Pds Hempadur Glass Flake 35851 En-gb 216d1n

Product Data HEMPADUR GF 35851 High temperatures 35851 : BASE 35858 : CURING AGENT 97652 Description:

HEMPADUR GLASS FLAKE 35851 is a two-component, high solids, glass flake pigmented polyamide/ amine cured epoxy paint with good wetting properties and low water permeability. It is selfpriming and forms a hard and tough coating which has good resistance against abrasion and impact as well as to seawater, mineral oils, aliphatic hydrocarbons and splashes from petrol, jet fuel, lubrication oil and related products.

Recommended use:

As a coating for steel exposed to abrasion and/or severe corrosive environment.

Service temperature:

Maximum, dry exposure only: 140°C/284°F see REMARKS overleaf In seawater (no temperature gradient): 50°C/122°F Other liquids: HEMPEL

Availability:

Part of Group Assortment. Local availability subject to confirmation.

PHYSICAL CONSTANTS: Shade nos/Colours: Finish: Volume solids, %: Theoretical spreading rate: Flash point: Specific gravity: Dry to touch: Fully cured: VOC content:

12340* / Grey. Semi-gloss 78 ± 1 3.9 m2/l [156.4 sq.ft./US gallon] - 200 micron/8 mils 25 °C [77 °F] 1.6 kg/litre [13.2 lbs/US gallon] 7 - 8 hour(s) 20°C/68°F 7 day(s) 20°C/68°F 253 g/l [2.1 lbs/US gallon]

-

*other shades according to assortment list. The physical constants stated are nominal data according to the HEMPEL Group's approved formulas.

APPLICATION DETAILS: Version, mixed product: Mixing ratio: Application method: Thinner (max.vol.): Pot life: Nozzle orifice: Nozzle pressure: Cleaning of tools: Indicated film thickness, dry: Indicated film thickness, wet: Overcoat interval, min: Overcoat interval, max: Safety:

Date of issue: July 2015 -

35851 BASE 35858 : CURING AGENT 97652 3 : 1 by volume Airless spray / Brush 08450 (2%) / 08450 (2%) 1 hour(s) 20°C/68°F 0.021 - 0.023 " Reversible 250 bar [3625 psi] (Airless spray data are indicative and subject to adjustment) HEMPEL'S TOOL CLEANER 99610 200 micron [8 mils] 275 micron [11 mils] According to specification. According to specification. Handle with care. Before and during use, observe all safety labels on packaging and paint containers, consult HEMPEL Safety Data Sheets and follow all local or national safety regulations.

Page: 1/2

Product Data Sheet

HEMPADUR GF 35851 SURFACE PREPARATION:

New steel: Remove oil and grease etc. thoroughly with suitable detergent. Remove salts and other contaminants by high pressure fresh water cleaning. Abrasive blasting to minimum Sa 2½ (ISO 8501-1: 2007) with a surface profile equivalent to Rugotest No. 3, min. N9a, Keane-Tator Comparator (G), 2 mils segments or ISO Comparator Medium (G). After blasting, clean the surface carefully from abrasives and dust. Repair and maintenance: Remove oil and grease etc. thoroughly with suitable detergent. Remove salts and other contaminants by high pressure fresh water cleaning. Clean damaged areas thoroughly by power tool cleaning (minor areas) or by abrasive blasting. Feather edges to sound and intact areas. Dust off residues. Touch up bare spots to full film thickness. On pit-corroded surfaces, excessive amounts of salt residues may call for high pressure water jetting, wet abrasive blasting or, alternatively, dry abrasive blasting, high pressure fresh water hosting, drying, and finally dry abrasive blasting again. Alternatively, water jetting may be used provided the steel surface has already the surface profile as described in: New steel

APPLICATION CONDITIONS:

Apply only on a dry and clean surface with a temperature above the dew point to avoid condensation. Use only where application and curing can proceed at temperatures above: 10°C/50°F. The temperature of paint itself should be 15°C/59°F or above. Apply only on a dry and clean surface with a temperature above the dew point to avoid condensation. In confined spaces provide adequate ventilation during application and drying. Curing requires a relative humidity of: maximum 90%.

PRECEDING COAT:

None. HEMPADUR15590 can be used as a blast primer.

SUBSEQUENT COAT:

None, or as per specification. Recommended systems are: HEMPADUR

REMARKS: Weathering/service temperatures: The natural tendency of epoxy coatings to chalk in outdoor exposure and to become more sensitive to mechanical damage and chemical exposure at elevated temperatures is also reflected in this product. Application equipment: A reversible nozzle is recommended. Filter: Surge tank filter and tip filter should be removed. Film thicknesses/thinning: May be specified in another film thickness than indicated depending on purpose and area of use. This will alter spreading rate and may influence the drying time. Normal range is: 150-250 micron/6-10 mils. It is recommended to use heavy airless spray equipment with a pump transmission rate of 60:1 (approximately), and a theoretical output of min. 12 litres per minute.Thinning: Normally not to be diluted. Overcoating note: The long maximum overcoating interval for HEMPADUR will be reduced if the coating is more than just scarcely exposed to direct sunshine before overcoating. If the interval is exceeded, roughening of surface is necessary to ensure intercoat adhesion. Note: HEMPADUR GF 35851 For professional use only. ISSUED BY: HEMPEL A/S 3585112340

This Product Data Sheet supersedes those previously issued. For explanations, definitions and scope, see “Explanatory Notes” available on www.hempel.com. Data, specifications, directions and recommendations given in this data sheet represent only test results or experience obtained under controlled or specially defined circumstances. Their accuracy, completeness or appropriateness under the actual conditions of any intended use of the Products herein must be determined exclusively by the Buyer and/or . The Products are supplied and all technical assistance is given subject to HEMPEL's GENERAL CONDITIONS OF SALES, DELIVERY AND SERVICE, unless otherwise expressly agreed in writing. The Manufacturer and Seller disclaim, and Buyer and/or waive all claims involving, any liability, including but not limited to negligence, except as expressed in said GENERAL CONDITIONS for all results, injury or direct or consequential losses or damages arising from the use of the Products as recommended above, on the overleaf or otherwise. Product data are subject to change without notice and become void five years from the date of issue.

Date of issue: July 2015 -

Page: 2/2
