Roche/Hitachi 912 Specifications System

Discrete, fully-selective system for Clinical Chemistry, ISE (Na+, K+, Cl–) and Homogeneous Immunology

Test Throughput

360 tests/hr 720 tests/hr with ISE

Sample Types

Serum, Plasma, Urine, CSF, Hemolysate

Sample Input/Output

Load/unload capacity: 50 samples on the sample disk STAT samples are processed with priority, 20 positions on the sample disk

Sample Container Types

Primary tubes: Sample cup: Micro cup: Cup on tube:

Sample Volume

3 to 50µl

Sample Barcode Types

Code 128, Codabar (NW 7), Interleaved 2 of 5, Code 39

Reagents

ISE: Na+,K+,Cl– Onboard capacity: up to 36 tests

Control Unit

Windows NT™ PC with Pentium II processor, Touch-screen monitor

System Interfaces

RS 232 serial interface, bi-directional. Interface to the Service Processor and modem for Remote Diagnostic Access.

Electrical Requirements

230 Volts AC ±10%, 50 or 60Hz ±0.5% consumption 1.8KVA

Physical Dimensions

Width: 103cm (Disk version) 188cm (Rack version) Depth: 76cm Height: 117cm Control unit Width: 60cm Depth: 76cm Height: adjustable

Weight

300kg Analytical Unit 89 kg Control

Certification

GS, CE, UL, C-UL

5 to 10ml; 16x100, 16x75, 13x100, 13x75mm 2.5ml 1.5ml Cup on 16x75/100mm tube

3

Roche/Hitachi 912 Test Menu

Enzymes Acid Phosphatase ALP ALT (GPT) Amylase-T Amylase-P AST (GOT) CHE CK CK-MB γ-GT GLDH HBDH LDH Lipase

ISE Chloride Potassium Sodium

Drugs of Abuse Amphetamines Barbiturates Benzodiaepines Cannabinoids Cocaine Metabolite Ethanol Methadone Opiates Phencyclidine Propoxyphene

Others Salicylate T4 T-uptake

Therapeutic Drug Monitoring Carbamazepine CSA * Digitoxin Digoxin Gentamicin NAPA Phenobarbital Phenytoin Procainamide Salicylate Theophylline Tobramcyin Valproic Acid

Specific Proteins %-CDT α-1-Acid Glycoprotein α-1-Antitrypsin α-1-Microglobulin β-2-Microglobulin Albumin (Tina-quant) APO A1 APO B ASLO C3c C4 Ceruloplasmin CRP Ferritin Haptoglobin HbA1c Homocysteine * IgA IgE IgG IgM Kappa Light Chain Lamda Light Chain Lp (a) Myoglobin Prealbumin Rheumatoid Factor Soluble Transferrin Receptor Transferrin

Tests may be launched later in certain countries due to registration requirements. Urine and CSF applications are available for selected tests. * Assays currently under development

Substrates Albumin Ammonia Bicarbonate Bilirubin - direct Bilirubin - total Calcium Cholesterol HDL Cholesterol Direct LDL Cholesterol Direct Creatinine Fructosamine Glucose Iron Lactate Magnesium Phosphorus Total Protein U/CSF Protein Triglycerides UIBC Urea / BUN Uric Acid

Enzymes Acid Phosphatase Alkaline Phosphatase ALT / GPT Amylase - pancreatic Amylase - total AST / GOT Cholinesterase CK CK-MB GGT GLDH HBDH LD-1 LDH Lipase
