Replacing the Laser Scanner Assembly HP LaserJet P3015 P3015n P3015dn P3015x
608-831-2396 or 866-352-7108
Us
Search Search Products
All Products
Toner
Maintenance Kits
Printers
Parts
Tech
Search
Shopping Cart My Checkout
Home Other Instructions Replacing Laser Scanner Assemblies HP LaserJet Printers The Laser Scanner Assembly HP LaserJet P3015 P3015n P3015dn P3015x
Replacing
Tech Home Page Maintenance Kit Instructions
Replacing the Laser Scanner Assembly HP LaserJet P3015 P3015n P3015dn P3015x
Other Instructions Troubleshooting Articles, News, Blog
Featured Articles HP Error Codes Entering Service Mode Service Mode PIN Codes Counterfeit Parts Challenge Cold Reset Instructions Clearing Maintenance Count JetDirect Reference Guide Half-Way Test
The laser scanner assembly is a fairly common part to fail on the HP LaserJet P3015 family of printers. If you are seeing repeated error codes of 51.10 or similar, you should replace the laser scanner. Instructions for replacing this assembly begin below.
Repetitive Defect Ruler Testimonials Innovations From PrinterTechs Glossary Of How to Replace the Laser Scanner Assembly HP LaserJet P3015 P3015n P3015dn P3015x 1. Slide the DIMM cover (on the right side of the printer) toward the back of the printer.
2. Remove the DIMM cover.
http://www.printertechs.com/other-instructions/103-replacing-laser-scanner-assemblies-hp-laserjet-printers/466-replacing-the-laser-scanner-asse…
1/11
28/7/2017
Replacing the Laser Scanner Assembly HP LaserJet P3015 P3015n P3015dn P3015x
3. Next, remove 1 screw and slide the formatter cover towards the back of the printer. (see picture below)
4. Remove the formatter cover from the printer.
5. Open the rear door.
http://www.printertechs.com/other-instructions/103-replacing-laser-scanner-assemblies-hp-laserjet-printers/466-replacing-the-laser-scanner-asse…
2/11
28/7/2017
Replacing the Laser Scanner Assembly HP LaserJet P3015 P3015n P3015dn P3015x
6. Gently pull down on the door and lower the door until it is fully open.
7. Push up on the link arm to release it. The link arm is under spring tension-- do not let the link arm snap back toward the printer when you release it.
8. Remove two screws (circled as callout 1 in the picture below).
http://www.printertechs.com/other-instructions/103-replacing-laser-scanner-assemblies-hp-laserjet-printers/466-replacing-the-laser-scanner-asse…
3/11
28/7/2017
Replacing the Laser Scanner Assembly HP LaserJet P3015 P3015n P3015dn P3015x
9. Open the lower-rear door, and then release a tab on the lower right hand side as you face the rear (circled in picture below).
10. On the opposite side (lower left hand side as you face the rear), release another tab as circled in picture below.
11. Rotate the bottom of the rear-door assembly away from the printer.
12. Pull down on the rear-door assembly to remove it.
http://www.printertechs.com/other-instructions/103-replacing-laser-scanner-assemblies-hp-laserjet-printers/466-replacing-the-laser-scanner-asse…
4/11
28/7/2017
Replacing the Laser Scanner Assembly HP LaserJet P3015 P3015n P3015dn P3015x 12. Pull down on the rear-door assembly to remove it.
13. Accessing from the rear, remove the screw which is securing the left side cover (see picture below).
14. Next, accessing from the rear, release 3 tabs which are securing the left side cover in place. See picture below.
15. Release one tab located at the top of the left side cover, approximately in the center, see picture below.
http://www.printertechs.com/other-instructions/103-replacing-laser-scanner-assemblies-hp-laserjet-printers/466-replacing-the-laser-scanner-asse…
5/11
28/7/2017
Replacing the Laser Scanner Assembly HP LaserJet P3015 P3015n P3015dn P3015x
16. Next, rotate the rear of the left cover slightly away from the printer, and then slide the cover towards the front of the printer to remove it.
17. Remove 2 screws from the top right cover, circled in picture below.
18. Next, lift the top right cover off the printer to remove it.
19. Press the release button and open the front cartridge door. Make sure it is completely open.
http://www.printertechs.com/other-instructions/103-replacing-laser-scanner-assemblies-hp-laserjet-printers/466-replacing-the-laser-scanner-asse…
6/11
28/7/2017
Replacing the Laser Scanner Assembly HP LaserJet P3015 P3015n P3015dn P3015x
20. Disconnect the control 's cable (circled as callout 1 in picture below), and remove 1 screw (circled as callout 2 in picture below).
21. Slide the control toward the front of the printer to release it.
22. Lift the control off the printer.
http://www.printertechs.com/other-instructions/103-replacing-laser-scanner-assemblies-hp-laserjet-printers/466-replacing-the-laser-scanner-asse…
7/11
28/7/2017
Replacing the Laser Scanner Assembly HP LaserJet P3015 P3015n P3015dn P3015x
23. Remove three screws from the top cover assembly.
24. Slightly lift the rear of the cover, slide the cover toward the front of the printer, and then remove it.
25. Release 1 tab (circled as callout 1 in picture below) on the air duct, and then lift the air duct (labeled callout 2 in picture below) out of the printer.
http://www.printertechs.com/other-instructions/103-replacing-laser-scanner-assemblies-hp-laserjet-printers/466-replacing-the-laser-scanner-asse…
8/11
28/7/2017
Replacing the Laser Scanner Assembly HP LaserJet P3015 P3015n P3015dn P3015x
26. Remove the antistatic sponge which covers the standard cable -- see picture below.
27. Disconnect the standard cable (callout 1 in picture below) and the ribbon cable (callout 2 in picture below).
28. Remove 4 screws from the top of the laser scanner assembly, see photo below.
http://www.printertechs.com/other-instructions/103-replacing-laser-scanner-assemblies-hp-laserjet-printers/466-replacing-the-laser-scanner-asse…
9/11
28/7/2017
Replacing the Laser Scanner Assembly HP LaserJet P3015 P3015n P3015dn P3015x
29. Lift the laser scanner assembly up and out of the printer.
30. Install new laser scanner assembly, and re-attach 4 screws. 31. Replug the standard cable and the flat ribbon cable. Transfer the antistatic sponge to the new laser scanner and install it over the standard cable plug. Re-install the air duct. 32. Finish by reassembling s in reverse order of the previous steps.
Other Steps in Replacing Laser Scanner Assemblies HP LaserJet printers 1. Replacing the Laser Scanner Assembly HP Color LaserJet 5500 5550 2. Replacing the Laser Scanner Assembly HP LaserJet M601 M602 M603 3. Replacing the Laser Scanner Assembly HP LaserJet P3015 P3015n P3015dn P3015x 4. Replacing the Laser Scanner Assembly HP Color LaserJet 4600 4610 4650 5. Replacing the Laser Scanner Assembly HP LaserJet P4014 P4015 P4515
