Air-Cooled Scroll Condensing Units ACZ 010A – ACZ 155B, Condensing Units 10 to 155 Tons, (35 to 540 kW) 60 Hertz, R-22

Engineered for flexibility and performance. ¥

Cat ACZ-4

Table of Contents Introduction................................................................................................ 3 Features and Benefits................................................................................. 4 Design Features.......................................................................................... 6 Selection Procedure ................................................................................. 13 Performance Data..................................................................................... 14 Part Load Data ......................................................................................... 20 Sound Data............................................................................................... 21 Electrical Data, General........................................................................... 26 Electrical Data, Standard Ambient .......................................................... 27 Electrical Data, High Ambient................................................................. 40 Physical Data ........................................................................................... 49 Dimensional Data .................................................................................... 56 Application Data ...................................................................................... 60 Optional Features..................................................................................... 70 Product Specification............................................................................... 72

Controllers are BACnet certified with an

Controllers are LONMARK certified with an

optional BACnet communication module

optional LONMARK communication module

Manufactured in an ISO certified facility Document Number: Issued: Replaces:

Catalog ACZ-4 June 2005 PM ACZ-3

"Illustrations and information cover the McQuay International products at the time of publication and we reserve the right to make changes in design and construction at anytime without notice." ®™ The following are trademarks or ed trademarks of their respective companies: BACnet from ASHRAE; LONMARK and LONW ORKS from Echelon Corporation; McQuay and MicroTech II from McQuay International; Copeland's Compliant Scroll® from Copeland Corporation, Sidney, Ohio and ElectroFin from AST ElectroFin Inc.

2

ACZ 010A through 155B

Catalog ACZ-4

Introduction The ACZ family of air-cooled scroll condensing units offers a wide selection of units from 10 to 155 tons. The ACZ-A series has capacities from 10 to 39 tons with a single refrigerant circuit using a set of tandem scroll compressors. The ACZ-B series has capacities from 30 to 155 tons with dual refrigerant circuits with either two or three scroll compressors in each of two circuits. The ACZ series of air-cooled scroll condensing units continues McQuay’s legacy of high quality, high efficiency, latest technology and quiet operation. These features make the ACZ family the best overall value in air-cooled condensing units available today. Efficient Operation The ACZ units utilize R22 to meet the efficiency requirements of ASHRAE 90.1. With either two or three scroll compressors for each of two refrigerant circuits, excellent part load performance is achieved.

Latest Control Technology These units have the latest control technology through utilization of McQuay’s new MicroTech II™ microprocessor. Integrating with your building automation system is easy with the Protocol Selectability™ feature using LONMARK®, BACnet® or Modbus® network communication, requiring only the addition of a small communication module to the unit controller.

Compact Size Our reputation for compact designs with small footprints to minimize space requirements continues to be a primary feature. Quiet Operation The ACZ units further enhance McQuay’s reputation for low operating sound levels to make these condensing units “neighborhood friendly”. Figure 1, ACZ 130 (130 Tons) with Optional Full Louver Package

Catalog ACZ-4


3

Features and Benefits ACZ-A, Single Circuit, 10 to 39 Tons Great values also come in small packages. The ACZ-A units have a single refrigerant circuit with capacities from 10 to 39 tons. Customer benefits include high efficiency operation, low sound levels, scroll compressor technology and MicroTech II™ controls.

High Efficiency Operation The ACZ-A units operate at high efficiency with IPLVs up to 14.5 EER. Through the use of tandem scroll compressors and the latest control technology, excellent part load performance occurs.

Quiet Operation ACZ-A units have low sound ratings through the use of scroll compressors. These compressors are housed in a sheet metal enclosure to further reduce the levels. All units have a sound power rating of 90 dBA or less.

Superior Control With MicroTech II™ The MicroTech II™ controller is provided on the ACZ-A models providing control strategies expected of much larger condensing units.

Building Automation System Integration The MicroTech II™ controller allows for easy BAS integration through our Protocol Selectability™ feature using LONMARK, BACnet or Modbus communications. This is another advanced feature typical of larger condensing units. Figure 2, Model ACZ 033, 30 ton Condensing Unit

4


Catalog ACZ-4

ACZ-B Condensing Units, Dual Circuits, 30 to 155 Tons The ACZ-B units with dual refrigerant circuits from 30 to 155 tons offer outstanding benefits that make this product effect for a variety of applications. High Efficiency Full Load Operation ŸŸLower Energy Costs For High Loads Utilizing the new scroll compressor technology, the ACZ-B condensing units have high full load efficiency. All system components are selected for optimum performance including the large condenser coil areas and compressors. Full load EERs range up to 12.3 at ARI Standard Conditions (45°F saturated suction temperature, 95°F ambient temperature, sea level).

Excellent Part Load PerformanceŸŸLower Energy Costs for Most for the Year By using either four or six compressors on each condensing unit, unloading characteristics and part load performance are outstanding. The IPLV part load values for our scroll units range up to 14.6 EER. Integrated part load value (IPLV) is a part load performance indicator as outlined in ARI Standard 365. The IPLV rating compares the performance of different condensing units under identical conditions. When the IPLV is listed in EER (Energy Efficiency Ratio), a higher EER will indicate that the chiller’s overall performance is better.

Compact Design with Small FootprintŸŸInstallation Flexibility and Lower Cost Again, McQuay ACZ-B series condensing units have a reputation for a compact design and small footprint. A small footprint can save installation costs by minimizing the size of the concrete mounting pad or reduces the amount of structural steel if the unit is mounted on the roof.

Quiet Operation -- “Neighborhood friendly”ŸŸInstallation Flexibility The ACZ condensing units are designed with quiet scroll compressors. Fans are selected for good performance and lower sound levels. The attention to detail with sound in mind is critical in the design. Paying attention to small issues such as refrigerant piping, s for piping, and securing component to the structure are all important to making a quiet product. We proudly publish our sound performance.

Superior Controls -- MicroTech II™ ŸŸEfficient, Reliable Operation Once again, McQuay has provided the latest technology in controlling the ACZ-B condensing units. The new MicroTech II™ controller provides a “ friendly” environment for the operator. The control logic is designed to provide maximum efficiency, to help provide continuing operation in unusual operating conditions through proactive controls and to provide a history of conditions to aid in problem resolutions. Perhaps the greatest benefit is Protocol Selectability™ for integrating the unit with your building automation system (BAS). MicroTech II™ allows interfacing into the BAS directly through LONTALK®, BACnet® or Modbus®. See the complete control description on page 7 in this catalog.

Catalog ACZ-4


5

Design Features The McQuay ACZ Air-Cooled Condensing Unit is a product of the McQuay commitment to offer quiet, reliable, energy efficient equipment. An approach incorporating high quality compressors, state-of-the-art coil design, and innovative packaging. Construction Factory assembled and mounted on a heavy-gauge steel channel base. The base rails, s and cabinetry are powder-coat painted. The base distributes the unit weight for roof loading. Varied and convenient installation is possible by virtue of the unit's small footprint.

Compressors Copeland’s Compliant Scroll™ tandem or triple compressors are used. These rugged hermetic compressors are constructed with an integral cast iron frame, cast iron scrolls, three Teflon impregnated bearings, and three oil filtration devices for each compressor. Using Copeland's Compliant Scroll tandem compressors provides two, four or six steps of capacity modulation depending on unit model size. One compressor can run alone, depending on the load of the system, resulting in excellent part-load efficiency. Each refrigerant circuit has specially designed oil and gas equalization lines to control oil migration. The design also offers radial and axial compliance (no tip seals), a large internal volume for liquid handling, a removable suction screen, and a rotary dirt trap and oil screen. In addition, the compressor is self-compensating for wear, handles liquid and debris, and inherently yields the highest efficiency for its class. This well protected compressor includes a solid-state motor protection module, 4 individual motorwinding sensors, a patented internal discharge temperature probe, and a patented shutdown feature that prevents reverse rotation. An internal discharge check valve helps prevent shutdown noise and comes standard with high and low pressure taps with Schrader valves, a sight glass, an oil level adjustment valve, and an off cycle crankcase heater. Units are available in 60 Hertz electrical voltage configurations from 208 to 575 volt operating at 3500 rpm.

Condenser Coils Condenser coils have internally enhanced seamless copper tubes arranged in a staggered row pattern. The coils are mechanically expanded into McQuay lanced and rippled aluminum fins with full fin collars. A variety of optional coil material and coatings are available for corrosive atmospheres. An integral subcooler circuit provides subcooling to greatly reduce the possibility of liquid flashing. The external condenser coils are fitted with a protective wire mesh guard as standard equipment.

Condenser Fans and Motors Multiple direct drive dynamically balanced propeller fans operate in formed venturi openings at low tip speeds for maximum efficiency and minimum noise and vibration. A heavy-gauge vinylcoated fan guard protects each fan. Each condenser fan motor is heavy-duty, 3-phase, Totally Enclosed Air Over (TEAO) with permanently lubricated ball bearings and inherent overload protection. SpeedTrol option includes a single-phase motor with fan speed control on the lead fan for each circuit.

6


Catalog ACZ-4

Figure 3, ACZ-B Typical Condensing Unit Piping Schematic

NOTES: 1. A shell-and-tube water chiller is shown. A wide variety of evaporator types can be used. 2. The filter-drier, solenoid valve, sight glass and TXV must be located as close to the evaporato

Electrical Control Center Operating and equipment protection controls and motor starting components are separately housed in a centrally located, weather resistant control with hinged and key locked doors. In addition to the MicroTech II™ controller described in the next sections, the following components are housed in the : • Power terminal block, single point connection standard • Control, input, and output terminal block • Control transformer • Phase voltage monitor with under/over voltage and phase reversal protection • Fan ors with short circuit protective devices • Optional ground fault protection • The standard FanTrol™ head pressure control system controls refrigerant discharge pressure by fan staging. The FanTrol system cycles condenser fans based on discharge pressure and outdoor temperature and is designed for operation down to 35°F (1.7°C). • Models 010A through 039A have the optional SpeedTrol control using both fan cycling and fan speed control on the lead fan per circuit and allows operation to 0°F (-18°C) outdoor temperature. Models 030B through 155B use fan VFD for operation between 35°F and 0°F (1.7°C and -18°C). • Mechanical high pressure cutout •

Power connections are per following table: Power Connection

Power Block

Disc. Swt.

ACZ 010-039, Single-Point, (Std.) ACZ 030-155, Single Point, (Std ) ACZ 030-155, Multi-Point, (Opt.)

Std. Std Std

Opt Opt. Opt.

Comp. Circuit Breakers Not Avail. Std Not Avail.

Circuit Breakers w/ High Interr. Capacity Opt. Opt. Opt.

High Short Circuit Current Rating Not Avail Opt Opt.

Definitions on the following page. Catalog ACZ-4


7

Definitions: 1. Power Block, An electrical device to directly accept field wiring without any disconnecting means. 2. Disconnect Switch, A molded case switch that accepts field wiring and disconnects main power to the entire unit or each main power supply if the multi-point power supply option is selected. This option does not provide overcurrent protection. 3. Compressor Circuit Breakers, A manually reset circuit breaker for each compressor, providing compressor only protection and located ahead of the or. Provides overcurrent protection for each compressor. 4. Unit Circuit Breaker with High Interrupting Capacity, A molded case circuit breaker acting as the main disconnect switch with short circuit current rating (formally known as “withstand”). Capacities are shown on page 71. One circuit breaker is provided with each electrical circuit. The circuit breaker provides overcurrent protection for each power supply. 5. Control High Short Circuit Current Rating, (Previously known as “withstand rating”). The entire control is designed for short circuit current rating as shown on page 71. In the event of a short circuit, the damage is contained within the control enclosure.

Control System The MicroTech II™ advanced DDC unit controller sures all other microprocessorbased unit control systems available today. This powerful, -friendly control system provides the flexibility and performance needed for either stand-alone unit operation or the controller can be easily tied into your building automation system of choice using McQuay’s exclusive Protocol Selectability™ feature. Protocol Selectability™ allows you to choose from open standard protocols such as BACnet®, Modbus®, and LONTALK® to communicate easily with the Building Automation System that best meets your facility requirements. These optional communications modules are available factory-installed or can be easily field installed. MicroTech II™’s state-of-the-art design will not only permit the unit to run more efficiently, but will also simplify troubleshooting if a system failure occurs. Every MicroTech II controller is programmed and tested prior to shipment to help provide a trouble-free startup.

Operator-friendly The MicroTech II control menu structure is separated into four distinct categories that provide the operator or service technician with a full description of current unit status, control parameters, and alarms. Security protection helps prevent unauthorized changing of the setpoints and control parameters. MicroTech II continuously performs self-diagnostic checks, pressures and protection devices, monitoring system temperatures, and it will automatically shutdown a compressor, a refrigerant circuit or the entire unit if a fault occurs. The cause of the shutdown will be retained in memory and can be easily displayed in plain English or metric units for operator review. The MicroTech II unit controller can also retain and display the time the fault occurred and the operating conditions that were present at the time of the fault, which is an extremely useful feature for troubleshooting. In addition to displaying alarm diagnostics, the MicroTech II controller also provides the operator with a warning of pre-alarm conditions. Alarm notification data can also be ed to your BAS through an optional communications module.

8


Catalog ACZ-4

Staging Temperature control for the evaporator is provided by the installer through a field supplied temperature controller. The field supplied staging signals are provided to the MicroTech II controller which correspondingly activates and deactivates the scroll compressors. The temperature controller is required to close normally-open 24 volt s on a demand for cooling. These closure signals are field wired to the terminal strip (TB2) in the condensing unit. Refer to the typical field wiring diagram for details. The following control staging is required: Condensing Unit Model ACZ-010A through 039A ACZ-030B through 110B ACZ-120B through 155B

Number of Capacity Steps 2 4 6

Number of Required Closure Signals 2 4 6

Lead/lag is automatic and switched based on operating hours and compressor starts.

Equipment Protection The unit is protected in two ways: (1) by alarms that shut the unit down and require manual reset to restore unit operation and (2) by limit alarms that reduce unit operation in response to some out-of-limit condition. Shut down alarms can activate a remote alarm signal. Limit alarms activate a signal on the controller. Shutdown Alarms • High condenser pressure • Motor protection system • Phase voltage protection (Optional on ACZ-B only) • Outside ambient temperature • Sensor failures Limit Alarms • Condenser pressure stage down, unloads unit at high discharge pressures • Low ambient lockout, shuts off unit at low ambient temperatures • Low evaporator pressure hold, holds stage #1 until pressure rises • Low evaporator pressure unload, shuts off stage #2

Unit Enable Selection •

Enables unit operation from either local keypad, digital input, or BAS

Unit Mode Selection •

Selects standard cooling, or test operation mode

Digital Inputs •

Unit off switch

•

Remote start/stop

•

Flow switch

Digital Outputs • •

Catalog ACZ-4

Shutdown alarm; field wired, activates on an alarm condition, off when alarm is cleared Evaporator pump or air handler fan motor; field wired, starts when unit is set to start ACZ 010A through 155B

9

Condenser fan control The MicroTech II™ controller provides control of condenser fans. The controller stages condenser fans based on discharge pressure.

Building Automation System (BAS) Interface The following BAS standard protocols are ed through McQuay’s Protocol Selectability™ option: • BACnet/IP® • BACnet MS/TP® • BACnet Ethernet® • LONTALK ® • Modbus® The following functions are generally available depending on the application and protocol in use: • • • • • •

Enable/disable operation Select operating mode Set the network limit variable Read all digital and anaputs and outputs Read operating mode and status Send a description of each alarm when it occurs

Keypad/Display A 4-line by-20 character/line liquid crystal display and 6-key keypad is mounted on the unit controller. Its layout is shown below. Figure 4, MicroTech II™ Keypad Menu Button

"Enter" Button

The four arrow buttons (UP, DOWN, LEFT, RIGHT) have three modes of use. • Scroll between data screens as indicated by the arrows (default mode). • Select a specific data screen in a hierarchical fashion using dynamic labels on the right side of the display (this mode is entered by pressing the MENU button). • Change field values in edit mode.

10


Catalog ACZ-4

Figure 5, ACZ-B Control

Figure 6, ACZ-A Control

Optional Remote Interface The ACZ units can be individually equipped with a remote interface. It provides convenient access to unit diagnostics and control adjustments, remote from the condensing unit . A separate remote is required for each chiller on a job site. Each remote interface is similar to its unit-mounted counterpart and offers the same functionality, including: • Touch sensitive keypad with a 4 line by 20-character display format. • Digital display of messages in English language. • All operating conditions, system alarms, control parameters.

Catalog ACZ-4


11

Features • Can be wired up to 1,640 feet (500 meters) from the unit for flexibility in placing each remote interface within your building. • The main control is isolated from the remote interface wiring so that wiring problems are less likely to damage the unit interface. • Can be placed on a desk or surface or recessed wall mounted. Benefits • Allows you to access the interface for each unit from one location, inside the building. • s need to learn one format because the remote interface is identical to the unitmounted version. • • •

No additional field commissioning is required for the remote interface. Can be retrofit after unit installation. All the BAS communications options are still available with the remote interface .

Cable and Wiring Recommendations

Figure 7, Remote Interface Dimensions

No more than 1,640 feet (500 meters) of wiring can be used to connect the remote interface to the unit. Power: AWG 22 twisted pair cable. Communications: Belden 9841 or equal AWG 22 twisted pair. A separate small communication terminal board is used at the unit and at the remote . Figure 8, Remote Interface Wiring Diagram pLAN phone style cable to Remote Display pLAN phone style cable to J10 of chiller Unit control

Chiller Terminal Board

Display Terminal Board

Note: Maximum distance between terminal blocks is 1640 feet (500 m) A

A 0 1 2 3 4 5 6

0 1 2 3 4 5 6

sc

sc 30 Vdc +

Power is supplied through AWG22 twisted pair cable

Power Common RX+/Tx+ Rx-/TxShield

Communications cable is Belden 9841 or equivalent AWG22 twisted pair

12


Catalog ACZ-4

Selection Procedure ACZ condensing units are selected in conjunction with some kind of evaporator equipment. The ACZ ratings are based on saturated suction temperature at the compressor inlet and on ambient air dry-bulb temperature. For a system selection, the ACZ condensing unit is usually selected first, then the line loss added to the condensing unit saturated suction temperature to determine the saturated evaporating temperature. This temperature is then used for the selection of the evaporator, whether it is a DX coil or shell and tube heat exchanger. The pipe size can be determined from procedures and data in the Refrigerant Piping Section. For selection purposes, the tubing size is based on a pressure equivalent of a two-degree F line loss (equal to about 3-psi pressure drop). The correction for altitude found in Table 1 is applied, if applicable, by dividing the required job capacity by the correction factor to ascertain the necessary unit capacity in the Capacity Tables. ACZ performance is found in Table 2 through Table 8 (I-P and SI) covering the normal range of saturated suction temperatures and ambient air temperatures.

Selection example, Inch-Pound units Given: Dual refrigeration circuits are required 400 Mbh job requirement 95°F ambient temperature 40°F saturated suction temperature 2,000 foot altitude 1. Correct for altitude by dividing the required capacity by the correction factor found in Table 1. 400 Mbh required / 0.986 factor = 406 mbh corrected requirement. 2. From Table 3, ACZ 030B through 065B, an ACZ 040 at the given conditions will produce 410 Mbh with a unit power input of 41.3 kW and a unit EER of 9.9. 3. Correct for altitude: Capacity: 410 Mbh x 0.986 = 404 Mbh Power: 41.3 kW x 1.009 = 41.7 kW EER: 9.9 EER x 0.986/1.009 = 9.7 EER 4. An evaporator would be selected at 42°F saturated evaporating temperature.

Selection example-SI units Use the same procedure as for Inch-Pounds but use SI tables and units.

Application Adjustment Factors Altitude Correction Factors Performance tables are based at sea level. Elevations other than sea level affect the performance of the unit. The decreased air density will reduce condenser capacity consequently reducing the unit's performance. Table 1, Altitude Correction Factors

Catalog ACZ-4

Altitude

Capacity

Sea Level

1.000

1.000

2000 ft (610 m)

0.986

1.009

4000 ft (1220) m

0.973

1.021

6000 ft (1830) m

0.959

1.031


Power

13

Performance Data I-P Units Table 2, ACZ 010A through 039A ACZ Unit Size

010A

013A

016A

020A

025A

028A

033A

039A

Sat Fan & 80°F Suct. Control Unit PWR Temp Power Mbh kWi (kW) (°F) 30 1.8 86.4 8.0 35 1.8 96.0 8.1 40 1.8 105.6 8.3 45 1.8 115.2 8.4 50 1.8 126.0 8.6 55 1.8 136.8 8.9 30 1.8 111.6 10.4 35 1.8 124.8 10.7 40 1.8 139.2 10.9 45 1.8 154.8 11.3 50 1.8 170.4 11.6 55 1.8 187.2 11.9 30 1.8 148.8 13.6 35 1.8 164.4 13.9 40 1.8 180.0 14.1 45 1.8 198.0 14.4 50 1.8 217.2 14.7 55 1.8 237.6 15.1 30 1.8 178.8 16.8 35 1.8 196.8 17.2 40 1.8 216.0 17.6 45 1.8 236.4 18.0 50 1.8 256.8 18.5 55 1.8 279.6 19.0 30 2.7 232.8 21.8 35 2.7 256.8 22.3 40 2.7 282.0 22.8 45 2.7 308.4 23.4 50 2.7 337.2 24.1 55 2.7 366.0 24.7 30 2.7 254.4 24.3 35 2.7 280.8 24.9 40 2.7 307.2 25.6 45 2.7 336.0 26.3 50 2.7 366.0 27.1 55 2.7 398.4 27.9 30 2.7 318.0 28.0 35 2.7 350.4 28.8 40 2.7 384.0 29.5 45 2.7 418.8 30.4 50 2.7 456.0 31.3 55 2.7 495.6 32.3 30 2.7 393.6 36.7 35 2.7 433.2 37.7 40 2.7 474.0 38.9 45 2.7 516.0 40.1 50 2.7 560.4 41.5 55 2.7 608.4 42.9

85°F PWR Unit

95°F Unit PWR Unit

Unit

115°F PWR Unit

Unit

EER

Mbh

kWi

EER Mbh

kWi

EER

Mbh

kWi

EER Mbh

kWi

EER

10.9 11.8 12.7 13.7 14.6 15.5 10.7 11.7 12.7 13.7 14.7 15.7 10.9 11.8 12.8 13.7 14.7 15.7 10.7 11.5 12.3 13.1 13.9 14.7 10.7 11.5 12.4 13.2 14.0 14.8 10.5 11.3 12.0 12.8 13.5 14.3 11.4 12.2 13.0 13.8 14.6 15.3 10.7 11.5 12.2 12.9 13.5 14.2

85.2 93.6 103.2 112.8 123.6 134.4 108.0 121.2 135.6 151.2 166.8 183.6 145.2 159.6 176.4 193.2 212.4 232.8 175.2 192.0 211.2 230.4 250.8 272.4 228.0 250.8 274.8 301.2 328.8 357.6 248.4 273.6 300.0 327.6 357.6 388.8 310.8 342.0 374.4 409.2 445.2 483.6 384.0 422.4 462.0 502.8 547.2 592.8

8.3 8.4 8.6 8.7 8.9 9.2 10.9 11.1 11.4 11.7 12.0 12.4 14.2 14.5 14.7 15.0 15.3 15.7 17.5 17.9 18.3 18.8 19.3 19.8 22.7 23.2 23.8 24.3 25.0 25.7 25.3 25.9 26.6 27.3 28.1 28.9 29.3 30.0 30.8 31.7 32.6 33.6 38.2 39.3 40.5 41.8 43.1 44.6

10.2 11.1 12.0 12.9 13.8 14.6 10.0 11.0 11.9 12.9 13.9 14.8 10.2 11.1 12.0 12.9 13.8 14.8 10.0 10.7 11.5 12.3 13.0 13.8 10.0 10.8 11.6 12.4 13.2 13.9 9.8 10.6 11.3 12.0 12.7 13.4 10.6 11.4 12.2 12.9 13.7 14.4 10.1 10.7 11.4 12.1 12.7 13.3

8.9 9.1 9.2 9.4 9.6 9.8 11.8 12.1 12.3 12.6 13.0 13.3 15.5 15.7 16.0 16.3 16.6 17.0 19.1 19.5 20.0 20.4 20.9 21.4 24.7 25.2 25.8 26.3 27.0 27.7 27.4 28.1 28.8 29.5 30.3 31.1 32.1 32.8 33.7 34.5 35.5 36.5 41.5 42.7 43.9 45.2 46.6 48.1

9.0 9.8 10.6 11.4 12.2 13.0 8.7 9.6 10.5 11.4 12.3 13.1 8.9 9.7 10.5 11.3 12.1 13.0 8.6 9.3 10.0 10.7 11.4 12.0 8.8 9.4 10.1 10.8 11.6 12.3 8.6 9.2 9.9 10.5 11.2 11.8 9.2 9.9 10.6 11.3 11.9 12.6 8.8 9.4 9.9 10.5 11.1 11.6

75.6 84.0 92.4 100.8 110.4 121.2 97.2 109.2 122.4 135.6 151.2 165.6 130.8 144.0 159.6 175.2 192.0 210.0 156.0 171.6 188.4 206.4 224.4 243.6 202.8 224.4 246.0 270.0 294.0 320.4 220.8 243.6 267.6 294.0 320.4 348.0 278.4 306.0 336.0 367.2 400.8 434.4 340.8 374.4 410.4 447.6 487.2 526.8

9.7 9.8 10.0 10.1 10.3 10.6 12.9 13.2 13.4 13.7 14.1 14.4 17.0 17.2 17.5 17.8 18.1 18.5 20.9 21.3 21.8 22.2 22.7 23.3 26.8 27.4 28.0 28.6 29.2 29.9 29.8 30.5 31.2 32.0 32.8 33.6 35.1 35.9 36.7 37.7 38.7 39.7 45.0 46.3 47.6 49.0 50.4 52.0

7.8 8.5 9.2 10.0 10.7 11.4 7.5 8.3 9.1 9.9 10.7 11.5 7.7 8.4 9.1 9.8 10.6 11.3 7.5 8.1 8.7 9.3 9.9 10.5 7.6 8.2 8.8 9.4 10.1 10.7 7.4 8.0 8.6 9.2 9.8 10.3 7.9 8.5 9.2 9.8 10.4 10.9 7.6 8.1 8.6 9.1 9.7 10.1

10.5 10.6 10.8 11.0 11.2 11.4 14.1 14.4 14.7 15.0 15.3 15.7 18.5 18.8 19.1 19.4 19.7 20.1 22.7 23.2 23.7 24.2 24.7 25.3 29.2 29.8 30.4 31.1 31.7 32.5 32.4 33.1 33.9 34.7 35.5 36.4 38.3 39.2 40.1 41.1 42.1 43.2 48.7 50.1 51.5 52.9 54.5 56.1

6.8 7.4 8.0 8.7 9.3 10.0 6.4 7.1 7.8 8.5 9.3 10.0 6.6 7.2 7.8 8.5 9.1 9.8 6.4 6.9 7.5 8.0 8.5 9.1 6.5 7.0 7.6 8.2 8.7 9.3 6.4 6.9 7.4 7.9 8.4 9.0 6.8 7.4 7.9 8.4 8.9 9.5 6.5 7.0 7.4 7.9 8.3 8.8

80.4 88.8 97.2 106.8 117.6 127.2 103.2 115.2 129.6 144.0 158.4 175.2 138.0 152.4 168.0 184.8 201.6 220.8 165.6 182.4 199.2 218.4 237.6 258.0 216.0 237.6 261.6 285.6 312.0 339.6 235.2 259.2 284.4 310.8 339.6 368.4 295.2 324.0 355.2 388.8 423.6 459.6 363.6 399.6 436.8 476.4 517.2 560.4

Unit

105°F PWR Unit

Unit

70.8 78.0 86.4 94.8 104.4 114.0 91.2 102.0 115.2 128.4 141.6 156.0 123.6 135.6 150.0 164.4 180.0 198.0 146.4 160.8 176.4 193.2 211.2 229.2 189.6 210.0 230.4 253.2 276.0 301.2 206.4 228.0 250.8 274.8 300.0 326.4 261.6 288.0 315.6 345.6 376.8 408.0 315.6 348.0 381.6 417.6 453.6 492.0

NOTES:

1. 2. 3. 4.

14

Ratings based on HCFC-22, and sea level altitude. Interpolation is allowed; extrapolation is not permitted. Consult McQuay for performance outside the cataloged ratings. KWi and EER are for the entire unit, including compressors, fan motors and control power. Shaded ratings are ARI Standard 365-2002 standard rating of 95°F ambient air temperature and 45°F suction with 15 degrees superheat.


Catalog ACZ-4

Table 3, ACZ 030B through 065B Sat. Fan & ACZ Control Suct. Unit Power Temp. Size (kW) (°F)

030B

5.6

035B

5.6

040B

5.6

045B

5.6

050B

5.6

055B

5.7

060B

5.7

065B

5.7

30 35 40 45 50 55 30 35 40 45 50 55 30 35 40 45 50 55 30 35 40 45 50 55 30 35 40 45 50 55 30 35 40 45 50 55 30 35 40 45 50 55 30 35 40 45 50 55

Unit Mbh 306 338 372 410 451 496 341 376 415 456 500 548 376 415 457 502 550 601 436 482 531 583 639 699 484 535 589 647 708 774 534 590 650 714 783 856 593 655 720 791 866 945 652 719 791 867 949 1034

75 PWR kWi 27.2 27.6 28.1 28.6 29.2 29.9 30.0 30.5 31.1 31.8 32.5 33.3 32.8 33.5 34.2 34.9 35.8 36.7 37.4 38.0 38.7 39.4 40.3 41.2 42.5 43.4 44.3 45.3 46.3 47.5 45.7 46.6 47.5 48.5 49.6 50.8 50.8 51.9 53.1 54.4 55.9 57.5 55.8 57.2 58.7 60.4 62.2 64.2

Unit EER 11.2 12.2 13.3 14.3 15.5 16.6 11.3 12.3 13.3 14.4 15.4 16.5 11.4 12.4 13.4 14.4 15.4 16.4 11.7 12.7 13.7 14.8 15.9 17.0 11.4 12.3 13.3 14.3 15.3 16.3 11.7 12.7 13.7 14.7 15.8 16.9 11.7 12.6 13.6 14.5 15.5 16.4 11.7 12.6 13.5 14.4 15.3 16.1

Unit Mbh 290 321 354 391 430 473 323 357 394 433 476 522 357 394 434 476 522 571 414 458 504 554 607 664 460 508 560 615 673 736 509 562 619 680 745 814 564 623 686 753 824 900 620 684 753 826 904 986

85 PWR kWi 29.7 30.2 30.6 31.2 31.8 32.6 32.9 33.5 34.1 34.8 35.5 36.4 36.1 36.8 37.6 38.4 39.3 40.2 41.1 41.8 42.5 43.3 44.1 45.1 46.7 47.6 48.5 49.6 50.7 51.9 50.1 51.0 51.9 52.9 54.0 55.2 55.8 57.0 58.3 59.7 61.2 62.8 61.6 63.0 64.6 66.4 68.3 70.5

Ambient Air Temperature (°F) 95 Unit Unit PWR Unit Unit EER Mbh kWi EER Mbh 9.8 276 32.6 8.5 261 10.6 305 33.1 9.2 288 11.6 337 33.6 10.0 318 12.5 371 34.2 10.9 351 13.5 409 34.9 11.7 386 14.5 449 35.6 12.6 425 9.8 306 36.2 8.5 288 10.7 339 36.8 9.2 319 11.6 373 37.5 10.0 352 12.5 411 38.2 10.8 387 13.4 451 39.0 11.6 425 14.3 495 39.9 12.4 466 9.9 337 39.8 8.5 316 10.7 372 40.5 9.2 349 11.5 410 41.3 9.9 385 12.4 450 42.2 10.7 424 13.3 494 43.2 11.4 465 14.2 540 44.2 12.2 508 10.1 391 45.2 8.7 367 11.0 433 45.9 9.4 407 11.9 477 46.7 10.2 449 12.8 524 47.5 11.0 493 13.8 575 48.5 11.9 541 14.7 629 49.5 12.7 592 9.9 434 51.3 8.5 406 10.7 480 52.3 9.2 449 11.5 529 53.3 9.9 496 12.4 581 54.4 10.7 546 13.3 637 55.6 11.4 598 14.2 696 56.9 12.2 654 10.2 480 55.0 8.7 449 11.0 531 56.0 9.5 498 11.9 586 57.0 10.3 550 12.8 643 58.0 11.1 605 13.8 705 59.2 11.9 663 14.7 771 60.4 12.8 726 10.1 534 61.5 8.7 501 10.9 590 62.7 9.4 554 11.8 649 64.1 10.1 611 12.6 713 65.6 10.9 671 13.5 781 67.2 11.6 735 14.3 853 69.0 12.4 803 10.1 587 67.9 8.6 552 10.9 648 69.5 9.3 610 11.6 713 71.3 10.0 671 12.4 783 73.2 10.7 737 13.2 856 75.2 11.4 807 14.0 935 77.5 12.1 881

105 PWR kWi 35.9 36.4 36.9 37.6 38.3 39.1 39.8 40.5 41.2 42.0 42.9 43.8 43.8 44.6 45.5 46.5 47.5 48.6 49.7 50.5 51.4 52.3 53.3 54.3 56.4 57.5 58.7 59.9 61.2 62.6 60.5 61.6 62.7 63.9 65.1 66.4 67.7 69.1 70.6 72.2 74.0 75.8 74.9 76.7 78.6 80.6 82.9 85.3

Unit EER 7.3 7.9 8.6 9.3 10.1 10.9 7.2 7.9 8.5 9.2 9.9 10.6 7.2 7.8 8.5 9.1 9.8 10.5 7.4 8.1 8.7 9.4 10.2 10.9 7.2 7.8 8.5 9.1 9.8 10.5 7.4 8.1 8.8 9.5 10.2 10.9 7.4 8.0 8.6 9.3 9.9 10.6 7.4 8.0 8.5 9.1 9.7 10.3

Unit Mbh 243 270 298 328 361 397 269 298 329 362 398 437 295 326 360 397 435 476 343 380 420 462 507 555 376 417 461 508 558 611 415 462 511 563 619 678 466 516 570 627 687 752 517 571 629 690 756 826

115 PWR kWi 39.5 40.1 40.7 41.3 42.0 42.9 43.9 44.6 45.4 46.2 47.2 48.2 48.2 49.1 50.1 51.2 52.3 53.5 54.6 55.6 56.5 57.5 58.6 59.8 62.0 63.3 64.6 65.9 67.4 68.9 66.6 67.8 69.1 70.4 71.7 73.2 74.5 76.1 77.8 79.6 81.5 83.5 82.4 84.4 86.6 88.8 91.2 93.8

Unit EER 6.2 6.7 7.3 7.9 8.6 9.3 6.1 6.7 7.2 7.8 8.4 9.1 6.1 6.6 7.2 7.7 8.3 8.9 6.3 6.8 7.4 8.0 8.7 9.3 6.1 6.6 7.1 7.7 8.3 8.9 6.2 6.8 7.4 8.0 8.6 9.3 6.3 6.8 7.3 7.9 8.4 9.0 6.3 6.8 7.3 7.8 8.3 8.8

NOTES: 1. Ratings based on HCFC-22 and sea level altitude. 2. Interpolation is allowed; extrapolation is not permitted. Consult McQuay for performance outside the cataloged ratings. 3. KWi and EER are for the entire unit, including compressors, fan motors and control power. 4. Shaded ratings are ARI Standard 365-2002 standard rating of 95°F ambient air temperature and 45°F suction with 15 degrees superheat.

Catalog ACZ-4


15

Table 4, ACZ 070B through 155B ACZ Unit Size

Sat. Fan & Control Suct. Power Temp. (kW) (°F)

070B

7.3

080B

7.3

090B

10.9

100B

10.9

110B

10.9

120B

14.5

130B

14.5

140B

14.5

155B

14.5

35 40 45 50 55 30 35 40 45 50 55 30 35 40 45 50 55 30 35 40 45 50 55 30 35 40 45 50 55 30 35 40 45 50 55 30 35 40 45 50 55 30 35 40 45 50 55 30 35 40 45 50 55

Unit Mbh 773 851 934 1022 1117 748 825 907 997 1092 1195 850 938 1034 1137 1250 1372 937 1034 1138 1251 1372 1502 1024 1129 1243 1364 1494 1633 1131 1247 1373 1508 1653 1809 1273 1404 1547 1701 1869 2050 1402 1546 1702 1870 2051 2246 1531 1688 1858 2039 2234 2442

75 PWR kWi 61.8 63.4 65.3 67.3 69.5 65.8 67.6 69.6 71.8 74.2 76.9 73.3 75.2 77.1 79.2 81.5 84.0 80.2 82.3 84.6 87.1 89.9 92.9 87.0 89.4 92.1 95.0 98.3 101.8 96.6 98.8 101.3 103.9 106.8 110.0 110.5 113.6 116.8 120.4 124.3 128.5 121.5 125.0 128.9 133.1 137.7 142.8 132.4 136.4 140.9 145.7 151.1 157.1

Unit EER 12.5 13.4 14.3 15.2 16.1 11.4 12.2 13.0 13.9 14.7 15.5 11.6 12.5 13.4 14.4 15.3 16.3 11.7 12.6 13.5 14.4 15.3 16.2 11.8 12.6 13.5 14.4 15.2 16.0 11.7 12.6 13.6 14.5 15.5 16.4 11.5 12.4 13.2 14.1 15.0 16.0 11.5 12.4 13.2 14.1 14.9 15.7 11.6 12.4 13.2 14.0 14.8 15.5

Unit Mbh 736 810 890 974 1065 711 784 864 949 1040 1138 810 894 986 1085 1192 1308 891 984 1084 1192 1309 1434 973 1074 1183 1300 1426 1560 1077 1189 1309 1439 1578 1727 1212 1338 1474 1622 1782 1954 1332 1471 1621 1782 1955 2142 1453 1604 1767 1942 2129 2329

85 PWR kWi 67.8 69.5 71.4 73.5 75.8 72.1 74.1 76.2 78.5 81.1 83.9 79.7 81.6 83.6 85.8 88.2 90.8 87.2 89.4 91.7 94.3 97.1 100.1 94.7 97.1 99.8 102.7 105.9 109.5 105.5 107.8 110.3 113.1 116.1 119.4 120.4 123.6 127.0 130.8 134.8 139.2 132.3 136.0 140.0 144.4 149.2 154.5 144.3 148.5 153.0 158.0 163.5 169.7

Ambient Air Temperature (°F) 95 Unit Unit PWR Unit Unit EER Mbh kWi EER Mbh 10.9 697 74.5 9.4 656 11.7 768 76.3 10.1 723 12.5 844 78.4 10.8 795 13.3 924 80.6 11.5 872 14.0 1011 83.1 12.2 954 9.9 672 79.2 8.5 631 10.6 742 81.3 9.1 698 11.3 818 83.6 9.8 770 12.1 899 86.1 10.4 847 12.8 986 88.8 11.1 930 13.6 1080 91.7 11.8 1018 10.2 767 86.9 8.8 721 11.0 848 88.9 9.5 799 11.8 936 91.1 10.3 883 12.6 1030 93.4 11.0 973 13.5 1133 95.9 11.8 1071 14.4 1243 98.6 12.6 1176 10.2 844 95.1 8.9 794 11.0 933 97.4 9.6 879 11.8 1029 99.8 10.3 971 12.7 1132 102.5 11.0 1070 13.5 1243 105.4 11.8 1176 14.3 1363 108.6 12.6 1290 10.3 920 103.2 8.9 867 11.1 1017 105.8 9.6 959 11.9 1121 108.6 10.3 1059 12.7 1234 111.6 11.1 1166 13.5 1354 114.9 11.8 1281 14.2 1483 118.6 12.5 1404 10.2 1019 115.5 8.8 959 11.0 1127 118.0 9.5 1061 11.9 1242 120.7 10.3 1171 12.7 1366 123.6 11.1 1290 13.6 1499 126.7 11.8 1416 14.5 1641 130.2 12.6 1552 10.1 1147 131.6 8.7 1076 10.8 1268 135.0 9.4 1193 11.6 1398 138.6 10.1 1318 12.4 1539 142.6 10.8 1453 13.2 1692 146.9 11.5 1598 14.0 1856 151.6 12.2 1754 10.1 1260 144.5 8.7 1185 10.8 1393 148.5 9.4 1312 11.6 1536 152.7 10.1 1449 12.3 1690 157.4 10.7 1596 13.1 1856 162.4 11.4 1754 13.9 2034 168.0 12.1 1924 10.1 1374 157.5 8.7 1294 10.8 1518 162.0 9.4 1432 11.5 1674 166.8 10.0 1580 12.3 1841 172.2 10.7 1740 13.0 2021 178.0 11.4 1911 13.7 2213 184.4 12.0 2095

105 PWR kWi 81.9 84.0 86.2 88.6 91.2 87.1 89.4 91.9 94.6 97.5 100.6 95.2 97.3 99.6 102.0 104.6 107.5 103.9 106.4 109.0 111.9 115.0 118.3 112.6 115.5 118.5 121.8 125.3 129.2 126.9 129.5 132.4 135.5 138.8 142.5 144.4 148.0 151.9 156.1 160.6 165.6 158.3 162.6 167.2 172.2 177.6 183.5 172.1 177.1 182.4 188.2 194.5 201.4

Unit EER 8.0 8.6 9.2 9.8 10.5 7.2 7.8 8.4 9.0 9.5 10.1 7.6 8.2 8.9 9.5 10.2 10.9 7.6 8.3 8.9 9.6 10.2 10.9 7.7 8.3 8.9 9.6 10.2 10.9 7.6 8.2 8.8 9.5 10.2 10.9 7.5 8.1 8.7 9.3 9.9 10.6 7.5 8.1 8.7 9.3 9.9 10.5 7.5 8.1 8.7 9.2 9.8 10.4

Unit Mbh 613 677 745 817 894 587 651 719 792 870 954 672 747 827 913 1006 1106 743 824 911 1005 1106 1215 814 901 996 1097 1207 1324 895 992 1097 1209 1329 1458 1000 1112 1232 1361 1499 1647 1108 1229 1359 1499 1650 1812 1216 1346 1486 1638 1801 1976

115 PWR kWi 90.2 92.4 94.8 97.4 100.2 96.0 98.5 101.2 104.1 107.2 110.6 104.6 106.9 109.3 111.8 114.6 117.6 113.8 116.6 119.5 122.6 125.9 129.5 123.1 126.3 129.7 133.3 137.2 141.3 139.5 142.5 145.6 148.9 152.5 156.4 159.1 162.9 167.0 171.5 176.3 181.6 173.6 178.4 183.5 188.9 194.8 201.2 188.2 193.9 199.9 206.3 213.3 220.8

Unit EER 6.8 7.3 7.9 8.4 8.9 6.1 6.6 7.1 7.6 8.1 8.6 6.4 7.0 7.6 8.2 8.8 9.4 6.5 7.1 7.6 8.2 8.8 9.4 6.6 7.1 7.7 8.2 8.8 9.4 6.4 7.0 7.5 8.1 8.7 9.3 6.3 6.8 7.4 7.9 8.5 9.1 6.4 6.9 7.4 7.9 8.5 9.0 6.5 6.9 7.4 7.9 8.4 8.9

NOTES: 1. Ratings based on HCFC-22 and sea level altitude. 2. Interpolation is allowed; extrapolation is not permitted. Consult McQuay for performance outside the cataloged ratings. 3. KWi and EER are for the entire unit, including compressors, fan motors and control power. 4. Shaded ratings are ARI Standard 365-2002 standard rating of 95°F ambient air temperature and 45°F suction with 15 degrees superheat.

16


Catalog ACZ-4

SI Units Table 5, ACZ 010A - ACZ 039A Ambient Air Temperature (°C) Sat Fan & Suct. Control 24°C 30°C 35°C 41°C 47°C Temp Power Unit PWR Unit Unit PWR Unit Unit PWR Unit Unit PWR Unit Unit PWR Unit (kW) (°C) kW kWi COP kW kWi COP kW kWi COP kW kWi COP kW kWi COP -1 1.8 26.1 7.7 3.4 24.8 8.4 3.0 23.6 8.9 2.6 22.1 9.7 2.3 20.6 10.6 1.9 2 1.8 29.0 7.9 3.7 27.6 8.5 3.2 26.3 9.1 2.9 24.7 9.9 2.5 23.0 10.8 2.1 5 1.8 32.1 8.0 4.0 30.6 8.7 3.5 29.1 9.3 3.1 27.4 10.1 2.7 25.6 11.0 2.3 010A 8 1.8 35.4 8.2 4.3 33.7 8.9 3.8 32.2 9.5 3.4 30.3 10.3 3.0 28.4 11.2 2.5 11 1.8 38.9 8.5 4.6 37.1 9.1 4.1 35.4 9.7 3.7 33.4 10.5 3.2 31.3 11.4 2.7 13 1.8 41.4 8.6 4.8 39.4 9.2 4.3 37.7 9.8 3.8 35.5 10.7 3.3 33.3 11.6 2.9 -1 1.8 33.5 10.0 3.3 31.8 11.0 2.9 30.3 11.8 2.6 28.5 13.0 2.2 26.5 14.4 1.8 2 1.8 37.9 10.3 3.7 36.0 11.2 3.2 34.4 12.1 2.8 32.4 13.3 2.4 30.1 14.7 2.1 5 1.8 42.6 10.6 4.0 40.5 11.5 3.5 38.7 12.4 3.1 36.5 13.6 2.7 34.1 15.0 2.3 013A 8 1.8 47.6 11.0 4.3 45.3 11.9 3.8 43.4 12.7 3.4 40.9 13.9 2.9 38.2 15.3 2.5 11 1.8 52.9 11.3 4.7 50.4 12.2 4.1 48.2 13.1 3.7 45.5 14.3 3.2 42.7 15.7 2.7 13 1.8 56.5 11.6 4.9 53.9 12.5 4.3 51.6 13.3 3.9 48.7 14.5 3.4 45.7 15.9 2.9 -1 1.8 44.8 13.1 3.4 42.4 14.4 3.0 40.6 15.5 2.6 38.3 17.1 2.2 35.8 18.8 1.9 2 1.8 49.8 13.4 3.7 47.2 14.6 3.2 45.2 15.8 2.9 42.6 17.4 2.5 39.9 19.1 2.1 5 1.8 55.1 13.7 4.0 52.4 14.9 3.5 50.1 16.1 3.1 47.3 17.7 2.7 44.3 19.4 2.3 016A 8 1.8 61.0 14.0 4.4 57.9 15.2 3.8 55.5 16.4 3.4 52.4 18.0 2.9 49.0 19.8 2.5 11 1.8 67.3 14.3 4.7 64.0 15.6 4.1 61.2 16.8 3.6 57.8 18.4 3.1 54.1 20.2 2.7 13 1.8 71.7 14.6 4.9 68.2 15.9 4.3 65.3 17.0 3.8 61.6 18.7 3.3 57.6 20.4 2.8 -1 1.8 54.0 16.1 3.3 51.1 17.7 2.9 48.7 19.1 2.5 45.6 21.0 2.2 42.5 23.1 1.8 2 1.8 59.8 16.5 3.6 56.7 18.1 3.1 54.0 19.6 2.8 50.7 21.5 2.4 47.3 23.6 2.0 5 1.8 66.1 17.0 3.9 62.6 18.6 3.4 59.6 20.1 3.0 56.0 22.0 2.5 52.3 24.1 2.2 020A 8 1.8 72.6 17.5 4.2 68.8 19.1 3.6 65.6 20.6 3.2 61.6 22.5 2.7 57.5 24.7 2.3 11 1.8 79.6 18.0 4.4 75.4 19.6 3.8 71.9 21.1 3.4 67.5 23.1 2.9 63.1 25.3 2.5 13 1.8 84.4 18.3 4.6 80.0 20.0 4.0 76.2 21.5 3.5 71.6 23.5 3.0 66.9 25.7 2.6 -1 2.7 70.2 21.0 3.3 66.6 22.9 2.9 63.5 24.7 2.6 59.5 27.0 2.2 55.2 29.6 1.9 2 2.7 77.9 21.5 3.6 74.0 23.5 3.2 70.5 25.3 2.8 66.1 27.6 2.4 61.5 30.3 2.0 5 2.7 86.2 22.1 3.9 81.8 24.1 3.4 78.0 25.9 3.0 73.2 28.3 2.6 68.2 31.0 2.2 025A 8 2.7 94.9 22.8 4.2 90.1 24.7 3.6 85.9 26.5 3.2 80.7 29.0 2.8 75.3 31.7 2.4 104. 23.5 11 2.7 4.4 98.8 25.4 3.9 94.3 27.2 3.5 88.6 29.7 3.0 82.7 32.4 2.6 110. 24.0 13 2.7 4.6 104.9 25.9 4.1 100.0 27.7 3.6 94.0 30.2 3.1 87.8 32.9 2.7 -1 2.7 76.7 23.4 3.3 72.8 25.5 2.9 69.3 27.5 2.5 64.7 30.0 2.2 59.8 32.8 1.8 2 2.7 85.0 24.1 3.5 80.7 26.2 3.1 76.9 28.2 2.7 72.0 30.8 2.3 66.7 33.7 2.0 5 2.7 93.9 24.8 3.8 89.2 26.9 3.3 85.0 28.9 2.9 79.7 31.6 2.5 74.0 34.5 2.1 028A 103. 25.6 8 2.7 4.0 98.1 27.7 3.5 93.5 29.7 3.1 87.7 32.4 2.7 81.6 35.4 2.3 113. 26.5 11 2.7 4.3 107.5 28.6 3.8 102.5 30.6 3.3 96.2 33.3 2.9 89.6 36.3 2.5 120. 27.1 13 2.7 4.4 113.9 29.2 3.9 108.6 31.2 3.5 102.0 33.9 3.0 95.1 36.9 2.6 -1 2.7 95.8 26.9 3.6 90.9 29.6 3.1 86.7 32.1 2.7 81.6 35.3 2.3 76.3 38.8 2.0 106. 27.7 2 2.7 3.8 100.8 30.4 3.3 96.2 32.9 2.9 90.5 36.2 2.5 84.6 39.8 2.1 117. 28.5 5 2.7 4.1 111.3 31.3 3.6 106.2 33.8 3.1 99.9 37.2 2.7 93.4 40.8 2.3 033A 128. 29.4 8 2.7 4.4 122.3 32.2 3.8 116.8 34.8 3.4 109.9 38.2 2.9 102.7 41.9 2.5 140. 30.4 11 2.7 4.6 133.9 33.2 4.0 127.9 35.9 3.6 120.3 39.3 3.1 112.5 43.1 2.6 149. 31.2 13 2.7 4.8 141.9 34.0 4.2 135.5 36.6 3.7 127.5 40.1 3.2 119.2 43.9 2.7 118. 35.3 -1 2.7 3.4 112.5 38.6 2.9 107.0 41.6 2.6 99.7 45.4 2.2 91.7 49.3 1.9 131. 36.4 2 2.7 3.6 124.4 39.8 3.1 118.4 42.8 2.8 110.5 46.7 2.4 101.9 50.8 2.0 144. 37.7 5 2.7 3.8 137.0 41.1 3.3 130.4 44.2 2.9 121.8 48.2 2.5 112.6 52.4 2.1 039A 158. 39.0 8 2.7 4.1 150.3 42.5 3.5 143.0 45.6 3.1 133.7 49.7 2.7 123.8 54.0 2.3 173. 40.5 11 2.7 4.3 164.2 44.0 3.7 156.2 47.2 3.3 146.1 51.3 2.8 135.4 55.7 2.4 183. 41.5 13 2.7 4.4 173.8 45.0 3.9 165.3 48.2 3.4 154.6 52.4 3.0 143.4 56.9 2.5 NOTES: 1. Ratings based on HCFC-22 and sea level altitude. 2. Interpolation is allowed; extrapolation is not permitted. Consult McQuay for performance outside the cataloged ratings. 3. KWi and COP are for the entire unit, including compressors, fan motors and control power. ACZ Unit Size

Catalog ACZ-4


17

Table 6, ACZ 030B - ACZ 065B Fan & Sat ACZ Control Suct. Unit Power Temp Size (kW) (°C)

030B

035B

040B

045B

050B

055B

060B

065B

Ambient Air Temperature (°C) 25

30

35

40

45

Unit PWR Unit KW kWi COP

Unit KW

PWR Unit kWi COP

Unit PWR Unit KW kWi COP

Unit KW

PWR Unit kWi COP

Unit KW

PWR Unit kWi COP

5.6

-1.0 2.0 5.0 8.0 11.0 13.0

89.1 99.2 110.2 122.3 135.6 144.9

27.7 28.2 28.7 29.3 30.0 30.5

3.2 3.5 3.9 4.2 4.5 4.8

85.0 94.8 105.4 117.1 129.9 138.8

30.0 30.5 31.0 31.7 32.4 32.9

2.8 3.1 3.4 3.7 4.0 4.2

81.1 90.5 100.7 111.9 124.1 132.7

32.6 33.1 33.7 34.4 35.1 35.7

2.5 2.7 3.0 3.3 3.5 3.7

77.1 86.1 95.8 106.4 117.9 126.1

35.6 36.1 36.7 37.4 38.2 38.8

2.2 2.4 2.6 2.9 3.1 3.3

72.7 81.1 90.3 100.3 111.2 118.9

38.8 39.4 40.0 40.8 41.6 42.2

1.9 2.1 2.3 2.5 2.7 2.8

5.6

-1.0 2.0 5.0 8.0 11.0 13.0

99.2 110.5 122.7 135.9 150.2 160.2

30.6 31.2 31.8 32.6 33.4 34.0

3.3 3.6 3.9 4.2 4.5 4.7

94.7 105.5 117.2 129.8 143.6 153.1

33.3 33.9 34.6 35.3 36.2 36.8

2.9 3.1 3.4 3.7 4.0 4.2

90.1 100.4 111.6 123.7 136.8 146.0

36.2 36.9 37.6 38.4 39.3 40.0

2.5 2.7 3.0 3.2 3.5 3.7

85.3 95.2 105.8 117.4 129.8 138.5

39.5 40.2 41.0 41.9 42.8 43.5

2.2 2.4 2.6 2.8 3.0 3.2

80.3 89.7 99.7 110.6 122.4 130.6

43.1 43.9 44.7 45.6 46.7 47.4

1.9 2.1 2.2 2.4 2.6 2.8

5.6

-1.0 2.0 5.0 8.0 11.0 13.0

109.4 121.8 135.1 149.4 164.8 175.5

33.5 34.2 35.0 35.9 36.8 37.5

3.3 3.6 3.9 4.2 4.5 4.7

104.3 116.2 128.9 142.6 157.2 167.4

36.5 37.3 38.1 39.0 40.0 40.7

2.9 3.1 3.4 3.7 3.9 4.1

99.0 110.4 122.5 135.5 149.5 159.2

39.8 40.6 41.5 42.5 43.5 44.3

2.5 2.7 3.0 3.2 3.4 3.6

93.6 104.3 115.9 128.3 141.6 150.9

43.4 44.3 45.3 46.3 47.5 48.3

2.2 2.4 2.6 2.8 3.0 3.1

87.9 98.2 109.2 121.0 133.6 142.4

47.3 48.3 49.4 50.5 51.8 52.6

1.9 2.0 2.2 2.4 2.6 2.7

5.6

-1.0 2.0 5.0 8.0 11.0 13.0

127.1 141.5 157.0 173.7 191.7 204.2

38.2 38.9 39.6 40.4 41.4 42.0

3.3 3.7 4.0 4.3 4.6 4.9

121.2 135.0 149.9 165.9 183.0 194.9

41.5 42.3 43.1 43.9 44.9 45.6

2.9 3.2 3.5 3.8 4.1 4.3

115.2 128.3 142.5 157.8 174.1 185.5

45.2 46.0 46.9 47.8 48.8 49.5

2.6 2.8 3.0 3.3 3.6 3.7

108.8 121.4 134.9 149.4 165.0 175.8

49.3 50.2 51.1 52.1 53.2 53.9

2.2 2.4 2.6 2.9 3.1 3.3

102.4 114.3 127.2 141.0 155.7 166.0

53.7 54.7 55.7 56.8 58.0 58.8

1.9 2.1 2.3 2.5 2.7 2.8

5.6

-1.0 2.0 5.0 8.0 11.0 13.0

141.1 157.1 174.2 192.7 212.5 226.2

43.4 44.3 45.3 46.4 47.6 48.5

3.3 3.6 3.9 4.2 4.5 4.7

134.6 149.9 166.3 183.9 202.8 215.9

47.2 48.2 49.2 50.4 51.6 52.5

2.9 3.1 3.4 3.7 3.9 4.1

127.7 142.3 158.0 174.8 192.8 205.3

51.3 52.4 53.5 54.8 56.1 57.0

2.5 2.7 3.0 3.2 3.4 3.6

120.2 134.3 149.2 165.3 182.4 194.3

55.9 57.1 58.4 59.7 61.1 62.1

2.2 2.4 2.6 2.8 3.0 3.1

112.3 125.7 140.0 155.3 171.6 182.9

60.9 62.3 63.7 65.1 66.7 67.8

1.9 2.0 2.2 2.4 2.6 2.7

5.7

-1.0 2.0 5.0 8.0 11.0 13.0

155.6 173.3 192.3 212.8 234.8 250.1

46.6 47.6 48.6 49.7 50.9 51.7

3.3 3.7 4.0 4.3 4.6 4.8

148.8 165.8 183.9 203.5 224.4 238.9

50.6 51.6 52.6 53.7 55.0 55.8

2.9 3.2 3.5 3.8 4.1 4.3

141.4 157.6 175.0 193.6 213.6 227.4

55.0 56.1 57.2 58.4 59.6 60.5

2.6 2.8 3.1 3.3 3.6 3.8

133.2 148.8 165.4 183.2 202.2 215.4

60.0 61.1 62.3 63.6 65.0 65.9

2.2 2.4 2.7 2.9 3.1 3.3

124.2 139.2 155.1 172.1 190.3 202.8

65.4 66.7 68.1 69.5 70.9 71.9

1.9 2.1 2.3 2.5 2.7 2.8

5.7

-1.0 2.0 5.0 8.0 11.0 13.0

172.9 192.3 213.2 235.6 259.6 276.2

51.8 53.1 54.4 55.9 57.5 58.7

3.3 3.6 3.9 4.2 4.5 4.7

165.2 183.8 203.8 225.3 248.2 264.2

56.4 57.7 59.1 60.7 62.4 63.6

2.9 3.2 3.5 3.7 4.0 4.2

157.0 174.9 194.0 214.5 236.4 251.6

61.5 62.9 64.4 66.0 67.8 69.1

2.6 2.8 3.0 3.3 3.5 3.6

148.4 165.4 183.6 203.2 224.1 238.5

67.1 68.7 70.3 72.1 74.0 75.3

2.2 2.4 2.6 2.8 3.0 3.2

139.2 155.4 172.8 191.3 211.1 224.9

73.2 74.9 76.7 78.6 80.7 82.1

1.9 2.1 2.3 2.4 2.6 2.8

5.7

-1.0 2.0 5.0 8.0 11.0 13.0

190.1 211.3 234.0 258.4 284.3 302.3

57.0 58.5 60.2 62.1 64.2 65.6

3.3 3.6 3.9 4.2 4.4 4.6

181.5 201.9 223.7 247.1 272.1 289.4

62.3 63.9 65.7 67.6 69.8 71.3

2.9 3.2 3.4 3.7 3.9 4.06

172.7 192.1 213.0 235.4 259.3 275.8

68.0 2.5 69.7 2.8 71.7 3.0 73.7 3.2 76.0 3.4 77.7 3.55

163.6 182.0 201.9 223.2 245.9 261.6

74.2 76.2 78.3 80.5 83.0 84.7

2.2 2.4 2.6 2.8 3.0 3.09

154.2 171.6 190.4 210.5 232.0 246.9

81.0 83.1 85.4 87.8 90.5 92.3

1.9 2.1 2.2 2.4 2.6 2.68

NOTES: 1. Ratings based on HCFC-22 and sea level altitude. 2. Interpolation is allowed; extrapolation is not permitted. Consult McQuay for performance outside the cataloged ratings. 3. KWi and COP are for the entire unit, including compressors, fan motors and control power.

18


Catalog ACZ-4

Table 7, ACZ 070B - 155B ACZ Unit Size

Sat Fan & Control Suct. Power Temp (kW) (°C)

070B

7.3

080B

7.3

090B

10.9

100B

10.9

110B

10.9

120B

14.5

130B

14.5

140B

14.5

155B

14.5

-1.0 2.0 5.0 8.0 11.0 13.0 -1.0 2.0 5.0 8.0 11.0 13.0 -1.0 2.0 5.0 8.0 11.0 13.0 -1.0 2.0 5.0 8.0 11.0 13.0 -1.0 2.0 5.0 8.0 11.0 13.0 -1.0 2.0 5.0 8.0 11.0 13.0 -1.0 2.0 5.0 8.0 11.0 13.0 -1.0 2.0 5.0 8.0 11.0 13.0 -1.0 2.0 5.0 8.0 11.0 13.0

Unit KW 204.4 227.2 251.8 278.3 306.7 326.4 217.8 242.2 268.5 297.0 327.8 349.2 247.9 275.8 306.2 339.4 375.6 401.0 273.1 303.7 337.0 373.0 412.0 439.3 298.3 331.7 367.8 406.7 448.5 477.6 329.6 366.5 406.5 449.7 496.3 528.9 371.0 412.6 458.1 507.6 561.5 599.3 408.4 454.2 503.9 557.7 615.9 656.6 445.9 495.7 549.6 607.8 670.2 713.8

25 PWR Unit kWi COP 61.5 3.3 63.2 3.6 65.0 3.9 67.1 4.2 69.3 4.4 70.9 4.6 67.1 3.3 69.2 3.5 71.4 3.8 73.9 4.0 76.6 4.3 78.5 4.5 74.7 3.3 76.7 3.6 78.8 3.9 81.2 4.2 83.7 4.5 85.5 4.7 81.7 3.4 84.0 3.6 86.5 3.9 89.3 4.2 92.4 4.5 94.6 4.7 88.6 3.4 91.3 3.6 94.2 3.9 97.5 4.2 101.1 4.4 103.7 4.6 98.5 3.4 100.9 3.6 103.6 3.9 106.6 4.2 109.8 4.5 112.1 4.7 112.6 3.3 116.0 3.6 119.6 3.8 123.6 4.1 127.9 4.4 131.0 4.6 123.8 3.3 127.7 3.6 131.9 3.8 136.6 4.1 141.8 4.4 145.5 4.5 134.9 3.3 139.4 3.6 144.3 3.8 149.7 4.1 155.8 4.3 160.1 4.5

Unit KW 195.2 217.2 240.8 266.3 293.6 312.6 208.0 231.4 256.8 284.1 313.6 334.2 237.1 263.9 293.2 325.0 359.7 384.1 260.9 290.4 322.5 357.2 394.8 421.0 284.7 317.0 351.8 389.3 429.8 457.9 315.1 350.7 389.2 430.8 475.7 507.0 354.7 394.8 438.4 486.0 537.6 573.9 390.0 434.1 481.9 533.7 589.7 628.8 425.3 473.3 525.3 581.4 641.7 683.8

30 PWR kWi 66.9 68.6 70.6 72.7 75.1 76.7 72.9 75.0 77.4 80.0 82.8 84.9 80.5 82.6 84.8 87.3 89.9 91.8 88.1 90.4 93.0 95.9 99.0 101.2 95.6 98.3 101.2 104.5 108.1 110.7 106.6 109.1 111.9 115.0 118.4 120.8 121.6 125.1 128.9 133.1 137.6 140.8 133.7 137.7 142.2 147.0 152.4 156.2 145.8 150.4 155.4 161.0 167.2 171.6

Ambient Air Temperature (°C) 35 Unit Unit PWR Unit Unit COP KW kWi COP KW 2.9 185.7 72.8 2.6 175.8 3.2 206.7 74.7 2.8 195.8 3.4 229.4 76.7 3.0 217.5 3.7 253.8 79.0 3.2 240.8 3.9 280.0 81.5 3.4 265.7 4.1 298.2 83.3 3.6 283.1 2.9 197.7 79.3 2.5 186.8 3.1 220.2 81.6 2.7 208.3 3.3 244.5 84.1 2.9 231.6 3.6 270.7 86.8 3.1 256.6 3.8 298.9 89.8 3.3 283.5 3.9 318.6 92.0 3.5 302.3 3.0 225.8 87.0 2.6 213.7 3.2 251.7 89.2 2.8 238.6 3.5 279.8 91.5 3.1 265.6 3.7 310.3 94.1 3.3 295.0 4.0 343.6 96.8 3.6 326.8 4.2 366.9 98.8 3.7 349.1 3.0 248.3 95.2 2.6 235.2 3.2 276.7 97.6 2.8 262.4 3.5 307.5 100.3 3.1 292.0 3.7 340.9 103.3 3.3 324.0 4.0 377.0 106.5 3.5 358.7 4.2 402.2 108.8 3.7 382.9 3.0 270.8 103.3 2.6 256.6 3.2 301.7 106.1 2.8 286.3 3.5 335.2 109.2 3.1 318.4 3.7 371.4 112.5 3.3 353.1 4.0 410.4 116.3 3.5 390.5 4.1 437.6 118.9 3.7 416.7 3.0 300.0 115.6 2.6 284.0 3.2 334.2 118.3 2.8 316.9 3.5 371.2 121.3 3.1 352.3 3.8 411.2 124.5 3.3 390.6 4.0 454.3 128.0 3.6 431.8 4.2 484.3 130.5 3.7 460.6 2.9 337.4 131.7 2.6 318.9 3.2 376.1 135.4 2.8 356.2 3.4 418.1 139.4 3.0 396.5 3.7 463.7 143.8 3.2 440.2 3.9 513.2 148.6 3.5 487.6 4.1 547.8 151.9 3.6 520.8 2.9 370.8 144.7 2.6 351.1 3.2 413.2 149.0 2.8 391.7 3.4 459.2 153.7 3.0 435.8 3.6 509.0 158.8 3.2 483.6 3.9 562.8 164.4 3.4 535.2 4.0 600.4 168.4 3.6 571.2 2.9 404.3 157.7 2.6 383.2 3.2 450.4 162.6 2.8 427.3 3.4 500.4 167.9 3.0 475.2 3.6 554.3 173.8 3.2 526.9 3.8 612.5 180.3 3.4 582.7 4.0 653.0 184.9 3.5 621.6

40 PWR kWi 79.4 81.4 83.6 86.1 88.7 90.6 86.4 88.9 91.6 94.5 97.7 100.0 94.4 96.7 99.2 101.9 104.8 106.8 103.1 105.8 108.7 111.8 115.2 117.6 111.8 114.9 118.2 121.7 125.7 128.5 125.8 128.7 131.8 135.2 138.9 141.6 143.3 147.2 151.4 156.0 161.0 164.6 157.1 161.7 166.7 172.2 178.2 182.4 170.8 176.2 182.0 188.4 195.3 200.3

Unit COP 2.2 2.4 2.6 2.8 3.0 3.1 2.2 2.4 2.5 2.7 2.9 3.0 2.3 2.5 2.7 2.9 3.1 3.3 2.3 2.5 2.7 2.9 3.1 3.3 2.3 2.5 2.7 2.9 3.1 3.3 2.3 2.5 2.7 2.9 3.1 3.3 2.2 2.4 2.6 2.8 3.0 3.2 2.2 2.4 2.6 2.8 3.0 3.1 2.3 2.4 2.6 2.8 3.0 3.1

Unit KW 165.4 184.5 205.1 227.2 250.9 267.4 175.3 195.8 218.0 241.8 267.5 285.3 200.7 224.7 250.7 278.8 309.2 330.5 221.7 247.8 276.1 306.7 339.9 363.0 242.7 270.8 301.5 334.7 370.5 395.5 267.2 298.6 332.5 369.0 408.4 435.8 299.0 334.9 373.7 415.6 460.9 492.6 330.7 369.7 411.9 457.5 506.9 541.3 362.5 404.4 450.1 499.5 552.8 590.1

45 PWR kWi 86.6 88.8 91.2 93.8 96.6 98.6 94.3 97.0 99.9 103.0 106.4 108.8 102.8 105.2 107.8 110.6 113.7 115.8 112.0 114.9 118.0 121.3 125.0 127.5 121.1 124.5 128.2 132.1 136.3 139.2 137.1 140.2 143.6 147.2 151.1 153.9 156.3 160.4 164.9 169.8 175.1 178.8 170.7 175.8 181.3 187.2 193.6 198.2 185.2 191.2 197.7 204.6 212.2 217.5

Unit COP 1.9 2.1 2.3 2.4 2.6 2.7 1.9 2.0 2.2 2.4 2.5 2.6 2.0 2.1 2.3 2.5 2.7 2.9 2.0 2.2 2.3 2.5 2.7 2.9 2.0 2.2 2.4 2.5 2.7 2.9 2.0 2.1 2.3 2.5 2.7 2.8 1.9 2.1 2.3 2.5 2.6 2.8 1.9 2.1 2.3 2.5 2.6 2.7 2.0 2.1 2.3 2.5 2.6 2.7

NOTES: 1. Ratings based on HCFC-22 and sea level altitude. 2. Interpolation is allowed; extrapolation is not permitted. Consult McQuay for performance outside the cataloged ratings. 3. KWi and COP are for the entire unit, including compressors, fan motors and control power.

Catalog ACZ-4


19

Part Load Data Table 8, ACZ 010A through 155B Unit Size

% Load

Capacity Mbh

Power kWi

EER

IPLV

Unit Size

% Load

Capacity Mbh

Power kWi

EER

IPLV

100 126 8.6 14.6 100 918 65.0 14.1 12.9 53 62 5.2 12.1 76 694 47.8 14.5 065B 14.4 100 170.4 11.6 14.7 50 459 33.0 13.9 013A 13.8 54 85 6.4 13.3 26 235 15.9 14.8 100 217 14.7 14.7 100 984 69.9 14.1 016A 14.3 54 109 7.9 14.0 70 692 47.5 14.6 070B 14.5 100 257 18.5 13.9 47 458 32.2 14.2 020A 14.2 56 132 9.3 14.2 24 234 16.3 14.4 100 337.2 24.1 14.0 100 1047 77.0 13.6 025A 14.2 50 156 11.0 14.2 72 757 54.4 13.9 080B 13.9 100 366 27.1 13.5 50 524 39.0 13.4 028A 13.9 55 187 13.5 13.9 22 233 16.4 14.2 100 456 31.3 14.6 100 1198 84.3 14.2 033A 15.1 55 233 15.3 15.2 76 905 64.0 14.1 090B 14.1 100 569 41.5 13.5 50 599 42.6 14.1 039A 14.8 56 292 19.3 15.1 26 306 22.3 13.7 100 437 30.4 14.4 100 1316 92.8 14.2 76 330 23.2 14.2 73 964 67.6 14.3 030B 13.9 100B 14.2 50 219 15.7 13.9 46 599 42.6 14.1 26 112 8.5 13.1 23 306 22.3 13.7 100 484 33.9 14.3 100 1434 101.3 14.2 73 355 24.5 14.5 75 1082 76.1 14.2 035B 14.1 110B 14.2 45 219 15.7 13.9 50 717 51.1 14.0 23 112 8.5 13.1 25 365 25.9 14.1 100 532 37.4 14.2 100 1587 110.7 14.3 76 403 28.0 14.4 71 1130 82.9 13.6 040B 14.2 120B 14.1 50 266 19.2 13.9 44 691 46.9 14.7 26 137 9.8 14.0 19 306 23.6 13.0 100 619 42.1 14.7 100 1792 128.6 13.9 76 468 31.9 14.7 67 1202 87.4 13.8 045B 14.5 130B 13.7 50 309 21.5 14.4 50 896 64.8 13.8 26 159 11.3 14.0 17 306 23.6 13.0 100 683 48.3 14.1 100 1967 142.3 13.8 73 501 34.3 14.6 70 1378 101.1 13.6 050B 14.4 140B 13.8 45 309 21.5 14.3 46 896 64.8 13.8 23 158 11.3 14.0 19 365 27.2 13.5 100 753 51.5 14.6 100 2143 156.0 13.7 76 569 38.8 14.7 67 1437 104.6 13.7 055B 14.5 155B 13.7 50 376 26.3 14.3 50 1071 78.5 13.6 26 193 13.6 14.2 17 365 27.2 13.5 100 836 58.3 14.3 73 611 41.1 14.9 060B 14.6 45 376 26.3 14.3 23 193 13.6 14.2 NOTE: Certified according to ARI Standard 365-2002. For IPLV calculations, the full load and part load ratings are at 80°F ambient air temperature and 50°F suction temperature, with 15 degrees F superheat. 010A

20


Catalog ACZ-4

Sound Data Table 9, ACZ 010A-155B Sound Pressure, w/o Sound Insulation ACZ Unit Model 010A 013A 016A 020A 025A 028A 033A 039A 030B 035B 040B 045B 050B 055B 060B 065B 070B 080B 090B 100B 110B 120B 130B 140B 155B

63 52 52 53 58 58 58 59 61 65 65 65 65 66 66 66 67 68 68 68 67 67 66 66 67 67

125 52 52 54 56 57 58 59 62 64 64 64 64 65 66 66 66 67 68 68 65 66 68 69 68 69

Octave Band at Center Frequency 250 500 1000 2000 52 54 48 46 52 54 48 46 54 55 48 47 55 53 52 50 56 54 52 50 56 55 52 50 61 58 54 53 63 59 55 54 61 60 56 51 61 60 56 51 62 60 56 51 63 61 57 52 64 62 58 52 64 62 58 52 66 62 59 54 67 62 59 54 67 62 60 54 67 62 60 54 68 62 60 54 65 64 62 56 66 64 62 56 65 65 62 56 66 65 62 56 66 65 62 58 67 65 62 59

4000 44 44 45 48 48 48 51 53 46 46 46 47 47 47 49 49 49 49 49 54 54 56 56 59 59

8000 42 42 42 48 48 48 50 51 41 41 41 42 42 42 44 44 44 44 44 54 54 55 55 56 56

Overall A-Weighted 55 55 56 57 58 58 61 63 61 61 61 62 63 63 64 64 65 65 65 66 66 67 67 68 68

8000 69 69 69 75 75 75 77 78 68 68 68 69 69 69 71 71 71 71 71 81 81 82 82 83 83


Note: Data at: 1. 30 feet (9m) from side of unit. 2. Q=2, unit on a flat roof or ground with no adjacent wall. 3. Octave band readings are flat dB, overall is “A” weighted.

Table 10, ACZ 010A-155B Sound Power, w/o Sound Insulation ACZ Unit Model 010A 013A 016A 020A 025A 028A 033A 039A 030B 035B 040B 045B 050B 055B 060B 065B 070B 080B 090B 100B 110B 120B 130B 140B 155B

63 79 79 80 85 85 85 86 88 92 92 92 92 93 93 93 94 95 95 95 94 94 93 93 94 94

Octave Band at Center Frequency (per ARI Standard 370) 125 250 500 1000 2000 4000 79 79 81 75 73 71 79 79 81 75 73 71 81 81 82 75 74 72 83 82 80 79 77 75 84 83 81 79 77 75 85 83 82 79 77 75 86 88 85 81 80 78 89 90 86 82 81 80 91 88 87 83 78 73 91 88 87 83 78 73 91 89 87 83 78 73 91 90 88 84 79 74 92 91 89 85 79 74 93 91 89 85 79 74 93 93 89 86 81 76 93 94 89 86 81 76 94 94 89 87 81 76 95 94 89 87 81 76 95 95 89 87 81 76 92 92 91 89 83 81 93 93 91 89 83 81 95 92 92 89 83 83 96 93 92 89 83 83 95 93 92 89 85 86 96 94 92 89 86 86

Sound data for units with sound insulation are on the next page.

Catalog ACZ-4


21

Table 11, ACZ 010A-1550B Sound Pressure w/ Sound Insulation ACZ Unit Model 010A 013A 016A 020A 025A 028A 033A 039A 030B 035B 040B 045B 050B 055B 060B 065B 070B 080B 090B 100B 110B 120B 130B 140B 155B

Number of Number of Comp. Fans 2 2 2 2 2 2 2 2 2 3 2 3 2 3 2 3 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 6 4 6 4 6 6 6 6 6 6 6 6 6

8000 41 41 41 42 43 43 43 43 44 43 43 43 43 43 43 43 43 43 43 44 44 44 44 44 44


Octave Band at Center Frequency (per ARI Standard 370) 63 125 250 500 1000 2000 4000 8000 79 79 78 79 73 72 70 68 79 79 78 79 73 72 70 68 79 80 78 80 74 72 70 68 79 80 80 81 74 72 71 69 80 81 81 82 75 73 72 70 81 81 81 82 75 73 72 70 81 81 82 83 76 74 73 70 82 82 83 84 77 75 74 70 84 84 84 86 79 76 75 71 84 84 83 84 77 75 74 70 84 84 83 84 77 75 74 70 84 84 83 84 77 75 74 70 85 85 85 86 80 77 75 70 85 85 85 86 80 77 75 70 85 85 85 86 80 77 75 70 85 85 85 86 80 77 75 70 86 85 85 86 80 77 75 70 88 85 85 86 80 77 75 70 88 85 86 86 81 81 77 70 88 86 86 86 83 80 77 71 88 86 86 86 83 80 77 71 90 86 86 86 83 80 77 71 90 86 86 86 83 80 77 71 90 86 87 86 83 80 77 71 90 86 87 87 84 80 77 71


63 52 52 52 52 43 54 54 55 57 57 57 57 58 58 58 58 59 61 61 61 61 63 63 63 63

125 52 52 53 53 54 54 54 55 57 57 57 57 58 58 58 58 58 58 58 59 59 59 59 59 59

Octave Band at Center Frequency 250 500 1000 2000 4000 51 52 46 45 43 51 52 46 45 43 51 53 47 45 43 53 54 47 45 44 54 55 48 46 45 54 55 48 46 45 55 56 49 47 46 56 57 50 48 47 57 59 52 49 48 56 57 50 48 47 56 57 50 48 47 56 57 50 48 47 58 59 53 50 48 58 59 53 50 48 58 59 53 50 48 58 59 53 50 48 58 59 53 50 48 58 59 53 50 48 59 59 54 54 50 59 59 56 53 50 59 59 56 53 50 59 59 56 53 50 59 59 56 53 50 60 59 56 53 50 60 60 57 53 50

Notes: Data at: 1. 30 feet (9m) from side of unit. 2. Q=2, unit on a flat roof or ground with no adjacent wall. 3. Octave band readings are flat dB, overall is “A” weighted.

Table 12, ACZ 010A-155B Sound Power w/ Sound insulation ACZ Unit Model 010A 013A 016A 020A 025A 028A 033A 039A 030B 035B 040B 045B 050B 055B 060B 065B 070B 080B 090B 100B 110B 120B 130B 140B 155B

Number of Number of Comp. Fans 2 2 2 2 2 2 2 2 2 3 2 3 2 3 2 3 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 6 4 6 4 6 6 8 6 8 6 8 6 8

Note: Octave band readings are flat dB, overall is “A” weighted.

22


Catalog ACZ-4

Sound levels can be as important as unit cost and efficiency, and must be addressed before the start of any development program. Efforts by McQuay Design Engineers to design units that are sensitive to the sound requirements of the market, combined with inherently quiet scroll compressors, have paid off.

Background Information Sound is a vibration in an elastic medium and is essentially a pressure and particle displacement phenomena. A vibrating body produces compression waves, and as the waves are emitted from the vibrating body, molecules are ultimately compressed. These values are transmitted through gas, liquid, solid⎯anything which is elastic or viscous. The sound data provided in this section is presented with both sound pressure and sound power levels. Sound power is the total sound energy radiated by a source per unit of time integrated over the surface through which the sound is radiated. Sound power is a calculated quantity and cannot be measured directly like sound pressure. Sound power is not dependent on the surrounding environment or distance from the source, as is sound pressure. Sound pressure varies with the distance from the source and is dependent on its surroundings. For example, a brick wall located 10 feet from a unit will affect the sound pressure measurements differently than a brick wall at 20 feet. Sound pressure is measured in decibels (dB), which is a dimensionless ratio (on a logarithmic scale) between measured sound pressure and a reference sound pressure level.

Sound Pressure Levels - Full Load All sound pressure tables give the overall "A" weighted sound pressure levels which are considered typical of what can be measured in a free field with a hand held sound meter, in the absence of any nearby reflective surfaces. The sound pressure levels are measured at 30 feet (10 meters) from the side of the unit at 100% unit load and ARI conditions. 95°F (35°C) ambient air temperature and 50°F suction temperature.

Sound Power Levels Acoustical consultants can require sound power octave band data to perform a detailed acoustical analysis. The tables present sound power levels per ARI Standard 370, “Sound Rating of Large Outdoor Refrigerating and Air Conditioning Equipment”. These standards were developed to establish uniform methods of determining the sound power radiated by large outdoor and indoor equipment. The aforementioned methods are based on providing sound power levels by octave band and the overall ‘A’ weighted value. Measurements are taken over a prescribed area around the unit and the data is mathematically calculated to give the sound power, dB. Sound power can be thought of as basic sound level emanating from the unit without consideration of distance or obstructions.

Sound Reduction due to Distance from the Unit The distance between a source of sound and the location of the sound measurement plays an important role in minimizing sound problems. The equation below can be used to calculate the sound pressure level at any distance if the sound power is known. Results for typical distances are tabulated in Table 13. Another way of determining the effect of distance is to work from sound pressure only. “Q”, the directionality factor, is a dimensionless number that compensates for the type of sound reflection from the source. For example, a unit sitting on a flat roof or ground with no other reflective surfaces or attenuation due to grass, snow, etc., between source and receiver: Q=2.

Catalog ACZ-4


23

Figure 9, "Q" Definition, Plan View, Unit Located in Center

Uniform Spherical Radiation Q=1 no reflecting surface

Uniform Hemispherical Radiation Q=2 single reflecting surface

Uniform Radiation over ¼ of sphere Q=4 two reflecting surfaces

Sound pressure can be calculated at any distance from the unit if the sound power is known. Lp=Lw-(20 log r) + (10 log Q) - .5 Lp = sound pressure

r = distance from unit in feet

Lw = sound power

Q = directionality factor

With Q=1, Unit suspended in space (theoretical condition), the equation simplifies to: Lp = Lw – (20)(log r) –0.5 With Q=2, for a unit sitting on a flat roof or ground with no adjacent vertical wall as a reflective surface, the equation simplifies to: Lp = Lw – (20)(log r) + 2.5 With Q=4 for a unit sitting on a flat roof or ground with one adjacent vertical wall as a reflective surface, the equation simplifies to: Lp = Lw – (20)(log r) + 5.5 The equations are reduced to table form in Table 13 for various distances and the two most usual cases of “Q” type of location. Table 13, dB Conversion of Sound Power to Pressure for Distance Distance from Sound Source ft. (m)

24

dB Reduction from Sound Power at the Source to Sound Pressure at Referenced Distance Q=2 Q=4

30 (9)

27.1

24.0

50 (15)

31.6

28.5

75 (23)

35.1

32.0

100 (30)

37.6

34.5

150 (46)

41.1

38.0

200 (61)

43.6

40.5

300 (91)

47.6

44.0


Catalog ACZ-4

Figure 10, Sound Pressure Attenuation Due to Distance from Unit

Sound Pressure Reduction - Low Ambient Conditions Unit operation at a lower ambient temperature than 95°F (35°C) will also result in lower sound pressure levels. The sound pressure level will decrease 1 dBA for ambient temperatures between 85°F and 94°F (29.4°C and 34.4°C), 2 dBA for ambient temperatures between 75°F and 84°F (23.9°C and 28.9°C), and 3 dBA for ambient temperatures between 65°F and 74°F (18.3°C and 23.3°C). Figure 11, Model ACZ 155B, Nominal 158 Ton Condensing Unit

Catalog ACZ-4


25

Electrical Data, General There are many installations where the expected summer ambient air temperatures will be at 105°F (40.1°C) or less, resulting in smaller unit electrical requirements compared to operation at 106°F (41.1°C) and above. In these lower temperature cases, there can be considerable installation cost savings by using smaller and more appropriate electrical service. Single circuit models, ACZ-A, are rated to 115°F (46°C) as standard. There is no High Ambient Option. For two circuit models, ACZ-B, the electrical data is divided into two classifications based on the ambient environment where the unit will operate. “Standard Units” operate in ambient temperatures of 105°F or less. Units with the “High Ambient” option will be for ambient temperatures above 105°F. The “Standard Ambient” ACZ-B units have lower electrical requirements where possible. This electrical data will be listed on the unit’s nameplate shipping from the factory. Units with the “High Ambient” option will include not only the addition of a small fan with a filter in the air intake to cool the control , but also a different unit nameplate that lists the larger electrical requirements. Models ACZ 030B – 155B Winter Operation Fan Control Design Ambient Air Temperature Electrical Data (3) Fan Required (4) Model

0°F to 34°F

35°F and Above

Optional VFD (1)

Standard FanTrol (2)

<105°F Standard Ambient Yes

>106°F High Ambient Yes

<105°F Standard Ambient No

>106°F High Ambient Yes

BC

BH

BC

BH

Notes: 1. VFD is variable speed, fan control through the MicroTech II controller. 2. FanTrol is fan cycling off discharge pressure. 3. The VFD option automatically includes the factory-installed fan and filter set.

26


Catalog ACZ-4

Electrical Data, Standard Ambient Table 14, ACZ 010A – 039A, Single Point Electrical Data (to 115°F Ambient) Power Supply ACZ Unit Size

Volts

Minimum Circuit Ampacity (MCA)

Hub (Conduit Connection)

Field Wire

Quantity

Wire Gauge 75C

Quantity

Field Fuse Size or HACR (Heating/AirConditioning/Refrigeration) Breaker Size

Nominal Size Recommended In. (mm)

Maximum

010A

208 230 460 575

45 45 22 18

3 3 3 3

8 8 10 10

1 1 1 1

1.00 (25) 1.00 (25) 1.00 (25) 1.00 (25)

50 50 25 20

50 50 25 20

013A

208 230 460 575

54 54 26 23

3 3 3 3

6 6 10 10

1 1 1 1

1.00 (25) 1.00 (25) 1.00 (25) 1.00 (25)

60 60 30 25

70 70 35 30

208 230 460 575

65 65 34 27

3 3 3 3

6 6 10 10

1 1 1 1

1.00 (25) 1.00 (25) 1.00 (25) 1.00 (25)

80 80 40 30

80 80 45 35

020A

208 230 460 575

79 79 41 33

3 3 3 3

4 4 8 10

1 1 1 1

1.00 (25) 1.00 (25) 1.00 (25) 1.00 (25)

90 90 45 40

100 100 50 40

025A

208 230 460 575

103 103 53 45

3 3 3 3

2 2 6 8

1 1 1 1

1.25 (32) 1.25 (32) 1.00 (25) 1.00 (25)

125 125 60 50

125 125 70 60

028A

208 230 460 575

110 110 58 48

3 3 3 3

2 2 6 8

1 1 1 1

1.25 (32) 1.25 (32) 1.00 (25) 1.00 (25)

125 125 70 60

150 150 80 60

033A

208 230 460 575

127 127 62 58

3 3 3 3

1 1 6 6

1 1 1 1

1.50 (38) 1.50 (38) 1.00 (25) 1.00 (25)

150 150 70 70

175 175 80 70

039A

208 230 460 575

182 182 79 63

3 3 3 3

3/0 3/0 4 6

1 1 1 1

1.50 (38) 1.50 (38) 1.00 (25) 1.00 (25)

225 225 90 80

250 250 100 80

016A

NOTE: See page 46 for all Electrical Data notes.

Catalog ACZ-4


27

Table 15, ACZ 030B – 065B, Single Point Power Electrical Data (to 105°F Ambient Temperature)

Wire Gauge

Recomm’d. Fuse Or HACR Breaker Size

Max. Fuse Or HACR Breaker Size

3 3 3 3 3

1/0 #1 #4 #4 #6

150 150 90 80 60

150 150 90 80 60

146 143 88 74 58

3 3 3 3 3

1/0 1/0 #3 #4 #6

175 175 100 80 70

175 175 100 90 70

040

208 230 380 460 575

158 150 96 79 64

3 3 3 3 3

2/0 1/0 #3 #4 #6

175 175 110 90 70

175 175 110 90 70

045

208 230 380 460 575

167 167 113 81 70

3 3 3 3 3

2/0 2/0 #2 #4 #4

200 200 125 90 80

200 200 125 90 80

050

208 230 380 460 575

184 184 121 94 78

3 3 3 3 3

3/0 3/0 #1 #3 #4

225 225 125 110 90

225 225 125 110 90

055

208 230 380 460 575

199 199 127 104 86

3 3 3 3 3

3/0 3/0 #1 #2 #3

225 225 150 125 100

225 225 150 125 100

060

208 230 380 460 575

221 214 145 108 96

3 3 3 3 3

4/0 4/0 1/0 #2 #3

250 250 175 125 110

250 250 175 125 110

065

208 230 380 460 575

248 228 156 112 105

3 3 3 3 3

250 4/0 2/0 #2 #2

300 250 175 150 125

300 250 175 150 125

POWER SUPPLY


Quantity

030

208 230 380 460 575

133 126 80 68 52

035

208 230 380 460 575

ACZ-B Unit Size

Volts

Field Wire

NOTES: 1. See page 46 for all other Electrical Data notes. 2. Conduit hubs are not provided.

28


Catalog ACZ-4

Table 16, ACZ 070B - 155B 60 Hz, Single Point Electrical Power (to 105°F Ambient Temperature) Minimum Circuit Ampacity (MCA)

POWER SUPPLY Field Wire

Recomm’d. Fuse Or HACR Breaker Size

Max. Fuse Or HACR Breaker Size

300 300 2/0 #1 #2

350 350 200 150 125

350 350 200 150 125

3 3 3 3 3

350 350 2/0 #1 #2

350 350 200 150 125

350 350 200 150 125

358 358 187 150 125

6 6 3 3 3

4/0 4/0 3/0 1/0 #1

400 400 225 175 150

400 400 225 175 150

100

208 230 380 460 575

380 380 219 171 136

6 6 3 3 3

250 250 250 2/0 1/0

450 450 250 200 150

450 450 250 200 150

110

208 230 380 460 575

414 414 248 188 146

6 6 3 3 3

300 300 250 3/0 1/0

500 500 300 225 175

500 500 300 225 175

120

208 230 380 460 575

463 463 260 199 171

6 6 3 3 3

350 300 300 3/0 2/0

500 500 300 225 175

500 500 300 225 175

130

208 230 380 460 575

528 528 282 220 182

6 - (2) 6 - (2) 3 3 3

300 300 300 4/0 3/0

600 600 300 250 200

600 600 300 250 200

140

208 230 380 460 575

613 613 323 248 198

6 - (2) 6 - (2) 3 3 3

350 350 400 250 3/0

700 700 350 250 225

700 700 350 250 225

155

208 230 380 460 575

613 613 361 273 212

6 - (2) 6 - (2) 6 3 3

350 350 4/0 300 4/0

700 700 400 300 225

700 700 400 300 225

ACZ-B Unit Size

Volts

070

208 230 380 460 575

281 281 162 124 109

3 3 3 3 3

080

208 230 380 460 575

301 301 168 130 112

090

208 230 380 460 575

Quantity Wire Gauge

NOTES: 1. See page 46 for all other Electrical Data notes. 2. (2) indicates that two conduits are required. 3. Conduit hubs are not provided.

Catalog ACZ-4


29

Table 17, ACZ 010A – 039A Compressor and Condenser Fan Motor Amp Draw ACZ Unit Size

Volts

010A

208 230 460 575

013A

208 230 460 575

016A

208 230 460 575

020A

208 230 460 575

025A

208 230 460 575

028A

208 230 460 575

033A

208 230 460 575

039A

208 230 460 575

Hz.

Rated Load Amps F.L. Amps Fan Motor No. 1 No. 2 (Each)

60

14.8 14.8 7.1 5.8

14.8 14.8 7.1 5.8

5.8 5.8 2.8 2.5

2 2 2 2

23.7 21.4 10.7 11.0

91 91 50 37

91 91 50 37

60

18.6 18.6 9.1 7.4

18.6 18.6 9.1 7.4

5.8 5.8 2.8 2.5

2 2 2 2

23.7 21.4 10.7 11.0

156 156 75 54

156 156 75 54

60

23.7 23.7 12.5 9.1

23.7 23.7 12.5 9.1

5.8 5.8 2.8 2.5

2 2 2 2

23.7 21.4 10.7 11.0

189 189 99 74

189 189 99 74

60

29.9 29.9 15.3 11.6

29.9 29.9 15.3 11.6

5.8 5.8 2.8 2.5

2 2 2 2

23.7 21.4 10.7 11.0

232 232 125 100

232 232 125 100

60

33.6 33.6 16.5 13.7

41 41 21.8 17.3

5.8 5.8 2.8 2.5

3 3 3 3

23.7 21.4 10.7 11.0

278 278 127 100

350 350 158 125

60

41.0 41.0 21.8 17.3

41.0 41.0 21.8 17.3

5.8 5.8 2.8 2.5

3 3 3 3

23.7 21.4 10.7 11.0

350 350 158 125

350 350 158 125

60

48.5 48.5 23.7 21.7

48.5 48.5 23.7 21.7

5.8 5.8 2.8 2.5

3 3 3 3

23.7 21.4 10.7 11.0

425 425 187 148

425 425 187 148

60

73.1 73.1 31.0 24.4

73.1 73.1 31.0 24.4

5.8 5.8 2.8 2.5

3 3 3 3

23.7 21.4 10.7 11.0

505 505 225 180

505 505 225 180

Compressors

No. of Fan Mtrs

Locked Rotor Amps L.R.Amps Compressors Fan Across-The-Line Motor No. 1 No. 2 (Each)


30


Catalog ACZ-4

Table 18, ACZ 030B - 065B, Compressor And Condenser Fan Motor Amp Draw Rated Load Amps ACZ-B F.L.Amps No. Of Compressors Fan Unit Volts Fan Motors Size Motors No. 1 No. 3 No. 5 No. 2 No. 4 No. 6 (Each)

Locked Rotor Amps Compressors

Fan Motors (Each)

No.1

Across-The-Line No. 3 No. 5

No.2

No.4

No. 6

030

208 230 380 460 575

25.7 24.2 14.9 13.4 9.3

25.7 24.2 14.9 13.4 9.3

-

25.7 24.2 14.9 13.4 9.3

25.7 24.2 14.9 13.4 9.3

-

5.8 5.8 4.1 2.8 3.0

4 4 4 4 4

23.3 26.1 20.0 13.0 14.0

189 189 112 99 74

189 189 112 99 74

-

189 189 112 99 74

189 189 112 99 74

-

035

208 230 380 460 575

25.7 24.2 14.9 13.4 9.3

25.7 24.2 14.9 13.4 9.3

-

31.8 31.8 18.6 16.0 12.2

31.8 31.8 18.6 16.0 12.2

-

5.8 5.8 4.1 2.8 3.0

4 4 4 4 4

23.3 26.1 20.0 13.0 14.0

189 189 112 99 74

189 189 112 99 74

-

232 232 144 125 100

232 232 144 125 100

-

040

208 230 380 460 575

31.8 29.9 18.6 16.0 12.2

31.8 29.9 18.6 16.0 12.2

-

31.8 29.9 18.6 16.0 12.2

31.8 29.9 18.6 16.0 12.2

-

5.8 5.8 4.1 2.8 3.0

4 4 4 4 4

23.3 26.1 20.0 13.0 14.0

232 232 144 125 100

232 232 144 125 100

-

232 232 144 125 100

232 232 144 125 100

-

045

208 230 380 460 575

33.8 33.8 22.8 16.5 13.7

33.8 33.8 22.8 16.5 13.7

-

33.8 33.8 22.8 16.5 13.7

33.8 33.8 22.8 16.5 13.7

-

5.8 5.8 4.1 2.8 3.0

4 4 4 4 4

23.3 26.1 20.0 13.0 14.0

278 278 151 127 100

278 278 151 127 100

-

278 278 151 127 100

278 278 151 127 100

-

050

208 230 380 460 575

33.8 33.8 22.8 16.5 13.7

33.8 33.8 22.8 16.5 13.7

-

41.4 41.4 26.0 21.8 17.3

41.4 41.4 26.0 21.8 17.3

-

5.8 5.8 4.1 2.8 3.0

4 4 4 4 4

23.3 26.1 20.0 13.0 14.0

278 278 151 127 100

278 278 151 127 100

-

350 350 195 158 125

350 350 195 158 125

-

055

208 230 380 460 575

41.4 41.4 26.0 21.8 17.3

41.4 41.4 26.0 21.8 17.3

-

41.4 41.4 26.0 21.8 17.3

41.4 41.4 26.0 21.8 17.3

-

5.8 5.8 4.1 2.8 3.0

4 4 4 4 4

23.3 26.1 20.0 13.0 14.0

350 350 195 158 125

350 350 195 158 125

-

350 350 195 158 125

350 350 195 158 125

-

060

208 230 380 460 575

41.0 41.0 26.0 21.8 17.3

41.0 41.0 26.0 21.8 17.3

-

51.3 48.1 33.8 23.7 21.8

51.3 48.1 33.8 23.7 21.8

-

5.8 5.8 4.1 2.8 3.0

4 4 4 4 4

23.3 26.1 20.0 13.0 14.0

350 350 195 158 125

350 350 195 158 125

-

425 425 239 187 148

425 425 239 187 148

-

065

208 230 380 460 575

52.8 48.1 32.7 23.7 21.8

52.8 48.1 32.7 23.7 21.8

-

52.8 48.1 32.7 23.7 21.8

52.8 48.1 32.7 23.7 21.8

-

5.8 5.8 4.1 2.8 3.0

4 4 4 4 4

23.3 26.1 20.0 13.0 14.0

425 425 239 187 148

425 425 239 187 148

-

425 425 239 187 148

425 425 239 187 148

-


Catalog ACZ-4


31

Table 19, ACZ 070B - 155B, Compressor And Condenser Fan Motor Amp Draw Rated Load Amps Locked Rotor Amps F.L. Compressors Compressors No. Of ACZ-B Fan Amps Fan Unit Volts Across-The-Line Motors Fan Size No. 1 No. 2 No. 3 No. 4 No. 5 No. 6 Motors Motors (Each) No.1 No. 3 No. 5 No.2 No.4 (Each)

No. 6

070

208 230 380 460 575

52.8 52.8 32.7 23.7 21.8

52.8 52.8 32.7 23.7 21.8

-

52.8 52.8 32.7 23.7 21.8

73.1 73.1 38.2 30.1 25.2

-

7.8 7.8 4.1 3.6 3.0

4 4 4 4 4

31.7 35.6 20.0 17.8 14.0

425 425 239 187 148

425 425 239 187 148

-

425 425 239 187 148

505 505 280 225 180

-

080

208 230 380 460 575

52.8 52.8 32.7 23.7 21.8

73.1 73.1 38.2 30.1 25.2

-

52.8 52.8 32.7 23.7 21.8

73.1 73.1 38.2 30.1 25.2

-

7.8 7.8 4.1 3.6 3.0

4 4 4 4 4

31.7 35.6 20.0 17.8 14.0

425 425 239 187 148

505 505 280 225 180

-

425 425 239 187 148

505 505 280 225 180

-

090

208 230 380 460 575

73.1 73.1 38.2 30.1 25.2

73.1 73.1 38.2 30.1 25.2

-

73.1 73.1 38.2 30.1 25.2

73.1 73.1 38.2 30.1 25.2

-

7.8 7.8 4.1 3.6 3.0

6 6 6 6 6

31.7 35.6 20.0 17.8 14.0

505 505 280 225 180

505 505 280 225 180

-

505 505 280 225 180

505 505 280 225 180

-

100

208 230 380 460 575

73.1 73.1 38.2 30.1 25.2

73.1 73.1 38.2 30.1 25.2

-

83.3 83.3 52.5 39.0 30.0

83.3 83.3 52.5 39.0 30.0

-

7.8 7.8 4.1 3.6 3.0

6 6 6 6 6

31.7 35.6 20.0 17.8 14.0

505 505 280 225 180

505 505 280 225 180

-

500 500 305 250 198

500 500 305 250 198

-

110

208 230 380 460 575

86.4 86.4 52.5 39.0 30.0

86.4 86.4 52.5 39.0 30.0

-

86.4 86.4 52.5 39.0 30.0

86.4 86.4 52.5 39.0 30.0

-

7.8 7.8 4.1 3.6 3.0

6 6 6 6 6

31.7 35.6 20.0 17.8 14.0

500 500 305 250 198

500 500 305 250 198

-

500 500 305 250 198

500 500 305 250 198

-

120

208 230 380 460 575

52.8 52.8 32.7 23.7 21.8

52.8 52.8 32.7 23.7 21.8

52.8 52.8 32.7 23.7 21.8

74.5 74.5 39.8 30.6 25.2

74.5 74.5 39.8 30.6 25.2

74.5 74.5 39.8 30.6 25.2

7.8 7.8 4.1 3.6 3.0

8 8 8 8 8

31.7 35.6 20.0 17.8 14.0

425 425 239 187 148

425 425 239 187 148

425 425 239 187 148

505 505 280 225 180

505 505 280 225 180

505 505 280 225 180

130

208 230 380 460 575

74.5 74.5 39.8 30.6 25.2

74.5 74.5 39.8 30.6 25.2

74.5 74.5 39.8 30.6 25.2

74.5 74.5 39.8 30.6 25.2

74.5 74.5 39.8 30.6 25.2

74.5 74.5 39.8 30.6 25.2

7.8 7.8 4.1 3.6 3.0

8 8 8 8 8

31.7 35.6 20.0 17.8 14.0

505 505 280 225 180

505 505 280 225 180

505 505 280 225 180

505 505 280 225 180

505 505 280 225 180

505 505 280 225 180

140

208 230 380 460 575

87.9 87.9 39.8 30.6 25.2

87.9 87.9 39.8 30.6 25.2

87.9 87.9 39.8 30.6 25.2

88.0 88.0 52.5 39.0 30.0

88.0 88.0 52.5 39.0 30.0

88.0 88.0 52.5 39.0 30.0

7.8 7.8 4.1 3.6 3.0

8 8 8 8 8

31.7 35.6 20.0 17.8 14.0

505 505 280 225 180

505 505 280 225 180

505 505 280 225 180

500 500 305 250 198

500 500 305 250 198

500 500 305 250 198

155

208 230 380 460 575

88.0 88.0 52.5 39.0 30.0

88.0 88.0 52.5 39.0 30.0

88.0 88.0 52.5 39.0 30.0

88.0 88.0 52.5 39.0 30.0

88.0 88.0 52.5 39.0 30.0

88.0 88.0 52.5 39.0 30.0

7.8 7.8 4.1 3.6 3.0

8 8 8 8 8

31.7 35.6 20.0 17.8 14.0

500 500 305 250 198

500 500 305 250 198

500 500 305 250 198

500 500 305 250 198

500 500 305 250 198

500 500 305 250 198


32


Catalog ACZ-4

Table 20, ACZ 010A – 039A, Field Wiring Data, Single Point Power Wiring to Wiring to Standard Power Block Terminal Optional Disconnect Switch Maximum Connector Wire Factory Option Disconnect Terminal Range Connector Wire Range Size Amps (Copper Wire Only) (Copper Wire Only)

ACZ UNIT SIZE

Volts

010A

208 230 460 575

175 175 175 175

14 GA – 2/0 14 GA – 2/0 14 GA – 2/0 14 GA – 2/0

100 100 63 63

#8-1/0 #8-1/0 #1-#14 #1-#14

013A

208 230 460 575

175 175 175 175

14 GA – 2/0 14 GA – 2/0 14 GA – 2/0 14 GA – 2/0

100 100 63 63

#8-1/0 #8-1/0 #1-#14 #1-#14

016A

208 230 460 575

175 175 175 175

14 GA – 2/0 14 GA – 2/0 14 GA – 2/0 14 GA – 2/0

100 100 63 63

#8-1/0 #8-1/0 #1-#14 #1-#14

020A

208 230 460 575

175 175 175 175

14 GA – 2/0 14 GA – 2/0 14 GA – 2/0 14 GA – 2/0

100 100 63 63

#10-1/0 #10-1/0 #1-#14 #1-#14

025A

208 230 460 575

175 175 175 175

14 GA – 2/0 14 GA – 2/0 14 GA – 2/0 14 GA – 2/0

225 225 100 100

#2-4/0 #2-4/0 #8-1/0 #10-1/0

028A

208 230 460 575

175 175 175 175

14 GA – 2/0 14 GA – 2/0 14 GA – 2/0 14 GA – 2/0

225 225 100 100

#2-4/0 #2-4/0 #8-1/0 #10-1/0

033A

208 230 460 575

175 175 175 175

14 GA – 2/0 14 GA – 2/0 14 GA – 2/0 14 GA – 2/0

225 225 100 100

#2-4/0 #2-4/0 #8-1/0 #10-1/0

039A

208 230 460 575

335 335 175 175

6 GA – 400 kcmil 6 GA – 400 kcmil 14 GA – 2/0 14 GA – 2/0

225 225 125 100

#2-4/0 #2-4/0 #3-3/0 #10-1/0


Catalog ACZ-4


33

Table 21, ACZ 030B – 065B, Field Wiring Data, Single Point Power Wiring to Standard Power Block Connector Wire Terminal Range Amps (Copper Wire Only)

ACZ Unit Size

Volts

030B

208 230 380 460 575

175 175 175 175 175

035B

208 230 380 460 575

Wiring to Optional Non-Fused Disconnect Switch Disconnect Size

Connector Wire Range (Copper Wire Only)

14 GA – 2/0 14 GA – 2/0 14 GA – 2/0 14 GA – 2/0 14 GA – 2/0

225 225 150 150 150

# 4 - 300 kcmil # 4 - 300 kcmil # 4 - 300 kcmil # 4 - 300 kcmil # 4 - 300 kcmil

380 380 175 175 175

#4 – 500 kcmil #4 – 500 kcmil 14 GA – 2/0 14 GA – 2/0 14 GA – 2/0

225 225 150 150 150


040B

208 230 380 460 575

380 380 175 175 175


225 225 150 150 150


045B

208 230 380 460 575

380 380 175 175 175


225 225 150 150 150


050B

208 230 380 460 575

380 380 175 175 175


225 225 150 150 150


055B

208 230 380 460 575

380 380 175 175 175


250 250 150 150 150

#6 - 350 kcmil #6 - 350 kcmil # 4 - 300 kcmil # 4 - 300 kcmil # 4 - 300 kcmil

060B

208 230 380 460 575

380 380 175 175 175


400 400 250 150 150

250 kcmil -500 kcmil 250 kcmil -500 kcmil #6 - 350 kcmil # 4 - 300 kcmil # 4 - 300 kcmil

065B

208 230 380 460 575

380 380 380 175 175

#4 – 500 kcmil #4 – 500 kcmil #4 – 500 kcmil 14 GA – 2/0 14 GA – 2/0

400 400 250 150 150



34


Catalog ACZ-4

Table 22, ACZ 070B - 155B, 60 Hz, Field Wiring Data, Single Point Wiring to Standard Power Block Connector Wire Terminal Range Amps (Copper Wire Only)

ACZ Unit Size

Volts

070B

208 230 380 460 575

380 380 380 175 175

080B

208 230 380 460 575

Wiring to Optional Non-Fused Disconnect Switch Disconnect Size

Connector Wire Range (Copper Wire Only)

#4 – 500 kcmil #4 – 500 kcmil #4 – 500 kcmil 14 GA – 2/0 14 GA – 2/0

400 400 250 250 150


380 380 380 380 175

#4 – 500 kcmil #4 – 500 kcmil #4 – 500 kcmil #4 – 500 kcmil 14 GA – 2/0

400 400 250 250 150


090B

208 230 380 460 575

760 760 380 380 380

2 GA – 500 kcmil 2 GA – 500 kcmil #4 – 500 kcmil #4 – 500 kcmil #4 – 500 kcmil

600 600 250 250 250

(2) 250 kcmil -500 kcmil (2) 250 kcmil -500 kcmil #6 - 350 kcmil #6 - 350 kcmil #6 - 350 kcmil

100B

208 230 380 460 575

760 760 380 380 380


600 600 400 250 250

(2) 250 kcmil -500 kcmil (2) 250 kcmil -500 kcmil 250 kcmil -500 kcmil #6 - 350 kcmil #6 - 350 kcmil

110B

208 230 380 460 575

760 760 380 380 380


600 600 400 250 250

(2) 250 kcmil -500 kcmil (2) 250 kcmil -500 kcmil 250 kcmil -500 kcmil #6 - 350 kcmil #6 - 350 kcmil

120B

208 230 380 460 575

760 760 380 380 380


600 600 400 400 250

(2) 250 kcmil -500 kcmil (2) 250 kcmil -500 kcmil 250 kcmil -500 kcmil 250 kcmil -500 kcmil #6 - 350 kcmil

130B

208 230 380 460 575

760 760 380 380 380


800 800 400 400 400

(2) 250 kcmil -500 kcmil (2) 250 kcmil -500 kcmil 250 kcmil -500 kcmil (2) 3/0-250 kcmil (2) 3/0-250 kcmil

140B

208 230 380 460 575

760 760 380 380 380


800 800 400 400 400

(2) 250 kcmil -500 kcmil (2) 250 kcmil -500 kcmil 250 kcmil -500 kcmil 250 kcmil -500 kcmil (2) 3/0-250 kcmil

155B

208 230 380 460 575

760 760 760 380 380

2 GA – 500 kcmil 2 GA – 500 kcmil 2 GA – 500 kcmil #4 – 500 kcmil #4 – 500 kcmil

800 800 600 400 400

(2) 250 kcmil -500 kcmil (2) 250 kcmil -500 kcmil (2) 3/0-250 kcmil 250 kcmil -500 kcmil (2) 3/0-250 kcmil

NOTE: See page 46 for all Electrical Data notes. .

Catalog ACZ-4


35

Table 23, ACZ 030B - 065B, 60 Hz, Multi-Point, Power Electrical Data (to 105°F Ambient Temperature) Electrical Circuit #1 ACZ Unit Size

Electrical Circuit #2

Max. Recomm’d Minimum Power Supply Fuse Fuse Volts Circuit Field Wire or HACR or HACR Ampacity Breaker Breaker Wire (MCA) Qty Size Size Gauge

Power Recomm’d Max. Fuse Minimum Supply Fuse Circuit Field Wire or HACR or HACR Breaker Ampacity Breaker Wire Size (MCA) Qty Size Gauge

030B

208 230 380 460 575

70 66 42 36 27

3 3 3 3 3

#4 #4 #8 #8 #10

80 80 50 45 35

90 90 50 45 35

70 66 42 36 27

3 3 3 3 3

#4 #4 #8 #8 #10

80 80 50 45 35

90 90 50 45 35

035B

208 230 380 460 575

70 66 42 36 27

3 3 3 3 3

#4 #4 #8 #8 #10

80 80 50 45 35

90 90 50 45 35

83 83 50 42 34

3 3 3 3 3

#4 #4 #8 #8 #10

100 100 60 50 40

110 100 60 50 45

040B

208 230 380 460 575

83 79 50 42 34

3 3 3 3 3

#4 #4 #8 #8 #10

100 100 60 50 40

110 100 60 50 45

83 79 50 42 34

3 3 3 3 3

#4 #4 #8 #8 #10

100 100 60 50 40

110 100 60 50 45

045B

208 230 380 460 575

88 88 60 43 37

3 3 3 3 3

#3 #3 #6 #8 #8

110 110 70 50 45

110 100 80 50 50

88 88 60 43 37

3 3 3 3 3

#3 #3 #6 #8 #8

110 110 70 50 45

110 100 80 50 50

050B

208 230 380 460 575

88 88 60 43 37

3 3 3 3 3

#3 #3 #6 #8 #8

110 110 70 50 45

110 110 80 50 50

105 105 67 55 45

3 3 3 3 3

#2 #2 #4 #6 #8

125 125 80 70 50

125 125 80 70 60

055B

208 230 380 460 575

105 105 67 55 45

3 3 3 3 3

#2 #2 #4 #6 #8

125 125 80 70 50

125 125 80 70 60

105 105 67 55 45

3 3 3 3 3

#2 #2 #4 #6 #8

125 125 80 70 50

125 125 80 70 60

060B

208 230 380 460 575

105 105 67 55 45

3 3 3 3 3

#2 #2 #4 #6 #8

125 125 80 70 50

125 125 80 70 60

130 120 82 59 55

3 3 3 3 3

#1 #1 #3 #6 #6

150 150 100 70 70

175 150 110 80 70

065B

208 230 380 460 575

130 120 82 59 55

3 3 3 3 3

#1 #1 #3 #6 #6

150 150 100 70 70

175 150 110 80 70

130 120 82 59 55

3 3 3 3 3

#1 #1 #3 #6 #6

150 150 100 70 70

175 150 110 80 70


36


Catalog ACZ-4

Table 24, ACZ 070B - 155B, 60 Hz, Multi-Point, Power Electrical Data (to 105°F Ambient Temperature) Electrical Circuit #1

Electrical Circuit #2

Power Supply Field Wire

Power Supply Field Wire

Recomm’d Max. Minimum Fuse Fuse Circuit or HACR or HACR Ampacity Breaker Breaker Wire (MCA) Size Size Gauge

Max. Recomm’d Fuse Fuse or HACR or HACR Breaker Breaker Wire Qty Size Size Gauge

ACZ Unit Size

Volts

070B

208 230 380 460 575

135 135 82 61 55

3 3 3 3 3

1/0 1/0 #4 #6 #6

175 175 100 70 70

175 175 110 80 70

160 160 89 69 59

3 3 3 3 3

2/0 2/0 #3 #4 #6

200 200 110 90 70

225 225 125 100 80

080B

208 230 380 460 575

160 160 89 69 59

3 3 3 3 3

2/0 2/0 #3 #4 #6

200 200 110 90 70

225 225 125 100 80

160 160 89 69 59

3 3 3 3 3

2/0 2/0 #3 #4 #6

200 200 110 90 70

225 225 125 100 80

090B

208 230 380 460 575

188 188 98 79 66

3 3 3 3 3

3/0 3/0 #3 #4 #4

225 225 110 90 80

250 250 125 110 90

188 188 98 79 66

3 3 3 3 3

3/0 3/0 #3 #4 #4

225 225 110 90 80

250 250 125 110 90

100B

208 230 380 460 575

188 188 98 79 66

3 3 3 3 3

3/0 3/0 #3 #4 #4

225 225 110 90 80

250 250 125 110 90

218 218 130 99 77

3 3 3 3 3

4/0 4/0 #1 #3 #4

250 250 150 125 90

300 250 175 125 100

110B

208 230 380 460 575

218 218 130 99 77

3 3 3 3 3

4/0 4/0 #1 #3 #4

250 250 150 125 90

300 250 175 125 100

218 218 130 99 77

3 3 3 3 3

4/0 4/0 #1 #3 #4

250 250 150 125 90

300 250 175 125 100

120B

208 230 380 460 575

203 203 123 92 83

3 3 3 3 3

4/0 3/0 #1 #3 #4

250 225 150 110 100

250 225 150 110 100

273 273 146 114 94

3 3 3 3 3

300 300 1/0 #1 #3

300 300 175 150 110

300 300 200 175 125

130B

208 230 380 460 575

273 273 146 114 94

3 3 3 3 3

300 300 1/0 #1 #3

300 300 175 125 110

300 300 175 125 110

273 273 146 114 94

3 3 3 3 3

300 300 1/0 #1 #3

300 300 175 125 110

300 300 175 125 110

140B

208 230 380 460 575

317 317 146 114 94

3 3 3 3 3

300 300 1/0 #1 #3

400 400 175 125 110

400 400 175 125 110

317 318 187 141 110

3 3 3 3 3

400 400 2/0 1/0 #2

400 400 225 175 125

400 400 225 175 125

155B

208 230 380 460 575

317 318 187 141 110

3 3 3 3 3

400 400 2/0 1/0 #2

400 400 225 175 125

400 400 225 175 125

317 318 187 141 110

3 3 3 3 3

400 400 2/0 1/0 #2

400 400 225 175 125

400 400 225 175 125

Minimum Circuit Ampacity (MCA) Qty


Catalog ACZ-4


37

Table 25, ACZ 030B - 065B, Multi-Point, Field Wiring Data Wiring to Standard Power Block Terminal Connector Wire Range Amps (Copper Wire Only)

Wiring to Optional Non-Fused Disconnect Switch Disconnect Connector Wire Range Size (Copper Wire Only)

ACZ Unit Size

Volts

Cir #1

Cir #2

Cir #1

Cir #2

Cir #1

Cir #2

Cir #1

Cir #2

030B

208 230 380 460 575

175 175 175 175 175

175 175 175 175 175

14 GA – 2/0 14 GA – 2/0 14 GA – 2/0 14 GA – 2/0 14 GA – 2/0

14 GA – 2/0 14 GA – 2/0 14 GA – 2/0 14 GA – 2/0 14 GA – 2/0

150 150 150 150 150

150 150 150 150 150

#14 - 1/0 #14 - 1/0 #14 - 1/0 #14 - 1/0 #14 - 1/0

#14 - 1/0 #14 - 1/0 #14 - 1/0 #14 - 1/0 #14 - 1/0

035B

208 230 380 460 575

175 175 175 175 175

175 175 175 175 175

14 GA – 2/0 14 GA – 2/0 14 GA – 2/0 14 GA – 2/0 14 GA – 2/0

14 GA – 2/0 14 GA – 2/0 14 GA – 2/0 14 GA – 2/0 14 GA – 2/0

150 150 150 150 150

150 150 150 150 150

#14 - 1/0 #14 - 1/0 #14 - 1/0 #14 - 1/0 #14 - 1/0

#14 - 1/0 #14 - 1/0 #14 - 1/0 #14 - 1/0 #14 - 1/0

040B

208 230 380 460 575

175 175 175 175 175

175 175 175 175 175

14 GA – 2/0 14 GA – 2/0 14 GA – 2/0 14 GA – 2/0 14 GA – 2/0

14 GA – 2/0 14 GA – 2/0 14 GA – 2/0 14 GA – 2/0 14 GA – 2/0

150 150 150 150 150

150 150 150 150 150

#14 - 1/0 #14 - 1/0 #14 - 1/0 #14 - 1/0 #14 - 1/0

#14 - 1/0 #14 - 1/0 #14 - 1/0 #14 - 1/0 #14 - 1/0

045B

208 230 380 460 575

175 175 175 175 175

175 175 175 175 175

14 GA – 2/0 14 GA – 2/0 14 GA – 2/0 14 GA – 2/0 14 GA – 2/0

14 GA – 2/0 14 GA – 2/0 14 GA – 2/0 14 GA – 2/0 14 GA – 2/0

150 150 150 150 150

150 150 150 150 150

#14 - 1/0 #14 - 1/0 #14 - 1/0 #14 - 1/0 #14 - 1/0

#14 - 1/0 #14 - 1/0 #14 - 1/0 #14 - 1/0 #14 - 1/0

050B

208 230 380 460 575

175 175 175 175 175

175 175 175 175 175

14 GA – 2/0 14 GA – 2/0 14 GA – 2/0 14 GA – 2/0 14 GA – 2/0

14 GA – 2/0 14 GA – 2/0 14 GA – 2/0 14 GA – 2/0 14 GA – 2/0

150 150 150 150 150

150 150 150 150 150

#14 - 1/0 #14 - 1/0 #14 - 1/0 #14 - 1/0 #14 - 1/0

#14 - 1/0 #14 - 1/0 #14 - 1/0 #14 - 1/0 #14 - 1/0

055B

208 230 380 460 575

175 175 175 175 175

175 175 175 175 175

14 GA – 2/0 14 GA – 2/0 14 GA – 2/0 14 GA – 2/0 14 GA – 2/0

14 GA – 2/0 14 GA – 2/0 14 GA – 2/0 14 GA – 2/0 14 GA – 2/0

150 150 150 150 150

150 150 150 150 150

#14 - 1/0 #14 - 1/0 #14 - 1/0 #14 - 1/0 #14 - 1/0

#14 - 1/0 #14 - 1/0 #14 - 1/0 #14 - 1/0 #14 - 1/0

060B

208 230 380 460 575

175 175 175 175 175

175 175 175 175 175

14 GA – 2/0 14 GA – 2/0 14 GA – 2/0 14 GA – 2/0 14 GA – 2/0

14 GA – 2/0 14 GA – 2/0 14 GA – 2/0 14 GA – 2/0 14 GA – 2/0

150 150 150 150 150

150 150 150 150 150

#14 - 1/0 #14 - 1/0 #14 - 1/0 #14 - 1/0 #14 - 1/0

#14 - 1/0 #14 - 1/0 #14 - 1/0 #14 - 1/0 #14 - 1/0

065B

208 230 380 460 575

175 175 175 175 175

175 175 175 175 175

14 GA – 2/0 14 GA – 2/0 14 GA – 2/0 14 GA – 2/0 14 GA – 2/0

14 GA – 2/0 14 GA – 2/0 14 GA – 2/0 14 GA – 2/0 14 GA – 2/0

150 150 150 150 150

150 150 150 150 150

#14 - 1/0 #14 - 1/0 #14 - 1/0 #14 - 1/0 #14 - 1/0

#14 - 1/0 #14 - 1/0 #14 - 1/0 #14 - 1/0 #14 - 1/0


38


Catalog ACZ-4

Table 26, ACZ 070B - 155B, Multi-Point, Field Wiring Data Wiring to Standard Power Block Connector Wire Range (Copper Wire Only)

Wiring to Optional Non-Fused Disconnect Switch Disconnect Connector Wire Range Size (Copper Wire Only)

ACZ Unit Size

Volts

Cir #1

Cir #2

Cir #1

Cir #2

Cir #1

Cir #2

Cir #1

Cir #2

070B

208 230 380 460 575

380 380 175 175 175

380 380 175 175 175



225 225 150 150 150

225 225 150 150 150

#4 – 300 kcmil #4 – 300 kcmil #14 - 1/0 #14 - 1/0 #14 - 1/0

#4 – 300 kcmil #4 – 300 kcmil #14 - 1/0 #14 - 1/0 #14 - 1/0

080B

208 230 380 460 575

380 380 175 175 175

380 380 175 175 175



225 225 150 150 150

225 225 150 150 150

#4 – 300 kcmil #4 – 300 kcmil #14 - 1/0 #14 - 1/0 #14 - 1/0

#4 – 300 kcmil #4 – 300 kcmil #14 - 1/0 #14 - 1/0 #14 - 1/0

090B

208 230 380 460 575

380 380 175 175 175

380 380 175 175 175



250 250 250 150 150

250 250 250 150 150

#4 – 300 kcmil #4 – 300 kcmil #4 – 300 kcmil #14 - 1/0 #14 - 1/0


100B

208 230 380 460 575

380 380 175 175 175

380 380 175 175 175



250 250 250 150 150

250 250 250 150 150



110B

208 230 380 460 575

380 380 175 175 175

380 380 175 175 175



250 250 250 150 150

250 250 250 150 150



120B

208 230 380 460 575

380 380 175 175 175

380 380 175 175 175



250 250 150 150 150

400 400 250 250 150

#4 – 300 kcmil #4 – 300 kcmil #14 - 1/0 #14 - 1/0 #14 - 1/0

250 – 500 kcmil 250 - 500 kcmil #4 – 300 kcmil #4 – 300 kcmil #14 - 1/0

130B

208 230 380 460 575

380 380 380 380 175

380 380 380 380 175



400 400 250 250 150

400 400 250 250 150

250 – 500 kcmil 250 – 500 kcmil 250 – 500 kcmil 250 - 500kcmil #4 – 300 kcmil #4 - 300kcmil #4 – 300 kcmil #4 - 300kcmil #14 - 1/0 #14 - 1/0

140B

208 230 380 460 575

380 380 380 380 175

380 380 380 380 175



400 400 250 250 150

400 400 250 250 150

250 – 500 kcmil 250 - 500 kcmil 250 – 500 kcmil 250 – 500 kcmil #4 – 300 kcmil #4 – 300 kcmil #4 – 300 kcmil #4 – 300 kcmil #14 - 1/0 #14 - 1/0

155B

208 230 380 460 575

380 380 380 380 175

380 380 380 380 175



400 400 250 250 150

400 400 250 250 150

250 – 500 kcmil 250 – 500 kcmil 250 – 500 kcmil 250 – 500 kcmil #4 – 300 kcmil #4 – 300 kcmil #4 – 300 kcmil #4 – 300 kcmil #14 - 1/0 #14 - 1/0

Terminal Amps


Catalog ACZ-4


39

Electrical Data, High Ambient Table 27, ACZ 030BH – 065BH, Electrical Data, Single Point (Above 105°F to 115°F) ACZ Unit Size

030B

035B

040B

045B

050B

055B

060B

065B

Volts


208 230 380 460 575 208 230 380 460 575 208 230 380 460 575 208 230 380 460 575 208 230 380 460 575 208 230 380 460 575 208 230 380 460 575 208 230 380 460 575

147 133 80 68 53 158 144 88 74 59 168 155 96 80 64 187 167 113 84 70 207 188 123 94 78 226 207 132 104 86 249 229 147 115 96 270 248 160 124 105

Power Supply Field Wire Wire Quantity Gauge 75C 3 1/0 3 1/0 3 #4 3 #4 3 #6 3 2/0 3 1/0 3 #3 3 #4 3 #6 3 2/0 3 2/0 3 #3 3 #4 3 #6 3 3/0 3 2/0 3 #2 3 #4 3 #4 3 4/0 3 3/0 3 #1 3 #3 3 #4 3 4/0 3 3/0 3 1/0 3 #2 3 #3 3 250 3 4/0 3 1/0 3 #2 3 #3 3 300 3 250 3 2/0 3 #1 3 #2

Max. Fuse Or HACR Breaker Size 175 150 90 80 60 175 175 100 90 70 200 175 110 90 70 200 200 125 90 80 225 225 125 110 90 225 225 150 125 100 250 250 175 125 110 300 250 175 150 125

NOTES: 1. See page 46 for all Electrical Data notes. 2. Conduit hubs are not provided.

40


Catalog ACZ-4

Table 28, ACZ 030BH – 065BH, Compressor & Fan Motor Amps, Single & Multi-Point ACZ Unit Size

Rated Load Amps Compressors Volts No. 1

No. 3

No. 2

No. 4

208 29.0 29.0 29.0 29.0 230 25.7 25.7 25.7 25.7 030B 380 14.9 14.9 14.9 14.9 460 13.4 13.4 13.4 13.4 575 9.5 9.5 9.5 9.5 208 29.0 29.0 34.0 34.0 230 25.7 25.7 30.9 30.9 035B 380 14.9 14.9 18.6 18.6 460 13.4 13.4 16.2 16.2 575 9.5 9.5 12.2 12.2 208 34.0 34.0 34.0 34.0 230 30.9 30.9 30.9 30.9 040B 380 18.6 18.6 18.6 18.6 460 16.2 16.2 16.2 16.2 575 12.2 12.2 12.2 12.2 208 38.5 38.5 38.5 38.5 230 33.8 33.8 33.8 33.8 045B 380 22.8 22.8 22.8 22.8 460 17.0 17.0 17.0 17.0 575 13.7 13.7 13.7 13.7 208 38.5 38.5 47.6 47.6 230 33.8 33.8 43.3 43.3 050B 380 22.8 22.8 27.2 27.2 460 17.0 17.0 21.8 21.8 575 13.7 13.7 17.3 17.3 208 47.6 47.6 47.6 47.6 230 43.3 43.3 43.3 43.3 055B 380 27.2 27.2 27.2 27.2 460 21.8 21.8 21.8 21.8 575 17.3 17.3 17.3 17.3 208 47.6 47.6 58.1 58.1 230 43.3 43.3 52.8 52.8 060B 380 27.2 27.2 33.8 33.8 460 21.8 21.8 26.5 26.5 575 17.3 17.3 21.8 21.8 208 58.1 58.1 58.1 58.1 230 52.8 52.8 52.8 52.8 065B 380 33.8 33.8 33.8 33.8 460 26.5 26.5 26.5 26.5 575 21.8 21.8 21.8 21.8 NOTE: See page 46 for all Electrical Data notes.

Catalog ACZ-4

Fan Motors (Each)

No. Of Fan Motors

5.8 5.8 4.1 2.8 3.0 5.8 5.8 4.1 2.8 3.0 5.8 5.8 4.1 2.8 3.0 5.8 5.8 4.1 2.8 3.0 5.8 5.8 4.1 2.8 3.0 5.8 5.8 4.1 2.8 3.0 5.8 5.8 4.1 2.8 3.0 5.8 5.8 4.1 2.8 3.0


4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4

Fan Motors (Each) 23.3 26.1 20.0 13.0 14.0 23.3 26.1 20.0 13.0 14.0 23.3 26.1 20.0 13.0 14.0 23.3 26.1 20.0 13.0 14.0 23.3 26.1 20.0 13.0 14.0 23.3 26.1 20.0 13.0 14.0 23.3 26.1 20.0 13.0 14.0 23.3 26.1 20.0 13.0 14.0

Locked Rotor Amps Compressors Across-The-Line No. 1

No. 3

No. 2

No. 4

189 189 112 99 74 189 189 112 99 74 232 232 144 125 100 278 278 151 127 100 278 278 151 127 100 350 350 195 158 125 350 350 195 158 125 425 425 239 187 148

189 189 112 99 74 189 189 112 99 74 232 232 144 125 100 278 278 151 127 100 278 278 151 127 100 350 350 195 158 125 350 350 195 158 125 425 425 239 187 148

189 189 112 99 74 232 232 144 125 100 232 232 144 125 100 278 278 151 127 100 350 350 195 158 125 350 350 195 158 125 425 425 239 187 148 425 425 239 187 148

189 189 112 99 74 232 232 144 125 100 232 232 144 125 100 278 278 151 127 100 350 350 195 158 125 350 350 195 158 125 425 425 239 187 148 425 425 239 187 148

41

Table 29, ACZ 070BH – 155BH, Compressor and Fan Motor Amps, Single and Multi-Point (Above 105°F to 125°F) ACZ Unit Size

070B

080B

090B

100B

110B

120B

130B

140B

155B

NOTE:

42

Rated Load Amps Compressors Volts No. 1

No. 3 No. 5 No. 2

208 58.1 58.1 230 52.8 52.8 380 32.7 32.7 460 25.5 25.5 575 21.8 21.8 208 58.1 78.0 230 52.8 74.1 380 32.7 39.8 460 25.5 37.5 575 21.8 29.9 208 78.0 78.0 230 74.1 74.1 380 39.8 39.8 460 38.8 38.8 575 29.9 29.9 208 78.0 78.0 230 74.1 74.1 380 39.8 39.8 460 38.8 38.8 575 29.9 29.9 208 86.9 86.9 230 83.3 83.3 380 57.6 57.6 460 44.5 44.5 575 32.5 32.5 208 58.1 58.1 58.1 230 52.8 52.8 52.8 380 32.7 32.7 32.7 460 25.5 25.5 25.5 575 21.8 21.8 21.8 208 87.9 87.9 87.9 230 74.2 74.2 74.2 380 43.8 43.8 43.8 460 37.5 37.5 37.5 575 29.9 29.9 29.9 208 87.9 87.9 87.9 230 74.2 74.2 74.2 380 43.8 43.8 43.8 460 37.5 37.5 37.5 575 29.9 29.9 29.9 208 88.0 88.0 88.0 230 88.0 88.0 88.0 380 57.6 57.6 57.6 460 44.5 44.5 44.5 575 32.5 32.5 32.5 See page 46 for all Electrical

No. 4

58.1 78.0 52.8 74.1 32.7 39.8 25.5 37.5 21.8 29.9 58.1 78.0 52.8 74.1 32.7 39.8 25.5 37.5 21.8 29.9 78.0 78.0 74.1 74.1 39.8 39.8 38.8 38.8 29.9 29.9 86.9 86.9 83.3 83.3 57.6 57.6 44.5 44.5 32.5 32.5 86.9 86.9 83.3 83.3 57.6 57.6 44.5 44.5 32.5 32.5 87.9 87.9 74.2 74.2 43.8 43.8 37.5 37.5 29.9 29.9 87.9 87.9 74.2 74.2 43.8 43.8 37.5 37.5 29.9 29.9 88.0 88.0 88.0 88.0 57.6 57.6 44.5 44.5 32.5 32.5 88.0 88.0 88.0 88.0 57.6 57.6 44.5 44.5 32.5 32.5 Data notes.

Locked Rotor Amps Compressors Across-The-Line

No. R.L.Amps F.L.Amps of Fan Fan Fan No. 6 Motors Motors Motors (Each) (Each)

No.1

87.9 74.2 43.8 37.5 29.9 87.9 74.2 43.8 37.5 29.9 88.0 88.0 57.6 44.5 32.5 88.0 88.0 57.6 44.5 32.5

425 425 239 187 148 425 425 239 187 148 505 505 280 225 180 505 505 280 225 180 500 500 305 250 198 425 425 239 187 148 505 505 280 225 180 505 505 280 225 180 500 500 305 250 198

7.8 7.8 4.1 3.6 3.0 7.8 7.8 4.1 3.6 3.0 7.8 7.8 4.1 3.6 3.0 7.8 7.8 4.1 3.6 3.0 7.8 7.8 4.1 3.6 3.0 7.8 7.8 4.1 3.6 3.0 7.8 7.8 4.1 3.6 3.0 7.8 7.8 4.1 3.6 3.0 7.8 7.8 4.1 3.6 3.0

4 4 4 4 4 4 4 4 4 4 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 8 8 8 8 8 8 8 8 8 8 8 8 8 8 8 8 8 8 8 8


31.7 35.6 20.0 17.8 14.0 31.7 35.6 20.0 17.8 14.0 31.7 35.6 20.0 17.8 14.0 31.7 35.6 20.0 17.8 14.0 31.7 35.6 20.0 17.8 14.0 31.7 35.6 20.0 17.8 14.0 31.7 35.6 20.0 17.8 14.0 31.7 35.6 20.0 17.8 14.0 31.7 35.6 20.0 17.8 14.0

No. 3 No. 5 425 425 239 187 148 505 505 280 225 180 505 505 280 225 180 505 505 280 225 180 500 500 305 250 198 425 425 239 187 148 505 505 280 225 180 505 505 280 225 180 500 500 305 250 198

425 425 239 187 148 505 505 280 225 180 505 505 280 225 180 500 500 305 250 198

No.2

No.4

No. 6

425 425 239 187 148 425 425 239 187 148 505 505 280 225 180 500 500 305 250 198 500 500 305 250 198 505 505 280 225 180 505 505 280 225 180 500 500 305 250 198 500 500 305 250 198

505 505 280 225 180 505 505 280 225 180 505 505 280 225 180 500 500 305 250 198 500 500 305 250 198 505 505 280 225 180 505 505 280 225 180 500 500 305 250 198 500 500 305 250 198

505 505 280 225 180 505 505 280 225 180 500 500 305 250 198 500 500 305 250 198

Catalog ACZ-4

Table 30, ACZ 030BH - 065BH, Electrical Data, Multi-Point (Above 105°F to 125°F) ACZ Unit Size

030B

035B

040B

045B

050B

055B

060B

065B

Volts

208 230 380 460 575 208 230 380 460 575 208 230 380 460 575 208 230 380 460 575 208 230 380 460 575 208 230 380 460 575 208 230 380 460 575 208 230 380 460 575

Electrical Circuit #1 Electrical Circuit #2 Power Supply Power Supply Max. Fuse Max. Fuse Minimum Minimum Field Wire Field Wire or HACR Circuit or HACR Circuit Wire Wire Breaker Breaker Ampacity Ampacity Qty Gauge Qty Gauge Size (MCA) Size (MCA) 75C 75C 77 3 #4 100 77 3 #4 100 70 3 #4 90 70 3 #4 90 42 3 #8 50 40 3 #8 50 36 3 #8 45 36 3 #8 45 27 3 #10 35 27 3 #10 35 77 3 #4 100 88 3 #3 110 70 3 #4 90 81 3 #4 110 42 3 #8 50 50 3 #8 60 36 3 #8 45 42 3 #8 50 27 3 #10 35 34 3 #10 45 88 3 #3 110 88 3 #3 110 81 3 #4 110 81 3 #4 110 50 3 #8 60 50 3 #8 60 42 3 #8 50 42 3 #8 50 34 3 #10 45 34 3 #10 45 98 3 #3 125 98 3 #3 125 88 3 #3 110 88 3 #3 110 60 3 #6 80 60 3 #6 80 44 3 #8 60 44 3 #8 60 37 3 #8 50 37 3 #8 50 98 3 #3 125 119 3 #1 150 88 3 #3 110 109 3 #2 150 60 3 #6 80 70 3 #4 90 44 3 #8 60 55 3 #6 70 37 3 #8 50 45 3 #8 60 119 3 #1 150 119 3 #1 150 109 3 #2 150 109 3 #2 150 70 3 #4 90 70 3 #4 90 55 3 #6 70 55 3 #6 70 45 3 #8 60 45 3 #8 60 119 3 #1 150 142 3 1/0 200 109 3 #2 150 130 3 #1 175 70 3 #4 90 84 3 #4 110 55 3 #6 70 65 3 #4 90 45 3 #8 60 55 3 #6 70 142 3 1/0 200 142 3 1/0 200 130 3 #1 175 130 3 #1 175 84 3 #4 110 84 3 #4 110 65 3 #4 90 65 3 #4 90 55 3 #6 70 55 3 #6 70

Notes: 1. See page 46 for all Electrical Data notes. 2. Conduit hubs are not supplied.

Catalog ACZ-4


43

Table 31, ACZ 070BH – 155BH, Electrical Data, Multi-Point (Above 105°F to 125°F) ACZ Unit Size

Volts

Electrical Circuit #1 Electrical Circuit #2 Power Power Supply Supply Max. Fuse Max. Fuse Minimum Minimum or HACR Circuit or HACR Circuit Field Wire Field Wire Breaker Breaker Ampacity Ampacity Wire Wire Size (MCA) Size (MCA) Qty Gauge Qty Gauge 75C 75C 146 3 1/0 200 171 3 2/0 225 134 3 1/0 175 161 3 2/0 225 82 3 #4 110 91 3 #3 125 67 3 #6 90 80 3 #4 110 55 3 #6 70 65 3 #6 90 171 3 2/0 225 171 3 2/0 225 161 3 2/0 225 161 3 2/0 225 91 3 #3 125 91 3 #3 125 80 3 #4 110 80 3 #4 110 65 3 #6 90 65 3 #6 90 199 3 3/0 250 199 3 3/0 250 190 3 3/0 250 190 3 3/0 250 102 3 #2 125 102 3 #2 125 99 3 #3 125 99 3 #3 125 76 3 #4 100 76 3 #4 100 199 3 3/0 250 219 3 4/0 300 190 3 3/0 250 211 3 4/0 250 102 3 #2 125 142 3 1/0 175 99 3 #3 125 111 3 #2 150 76 3 #4 100 83 3 #3 110 219 3 4/0 300 219 3 4/0 300 211 3 4/0 250 211 3 4/0 250 142 3 1/0 175 142 3 1/0 175 111 3 #2 150 111 3 #2 150 83 3 #3 110 83 3 #3 110 220 3 4/0 250 317 3 400 400 203 3 4/0 250 272 3 300 300 123 3 #1 150 159 3 2/0 200 101 3 #2 125 136 3 1/0 175 83 3 #4 100 109 3 #2 125 317 3 400 400 317 3 400 400 272 3 300 300 272 3 300 300 159 3 2/0 200 159 3 2/0 200 136 3 1/0 175 136 3 1/0 175 109 3 #2 125 109 3 #2 125 317 3 400 400 317 3 400 400 272 3 300 300 317 3 400 400 159 3 2/0 200 204 3 4/0 250 136 3 1/0 175 159 3 2/0 200 109 3 #2 125 118 3 #1 150 317 3 400 400 317 3 400 400 317 3 400 400 317 3 400 400 204 3 4/0 250 204 3 4/0 250 159 3 2/0 200 159 3 2/0 200 118 3 #1 150 118 3 #1 150

208 230 070B 380 460 575 208 230 080B 380 460 575 208 230 090B 380 460 575 208 230 100B 380 460 575 208 230 110B 380 460 575 208 230 120B 380 460 575 208 230 130B 380 460 575 208 230 140B 380 460 575 208 230 155B 380 460 575 NOTES: 1. See page 46 for all Electrical Data notes. 2. Conduit hubs are not supplied.

44


Catalog ACZ-4

Table 32, ACZ 070BH – 155BH, Electrical Data, Single Point (Above 105°F to 125°F) ACZ Unit Size

070B

080B

090B

100B

110B

120B

130B

140B

155B

Volts


208 230 380 460 575 208 230 380 460 575 208 230 380 460 575 208 230 380 460 575 208 230 380 460 575 208 230 380 460 575 208 230 380 460 575 208 230 380 460 575 208 230 380 460 575

303 282 164 138 115 323 304 172 150 123 378 362 194 187 145 398 382 234 200 151 416 401 270 211 157 522 462 273 230 187 612 526 307 263 211 612 571 352 286 219 613 613 393 307 228

Power Supply Field Wire Wire Quantity Gauge 75C 3 350 3 300 3 2/0 3 1/0 3 #2 3 400 3 350 3 2/0 3 1/0 3 #1 6 250 6 4/0 3 3/0 3 3/0 3 1/0 6 250 6 250 3 250 3 4/0 3 1/0 6 300 6 350 3 300 3 4/0 3 2/0 6 400 6 350 3 300 3 4/0 3 3/0 6 - (2) 350 6 - (2) 300 3 350 3 300 3 4/0 6 - (2) 350 6 - (2) 350 6 - (2) 4/0 3 350 3 4/0 6 - (2) 350 6 - (2) 350 6 250 3 350 3 250

Max. Fuse Or HACR Breaker Size 350 350 200 175 125 400 350 200 175 150 450 400 225 225 175 450 450 250 225 175 500 450 300 250 175 600 500 300 250 200 700 600 350 300 225 700 600 400 300 250 700 700 450 350 250

NOTES: 1. See page 46 for all Electrical Data notes. 2. (2) in column with wire qty. indicates that two conduits are required. 3. Conduit hubs are not supplied.

Catalog ACZ-4


45

Notes for “Electrical Data Single-and Multi-Point” Power: 1. Unit wire size ampacity (MCA) is equal to 125% of the largest compressor-motor RLA plus 100% of RLA of all other loads in the circuit including the control transformer. 2. The control transformer is furnished and no separate 115V power is required. On ACZ 030B through 155B, for both single- and multi-point power connections, the control transformer is in circuit #1 with control power wired from there to circuit #2. In multipoint power, disconnecting power to circuit #1 will disconnect all control power to the unit. 3. If a separate 115V power supply is used for the control circuit, then the wire sizing amps is 10 amps for all unit sizes. 4. Recommended power lead wire sizes for 3 conductors per conduit are based on 100% conductor ampacity in accordance with NEC. Voltage drop has not been included. Therefore, it is recommended that power leads be kept short. All terminal block connections must be made with copper (type THW) wire. 5. “Recommended Fuse Sizes” are selected at approximately 150% to 175% of the largest compressor RLA, plus 100% of all other loads in the circuit. 6. “Maximum Fuse or HACR breaker size” is selected at approximately 225% of the largest compressor RLA, plus 100% of all other loads in the circuit. 7. The recommended power lead wire sizes are based on an ambient temperature of 86°F (30°C). Ampacity correction factors must be applied for other ambient temperatures. Refer to the National Electrical Code Handbook. 8. Must be electrically grounded according to national and local electrical codes.

Voltage Limitations: Within ± 10 percent of nameplate rating Important: Voltage unbalance not to exceed 2% with a resultant current unbalance of 6 to 10 times the voltage unbalance per NEMA MG-1, 1998 Standard. This is an important restriction that must be adhered to.

Notes for “Compressor and Condenser Fan Amp Draw”: 1. Compressor RLA values are for wiring sizing purposes only but do not reflect normal operating current draw at rated capacity.

Notes for “Field Wiring Data” 1. Requires a single disconnect to supply electrical power to the unit. This power supply must either be fused or use an HACR type circuit breaker. 2. All field wiring to unit power block or optional non-fused disconnect switch must be copper. 3. All field wire size values given in table apply to 75°C rated wire per NEC.

Circuit Breakers (ACZ 030 to 155 only) Factory installed circuit breakers are standard on units with single point power supply only. This option provides unit installed compressor short circuit protection and makes servicing easier.

46

Connection Type

Power Block

Single Point (Standard) Multi-Point (Optional)

Std Std

Disconnect Swt. Opt. Opt.


Circuit Breakers Std Not Avail.

High Short Circuit Current Opt Opt.

Catalog ACZ-4

Figure 12, ACZ 010 – 039A, Typical Single-Point Field Wiring UNIT MAIN TERMINAL BLOCK

DISCONNECT (BY OTHERS)

GND LUG

3 PHASE TO COMPRESSOR(S) AND FAN MOTORS

POWER SUPPLY

NOTE: ALL FIELD WIRING TO BE INSTALLED AS NEC CLASS 1 WIRING SYSTEM WITH CONDUCTOR RATED 600 VOLTS

FUSED CONTROL CIRCUIT TRANSFORMER 120 VAC DISCONNECT (BY OTHERS)

TB1-20

N

TB1

10A FUSE

120VAC CONTROL POWER

CONTROL CIRCUIT FUSE

1

(BY OTHERS)

LIQUID LINE SOLENOID 120 VAC 1.0 AMP MAX

2

120 VAC

SV1 13 16

120 VAC

SV5 14 HOT GAS BY SOLENOID 120 VAC 1.0 AMP MAX

120 VAC

12

N 17 DX EVAP. FAN PUMP RELAY (BY OTHERS) 120 VAC 1.0 AMP MAX

ALARM BELL OPTION

FACTORY SUPPLIED ALARM FIELD WIRED

120 VAC

11 ALARM BELL RELAY 17

GND

TIME CLOCK

AUTO

OFF

TB2

ON

REMOTE STOP SWITCH (BY OTHERS)

25

EVAP. FLOW SWITCH ---MANDATORY–(BY OTHERS)

843

IF REMOTE STOP CONTROL IS USED, REMOVE LEAD 843 FROM TERM. 25 TO 35.

35

MANUAL

26

NOR. OPEN PUMP AUX. S (OPTIONAL)

ALARM BELL RELAY

36

22

COM

NO

BELL

31

1

2

ALARM BELL OPTION 23

STAGE 1 NOR. OPEN ORS

33

28

STAGE 2 NOR. OPEN ORS

34

Catalog ACZ-4

J5-ID7

J5-ID8


DWG. 330539401 REV.0B

47

Figure 13, ACZ 030 – 155B, Field Wiring Diagram UNIT MAIN TERMINAL BLOCK


GND LUG

3 PHASE TO COMPRESSOR(S)

POWER

AND FAN MOTORS

NOTE 1: ALL FIELD WIRING TO BE INSTALLED AS NEC CLASS 1 WIRING SYSTEM WITH CONDUCTOR RATED 600 VOLTS

FUSED CONTROL CIRCUIT TRANSFORMER

120 VAC

FIELD SUPPLIED OPTION


TB1-20

N

10A FUSE 120VAC CONTROL POWER

TB1 1

(BY OTHERS)

CONTROL CIRCUIT FUSE

2

120 VAC

35

N

33 DX EVAP FAN RELAY (BY OTHERS) 120 VAC 1.0 AMP MAX

FACTORY SUPPLIED ALARM FIELD WIRED

ALARM BELL OPTION

CONTROLLER

120 VAC

34 ALARM BELL RELAY 32

TIME CLOCK REMOTE STOP SWITCH (BY OTHERS)

GND AUTO OFF

TB2

ON 52

585

72

MANUAL EVAP FLOW SWITCH ---MANDATORY–(BY OTHERS)

IF REMOTE STOP CONTROL IS USED, REMOVE LEAD 585 FROM TERM. 52 TO 72.

ALARM BELL RELAY

43 COM 83

1

2

NO

ALARM BELL OPTION

44 NOR. OPEN PUMP AUX. S (OPTIONAL) 61 54

(SEE NOTE 2) 4-20MA FOR DEMAND LIMIT (BY OTHERS)

J20-ID18

+ -

70 71 GND

NOTE 2: EVAP. AIR FLOW SWITCH OR FAN AUX. FOR CIRCUIT #2 FAN WHEN UNIT IS SET FOR CIRCUIT SEQUENCING MODE.

LESS EVAPORATOR ONLY 24 VAC

91 93

N

LIQUID LINE #1 SOLENOID 24 VAC 1.5 AMP MAX.

24 VAC

92 93

N

LIQUID LINE #2 SOLENOID 24 VAC 1.5 AMP MAX.

24 VAC

95 97

N

HOT GAS BY #1 SOLENOID 24 VAC 1.0 AMP MAX.

24 VAC

96 97

N

HOT GAS BY #2 SOLENOID 24 VAC 1.0 AMP MAX.

STAGING OPERATION IN UNIT SEQUENCING SETTING STAGE 1 1ST COMPR. - EITHER CIRCUIT

NOTE 3: WHEN CONNECTED TO EVAPORATORS USING OPTIONAL CIRCUIT CONTROL, STAGES 1-3 ACTIVATE COMPRESSORS FOR CONDENSING UNIT CIRCUIT #1 AND STAGES 4-6 ACTIVATE COMPRESSORS FOR CONDENSING UNIT CIRCUIT #2.

STAGE 2

1

ST

TB3

101

102

STAGING OPERATION IN CIRCUIT SEQUENCING SETTING STAGE 1 1 ST COMPR. - CIRCUIT #1 STAGE 2

103

COMPR. - OPPOSITE CIRCUIT STAGE 3

2ND COMPR. - INITIAL CIRCUIT STAGE 4

2 ND COMPR. - OPPOSITE CIRCUIT STAGE 5

3RD COMPR. - INITIAL CIRCUIT STAGE 6

3 RD COMPR. - OPPOSITE CIRCUIT

2ND COMPR. - CIRCUIT #1 104

105 106

STAGE 3

3RD COMPR. - CIRCUIT #1 STAGE 4

107

1 ST COMPR. - CIRCUIT #2 108 109 110

111 112

STAGE 5

101 102 103

105 106 107 108 109

3RD COMPR. - CIRCUIT #3

UNIT CIRCUIT #1

104

2ND COMPR. - CIRCUIT #2 STAGE 6

(SEE NOTE 3)

TB3

UNIT CIRCUIT #2

110 111 112

LABEL DWG. 330423201 REV.0D

48


Catalog ACZ-4

Physical Data ACZ-A Table 33, Physical Data, ACZ 010A through 020A ACZ MODEL NUMBER

PHYSICAL DATA 010A

013A

016A

020A

1

1

BASIC DATA Number Of Refrigerant Circuits

1

1

Unit Operating Weight, Lbs. (kg)

22.0 (10.0) 73.6 x 46.3 x 50.8 (1869) x (1176) x (1289) 1000 (454)

22.0 (10.0) 73.6 x 46.3 x 50.8 (1869) x (1176) x (1289) 1000 (454)

Unit Shipping Weight, Lbs. (kg)

1080 (490)

1080 (490)

1300 (590)

1420 (645)

Add'l Weight If Copper Finned Coils, Lb. (kg)

220 (99.7)

220 (99.7)

220 (99.7)

220 (99.7)

Unit Operating Charge, R-22, Lb. (kg) Cabinet Dimensions, LxWxH, In. Cabinet Dimensions, LxWxH, (mm)

24.0 (10.9) 31.0 (14.1) 73.6 x 46.3 x 73.6 x 46.3 x 50.8 50.8 (1869) x (1176) (1869) x (1176) x x (1289) (1289) 1220 (554) 1340 (608)

COMPRESSORS Type Nominal Horsepower Oil Charge Per Compressor, Oz. (g)

Scroll

Scroll

Scroll

Scroll

4.0 / 4.0

6.0 / 6.0

7.5 / 7.5

9.0 / 9.0

57 (1616)

60 (1701)

140 (3969)

140 (3969)

0 – 50 – 100

0 – 50 – 100

0 – 50 – 100

CAPACITY REDUCTION STEPS - PERCENT OF COMPRESSOR DISPLACEMENT Standard Staging

0 – 50 – 100

CONDENSERS - HIGH EFFICIENCY FIN AND TUBE TYPE WITH INTEGRAL SUBCOOLING Coil Face Area, Sq. Ft. (M2) Finned Height x Finned Length, In. Finned Height x Finned Length, (mm)

30.3 (2.8)

30.3 (2.8)

30.3 (2.8)

84 x 52

84 x 52

84 x 52

30.3 (2.8) 84 x 52

(2134) x (1321)

(2134) x (1321)

(2134) x (1321)

(2134) x (1321)

Fins Per Inch x Rows Deep

16 x 2

16 x 2

16 x 3

16 x 3

Pumpdown Capacity lb. (kg)

35.3 (16.0)

35.3 (16.0)

50.3 (22.8)

50.3 (22.8)

CONDENSER FANS - DIRECT DRIVE PROPELLER TYPE Number Of Fans - Fan Diameter, In. (mm)

2 – 26 (660)

2 – 26 (660)

2 – 26 (660)

2 – 26 (660)

Number Of Motors - HP (kW)

2 – 1.0 (0.75)

2 – 1.0 (0.75)

2 – 1.0 (0.75)

2 – 1.0 (0.75)

Fan And Motor RPM, 60 Hz 60 Hz Total Unit Airflow, CFM (l/s)

Catalog ACZ-4

1140

1140

1140

1140

13950 (6584)

13950 (6584)

12000 (5664)

12000 (5664)


49

Table 34, Physical Data, ACZ 025A through 039A ACZ MODEL NUMBER

PHYSICAL DATA 025A

028A

1

1

033A

039A

BASIC DATA Number Of Refrigerant Circuits Unit Operating Charge, R-22, Lb. (kg) Cabinet Dimensions, LxWxH, In. Cabinet Dimensions, LxWxH, (mm) Unit Operating Weight, Lbs. (kg)

34.0 (15.4) 36.0 (16.3) 106.2x 46.3 x 106.2x 46.3 x 50.8 50.8 (2697) x (1176) (2697) x (1176) x (1289) x (1289) 1470 (667) 1490 (676)

1

1

47.0 (21.3) 106.2x 46.3 x 58.8 (2697) x (1176) x (1493) 1760 (799)

50.0 (22.7) 106.2x 46.3 x 58.8 (2697) x (1176) x (1493) 1960 (890)

Unit Shipping Weight, Lbs. (kg)

1580 (717)

1600 (726)

1890 (858)

2090 (949)

Add'l Weight If Copper Finned Coils, Lb. (kg)

350 (159)

350 (159)

435 (197)

435 (197)

COMPRESSORS Type

Scroll

Scroll

Scroll

Scroll

Nominal Horsepower

10.0 / 13.0

13.0 / 13.0

15.0 / 15.0

20.0 / 20.0

Oil Charge Per Compressor, Oz. (g)

140 (3969)

140 (3969)

140 (3969)

296 (8392)

0 – 50 – 100

0 – 50 – 100

CAPACITY REDUCTION STEPS - PERCENT OF COMPRESSOR DISPLACEMENT Standard Staging

0 – 45 - 100

0 – 50 – 100

CONDENSERS - HIGH EFFICIENCY FIN AND TUBE TYPE WITH INTEGRAL SUBCOOLING Coil Face Area, Sq. Ft. (M2) Finned Height x Finned Length, In. Finned Height x Finned Length, (mm)

49.0 (4.6)

49.0 (4.6)

58.3 (5.4)

84 x 84

84 x 84

100 x 84

100 x 84

(2545) x (2134)

(2545) x (2134)

(2134) x (2134) (2134) x (2134)

58.3 (5.4)


16 x 2

16 x 2

16 x 3

16 x 3

Pumpdown Capacity lb. (kg)

53.1 (24.0)

53.1 (24.0)

90.7 (41.1)

92.8 (42.0)

CONDENSER FANS - DIRECT DRIVE PROPELLER TYPE Number Of Fans - Fan Diameter, In. (mm)

3 – 26 (660)

3 – 26 (660)

3 – 26 (660)

3 – 26 (660)

Number Of Motors - HP (kW)

3 – 1.0 (0.75)

3 – 1.0 (0.75)

3 – 1.0 (0.75)

3 – 1.0 (0.75)

Fan And Motor RPM, 60 Hz 60 Hz Total Unit Airflow, CFM (l/s)

50

1140

1140

1140

1140

20925 (9877)

20925 (9877)

19800 (9346)

19800 (9346)


Catalog ACZ-4

Table 35, ACZ 030B through 040B ACZ MODEL NUMBER

PHYSICAL DATA

030B

BASIC DATA

Ckt.1

Number Of Refrigerant Circuits

035B Ckt.2

Ckt.1

2

040B Ckt.2

Ckt.1

2

Ckt.2 2

Unit Operating Charge, R-22, Lbs.

24

24

26

26

29

29

Unit Operating Charge, R-22, (kg)

10

10

11

11

13

13

Cabinet Dimensions, LxWxH, In.

94.4 x 88.0 x 100.4

94.4 x 88.0 x 100.4

94.4 x 88.0 x 100.4

Cabinet Dimensions, LxWxH, (mm)

2398 x 2235 x 2550 2398 x 2235 x 2550 2398 x 2235 x 2550

Unit Operating Weight, Lb (kg)

3600 (1634)

3600 (1634)

3600 (1634)

Unit Shipping Weight, Lb (kg)

3550 (1612)

3550 (1612)

3550 (1612)

284 (129)

284 (129)

284 (129)

Tandem Scrolls

Tandem Scrolls

Tandem Scrolls

Add'l Weight If Copper Finned Coils, Lb (kg) COMPRESSORS Type Nominal tonnage of each Compressor

7.5

7.5

7.5

9.0

9.0

2

2

2

2

2

2

Oil Charge Per Compressor, Oz.

140

140

140

140

140

140

Oil Charge Per Compressor, (g)

(496)

(496)

(496)

(496)

(496)

(496)

Number Of Compressors per Circuit

9.0

CAPACITY REDUCTION STEPS - PERCENT OF COMPRESSOR DISPLACEMENT Staging, 4 Stages, Circuit #1 in Lead

0-25-50-75-100

0-23-50-73-100

0-25-50-75-100

Staging, 4 Stages, Circuit #2 in Lead

0-25-50-75-100

0-27-50-77-100

0-25-50-75-100

CONDENSERS - HIGH EFFICIENCY FIN AND TUBE TYPE WITH INTEGRAL SUBCOOLING Coil Face Area, Sq. Ft.

26.3

26.3

26.3

26.3

26.3

Coil Face Area, (M2)

2.4

2.4

2.4

2.4

2.4


50x75.6 1270 x 1920 16 x 3

50x75.6 1270 x 1920 16 x 3

50x75.6 1270 x 1920 16 x 3

50x75.6 50x75.6 1270 x 1270 x 1920 1920 16 x 3 16 x 3

50x75.6 1270 x 1920 16 x 3

Pumpdown Capacity, 90% Full Lbs. (kg) Maximum Relief Valve Pressure Setting, psig (kPa)

49 (22) 450 (3103)

49 (22) 450 (3103)

49 (22) 450 (3103)

49 (22) 450 (3103)

49 (22) 450 (3103)

Finned Height x Finned Length, In. Finned Height x Finned Length, (mm)

26.3 2.4

49 (22) 450 (3103)

CONDENSER FANS - DIRECT DRIVE PROPELLER TYPE Number Of Fans - Fan Diameter, In. (mm) Number Of Motors - HP (kW) (Note 1) Fan And Motor RPM, 60Hz 60 Hz Fan Tip Speed, FPM (M/Sec) 60 Hz Total Unit Airflow, CFM (M3/sec)

4 – 30 (762)

4 – 30 (762)

4 – 30 (762)

4 – 1.0

4 – 1.0

4 – 1.0

1140

1140

1140

8950 (4224)

8950 (4224)

8950 (4224)

24,316 (11,478)

24,316 (11,478)

24,316 (11,478)

NOTE: Except for 380V/60 & 575V/60, HP = 2.0

Catalog ACZ-4


51


PHYSICAL DATA BASIC DATA

045B Ckt.1


050B Ckt.2

Ckt.1

2

055B Ckt.2

Ckt.1

2

060B

Ckt.2

Ckt.1

2

Ckt.2 2

Unit Operating Charge, R-22, lbs.

33

33

34

34

36

36

45

45


15

15

15

15

16

16

20

20

Cabinet Dimensions, LxWxH, in. Cabinet Dimensions, LxWxH, (mm) Unit Operating Weight, Lbs. (kg) Unit Shipping Weight, Lbs. (kg)

94.4 x 88.0 x 100.4 94.4 x 88.0 x 100.4 94.4 x 88.0 x 100.4 94.4 x 88.0 x 100.4 2398 x 2235 x 2398 x 2235 x 2398 x 2235 x 2398 x 2235 x 2250 2250 2250 2250 3610 (1639) 3650 (1657) 3800 (1725) 3850 (1748) 3550 (1612)

3590 (1630)

3730 (1693)

3780 (1716)

288 (130)

288 (130)

476 (130)

476 (130)

Type

Tandem Scrolls

Tandem Scrolls

Tandem Scrolls

Tandem Scrolls

Nominal tonnage of each Compressor

10.0

10.0

13.0

Add'l Weight If Copper Finned Coils, lbs. (kg) COMPRESSORS


10.0

13.0

13.0

130

15.0

2

2

2

2

2

2

2

2

Oil Charge Per Compressor, oz.

140

140

140

140

140

140

140

140


(496)

(496)

(496)

(496)

(496)

(496)

(496)

(496)

CAPACITY REDUCTION STEPS - PERCENT OF COMPRESSOR DISPLACEMENT Staging, 4 Stages, Circuit #1 in Lead Staging, 4 Stages, Circuit #2 in Lead

0-25-50-75-100 0-25-50-75-100

0-22-50-72-100 0-28-50-78-100

0-25-50-75-100 0-25-50-75-100

0-23-50-73-100 0-27-50-77-100

CONDENSERS - HIGH EFFICIENCY FIN AND TUBE TYPE WITH INTEGRAL SUBCOOLING Coil Face Area, sq. ft.

26.3

26.3

44.1

44.1

44.1

44.1

44.1

44.1

Coil Face Area (sq. M)

2.4

2.4

4.1

4.1

4.1

4.1

4.1

4.1

Finned Height x Finned Length, in.


50x75.6 1270 x 1920 16 x 3

50x75.6 42x75.6 42x75.6 42x75.6 1270 x 1067 x 1067 x 1067 x 1920 1920 1920 1920 16 x 3 16 x 2 16 x 2 16 x 2

Pumpdown Capacity, 90% Full Lbs. (kg) Maximum Relief Valve Pressure Setting, psig (kPa)

49 (22) 450 (3103)

49 (22) 450 (3103)

Finned Height x Finned Length, (mm)

60(27) 450 (3103)

60(27) 450 (3103)

60(27) 450 (3103)

42x75.6 1067 x 1920 16 x 2 60(27) 450 (3103)

42x75.6 42x75.6 1067 x 1067 x 1920 1920 16 x 3 16 x 3 82 (37) 450 (3103)

82 (37) 450 (3103)

CONDENSER FANS - DIRECT DRIVE PROPELLER TYPE Number Of Fans - Fan Diameter, in. (mm) Number Of Motors - HP (kW) (Note 1) Fan And Motor RPM, 60Hz 60 Hz Fan Tip Speed, FPM (m/sec) 60 Hz Total Unit Airflow, CFM (m3/sec)

4 – 30 (762)

4 – 30 (762)

4 – 30 (762)

4 – 30 (762)

4 – 1.5

4 – 1.5

4 – 1.5

4 – 1.5

1140

1140

1140

1140

8950 (4224)

8950 (4224)

8950 (4224)

8950 (4224)

39,600 (18,692)

39,600 (18,692)

37,228 (17,572)

37,228 (17,572)


52


Catalog ACZ-4


PHYSICAL DATA

065B

BASIC DATA

Ckt.1


070B Ckt.2

Ckt.1

2

080B Ckt.2

Ckt.1

2

Ckt.2 2

Unit Operating Charge, R-22, lbs.

46

46

52

52

59

59


(21)

(21)

(24)

(24)

(27)

(27)

Cabinet Dimensions, LxWxH, in.

94.4 x 88.0 x 100.4 94.4 x 88.0 x 100.4 94.4 x 88.0 x 100.4 2398 x 2235 x 2398 x 2235 x 2398 x 2235 x 2550 2550 2550 4040 (1834) 4070 (1848) 4180 (1898)

Cabinet Dimensions, LxWxH, (mm) Unit Operating Weight, Lbs. (kg) Unit Shipping Weight, Lbs. (kg)

3820 (1734)

3970 (1802)

4080 (1852)

476 (216)

568 (258)

568 (258)

Type

Tandem Scrolls

Tandem Scrolls

Tandem Scrolls

Nominal tonnage of each Compressor

15.0

15.0

15 / 20

15 / 20

15 / 20

2

2

2

Add'l Weight If Copper Finned Coils, lbs. (kg) COMPRESSORS


15.0

2

2

2

Oil Charge Per Compressor, oz.

140

140

140

140 /148 140 /148 140 /148


(496)

(496)

(496)

496/ 525 496/ 525 496/ 525

CAPACITY REDUCTION STEPS - PERCENT OF COMPRESSOR DISPLACEMENT Staging, 4 Stages, Circuit #1 in Lead Staging, 4 Stages, Circuit #2 in Lead

0-25-50-75-100 0-25-50-75-100

0-23-46-77-100 0-31-46-69-100

0-25-50-75-100 0-25-50-75-100

CONDENSERS - HIGH EFFICIENCY FIN AND TUBE TYPE WITH INTEGRAL SUBCOOLING Coil Face Area, sq. ft.

44.1

44.1

52.6

52.6

52.6

52.6

Coil Face Area, (m2)

4.1

4.1

4.9

4.9

4.9

4.9

Finned Height x Finned Length, in.

42x75.6 1067 x 1920 16 x 3

Finned Height x Finned Length, (mm) Fins Per Inch x Rows Deep Pumpdown Capacity, 90% Full Lbs. (kg) Maximum Relief Valve Pressure Setting, psig (kPa)

82 (37 450 (3103)

42x75.6 100x75.6 100x75.6 100x75.6 100x75.6 1067 x 2540 x 2540 x 2540 x 2540 x 1920 1920 1920 1920 1920 16 x 3 16 x 3 16 x 3 16 x 3 16 x 3 82 (37 450 (3103)

98 (44 450 (3103)

98 (44 450 (3103)

98 (44 450 (3103)

98 (44 450 (3103)

CONDENSER FANS - DIRECT DRIVE PROPELLER TYPE Number Of Fans - Fan Diameter, in. (mm) Number Of Motors - HP (kW) (Note 1) Fan And Motor RPM, 60Hz 60 Hz Fan Tip Speed, FPM (m/sec) 60 Hz Total Unit Airflow, CFM (m3/sec)

4 – 30 (762)

4 – 30 (762)

4 – 30 (762)

4 – 1.5

4 – 2.0

4 – 2.0

1140

1140

1140

8950 (4224)

8950 (4224)

8950 (4224)

37,228 (17,572

43,452 (20,510)

43,452 (20,510)


Catalog ACZ-4


53

Table 38, ACZ 090B through 110B PHYSICAL DATA

ACZ MODEL NUMBER 100B 110B Ckt.1 Ckt.2 Ckt.1 Ckt.2 Ckt.1 Ckt.2 2 2 2 59 59 59 69 69 69 (27) (27 (27 (31) (31 (31 134.9 x 88.0 x 100.4 134.9 x 88.0 x 100.4 134.9 x 88.0 x 100.4 3426 x 2235 x 2550 3426 x 2235 x 2550 3426 x 2235 x 2550 5630 (2556) 5790 (2629) 5950 (2701) 5510 (2502) 5670 (2574) 5830 (2647) 870 (395) 870 (395) 870 (395) 090B

BASIC DATA Number Of Refrigerant Circuits Unit Operating Charge, R-22, lbs. Unit Operating Charge, R-22, (kg) Cabinet Dimensions, LxWxH, in. Cabinet Dimensions, LxWxH, (mm) Unit Operating Weight, Lbs. (kg) Unit Shipping Weight, Lbs. (kg) Add'l Weight If Copper Finned Coils, lbs. (kg) COMPRESSORS Type Tandem Scrolls Tandem Scrolls Tandem Scrolls Nominal tonnage of each Compressor 20.0 20.0 20.0 25.0 25.0 25.0 Number Of Compressors per Circuit 2 2 2 2 2 2 Oil Charge Per Compressor, oz. 148 148 148 200 200 200 Oil Charge Per Compressor, (g) (525) (525) (525) (709) (709) (709) CAPACITY REDUCTION STEPS - PERCENT OF COMPRESSOR DISPLACEMENT Staging, 4 Stages, Circuit #1 in Lead 0-25-50-75-100 0-22-50-72-100 0-25-50-75-100 Staging, 4 Stages, Circuit #2 in Lead 0-25-50-75-100 0-28-50-78-100 0-25-50-75-100 CONDENSERS - HIGH EFFICIENCY FIN AND TUBE TYPE WITH INTEGRAL SUBCOOLING Coil Face Area, sq. ft. 78.8 78.8 78.8 78.8 78.8 78.8 Coil Face Area, (m2) 7.3 7.3 7.3 7.3 7.3 7.3 Finned Height x Finned Length, in. 50 x113.4 50 x113.4 50 x113.4 50 x113.4 50 x113.4 50 x113.4 1270 x 1270 x 1270 x 1270 x 1270 x 1270 x Finned Height x Finned Length, (mm) 2880 2880 2880 2880 2880 2880 Fins Per Inch x Rows Deep 16 x 3 16 x 3 16 x 3 16 x 3 16 x 3 16 x 3 Pumpdown Capacity, 90% Full Lbs. (kg) 147 (67) 147 (67) 147 (67) 147 (67) 147 (67) 147 (67) 450 450 450 450 450 450 Maximum Relief Valve Pressure Setting, psig (kPa) (3103) (3103) (3103) (3103) (3103) (3103) CONDENSER FANS - DIRECT DRIVE PROPELLER TYPE Number Of Fans - Fan Diameter, in. (mm) 6 – 30 (762) 6 – 30 (762) 6 – 30 (762) Number Of Motors - HP (kW) (Note 1) 6 – 2.0 6 – 2.0 6 – 2.0 Fan And Motor RPM, 60Hz 1140 1140 1140 60 Hz Fan Tip Speed, FPM (m/sec) 8950 (4224) 8950 (4224) 8950 (4224) 60 Hz Total Unit Airflow, CFM (m3/sec) 65,178 (30,765) 65,178 (30,765) 65,178 (30,765) NOTE: Except for 380V/60 & 575V/60, HP = 2.0

54


Catalog ACZ-4

Table 39, ACZ 120B through 155B PHYSICAL DATA

120B

ACZ MODEL NUMBER 130B 140B Ckt.1 Ckt.2 Ckt.1 Ckt.2 2 2 86 86 86 104 (39) (39) (39) (47) 173.1 x 88.0 x 100.4 173.1 x 88.0 x 100.4 4397 x 2235 x 2550 4397 x 2235 x 2550 7230 (3282) 7480 (3396) 7080 (3214) 7360 (3341) 1155 (524) 1155 (524)

BASIC DATA Ckt.1 Ckt.2 Number Of Refrigerant Circuits 2 Unit Operating Charge, R-22, lbs. 76 86 Unit Operating Charge, R-22, (kg) (35) (39) Cabinet Dimensions, LxWxH, in. 173.1 x 88.0 x 100.4 Cabinet Dimensions, LxWxH, (mm) 4397 x 2235 x 2550 Unit Operating Weight, Lbs. (kg) 6970 (3164 Unit Shipping Weight, Lbs. (kg) 6820 (3096) Add'l Weight If Copper Finned Coils, lbs. (kg) 1155 (524) COMPRESSORS Type Trio Scrolls Trio Scrolls Trio Scrolls Nominal tonnage of each Compressor 15.0 20.0 20.0 20.0 20.0 25.0 Number Of Compressors per Circuit 3 3 3 3 3 3 Oil Charge Per Compressor, oz. 140 148 148 148 148 200 Oil Charge Per Compressor, (g) (496) (525) (525) (525) (525) (709) CAPACITY REDUCTION STEPS - PERCENT OF COMPRESSOR DISPLACEMENT Staging, 6 Stages, Circuit #1 in Lead 0-14-33-48-67-81-100 0-17-33-50-67-83-100 0-15-33-48-67-81-100 Staging, 6 Stages, Circuit #2 in Lead 0-19-33-52-67-86-100 0-17-33-50-67-83-100 0-19-33-52-67-86-100 CONDENSERS - HIGH EFFICIENCY FIN AND TUBE TYPE WITH INTEGRAL SUBCOOLING Coil Face Area, sq. ft. 105.3 105.3 105.3 105.3 105.3 105.3 Coil Face Area, (m2) 9.8 9.8 9.8 9.8 9.8 9.8 Finned Height x Finned Length, in. 50 x151.6 50 x151.6 50 x151.6 50 x151.6 50 x151.6 50 x151.6 1270 x 1270 x 1270 x 1270 x 1270 x 1270 x Finned Height x Finned Length, (mm) 3851 3851 3851 3851 3851 3851 Fins Per Inch x Rows Deep 16 x 3 16 x 3 16 x 3 16 x 3 16 x 3 16 x 3 Pumpdown Capacity, 90% Full Lbs. (kg) 196 (89) 196 (89) 196 (89) 196 (89) 196 (89) 196 (89) Maximum Relief Valve Pressure Setting, psig 450 450 450 450 450 450 (kPa) (3103) (3103) (3103) (3103) (3103) (3103) CONDENSER FANS - DIRECT DRIVE PROPELLER TYPE Number Of Fans - Fan Diameter, in. (mm) 8 – 30 (762) 8 – 30 (762) 8 – 30 (762) Number Of Motors - HP (kW) 8 – 2.0 8 – 2.0 8 – 2.0 Fan And Motor RPM, 60Hz (Note 1) 1140 1140 1140 60 Hz Fan Tip Speed, FPM (m/sec) 8950 (4224) 8950 (4224) 8950 (4224) 60 Hz Total Unit Airflow, CFM (m3/sec) 86,904 (41,020) 86,904 (41,020) 86,904 (41,020)

155B Ckt.1

Ckt.2 2

104 104 (47) (47) 173.1 x 88.0 x 100.4 4397 x 2235 x 2550 7760 (3523) 7640 (3469) 1155 (524) Trio Scrolls 25.0 25.0 3 3 200 200 (709) (709) 0-17-33-50-67-83-100 0-17-33-50-67-83-100 105.3 105.3 9.8 9.8 50 x151.6 50 x151.6 1270 x 1270 x 3851 3851 16 x 3 16 x 3 196 (89) 196 (89) 450 450 (3103) (3103) 8 – 30 (762) 8 – 2.0 1140 8950 (4224) 86,904 (41,020)


Catalog ACZ-4


55

Dimensional Data Figure 14, ACZ 010A through 020A 46.27 (1175.26) POWER ENTRY KNOCKOUT (OTHER SIDE)

POWER ENTRY

CONTROL ACCESS DOORS

CONTROL ELECTRICAL KNOCKOUT

51.0 (1295.40)

SUCTION INLET

ACCESS DOOR

HOT GAS BY

Z

LIQUID OUTLET

6.0 (152.4)

6.0 (152.4)

X

21.32 (541.53) 46.23 (1174.24)

6.0 (152.4)

6.0 (152.4)

Y

LIFTING SLOTS

31.11 (790.19) MOUNTING HOLES

3.94 (100.08) M0UNTING HOLES QTY. 4 01.00 (25.4)

49.06 (1246.12) 73.55 (1868.17)

ACZ Unit Size

Liquid Conn. inches (mm)

Suction Conn inches (mm)

Optional Hot Gas By

010A, 013A

7/8 (22.2)

1 1/8 (28.6)

016A, 020A

7/8 (22.2)

1 5/8 (41.3)

7.55 (191.77)

Center of Gravity inches (mm) X

Y

Z

5/8 (15.8)

28 (711.2)

22 (558.8)

23 (584.2)

5/8 (15.8)

25 (635.0)

21 (553.4)

23 (584.2)

Figure 15, ACZ 025A - 039A 46.26 (1175.26)

POWER ENTRY KNOCKOUT (OTHER SIDE)

POWER ENTRY

CONTROL ACCESS DOORS

CONTROL ELECTRICAL KNOCKOUT

A

SUCTION INLET ACCESS DOOR

HOT GAS BY

Z

LIQUID OUTLET

X 21.32 (541.53) 49.06 (1246.12)

46.19 (1173.23) 49.06 (1246.12)

105.97 (2691.64)

56

ACZ Unit Size

A inches (mm)

Liquid Conn. inches (mm)

Suction Conn inches (mm)

025A, 028A

51 (1295)

7/8 (22.2)

1 5/8 (41.3)

033A, 039A

59 (1499)

7/8 (22.2)

2 1/8 (53.9)

6.0 (152.4) 6.0 (152.4)

6.0 (152.4) LIFTING SLOTS 3.94 (100.08) MOUNTING HOLES QTY. 6 0 1.00 (25.4)


Optional Hot Gas By

6.0 (152.4)

Y 31.11 (790.19) 7.55 MOUNTING (191.77) HOLES

Center of Gravity inches (mm) X

Y

Z

5/8 (15.8)

35 (889.0)

21 (553.4)

23 (584.2)

7/8 (22.28)

35 (889.0)

25 (635.0)

24 (609.6)

Catalog ACZ-4

Figure 16, Dimensions ACZ 030B through 080B

ISOLATOR LOCATIONS ON BOTTOM OF RAIL 67.8 (1721) COMPRESSOR COMPRESSOR CIRCUIT #1 CIRCUIT #2

13.3 (338)

13.3 (338)

REFRIGERANT CONNECTIONS SUCTION LINE #2

SUCTION LINE #1

HOT GAS BY #1

HOT GAS BY #2

LIQUID LINE #1

25.0 (636)

LIQUID LINE #2

2.0 (51) 8.9 (226)

51.2 (1301)

CONTROL

CONTROL

POWER ENTRY POINT 0.875 KNOCK OUT

FIELD CONTROL CONNECTION

100.4 (2550)

SUCTION CONN. Y 43.8 (1111)

25.8 (656) 16.7 424) 19.9 (506)

HOT GAS CONN.

LIQUID CONN.

19.9 (507)

25.1 (637)

9.1 (231)

Z

14.3 (364)

6.4 (162) X

DWG. #3305196

88.0 (2335)

94.4 (2397)

NOTE: Hail and wind guards add 20 inches to the width of each side. Suction Conn. inches

Liquid Conn. inches

Circuit 1

Circuit 2

Optional HGBP inches

030

(2) 7/8

1 5/8

1 5/8

035

(2) 7/8

1 5/8

1 5/8

040

(2) 7/8

1 5/8

045

(2) 7/8

050 055

ACZ-B Unit Size

Center of Gravity in. (mm)

Weights lbs. (kg)

X

Y

Z

Shipping

Operating

(2) 7/8

36 (914)

42 (1067)

42 (1067)

3550 (1610)

3600 (1633)

(2) 7/8

36 (914)

42 (1067)

42 (1067)

3550 (1610)

3600 (1633)

1 5/8

(2) 7/8

36 (914)

42 (1067)

42 (1067)

3550 (1610)

3600 (1633)

1 5/8

1 5/8

(2) 7/8

36 (914)

41 (1041)

41 (1041)

3550 (1610)

3610 (1637)

(2) 7/8

1 5/8

1 5/8

(2) 7/8

36 (914)

41 (1041)

41 (1041)

3590 (1628)

3650 (1656)

(2) 7/8

1 5/8

1 5/8

(2) 7/8

36 (914)

42 (1067)

42 (1067)

3730 (1692)

3800 (1724)

060

(2) 7/8

1 5/8

2 1/8

(2) 7/8

35 (889)

42 (1067)

43 (1092)

3780 (1715)

3850 (1746)

065

(2) 7/8

2 1/8

2 1/8

(2) 7/8

35 (889)

42 (1067)

43 (1092)

3820 (1733)

4040 (1833)

070

(2) 7/8

2 1/8

2 5/8

(2) 7/8

35 (889)

43 (1092)

45 (1143)

3970 (1801)

4070 (1846)

080

(2) 7/8

2 5/8

2 5/8

(2) 7/8

36 (914)

44 (1118)

46 (1168)

4080 (1851)

4180 (1896)

Catalog ACZ-4


57

Figure 17, Dimensions, ACZ 090B through 110B ISOLATOR LOCATIONS ON BOTTOM OF RAIL 110.1 (2797)

12.4 (315)

COMPRESSORS CIRC #2

12.4 (315)

REFRIGERANT CONNECTIONS 2.0 (51) SUCTION LINE #2

53.7 (1365)

SUCTION LINE #1

HOT GAS BY #2

47.9 (1218) 40.0 (1017) 34.3 (870)

2.0 (51)

51.3 (1304)

HOT GAS BY #1

LIQUID LINE #2

LIQUID LINE #1

COMPRESSORS CIRC #1

CONTROL POWER ENTRY POINT 0.875 KNOCK OUTS

CONTROL


100.4 (2550) Y

28.5 (724)

6.4 (162)

28.5 (724)

Z

14.4 (364) X Dwg. #3305025-R3

88.0 (2235)

134.7 (3421)

NOTE: Hail and wind guards add 20 inches to the width of each side.

58

Circuit 1

Circuit 2

Optional Hot Gas By inches

(2) 1 1/8

2 5/8

2 5/8

1 1/8

100B

(2) 1 1/8

2 5/8

3 1/8

1 1/8

110B

(2) 1 1/8

3 1/8

3 1/8

1 1/8

ACZ Unit Size

Liquid Conn. inches

090B

Suction Conn. inches

Center of Gravity Inches (mm)

Weights Lbs. (kg)

X

Y

Z

Shipping Weight

Operating Weight

44 (1118) 43 (1092) 44 (1118)

46 (1168) 44 (1118) 41 (1041)

58 (1473) 58 (1473) 57 (1448)

5510 (2499) 5670 (2572) 5830 (5830)

5630 (2554) 5790 (2626) 5950 (2699)


Catalog ACZ-4

Figure 18, ACZ120B through 155B

25.2 (640)

ISOLATOR LOCATIONS ON BOTTOM OF RAIL 67.8 (1721) 67.8 (1721)

12.4 COMPRESSORS CIRC #2 (315)

REFRIGERANT CONNECTIONS 2.0 (51)

53.73 (1364.7) 48.00 (1319.2) 39.95 (1014.7) 34.22 (869.2)

SUCTION LINE #2

SUCTION LINE #1

HOT GAS BY #2

HOT GAS BY #1

2.0 (51) LIQUID LINE #2

COMPRESSORS CIRC #1

82.4 (2093)

LIQUID LINE #1

CONTROL CONTROL


17.6 (447)

100.4 (2550)

Y

9.0 (229)

23.9 (114)

POWER ENTRY POINT 0.875 KNOCK OUTS

Z

43.8 (1111)

6.4(1624)

23.9 (114)

X

88.0 (2235)

14.4 (365) DWG. #3305026

173.1 (4396)

NOTE: Hail and wind guards add 20 inches to the width of each side.

Suction Conn. inches

ACZ Unit Size

Liquid Conn. inches

Circuit 1

Circuit 2

Optional Hot Gas By

120B

(2) 1 1/8

2 5/8

3 1/8

130B

(2) 1 1/8

3 1/8

3 1/8

140B

(2) 1 1/8

3 1/8

155B

(2) 1 1/8

3 1/8

Catalog ACZ-4

Center of Gravity Inches (mm)

Weights Lbs. (kg)

X

Y

Z

Shipping Weight

1 1/8

43 (1092)

46 (1168)

75 (1905)

6820 (3094)

6970 (3162)

1 1/8

44 (1118)

46 (1168)

73 (1854)

7080 (3211)

7230 (3280)

3 1/8

1 1/8

43 (1092)

63 (1600)

73 (1854)

7360 (3338)

7480 (3393)

3 1/8

1 1/8

44 (1118)

40 (1016)

71 (1803)

7640 (3466)

7760 (3520)


Operating Weight

59

Application Data Unit Placement ACZ units are for outdoor applications and can be mounted either on a roof or at ground level. For roof mounted applications, install the unit on a steel channel or I-beam frame to the unit above the roof. For ground level applications, install the unit on a substantial base that will not settle. Use a one-piece concrete slab with footings extended below the frost line. Be sure the foundation is level within 1/2" (13mm) over its length and width. The foundation must be strong enough to the weights listed in the Physical Data Tables beginning on page 49.

Figure 19, Clearances SEE TABLE 32 DIMENSION “A”

4 FT. (1220mm) CLEARANCE FOR SERVICE ACCESS

4 FT. (1220) CLEARANCE FOR SERVICE ACCESS

SEE TABLE 32 DIMENSION “A”

Table 40, Recommended Minimum Clearances Model Size

Coil Side “A”

“B”

End Opposite Controls

“C”

Control End

010A - 039A

4 (1.2)

8

6

4 (1.2)

4 (1.2)

030B – 080B

4 (1.2)

8

6

4 (1.2)

4 (1.2)

090B – 155B

6 (1.8)

12

8

4 (1.2)

4 (1.2)

NOTE: Dimensions in ft (m).

Clearances Do not block the flow of air to and from the condenser coil. Restricting airflow or allowing air recirculation will result in a decrease in unit performance and efficiency because the unit discharge pressure is increased. There must be no obstruction above the unit that would deflect discharge air downward where it could be recirculated back to the inlet of the condenser coil. The condenser fans are propeller type and will not operate with ductwork. Install the unit with enough side clearance for air entrance to the coil and for servicing. Provide sufficient service access to the compressors, electrical control and piping components.

60

AIR DISCHARGE

AIR DISCHARGE

AIR FLOW AIR FLOW

AIR FLOW

“B”

The recommended minimum side clearance between two units is dimension “B’ in Table 32.

AIR DISCHARGE AIR FLOW

AIR FLOW

“C”

“C”

The unit must not be installed in a pit or enclosure that is deeper or taller than the height of the unit unless extra space is provided. The minimum clearance on each side of the unit is dimension “C” in Table 32.


Catalog ACZ-4

Do not allow debris to accumulate near the unit where it could be drawn into the condenser coil. Keep condenser coils and fan discharge free of snow and other obstructions to permit adequate airflow for proper operation.

Restricted Air Flow Hail and Wind Guards

If hail and wind guards are used, care must be taken when considering air flow clearances. The guards add 20 inches to the width of each side of the unit and essentially increase the total unit width by that amount. Wall spacing in the following discussions must be taken from the outside of the guards, i.e. 20 inches from the side of the unit. General

The clearances required for design-life operation of ACZ air-cooled condensers are described in the previous section. Occasionally, these clearances cannot be maintained due to site restrictions such as units being too close together or a fence or wall restricting airflow, or both. Fortunately, the McQuay ACZ condensing units have several features that can mitigate the penalties attributable to restricted airflow. •

The condenser section is “W” shaped, as shown below. This allows inlet air for these coils to come in from either side. A vertical coil and its adjacent angled coil are manifolded together to serve one circuit. Every compressor set has its own independent refrigerant circuit.

•

The MicroTech II™ control is proactive in response to “off-design conditions”. In the case of single or compounded influences restricting airflow to the unit, the microprocessor will act to keep the unit running (possibly at reduced capacity) rather than allowing a complete shut-off on high discharge pressure.

•

The MicroTech II™ control can be programmed to sequence the compressors in the most advantageous way. For example, in the diagram shown below, it might be desirable to program circuit #1 to be the lag circuit (last circuit to reach full load) during periods of high ambient temperatures.

Building

Figure 20, Coil and Fan Arrangement

Circuit #1

Circuit #2

The following sections discuss the most common situations of condenser air restriction and give capacity and power adjustment factors for each. Note that in unusually severe conditions, the MicroTech II™ controller would adjust the unit operation to remain online until a less severe condition is reached.

Catalog ACZ-4


61

Case 1, Building or Wall on One Side of One Unit The existence of a screening wall or the wall of a building in close proximity to an aircooled unit is common in both rooftop and ground level applications. Hot air recirculation on the coils ading the wall will increase compressor discharge pressure, decreasing capacity and increasing power consumption. Only the compressor(s) connected to these coils will be affected. Circuits opposite the wall are unaffected. When close to a wall, it is desirable to place the units on the North or East side of them. It is also desirable to have prevailing winds blowing parallel to the unit’s long axis. The worst case is to have wind blowing hot discharge air into the wall. Figure 21, Unit Adjacent to Wall

H D

Figure 22, Adjustment Factors ACZ ACZ 090-155 010-080 3.0

4.5 ft. (1.4m)

3.0 ft. (0.9m)

2.0

62

4.0

4.5 ft. (1.4m)

3.0 ft. (0.9m)

5 ft. (1.5m)

3.5 ft. (1.0m)

6 ft. (1.8m)

4 ft. (1.2m)

3.0

1.0

5 ft. (1.5m)

3.5 ft. (1.0m)

.5

6 ft. (1.8m)

4 ft. (1.2m)

0

ACZ ACZ 090-155 010-080

2.0

0


Catalog ACZ-4

Case 2, Two Units Side By Side Two or more units sited side by side are common. If spaced closer than 12 feet (3.7 meters) or 8 feet (2.5meters) depending on size, it is necessary to adjust the performance of each unit; circuits ading each other are affected. NOTE: This case applies only to two units side by side. See Case 3 for three or more parallel units. If one of the two units also has a wall ading it, see Case 1. Add the two adjustment factors together and apply to the unit located between the wall and the other unit. Mounting units end to end will not necessitate adjusting performance. Depending on the actual arrangement, sufficient space must be left between the units for access to the control door opening. See “Clearance” section of this guide for requirements for specific units.

Figure 23, Two Units Side by Side

Figure 24, Adjustment Factor

3.0

6.0

2.0

4.0

1.0

2.0

0

Catalog ACZ-4

0

9 ACZ 090-155 (2.7)

10 (3.0)

11 (3.3)

12 (3.6)

9 ACZ 090-155 (2.7)

10 (3.0)

11 (3.3)

12 (3.6)

ACZ 010-080 6.5 (2.0)

7 (2.1)

7.5 (2.2)

8 (2.4)

ACZ 010-080 6.5 (2.0)

7 (2.1)

7.5 (2.2)

8 (2.4)


63

Case 3, Three or More Units Side By Side When three or more units are side by side, the outside units (1 and 3 in this case) are influenced by the middle unit only on their inside circuits. Their adjustment factors will be the same as Case 2. All inside units (only number 2 in this case) are influenced on both sides and must be adjusted by the factors shown below. Figure 25, Three or More Units


4.0

8.0

3.0

6.0

2.0

4.0

1.0

2.0

0 15 (4.6)

16 (4.9)

17 (5.2)

18 (5.5)

0 ACZ 090-155 (0.0)

15 (4.6)

16 (4.9)

17 (5.2)

18 (5.5)

0 (0.0)

11 (3.3)

12 (3.7)

13 (4.0)

14 (4.3)

ACZ 010-080

0 (0.0)

11 (3.3)

12 (3.7)

13 (4.0)

14 (4.3)

ACZ 010-080

64

0

0 ACZ 090-155 (0.0)


Catalog ACZ-4

Case 4, Open Screening Walls Decorative screening walls are often used to help conceal a unit either on grade or on a rooftop. These walls should be designed such that the combination of their open area and distance from the unit do not require performance adjustment. It is assumed that the wall height is equal to or less than the unit height when mounted on its base . This is usually satisfactory for concealment. If the wall height is greater than the unit height, see Case 5, Pit Installation. The distance from the ends of the unit to the end walls should be sufficient for service and opening control doors. If each side wall is a different distance from the unit, the distances can be averaged providing either wall is not less than 8 feet (2.4 meters) from the unit. For example, do not average 4 feet and 20 feet to equal 12 feet. Figure 27, Open Screening Walls

,Figure 28, Wall Free Area vs Distance ACZ 030-080

ACZ 090-155

4 (1.2)

6 (1.8)

3.5 (1.0)

5 (2.0)

3.0 (0.9)

4 (1.2)

2.5 (0.7)

3 (0.9) 0

Catalog ACZ-4

10

20


30

40

50

65

Case 5, Pit/Solid Wall Installation Pit installations can cause operating problems and great care should be exercised if they are to be used on an installation. Recirculation and restriction can both occur. A solid wall surrounding a unit is substantially the same as a pit and the data presented here should be used. Steel grating is sometimes used to cover a pit to prevent accidental falls or trips into the pit. The grating material and installation design must be strong enough to prevent such accidents, yet provide abundant open area or serious recirculation problems will occur. Have any pit installation reviewed by McQuay application engineers prior to installation to make sure it has sufficient air-flow characteristics. The installation design engineer must approve the work to avoid an unreasonable risk of accident. Figure 29, Pit Installation


ACZ 010-080

D=4 (1.4)

D=5 (2.0)

ACZ 010-080

D=4 (1.4)

D=5 (2.0)

ACZ 090-155

D=6 (1.8)

D=8 (2.4)

ACZ 090-155

D=6 (1.8)

D=8 (2.4)

ACZ ACZ 090-155 010-080 D=10 D=7 (3.1) (2.1)

66


ACZ ACZ 090-155 010-080 D=10 D=7 (3.1) (2.1)

Catalog ACZ-4

Refrigerant Piping Proper refrigerant piping makes the difference between a reliable or an inefficient problematic system. The primary concerns related to piping are refrigerant pressure drop, a solid liquid feed to the expansion valves, continuous oil return and properly sized refrigerant specialties. The recommended source for refrigerant piping techniques and sizing is the ASHRAE 2002 Refrigeration Handbook, chapter #2. Refrigerant specialties including the expansion valves, solenoid valves, filter drier and sight glasses for use with the remote evaporator applications are supplied and installed by the installing contractor. The remaining components including pipe, insulation, fittings and Schrader valves are also provided and piped by the installer. The optional hot gas by valve with solenoid valve can be provided as a field installed or factory installed option. A holding charge of R22 is provided for the unit. The installer must properly evacuate the piping system and provide the operating charge of R22. Although conflicting piping recommendations can be found in different sources, McQuay offers the following recommendations for these controversial issues. The use of double risers for vertical gas risers is generally not required and should be used only as a last resort to maintain the minimum refrigerant flow to carry oil up the vertical risers. Slightly downsizing the vertical riser is a superior option to providing double risers. Slope the refrigerant lines 1” per 10 feet of horizontal run in the direction of refrigerant flow to assist oil return. Resist using hot gas by for applications when operation in ambient temperature below 40 degrees is expected. This recommendation helps to maintain adequate condensing pressures and liquid refrigerant at the expansion valve when condenser capacities are at their maximum. Pressure drops in the refrigerant lines should be maintained at or below the ASHRAE recommendations and line lengths should be made as short as possible. Exceeding these recommendations will decrease performance and could impact reliability. Small traps should be provided at the base of each major vertical gas riser to assist in the collection of oil. If vertical risers exceed more than 25 feet, install a small trap at the midpoint and not to exceed more than 20 feet intervals. Use caution in sizing the liquid line in applications where the evaporator is above the outdoor section. The weight of the liquid refrigerant in the vertical column will decrease the pressure at the top of the riser (approximately .5 PSI per foot of vertical rise) allowing some of the refrigerant to flash to a gas. Adequate refrigerant subcooling is needed at the outdoor section to prevent large volumes of refrigerant gas at the expansion valve. It is recommended that the piping systems always extend above the highest component in the refrigeration system before dropping down to make the final refrigerant connections to components. This practice will hinder the draining of condensed refrigerant to the lower component when normal shutdown procedures do not occur (such as a power failure). NOTE: Do not run refrigerant piping underground.

Operating/Standby Limits Maximum standby ambient air temperature, 130°F (5 5°C) Maximum operating ambient air temperature Standard Ambient Unit, 105°F (40.6°C) and below, Models BC High Ambient Unit, above 105°F (40.6°C) to 125°F 51.7°C), Models BH

Catalog ACZ-4


67

Minimum operating ambient temperature (standard), 35°F (2°C) Minimum operating ambient temperature (with optional low-ambient control), 0°F (-18°C)

Vibration Isolators Vibration isolators are recommended for all roof-mounted installations or wherever vibration transmission is a consideration. The unit should be initially on shims or blocks at the listed free height. When all piping, wiring, flushing, charging, etc. is completed, the springs are adjusted upward to loosen the blocks or shims that are then removed. A rubber anti-skid pad is part of the isolator. Installation of spring isolators requires flexible piping connections and at least three feet of flexible conduit to avoid straining the piping and transmitting vibration and noise.

Isolator Installation The unit should be initially installed on shims or blocks at the listed free height. When all piping, wiring, flushing, charging, etc. is completed, adjust the springs upward to load them and to provide clearance to remove the shims or blocks. Installation of spring isolators requires flexible piping connections and at least three feet of conduit flex tie-ins. Piping and conduit must be ed independently of the unit. Bolting: If the chiller base is to be bolted to the isolators, it is recommended that the short threaded studs usually found on isolators be replaced with eight-inch threaded rod that can extend through the holes on the top of the base and then be bolted. Washers will be required. Models ACZ 010 through 039 cannot be bolted to the isolators.

Models ACZ 010 - 039 Corner Operating Weights ACZ Unit Model 010 013 016 020 025 028 033 039

RF

LF

RB

LB

Total

259 259 353 377 498 508 605 712

257 257 360 383 505 515 567 649

243 243 251 288 232 232 304 313

241 241 256 292 235 235 284 286

1000 1000 1220 1340 1470 1490 1760 1960

RP-3, Neoprene-in Shear Isolator

68


R IB

RIF Control

L IB

LIF

-1, Spring Isolator

Catalog ACZ-4

Table 41, Isolator Loads At Each Mounting Location (With Aluminum Fins) ACZ-B Model

AGZ-BM Model

ACZ 030

AGZ 026

ACZ 035

AGZ 030

ACZ 040 ACZ 045 ACZ 050 ACZ 055 ACZ 060 ACZ 065

AGZ 035 AGZ 040 AGZ 045 AGZ 050 AGZ 055 AGZ 060

ACZ 070

AGZ 065

ACZ 080

AGZ 070

Shipping Wt

Operating. Wt

Loc. 1

Loc. 2

Loc. 3

Loc. 4

Total

(1) Add’l for Copper Fins

lbs

3550

3600

1227

901

849

623

3600

72

kg

1608

1631

556

408

385

282

1631

32

lbs

3550

3600

1227

901

849

623

3600

72

kg

1608

1631

556

408

385

282

1631

32

lbs

3550

3600

1227

901

849

623

3600

72

kg

1608

1631

556

408

385

282

1631

32

lbs

3550

3610

1261

872

873

604

3610

72

kg

1608

1635

571

395

395

274

1635

32

lbs

3590

3650

1275

881

883

611

3650

72

kg

1626

1653

578

399

400

277

1653

32

lbs

3730

3800

1295

951

896

658

3800

119

kg

1690

1721

587

431

406

298

1721

54

lbs

3780

3850

1303

1016

860

671

3850

119

kg

1712

1744

590

460

390

304

1744

54

lbs

3820

4040

1367

1066

903

704

4040

142

kg

1730

1830

619

483

409

319

1830

65

lbs

3970

4070

1305

1146

862

757

4070

142

kg

1798

1844

591

519

390

343

1844

65

lbs

4080

4180

1278

1192

885

825

4180

217

kg

1848

1894

579

540

401

374

1894

99

NOTE (1): Additional weight for copper coils is per mounting location.

Table 42, Isolator Loads At Each Mounting Location (With Aluminum Fins) ACZ Model

AGZ-BM Model

ACZ090

AGZ 075

ACZ100

AGZ 085

ACZ110

AGZ 090

ACZ120

AGZ 100

ACZ130

AGZ 110

ACZ140

AGZ 120

ACZ155

AGZ 130

Shipping Operating Loc 1 Wt. Wt.

Loc 2

Loc 3

Loc 4

Loc 5

Loc 6

(1) Add’l for TOTAL Copper Fins

lbs

5510

5630

1649

1166

1649

1166

-

-

5630

kg

2496

2550

747

528

747

528

-

-

2550

217 99

lbs

5670

5790

1734

1227

1657

1172

-

-

5790

217

kg

2569

2623

786

556

751

531

-

-

2623

99

lbs

5830

5950

1770

1205

1770

1205

-

-

5950

217

kg

2641

2695

802

546

802

546

-

-

2695

99

lbs

6820

6970

1323

1188

1053

1265

1135

1006

6970

289

kg

3089

3157

599

538

477

573

514

456

3157

131

lbs

7080

7230

1396

1205

1014

1396

1205

1014

7230

289

kg lbs kg

3207 7360 3334

3275 7480 3388

632 1477 669

546 1275 578

459 1073 486

632 1411 639

546 1218 552

459 1026 465

3275 7480 3388

131 289 131

lbs

7640

7760

1555

1293

1032

1555

1293

1032

7760

289

kg

3461

3515

704

586

467

704

586

467

3515

131

NOTE (1): Additional weight for copper coils is per mounting location.

Catalog ACZ-4


69

Optional Features Controls Hot Gas By Hot gas by permits unit operation down to 10% of full load capacity. This option includes a factory-installed hot gas by valve, solenoid valve, and manual shutoff valve for each circuit. Interconnecting piping to an evaporator is field installed.

Head Pressure Control Optional SpeedTrol head pressure (on ACZ 010A to 039A) or fan VFD control (ACZ 030B to 155B) allows unit operation down to 0°F (-18°C). (Not available on 380 volt, 60 Hertz units.)

Alarm Bell Field installed and wired to the control to provide remote indication of unit alarm condition.

Remote Operator Interface A remote interface , field wired to the unit, providing all the data viewable on the unit’s controller, including alarm clearing and setpoint change capability. See page 11 for details.

BAS Interface (Protocol Selectability™ ) A module is factory installed on the MicroTech II™ controller to provide direct interface to the following standard protocols: Also available as a field installed kit. BACnet/IP

BACnet MS/TP

LONTALK (FTT-10A)

Modbus

BACnet Ethernet

Unit Vibration Isolators Spring or neoprene-in-shear vibration isolators are available for field installation to reduce vibration transmission through the unit base.

Protective Base Guards (ACZ 030B to 155B only) Optional factory installed vinyl-coated welded wire base guards provide all-around lower unit protection on ground level installations. Coil guards are standard.

Louvers/Hail Guard/Wind Baffles Available for the upper portion (condenser coils) and/or lower portion of unit on ACZ 030B through 155B. Selecting both will completely enclose the unit with louvers. Models ACZ 010A through 039A have louvers covering the coil only, which due to the unit design, effectively encloses the entire unit. The louvers improve unit appearance, protect the coils from hail damage and also stabilize operation during windy, low ambient operation. See page 3 for photograph.

Hail and Wind Guards (ACZ 030B – 155B only) Field-mounted box type hail and wind guards shipped as a kit for field assembly, including s, fasteners, and instructions. The guards add 20 inches to each side of the unit.

70


Catalog ACZ-4

Copper Fin Condenser Coils Copper fin condenser coils are available as an option on all models.

Black Fin Coils Aluminum fin stock precoated with a phenolic coating with 1000-hour salt spray resistance (ASTM B117-90).

Coated Fins Copper or aluminum fins coated with ElectroFin® baked epoxy protective coating with 5000-hour salt spray resistance (ASTM B117-90).

Sound Reduction Acoustical blankets are factory-installed on each compressor. They are also available for retrofit field installation.

Electrical Multi-Point Electrical Connection (ACZ 030B –155B only) Provides a power connection to each of the unit’s two electrical circuits.

Disconnect Switch with Through-the-Door Handle A factory or field installed option for service use, nonfused disconnect switch (mounted inside the power section of the control box) with a through-the-door handle is available with single and multi-point power supply only.

Phase Loss/Voltage Protection (P/N 350015201) Phase loss with under/over voltage protection and multiple LED indication of fault type is available as a factory installed option to guard against compressor motor burnout.

Convenience Outlet (ACZ 030B – 155B only) 10.0 amp, 115 volt outlet located in control to provide power for servicing unit.

Ground Fault Protection (ACZ 030B – 155B only) Protects equipment from damage from low level line-to-ground fault currents, less than those required for conductor protection and quickly shuts off power.

High Ambient Control Consists of exhaust fan with rain hood, two inlet screens with filters, necessary controls and wiring. The option can be factory installed or field installed as a kit. Must be used for: •

All ambient temperatures above 105°F (40°C) with fan VFD (low ambient option)

•

Ambient temperatures above 115°F (46°C) with standard FanTrol control.

High Short Circuit Current Protection Provides control protection against short circuit currents per following table:

Catalog ACZ-4

Voltage

208

240

460

600

Current (kA)

120

100

65

35


71

Product Specification Specifications are available in MSWord format. the local McQuay sales office.

SECTION 15XXX AIR-COOLED SCROLL COMPRESSOR CONDENSING UNITS ACZ 010A-ACZ 155B PART 1 - GENERAL 1.01

SUMMARY Section includes design, performance criteria, refrigerants, controls, and installation requirements for air-cooled scroll compressor condensing units.

1.02

REFERENCES Comply with applicable Standards/Codes of ARI 365-94, ANSI/ASHRAE 15, ETL, cETL, NEC, and OSHA as adopted by the State. Units shall meet the efficiency standards of ASHRAE Standard 90.1.

1.03

SUBMITTALS A.

Submit shop drawings and product data in accordance with the specifications.

B.

Submittals shall include the following: 1.

Dimensioned plan and elevation view drawings, required clearances, and location of all field connections.

2.

Summary of all auxiliary utility requirements, such as electricity, water, compressed air, etc. Summary shall indicate quality and quantity of each required utility.

3.

Single-line schematic drawing of the power field hookup requirements, indicating all items that are furnished.

4.

Schematic diagram of control system indicating points for field interface/connection.

1.04

5.

Diagram shall fully delineate field and factory wiring.

6.

Installation manuals.

QUALITY ASSURANCE A.

Qualifications: Equipment manufacturer must specialize in the manufacture of the type of products specified and have five years experience with similar equipment and refrigerant offered.

72

B.

Regulatory Requirements: Comply with the codes and standards specified.

C

Manufacturer's plant must be ISO ed.


Catalog ACZ-4

1.05

DELIVERY AND HANDLING A.

Condensing units shall be delivered to the job site assembled and charged with a holding charge of refrigerant and full oil charge by the manufacturer.

B.

1.06.

Comply with the manufacturer's instructions for rigging and handling equipment.

WARRANTY The refrigeration equipment manufacturer’s guarantee shall be for a period of one year from date of equipment start-up but not more than 18 months from shipment. The guarantee shall provide for repair or replacement due to failure by material and workmanship that prove defective within the above period, excluding refrigerant.

1.07

MAINTENANCE Maintenance of the units shall be the responsibility of the owner and performed in accordance with the manufacturer’s instructions.

PART 2--PRODUCTS 2.01

2.02

ACCEPTABLE MANUFACTURERS A.

McQuay International

B.

(Approved Equal)

UNIT DESCRIPTION Provide and install as shown on the plans factory-assembled, air-cooled scroll compressor condensing units in the size and quantity specified. Each unit shall consist of hermetic tandem or triple scroll compressor sets, air-cooled condenser section, control system and all components necessary for controlled unit operation when field piped and wired to low side equipment specified elsewhere.

2.03

DESIGN REQUIREMENTS A.

General: Provide a complete scroll-compressor condensing unit as specified herein and as shown on the drawings. The unit shall be in accordance with the standards referenced in section 1.02 and any local codes in effect.

B.

Performance: Refer to the schedule of performance on the drawings. The unit shall be capable of stable operation to a minimum of 50 percent of full load without hot gas by. Performance shall be in accordance with ARI Standard 365-94.

C.

Acoustics: Sound pressure levels for the unit shall not exceed the following specified levels. The manufacturer shall provide the necessary sound treatment to meet these levels if required. Sound data shall be provided with the quotation. Test shall be in accordance with ARI Standard 370.

Catalog ACZ-4


73

Octave Band 63 ____

125 ____

250 ____

500 ____

1000 ____

2000 ____

4000 ____

8000 ____

dBA ____

2.04 CONDENSING UNIT COMPONENTS A. Compressors: The compressors shall be sealed hermetic scroll type with crankcase oil heater and suction strainer. Compressor shall have a forced-feed lubrication system with integral oil pump and oil charge. The compressor motor shall be refrigerant gas cooled, high torque, hermetic induction type, two-pole, with inherent thermal protection on all three phases and shall be mounted on RIS vibration isolator pads. B.

Condenser: The condenser coils shall consist of 3/8 inch (10mm) seamless copper tubes mechanically bonded into plate-type fins. The fins shall have full drawn collars to completely cover the tubes. A subcooling coil shall be an integral part of the main condenser coil. Condenser fans shall be propeller type arranged for vertical air discharge and individually driven by direct-drive fan motors. They shall be equipped with a heavy-gauge fan guard. Fan motors shall be TEAO, threephase, direct-drive, 1140 rpm.

D.

Refrigerant Circuit: Capped connections shall be provided for field connection of refrigerant piping. Refrigerant specialties shall be field supplied and installed.

E.

Control System: A centrally located weatherproof control shall contain the field power connection points, control interlock terminals, and control system. Power and starting components shall include factory short circuit protection of fan motors and control circuit, individual ors for each fan motor, solid-state compressor three-phase motor overload protection, inherent fan motor overload protection and unit power connections for connection to remote disconnect switch. Hinged access doors shall be tool-lockable. Barrier s or separate doors are required to protect against accidental with line voltage when accessing the control system.

F.

An advanced DDC microprocessor unit controller with a 4-line by 20-character liquid crystal display provides the operating and protection functions. The controller shall be capable of receiving a 4 to 20 mA signal for demand limiting and be remotely enabled with a digital input. The controller shall take pre-emptive limiting action in case of high discharge pressure or low evaporator pressure. The controller shall contain the following features as a minimum: Equipment Protection The unit shall be protected in two ways: (1) by alarms that shut the unit down and require manual reset to restore unit operation and (2) by limit alarms that reduce unit operation in response to some out-of-limit condition. Shut down alarms shall activate an alarm signal.

74


Catalog ACZ-4

Shutdown Alarms • Low evaporator pressure • High condenser pressure • Motor protection system • Phase voltage protection (Optional) • Outside ambient temperature • Sensor failures Limit Alarms • Condenser pressure stage down, unloads at high discharge pressures • Low ambient lockout, shuts off unit at low ambient temperatures • Low evaporator pressure hold, holds stage #1 until pressure rises • Low evaporator pressure unload, shuts off one compressor Unit Enable Selection Enables unit operation from either local keypad, digital input, or BAS Unit Mode Selection Selects standard cooling or test operation mode Digital Inputs • Unit off switch • Remote start/stop • Motor protection Digital Outputs • Shutdown alarm; field wired, activates on an alarm condition, off when alarm is cleared Condenser fan control The unit controller shall provide control of condenser fans based on compressor discharge pressure. Building Automation System (BAS) Interface Factory mounted DDC controller(s) shall operation on a BACnet®, Modbus® or LONMARKS ® network via one of the data link / physical layers listed below as specified by the successful Building Automation System (BAS) supplier.

• • • •

BACnet MS/TP master (Clause 9) BACnet IP, (Annex J) BACnet ISO 8802-3, (Ethernet) LONMARKS FTT-10A. The unit controller shall be LONMARKS® certified.

The information communicated between the BAS and the factory mounted unit controllers shall include the reading and writing of data to allow unit monitoring, control and alarm notification as specified in the unit sequence of operation and the unit points list. For chillers communicating over a LONMARK network, the corresponding LONMARK eXternal Interface File (XIF) shall be provided with the chiller submittal data. All communication from the chiller unit controller as specified in the points list shall be via standard BACnet objects. Proprietary BACnet objects shall not be allowed. BACnet communications shall conform to the BACnet protocol (ANSI/ASHRAE135-2001). A BACnet Protocol Implementation Conformance Statement (PICS) shall be provided along with the unit submittal. 2.05

Catalog ACZ-4

OPTIONS AND ACCESSORIES


75

The following options are to be included: •

Hot gas by to allow unit operation to 10 percent of full load

•

Low ambient head pressure control to 0°F (-17.8°C)

•

Non-fused disconnect switch with through-the-door handle

•

Aluminum fins pre-coated with a phenolic epoxy coating with 1000 hour salt spray rating (ASTM B117-90

•

Copper fin condenser coils

•

ElectroFin™ baked epoxy coating providing 3000+ hour salt spray resistance (ASTM B117-90) and is applied to both the coil and the coil frames.

•

Spring vibration isolators for field installation

•

Neoprene-in-shear vibration isolators for field installation

•

Hail and wind guards

•

Full louvers for top and bottom of unit

•

High short circuit current protection

•

Remote operator interface

•

BAS interface module for standard protocols

•

Sound reduction blankets for compressors

•

115V convenience outlet

PART 3 - EXECUTION 3.01

INSTALLATION A.

Install in strict accordance with manufacturer’s requirements, shop drawings, and contract documents.

3.02

B.

Adjust and level unit in alignment on s.

C.

Coordinate electrical installation with electrical contractor.

D

Coordinate controls with control contractor.

E.

Provide all appurtenances required for a fully operational and functional unit.

START-UP A.

Install proper charge of refrigerant and oil.

B.

Provide testing and starting of machine, and instruct the Owner in its proper operation and maintenance.

76


Catalog ACZ-4

Catalog ACZ-4


77

78


Catalog ACZ-4

Catalog ACZ-4


79

This document contains the most current product information as of this printing. For the most up-todate product information, please go to www.mcquay.com.

¤2005 McQuay International • (800) 432-1342 • www.mcquay.com

Catalog ACZ-4 (12/05)

Cat-acz-4 2b6c5r

Overview 3e4r5l

More details w3441

More Documents from "Sandra Ferrell" 6qd5

Cat-acz-4 2b6c5r

Recepcion Del Derecho Romano 6k611o

Yann Tiersen - Toujours La 2k5s61

Codigos Norma Din Eletrica Automotiva 131g3a

P.e.i Misael Pastrana Borrero 1w399

Catalogo Baterias Velox 1v694t
