STUDY OF ESA 86/88-2 MICROPROCESSOR TRAINER KIT Aim: To study the ESA 86/88-2 Microprocessor trainer kit Apparatus required: ESA 86/88-2 Microprocessor trainer kit and its manual

Specifications: U: 8086/8088 U @ 5MHz (Supplied with 8086 U). The Processor is configured in maximum mode. CO – PROCESSOR: 8087 Numeric Data Processor (optional) MEMORY: 8 JEDEC sockets provide the following memory configuration: EPROM: 128K bytes of system firmware using 27256s. (32K X 4) RAM: 128K bytes using 62256 (32K X 4) Memory Map PROM System Application: F8000 – FFFFF H Expansion: F0000 – F7FFF H SRAM Supplied with Kit: 00000 – 0FFFF H Available for Expansion: 10000 – 1FFFF H PERIPHERALS: 8255: PPI, Two Nos, Each 24 I/O lines. I/O Addresses: FFE7, FFE1, FFE3, FFE5 (High Port) and FFE6, FFE0, FFE2, FFE4 (Low Port) 8253: PIT, (Three16 bit programmable timers). Timer0 is used for baud clock. Timer1 and Timer2 are available for I/O Addresses: FFFF, FFF9, FFFB, FFFD (Continued in page no: 6) SSN EC / BE – ECE / V ‘B’ / EC2308: Microprocessor and Microcontroller Lab

Page 1 of 6

Fig. 1. 8086 in Maximum Mode – Generation of System Bus Signals

Fig. 2. ESA 86/88-2 in Trainer Kit

SSN EC / BE – ECE / V ‘B’ / EC2308: Microprocessor and Microcontroller Lab

Page 2 of 6

Table-1 Hexadecimal keypad legend Interpretation Hexadecimal Key

Command Acronym

Name

Acronym

Name

0 EB / AX

EB

Examine Byte

AX

Accumulator

1 ER / BX

ER

Examine

BX

Base

2 GO / CX

GO

Go

CX

Count

3 ST / DX

ST

Single Step

DX

Data

4 IB / SP

IB

Input Byte

SP

Stack Pointer

5 OB / BP

OB

Output Byte

BP

Base Pointer

6 MV / SI

MV

Move

SI

Source Index

7 EW / DI

EW

Examine Word

DI

Source Index

8 IW / CS

IW

Input Word

CS

Code Segment

9 OW / DS

OW

Output Word

DS

Data Segment

A / SS

SS

Stack Segment

B / ES

ES

Extra Segment

C / IP

IP

Instruction Pointer

FL

Flag

D / FL

EB

Examine Byte

E F

SSN EC / BE – ECE / V ‘B’ / EC2308: Microprocessor and Microcontroller Lab

Page 3 of 6

Table-2 Function Key Operation

Function Key RESET

Operation The RESET key allows the to terminate any present activity and to return the kit to an initialized state. When pressed, a sign-on message appears in the display and the kit is ready for a command entry

KB / INT

The KB/INT key is used to generate an immediate, non-maskable type 2 interrupt

+

The + (plus) key allows the to add two hexadecimal values.

-

The - (minus) key allows the to subtract one hexadecimal value from another.

:

The : (colon) key is used to separate an address to be entered in two parts; a segment value and an offset value.

REG

The REG key allows the to use the contents of any of the Processor’s s as an address or data value.

NEXT (,)

The NEXT key is used to separate keypad entries and to increment the address field to the next consecutive memory locations

PREV

The PREV key is used to decrement the address field to previous memory location

EXEC (.)

The dot key is the command terminator. When pressed, the current command is executed.

SSN EC / BE – ECE / V ‘B’ / EC2308: Microprocessor and Microcontroller Lab

Page 4 of 6

Table-3 Summary of Monitor Commands Command Group Examine / Modify

Command Examine Byte

Function / Format Displays / modifies memory byte locations

EB

NEXT [[] NEXT or PREV]* Examine Word

Displays / modifies memory word locations

EW

, [[],] NEXT or PREV]* Examine

Displays / modifies processor contents

ER [[ ] NEXT [.] Input / Output

Input Byte

Displays the data byte at the input port

IB <port address> NEXT [NEXT]* Input Word

Displays the data word at the input port

IW <port address> NEXT [NEXT]* Output Byte

Outputs the data byte to the output port

OB <port address> NEXT [NEXT ]* Output Word

Outputs the data word to the output port

OW <port address> NEXT [NEXT ]* Execution

Step

Executes one single instruction

ST [<start address>] NEXT[[<start address>]NEXT]* Go

Transfers control from monitor to program

GO [

] [NEXT ] Block Move

Move

Moves block of data within memory

MV <start address> NEXT<end address> NEXT<destination address> Note: [X] – Indicates a keyboard key; [V] – Indicates “V” is optional; [V]* - Indicates one or more optional occurrences of “V”; - Indicates that “V” is a parameter to be entered by the .

SSN EC / BE – ECE / V ‘B’ / EC2308: Microprocessor and Microcontroller Lab

Page 5 of 6

8251: Programmable communication interface for serial communication ing all standard baud rates from 110 to 19200 I/O Addresses: FFF2 (Command / Status port) and FFF0 (Data port) 8259: Programmable interrupt controller provides interrupt vectors for 8 sources I/O Addresses: FFF4 (Command / Status port) and FFF6 (Data port) 8279: Keyboard / Display controller – Interfaces 4*8 matrix keyboard and 8-digit LED display I/O Addresses: FFEB (Command / Status port) and FFE9 (Data port) 8288: Bus-controller used to generate control signals 8284: Clock-generator used to generate clock for processor and associated peripherals INTERRUPTS External: NMI connected to INTR key switch of keyboard. INTR controlled by 8259A PIC for 8 sources. (8251 – TXRDY & RxRDY; 8253 – Out1 & Out2; 8255 – PC0 & PC3 in Handshake mode) Internal: Interrupt Vectors 1 (single step) and 3 (breakpoint) reserved for monitor. INTERFACING SIGNALS: U Bus: De-multiplexed and fully buffered, TTL compatible, Address, Data & Control signals are available on two 50-pin ribbon cable connectors. Parallel I/O: 48 programmable parallel I/O lines (TTL compatible) through two 26 pin ribbon cable connectors. Serial I/O: RS 232C through on-board 9-pin D-type female connector. POWER SUPPLY REQUIREMENT: +5V @ 3A (max) RESULT:

SSN EC / BE – ECE / V ‘B’ / EC2308: Microprocessor and Microcontroller Lab

Page 6 of 6
