Presentation on NTPC Inspection Services

Presentation Outline   

    

Introduction Objectives of Inspection Services Functions of Inspection Services Organization Structure Roles of Inspection Engineer Customers (External &Internal) Inspection Process Summary

2

Quality Assurance & Inspection 



Quality is a relative term and is generally expressed with reference to end use of product Planned and systematic actions necessary to provide confidence thereby assure the suitability of product for its intended purpose



Control is a system for measuring and inspecting a phenomenon



Inspection means checking the acceptability of product



Inspection measure the quality of product

3

QUALITY IS DEFINED AS “FITNESS FOR USE” FITNESS IS DEFINED BY CUSTOMER JOSEPH M. JURAN

“CONFORMANCE TO THE REQUIREMENTS” PHILIP B. CROSSBY DEGREE

TO

WHICH

A

SET

OF

INHERENT

CHARACTERISTICS FULLFILLS REQUIREMENTS

ISO 9000

QUALITY IS DEFINED AS THE CHARACTERISTICS OF A PRODUCT OR SERVICE THAT BEAR ON ITS ABILITY TO SATISFY STATED OR IMPLIED NEEDS A PRODUCT OR SERVICE FREE OF DEFICIENCIES

AMERICAN SOCIETY OF QUALITY

“Quality By-design & not By-chance”

TWO KEY PRINCIPLES CHARACTERIZE QA FIT FOR PURPOSE

THE PRODUCT SHALL BE SUITABLE FOR THE INTENDED PURPOSE

RIGHT FIRST TIME

MISTAKES SHOULD BE ELIMINATED

6

QUALITY ASSURANCE INCLUDES REGULATIONS OF QUALITY OF RAW MATERIAL, ASSEMBLIES,PRODUCTS AND COMPONENTS, SERVICES RELATED TO PRODUCTION AND INSPECTION

7

QUALITY CONTROL THOSE QUALITY ASSURANCE ACTIONS WHICH PROVIDE MEANS TO CONTROL AND MEASURE THE CHARACTERISTICS OF AN ITEM, PROCESS OR FACILITY TO ESTABLISH FITNESS FOR USE “VARIATION IS LAW OF NATURE” FOR EACH PROCESS THE VARIATIONS NEED TO BE IDENTIFIED AND

CONTROL

MAINTAINED

TO

LIMIT

THE

VARIATIONS

WITHIN

SPECIFICATIONS. THIS IS QUALITY CONTROL. 8

INSPECTION THE PROCESS OF MEASURING , EXAMINING, TESTING , GAUGING OR OTHERWISE COMPARING ONE OR MORE CHARACTERISTICS OF A PRODUCT OR SERVICE WITH THE SPECIFIED REQUIREMENTS. “ A process of segregating good from bad”

9

QUALITY MANAGEMENT SYSTEM A SET OF POLICIES, PROCESSES AND PROCEDURES REQUIRED

FOR

PLANNING

AND

EXECUTION

(PRODUCTION / DEVELOPMENT / SERVICE) IN THE CORE BUSINESS AREA OF AN ORGANIZATION.

10

OBJECTIVES OF INSPECTION SERVICES 





TO ENSURE THAT DEFECT FREE PLANT & EQUIPMENT COMPLIANT WITH TECHNICAL SPECIFICATIONS AND OF SPECIFIED QUALITY. TO UNDERSTAND INSPECTION TECHNICAL SPECIFICATION

REQUIREMENTS

OF

ON-LINE PLANNING OF INSPECTION CALLS WITH A VIEW TO IMPROVE TIME SCHEDULE FOR DISPOISITIONING OF INSPECTION CALLS AND TO ATTEND INSPECTION CALLS IN LINE WITH CUSTOMER REQUIREMENTS.

11

Functions of Inspection Services 



specified quality level of equipment by carrying out inspection at contractors / sub-Contractors premises, or by review of test certificate in accordance with agreed Quality Plan and contract requirements, for equipment ordered from Corporate Contract, consultancy assignment and from project ordered equipment and to carry out inspection activities as per agreed schedule matching Project Schedule and requirements. Ensure implementation of agreed documented quality system and programme at contractors / sub- contractors works by ing inspection records, process control records, calibration status during inspection of equipment. 12

Contd.. 



 

Provide to CQA and contractor (need base) for improvement of contractors / sub- contractors manufacturing capabilities, inspection and test facilities and implementation of Quality Programme. Assist contractors / sub- contractors, wherever required, to improve quality of equipment, manufacturing facilities and process. Provide Inspection Services for Consultancy jobs as per contract for the same. Provide to Corporate Contracts/ Engineering/CQA in respect of hold ups in manufacturing activities or likely delays for speedy redressal of these hold ups by concerned departments. 13

ORGANIZATIONAL STRUCTURE DIRECTOR (TECHNICAL) ED (ENGINEERING)

HEAD QA & I INSPECTION SERVICES

RIO DELHI

RIO HWR

RIO MUB

RIO BPL

RIO BRD

RIO PUN

RIO KOL

RIO TRY

RIO RPN

RIO HYD

RIO BLR

RIO CHN

RIO TRVN

14

Role of Inspection Engineer 

Product identification & traceability wherever applicable.



Verification of clearance of earlier inspection stages, wherever applicable.



Ensure calibration of the measuring equipment used during inspection.





comprehensive review of the internal quality records of the Contractor as per the quality plan ensuring adherence to the requirement and dispositioning of deviations, if any. Surveillance check on the quality programme of the Contractor agreed as per the contract. 15

Contd.. 









Provide feed back on Contractor’s process control, manufacturing facilities & quality. Reporting Non conformities observed. Provide regular to Corporate Contracts/ Engg. regarding holdups or likely delays in Manufacturing Programme. Causes for such hold ups / likely delays are identified in their reports for speedy redressal.

Monitoring of Inspection Calls, Issue of MDCC for dispatch of equipment after satisfactory final inspection and clearance of CHPs & verification of implementation of corrective action, as agreed, for dispositioning of Non conformities. Association with CQA, as required, for audit of Quality system of Contractors,/Sub Contractors. Assess the actual manufacturing Progress of the critical items required by the Project Contract Services, identify any hold ups in their manufacturing and send a report to Project, Engg/CQA Corporate Contracts. 16

Calibration of Instruments       

  

Ensures Correct reading Appropriate reference Logical approach Minimum inconsistencies Better accuracies Repeatability of measurements All time confidence Traceability of records Integrity of reports Optimum performance 17

Customers



External -

Contractors/Suppliers



Internal

-

Projects/Sites

18

DOCUMENTS FOR INSPECTION  

  

Quality requirements and testing provisions needs to be the part of contract for its effective implementation. Documents needed for inspection are prepared and submitted by suppliers and processed and finalized by other groups/div of NTPC and therefore close coordination by inspection services is needed with all these groups and suppliers Pre award finalization/commitments include List of agreed make/model/manufacturer of various subcomponents submitted by supplier and mutually agreed with CQA Finalization of manufacturing quality plan(MQP) containing a) listing all tests and checks to be done during manufacturing and records to be kept for review by inspection engineer during inspection b)List all test/checks with sampling plan for test to be witnessed by NTPC These documents are submitted by supplier and approved by CQA 19

Contd..      

List of type tests to be done by supplier and to be approved by NTPC Engg List of type tests to be done by supplier and to be approved by NTPC Engg list of drawing/datasheet requiring approval by NTPC Engg Billing breakup for purpose of on payments and issuance of MDCC approved and issued by Contract Div Contract agreements tly signed by supplier and NTPC Standards such as IS , BIS, ASME, IEC Etc which broadly specify testing procedures , acceptance norms etc[Checks identified in MQP are broadly derived from these standards]

20

Process of Inspection and Issuance of CHP and MDCC 





Complete process is mapped and controlled through a web based application (known as WINDSOR’x) accessible through Internet by all inspection offices, suppliers and sub-suppliers and other s of inspection related data Suppliers submits offer for inspection listing details of BBU no , item , total qty , qty already supplied and qty offered for inspection with proposed date for inspection using online portal The inspection call is scanned for completeness of approved documents

21

Contd..       

The inspection planning is done through the same portal by the In-charge of inspection office. Inspection engineers visit the place of manufacture and checks the following before starting inspection/testing: Quality plans are approved. Drawing/ Datasheets are approved. Review all internal test records maintained by the manufacturer. Check that all the sub-components are of approved/agreed make. All the testing equipments are calibrated and are in working conditions. 22

Contd..         



After ensuring the above, the preliminary work involvesVerification of availability of complete material for inspection. Identification(stamping)of the offered lot.{to the extent feasible} Performing random sampling of items for testing.{Inline with quality plan} After selecting sample for testing, witnessing of actual testing starts . Few parameters to check areVisual Dimensional Conformity. Functional compatibility checks. examples pressure parts/rotary parts Quality of welds by RT and DP Hydro test/pneumatic pr test at 2.0 times working pressure Mechanical testing and chemical composition of body material hardness test 23 Efficiency test for pumps/blowers/motors

Contd.. 



After completion of tests , inspection report(CHP) is generated on line using inspection portal from the place of inspection and MDCC is also issued from the portal and handed over to supplier if item is found acceptable in all respect. The data thus generated, updated and modified by NTPC as well as its suppliers and manufacturers (as a normal course of discharging their functions) provides comprehensive and customized online information to various groups and monitoring agencies as well as the clients and suppliers who in turn take immediate corrective actions for ensuring timely availability of materials and components at the project site.

24

SNAPSHOTS OF WINDSOR’x

Inspection call entry screen

25

SNAPSHOTS OF WINDSOR’x A typical list of contracts awarded for NTPC Mauda project

26

SNAPSHOTS OF WINDSOR’x Inspection Planning sheet

27

SNAPSHOTS OF WINDSOR’x Inspection weekly grid

28

SNAPSHOTS OF WINDSOR’x

CHP report

29

SNAPSHOTS OF WINDSOR’x MDCC Reports

30

SNAPSHOTS OF WINDSOR’x Inspection Planning sheet

31

SNAPSHOTS OF WINDSOR’x Inspection weekly grid

32

“Quality is not an act .It is a habit”

“Quality By-design & not By-chance”

34
