The 5-Minute PBX: It’s Incredible PBX 11 Virtual Machine for VirtualBox In our last article, we introduced the PBX in a Flash Virtual Machine for Oracle’s VirtualBox. To commemorate the end of the world today, we wanted to go out with a bang. So we’re pleased to introduce Incredible PBX 11 Virtual Machine. As with the PIAF-Green Virtual Machine, this new appliance features CentOS 6.3, Asterisk® 11, and FreePBX® 2.11 beta. In addition, it includes Incredible Fax with HylaFax and AvantFax, SMS speechto-text messaging as well as SMS message blasting with Google Voice, and several dozen turnkey Asterisk applications including a speech-to-text phonebook dialer, text-to-speech news, weather, tide, and stock reports, a conference bridge for MeetMe conferencing, NeoRouter and PPTP VPN , SAMBA for Windows Networking, ODBC database integration, Telephone Reminders and Hotel-Style Wakeup Calls, CallerID Superfecta, PBX End Point Manager, and Wolfram Alpha to name but a few. With the addition of free Google Voice s, you still get free voice and fax calling throughout the United States and Canada. And, yes, Incredible PBX 11 still installs and is ready to go in under 5 minutes on any Windows, Mac, Linux, or Solaris desktop.

The Ultimate VoIP Appliance: Incredible PBX 11 Virtual Machine for VirtualBox

Machine for VirtualBox We broke new ground in the virtual machine development arena last week with the introduction of the PIAF Virtual Machine. Today we take it to the next plateau with a turnkey VoIP appliance that can be deployed and functional in less time than it takes you to shave. Today’s Incredible PBX Virtual Machine still gives you everything a bare metal install from source code would have provided. And, most importantly, the components are truly portable. They can be copied to a 4GB flash drive1 for the price of a good hamburger and installed from there onto any type of machine that happens to be in front of you. Five minutes later, you have a fully functional Asterisk server with FreePBX and exactly the same feature set and source code that you would have had installing Incredible PBX onto a dedicated server. Before you ask any questions, we urge you to try this VoIP appliance for yourself. The install process is as easy as 1-2-3: 1. and install VirtualBox onto a Desktop Machine of your choice 2. and double-click on Incredible PBX 11 Virtual Machine to import it into VirtualBox 3. Select the Incredible PBX 11 Virtual Machine in VirtualBox Manager Window and click the Start button

Introducing Oracle VM VirtualBox

Here’s a quick review if you missed our last article. VirtualBox®, Oracle’s virtual machine platform inherited from Sun, is really something. It’s not only free, but it’s pure GPL2 code. VirtualBox gives you a virtual machine platform that runs on top of any desktop operating system. In of limitations, we haven’t found any. We even tested this on an Atom-based Windows 7 machine with 2GB of RAM, and it worked without a hiccup. So step #1 is to one or more of the VirtualBox installers from VirtualBox.org or Oracle.com. As mentioned, our recommendation is to put all of the 100MB installers on a 4GB thumb drive. Then you’ll have

everything in one place whenever and wherever you happen to need it. Once you’ve ed the software, simply install it onto your favorite desktop machine. Accept all of the default settings, and you’ll be good to go. For details, here’s a link to Oracle’s VM VirtualBox Manual.

Introducing Incredible PBX Virtual Machine To get Incredible PBX VM installed on your desktop is quick and easy. Because the image tips the scales at over 2GB and due to the 2GB file size limit on many systems, we’ve chosen to split this into two pieces. You need both of them. Just them onto any flavor desktop from SourceForge. Once you’ve ed the two files, reassemble them into a single file known as an Open Virtualization Appliance (.ova). Then the checksums for the reassembled file to be sure everything is in its proper place. Finally, doubleclick on the .ova file which will initiate the import process into VirtualBox. So let’s begin by ing the two halves from SourceForge: INCREDIBLEPBX11aa and INCREDIBLEPBX11ab. The reassembly procedure depends upon your desktop operating system. For Windows PCs, you’ll need to drop down to the Command Prompt, change to the directory in which you ed the two files, and type the following command: copy /b INCREDIBLEPBX11aa + INCREDIBLEPBX11ab IncrediblePBX11.ova

To check the MD5/SHA1 checksums in Windows, and run Microsoft’s File Checksum Integrity Verifier. For Mac or Linux desktops, open a Terminal window, change to the directory in which you ed the two files, and type the following commands: cat INCREDIBLEPBX11a{a..b} > IncrediblePBX11.ova md5 IncrediblePBX11.ova (use md5sum for Linux) openssl sha1 IncrediblePBX11.ova

The MD5 checksum for IncrediblePBX11.ova is b095cc910c22c0f8cab089e0bdc97e18. The SHA1 checksum is c9a5b834992b9527aa3994eab8d7559ae612705a. If you have a match, proceed. Otherwise, rinse and repeat.

Importing Incredible PBX 11 Virtual Machine into VirtualBox You only perform the import step one time. Once imported into VirtualBox, Incredible PBX is ready to use. There’s no further installation required, just like an OpenVZ template… only better. Double-click on the .ova file you ed to begin the procedure and load VirtualBox. When prompted, be sure to check the Reinitialize the Mac address of all network cards box. Read and accept the license agreement. Then click the Import button. Once the import is finished, you’ll see a new IncrediblePBX11 virtual machine in your VM List on the VirtualBox Manager Window. You need to make a couple of one-time adjustments to the IncrediblePBX11 Virtual Machine configuration to for differences in sound and network cards on different host machines.

Click on IncrediblePBX11 Virtual Machine in the VM List. Then click Settings -> Audio and check the Enable Audio option and choose your sound card. Save your setup by clicking the OK button. Next click Settings -> Network. For Adapter 1, check the Enable Network Adapter option. From the Attached to pull-down menu, choose Bridged Adapter. Then select your network card from the Name list. Then click OK to save your setup. Finally, click Settings -> System, uncheck Hardware clock in UTC time, and click OK. That’s all the configuration that is necessary for Incredible PBX Virtual Machine. If you blinked, you probably missed it.

Running Incredible PBX Virtual Machine in VirtualBox Once you’ve imported and configured Incredible PBX Virtual Machine, you’re ready to go. Highlight the appliance in the VM List on the VirtualBox Manager Window and click the Start button. The boot procedure with CentOS 6.3 will begin just as if you had installed PBX in a Flash and Incredible PBX on a standalone machine. You’ll see a couple of dialogue boxes pop up that explain the keystrokes to move back and forth between your host operating system desktop and Incredible PBX.

Here’s what you need to know. To work in the Incredible PBX Virtual Machine, just left-click your mouse while it is positioned inside the VM window. To return to your host operating system desktop, press the right Option key on Windows machines or the left Command key on any Mac. For other operating systems, read the dialogue boxes for instructions on moving around. Always shut down Incredible PBX gracefully! Click in the VM window with your mouse, as root, and type: shutdown -h now. Or, from the VirtualBox Manager Window, Ctl-Click on the IncrediblePBX11 VM and choose Close -> AI Shutdown. Always run Incredible PBX VM behind a hardware-based firewall with no Internet port exposure! Linux CLI Setup. To begin, position your mouse over the VM window and left-click. Once the virtual machine has booted, as root with as the . Change your root immediately by typing wd at the command prompt. Now set up a secure maint for FreePBX as well. Type wdmaster. If you’re not in the Eastern U.S. time zone, then you’ll want to adjust your timezone setting so that reminders and other time-sensitive events happen at the correct time. Issue the following command to pick your time zone: /root/timezone-setup. If you plan to use Incredible Fax to send and receive faxes, set an email address for delivery of incoming faxes: /root/incrediblefax-setup. To use SMS messaging in Incredible PBX, you’ll need a Google Voice which is covered below. Once you have your credentials, edit extensions_custom.conf in /etc/asterisk and insert your name and in the 767 extension. To use SAMBA for Windows networking, replace the Interfaces IP address in /etc/samba/smb.conf with your actual IP address. Next, run smbwd and assign a for root access to your server. Then restart SAMBA: service smb restart.

FreePBX Setup. Use a browser to to your Incredible PBX server by pointing to the IP address of the virtual machine displayed in the status window of the CLI. Click on the button to display the choices in the Main PIAF Menu. Click on the FreePBX option to load the FreePBX GUI. You will be prompted for a name and . For the name, use maint. For the , use whatever you set up with wd-master above. You’ll want to keep FreePBX up to date. The easiest way is to configure FreePBX for email notifications when there are updates. In the FreePBX GUI, choose -> Module -> Upgrade Notifications and plug in your email address. Updates are installed in this same window. Click Check Online -> Upgrade All -> Process and Confirm. Scroll to the bottom of the Status window and click Return. Then click Apply Config. Now you try it. GOOGLE VOICE ALERT: For old-timers that used the previous Google Voice module in FreePBX 2.x, it’s a little different in FreePBX 2.11. It now is called Google Voice (Motif), and you’ll find it under the Connectivity tab instead of the Other tab. More importantly, the form has changed. Do NOT check all 3 checkboxes as you did previously, or your incoming calls won’t be answered. Leave last checkbox “Send Unanswered to GoogleVoice Voicemail” UNCHECKED!! Incredible PBX s SIP, IAX, and Google Voice trunks to handle your outbound and incoming calls. The easiest way to get started it to set up a couple of Google Voice trunks, one for voice calls and one for faxing. These trunks must be dedicated for exclusive use with Incredible PBX. If you’re logged into these Google Voice s elsewhere, Incredible PBX won’t receive incoming calls. Read our Incredible PBX Quick Start Guide for the procedure to for new Google Voice s. Once you have your credentials and phone numbers, choose Connectivity -> Google Voice in FreePBX to set up the s in FreePBX. For each trunk, you also need to set up an Inbound Route to tell FreePBX how to route the incoming calls. For your Fax trunk, here’s the drill. Choose Connectivity -> Inbound Routes. Insert your 10-digit Google Voice number in the DID Number field. Check Enable CID Superfecta and, for Set Destination, choose Custom Destinations -> Fax (HylaFax). Click Submit and then click Apply Config. Before your Google Voice trunks will work reliably, there are two final steps. First, restart Asterisk from the Linux CLI: amportal restart. Then, make at least one outbound call using each Google Voice trunk. We’ve preconfigured SIP trunks for all of the major VoIP providers in Incredible PBX. All you have to do is sign up for a few s. This isn’t like the old Ma Bell days so take advantage of the redundancy that using multiple VoIP providers gives you. There’s a very special offer from one of the major sponsors of the PBX in a Flash and Nerd Vittles projects below. Take advantage of it and our open source projects. Update: We’ve just released Incredible PBX 11.1 which includes Asterisk 11.1.0 and the latest FreePBX 2.11 beta. It also includes several bug fixes as well as an automatic update utility. You can read all about it in the ree file on SourceForge. Enjoy! Now read the latest Incredible PBX Quick Start Guide and begin your VoIP adventure. Then you’ll want to do some reading on VirtualBox. We’ve barely scratched the surface. Setting up Headless VMs that run in the background on any server is a breeze. From the command line, here’s an article to get you started. But you also can start Headless VMs from within the GUI by highlighting the VM and clicking Shift->Start. : Always shut down VMs gracefully: Close->AI Shutdown. You’ll find more great tips at virtualbox.org and GitHub.

One of the real beauties of VirtualBox is you don’t have to use a GUI at all. The entire process can be driven from the command line. Other than on a Mac, here is the procedure to import, configure, and run Incredible PBX 11 Virtual Machine: VBoxManage import IncrediblePBX11.ova VBoxManage modifyvm "IncrediblePBX11" --nic1 nat VBoxManage modifyvm "IncrediblePBX11" --ai on --nic1 bridged VBoxHeadless --startvm "IncrediblePBX11" & # Wait 1 minute for IncrediblePBX11 to load. Then decipher IP address like this: VBoxManage guestproperty get "IncrediblePBX11" /VirtualBox/GuestInfo/Net/0/V4/IP # Now you can use SSH to to IncrediblePBX11 at the displayed IP address # Shutdown the IncrediblePBX11 Virtual Machine with the following command: VBoxManage controlvm "IncrediblePBX11" aipowerbutton

On a Mac, everything works the same way except for deciphering the IP address. our findip script for that. Have a very Merry Christmas! Tw eet

Originally published: Friday, December 21, 2012 Updated: Saturday, December 22, 2012
