysql. Se você precisar somente reconfigurar o perfil em uso, selecione-o e você será questionado à entrar com os parâmetros da configuração. Para aplicar as alterações que você selecionou, clique em “aplique e salve todas as mudanças / Apply and save all changes” ou rode o comando da reconfiguração do Ossim “ossim-reconfig”. Configuração de Rede Aquelas máquinas que rodam o OSSIM exigem um cuidado especial ao configurar a rede. Those machines running OSSIM require special care when configuring networking. A configuração de rede é definida no seguinte arquivo: /etc/network/interfaces Se a configuração de rede foi modificada, para aplicar-lhe as mudanças use o seguinte comando: /etc/init.d/networking restart Cada OSSIM Box deve ter pelo menos um endereço IP estático, assim os componentes diferentes do OSSIM podem comunicar-se entre si e o pode ter o o remoto às máquinas. Cada interface (placa de rede) com um endereço IP válido, deve ter uma entrada no arquivo /etc/network/interfaces usando o seguinte esquema:


OSSIM

by FUDforum 2.7.7

allow-hotplug eth0 iface eth0 inet static address 192.168.1.133 netmask 255.255.0.0 network 192.168.0.0 broadcast 192.168.255.255 gateway 192.168.1.1 dns-nameservers 192.168.1.100 Aquelas interface (placa de rede) usadas para coletar todo o tráfego de rede nunca devem ter um endereço IP. As interface (placa de rede) em modo promíscuos (promiscuous mode) não exigem nenhuma configuração especial no arquivo de configuração da rede.

Atualizando o OSSIM Os seguintes comandos atualizarão o sistema OSSIM: apt-get update; apt-get dist-upgrade; O software que atualiza o sistema, usado no instalador do OSSIM, foi projetado para assegurar-se que as versões corretas sejam usadas. Permite aos colaboradores de OSSIM bloquearem ou forçar atualizações de determinado software no sistema. Por este motivo, você nunca deve incluir repositórios de software novos em seu /etc/apt/sources.list. Esta informação é muito importante. Fonte: http://ossim.net/dokuwiki/doku.php?id=installation Artigo Original: Juan Manuel Lorenzo (jmlorenzo at AlienVault dot com) Tradução e complementos: Jailson Jan (jailsonjan at yahoo dot com dot br / jailsonjan at previsioni dot com dot br) http://www.previsioni.com.br/jailsonjan/ Jailson Jan é o tradutor do Ossim para o português do Brasil (pt_BR)

Subject: Guia de Instalação do OSSIM – Parte IV Posted by jailsonjan on Mon, 21 Dec 2009 15:25:37 GMT View Forum Message <> Reply to Message Guia de Instalação do OSSIM (AlienVault Open Source SIM ) – Parte IV


OSSIM

by FUDforum 2.7.7

Ossim na versão profissional Além de conduzir o desenvolvimento de OSSIM, a AlienVault está desenvolvendo uma versão profissional “AlienVault Professional SIEM” que oferece importantes recursos para ambientes de muita demanda. A versão comercial, possui: * SEM: armazenamento de alto volume * Escalabilidade: distribuídas, hierárquicas * Desempenho: performance 30 vezes maior * Confiabilidade: Redundância e alta disponibilidade Recomendações Gerais * Em ambientes de produção é recomendado sempre usar arquiteturas de 64-bit, já que há uma grande diferença em termos de desempenho se comparados com a versão de 32 bits. * Nunca instale um Sensor de OSSIM em um ambiente virtualizado se este sensor está indo coletar enormes quantidades de tráfego de rede. Por causa da maneira que estas ferramentas da virtualização controlam as interfaces de rede virtual, uma grande quantidade do tráfego da rede é perdido, sem ser analisada. * Nunca instale softwares no OSSIM Box, que necessitem de alteração dos repositórios de Debian no arquivo “/etc/apt/sources.list”. * O OSSIM sempre terá e para a versão mais estável do Debian GNU/Linux. Quando uma versão nova de Debian for liberada os colaboradores fornecerão um guia em como atualizar o o Ossim instalado para a versão mais nova. * Não há nenhuma limitação de instalação de software que possa ser instalado nas máquinas (desde que estejam no sources.list original do Ossim), mas lembre-se que um elevado consumo de memória ou de processador (u) de algumas aplicações, podem prejudicar a performance da mesma. Como exemplo, você nunca deve instalar um ambiente desktop nas máquinas OSSIM. Fonte: http://ossim.net/dokuwiki/doku.php?id=installation Artigo Original: Juan Manuel Lorenzo (jmlorenzo at AlienVault dot com) Tradução e complementos: Jailson Jan (jailsonjan at yahoo dot com dot br / jailsonjan at previsioni dot com dot br) Blog: http://www.previsioni.com.br/jailsonjan/ Jailson Jan é o tradutor do Ossim para o português do Brasil (pt_BR)


OSSIM

by FUDforum 2.7.7

Subject: Ossim - Perfis Posted by jailsonjan on Mon, 21 Dec 2009 15:30:12 GMT View Forum Message <> Reply to Message Geralmente, uma distribuição típica do ossim consiste: * Um servidor de banco de banco de dados (normalmente MySql). * Um servidor que hospede o motor da avaliação de correlação, da qualificação e do risco. * Os N servidores dos agentes fazem a coleta de informação e que se encarregam de um número de dispositivos. Para uma lista de “plugins” veja em: http://www.alienvault.com/community.php?section=Plugins * Um controle automático (daemon), que faça algum trabalho de manutenção e anexe algumas partes. Isto é chamado de “frameworkd”. * O frontend (interface), baseado em web, unificando toda a informação recolhida, fornecendo a habilidade de controlar cada um dos componentes. Fonte: http://ossim.net/dokuwiki/doku.php?id=installation Artigo Original: Juan Manuel Lorenzo (jmlorenzo at AlienVault dot com) Tradução e complementos: Jailson Jan (jailsonjan at yahoo dot com dot br / jailsonjan at previsioni dot com dot br)

Blog: http://www.previsioni.com.br/jailsonjan/ Jailson Jan é o tradutor do Ossim para o português do Brasil (pt_BR)

Subject: Sensor do OSSIM - Os agentes - Parte I Posted by jailsonjan on Mon, 21 Dec 2009 18:37:40 GMT View Forum Message <> Reply to Message Sensor do OSSIM - Os agentes - Parte I http://www.previsioni.com.br/jailsonjan/

Subject: Sensor do OSSIM – Os agentes – Parte II Posted by jailsonjan on Mon, 21 Dec 2009 19:47:06 GMT View Forum Message <> Reply to Message


OSSIM

by FUDforum 2.7.7

Sensor do OSSIM – Os agentes – Parte II (Brazilian portuguese and English) http://www.previsioni.com.br/jailsonjan/

Subject: Ossim – Configuração Principal do Ossim – Parte I Posted by jailsonjan on Tue, 22 Dec 2009 18:54:45 GMT View Forum Message <> Reply to Message Ossim – Configuração Principal do Ossim – Parte I (Brazilian portuguese and English) http://www.previsioni.com.br/jailsonjan/

Subject: Re: OSSIM listing Posted by TMG1980 on Wed, 13 Jan 2010 18:03:41 GMT View Forum Message <> Reply to Message You can always use the following command to find the tomcat-s.xml file which contains the default pwd for and manager: $ find / -name 'tomcat-s.xml' Once you find the file path and navigate to it, you can use an editor(i.e. pico) to open and edit the file. Cheers

Subject: Ossim - Incidentes (brazilian portuguese) Posted by jailsonjan on Thu, 14 Jan 2010 12:24:59 GMT View Forum Message <> Reply to Message Translation for the Brasilian Portuguese and Complements, for Jailson Jan (translating of the Ossim for pt_BR)


OSSIM

by FUDforum 2.7.7

http://www.previsioni.com.br/jailsonjan/?p=278

Subject: Re: HOWTO: Get Snort 2.8.X on Ubuntu feeding to OSSIM Posted by jlambrecht on Fri, 15 Jan 2010 17:11:41 GMT View Forum Message <> Reply to Message my set-up is ossim (oss) image running centos with snort configured, logging to mysql Since so far i did not have time to delve into ossim-configuration and set-up i'm a bit lost. Is there a simple way to have ossim read the mysql-db on the centos-snort machine ? Since this set-up is experimental i assumed this would be read by setting the db in the configuration(advanced) but no luck. Please advise as the mailbox does not answer at all. tnx

Subject: Re: OSSEC Quick Start Guide Posted by punkrokk on Thu, 21 Jan 2010 19:29:21 GMT View Forum Message <> Reply to Message FYI -- I just did this with OSSEC 2.3 on a win 2k3 machine and the windows instructions worked great. jplee3 wrote on Wed, 04 November 2009 12:18Hey guys, will this still work with the latest versions of OSSEC and OSSIM? I was trying to tie the two together but could not figure it out. I'll have to play around with it more when I have the time.

Subject: Re: HOWTO: Get Snort 2.8.X on Ubuntu feeding to OSSIM Posted by kristian_paul on Mon, 25 Jan 2010 15:01:21 GMT View Forum Message <> Reply to Message I think that for non-patech snort on the wild, ossec could help to get those logs and then send it back to ossim Or you can patch snort to work with ossim agen using the unified stuff and get better speed if is needed


OSSIM

by FUDforum 2.7.7

regards

Subject: Re: Install Oinkmaster and update snort rules Posted by punkrokk on Fri, 29 Jan 2010 19:05:23 GMT View Forum Message <> Reply to Message I have made a cron job out of this:

#/bin/sh /usr/share/oinkmaster/makesidex.pl /etc/snort/rules/ >autodisable.conf oinkmaster -C /etc/oinkmaster.conf -C /etc/autodisable.conf -o /etc/snort/rules perl /usr/share/ossim/scripts/create_sidmap.pl /etc/snort/rules /etc/init.d/ossim-server restart Works great, run once every 24 hours or whatever. :d

Subject: Re: Install Oinkmaster and update snort rules Posted by rossonr on Mon, 01 Feb 2010 16:00:29 GMT View Forum Message <> Reply to Message Wouldn't this also need to be piped to mysql to update the database?

Subject: Re: Install Oinkmaster and update snort rules Posted by punkrokk on Mon, 01 Feb 2010 16:03:09 GMT View Forum Message <> Reply to Message Nope, (at least not that I can tell) The line: perl /usr/share/ossim/scripts/create_sidmap.pl /etc/snort/rules runs an OSSIM script that updates the db and correlates everything.

Subject: Re: Install Oinkmaster and update snort rules Posted by juanma on Mon, 01 Feb 2010 16:09:35 GMT Page 95 of 123 ---- Generated from

OSSIM

by FUDforum 2.7.7

View Forum Message <> Reply to Message create-sidmap.pl updates the database, is oinkmaster restarting snort? If not, you should also have to restart snort. juanma

Subject: Re: Install Oinkmaster and update snort rules Posted by rossonr on Mon, 01 Feb 2010 16:47:48 GMT View Forum Message <> Reply to Message I am using pulledpork. :) which can be reconfigured to restart snort

Subject: Re: Install Oinkmaster and update snort rules Posted by punkrokk on Mon, 01 Feb 2010 18:21:29 GMT View Forum Message <> Reply to Message Just to make sure, I added /etc/init.d/snort restart to the end of my script. Leaving me with: #/bin/sh /usr/share/oinkmaster/makesidex.pl /etc/snort/rules/ >autodisable.conf oinkmaster -C /etc/oinkmaster.conf -C /etc/autodisable.conf -o /etc/snort/rules perl /usr/share/ossim/scripts/create_sidmap.pl /etc/snort/rules /etc/init.d/snort restart /etc/init.d/ossim-server restart Note that if you subscribe to the snort rules your oinkmaster.conf path to grab the snort rules will be different. Here's some reading on the oinkmaster in debian topic: http://www.cyberarmy.net/library/article/1728 Now to figure out how to get Nessus to auto update :)

Subject: Re: Install Oinkmaster and update snort rules Posted by rossonr on Tue, 02 Feb 2010 13:13:46 GMT View Forum Message <> Reply to Message


OSSIM

by FUDforum 2.7.7

I have this in a script that I execute from cron /usr/local/bin/alienvault-feed-sync openvas /etc/init.d/openvas-server restart

P.S. For restart to work for openvas you need to edit /etc/init.d/openvas-server script to add the path for start-stop-daemon

Subject: Re: Install Oinkmaster and update snort rules Posted by punkrokk on Tue, 02 Feb 2010 21:34:37 GMT View Forum Message <> Reply to Message Is this required for OpenVAS correlation? rossonr wrote on Tue, 02 February 2010 06:13I have this in a script that I execute from cron /usr/local/bin/alienvault-feed-sync openvas /etc/init.d/openvas-server restart

P.S. For restart to work for openvas you need to edit /etc/init.d/openvas-server script to add the path for start-stop-daemon

Subject: Re: Install Oinkmaster and update snort rules Posted by rossonr on Wed, 03 Feb 2010 12:52:58 GMT View Forum Message <> Reply to Message After the execution of this "/usr/local/bin/alienvault-feed-sync openvas" it tells you the openvasd needs to be restarted.

Subject: Re: OSSEC Quick Start Guide Posted by s00pcan on Wed, 03 Feb 2010 19:04:43 GMT View Forum Message <> Reply to Message On an ubuntu agent: root@ubuntu-vm:/var/ossec/bin# ./ossec-control start ... 2010/02/03 14:46:48 ossec-agentd(4105): ERROR: No valid server IP found. 2010/02/03 14:46:48 ossec-agentd(1215): ERROR: No client configured. Exiting.


OSSIM

by FUDforum 2.7.7

How do I configure the server IP then?

Subject: Re: Use HTTPS instead of HTTP Posted by dropadrop on Sat, 06 Feb 2010 20:14:54 GMT View Forum Message <> Reply to Message Maybe a silly question, but would'nt it be easier to just install a second apache in front as a proxy?

Subject: Re: Use HTTPS instead of HTTP Posted by juanma on Sun, 07 Feb 2010 12:53:45 GMT View Forum Message <> Reply to Message This will come by default in OSSIM 2.2

Subject: Re: Use HTTPS instead of HTTP Posted by dropadrop on Tue, 09 Feb 2010 08:29:02 GMT View Forum Message <> Reply to Message Great, then I won't waste time configuring it now. :)

Subject: how to set ossim server and ossim sensor Posted by manean on Fri, 12 Feb 2010 18:12:56 GMT View Forum Message <> Reply to Message Hi, Kindly give me an guidance and steps for to implement ossim server and ossim sensor. Mainly how to connect and use the database . Early help is appreciated. Thanks in advance. :p with regards., manean.kvs.


OSSIM

by FUDforum 2.7.7

Subject: Re: Install Oinkmaster and update snort rules Posted by nokster on Fri, 12 Feb 2010 19:55:37 GMT View Forum Message <> Reply to Message punkrokk wrote on Mon, 01 February 2010 13:21 Now to figure out how to get Nessus to auto update :)

"usr/local/bin/alienvault-feed-sync" apparently also accepts nessus as a parameter? tried it out and I'm not sure if it works though because it ends with an error... thanks for the cron script.

Subject: Re: Install Oinkmaster and update snort rules Posted by punkrokk on Fri, 12 Feb 2010 20:07:39 GMT View Forum Message <> Reply to Message haha, you're welcome! :)

Subject: Re: OSSIM listing Posted by pettiet on Wed, 17 Feb 2010 14:07:10 GMT View Forum Message <> Reply to Message I'm new to OSSIM and just made a proof of concept intall yesterday. As recommended, I reset the but was unable to today. How can the be reset if you cannot ? Thanks for the help.

Subject: Re: OSSIM listing Posted by TMG1980 on Wed, 17 Feb 2010 14:37:04 GMT View Forum Message <> Reply to Message Default uid and pwd is when you on the frontend (use the IP you assigned to OSSIM). Try that first.

Subject: Re: OSSIM listing Posted by pettiet on Wed, 17 Feb 2010 14:56:47 GMT View Forum Message <> Reply to Message Yes, that is what worked after installing yesterday. However, I thought I changed the but it does not work today. Any suggestions for resetting a lost without


OSSIM

by FUDforum 2.7.7

having to reinstall everything?

Subject: Re: OSSIM listing Posted by TMG1980 on Wed, 17 Feb 2010 15:32:40 GMT View Forum Message <> Reply to Message ssh or logon to the OSSIM box as root. find the tomcat-s.xml file and edit that file. There should be a line that contains the and Manger s. Change the pwd there. Quick way to find the file: $ find / -name 'tomcat-s.xml'

Subject: Re: OSSIM listing Posted by pettiet on Wed, 17 Feb 2010 15:39:37 GMT View Forum Message <> Reply to Message Thanks, got it going now. I appreciate the help.

Subject: Re: Use HTTPS instead of HTTP Posted by stlist on Thu, 04 Mar 2010 21:41:42 GMT View Forum Message <> Reply to Message Juanma, OSSIM 2.2 is out. I don't see any straightforward way to setup https for the OSSIM webpages. Could you point us to the right direction? Thanks, Sam

Subject: Re: Set second OSSIM server as sensor/agent only Posted by TrevorBenson on Thu, 18 Mar 2010 01:15:01 GMT View Forum Message <> Reply to Message In step three it says:Quote:Check on sensor ossim_setup.conf so it will act as sensor In my file I have:ocs_db=ocsweb ossim_db=ossim


OSSIM

by FUDforum 2.7.7

osvdb_db=osvdb =<something> type=mysql =root [expert] profile=server [sensor] detectors=snare, p0f, osiris, arpwatch, snortunified, pads, ssh, pam_unix, rrd, sudo, iptables, nagios interfaces=eth0 ip= monitors=nmap-monitor, ntop-monitor, ossim-monitor name=ossim priority=5 [server] server_ip= server_plugins=osiris, pam_unix, ssh, snare, sudo server_port=40001

Does this refer to changing the expert profile setting to sensor instead of server? Not really sure what it means to 'check on sensor', if eth0 is the configuration in the /etc/network/interfaces, then would this ossim_setup.conf already be a working configuration? Also mentioned in step 4: Quote: Check sensor's interface(s) in /etc/network/interfaces so it's configuration is consistent with /etc/ossim/ossim_setup.conf, one as default, other set in promiscuous mode if it have more than 1 interface I assume this means if you have 2 interfaces in the same network, use 1 as default management and 1 as promiscuous for snort etc.? Otherwise if you have multiple interfaces in different subnets wouldn't you want it promiscuous on all interfaces? Thanks, Trevor

Subject: Re: Method to check and see what OSSEC is logging (without the web gui) Posted by kristian_paul on Thu, 25 Mar 2010 19:32:52 GMT View Forum Message <> Reply to Message I used to activay temporally logall option in the ossec config so i can debug what are logs are


OSSIM

by FUDforum 2.7.7

been received from agents

Subject: Guide: Nessus 4.0.2 on OSSIM 2.2.1 Posted by fable on Wed, 31 Mar 2010 06:51:31 GMT View Forum Message <> Reply to Message I have been trying to Make NESSUS work on OSSIM 2.2.1 for a few days now and I have to it it was hell! From what I discovered it OSSIM will most likeley not work with NESSUS 4.2.x and a HomeFeed (as I posted here too: https://www.alienvault.com/forum/index.php?t=msg&th=2107 &start=0&S=dbf97230c72cc76508327ff1afae4e76). That was not the only problem though. I made this guide to collecting what I found in the forum and what I discovered myself. Use this a step-by-step guide to make NESSUS 4.0.2 work on a fresh OSSIM 2.2.1 install.

1. version 4.0.2 Navigate to http://www.nessus.org//. Go the the bottom of the page, there is a link there. While you are there you can for a Feed Code as well. the file to your OSSIM server using S.I ed it to the /home directory. 2. Update OSSIM run: /ossim-update. Answer "yes" to all questions 3. Disable the firewall run: ossim-setup go to Change General Setting --> Configure Firewall. Highlight "No" and hit space. Hit OK and then "Save $ Exit". This step is not necessarily needed if you have correctly configured your firewall. 4. Install NESSUS run: dpkg -i /home/Nessus-4.0.2-debian5_i386 5. Update Plugins run /opt/nessus/bin/nessus-fetch --

. Replace  with your HomeFeed or ProfessionalFeed code.


                   Page 102 of 123 ---- Generated from


                   OSSIM


                   by FUDforum 2.7.7


                   6. Configure the OSSIM database for NESSUS (From "DK's" post on this thread) run: ossim-db TRUNCATE `vuln_nessus_category`; TRUNCATE `vuln_nessus_family`; TRUNCATE `vuln_nessus_plugins`; TRUNCATE `vuln_nessus_preferences`; TRUNCATE `vuln_nessus_preferences_defaults`; TRUNCATE `vuln_nessus_settings`; TRUNCATE `vuln_nessus_settings_category`; TRUNCATE `vuln_nessus_settings_family`; TRUNCATE `vuln_nessus_settings_plugins`; exit 7. Configure NESSUS a. Change Listening IP: run: nano /opt/nessus/etc/nessus/nessusd.conf and change the "listening ip" to your local IP. ATTENTION: This is the IP assigned to your NIC (e.g. 192.168.1.1), NOT LOCALHOST b. Create a  run: /opt/nessus/sbin/nessus-add. Use  instead of cert and make  an  c. Create a cert run: /opt/nessus/sbin/nessus-mkcert. Choose all the defaults 8. Configure OSSIM a. Edit the web interface go to Configuration-->Main-->Advanced-->Vulnerability Scanner. Enter the  name and  of the  you just created. For IP enter the IP assigned to your NIC (the one you entered on step 7a). Port: 1241, location: /opt/nessus/bin/nessus 9. Start NESSUS


                   Page 103 of 123 ---- Generated from


                   OSSIM


                   by FUDforum 2.7.7


                   run: /opt/nessus/sbin/nessus-service . Wait until you get the All plugins loaded message. Leave this window open and start a new ssh session to your OSSIM server. (I haven't found a way to make this run in the background yet) 10. Configure the OSSIM database Run: cd /usr/share/ossim/scripts/vulnmeter/ ./updateplugins.pl cd /usr/share/ossim/scripts/vulnmeter/ ./update_nessus_ids.pl Your NESSUS setup is now completed! You can initiate new scans by going to OSSIM's web interface under Analysis-->Vulnerabilities-->Scan Jobs


                   Subject: Re: Guide: Nessus 4.0.2 on OSSIM 2.2.1 Posted by jmalbarracin on Wed, 31 Mar 2010 07:47:45 GMT View Forum Message <> Reply to Message Hi, Please TRUNCATE `vuln_nessus_settings_preferences`; TRUNCATE `vuln_settings`; Not necesary!! Thx


                   Subject: Re: Guide: Nessus 4.0.2 on OSSIM 2.2.1 Posted by fable on Wed, 31 Mar 2010 08:09:49 GMT View Forum Message <> Reply to Message hello jmalbarracin, thanx for your input, but could you briefly explain why? I merely copy-pasted those lines from DK's post, don't know much about their functionality other than they change settings in the database. fable


                   Page 104 of 123 ---- Generated from


                   OSSIM


                   by FUDforum 2.7.7


                   Subject: Re: Guide: Nessus 4.0.2 on OSSIM 2.2.1 Posted by jmalbarracin on Wed, 31 Mar 2010 08:20:34 GMT View Forum Message <> Reply to Message I know, but updateplugins.pl doesn't modify those tables. Analisys->Vulnerabilities->Settings Thx


                   Subject: Re: Guide: Nessus 4.0.2 on OSSIM 2.2.1 Posted by fable on Wed, 31 Mar 2010 08:24:59 GMT View Forum Message <> Reply to Message gotcha! I updated the guide. Thank you!


                   Subject: Re: Method to check and see what OSSEC is logging (without the web gui) Posted by link on Wed, 31 Mar 2010 10:55:57 GMT View Forum Message <> Reply to Message I see all the logs of my devices in ossec.log but when I go to check this logs in SIEM gui, I can't see all these logs. Where is the problem if ossec receive all logs correctly?


                   Subject: Re: Method to check and see what OSSEC is logging (without the web gui) Posted by juanma on Wed, 31 Mar 2010 11:01:49 GMT View Forum Message <> Reply to Message hi link, please use the  forum and open a new thread for that issue.


                   Subject: Re: Guide: Nessus 4.0.2 on OSSIM 2.2.1 Posted by whitehat on Thu, 01 Apr 2010 08:24:44 GMT View Forum Message <> Reply to Message


                   Page 105 of 123 ---- Generated from


                   OSSIM


                   by FUDforum 2.7.7


                   I've removed old nessus by running apt-get remove nessus nessusd nessus-plugins and followed your manual - and now all works great! Thank You!


                   Subject: Re: Guide: Nessus 4.0.2 on OSSIM 2.2.1 Posted by jchristmas on Mon, 05 Apr 2010 16:40:52 GMT View Forum Message <> Reply to Message Great tutorial I am going to try it out now with my server and settings but I have a few quick questions for everyone if they have time to think about it. I have a nessus system thats not a part of ossim at all... I want to use this system to scan. My environment is a bit different. I have 1 dedicated manager no sensors on it and 2 dedicated sensors no manager on them. My question is do I need to install nessus 4.x on the manager in order to use my external nessus machine? Or will the client on the nessus system work just the same to connect and pull the data over?


                   Subject: Re: Guide: Nessus 4.0.2 on OSSIM 2.2.1 Posted by jchristmas on Mon, 05 Apr 2010 16:52:40 GMT View Forum Message <> Reply to Message To answer my own question for my custom setup to get the update scripts for plugins working I needed to install at least the client for nessus 4.0.2 on my system so I uninstalled nessus nessusd etc... and installed the nessus client package from the site. Seems to be loading the plugins correctly now.


                   Subject: Re: Guide: Nessus 4.0.2 on OSSIM 2.2.1 Posted by jchristmas on Mon, 05 Apr 2010 18:47:19 GMT View Forum Message <> Reply to Message Found a minor bug in all of this or at least an issue I am having. After updating the plugins they all show they are Serious level vulnerabilities. There are 2 lows and the rest of serious... Did something fail?


                   Subject: Re: Guide: Nessus 4.0.2 on OSSIM 2.2.1 Posted by fable on Tue, 06 Apr 2010 04:48:19 GMT View Forum Message <> Reply to Message


                   Page 106 of 123 ---- Generated from


                   OSSIM


                   by FUDforum 2.7.7


                   Hello jchristmas, Thank you for your comments. I run this tutorial on a clean OSSIM 2.2.1 install and I noticed something similar to what you did. If I run a scan job and try to open the report that appears next to my scan under the "scan jobs" tab, I have a much different report from the one under the "vulnerabilities" tab. The "scan jobs" tab report though is the same as the one under the "reports" tab. The report under "vulnerabilities" tab didn't have nearly as many vulnerabilities as the one under "scan jobs" and "reports" tab, which were much more spread out (serious, high,medium,info etc). My guess is that the reports under the "scan jobs" and "reports" tabs are actually the "raw" Nessus scans with just the Alienvault logo in them. The report under "vulnerabilities" tab though, are processed by OSSIM. Over there OSSIM actually presents what vulnerabilities it thinks were present (based on the way it processes Nessus reports). What's weird though is that OSSIM is generating as many tickets as vulnerabilities found in the report under "scan jobs". Can you check to see if there are any differences on the various reports available? Also, could you run a credentiated scan towards an unpatched pc (e.g. windows xp) just so you know you will normal get a lengthy report.


                   Subject: Re: Guide: Nessus 4.0.2 on OSSIM 2.2.1 Posted by fable on Tue, 06 Apr 2010 07:27:49 GMT View Forum Message <> Reply to Message I actually just noticed that when I go to "assets-->assets" and click on the host I just scanned (OSSIM ganerates the "general report") in the "vulnerabilities" "window" OSSIM reports "No vulnerabilities found for

                   ". This is very ironic because a few windows over there is a bunch of tickets oppened that say "Vulnerability:Unknown". Could someone shed some light on why OSSIM isn't actually intergratting the NESSUS scans? Because the way I see it right now, it NESSUS is just a way to generate reports. Something that I can do by installing nessus on a windows xp machine and run the scan from there? I think the vulnerability management capability of OSSIM is very important to its general purpose as a Security Information Management System. fable




                    Page 107 of 123 ---- Generated from




                    OSSIM




                    by FUDforum 2.7.7




                    Subject: Re: Use HTTPS instead of HTTP Posted by traz on Wed, 07 Apr 2010 10:29:07 GMT View Forum Message <> Reply to Message stlist wrote on Thu, 04 March 2010 14:41Juanma, OSSIM 2.2 is out. I don't see any straightforward way to setup https for the OSSIM webpages. Could you point us to the right direction? Thanks, Sam truth




                    Subject: Re: Guide: Nessus 4.0.2 on OSSIM 2.2.1 Posted by jchristmas on Wed, 07 Apr 2010 17:28:24 GMT View Forum Message <> Reply to Message So let me clarify a few things and also say something else. I am trying to use a nessus 4 professional feed on a ubuntu box that I installed the ossim agent on. If I click in the vulnerabilities tab and select threat database I show almost all the vulnerabilities listed under critical... Tried to update the plugins again and didnt fix it. The new problem I just started to notice is that even though I updated the settings to point to the new nessus scanner it does not want to show up as an option to scan with. So I checked things out in the database and sure enough in the vuln_nessus_servers the new server isnt showing up. I could add it manually I suppose but I wanted to know where it was suppose to be added from i.e. script or web interface that inserts it into the mysql table. I am actually thinking I will rebuild all my systems soon and re-install them all virtually on each box so that I can make snapshots as well as have another group of "testing servers" that I can use before upgrading to production. But I want to make sure that before I do that everything else is in good working order. I also can't do it until roughly may due to some project obligations I have. So DK or Jamie or anyone else have any idea why its not inserting the nessus server in there and also any idea why its not doing what I am expecting? I can work with you more outside of the forums if you guys like. Thanks,




                    Subject: Re: Use HTTPS instead of HTTP Posted by portstats on Fri, 16 Apr 2010 16:02:43 GMT Page 108 of 123 ---- Generated from




                    OSSIM




                    by FUDforum 2.7.7




                    View Forum Message <> Reply to Message Any update on this ?




                    Subject: Re: OSSIM  listing Posted by manulpz on Mon, 03 May 2010 19:22:53 GMT View Forum Message <> Reply to Message I need reset de  to acces via web. but i edit the archive - ossim (/etc/ossim/framework/ossim.conf) but no take effect. the  is  by the  no can reset. thanks.




                    Subject: Re: OSSIM  listing Posted by bvand on Mon, 17 May 2010 09:36:47 GMT View Forum Message <> Reply to Message The  to access ossim web interface is not in "/etc/ossim/framework/ossim.conf" You can access the web interface by  im




                    Subject: Re: Install Oinkmaster and update snort rules Posted by bvand on Wed, 26 May 2010 15:01:11 GMT View Forum Message <> Reply to Message Hi, I tried to update snort rules with the current version of snort in OSSIM (2.8.5.2) so with the url : url = http://www.snort.org/pub-bin/oinkmaster.cgi/MY-oinkcode/snor trules-snapshot-2852.tar.gz But the file doesn't exist The url : url = http://www.snort.org/pub-bin/oinkmaster.cgi/MY-oinkcode/snor trules-snapshot-2.8.tar.gz




                    Page 109 of 123 ---- Generated from




                    OSSIM




                    by FUDforum 2.7.7




                    Doesn't work either... Can I update snort to the official version, or is it another way to update the rules ? Regards




                    Subject: ossec&asterisk Posted by jabi on Fri, 28 May 2010 09:43:15 GMT View Forum Message <> Reply to Message I've written two posts about protecting Asterisk with OSSEC. http://sysbrain.wordpress.com/2010/04/22/asterisk-ossec-part -1/ http://sysbrain.wordpress.com/2010/05/24/asterisk-ossec-part -ii/ I hope it will help you and if you see any error or improvement, tell me.




                    Subject: Re: Guide: Nessus 4.0.2 on OSSIM 2.2.1 Posted by temon on Fri, 11 Jun 2010 08:04:03 GMT View Forum Message <> Reply to Message Hello, I'm new in OSSIM and now i'm curious with OSSIM and NESSUS. I've installed Nessus 4.0.2 and yes I got same problems like any of you got there. Here's the problems : 1. Threats Database is showing Serious risk there (value == 7) 2. Cross Correlation with SNORT is not working because of some issue that i'll explain below. 3. Assets info shows no vulnerabilities there. The positive issue is scan jobs and results (at vulnerability --> scan jobs) show us actual info :) About the problems, here I try to find out why (from updateplugins.pl) : 1. Risk level value is 7 (all serious) is caused by this : if ( !defined( $plugin_crisk ) || $plugin_crisk eq "" ) { $plugin_crisk = "NULL"; } my $risk=7; $risk=1 if ($pdescription =~ m/Risk [fF]actor\s*:\s*(\\n)*Serious/s);




                    Page 110 of 123 ---- Generated from




                    OSSIM




                    by FUDforum 2.7.7




                    $risk=1 if ($pdescription =~ m/Risk [fF]actor\s*:\s*(\\n)*Critical/s); $risk=2 if ($pdescription =~ m/Risk [fF]actor\s*:\s*(\\n)*High/s); $risk=3 if ($pdescription =~ m/Risk [fF]actor\s*:\s*(\\n)*Medium/s); $risk=4 if ($pdescription =~ m/Risk [fF]actor\s*:\s*(\\n)*Medium\/Low/s); $risk=5 if ($pdescription =~ m/Risk [fF]actor\s*:\s*(\\n)*Low\/Medium/s); $risk=6 if ($pdescription =~ m/Risk [fF]actor\s*:\s*(\\n)*Low/s); $risk=7 if ($pdescription =~ m/Risk [fF]actor\s*:\s*(\\n)*Info/s); $risk=7 if ($pdescription =~ m/Risk [fF]actor\s*:\s*(\\n)*[nN]one/s); not really sure about that..but by default the risk will set to 7 if..bla bla bla..and if risk factor value is NONE then it will set to 7 :d. From another thread of openVAS, the problem looks like not happened, i'll check the scripts later (openVAS is terribly slower than NESSUS) :( 2. next..about cross correlation and customation there not working, why? Here i try to find out : mysql> select * from host_plugin_sid where plugin_id='3001'; +------------+-----------+------------+ | host_ip | plugin_id | plugin_sid | +------------+-----------+------------+ | 2886731465 | 3001 | 10114 | | 2886731465 | 3001 | 10150 | | 2886731465 | 3001 | 10287 | | 2886731465 | 3001 | 10394 | | 2886731465 | 3001 | 10395 | | 2886731465 | 3001 | 10397 | -----------------skip------------------178 rows in set (0.00 sec) Here's the place where NESSUS store IP and its Vulnerabilities (from scanning result). mysql> select * from plugin_sid where plugin_id='3001'; +-----------+-------+-------------+----------+-------------+----------+-----------------------------------------------------------------------+--------+ | plugin_id | sid | category_id | class_id | reliability | priority | name | aro | +-----------+-------+-------------+----------+-------------+----------+-----------------------------------------------------------------------+--------+ | 3001 | 10048 | NULL | NULL | 2| 7 | nessus: CommuniGate Pro HTTP Configuration Port Remote Overflow | 0.0000 | | 3001 | 11351 | NULL | NULL | 2| 7 | nessus: Sendmail < 8.10.0 mail.local Newline Handling Remote DoS | 0.0000 | | 3001 | 11458 | NULL | NULL | 2| 7 | nessus: SMB Registry : Dial In Enabled | 0.0000 | | 3001 | 11606 | NULL | NULL | 2| 7 | nessus: WebLogic Crafted GET Request Hostname Disclosure | 0.0000 | | 3001 | 14446 | NULL | NULL | 2| 7 | nessus: [GLSA-200402-02] XFree86




                    Page 111 of 123 ---- Generated from




                    OSSIM




                    by FUDforum 2.7.7




                    Font Information File Buffer Overflow | 0.0000 | | 3001 | 16468 | NULL | NULL | 2| 7 | nessus: Sami HTTP Server Multiple Remote Vulnerabilities | 0.0000 | | 3001 | 29898 | NULL | NULL | 2| 7 | nessus: Novell Client nicm.sys Local Privilege Escalation | 0.0000 | | 3001 | 35388 | NULL | NULL | 2| 7 | nessus: Fedora 9 2009-0059: xterm | 0.0000 | | 3001 | 35391 | NULL | NULL | 2| 7 | nessus: Fedora 8 2009-0154: xterm | 0.0000 | | 3001 | 36641 | NULL | NULL | 2| 7 | nessus: Fedora 10 2009-0091: xterm | 0.0000 | | 3001 | 42468 | NULL | NULL | 2| 7 | nessus: CUPS < 1.4.2 kerberos Parameter XSS | 0.0000 | +-----------+-------+-------------+----------+-------------+----------+-----------------------------------------------------------------------+--------+ 11 rows in set (0.00 sec)




                    mine just showing 11 results there..hehehe..and still don't know why..if we trace back from update_nessus_ids.pl :




                    --snip-$query = "INSERT INTO plugin_sid(plugin_id, sid, category_id, class_id, reliability, priority, name) VALUES "; if(keys %plugin_rel_hash){ print "Updating...\n"; foreach $key (keys %plugin_rel_hash){ print "$key:$plugin_rel_hash{$key}:$plugin_prio_hash{$key}\n"; #$plugin_rel_hash{$key} =~ s/'/''/; $plugin_rel_hash{$key} =~ s/'/\\'/gs; $plugin_rel_hash{$key} =~ s/"/\\"/gs; my $sid = $key; if ($key =~ /\./){ my @tmp = split(/\./, $key); $sid = $tmp[$#tmp]; } $query .= "(3001, $sid, NULL, NULL, $plugin_prio_hash{$key}, 7, 'nessus: $plugin_rel_hash{$key}'),"; }




                    Page 112 of 123 ---- Generated from




                    OSSIM




                    by FUDforum 2.7.7




                    --snip--




                    it must be load data from somewhere, process, then insert to this table :( Next about 'plugin_reference' table (used for correlate with another plugins by default) : mysql> select * from plugin_reference where reference_id='3001'; +-----------+------------+--------------+---------------+ | plugin_id | plugin_sid | reference_id | reference_sid | +-----------+------------+--------------+---------------+ | 1001 | 103 | 3001 | 10024 | | 1001 | 103 | 3001 | 10409 | | 1001 | 107 | 3001 | 10024 | | 1001 | 107 | 3001 | 10409 | ------------------------skip----------------------------7294 rows in set (0.05 sec)




                    Another tables which need to be checked is 'vuln_nessus_plugins' that shows complete information of those plugins: mysql> select count(*) from vuln_nessus_plugins; +----------+ | count(*) | +----------+ | 35979 | +----------+ 1 row in set (0.00 sec)




                    Now we try to manually correlate both of them :) 1. We try to find out one result (nessus plugin sid) from scanning activity : mysql> select inet_ntoa('2886731465'); +-------------------------+ | inet_ntoa('2886731465') | +-------------------------+ | 172.16.6.201 | +-------------------------+ 1 row in set (0.00 sec) mysql> select * from host_plugin_sid where plugin_id='3001' and host_ip='2886731465' limit 1,5;




                    Page 113 of 123 ---- Generated from




                    OSSIM




                    by FUDforum 2.7.7




                    +------------+-----------+------------+ | host_ip | plugin_id | plugin_sid | +------------+-----------+------------+ | 2886731465 | 3001 | 10150 | | 2886731465 | 3001 | 10287 | | 2886731465 | 3001 | 10394 | | 2886731465 | 3001 | 10395 | | 2886731465 | 3001 | 10397 | +------------+-----------+------------+ 5 rows in set (0.00 sec) mysql> select id,name from vuln_nessus_plugins where id='10150'; +-------+----------------------------------------------------------+ | id | name | +-------+----------------------------------------------------------+ | 10150 | Windows NetBIOS / SMB Remote Host Information Disclosure | +-------+----------------------------------------------------------+ 1 row in set (0.00 sec) mysql> select id,name from vuln_nessus_plugins where id='10287'; +-------+------------------------+ | id | name | +-------+------------------------+ | 10287 | Traceroute Information | +-------+------------------------+ 1 row in set (0.01 sec) mysql> select id,name from vuln_nessus_plugins where id='10394'; +-------+---------------------+ | id | name | +-------+---------------------+ | 10394 | SMB  Possible | +-------+---------------------+ 1 row in set (0.02 sec) mysql> select id,name from vuln_nessus_plugins where id='10395'; +-------+------------------------+ | id | name | +-------+------------------------+ | 10395 | SMB Shares Enumeration | +-------+------------------------+ 1 row in set (0.01 sec) mysql> select id,name from vuln_nessus_plugins where id='10397'; +-------+-------------------------------------------+ | id | name |




                    Page 114 of 123 ---- Generated from




                    OSSIM




                    by FUDforum 2.7.7




                    +-------+-------------------------------------------+ | 10397 | SMB LanMan Pipe Server Listing Disclosure | +-------+-------------------------------------------+ 1 row in set (0.01 sec) mysql> select id,name,description from vuln_nessus_plugins where id='10150'; +-------+----------------------------------------------------------+-------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+ | id | name | description | +-------+----------------------------------------------------------+-------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+ | 10150 | Windows NetBIOS / SMB Remote Host Information Disclosure | ;Synopsis :;;It is possible to obtain the network name of the remote host.;;Description :;;The remote host listens on UDP port 137 or T port 445 and replies to ;NetBIOS nbtscan or SMB requests.;;Note that this plugin gathers information to be used in other vuln_plugins;but does not itself generate a report.;;Solution :;;n/a;;Risk factor :;;None;; | +-------+----------------------------------------------------------+-------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+ 1 row in set (0.00 sec) mysql> enough for the first part, i try to lookup the vulnerability information from 'host_plugin_sid' then try to find out what is the vulnerability shown there (show by plugin_sid) at 'vuln_nessus_plugins' in 'id' field. next try to find out the plugin_sid at correlation tables (plugin_reference and plugin_sid) : mysql> select * from host_plugin_sid where plugin_id='3001' and host_ip='2886731465' limit 1,5; +------------+-----------+------------+ | host_ip | plugin_id | plugin_sid | +------------+-----------+------------+ | 2886731465 | 3001 | 10150 | | 2886731465 | 3001 | 10287 | | 2886731465 | 3001 | 10394 | | 2886731465 | 3001 | 10395 | | 2886731465 | 3001 | 10397 |




                    Page 115 of 123 ---- Generated from




                    OSSIM




                    by FUDforum 2.7.7




                    +------------+-----------+------------+ 5 rows in set (0.00 sec) mysql> select * from plugin_reference where reference_sid='10150'; Empty set (0.00 sec) mysql> select * from plugin_reference where reference_sid='10287'; Empty set (0.00 sec) mysql> select * from plugin_reference where reference_sid='10394'; Empty set (0.01 sec) mysql> select * from plugin_reference where reference_sid='10395'; Empty set (0.01 sec) mysql> select * from plugin_reference where reference_sid='10397'; Empty set (0.01 sec)




                    can't find the correlation between snort and nessus sid there, so i have to customize/define/create it first :p need to check another table : mysql> select * from host_plugin_sid where plugin_id='3001' and host_ip='2886731465' limit 1,5; +------------+-----------+------------+ | host_ip | plugin_id | plugin_sid | +------------+-----------+------------+ | 2886731465 | 3001 | 10150 | | 2886731465 | 3001 | 10287 | | 2886731465 | 3001 | 10394 | | 2886731465 | 3001 | 10395 | | 2886731465 | 3001 | 10397 | +------------+-----------+------------+ 5 rows in set (0.00 sec) mysql> select * from plugin_reference where reference_sid='10150'; Empty set (0.00 sec) mysql> select * from plugin_reference where reference_sid='10287'; Empty set (0.00 sec) mysql> select * from plugin_reference where reference_sid='10394'; Empty set (0.01 sec) mysql> select * from plugin_reference where reference_sid='10395'; Empty set (0.01 sec)




                    Page 116 of 123 ---- Generated from




                    OSSIM




                    by FUDforum 2.7.7




                    mysql> select * from plugin_reference where reference_sid='10397'; Empty set (0.01 sec)




                    see, just like what i've said at first..in this table, i just got 11 (eleven) entries, so i can do nothing except manually insert reference from vuln_nessus_plugins to this plugin_sid :( (which should've be done by script "update_nessus_ids.pl". Any info from developers? Oh I forgot, I also realized about the "alienvault_feed_sync.sh" script, have tried it but failed. Looks like alienvault rsync server is now down. siem:/usr/share/ossim/scripts/vulnmeter# ../alienvault-feed-sync.sh nessus AlienVault NVT Feed Sync Configured Scanner: nessus Configured NVT Feed: rsync://feed.alienvault.com:/nvt-feed Synchronized into: /opt/nessus/lib/nessus/plugins/




                    Searching for required system tools ... Synchonizing NVTs via RSYNC ... rsync: failed to connect to feed.alienvault.com: Connection refused (111) rsync error: error in socket IO (code 10) at clientserver.c(122) [receiver=3.0.3] Error: rsync failed. Your NVT collection might be broken now. siem:/usr/share/ossim/scripts/vulnmeter# cat /etc/services | grep rsync rsync873/t rsync873/udp siem:/usr/share/ossim/scripts/vulnmeter# telnet feed.alienvault.com rsync Trying 207.158.15.208... telnet: Unable to connect to remote host: Connection refused siem:/usr/share/ossim/scripts/vulnmeter# telnet feed.alienvault.com 873 Trying 207.158.15.208... telnet: Unable to connect to remote host: Connection refused siem:/usr/share/ossim/scripts/vulnmeter# Any advance? Thank you before :)




                    Subject: Re: Guide: Nessus 4.0.2 on OSSIM 2.2.1 Page 117 of 123 ---- Generated from




                    OSSIM




                    by FUDforum 2.7.7




                    Posted by temon on Fri, 18 Jun 2010 04:48:08 GMT View Forum Message <> Reply to Message just want to update after waiting for several days and got no reply here, so i tried to find out the problems and now it's all fixed..next step is to make sure that snort <-> nessus correlation will work :d 1. Analysis --> Vulnerabilities --> Threats Database Problem, all vulnerabilities/plugins have 'serious' risk factor. 2. Intelligence --> Cross Correlation --> Correlation Rules, nessus plugins not loaded/inserted well into ossim.plugin_sid table in database. Here the new scripts to fix the problems (rename it to .pl, run updateplugins.pl first then update_nessus_ids.pl): 1. http://temon.banget.de/ossim/updateplugins.txt 2. http://temon.banget.de/ossim/update_nessus_ids.txt




                    thx to fabe for update_nessus_ids.pl patch :) Toggle Spoiler https://www.alienvault.com/forum/index.php?t=msg&S=739e3 1dbae2442b0334ec6e41e5d8d3e&th=1973&goto=6712#msg_67 12




                    Subject: Re: Guide: Nessus 4.0.2 on OSSIM 2.2.1 Posted by whitehat on Fri, 18 Jun 2010 10:13:37 GMT View Forum Message <> Reply to Message temon wrote on Fri, 18 June 2010 07:48 1. http://temon.banget.de/ossim/updateplugins.txt 2. http://temon.banget.de/ossim/update_nessus_ids.txt




                    Can You please  theese files to another server? Or to this forum?




                    Page 118 of 123 ---- Generated from




                    OSSIM




                    by FUDforum 2.7.7




                    Subject: Re: Guide: Nessus 4.0.2 on OSSIM 2.2.1 Posted by temon on Fri, 18 Jun 2010 12:28:32 GMT View Forum Message <> Reply to Message try to attach those files here... :d




                    File Attachments 1) ossim_nessus_dbupdate.tar.gz, ed 36 times




                    Subject: Re: OSSEC Quick Start Guide Posted by Lorax on Fri, 18 Jun 2010 12:59:44 GMT View Forum Message <> Reply to Message Look inside ossec.conf in /var/ossec/etc/ and edit the server IP at the top:


                     <server-ip>10.1.1.8
                     <syscheck>

                     79200





                     Subject: OSSIM integration with an existing OCS Inventory install Posted by westie5017 on Mon, 21 Jun 2010 16:37:05 GMT View Forum Message <> Reply to Message Good Afternoon, I hope you are well. We have an existing OCS Inventory install that has data on all of our existing assets. It is also integrated with our CMDB System (CMDBuild) and ITSM system. I'm wanting to deploy an OSSIM server (initially in a development lab) so I can test the system and prepare it for a production environment. Is it possible to integrate OSSIM with an existing OCS Inventory installation? Be it via an API, Database synchronisation or by simply point the OSSIM to the existing build?




                     Page 119 of 123 ---- Generated from




                     OSSIM




                     by FUDforum 2.7.7




                     Any assistance would be greatly appreciated...as I'm keen to demonstrate the ROI on this system and get the project off the ground. Kind Regards




                     Harry West




                     Subject: Re: Guide: Nessus 4.0.2 on OSSIM 2.2.1 Posted by bcarty on Tue, 22 Jun 2010 20:15:28 GMT View Forum Message <> Reply to Message I can not connect to port 1241 with both OSSIM and the Nessus Client (for giggles) which led me to do the google. Here is a link to the forum I found it in. The thread started back in December of 2009 https://discussions.nessus.org/message/4293#4293 Thoughts?




                     Subject: Re: Guide: Nessus 4.0.2 on OSSIM 2.2.1 Posted by temon on Fri, 25 Jun 2010 04:08:21 GMT View Forum Message <> Reply to Message have you checked that nessus is running and port 1241 is opened? 1241 is NTP that used to communicate between nessus-client and nessus-scanner (server). netstat -plant | grep nessus ps ax | grep nessus if port 1241 opened, then try to connect to port 1241 using telnet from another machine telnet machine-running-nessus-server 1241 if you get connection refused, try to flush iptables first iptables -F ; iptables -X try to telnet again, if you get escape character is ^] means you've successfully connected and try to connect using nessus-client again. Don't forget to allow port 1241 on ossim-firewall. NOTE : Nessus 4.2 is not  NTP (port 1241) for homefeed, only professional feed




                     Page 120 of 123 ---- Generated from




                     OSSIM




                     by FUDforum 2.7.7




                      NTP, that's why in here we use nessus 4.0 for our env ;)




                     Subject: Re: OSSIM integration with an existing OCS Inventory install Posted by NicoArias on Tue, 29 Jun 2010 16:37:57 GMT View Forum Message <> Reply to Message you should edit these 2 files in order to use the already populated database: /etc/apache2/conf.d/ocsinventory.conf /usr/share/ossim/www/ocsreports/dbconfig.inc.php




                     Subject: Re: OSSIM  listing Posted by mattspierce on Wed, 30 Jun 2010 14:23:19 GMT View Forum Message <> Reply to Message I've locked myself out of the  interface for the website. Modifying the tomcat s file doesn't do anything to help as the  there is set to :. From the tutorial I figured the  is stored in the ossim.s table and sure enough I see the string. I'v tried nulling that value to get back in but no such luck. I'm guessing that the salt is being applied to the null value. Is there anyway to determine what the salt is? Better yet, is there a way to reset the web  ? What I did: logged into mysql mysql -p used  extracted via the first post. use ossim; update s set =NULL where =''; *Another thread pointed out the fix* update s set ='21232f297a57a5a743894a0e4a801fc3' where ='' This sets the  back to :




                     Subject: Re: Use HTTPS instead of HTTP Posted by nhirst100 on Fri, 02 Jul 2010 22:11:35 GMT View Forum Message <> Reply to Message




                     Page 121 of 123 ---- Generated from




                     OSSIM




                     by FUDforum 2.7.7




                     This has not worked for me. I followed the steps listed above and then when I try to connect to the server over https I receive the following error in firefox (Error code: ssl_error_rx_record_too_long) I am running OSSIM 2.2.1 TIA, Nathan




                     Subject: Re: Installing the OSSEC Web Interface on OSSIM Posted by aimar on Wed, 07 Jul 2010 10:39:44 GMT View Forum Message <> Reply to Message hidoa wrote on Fri, 13 February 2009 23:03I followed the instructions and I get the error below when I try to browse to the site.... My step 5 was ossec:x:113:www-data not ossec:x:1002:www-data. Not sure if that matters or not... Warning: opendir(/var/ossec) [function.opendir]: failed to open dir: Permission denied in /var/www/ossec-wui/lib/os_lib_handle.php on line 94 Unable to access ossec directory.




                     Then do the following: # nano /etc/group .. From: ossec:x:109: To: ossec:x:109:www-data




                     Worked for me :p (OSSIM 2.2.4)




                     Subject: Re: Osiris - Quick Guide Posted by aimar on Thu, 08 Jul 2010 10:06:03 GMT View Forum Message <> Reply to Message With my OSSIM 2.2, I needed to run the following command before playing around with osiris:




                     Page 122 of 123 ---- Generated from




                     OSSIM




                     by FUDforum 2.7.7




                     apt-get install osiris osirismd Otherwise, very nice tutorial, cheers ;)




                     Subject: Re: Use HTTPS instead of HTTP Posted by nhirst100 on Mon, 19 Jul 2010 18:35:19 GMT View Forum Message <> Reply to Message It looks like this can be done in version 2.2.1 by running a2ensite default-ssl a2dissite default /etc/init.d/apache2 reload




                     Page 123 of 123 ---- Generated from




                     OSSIM




                     by FUDforum 2.7.7

Ossec 6t1q

Overview 3e4r5l

More details w3441

Related Documents 3m3m1z

Ossec 6t1q

More Documents from "Srinivasarao Kasi" 254s69

Ossec 6t1q

Go.ms.no= 93---general Transfers 3zm17

Vii_telugu Ccemodel Lesson Plan Stu Kurnool.pdf q1f6s

Clusters List-(chncs) ======go-209 5m4645

Movie List 4b144

Cas Provisional Seniority List (24.02.2010) 1f1119
