POORNIMA COLLEGE OF ENGINEERING A PRESENTATION ON

MAJOR PROJECT SEMINAR(STAGE-II)

“GSM BASED E-NOTICE BOARD”

SUBMITTED TO: Mr. MANISH SINGHAL

SUBMITTED BY: PAWAN KUMAR PRAJAPAT (EC/09/140)

Mr. S.VENKATESH

RAGHUVEER SINGH(EC/09/62) PANKAJ GUPTA (EC/09/92) PARAMJEET(EC/09/120) ECE-FINAL YEAR

CONTENT 1. AIM OF THE PROJECT 2. EXISTING SYSTEMS IN MARKET 3. INTRDUCTION 4. SCOPE OF WORK AND IDEA 5. BLOCK DIAGRAM 6. CIRCUIT DIAGRAM 7. COMPONENT LIST 8. THE MICROCONTROLLER 9. DISPLAY UNIT(LCD) 10. GSM MODULE 11. MAX232 IC 12. PROGRAMMINGFEASIBILITY 13. APPLICATION AND PURPOSE 14. FURTHER ENHANCEMENT 15. WORK DISTRIBUTION BETWEEN TEAM 16. REFRENCES 2

AIM OF THE PROJECT

The main aim of the project will be to design a GSM based electronic notice display system which can replace the currently used programmable electronic display. We can display anything we want through the use of a SMS via a mobile through implementation of a GSM modem in the project. 3

EXISTING SYSTEMS IN MARKET

currently programmable electronic display are not wireless and SMS based display of information on notice board.

There remains a particular message in the programming phenomenon of the system.

4

INTRODUCTION

The message containing the information would be display on the LCD screen via a GSM modem. The message to be displayed is sent through a SMS from an authorized transmitter. The microcontroller receives the SMS, validates the sending Mobile Identification Number (MIN) and displays the desired information. 5.

SCOPE OF WORK AND IDEA

In controlling the appliances using wireless communication and Embedded System. Work on “Embedded System in 1 Communication” is widely do in this project. The main idea is that a GSM modem receives a SMS and The microcontroller validates the SMS and then displays the message in the LCD display board. 6.

BLOCK DIAGRAM

7.

CIRCUIT DIAGRAM

8

COMPONENT LIST

MICROCONTROLLER(AT89C51) RESISTANCE(470,330,1K) CRYSTAL OSCILLATOR(11.0592MHZ) CAPACITORS(33PF,10MF,1MF) MAX 232 GSM MODULE(SIMADO GDT11 ) SIM CARD POWER ADEPTER(+5V) LCD DISPLAY(4*20 TEXT LCD) RESISTANCE ARRAY(10K)

9

THE MICROCONTROLLER

10

DISPLAY UNIT(LCD)

11

12

GSM MODEM

The GSM modem provides a low cost, long range, wireless communication channel for applications that need connectivity rather than high data rates.

13

GSM MODEM AND MICRO-CONTROLLER INTERFACING:

14

AT COMMANDS

15

CONT…

SOME AT-COMMANDS FOR GSM MODEM:

AT+CMGF = 1 Select the text mode for SMS ;This command configures the GSM modem in text mode. AT+CMGS =+923005281046 for sending SMS message in text mode along with mobile number to the GSM Modem

16

MAX232 IC

 The MAX232 is a dual driver/receiver that includes a capacitive voltage generator to supply TIA/EIA-232 voltage levels from a single 5-V supply.  The microcontroller is interfaced with PC or the GSM MODEM via a MAX 232 to convert TTL logic to EIA 232 or RS232 and vice versa. 17

Pin description of MAX 232 IC

18

INTERNAL ARICHECTURE

19

PROGRAMMING FEASIBILITY

Express pcb Proteus design

Embedd ed c

Keil compiler

20

APPLICATIONS

 Institutional Use: In colleges an Univ.  Industrial organization Railway station Managing traffic ment Banking system Emergency message display in Hospitals

21

ADVANTAGES Faster

and more efficient service Reduces human efforts Increases efficiency Reducing delays Reduces human errors. Digitalization of all campous. Low maintance cost Increase green economy. Save paper Long time display

22

DISADVANTAGES DISADVANGE High

installition cost. Dependency on N/W. Limiations on character Lcd display.

23

FURTHER ENHANCEMENTS

Alphanumeric LCD’S have a limitation on size and character display. We can use a LED ARRAYS to remove the limitation. Robots can be controlled in a similar fashion by sending the commands to the robots. These commands are read by using AT commands and appropriate action is taken. Farmers can turn on or off pump and drippers via gsm modem.

24

WORK DISRRIBUTION AMONG TEAM

 Paramjeet: Drilling, Etching and component mounting, Documentation.  Pawan prajapat: PCB deg on EXPRESS 7PCB or DIPTRESS, simulation on PROTEUS ,soldering.  Pankaj Gupta and Raghuveer Singh: Circuit deg, Coding, Debugging, Component purchasing, Documentation. 25

REFRENCES 1. “8051 and embedded system” by Mazidi and Mazidi 2. All datasheets from www.datasheetcatalog.com 3. About AT89s8252 from www.atmel.com 4. And www.triindia.co.in 5. About DS1820 from www.dallas.com 6.www.hbeonlabs.com 26

27

QUERIES???..
