Sydney Harbour Bridge

Coordinates: 33°51′08″S 151°12′38″E

From Wikipedia, the free encyclopedia

The Sydney Harbour Bridge is a steel through arch bridge across Sydney Harbour that carries rail, vehicular, bicycle and pedestrian traffic between the Sydney central business district (CBD) and the North Shore. The dramatic view of the bridge, the harbour, and the nearby Sydney Opera House is an iconic image of Sydney, and Australia. The bridge is nicknamed "The Coathanger" because of its arch-based design.[1][2] Under the directions of Dr J.J.C. Bradfield of the NSW Department of Public Works, the bridge was designed and built by BRITISH firm Dorman Long and Co Ltd of Middlesbrough and opened in 1932.[3][4] The bridge's design was influenced by the Hell Gate Bridge in New York.[5] It is also the sixth longest spanning-arch bridge in the world, and it is the tallest steel arch bridge, measuring 134 m (440 ft) from top to water level.[6] It was also the world's widest long-span bridge, at 48.8 m (160 ft) wide, until construction of the new Port Mann Bridge in Vancouver.[7][8]

Contents 1 Structure 1.1 Arch 1.2 Pylons 2 History 2.1 Early proposals 2.2 Planning 2.3 Construction 2.4 Opening 3 Operations 3.1 Road 3.2 Tidal flow 3.3 Tolls 3.4 Pedestrians 3.5 Cyclists 3.6 Rail 3.7 Maintenance 4 Tourism 4.1 South-east pylon 4.2 BridgeClimb 5 Celebrations 5.1 50th Anniversary celebrations (1982) http://en.wikipedia.org/wiki/Sydney_Harbour_Bridge

Sydney Harbour Bridge

Official name Sydney Harbour Bridge Carries

Trains, Motor vehicles, pedestrians and bicycles

Crosses

Port Jackson

Locale

Sydney, Australia

Design

Through arch bridge

Total length

1,149 m (3,770 ft)

Width

49 m (161 ft)

Height

134 m (440 ft)

Longest span 503 m (1,650 ft) Clearance below

49 m (161 ft) at mid-span

Construction 28 July 1923 begin Construction 19 January 1932 end Opened

19 March 1932

Coordinates

33°51′08″S 151°12′38″E

1/20

3/19/2014


5.2 Bicentennial Australia Day celebrations (1988) 5.3 Sydney New Year's Eve (1993–present) 5.4 Walk for Reconciliation (2000) 5.5 Sydney 2000 Olympics 5.6 Formula One promotion (2005) 5.7 75th anniversary (2007) 5.8 Breakfast on the Bridge (2009–10) 5.9 80th anniversary 6 Quotations 7 See also 8 References 8.1 Other sources 9 External links

Sydney Harbour from the air, showing the Opera House, the CBD, Circular Quay, the Bridge, the Parramatta River, North Sydney and Kirribilli in the foreground

Structure The southern (CBD) bridge end is located at Millers Point in The Rocks area, and the northern end at Milsons Point in the lower North Shore area. It carries the original six lanes of road traffic on its main roadway, plus two additional lanes of road trafffic on its eastern side (these lanes were formerly two tram tracks). The eastern path is a pedestrian footpath, and the western path is for bicycle use only. Finally, the two western lanes on the road deck are railway tracks, included in the original design. The main roadway across the bridge is known as the Bradfield Highway and is about 2.4 km (1.5 mi) long, making it one of the shortest highways in Australia.

Arch The arch is composed of two 28- arch trusses; their heights vary from 18 m (59 ft) at the centre of the arch to 57 m (187 ft) at the ends next to the pylons. The arch has a span of 504 m (1,654 ft) and its summit is 134 m (440 ft) above mean sea level; however, expansion of the steel structure on hot days can increase the height of the arch by as much as 18 cm (7.1 in).[9] Large steel pins (or bearings) each end of the arch, allowing it to rotate to accommodate expansion and contraction caused by changes of temperature, and avoiding stresses that would otherwise cause damage.

One of the nuts that hold the bridge on its abutments; this one is at the north end.

The total weight of the steelwork of the bridge, including the arch and approach spans, is 52,800 tonnes (52,000 long tons; 58,200 short tons), with the arch itself weighing 39,000 tonnes (38,000 long tons; 43,000 short tons).[10] About 79% of the steel was imported from England, with the rest being sourced from Newcastle.[11] On site, the contractors (Dorman Long and Co.) set up two workshops at Milsons Point, at the site of the present day Luna Park, and fabricated the steel into the girders and other required parts.[11]

http://en.wikipedia.org/wiki/Sydney_Harbour_Bridge

2/20

3/19/2014


The bridge is held together by six million Australian-made hand-driven rivets supplied by the Mherson company of Melbourne,[12][13] the last being driven through the deck on 21 January 1932.[11][14] The rivets were heated red-hot and inserted into the plates; the headless end was immediately rounded over with a large pneumatic rivet gun.[15] The largest of the rivets used weighed 3.5 kg (8 lb) and was 39.5 cm (15.6 in) long.[10][16] The practice of riveting large steel structures, rather than welding, was, at the time, a proven and understood construction technique, whilst structural welding had not at that stage been adequately developed for use on the bridge.[15]

Pylons At each end of the arch stands a pair of 89 m (292 ft) high concrete pylons, faced with granite.[17] The pylons were designed by the Scottish architect Thomas S. Tait,[18] a partner in the architectural firm John Burnet & Partners.[19] Some 250 Australian, Scottish, and Italian stonemasons and their families relocated to a temporary settlement at Moruya, NSW, 300 km (186 mi) south of Sydney, where they quarried around 18,000 m3 (635,664 cu ft) of granite for the bridge pylons.[11] The stonemasons cut, dressed, and numbered the blocks, which were then transported to Sydney on three ships built specifically for this purpose.[11] The concrete used was also Australian-made.[citation needed] Abutments at the base of the pylons are essential to the loads from the arch and hold its span firmly in place, however, the pylons themselves have no structural purpose. They were included to provide a frame for the arch s and to give better visual balance to the bridge. The pylons were not part of the original design, and were only added to allay public concern about the structural integrity of the bridge.[20]

The south-eastern pylon containing the tourist lookout, made of granite quarried at Moruya, NSW

Although originally added to the bridge solely for their aesthetic value, all four pylons have now been put to use. The south-eastern pylon contains a museum and tourist centre, with a 360° lookout at the top providing views across the harbour and city. The south-western pylon is used by the New South Wales Roads and Traffic Authority (RTA) to its CCTV cameras overlooking the bridge and the roads around that area. The two pylons on the north shore include venting chimneys for fumes from the Sydney Harbour Tunnel, with the base of the southern pylon containing the RMS maintenance shed for the bridge, and the base of the northern pylon containing the traffic management shed for tow trucks and safety vehicles used on the bridge.[citation needed] In 1942 the pylons were modified to include parapets and anti-aircraft guns designed to assist in both Australia's defence and general war effort.[citation needed]The top level of stonework was never removed.[citation needed][21]

History Early proposals There had been plans to build a bridge as early as 1815, when convict and noted architect Francis Greenway reputedly proposed to Governor Lachlan Macquarie that a bridge be built from the northern to the southern shore of the harbour.[6][22] In 1825, Greenway wrote a letter to the then "The Australian" newspaper stating that such a bridge http://en.wikipedia.org/wiki/Sydney_Harbour_Bridge

3/20

3/19/2014


would "give an idea of strength and magnificence that would reflect credit and glory on the colony and the Mother Country".[22] Nothing came of Greenway's suggestions, but the idea remained alive, and many further suggestions were made during the nineteenth century. In 1840, naval architect Robert Brindley proposed that a floating bridge be built. Engineer Peter Henderson produced one of the earliest known drawings of a bridge across the harbour around 1857. A suggestion for a truss bridge was made in 1879, and in 1880 a high-level bridge estimated at $850,000 was proposed.[22] In 1900, the Lyne government committed to building a new Central railway station and organised a worldwide competition for the design and construction of a harbour bridge. Local engineer Norman Selfe submitted a design for a suspension bridge and won the second prize of £500. In 1902, when the outcome of the first competition became mired in controversy, Selfe won a second competition outright, with a design for a steel cantilever bridge. The selection board were unanimous, commenting that, "The structural lines are correct and in true proportion, and... the outline is graceful".[23] However due to an economic downturn and a change of government at the 1904 NSW State election construction never began.[citation needed]

Planning In 1914 J.J.C. Bradfield was appointed "Chief Engineer of Sydney Harbour Bridge and Metropolitan Railway Construction", and his work on the project over many years earned him the legacy as the "father" of the bridge.[3] Bradfield's preference at the time was for a cantilever bridge without piers, and in 1916 the NSW Legislative Assembly ed a bill for such a construction, however it did not proceed as the Legislative Council rejected the legislation on the basis that the money would be better spent on the war effort.[22]

Sketches of designs submitted when tenders were called for a harbour crossing in 1900

Norman Selfe's winning design at the second competition c.1903

Following World War I, plans to build the bridge again built momentum.[6] Bradfield persevered with the project, fleshing out the details of the specifications and financing for his cantilever bridge proposal, and in 1921 he travelled overseas to investigate tenders. On return from his travels Bradfield decided that an arch design would also be suitable[22] and he and officers of the NSW Department of Public Works prepared a general design[3][6] for a single-arch bridge based upon New York City's Hell Gate Bridge.[5][24] In 1922 the government ed the Sydney Harbour Bridge Act No. 28, specifying the construction of a high-level cantilever or arch bridge across the harbour between Dawes Point and Milsons Point, along with construction of necessary approaches and electric railway lines,[22] and worldwide tenders were invited for the project.[3] As a result of the tendering process, the government received twenty proposals from six companies; on 24 March 1924 the contract was awarded to English firm Dorman Long and Co Ltd, of Middlesbrough well known as the contractors who built the similar Tyne Bridge of Newcastle Upon Tyne, for an arch bridge at a quoted price of AU £4,217,721 11s 10d.[3][22] The arch design was cheaper than alternative cantilever and suspension bridge proposals, and also provided greater rigidity making it better suited for the heavy loads expected.[22] http://en.wikipedia.org/wiki/Sydney_Harbour_Bridge

4/20

3/19/2014


To offset concerns about a foreign firm participating in the project, assurances were given by Bradfield that the workforce building the bridge would all be Australians.[citation needed] Bradfield and his staff were ultimately to oversee the entire bridge design and building process, while Dorman Long and Co's Consulting Engineer, Sir Ralph Freeman of Sir Douglas Fox and Partners, and his associate Mr. G.C. Imbault, carried out the detailed design and erection process of the bridge.[3] Architects for the contractors were from the British firm John Burnet & Partners of Glasgow, Scotland.[19] The building of the bridge coincided with the construction of a system of underground railways in Sydney's CBD, known today as the City Circle, and the bridge was designed with this in mind. The bridge was designed to carry six lanes of road traffic, flanked on each side by two railway tracks and a footpath. Both sets of rail tracks were linked into the underground Wynyard railway station on the south (city) side of the bridge by symmetrical ramps and tunnels. The eastern-side railway tracks were intended for use by a planned rail link to the Northern Beaches;[citation needed] in the interim they were used to carry trams from the North Shore into a terminal within Wynyard station, and when tram services were discontinued in 1958, they were converted into extra traffic lanes. The Bradfield Highway, which is the main roadway section of the bridge and its approaches, is named in honour of Bradfield's contribution to the bridge.

Construction The building of the bridge was under the management of Bradfield. Three other people heavily involved in the bridge's design and construction were Lawrence Ennis, Edward Judge, and Sir Ralph Freeman. Ennis was the engineer-in-charge at Dorman Long and Co and the main on-site supervisor (Bradfield visited occasionally throughout the project and, in particular, at many key stages of the project, to inspect progress and make managerial decisions), Judge was chief technical engineer of Dorman Long, and Freeman was hired by the company to design the accepted model in further detail. Later a bitter disagreement broke out between Bradfield and Freeman as to who actually designed the bridge. Another name connected with the bridge's design is that of Arthur Plunkett.[citation needed]

Sydney Harbour Bridge under construction

The official ceremony to mark the "turning of the first sod" occurred on 28 July 1923, on the spot at Milsons Point on the north shore where two workshops to assist in building the bridge were to be constructed.[25] An estimated 469 buildings on the north shore, both private homes and commercial operations, were demolished to allow construction to proceed, with little or no compensation being paid. Work on the bridge itself commenced with the construction of approaches and approach spans, and by September 1926 concrete piers to the approach spans were in place on each side of the harbour.[25] As construction of the approaches took place, work was also started on preparing the foundations required to the enormous weight of the arch and loadings. Concrete and granite faced abutment towers were constructed, with the angled foundations built into their sides.[25]


The arch being constructed. Courtesy, State Library of New South Wales

5/20

3/19/2014


Once work had progressed sufficiently on the structures, a giant "creeper crane" was erected on each side of the harbour.[26] These cranes were fitted with a cradle, and then used to hoist men and materials into position to allow for erection of the steelwork. To stabilise works while building the arches, tunnels were excavated on each shore with steel cables ed through them and then fixed to the upper sections of each half-arch to stop them collapsing as they extended outwards.[25] Arch construction itself began on 26 October 1928. The southern end of the bridge was worked on ahead of the northern end, to detect any errors and to help with alignment. The cranes would "creep" along the arches as they were constructed, eventually John Bradfield riding the first test HMAS Canberra sailing under the meeting up in the middle. In less train across the bridge on 19 January completed arch from which the deck than two years, on Tuesday, 19 1932 is being suspended in 1930 August 1930, the two-halves of the arch touched for the first time. Workers riveted both top and bottom sections of the arch together, and the arch became self-ing, allowing the cables to be removed. On 20 August 1930 the ing of the arches was celebrated by flying the flags of Australia and the United Kingdom (Australia being very much part of the British Commonwealth) from the jibs of the creeper cranes.[25] Once the arch was completed, the creeper cranes were then worked back down the arches, allowing the roadway and other parts of the bridge to be constructed from the centre out. The vertical hangers were attached to the arch, and these were then ed with horizontal crossbeams. The deck for the roadway and railway were built on top of the crossbeams, with the deck itself being completed by June 1931, and the creeper cranes were dismantled. Rails for trains and trams were laid, and road was surfaced using concrete topped with asphalt.[25] Power and telephone lines, and water, gas, and drainage pipes were also all added to the bridge in 1931.[citation needed] The pylons were built atop the abutment towers, with construction advancing rapidly from July 1931. Carpenters built wooden scaffolding, with concreters and masons then setting the masonry and pouring the concrete behind it. Gangers built the steelwork in the towers, while day labourers manually cleaned the granite with wire brushes. The last stone of the north-west pylon was set in place on 15 January 1932, and the timber towers used to the cranes were removed.[17][25] On 19 January 1932, the first test train, a steam locomotive, safely crossed the bridge.[citation needed] Load testing of the bridge took place in February 1932, with the four rail tracks being loaded with as many as 96 steam locomotives positioned end-to-end. The bridge underwent testing for three weeks, after which it was declared safe and ready to be opened.[25] The construction worksheds were demolished after the bridge was completed, and the land that they were on is now occupied by Luna Park.[citation needed] The standards of industrial safety during construction were poor by today's standards. Sixteen workers died during construction,[27] but surprisingly only two from falling off the bridge. Several more were injured from unsafe working practices undertaken whilst heating and inserting its rivets, and the deafness experienced by many of the workers in later years was blamed on the project. Henri Mallard between 1930 and 1932 produced hundreds of stills[28] and film footage[29] which reveal at close quarters the bravery of the workers in tough Depression-era conditions.[citation needed] http://en.wikipedia.org/wiki/Sydney_Harbour_Bridge

6/20

3/19/2014


The total financial cost of the bridge was AU£6.25 million, which was not paid off in full until 1988.[30]

Opening The bridge was formally opened on Saturday, 19 March 1932.[31] Amongst those who attended and gave speeches were the state Governor, Sir Philip Game, the Minister for Public Works, and Lawrence Ennis. The Labor Premier of New South Wales, Jack Lang, was to open the bridge by cutting a ribbon at its southern end.[citation needed] However, just as Lang was about to cut the ribbon, a man in military uniform rode up on a horse, slashing the ribbon with his sword and opening the Sydney Harbour Bridge in the name of the people of New South Wales before the official ceremony began. He was promptly arrested.[32] The ribbon was hurriedly retied and Lang performed the official opening ceremony. After he did so, there was a 21-gun salute and an RAAF flypast. The intruder was identified as Francis de Groot. He was convicted of offensive behaviour and fined £5 after a psychiatric test proved he was sane, but this verdict was reversed on appeal. De Groot then successfully sued the Commissioner of Police for wrongful arrest, and was awarded an Francis de Groot declares the bridge undisclosed out of court settlement. De Groot was a member of a right-wing open paramilitary group called the New Guard, opposed to Lang's leftist policies and resentful of the fact that a member of the Royal Family had not been asked to open the bridge.[32] De Groot was not a member of the regular army but his uniform allowed him to blend in with the real cavalry. This incident was one of several involving Lang and the New Guard during that year.[citation needed] A similar ribbon-cutting ceremony on the bridge's northern side by North Sydney's mayor, Alderman Primrose, was carried out without incident. It was later discovered that Primrose was also a New Guard member but his role in and knowledge of the de Groot incident, if any, are unclear.[citation needed] The pair of golden scissors used in the ribbon cutting ceremonies on both sides of the bridge was also used to cut the ribbon at the dedication of the Bayonne Bridge, which had opened in Bayonne, New Jersey, close to New York City, the year before.[33][34] Despite the bridge opening in the midst of the Great Depression, opening celebrations were organised by the Citizens of Sydney Organising Committee, an influential body of prominent men and politicians that formed in 1931 under the chairmanship of the Lord Mayor to oversee the festivities. The celebrations included an array of decorated floats a procession of enger ships sailing below the bridge, and a Venetian Carnival.[22] A message from a primary school in Tottenham, 515 km (320 mi) away in rural New South Wales, arrived at the bridge on the day and was presented at the opening ceremony. It had been carried all the way from Tottenham to the bridge by relays of school children, with the final relay being run by two children from the nearby Fort Street Boys' and Girls' schools. The City of Sydney organising Committee[35] also announced plans for a Great Eisteddfod. Lord Mayor Samuel Walder (http://adb.anu.edu.au/biography/walder-sir-samuel-robert-1096) told the press that the competition would begin at the Town Hall in August 1933 and thus began the Sydney Eisteddfod.[citation needed] After the official ceremonies, the public was allowed to walk across the bridge on the deck, something that would not be repeated until the 50th anniversary celebrations.[22] Estimates suggest that between 300,000 and one million people took part in the opening festivities,[22] a phenomenal number given that the entire population of Sydney at the time was only a little over a million people.[citation needed]


7/20

3/19/2014


There had also been numerous preparatory arrangements. On 14 March 1932, three postage stamps were issued to commemorate the imminent opening of the bridge. Several songs were composed for the occasion.[citation needed] The bridge itself was regarded as a triumph over Depression times, earning the nickname "the Iron Lung", as it kept many Depression-era workers employed.[citation needed]

Operations Road Main article: Bradfield Highway, Sydney From the Sydney CBD side, motor vehicle access to the bridge is normally via Grosvenor Street, Clarence Street, Kent Street, the Cahill Expressway, or the Western Distributor. Drivers on the northern side will find themselves on the Warringah Freeway, though it is easy to turn off the freeway to drive westwards into North Sydney or eastwards to Neutral Bay and beyond upon arrival on the northern side.[citation needed] The bridge originally only had four wider traffic lanes occupying the central space which now has six, as photos taken soon after the opening clearly show. In 1958 tram services across the bridge were withdrawn and the tracks replaced by two extra road lanes; these lanes are now the leftmost southbound lanes on the bridge and are still clearly distinguishable from the other six road lanes. Lanes 7 and 8 now connect the bridge to the elevated Cahill Expressway that carries traffic to the Eastern Distributor.[citation needed] In 1988, work began to build a tunnel to complement the bridge. It was determined that the bridge could no longer the increased traffic flow of the 1980s. The Sydney Harbour Tunnel was completed in August 1992. It is intended for use only by motor vehicles.[citation needed]

The roadway of the bridge, from the southern or city approach. From left: walkway, eight traffic lanes (the two leftmost once carried the Sydney trams), two railway tracks, and cycleway. The gantries with lights controlling traffic tidal flow are clearly visible, while the tollbooths can be seen near the bases of the high-rise buildings

The Bradfield Highway is designated as a Travelling Stock Route which means that it is permissible to herd livestock across the bridge, but only between midnight and dawn, and after giving notice of intention to do so. In practice, owing to the high-density urban nature of modern Sydney, and the relocation of abattoirs and markets, this has not taken place for approximately half a century.[citation needed]

Tidal flow The bridge is equipped for tidal flow operation, permitting the direction of traffic flow on the bridge to be altered to better suit the morning and evening rush hours' traffic patterns.[citation needed] The bridge has eight lanes in total, numbered one through eight from west to east. Lanes three, four and five are reversible. One and two always flow north. Six, seven, and eight always flow south. The default is four each way. For the morning rush hour, the lane changes on the bridge also require changes to the Warringah Freeway, with its inner western reversible carriageway directing traffic to the bridge lane numbers three and four southbound.[citation needed] http://en.wikipedia.org/wiki/Sydney_Harbour_Bridge

8/20

3/19/2014


The bridge has a series of overhead gantries which indicate the direction of flow for each traffic lane. A green arrow pointing down to a traffic lane means the lane is open. A flashing red "X" indicates the lane is closing, but is not yet in use for traffic travelling in the other direction. A static red "X" means the lane is in use for oncoming traffic. This arrangement was introduced in the 1990s, replacing a slow operation where lane markers were manually moved to mark the centre median.[citation needed] It is possible to see odd arrangements of flow during night periods when maintenance occurs, which may involve completely closing some lanes. Normally this is done between midnight and dawn, because of the enormous traffic demands placed on the bridge outside these hours.[citation needed]

Tolls The vehicular traffic lanes on the bridge are operated as a toll road. As of 27 January 2009 there is a variable tolling system for all vehicles headed into the CBD (southbound). The toll paid is dependent on the time of day in which the vehicle es through the toll plaza. The toll varies from a minimum value of $2.50 to a maximum value of $4.[36] There is no toll for northbound traffic (though taxis travelling north may charge engers the toll in anticipation of the toll the taxi must pay on the return journey). There are toll plazas at the northern and southern ends. The two eastern lanes (which continue over the Cahill Expressway at the southern end of the bridge) have their tollbooths at the northern end, while the other southbound lanes (for CBD traffic) are serviced by tollbooths at the southern end of the bridge. There is a bridge-long median strip between lanes 6 and 7 to separate traffic which has already paid the toll (at the northern end) from other southbound traffic (which must pay the toll at the southern end).[citation needed] The toll was originally placed on travel across the bridge, in both directions, to recoup the cost of its construction. This cost was recovered in the 1980s, but the toll has been kept (indeed increased) by the state government's Roads and Traffic Authority to recoup the costs of the Sydney Harbour Tunnel.[citation needed] After the decision to build the Sydney Harbour Tunnel was made in the early 1980s, the toll was increased (from 20 cents to $1, then to $1.50, and finally to $2 by the time the tunnel opened) to pay for its construction. The tunnel also had an initial toll of $2 southbound. After the increase to $1, the concrete barrier on the bridge separating the Bradfield Highway from the Cahill Expressway was increased in height, because of the large numbers of drivers crossing it illegally from lane 6 to 7, to avoid the toll. The toll for all southbound vehicles was increased to $3 in March 2004.[citation needed] Originally it cost a car or motorcycle six pence to cross, a horse and rider being three pence. Use of the bridge by bicycle riders (provided that they use the cycleway) and by pedestrians is free. Later governments capped the fee for motorcycles at one-quarter of the enger-vehicle cost, but now it is again the same as the cost for a enger vehicle.[citation needed] In July 2008 a new electronic tolling system called e-TAG was introduced. The Sydney Harbour Tunnel was converted to this new tolling system while the Sydney Harbour Bridge itself had several cash lanes. The electronic system as of 12 January 2009 has now replaced all booths with E-tag lanes.[37]

Pedestrians The pedestrian only footway is located on the east side of the bridge. Access from the northern side involves climbing an easily-spotted flight of stairs, located on the east side of the bridge at Broughton St, Kirribilli. Pedestrian access on the southern side is more complicated, but signposts in the Rocks area now direct pedestrians to the long and


9/20

3/19/2014


sheltered flight of stairs that leads to the bridge's southern end. These stairs are located near Gloucester Street and Cumberland Street.[citation needed] The bridge can also be approached from the south by accessing Cahill Walk, which runs along the Cahill Expressway. Pedestrians can access this walkway from the east end of Circular Quay by a flight of stairs or a lift. Alternatively it can be accessed from the Botanic Gardens.[citation needed]

Cyclists The bike only cycleway is located on the west side of the bridge. Access from the northern side involves carrying or pushing a bicycle up a staircase, consisting of 55 steps, located on the west side of the bridge at Burton St, Milsons Point. A campaign to eliminate the steps on this popular cycling route to the CBD has been running since at least 2008.[38][39] Cyclist access on the southern side is via the north end of the Kent St. cycleway and/or Upper Fort St.[citation needed]

Rail The bridge lies between Milsons Point and Wynyard railway stations, located on the north and south shores respectively, with two tracks running along the western side of the bridge. These tracks are part of the North Shore railway line.[citation needed] In 1958 tram services across the bridge were withdrawn and the tracks they had used were removed and replaced by two extra road lanes; these lanes are now the leftmost southbound lanes on the bridge and are still clearly distinguishable from the other six road lanes. The original ramp that took the trams into their terminus at the underground Wynyard railway station is still visible at the southern end of the main walkway under lanes 7 and 8, although the tunnels have been converted into a car park and firing range.[citation needed]

First enger train crossing the bridge, 19 March 1932

Maintenance The Sydney Harbour Bridge requires constant inspections and other maintenance work to keep it safe for the public, and to protect from corrosion. Among the trades employed on the bridge are painters, ironworkers, boilermakers, fitters, electricians, plasterers, carpenters, plumbers, and riggers.[24] The most noticeable maintenance work on the bridge involves painting. The steelwork of the bridge that needs to be painted is a combined 485,000 m2 (120 acres), the equivalent of sixty football fields. Each coat on the bridge requires some 30,000 l (6,600 imp gal) of paint.[24] A special fast-drying Maintenance crew painting the bridge paint is used, so that any paint drops have dried before reaching the vehicles or bridge surface.[16] One notable identity from previous bridge-painting crews is Australian comedian and actor Paul Hogan, who worked as a bridge painter before rising to media fame in the 1970s.[6] http://en.wikipedia.org/wiki/Sydney_Harbour_Bridge

10/20

3/19/2014


In 2003 the Roads & Traffic Authority began completely repainting the southern approach spans of the bridge. This involved removing the old lead-based paint, and repainting the 90,000 m2 (22 acres) of steel below the deck. Workers operated from self-contained platforms below the deck, with each platform having an air extraction system to filter airborne particles. An abrasive blasting was used, with the lead waste collected and safely removed from the site for disposal.[24]

Tourism South-east pylon Even during its construction, the bridge was such a prominent feature of Sydney that it would attract tourist interest. One of the ongoing tourist attractions of the bridge has been the south-east pylon, which is accessed via the pedestrian walkway across the bridge, and then a climb to the top of the pylon of about 200 steps.[14] Not long after the bridge's opening, commencing in 1934, Archer Whitford first converted this pylon into a tourist destination.[40] He installed a number of attractions, including a café, a camera obscura, an Aboriginal museum, a "Mother's Nook" where visitors could write letters, and a "pashometer". The main attraction was the viewing platform, where "charming attendants" assisted visitors to use the telescopes available,[40] and a copper cladding (still present) over the granite guard rails identified the suburbs and landmarks of Sydney at the time.[41]

Historic tourist signs for the pylon lookout, from Rentoul's 'All Australian Exhibition', 1948 – 1971

The outbreak of World War II in 1939 saw tourist activities on the bridge cease, as the military took over the four pylons and modified them to include parapets and anti-aircraft guns.[42] BridgeClimb participants, wearing the

In 1948 Yvonne Rentoul opened the "All Australian Exhibition" in the pylon. mandatory special jumpsuits This contained dioramas, and displays about Australian perspectives on subjects such as farming, sport, transport, mining, and the armed forces. An orientation table was installed at the viewing platform, along with a wall guide and binoculars. The owner kept several white cats in a rooftop cattery, which also served as an attraction, and there was a souvenir shop and postal outlet.[43] Rentoul's lease expired in 1971, and the pylon and its lookout remained closed to the public for over a decade.[44] The pylon was reopened in 1982, with a new exhibition celebrating the bridge's 50th anniversary.[45] In 1987 a "Bicentennial Exhibition" was opened to mark the 200th anniversary of European settlement in Australia in 1988.[46] The pylon was closed from April to November 2000 for the Roads & Traffic Authority and BridgeClimb to create a new exhibition called "Proud Arch". The exhibition focussed on Bradfield, and included a glass direction finder on the observation level, and various important heritage items.[47] The pylon again closed for four weeks in 2003 for the installation of an exhibit called "Dangerous Works", highlighting the dangerous conditions experienced by the original construction workers on the bridge, and two stained glass feature windows in memory of the workers.[48]

BridgeClimb http://en.wikipedia.org/wiki/Sydney_Harbour_Bridge

11/20

3/19/2014


In 1950s and 1960s there were occasional newspaper reports of climbers who had made illegal arch traversals of the bridge, invariably by night. In 1973 Philippe Petit walked across a wire between the two pylons at the southern end of the Sydney Harbour Bridge. Since 1998, BridgeClimb[49] has made it possible for tourists to legally climb the southern half of the bridge. Tours run throughout the day, from dawn to night, and are only cancelled for electrical storms or high wind.[citation needed] Groups of climbers are provided with protective clothing appropriate to the prevailing weather conditions, and are given an orientation briefing before climbing. During the climb, attendees are secured to the bridge by a wire lifeline. Each climb begins on the eastern side of the bridge and ascends to the top. At the summit, the group crosses to the western side of the arch for the descent. Each climb takes three-and-a-half-hours, including the preparations.[citation needed]

BridgeClimbers ire the view midclimb, while a second group reach the top of the arch. Note also the light fixtures and extensive use of rivets

In December 2006, BridgeClimb[49] launched an alternative to climbing the upper arches of the bridge. The Discovery Climb allows climbers to ascend the lower chord of the bridge and view its internal structure. From the apex of the lower chord, climbers ascend a staircase to a platform at the summit.[citation needed]

Celebrations Since the opening, the bridge has been the focal point of much tourism and national pride.[citation needed]

50th Anniversary celebrations (1982) In 1982 the bridge celebrated the 50th anniversary of its opening. For the first time since its opening in 1932, the bridge was closed to vehicles, and pedestrians were allowed full access for the day.[11] The celebrations were attended by Edward Judge, who represented Dorman Long.[citation needed]

Bicentennial Australia Day celebrations (1988) Australia's bicentennial celebrations on 26 January 1988 attracted large crowds in the bridge's vicinity as merrymakers flocked to the foreshores to view the events on the harbour. The highlight was the biggest parade of sail ever held in Sydney, square-riggers from all over the world, surrounded by hundreds of smaller craft of every description, ing majestically under the Sydney Harbour Bridge. The day's festivities culminated in a fireworks display in which the bridge was the focal point of the finale, with fireworks streaming from the arch and roadway. This was to become the pattern for later firework displays.[citation needed]

Postage stamp, Australia, 1932

Sydney New Year's Eve (1993–present) Main article: Sydney New Year's Eve http://en.wikipedia.org/wiki/Sydney_Harbour_Bridge

12/20

3/19/2014


The Harbour Bridge is an integral part of the Sydney New Year's Eve celebrations, generally being used in spectacular ways during the fireworks displays at 9:00 P.M. and midnight. In recent times, the bridge has included a ropelight display on a framework in the centre of the eastern arch, which is used to complement the fireworks. As the scaffolding and framework are clearly visible for some weeks before the event, revealing the outline of the design, there is much speculation as to how the effect is to be realised. During the millennium celebrations in 2000, the Sydney Harbour Bridge was lit up with the word "Eternity", as a tribute to the legacy of Arthur Stace a Sydney artist who for many years inscribed that word on pavements in chalk in beautiful copperplate writing despite the fact that he was illiterate.[citation needed] The effects have been as follows:[citation needed] NYE1997: Smiley face; NYE1999: The word "Eternity" in copperplate writing, NYE2000: Rainbow Serpent and Federation Star; NYE2001: Uluru, the Southern Cross and the Dove of Peace; NYE2002: Dove of Peace and the word "PEACE". NYE2003: Light show; NYE2004: "Fanfare"; NYE2005: Three concentric hearts NYE2006: Coathanger and a diamond NYE2007: Mandala; NYE2008: The Sun NYE2009: Taijitu Symbol, a Blue moon and a ring of fire NYE2010: Handprint, "X" Mark and a Spot NYE2011: Thought Bubble, Sun and Endless Rainbow NYE2012: Butterfly and a Lip NYE2013: Eye

The opening sequence to the 2008–09 Midnight Fireworks, using the Sun for its bridge effect.

The numbers for the New Year's Eve countdown also appear on the eastern side of the Bridge pylons.[citation needed]

Walk for Reconciliation (2000) In May 2000 the bridge was closed to vehicular access for a day to allow a special reconciliation march—the "Walk for Reconciliation"—to take place. This was part of a response to an Aboriginal Stolen Generations inquiry, which found widespread suffering had taken place amongst Australian Aboriginal children forcibly placed into the care of white parents in a little-publicised state government scheme. Between 200,000 and 300,000 people were estimated to have walked the bridge in a symbolic gesture of crossing a divide.[50]

Sydney 2000 Olympics During the Sydney 2000 Olympics in September and October 2000, the bridge was adorned with the Olympic Rings. It was included in the Olympic torch's route to the Olympic stadium. The men's and women's Olympic marathon events likewise included the bridge as part of their route to the Olympic stadium. A fireworks display at the end of the closing ceremony ended at the bridge. The east-facing side of the bridge has been used several times since as a framework from which to hang static fireworks, especially during the elaborate New Year's Eve displays.[citation needed] http://en.wikipedia.org/wiki/Sydney_Harbour_Bridge

13/20

3/19/2014


Formula One promotion (2005) In 2005 Mark Webber drove a Williams-BMW Formula One car across the bridge.[51]

75th anniversary (2007) In 2007, the 75th anniversary of its opening was commemorated with an exhibition at the Museum of Sydney, called "Bridging Sydney".[52] An initiative of the Historic Houses Trust, the exhibition featured dramatic photographs and paintings with rare and previously unseen alternative bridge and tunnel proposals, plans and sketches.[citation needed] On 18 March 2007, the Sydney Harbour Bridge celebrated its 75th anniversary. The occasion was marked with a ribbon-cutting ceremony by the governor, Marie Bashir and the premier of New South Wales, Morris Iemma. The bridge was subsequently open to the public to walk southward from Milsons Point or North Sydney. Several major roads, mainly in the CBD, were closed for the day. An Aboriginal smoking ceremony was held at 7 pm.[citation needed] Approximately 250,000 people (50,000 more than were ed) took part in the event. Bright yellow souvenir caps were distributed to walkers. A series of speakers placed at intervals along the bridge formed a sound installation. Each group of speakers broadcast sound and music from a particular era (e.g. King Edward VIII's abdication speech; Gough Whitlam's speech at Parliament House in 1975), the overall effect being that the soundscape would "flow" through history as walkers proceeded along the bridge. A light-show began after sunset and continued late into the night, the bridge being bathed in constantly changing, multi-coloured lighting, designed to highlight structural features of the bridge. In the evening the bright green caps were replaced by orange caps with a small, bright LED attached. The bridge was closed to walkers at about 8.30 p.m.[citation needed]

Walkers with LED caps on the bridge's 75th Anniversary

The commemorative hats given to walkers

Breakfast on the Bridge (2009–10) On 25 October 2009 turf was laid across the eight lanes of bitumen, and 6,000 people celebrated a picnic on the bridge accompanied by live music.[53] The event was repeated in 2010.[54] Although originally scheduled again in 2011, this event was moved to Bondi Beach due to traffic concerns about the prolonged closing of the bridge.[55][56]

80th anniversary


14/20

3/19/2014


On 19 March 2012 the 80th anniversary of the Sydney Harbour Bridge was celebrated with a picnic dedicated to the stories of people with personal connections to the bridge.[57] In addition, Google dedicated its Google Doodle on the 19th to the event.[58] The proposal to upgrade the bridge tolling equipment was announced by the NSW Roads Minister Duncan Gay.[59]

Quotations

“

There the proud arch Colossus like bestride Yon glittering streams and bound the strafing tide.

”

Prophetic observation of Sydney Cove by Erasmus Darwin, grandfather of Charles Darwin, from his poem "Visit of Hope to Sydney Cove, near Botany Bay", (1789).

“

I open this bridge in the name of His Majesty the King and all the decent citizens of NSW.

”

Francis de Groot "opening" the Sydney Harbour Bridge, (1932). His organisation, the New Guard, had resented the fact that King George V had not been asked to open the bridge.[citation needed]

“

To get on in Australia, you must make two observations. Say, "You have the most beautiful bridge in the world" and "They tell me you trounced England again in the cricket." The first statement will be a lie. Sydney Bridge [sic] is big, utilitarian and the symbol of Australia, like the Statue of Liberty or the Eiffel Tower. But it is very ugly. No Australian will it this.

The "International Historic Civil Engineering Landmark" plaque presented to Sydney Harbour Bridge by the American Society of Civil Engineers in 1988

”

James Michener assessing the Sydney Harbour Bridge in his book "Return to Paradise", (1951).

“

...you can see it from every corner of the city, creeping into frame from the oddest angles, like an uncle who wants to get into every snapshot. From a distance it has a kind of gallant restraint, majestic but not assertive, but up close it is all might. It soars above you, so high that you could a tenstorey building beneath it, and looks like the heaviest thing on earth. Everything that is in it – the stone blocks in its four towers, the latticework of girders, the metal plates, the six-million rivets (with heads like halved apples) – is the biggest of its type you have ever seen... This is a great bridge.

”

American travel-writer Bill Bryson's impressions of the Sydney Harbour Bridge in his book "Down Under", (2000).[60]


15/20

3/19/2014


Sydney Harbour Bridge as viewed from Kirribilli on the North Shore, with the Sydney Opera House on the left.

See also Australian landmarks List of the largest arch bridges
