Real-Time Pacer for Simulink - File Exchange - MATLAB Central
File Exchange Real-Time Pacer for Simulink
4.8 41 Ratings
version 1.0.0.1 (18.7 KB) by Gautam Vallabha
154 s
Simulink block for forcing a simulation to run in real (wall clock) time
Updated 01 Sep 2016 View License
Follow
Overview
Functions
Models
Editor's Note: This file was selected as MATLAB Central Pick of the Week
The RealTime Pacer block slows down ("paces") simulation time so that it synchronizes with real elapsed time. The degree of slowdown is controllable via a Speedup parameter. 1) The block is implemented using an M S-function, so it works on any ed Simulink platform. It does not code generation. 2) The block uses the MATLAB PAUSE function to slow down the simulation. The PAUSE command gives up the processor during the pause, so system performance does not degrade. 3) The M-S function illustrates how to use nested functions to simplify the code. The matching between simulation time and elapsed real time is approximate, with expected differences on the order of 10 to 30 milliseconds. This limitation is due to difficulties of precise timing with a multitasking operating system. -------RELATED FX ENTRIES The following FX entries also implement "real time" functionality for Simulink. They are based on C S-functions and therefore code generation. * Simulink Real Time Execution (Real-Time Slower) (Filex# 21908) * Real-Time Blockset 7.1 for Simulink (Filex# 3175) * RTsync Blockset (Filex# 24975)
Comments and Ratings (47) Rate this submission
1 2 3 4 5
(Rating not required)
Comment on this submission
