Project Documentation Mickey Mouse Program

Submitted by: by: Sandeep Singh Monga Sahil Talwar Professor

Guided Ms. Suhasini Assistant

Roll no. A20 & A21 Section RA3802 Registration no. 10805743 10805845 Lovely Professional University

1|Page

Certificate

This is to certify that this dissertation entitled “Mickey Mouse Program” submitted for the degree of Bachelors of computer applications (BCA hons) in the subject of Computer Application Department to the Lovely Professional University (Phagwara), work carried out by Sandeep Singh and Sahil Talwar Registration no. 10805743 and 10805845 under the guidance in partial fulfillment of the requirement for the course: Computer Graphics (CAP 367)

2|Page

Ms.Suhasini Monga Kaur Asst. Professor Professor Faculty Advisor

Ms. Kuljeet Asst. COD

Declaration I hereby declare that the project work entitled “MICKEY MOUSE PROGRAM” is an authentic record of my own work carried out at Lovely Professional University as requirements of project for the award of degree of BCA (Hons.) Lovely Professional University, Phagwara, under the guidance of Ms. Suhasini Monga during February to May, 2011.

3|Page

Sandeep Singh Sahil Talwar RA3802A20 RA3802A21 Reg. No. 10805743 108058 45

Acknowledgement My deep gratitude, fullness which I have for my madam, Ms. Suhasini Monga , under whose guidance, advice, help, inspiration and encouragement it is easy for me to make this project and also for his contribution in coordination and cooperating us during the course of development. He enriched us with knowledge whenever we reached him. I am also thankful to my colleagues with whom I have fruitful discussions which have helped us a lot in giving a final shape to the program. At last but not the least I express our heartiest gratitude towards almighty for providing us the environment and . 4|Page

Sandeep Singh Sahil Talwar RA3802A20 RA3802A21 Reg. No. 10805743 10805 845

CONTENTS Sr. No.

TOPICS

Page No.

1

Project Name and Description

6

2

Profile of the problem

7

3

Existing System  Existing Software  DFD of present system

7-8 8

5|Page

4

5

6

7

8 9

10 11 12

Problem Analysis  Problem Definition  Feasibilty Analysis  Project Plan Software Requirement Analysis  Introduction  General Description  Specific Requirements Design  System Design  Detailed Design  Pseudo code Testing  Functional Testing  Structural testing Implementation Project Legacy  Current status of project  Remaining area of concern Manual Source Code • Final Output Bibliography

9 9

10

11-14

14-15

15

15 16-21 22-23 24

6|Page

1. Project Name and Description: Name of Project:- “Mickey Mouse Program” Project Description:The project includes different modules that are needed to generate different pictures into a single animated picture (include motion of pictures) in same program in a same time. In this project we can display a picture of Mickey Mouse with the help of motion as it looks like animated. The project Mickey mouse program will be made by the use of arcs, lines, circle, ellipse etc. We can add some colour to Mickey mouse so that it will be seen attractive. This project includes animated Mickey mouse that includes smiley face using arcs, lines, circles, ellipse etc. This application is easy to use and display an animated Mickey mouse. It can use in animation or animated movies. It will be the full source of entertainment. Header Files in our project: #include : It is used to draw graphical objects in our project. #include : It is a C header file used in old MS-DOS compilers to create text interfaces. #include<dos.h>: It is used to move the car in our project. #include<stdio.h>: It is used for printf and scanf in our project. In this project, We used different predefined functions to create Mickey Mouse Program. Some of the in built functions which we have mostly used to create Mickey Mouse Program are: 1. line() : This function helped us in making doors, mirrors, bumper, light, rear etc of the car. 2. Ellipse() : Ellipse function is used in our project for making the roof and tyers of the car. 3. floodfill() : This function helped us in our project to fill a specific part to make it more attractive. 4. setfillstyle() : This function helped us making different patterns on the car such as dotted lines etc. 5. outtextxy(): It is used in our project to place text on the output screen.

7|Page

2. Profile of the problem:-



It is time consuming.



It is very tedious.



It includes a lot of paper work.



It is very complex and not easy to understand.

3. Existing System:-

a) Exiting software:- Not any specific system for this at this time. b) DFD for Present system:-

8|Page

Start Header Files

Datatypes

Shapes ellipse,line

Declarations

Styles

Asg variables

Deg

Colors,Patter ns

Animations

Coding

Errors

Compile Yes Correct Errors Errors

Chec k Error s No

Errors

Execute

Display Output

END

9|Page

4. Problem Analysis:In this projects we face two problem’s ♦ Void left () function----this function help to club the pixels from one place to another. ♦ Set fill / flood fill---These function help to change the view of the project like pattern of colour, its colour /design.

a) Product definition:- The project includes different modules that are needed to generate different pictures into a single animated picture (include motion of pictures) in same program in a same time. In this project we can display a picture of Mickey Mouse with the help of motion as it looks like animated. The project Mickey mouse program will be made by the use of arcs, lines, circle, ellipse etc. We can add some colour to Mickey mouse so that it will be seen attractive. This project includes animated Mickey mouse that includes smiley face using arcs, lines, circles, ellipse etc. This application is easy to use and display an animated Mickey mouse. It can use in animation or animated movies. It will be the full source of entertainment.

b) Feasibility Analysis---Technical feasibility:  

I can develop this kind of system in Turbo c++ which is flexible. Easy to make changes in turbo c++

Operational feasibility:  

This system is totally feasible respect to operations and functionality Calculation can be done by simple mathematics.

Cost feasibility:  

No additional hardware is required to develop the program We need Turbo c++ and DosBox.

c) Project Plan:First of all we decide to making of project we draw it like:- Arc’s 10 | P a g e

 Lines  Ellipse  flood fill  set-fill Then we start to making the project.

11 | P a g e

5. Software requirement Analysis: a. Introduction:- C is an imperative (procedural) systems implementation language. It was designed to be compiled using a relatively straightforward compiler, to provide low-level access to memory, to provide language constructs that map efficiently to machine instructions, and to require minimal run-time . C was therefore useful for many applications that had formerly been coded in assembly language. b. General Description:-Despite its low-level capabilities, the language was designed to encourage cross-platform programming. A standardscompliant and portably written C program can be compiled for a very wide variety of computer platforms and operating systems with few changes to its source code. The language has become available on a very wide range of platforms, from embedded micro controllers to supercomputers. •

Operating system: Windows 9.x, Windows 2000, Windows XP, Windows Vista, Windows 7.

c. Specific Requirements :-It will work on windows only because .exe files do not work on linux or unix. Compiler is needed to edit the project in future in case of any requirements.

12 | P a g e

6. Design----

a. System Design:- Systems design is the process of defining the components, modules, interfaces, and data for a system to satisfy specified requirements and we have divided our project into different modules for its better understanding and to make it friendly. b. Detailed design:-

Starting Phase of project:-

Second Phase:-

13 | P a g e

Final Output:-

14 | P a g e

c. Pseudo code:- An algorithm is a procedure for solving a problem in of the actions to be executed and the order in which those actions are to be executed. An algorithm is merely the sequence of steps taken to solve a problem. The steps are normally "sequence," "selection, " "iteration," and a case-type statement. In C, "sequence statements" are imperatives. The "selection" is the "if then else" statement, and the iteration is satisfied by a number of statements, such as the "while," " do," and the "for," while the casetype statement is satisfied by the "switch" statement. Pseudo code is an artificial and informal language that helps programmers develop algorithms. Pseudo code is a "text-based" detail (algorithmic) design tool. The rules of Pseudo code are reasonably straightforward. All statements showing "dependency" are to be indented. These include while, do, for, if, switch. Examples below will illustrate this notion. while(!kbhit()) { if(i==0) { setfillstyle(1,15); setcolor(15); ellipse(210,133,0,360,10,10);//left eye ball ellipse(265,133,0,360,10,10);//right eye ball setcolor(0); ellipse(210,133,0,360,3,3);//left eye ball ellipse(265,133,0,360,3,3);//right eye ball floodfill(210,133,15); floodfill(265,133,15); setcolor(0); putimage(391,209,buf,1); firstleft(); 15 | P a g e

setcolor(15); secondleft(); putimage(409,224,buf,0); i=1; } else { setfillstyle(1,0); setcolor(0); ellipse(210,133,0,360,10,10);//left eye ball ellipse(265,133,0,360,10,10);//right eye ball floodfill(210,133,0); floodfill(265,133,0); setcolor(15); ellipse(210,133,0,360,3,3);//left eye ball ellipse(265,133,0,360,3,3);//right eye ball floodfill(210,133,15); floodfill(265,133,15); setcolor(0); putimage(409,224,buf,1); secondleft(); setcolor(15); firstleft(); putimage(391,209,buf,0); i=0; } delay(300); }

7. Testing:- We test the project after completing the step by step.after complete every step of project we check it if step run properly then we start coding for next step.it help to making project easily..

a. Functional Testing:- Testing is an investigation conducted to information about the quality of the product or service under test. Software testing also provides an objective, independent view of the software to allow the business to appreciate and understand the risks of software implementation. Test techniques include, but are not limited to, the process of executing a program or application with the intent of finding software bugs .

b. Structural Testing:- Structural testing on checking that all executable statements within each module have been exercised and the corresponding branches and paths through that module have been covered. Structural testing can therefore be considered as concentrating on checking that the control logic

16 | P a g e

operates correctly. The coverage measurements that fall into this category are: statement, branch, condition and expression, and path coverage.

c. Testing of the Project:- We have tested our project in different modules. The project is running successful with no errors.

8. Implementation

a. Implementation of the project Implementation of the project in the organization will include various things. Organization should have compatible hardware and software to implement this. And Executable file of this project is given to end s so that they can use the software.

9. Project Legacy:- We don’t copy any type of code of the project. We make the project with the help of two books-

 Computer Graphics C Version  LET US C  ANSI C And with own knowledge/and teacher help.

a. Current status of project:- The current status is the project the totally complete. Nothing is rest.

b. Remaining area of concern:- No Remaining area of concern in the project. the project the totally complete. Nothing is rest.

c. Technical and Managerial Lessons learned:- Technically, we learned how to create animated project using C language and to make it more attractive. Managerial lessons we learnt from this project is how to manage do work as a team.

17 | P a g e

10. Manual:- First of all you have to install turbo c++ in your operating system. After installation open the (c:\) drive from My computer. And then save the file in C:\turbo\Tc folder. Open your turbo c++. Then from menu bar open the newmickey.c file and run it.

18 | P a g e

11.Source code:-

#include #include<dos.h> #include #include void *buf; void firstleft(); void secondleft(); void main() { int gd=DETECT,gm,i=0,x,y,area; initgraph(&gd,&gm,"tc:\bgi"); rectangle(0,0,getmaxx(),getmaxy()); outtextxy(250,10,"MICKEY MOUSE PROGRAM"); outtextxy(520,100,"SAHIL TALWAR"); outtextxy(518,120,"SANDEEP SINGH"); arc(240,120,40,140,70); ellipse(165,80,10,280,20,20); ellipse(315,80,-100,170,20,20); arc(235,120,163,215,70); arc(245,120,-35,17,70);

19 | P a g e

ellipse(193,178,85,280,40,20); ellipse(283,178,-100,95,40,20); ellipse(238,199,180,0,39,50); ellipse(213,123,44,240,33,40); ellipse(262,123,-60,135,33,40); ellipse(210,123,0,360,13,20);//left eye ellipse(265,123,0,360,13,20);//right eye ellipse(210,133,0,360,10,10);//left eye ball ellipse(265,133,0,360,10,10);//right eye ball ellipse(210,133,0,360,3,3);//left eye ball ellipse(265,133,0,360,3,3);//right eye ball ellipse(238,160,0,360,10,13);//nose arc(240,125,228,312,68);//mouth arc(240,120,230,310,72);//mouth setfillstyle(1,4); floodfill(238,160,15);//nose setfillstyle(1,5); floodfill(210,113,15); floodfill(265,113,15); setfillstyle(1,6); floodfill(210,100,15); setfillstyle(1,0); floodfill(315,80,15);/*setfillstyle(1,4); floodfill(238,160,15);//nose

20 | P a g e

setfillstyle(1,15); floodfill(210,113,15); floodfill(265,113,15); setfillstyle(1,9); floodfill(210,100,15); setfillstyle(1,1); floodfill(315,80,15); */ moveto(203,220); lineto(203,260); lineto(183,260); lineto(183,350); lineto(293,350); lineto(293,260); lineto(273,260); lineto(273,220); moveto(183,350); lineto(173,460); lineto(213,460); lineto(238,400); lineto(263,460); lineto(303,460); lineto(293,350); moveto(173,460); lineto(143,478);

21 | P a g e

lineto(213,478); lineto(213,460); moveto(263,460); lineto(263,478); lineto(333,478); lineto(303,460); line(238,400,238,350); //right hand moveto(183,260); lineto(113,310); lineto(183,375); moveto(183,280); lineto(137,310); lineto(181,353); setfillstyle(8,4); floodfill(190,300,15); setfillstyle(6,9); floodfill(223,400,15); setfillstyle(6,9); floodfill(253,400,15); setfillstyle(9,2); floodfill(173,470,15); floodfill(303,470,15); /*setfillstyle(2,13);

22 | P a g e

floodfill(190,300,15); setfillstyle(1,5); floodfill(223,400,15); setfillstyle(1,5); floodfill(253,400,15); setfillstyle(1,6); floodfill(173,470,15); floodfill(303,470,15);*/ //fingers secondleft(); ellipse(413.5,228,0,180,3.5,3.5); line(420,240,433,240); line(423,247,440,247); line(413,240,410,228); line(417,228,420,240); ellipse(433,243.5,-90,90,3.5,3.5); line(423,254,440,254); ellipse(440,250.5,-90,90,3.5,3.5); ellipse(430,257,-90,90,3,3); line(413,260,430,260); area=imagesize(409,224,444,261); buf=malloc(area); getimage(409,224,444,261,buf); while(!kbhit())

23 | P a g e

{ if(i==0) { setfillstyle(1,15); setcolor(15); ellipse(210,133,0,360,10,10);//left eye ball ellipse(265,133,0,360,10,10);//right eye ball setcolor(0); ellipse(210,133,0,360,3,3);//left eye ball ellipse(265,133,0,360,3,3);//right eye ball floodfill(210,133,15); floodfill(265,133,15); setcolor(0); putimage(391,209,buf,1); firstleft(); setcolor(15); secondleft(); putimage(409,224,buf,0); i=1; } else { setfillstyle(1,0); setcolor(0);

24 | P a g e

ellipse(210,133,0,360,10,10);//left eye ball ellipse(265,133,0,360,10,10);//right eye ball floodfill(210,133,0); floodfill(265,133,0); setcolor(15); ellipse(210,133,0,360,3,3);//left eye ball ellipse(265,133,0,360,3,3);//right eye ball floodfill(210,133,15); floodfill(265,133,15); setcolor(0); putimage(409,224,buf,1); secondleft(); setcolor(15); firstleft(); putimage(391,209,buf,0); i=0; } delay(300); } getch(); } void firstleft() { moveto(293,260);

25 | P a g e

lineto(353,276); lineto(395,223); moveto(293,280); lineto(355,296); lineto(395,245); } void secondleft() { moveto(293,260); lineto(363,280); lineto(413,240); moveto(293,280); lineto(363,300); lineto(413,260); }

26 | P a g e

Final Output:-

27 | P a g e

28 | P a g e

12.Bibliography: Computer Graphics C version  LET US C  ANSI C  http://www.unf.edu/~broggio/cop3530/3530pseu.htm  http://www.whitehatandroid.com/2010/09/dosbox-run-turbo-cin-windows-7vista-in.html 
