ADVANCED TOLL MANAGEMENT SYSTEM
INTRODUCTION
Toll management systems play an important role in the growth of infrastructure all over the world. It is a kind of the money that a commuter has to pay to the road authorities while ing from one city to another. This in turn is a kind of tax that is used in the construction of roads, flyovers, and expressways.Tolling is a highly effective strategy for dealing with some of today’s most pressing transportation issues. Toll facilities help reduce congestion and improve mobility, and provide an additional source of funding for local construction and maintenance projects.
This Application can provide all the information related to Toll booth and the enger checks in online and pays the amount,with the help of android application the system through bluetooth ,then the identity of the and then the vehicle. After the verification the system will automatically open the toll gate
Toll App is a mobile application developed for automatic and easy payment in Toll gates. Toll App is a useful and convenient application that spares you the trouble of stopping your vehicle and makes the payment in Toll gate. This application helps people to automatically pay their charge while crossing toll fences. The application which we develop here uses state of the art technology to track ’s location accurately and secure payment. Toll gates are created as virtual geo-fences using this App and the cost of crossing the fence is defined. The is tracked via his bluetooth enabled device and the payment is made automatically from his credits purchased.
objective
Will allow people to pay their highway tolls online without needing to stop at the toll plazas. Cashless transaction at toll plazas. Relief to commuters on national highways(NHs). Cut down the travelling time on highways. Plug revenue leakages from toll collection. To improve quality of work and accuracy. To improve work speed and accuracy. To provide the easy and friendly environment. Get instant and detail information at single terminal.
Existing system
In existing system, current times of increasing traffic on the road, it is important to collect the toll tax in a managed and controlled process so that it doesn't result in a total unorganized jungle of traffic. It is very challenging to handle a vehicular flow by a manual system of revenue collection. Poor management at toll plaza may result into great chaos and revenue loss. This would not be desired any one.
DRAWBACKS
It was very time consuming
Reports were generated manually.
The Activities are often prone to errors.
The speed of processing of data is very slow.
The information required was not readily available.
Lots of paper work was there.
Proposed system
Toll lane capacity:Vehicles online gate require less time to conduct a toll transaction.
Reduction in vehicle waiting times: An increase in a toll lane service rate causes a decrease in the average waiting time of vehicles at the toll plaza.
Reduction of vehicle emission:Vehicle emissions are reduced as vehicle speeds through the toll plaza are increased and accelerations and decelerations reduced.
Simplified infrastructure and ing system: Requires for less road side infrastructure than manual tollbooths. It simplifies the ing system as well as the allocation of revenue between peak and non-peak hours by automating toll collection and vehicle counting.
Reduction of toll costs :Reduces the cost of processing toll transactions.
Easy to Commute:With the construction and improvement of many roads, flyover, and bridges, the commuting has become easy. The improved and smooth roads and bridges have made commuting an easy job.
The android app with , request the server for current status and then inform the tool booth system was the toll paid or not.
Traffic Control and Security: With the introduction of new equipment’s and techniques in a toll system, there is a constant control on the traffic running on roads and highways. Moreover, now commuters also feel secure while driving on road.
The growing demand for Toll Collection systems has increasingly shifted focus towards optimization in the areas of efficiency, faster service, and cost.
Module description There are four basic s – , customer,staff and higher authority. Staff Management a)Add staff. b)Edit/Delete staff. Customer Management a)Add,View and search customer. b)Amount,update and collection views. c)View complaints and . Toll gate and Route Management a)Add gates and routes.
Staff provide the notification message to the logged s via webpage. View collection. View payment details Give Approval for the request that had been sent by the customer for toll gate authentication Vehicle Management a) vehicles.
Customer Provide identities in the website. View history about payments made. Receive notification about the charges when he crosses the fences that created in Toll app. Give complaints to the concerned people.
Gate management
a)Route and
booking
b)cancellation View toll gate
Higher Authority Has the right to give approval for the request that had been send by the for new toll booth creation .
PHP Modules:
Toll payment Module:
The Customer provide their identites in the website.
Then,the Customer given the details of the journey such as date of the journey, origin and destination,Route,Toll.
The server will calculate the toll and inform the , and he can pay the toll online.
Customers can be able to purchase credits using credit cards/pay pal /debit card.
Staff Management Module: Vehicle Management
In this module staff will the customer details and also have the ability to monitor / the vehicles.
send the approval to the customers for toll gate authentication.
View payment details.
Maintenance In this module all the details and decisions related to the maintenance of the roads under each toll booth
Lot of maintenance work goes on each toll roads regularly, like road patch works, dividers patch works, posts maintenance etc.
All these operations need approvals and fund which can be proposed through this module.
Creating New Toll Booths Module: In this module the processes related to Toll booth creation takes place.
Processes like Road survey, Land acquiring, Budget approvals etc are maintained and approved through this module only.
Once a toll booth got approved it will be added to the exiting Toll management processes
Android Modules: Toll Gate Authentication Module: Request Module In this module the customer the Tollapp.
After , send the customer credentials Via bluetooth/sms to the system in the toll booth and wait for approval.
Staff will the details and send back the approval.
At the same time toll gate will automatically open.
Notification This module will also notify the Customer about their balance and validity.
.
s can receive notification about the charges when he crosses the fences that created in TollApp.
This module can notify the about the status of approval.
Complaint and Module: This will help the customer to the complaints online and get serviced soon.once a complaint got serviced they will get an response message.
Customer can give through this module to the concerned authority.
DATA FLOW DIAGRAMS Level-0
Level-1()
Level-1(Staff)
Level-1()
Level-2()
Level-2(Staff)
Level-2()
ER DIAGRAM
FORM DESIGN Customer Registration
Get -Form(1)
Get -Form(2)
Get -Form(3)
Form
Maintains Request Form
Table design Bookings Sl no
Field Name
Data Type
Size
Constraint
1
Booking_Id
Int
11
Primary Key
2
Vehicletype
Varchar
11
Foreign Key
3
Toll_Id
Int
11
Foreign Key
4
Bookingtype
Varchar
10
5
BookingDate
Date
30
6
ExpiryDate
Date
30
7
Amount
7
PaymentMode
Varchar
30
8
Status
Varchar
30
Double
20
Charges Sl no 1 2
Field Name Vehicletype Vehiclechrge
Data Type Varchar Double
Size 10 20
3
Week
Double
20
4
Month
Double
20
5
Year
Double
20
Constraint Primary Key
Route Sl no
Field Name
Data Type
Size
1
Route_Id
Int
11
2
Scity
Varchar
30
3
Sdistrict
Varchar
30
4
Sstate
Varchar
30
5
Dcity
Varchar
30
6
Ddistrict
Varchar
30
7
Dstate
Varchar
30
8
Status
Varchar
30
Constraint Primary Key
Toll Sl
Field Name
Data Type
Size
Constraint
1 Toll_Id 2 Tollname
Int Varchar
30 30
Primary Key
2 Route_Id 3 FromCity
Varchar Varchar
30 100
Foreign key
4 Tocity
Varchar
30
5 Status
Varchar
20
no
Sl no
Field Name
Data Type
Size
1
name
Varchar
10
2
Varchar
40
Constraint Primary key
Customer Registration Sl no
Field Name
Data Type
1
OwnerName
Varchar
40
2
VehicleRegNum
Varchar
20
3
Vehicletype
Varchar
20
4
Address
Varchar
50
5
City
Varchar
30
6
Country
Varchar
40
7
Email
Varchar
30
8
Phone
Number
10
9
Name
Varchar
10
Varchar
40
10
Size
Constraintg
Primary Key
Staff Sl no 1
Field Name Fname
Data Type Varchar
Size 40
Constraint
2
Dob
Date
20
3
Sex
Varchar
20
4
Email
Varchar
30
5
Address
Varchar
50
6 7
Toll_Id Phone
Int Number
11 10
Foreign Key
8 9
Name
Varchar Varchar
10 40
Primary Key
Road Maintenance Sl no
Field Name
Data Type
Size
Constraint
1
Maintenanc_Id
Int
30
Primary Key
2
Toll_Id
Int
30
Foreign key
3
Route_Id
Int
100
Foreign key
4
Maintenance
Varchar
100
double
30
description 5
Fund
Complaint Sl no
Field Name
Data Type
Size
Constraint
1
Complaint_id
Int
10
Primary Key
2
name
Int
10
Foreign key
3
Complaint
Varchar
100
Sl no
Field Name
Data Type
Size
Constraint
1
_id
Int
10
Primary Key
2
name
Int
10
Foreign key
3
Varchar
100
New Toll Booth Sl no Field Name 1 C_id 2 Place
Data Type Int Varchar
Size 10 30
3
Land
Varchar
100
4
Budget
Varchar
100
5
Road
Varchar
100
6
Isapproval
Varchar
50
Constraint Primary Key
