Windows Hang and Crash Dump Analysis Mark Russinovich Chief Software Architect Winternals Software Copyright © 2006 Mark Russinovich

About The Speaker Co-author of Windows Internals and Inside Windows 2000 (Microsoft Press) Senior Contributing Editor Windows IT Pro Magazine Author of tools on www.sysinternals.com Co-founder and chief software architect of Winternals Software (www.winternals.com) Microsoft Most Valuable Professional (MVP) 2005, 2006 Teach public and private live classes on Windows Internals and Advanced Troubleshooting with David Solomon (www.solsem.com)

Outline Crash dumps and tools Analysis basics IRQLs Stacks

Analyzing an “easy” crash Un-analyzable crashes Crash transformation Buffer overrun Code overwrite Microsoft Windows Memory Diagnostic

Manual analysis Stack trashes Hung Systems When there is no crash dump

Introduction Many systems s ignore Windows crash dump options “I didn’t know I could analyze crashes” “Crash analysis too hard” “A crash dump won’t tell me anything anyway”

Basic crash dump analysis is actually pretty straightforward Even if only 1 out of 5 or 10 dumps tells you what’s wrong, isn’t it worth spending a few minutes?

More advanced crash dump analysis much harder Not well documented Requires advanced internals, compiler and U knowledge Requires lots of experience Often difficult to pinpoint cause More often than not, victim is not the culprit For example, a driver corrupts an operating system structure; Windows crashes later

Why Does Windows Crash? This is called when something’s wrong in kernel-mode: Unhandled exception (for example, executing invalid instruction) OS or driver detects severe inconsistency Referencing paged out memory at interrupt level (famous “IRQL_NOT_LESS_EQUAL” crash) A reschedule is attempted at dispatch level IRQL or higher Hardware error

Why Does Windows Crash? Microsoft’s analysis of crash root causes indicates: ~70% caused by third-party driver code ~15% caused by unknown (memory is too corrupted to tell) ~10% caused by hardware issues ~5% caused by Microsoft code

There are lots of third-party drivers! From online crash analysis database: 55,000 unique drivers – 24 new/day (28,000 in 2004) 220,000 total drivers – 98 revised/day (130,000 in 2004)

Many Devices Over 1,263,300 distinct Plug and Play (PnP) IDs (680,000 in 2004) 1,600 PnP IDs added every day

What Happens at the Crash When a condition is detected that requires a crash, KeBugCheckEx is called Takes five arguments: Stop code (also called bugcheck code) Four stop-code defined parameters

KeBugCheckEx: Turns off interrupts Tells other Us to stop Paints the blue screen Notifies ed drivers of the crash If a dump is configured (and it is safe to do so), writes dump to disk

Bugcheck Codes Bugcheck codes are shared by many components and drivers There are about 150 defined stop codes Two common ones are: (DRIVER_) IRQL_NOT_LESS_OR_EQUAL (0x0A) - Usually an invalid memory access INVALID_KERNEL_MODE_TRAP (0x7F) and KMODE_EXCEPTION_NOT_HANDLED (0x1E) Generated by executing garbage instructions Its usually caused when a stack is trashed

Most are documented in the Debugging Tools help file Also search Microsoft Knowledge Base (www.microsoft.com/)

Often, bugcheck code and parameters are not enough to solve the crash Need to examine crash dump

Crash Dumps Options Small Memory Dump (aka minidump or Triage Dump) Default for Microsoft Windows 2000/Windows XP Professional/Home Only 64 KB (128 KB on 64-bit systems, up to 512 KB on Vista) Contains minimal crash information Creates a unique file name in \Windows\Minidump after reboot

Kernel Writes OS memory and not processes Most crash debugging doesn’t involve looking at process memory anyway

Useful for large memory systems Overwrites every time Default on Windows Vista

Full Writes all of RAM Overwrites every time

Minidumps On Windows XP, Windows Server 2003, and Windows Vista, minidump is always created, even if system set to full or kernel dump Can extract a minidump from a kernel or full dump using the debugger “.dump /m” command To analyze, requires access to the images on the system that crashed At least must have have access to the Ntoskrnl.exe Microsoft Symbol Server now has images for Windows XP and later Set image path to same as symbol path (covered later)

Writing a Crash Dump Crash dumps are written to the paging file Too risky to try and create a new file (no guarantee you will get a dump anyway)

How is even this protected? When the system boots it checks HKEY_LOCAL_MACHINE\System\ CurrentControlSet\Control\CrashControl The boot volume paging file’s on-disk mapping is obtained Relevant components are checksummed: Boot disk miniport driver Crash I/O functions Page file map

On crash, if checksum doesn’t match, dump is not written

Why Would You Not Get a Dump? Crash occurred before paging file was open For example a crash during driver initialization

The crash corrupted components involved in the dump process Spontaneous reboot Paging file on boot volume is too small Not enough free space for extracted dump Hung system We’ll cover how to troubleshoot these problems later

At The Reboot

WinLogon Session Manager

2

Memory.dmp 3 SaveDump

mode Kernel mode

1

NtCreatePagingFile

4

Paging File

At The Reboot Session Manager process (\Windows\system32\smss.exe) initializes paging file NtCreatePagingFile

1

NtCreatePagingFile determines if the dump has a crash header 2 Protects the dump from use Note: crash dump portion of paging file is in use during the copy, so virtual memory can run low while the copy is in progress

WinLogon calls NtQuerySystemInformation to tell if there’s a dump 3 to extract If there’s a dump, Winlogon executes SaveDump 4 (\Windows\system32\savedump.exe) Writes an event to the System event log SaveDump writes contents to appropriate file On Windows XP or later, checks to see if Windows Error Reporting should be invoked

Online Crash Analysis (OCA) By Default, after a reboot Windows XP/Windows Server 2003 prompts you to send information to http://watson.microsoft.com Can be configured with Computer Properties>Advanced->Error Reporting Can be customized with Group Policies Do/do not show UI Send dump to an internal error reporting server

Windows Error Reporting Savedump checks if kernel error reporting is enabled Checks two values under HKLM\Software\Microsoft\PCHealth\ErrorReporting: IncludeKernelFaults and DoReport

If crash reporting is enabled, Savedump: Extracts a minidump from the dump file (if system set to full or kernel dumps) Writes the name of the minidump under HKLM\Software\Microsoft\PCHealth\ErrorReporting\KernelFaults Adds a command to execute Dumprep.exe to HKLM\Software\Microsoft\Windows\CurrentVersion\Run This will cause it to run at the first log on

Dumpprep then: Generates an XML description of system version, drivers present, loaded plug and play drivers and depending on the configuration Displays the message box (if enabled) to send the dump Submits to dump for automatic analysis

What Gets Sent <SYSTEMINFO> <SYSTEM> Microsoft Windows XP Professional 5.1.2477 0.0

1033 ac97intc.sys 98112 05-17-2001

1. XML description of

system version, drivers present, loaded plug and play drivers 2. Minidump file

06:31:52 5.10.0.3518 <MANUFACTURER>Intel Corporation Intel(r) Integrated Controller Hub Audio Driver

What Does OCA Do? Server farm uses !analyze, but looks up crash fingerprint in Microsoft’s crash resolution database Sometimes OCA will point you at KB articles that describe the problem KB articles may tell you to use Windows Update to get newer drivers, a hotfix, or install a Service Pack

Many times OCA will say “A driver caused a problem”

OCA can’t tell you when it suspects a driver that hasn’t been conclusively identified as being responsible by hand analysis

Outline Crash dumps and tools Analysis basics IRQLs Stacks

Analyzing an “easy” crash Un-analyzable crashes Crash transformation Buffer overrun Code overwrite Windows Memory Diagnostic

Manual analysis Stack trashes Hung Systems When there is no crash dump

Analyzing a Crash Dump Yourself There are two kernel-level debuggers that can open crash dump files: WinDbg –Windows program Kd – command-line program Both provide same kernel debugger analysis commands

Must first configure to point to symbols Easiest to use Microsoft Symbol Server for symbol access Windbg: click on File->Symbol File Path Enter “srv*c:\symbols*http://msdl.microsoft.com//symbols”

If a minidump, must also configure image path to point to location of images (File->Image File Path) Use same string as for symbol server (Windows XP and beyond)

To open a crash dump: WinDbg: File->Open Crash DumpKd crash dump syntax: Kd: kd –z <memory dump file> -y <symbols directory> -i

IRQLs IRQL stands for Interrupt Request Level Each U maintains IRQL independently Software and hardware interrupts map to IRQLs When a U raises its IRQL to a level all interrupts at that level and below are masked for that U

Hardware Interrupts Current IRQL Software Interrupts

SYNCH_LEVEL : : : DEVICE_IRQL 2 DEVICE_IRQL 1 DISPATCH_LEVEL APC_LEVEL IVE_LEVEL

Unmasked

Masked

Key IRQLs IVE_LEVEL: No interrupts are masked mode code always executes at IVE_LEVEL Kernel-mode code executes at IVE_LEVEL most of the time

DISPATCH_LEVEL: Highest software interrupt level Scheduler is off Page faults cannot be handled and are illegal operations

Stacks Each thread has a -mode and kernel-mode stack The -mode stack is usually 1 MB on x86 The kernel-mode stack is typically 12 KB (20 KB for GUI threads) on x86 systems

Stacks allow for nested function invocation Parameters can be ed on the stack Stores return address Serves as storage for local variables

Stack Frames

Parameter 1 Return Address Frame Pointer Local Variable 1

Function 1

Local Variable 2

Function 2

Stack Frame

Parameter 3 Parameter 2 Parameter 1 Return Address Frame Pointer Local Variable 1 Local Variable 2

Function 3

Parameter 2 Parameter 1 Return Address Frame Pointer Local Variable 1

Higher Addresses

Calling Conventions Stacks are easy to interpret if functions use standard calling conventions Other calling conventions make the stack hard to figure out No frame pointer arguments (fast calls)

A debugger requires symbol information to parse non-standard stack frames Makes accurate analysis of crashes involving thirdparty drivers difficult

Outline Crash dumps and tools Analysis basics IRQLs Stacks

Analyzing an “easy” crash Un-analyzable crashes Crash transformation Buffer overrun Code overwrite Windows Memory Diagnostic

Manual analysis Stack trashes Hung Systems When there is no crash dump

NotMyFault.exe In order to demonstrate common crash scenarios, Mark wrote NotMyFault.Exe from http://www.sysinternals.com /files/notmyfault.zip

It loads MyFault.sys MyFault.Sys has an IOCTL interface that implements different bugs

Mode Kernel Mode

IOCTL Interface

MyFault.sys

Generating an Easy Crash Run NotMyFault and select “High IRQL fault (kernel mode)” Allocates paged pool buffer Frees the buffer Raises IRQL ≥ DISPATCH_LEVEL Touches the buffer and pages following the buffer

Paged buffers that are marked “not present” but are touched when IRQL ≥ DISPATCH_LEVEL result in the DRIVER_IRQL_NOT_LESS_OR_EQUAL bug check Memory Manager calls KeBugCheckEx from page fault handler The IRQL is not less than or equal to the maximum IRQL at which the operation is legal (which is < DISPATCH_LEVEL)

Analyzing an Easy Crash Open crash dump with Windbg !analyze easily identifies MyFault.sys by looking at the KeBugCheckEx parameters The Memory Manager looked at the stack and determined the address that caused the page fault !analyze often looks at the stack to determine the cause of a crash

Automated Analysis When you open a crash dump with Windbg or Kd you get a basic crash analysis: Stop code and parameters A guess at offending driver

The analysis is the result of the automated execution of the !analyze debugger command !Analyze uses heuristics to walk up the stack and determine what driver is the likely cause of the crash “Followup” is taken from optional triage.ini file

Don’t trust blame of ntoskrnl, win32k, hal, ntfs or other core Windows components

Crash Transformation Many crashes can’t be analyzed The “victim” crashed the system, not the criminal The analyzer may point at Ntoskrnl.exe or Win32K.sys or other Windows components Or, you may get many different crash dumps all pointing at different causes

You’re goal isn’t to analyze impossible crashes…

It’s to try to make an “unanalyzable” crash into one that can be analyzed

Outline Crash dumps and tools Analysis basics IRQLs Stacks

Analyzing an “easy” crash Un-analyzable crashes Crash transformation Buffer overrun Code overwrite Windows Memory Diagnostic

Manual analysis Stack trashes Hung Systems When there is no crash dump

Using the Driver Verifier The tool for crash transformation is the Driver Verifier (Verifier.exe – not in Start menu) Introduced in Windows 2000 Helps developers test their drivers and systems s identify faulty drivers

Run Verifier.exe Choose “Create Custom Settings” Choose “Select Individual Settings from a List” Enable all options except Low Resource Simulation

Selecting Drivers to Don’t all the drivers Performance hit will make system unusable Limits effectiveness of the Verifier

Crash Transformation Recipe The Recipe: 1. 2. 3. 4.

First, try any “suspicious” drivers (recently updated, known to be problematic, etc.) If still un-analyzable crashes, try enabling verification on all third-party drivers and/or all unsigned drivers As a last resort enable verification on groups of 10-20 drivers at a time Run the Windows Memory Diagnostic

The following crash examples demonstrate the Driver Verifier making “un-analyzable” crashes into ones that point at the problem Buffer overflow System code overwrite

Buffer Overruns Result when a driver goes past the end (overrun) or the beginning (underrun) of a buffer Usually detected when overwritten data is referenced Another driver or the kernel makes the reference There can be a long delay between corruption and detection

Higher Addresses

Another Driver’s Buffer Pool Structures Driver Buffer

Causing a Buffer Overrun Run NotMyFault and select “Buffer Overrun” Allocates a nonpaged pool buffer Writes a string past the end

Note that you might have to run several times since a crash will occur only if: The kernel references the corrupted pool structures A driver references the corrupted buffer

The crash tells you what happened, but not why

A Buffer Overrun Bluescreen In this example, where the crash was the result of the kernel tripping on corrupt pool tracking structures, the Bluescreen tells you what to do:

What is Special Pool? Special pool is a kernel buffer area where buffers are sandwiched with invalid pages Conditions for a driver allocating from special pool: Driver Verifier is ing driver Special pool is enabled and available Allocation is slightly less than one page (4 KB on x86)

Special pool is a limited resource When it runs out verified drivers allocate from standard pool

Note: can be enabled without rebooting

Page n+2

Invalid

Buffer Page n+1

Page n

Signature

Invalid

Higher Addresses

The Verifier Catching Buffer Overrun The Driver Verifier catches the overrun when it occurs The Bluescreen tells you who’s fault it is !analyze explains the crash and also tells you the buggy driver name The stack shows where the driver bug is

Code Overwrites Caused when a bug results in a wild pointer A wild pointer that points at invalid memory is easily detected A wild pointer that points at data is similar to buffer overrun Might not cause a problem for a long time Crash makes it look like its something else’s fault

System code write protection catches code overwrite, but it’s not on if: It’s a Windows 2000 system with > 127 MB memory It’s a Windows XP or Windows 2003 Server system with > 255 MB In other words, it’s off on most systems

Causing a Code Overwrite Run NotMyFault and select “Code Overwrite” Overwrites first bytes of nt!ntreadfile Function is most common entry to I/O system so a random thread will cause the crash

The crash hints that the fault occurred in NtReadFile The last -mode address is ZwReadFile The ebx in the exception frame points at NtReadFile NtReadFile’s start location looks scrambled (u ntreadfile)

System Code Write Protection To obtain a more obvious crash, enable system code write protection by turning on Driver Verifier on one or more drivers Can also manually enable by setting HKLM\System\CurrentControlSet\Control \Session Manager\Memory Management LargePageMinimum REG_DWORD 0xFFFFFFFF EnforceWriteProtection REG_DWORD 1 Reboot to take effect

Rerun NotMyFault Crash occurs immediately and even the blue screen points at MyFault.sys:

!analyze shows the address of the write and the target (NtReadFile)

Windows Memory Diagnostic Memory errors are a significant cause of hardware-related crashes Windows Memory Diagnostic checks memory for errors Free from Microsoft.com http://oca.microsoft.com/en/windiag.asp

Installs to floppy or CD ROM Built into Windows Vista

Run at least one

Outline Crash dumps and tools Analysis basics IRQLs Stacks

Analyzing an “easy” crash Un-analyzable crashes Crash transformation Buffer overrun Code overwrite Windows Memory Diagnostic

Manual analysis Stack trashes Hung Systems When there is no crash dump

Manual Analysis Sometimes !analyze isn’t enough Doesn’t tell you anything useful You want to know what was happening at the time of the crash

Useful commands: List loaded drivers: lm kv Make sure drivers are all recognized and up to date

Look at memory usage: !vm Make sure memory pools are not full If full, use !poolused (requires pool tagging to be on)

Examine current thread: !thread May or may not be related to the crash

List all processes: !process 0 0 Make sure you understand what was running on the system

If a Verifier detected deadlock: !deadlock Additional commands: !help

Stack Trashing An example of a crash requiring manual analysis is a stack trash Stack trashes have several possible causes: A driver pushing things on the stack causes the stack to overflow A driver overruns a stack-allocated buffer

Usually results in garbage code being executed (KMODE_EXCEPTION_NOT_HANDLED) Driver Verifier can’t determine cause Since the stack is corrupted, analysis is especially hard

Debugging Stack Trashes Run NotMyFault and select “Stack Trash” Allocates a buffer on the stack Overruns the buffer Returns to the caller

Crash doesn’t show much off hand !analyze actually blames Win32K.sys, the Win32 kernel-mode subsystem Stack doesn’t show anything except an exception handler

Look deeper !thread shows an outstanding IRP !irp shows that myfault.sys was the target of the IRP

Troubleshooting Crashes That Don’t Generate Crash Dumps If you are getting crashes with no resulting dump (or other “spontaneous reboots”), you need to boot in Debugging Mode: Press F8 during the boot and choose “Debugging Mode” Or, edit the target’s boot.ini file to configure: /debugport=comX /baudrate=XXX (note: default baud rate in Debugging Mode is 19200) Windows XP and Windows 2003 1394 Windows Vista s USB 2.0

In either case, this loads the kernel debugger at boot time Does not affect performance On a crash system will wait indefinitely for debugger connection even if configured to do so!

Connecting to a Crashed System When system crashes, attach a kernel debugger and analyze In Windbg, choose File->Kernel Debug Configure baud rate and COM port Click OK

Debugger should connect and display the bugcheck code Type !analyze –v, and if necessary, perform additional analysis commands as described earlier

To save complete memory dump for offline analysis, use “.dump” (or “.dump /f” to capture a full dump) Note: this will be slow over a serial cable

Hung Systems Sometimes system becomes unresponsive Keyboard and mouse freeze

Two types of hang: Instant lockup Kernel synchronization deadlock Infinite loop at high IRQL or very high priority thread

Grinding to a halt Storage stack resource deadlock

Two techniques that both require prior setup and a reboot: Manually crash the hung system and hope you get a dump to analyze offline Boot the system in debugging mode and when it hangs, break in with the kernel debugger and analyze system

Initiating a Manual Crash Crash from keyboard Requires PS2 keyboard and right control key Right CTRL button and then Scroll Lock twice Must be configured in the Registry: HKLM\SYSTEM\CurrentControlSet\Services\i8042prt\Parameters \CrashOnCtrlScroll (DWORD) – set to value of 1 Documented in Debugging Tools help file

Keyboard interrupts must run for this to work

Use a hardware “dump switch” Some servers come with an NMI button You can also make one: http://www.microsoft.com/whdc/system/CEC/dmpsw.mspx Must be configured in the Registry HKLM\System\CurrentControlSet\Control\CrashControl \NMICrashDump (DWORD) – set to value of 1

Breaking into a Hung System Instead of crashing you can boot in debugging mode and break in when it hangs After the hang, connect the host debugger system to the target Run WinDbg (or KD) Press Ctrl-C (or click Debug->Break) – this breaks into target system

Analyzing a Hang Then attempt to determine reason for hang. (This is the hard part.) Use !thread to see what’s running– check the stack Check each U by using the ~ command, for example, ~0, ~1

Use !locks to look at possible deadlocks Use !irql to see previous IRQL (Windows Server 2003 and later)

If you can’t figure it out but want to save it for later analysis: Use .crash to force a crash Or .dump to save the current state of the system in a dump file This can also be done with LiveKD (free from Sysinternals) on a live system

Generating a Hung System Enable keyboard-initiated manual crash and reboot Run Notmyfault Select “Hang” and press Do Bug On reboot, open dump and look at current thread !thread to check each U of a SMP: ~0, ~1, etc.

Try to determine reason for hang

Analyzing a “Sick” System Sometimes a system is still responsive, but you know that something is wrong with it You want to look at its kernel state, but… You don’t want to take it off line by crashing it or connecting a debugger to it

You can get a “dump” of a live system with LiveKd (free from Sysinternals.com) Use it to run Windbg or Kd Use .dump to snapshot live system

The Bluescreen Screen Saver Scare your enemies and fool your friends with the Sysinternals Bluescreen Screen Saver Remotely execute it (requires privilege on remote system): psexec –i –d –c “sysInternals bluescreen.scr” /s

Be careful, your job may be on the line!

More Information Windows Internals, 4th Edition – Chapter 10: Crash Dump Analysis The help file which is installed with Debugging Tools for Windows Knowledge Base Articles http://www.microsoft.com/ddk/debugging

Other books: http://www.microsoft.com/ddk/newbooks.asp

The debugger team wants your and bug reports [email protected] microsoft.public.windbg newsgroup

Resources Technical Chats and Webcasts http://www.microsoft.com/communities/chats/default.mspx http://www.microsoft.com/usa/webcasts/default.asp

Microsoft Learning and Certification http://www.microsoft.com/learning/default.mspx

MSDN & TechNet http://microsoft.com/msdn http://microsoft.com/technet

Virtual Labs http://www.microsoft.com/technet/traincert/virtuallab/rms.mspx

Newsgroups http://communities2.microsoft.com/ communities/newsgroups/en-us/default.aspx

Technical Community Sites http://www.microsoft.com/communities/default.mspx

Groups http://www.microsoft.com/communities/groups/default.mspx
