WIND MILL

Contents:  Introduction  Used

Open GL Functions  Software requirements  Hardware requirements  External interface requirements  Testing  Outputs  Conclusion

Introduction: The project “WINDMILL” is about to show how we efficiently make use of renewable energy using OpenGL function. We have used simple OpenGL functions to draw a rotating fans and We show the generation of electricity when the fans are rotated. Using this mechanical energy we can generate the electricity which is nonrenewable.

Used OpenGL Functions 



 

draw: Which is used to draw the fans. mount: This function is used to draw the mountains. lawn: Which is used to draw the lawn. streetlight: Which is used to draw the streetlights.

Software requirements 

Operating System : Fedora 10 and higher version

  

Language Tool

: OpenGL.

  

Compiler +complier.

: GNU GCC Compiler /C+

Libraries

: GL/gl.h, GL/glut.h, GL/glu.h

  

  

Documentation Tool

: vi editor, geditor

Hardware requirements 

   

 

Processor

: Intel 386 onwards Compatible

Hardware.  RAM : 16MB RAM and more. Hard Disk : 20 GB and more. Monitor : EGVGA Compatible. Keyboard : Standard 101 key Keyboard. Backup Media : Hard disk.  Mouse(ps/2),Printer (optional)

External interface requirements Interfaces:  The package provides good interface.  The system design should be based on functions.  The package should be flexible. Hardware Interface:  should provide main containing all functions.  Interface is required.  Presentation of the function should have a clear cut approach.  There should exist interaction between and system.

Outputs: Clockwise rotation

Outputs: Anti clockwise

Outputs: Stop rotation

Conclusion: 







We have used simple OpenGL functions to draw a rotating fans and we show the generation of electricity when the fans are rotated. Wind power  is the conversion of  wind energy  into a useful form of energy ,that is electrical energy which is used for daily routines. This project also helps us to analyze how we can use the different standard functions for creating the changes of rotation of fan in wind mill.(clockwise, anticlockwise). This graphics model is very useful, one showing the rotational changes implementation.

Thank You…
