Parrot Ck3100 Lcd Bluetooth Flash How To Revision A v66f

Parrot CK3100 LCD Bluetooth Flash How-to j System Requirements Windows XP WIDCOMM Bluetooth Internet connection Parrot Flash Update Wizard ( from www.parrot.biz and install) Vehicle and PC must be within Bluetooth range for Class II devices (30 feet) Getting Started On the Parrot product - CK3100 LCD Menu

Check current Firmware Revision: Settings>Information – Record installed version --------------------------------------------------------------------------------------------------------------------------------On the Parrot web site, get information on the current version: Go to: www.parrot.biz/usa/ Select CK3100 link:

Compare installed vs. current version

If current software is newer than your installed version and there are compatibility problems with the s phone then proceed with update. --------------------------------------------------------------------------------------------------------------------------------Back to the CK3100 LCD Menu: Enable Software Update: Settings>Advanced Settings>Software Update>Activated

JD Whitaker Parrot Inc. Revision A

Page 1

7/19/2006

Parrot CK3100 LCD Bluetooth Flash How-to Flash Binary On the PC - Go to Start

Open Parrot Flash Update Wizard (Look under All Programs if not pinned to Start Menu)

Select

JD Whitaker Parrot Inc. Revision A

Page 2

7/19/2006

Parrot CK3100 LCD Bluetooth Flash How-to Select product (Selection must match the product you are flashing)

Select NOTE: You do not need to enter anything in the File Location window

JD Whitaker Parrot Inc. Revision A

Page 3

7/19/2006

Parrot CK3100 LCD Bluetooth Flash How-to Note Warning and select

Make phone and language selections as required NOTE: Not all products require phone selection Then Select

JD Whitaker Parrot Inc. Revision A

Page 4

7/19/2006

Parrot CK3100 LCD Bluetooth Flash How-to Wait for to complete

When OK appears - Select

JD Whitaker Parrot Inc. Revision A

Page 5

7/19/2006

Parrot CK3100 LCD Bluetooth Flash How-to Select

then

STOP here! Bluetooth connection steps follow

NOTE: At this point, laptops can be removed from the network and moved to the vehicle. If using a Desktop PC, move the vehicle within 30 feet Getting Connected Go to Start

Open My Bluetooth Places

JD Whitaker Parrot Inc. Revision A

Page 6

7/19/2006

Parrot CK3100 LCD Bluetooth Flash How-to Start Bluetooth Setup Wizard

IMPORTANT NOTE: The virtual Bluetooth serial port shortcut you are about to create is unique to the paired car kit – It should not be saved after the update is complete - Right click and delete the UPDATE icon before attempting to update other kits. Activating multiple shortcuts assigned to the same serial port or re-pairing other car kits to existing shortcuts can corrupt My Bluetooth Places and the Windows Registry. When in doubt – Delete the shortcut and start over! If you get the following or a similar error message:

Your Bluetooth radio is not plugged in or may be turned off.

JD Whitaker Parrot Inc. Revision A

Page 7

7/19/2006

Parrot CK3100 LCD Bluetooth Flash How-to Select the highlighted option:

JD Whitaker Parrot Inc. Revision A

Page 8

7/19/2006

Parrot CK3100 LCD Bluetooth Flash How-to When Search completes - Select your Parrot product and

JD Whitaker Parrot Inc. Revision A

Page 9

7/19/2006

Parrot CK3100 LCD Bluetooth Flash How-to Enter PIN Code 1234 and NOTE: If the search completes and the product is not shown select

NOTE: If pairing fails, back up to Device Selection and try again

JD Whitaker Parrot Inc. Revision A

Page 10

7/19/2006

Parrot CK3100 LCD Bluetooth Flash How-to Select UPDATE

JD Whitaker Parrot Inc. Revision A

Page 11

7/19/2006

Parrot CK3100 LCD Bluetooth Flash How-to A Bluetooth Properties window automatically will open - Select

JD Whitaker Parrot Inc. Revision A

Page 12

7/19/2006

Parrot CK3100 LCD Bluetooth Flash How-to Select

JD Whitaker Parrot Inc. Revision A

Page 13

7/19/2006

Parrot CK3100 LCD Bluetooth Flash How-to In the My Bluetooth Places window, Double Click on the UPDATE Icon

Observe “Connecting” status message:

Record COM port number for reference in following steps

NOTE: COM Port assignments vary between computers – Your number may be different

JD Whitaker Parrot Inc. Revision A

Page 14

7/19/2006

Parrot CK3100 LCD Bluetooth Flash How-to Right click on the UPDATE icon and select STATUS

Bluetooth Connection Status – Signal Strength should be in the Good range

WARNING: Do not proceed if the Signal Strength is in the Too Weak area Select

JD Whitaker Parrot Inc. Revision A

Page 15

7/19/2006

Parrot CK3100 LCD Bluetooth Flash How-to Reopen Parrot Flash Update Wizard

In the Taskbar, Select Select COM Port noted above and then Select NOTE: Your COM Port number may be different than shown

JD Whitaker Parrot Inc. Revision A

Page 16

7/19/2006

Parrot CK3100 LCD Bluetooth Flash How-to Select

JD Whitaker Parrot Inc. Revision A

on the Connection pop-up – The Update Port is connected

Page 17

7/19/2006

Parrot CK3100 LCD Bluetooth Flash How-to Wait for Software Update to complete

Wait for Flash Update Successful window to appear Here, you can select or . If you select Flash Another Kit, all settings are saved except for the COM port selection – Network access is not required – Don’t forget to delete the UPDATE icon in MY Bluetooth Places and create a new one for the next kit.

JD Whitaker Parrot Inc. Revision A

Page 18

7/19/2006

Parrot CK3100 LCD Bluetooth Flash How-to NOTE: If power or Bluetooth link is interrupted, unit may require re-flash with a Parrot Serial Flash Cable connected to PC

Thank you for choosing Parrot.

James (JD) Whitaker Director, Technical Marketing Parrot Inc. [email protected] www.parrot.biz
